Rohde&Schwarz FSIQ3, FSIQ7, FSIQ26, FSIQ40 Operating Manual

Test and Measurement
Division

Operating Manual

SIGNAL ANALYZER

FSIQ3

1119.5005.13

FSIQ7

1119.5005.17

FSIQ26

1119.6001.27

FSIQ40

1119.6001.40

Printed in the Federal
Republic of Germany

1119.5063.12-02- 1 1/00

FSIQ Tabbed Divider Overview

Tabbed Divider Overview

Contents

Data Sheet

Safety Instructions
Certificate of Quality
EU Certificate of Conformity
List of R&S Representatives

Manuals for Signal Analyzer FSIQ

Tabbed Divider

1 Chapter 1: Putting into Operation

2 Chapter 2: Getting Started

3 Chapter 3: Operation

4 Chapter 4: Functional Description

5 Chapter 5: Remote Control – Basics

6 Chapter 6: Remote Control – Commands

7 Chapter 7: Remote Control – Program Examples

8 Chapter 8: Maintenance and Hardware Interfaces

9 Chapter 9: Error Messages

10 Index

1119.5065.12 RE E-2

Before putting the product into operation for

the first time, make sure to read the following

Safety Instructions

Rohde & Schwarz makes every effort to keep the safety standard of its products up to date and to offer
its customers the highest possible degree of safety. Our products and the auxiliary equipment required
for them are designed and tested in accordance with the relevant safety standards. Compliance with
these standards is continuously monitored by our quality assurance system. This product has been
designed and tested in accordance with the EC Certificate of Conformity and has left the manufacturer’s
plant in a condition fully complying with safety standards. To maintain this condition and to ensure safe
operation, observe all instructions and warnings provided in this manual. If you have any questions
regarding these safety instructions, Rohde & Schwarz will be happy to answer them.

Furthermore, it is your responsibility to use the product in an appropriate manner. This product is
designed for use solely in industrial and laboratory environments or in the field and must not be used in
any way that may cause personal injury or property damage. You are responsible if the product is used
for an intention other than its designated purpose or in disregard of the manufacturer's instructions. The
manufacturer shall assume no responsibility for such use of the product.

The product is used for its designated purpose if it is used in accordance with its operating manual and
within its performance limits (see data sheet, documentation, the following safety instructions). Using
the products requires technical skills and knowledge of English. It is therefore essential that the
products be used exclusively by skilled and specialized staff or thoroughly trained personnel with the
required skills. If personal safety gear is required for using Rohde & Schwarz products, this will be
indicated at the appropriate place in the product documentation.

Observe
operating
instructions

Supply
voltage
ON/OFF

Weight
indication for
units >18 kg

Standby
indication

Symbols and safety labels

Danger of
electric
shock

Direct
current
(DC)

Warning!
Hot
surface

PE terminal Ground

Alternating
current (AC)

Direct/alternating
current (DC/AC)

Ground
terminal

Device fully
protected by
double/reinforced
insulation

Attention!
Electrostatic
sensitive
devices

1171.0000.42-02.00 Sheet 1

Safety Instructions

Observing the safety instructions will help prevent personal injury or damage of any kind caused by
dangerous situations. Therefore, carefully read through and adhere to the following safety instructions
before putting the product into operation. It is also absolutely essential to observe the additional safety
instructions on personal safety that appear in other parts of the documentation. In these safety
instructions, the word "product" refers to all merchandise sold and distributed by Rohde & Schwarz,
including instruments, systems and all accessories.

Tags and their meaning

DANGER

WARNING

CAUTION This tag indicates a safety hazard with a low potential of risk for the user

ATTENTION

NOTE

These tags are in accordance with the standard definition for civil applications in the European
Economic Area. Definitions that deviate from the standard definition may also exist. It is therefore
essential to make sure that the tags described here are always used only in connection with the
associated documentation and the associated product. The use of tags in connection with unassociated
products or unassociated documentation can result in misinterpretations and thus contribute to personal
injury or material damage.

This tag indicates a safety hazard with a high potential of risk for the
user that can result in death or serious injuries.

This tag indicates a safety hazard with a medium potential of risk for the
user that can result in death or serious injuries.

that can result in slight or minor injuries.

This tag indicates the possibility of incorrect use that can cause damage
to the product.

This tag indicates a situation where the user should pay special attention
to operating the product but which does not lead to damage.

Basic safety instructions

1. The product may be operated only under
the operating conditions and in the
positions specified by the manufacturer. Its
ventilation must not be obstructed during
operation. Unless otherwise specified, the
following requirements apply to
Rohde & Schwarz products:
prescribed operating position is always with
the housing floor facing down, IP protection
2X, pollution severity 2, overvoltage
category 2, use only in enclosed spaces,
max. operation altitude max. 2000 m.
Unless specified otherwise in the data
sheet, a tolerance of ±10% shall apply to
the nominal voltage and of ±5% to the
nominal frequency.

2. Applicable local or national safety
regulations and rules for the prevention of
accidents must be observed in all work
performed. The product may be opened
only by authorized, specially trained
personnel. Prior to performing any work on
the product or opening the product, the

product must be disconnected from the
supply network. Any adjustments,
replacements of parts, maintenance or
repair must be carried out only by technical
personnel authorized by Rohde & Schwarz.
Only original parts may be used for
replacing parts relevant to safety (e.g.
power switches, power transformers,
fuses). A safety test must always be
performed after parts relevant to safety
have been replaced (visual inspection, PE
conductor test, insulation resistance
measurement, leakage current
measurement, functional test).

3. As with all industrially manufactured goods,
the use of substances that induce an
allergic reaction (allergens, e.g. nickel)
such as aluminum cannot be generally
excluded. If you develop an allergic
reaction (such as a skin rash, frequent
sneezing, red eyes or respiratory
difficulties), consult a physician immediately
to determine the cause.

1171.0000.42-02.00 Sheet 2
