R&S FSH-K1 Enabling Remote Control Option R&S FSH-K1
Contents
Enabling Remote Control Option R&S FSH-K1 ....................................................................................1
Connecting PCs ....................................................................................................................................2
Installation of the driver for the USB optical cable (R&S FSH-Z37) ..............................................2
Serial Port Configuration ...............................................................................................................2
Notational Conventions .........................................................................................................................3
Starting Remote Control Operation ...............................................................................................3
Device Messages ..................................................................................................................................4
Acknowledge Response <ack> .....................................................................................................4
Timeout..........................................................................................................................................4
Functional Description of Commands ...........................................................................................5
Parameter Overview..............................................................................................................................7
Get / Set Parameter.......................................................................................................................7
Get Parameter .............................................................................................................................10
CMD Commands .........................................................................................................................12
Command Description .........................................................................................................................13
General Commands ....................................................................................................................13
Frequency and Span Settings .....................................................................................................18
Amplitude Settings.......................................................................................................................21
Bandwidth Settings ......................................................................................................................25
Sweep Settings............................................................................................................................28
Trace Settings..............................................................................................................................30
Marker..........................................................................................................................................36
Measurement...............................................................................................................................45
Tracking Generator......................................................................................................................52
Power Sensor ..............................................................................................................................58
Channel Power ............................................................................................................................60
Occupied Bandwidth....................................................................................................................62
TDMA Power ...............................................................................................................................64
Distance To Fault Measurement .................................................................................................66
Receiver Mode.............................................................................................................................68
Carrier / Noise Measurement ......................................................................................................71
WCDMA BTS CDP Measurement ...............................................................................................76
Programming Examples ......................................................................................................................82
1157.3564.12 I.1 E-10
R&S FSH-K1 Enabling Remote Control Option R&S FSH-K1
Enabling Remote Control Option R&S FSH-K1
The R&S FSH spectrum analyzer can be fitted with the Remote Control Option R&S FSH-K1, which is
enabled by entering a key code. The key code is based on the unique serial number of the instrument.
To retrofit an option, enable it with a key code.
Operation
Press the GENERAL key.
Use the Rotary knob or the Cursor keys to select the OPTIONS... menu item and confirm the entry
with the ENTER key.
Enter the key code (ten-digit number) for the option with the decimal keys and confirm with the ENTER
key.
If the correct key code is entered, the R&S FSH displays "Remote Control enabled".
If an invalid key code is entered, the R&S FSH displays "Option key error".
The correct key code can then be entered.
1157.3564.12 1 E-10
Connecting PCs R&S FSH-K1
Connecting PCs
The R&S FSH can be remote controlled by a PC or Laptop equipped with an USB interface or a RS232
interface.
RS232 optical interface
The RS232 optical interface is used for connecting a PC or Laptop. The interface connector is located
at the right-hand side of the R&S FSH, it can be accessed by folding out the support.
The USB Optical Interface Cable R&S FSH-Z37 (supplied with the R&S FSH) or the RS232 Optical
Interface Cable R&S FSH-Z34 are used to make the connection. The optical connection prevents
spurious measurements being caused by interference from these devices.
Fold out the support at the rear of the
R&S FSH.
Connect the optical connector of the
RS-232 cable to the optical interface
on the right-hand side of the
R&S FSH.
Connect the USB connector of the
cable to the USB connector of the PC
(R&S FSH-Z37) or the 9-pin D-Sub
connector of the cable to the RS-232
connector of the PC (R&S FSH-Z34).
For the USB cable R&S FSH-Z37:
Install the USB driver supplied on the
R&S FSH CD-ROM.
Installation of the driver for the USB optical cable (R&S FSH-Z37)
The USB driver available on the R&S FSH CD-ROM emulates a serial COM port on the PC. In order to
install the driver on a PC equiped with Windows XP or Windows 2000 please proceed as follows:
Connect the optical USB cable to the PC. The hardware installation wizzard will pop up and state
that it has found a USB to serial bridge.
Insert the R&S FSH CD-ROM.
Select “automatic software installation” and press “Next”. The installation wizzard will automatically
search for the necessary driver and install it.
In case that the wizzard does not find the driver files you will be prompted for manual entry of the
corresponding path. The driver is located on the CD-ROM in folder “\drivers\USB”.
Press “Finish” in order to finalize the installation. The USB cable is now ready for use.
Serial Port Configuration
The serial interface configuration on the PC should be set to
8 data bits, 1 stop bit, no parity
The baud rate can be configured via the Setup menu on the R&S FSH or the SET BAUD command.
The baud rates can be 9.600, 19.200, 38.400, 57.600 or 115.200 Baud. The default baud rate is 19.200
Baud
1157.3564.12 2 E-10
R&S FSH-K1 Notational Conventions
Notational Conventions
The following section describes the notational conventions as they are used throughout this document.
eta Symbol
M
:= Equals
| Separator for selectable items
“...” Characters between “ “ are taken as they are, but the “ “ are excluded
[...] Specifies an optional element
{...} Specifies an element that may be repeated.
pecification
S
(example “,” means an ASCII comma).
Item Description
<character> ‘0’ .. ‘9’, ‘a’ .. ‘z’, ‘A’ .. ‘Z’
<string> <character> { <character> }
<sign> ( ‘+’ | ‘-’ )
<digit> ‘0’ .. ‘9’
<numeric value> [ <sign> ] <digit> { <digit> } [ . { <digit> } ] [ e | E [ <sign> ] { <digit>} ]
Starting Remote Control Operation
On power-on, the R&S FSH is always in the manual operation state (“LOCAL” state) and can be
operated via the front panel.
If the R&S FSH receives a remote command the
instrument remains in local state. It is switched to
remote state as soon as it receives the command
“REMOTE” from the PC.
In remote state the front panel access is disabled.
The R&S FSH can be switched back to local state
by sending the LOCAL command.
1157.3564.12 3 E-10
Device Messages R&S FSH-K1
Device Messages
The remote control command set of the R&S FSH can be grouped into three categories:
• SET commands
SET commands are used to program parameters of the instrument like
center frequency, span, etc.
• GET commands
GET commands are used to query current settings and data from the instrument like
center frequency, marker, trace data, etc.
• CMD commands
CMD commands are used to initiate an action or a state transition in the instrument like
marker-to-peak, preset, remote state, etc.
Acknowledge Response <ack>
After receiving a SET, GET or CMD command the R&S FSH responds with an “acknowledge”
message. The acknowledge message consists of an ASCII digit (“0” for no error) followed by a Carriage
Return <cr>. The response message indicates if the command or parameter is valid.
A second acknowledge response is generated after the command parameter.
<ack> response:
“0” No Error.
“1” Syntax Error. This response is generated when the command sent to the instrument is not
known or when the timeout on data reception expired. It is also generated, when the
parameter or value for the command are in the wrong data format.
“2” Execution Error. The command sent is not allowed in the current measurement mode.
“3” Dataset Storage Full. This response is generated when the dataset storage is full.
“4” Not Allowed. In the current state of the R&S FSH setting this parameter or value is not
allowed.
“5” Out Of Range. The parameter value is out of range and cannot be programmed.
Timeout
To prevent any lockups in the communication between PC and instrument the data transfer via the
serial interface is monitored by the R&S FSH. There is a timeout time of 60 seconds on every byte
received by the instrument. When the time between 2 bytes in a command or parameter send exceeds
60 seconds the R&S FSH will respond with a ‘Syntax Error’ acknowledge message (“1”<cr>).
Note: When using remote control commands and the sweep time is less than 30 ms (e.g. Zero
span) the measurement will stop until the complete command is received (in this case all
interrupts are switched off due to the processing of all data points).
1157.3564.12 4 E-10
R&S FSH-K1 Device Messages
Functional Description of Commands
The command strings and parameter strings are not case sensitive, eg ‘Freq’ is similar to ‘FREQ’.
GET Command
GET commands are used to query parameter settings or measured data from the instrument.
Program syntax: get<cr>
Response syntax: <ack><cr>
Program syntax: <parameter><cr>
<parameter> := <string>
This is one of the parameters defined in the following section.
Response syntax: <ack><cr>
<value><cr>
<value>:= This field depends on the type of parameter, see the specific value
descriptions
Example: This command queries the unit from the instrument.
get<cr> (send ‘get’ command)
0<cr> (responds ‘command ok’)
UNIT<cr> (send parameter ‘UNIT’)
0<cr> (responds ‘parameter ok’)
6<cr> (responds UNIT value ‘Volt’)
SET Command
SET commands are used to program parameter and setup settings of the instrument.
Program syntax: set<cr>
Response syntax: <ack><cr>
Program syntax: <parameter>,<value><cr>
<parameter> := <string>
This is one of the parameters defined in the following section.
<value>:= This field depends on the type of parameter, see the specific value
descriptions
Response syntax: <ack><cr>
Example: This command sets the unit to Watt.
set<cr> (send ‘set’ command)
0<cr> (responds ‘command ok’)
UNIT,7<cr> (send parameter ‘UNIT’ value is ‘Watt’)
0<cr> (responds ‘parameter ok’)
1157.3564.12 5 E-10
Device Messages R&S FSH-K1
CMD Command
CMD commands are used to initiate an action or a state transition on the instrument.
Program syntax: cmd<cr>
Response syntax: <ack><cr>
Program syntax: <parameter>,<value><cr>
<parameter> := <string>
This is one of the commands defined in the following section
<value>:= This field depends on the type of parameter, see the specific value
descriptions
Response syntax: <ack><cr>
Example 1: This command sets the instrument in Remote Controlled.
cmd<cr> (send ‘cmd’ command)
0<cr> (responds ‘command ok’)
REMOTE<cr> (send parameter ‘REMOTE’)
0<cr> (responds ‘parameter ok’)
Example 2: This command saves a dataset on the instrument with the name ‘test’.
cmd<cr> (send ‘cmd’ command)
0<cr> (responds ‘command ok’)
SAVE,test<cr> (send parameter ‘SAVE’ with name ‘test’)
0<cr> (responds ‘parameter ok’)
1157.3564.12 6 E-10
R&S FSH-K1 Parameter Overview
Parameter Overview
In the following tables all parameters and commands are listed with the different measurement modes
they are active in.
Note: Parameters are not always available; this depends on the type of measurement selected
and other settings.
Get / Set Parameter
Parameter
Analyzer
Tracking Gen.
Receiver Mode
ACCESSORY * * * * * * * * * * * *
ANTDIV *
AUTOCISPRBW *
AUTODET * * * * * * * *
AUTORBW * * * * * * *
AUTOSPAN * * * *
AUTOSWPTIME * * * * * * * *
AUTOVBW * * * * * * *
BAUD * * * * * * * * * * *
CABLELEN *
CABLEMOD *
CALKIT * *
CALKITLEN * *
CHANNEL * * * * * * *
CHMODE * * * * * * *
CHPWRBW *
CHPWRSTD *
CHPWRCSTD *
CHPWRUNIT *
CHTABLE * * * * * * *
CISPRBW *
CNCHBW *
CNCSTD *
CNMANREFPWR *
CNMEASMODE *
CNMODE *
CNNOISECOR *
CNNORM *
CNPILOTFRQ *
CNPWRDISP *
CNRATIOCHBW *
CNREFMEASMODE *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
1157.3564.12 7 E-10
Parameter Overview R&S FSH-K1
Parameter
Analyzer
Tracking Gen.
Receiver Mode
CNREFPWR *
CNUNIT *
CNVISIONFRQ *
CTRFREQOFFS *
COUPLEDTOREF *
DELTA1 * * * * * *
DELTA * * * * * *
DELTAALLON * * * * * *
DELTA1ON * * * * * *
DELTAON * * * * * *
DISPLAY * * * * * * * * * * * *
DTFMODE *
DYNRANGE * * * * * * * * * * *
EXTINPUT * * * * * * * * * * *
FREQ * * * * * * * * * * * *
FREQOFFS * * * * * *
FREQSTART *
FREQSTOP *
LENUNIT * * * * * * * * * * *
LIMDEF * * * * * * * * * *
LIMLOW * * * * * * * * * *
LIMUPP * * * * * * * * * *
LIMBEEP * * * * * * * * * *
LIMMSG * * * * * * * * * *
MARK1 * * * * * *
MARK * * * * * *
MARKALLON * * * * * *
MARK1ON * * * * * *
MARKON * * * * * *
MARKMODE * * * * * *
MARKDEMOD * * *
MARKTIME * * *
MARKVOL * * *
MARKIMPREF * *
MARKMEASY * *
MATHMODE *
MEAS * * * * * * * * * * * *
MEASTIME * * *
NDBDOWNVAL * * *
OBWSTD *
OBWCSTD *
OBWCHBW *
OFFSETLEN * *
PREAMP * * * * * * * * * *
PRESETSET * * * * * * * * * * * *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
1157.3564.12 8 E-10
R&S FSH-K1 Parameter Overview
Parameter
Analyzer
Tracking Gen.
Receiver Mode
PSCRCD *
PWRSSTD *
RANGE * * * * * * * * * *
RBW * * * * * * * * *
REFLUNIT *
REFLVL * * * * * * * * * * *
REFLVLOFFS * * * * * * * * * * * *
RFINPUT * * * * * * * * * *
SCANMODE *
SCANSTART *
SCANSTOP *
SCANSTEP *
SPAN * * * * * *
SSCRCD *
SWPCONT * * * * * * * * * *
SWPTIME * * * * * * * * *
TDMASTD *
TDMACSTD *
TGATT * *
TGLVL * *
TGMODE * *
THRLOW *
THRUPP *
TRACEAVG * * * * * * * *
TRACEDET * * * * * * * * *
TRACEMODE * * * * * * * * *
TRD1 * * * * * * *
TRD1X *
TRD1Y *
TRD1Z *
TRD2 * * * * * * * *
TRIGDEL * * * * * * * *
TRIGLVL * * * * * * * *
TRIGSRC * * * * * * * * *
UNIT * * * * * * * * * * * *
VBW * * * * * * * *
VVREF *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
1157.3564.12 9 E-10
Parameter Overview R&S FSH-K1
Get Parameter
Parameter
Analyzer
Tracking Gen.
Receiver Mode
CABLELOSS * *
CARRFREQERR *
CCORRTRACE * *
CCORRTRACEBIN * *
CHPWR *
CNVALUE *
CPICHEIRAT *
CPICHPWR *
CPICHSLOTNR *
CPICHSYMEVM *
CTRACE * * *
CTRACEBIN * * *
DELTAALL? * * * * * *
ELCABLENVAL * *
EXTREF * * * * * * * * * * *
IDN? * * * * * * * * * * *
LEVEL *
LIMCHKREMOTE *
LIMLIST * * * * * * * * * *
LIMPASS * * * * * * * * * *
MARKALL? * * * * * *
MTRACE * * * * * * * * * *
MTRACEBIN * * * * * * * * * *
OCCBW *
NDBDOWN * *
PCCPCHEIRAT *
PCCPCHPWR *
PCCPCHPWRREL *
PCCPCHSYMEVM *
PSCHPWR *
PSCHPWRREL *
PWR *
REFL *
REFLCAL * * *
REFLVECTCAL * * *
SSCHPWR *
SSCHPWRREL *
STB? * * * * * * * * * * *
SYNCRESULT *
TDMAPWR *
TEMP * * * * * * * * * * * *
THRPASS *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
1157.3564.12 10 E-10
R&S FSH-K1 Parameter Overview
Parameter
Analyzer
Tracking Gen.
Receiver Mode
TOTPWR *
TRACE * * * * * * * * * *
TRACEBIN * * * * * * * * * *
TRANSCAL * *
TRANSVECTCAL * *
VECTVOLT *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
1157.3564.12 11 E-10
Parameter Overview R&S FSH-K1
CMD Commands
Parameter
Analyzer
Tracking Gen.
Receiver Mode
AUTOSDSNGL *
AUTOSDMUL *
CAL_DTF *
CAL_TGSCLRFL * *
CAL_TGSCLTRN * *
CAL_TGVECRFL * *
CAL_TGVECTRN * *
INIT * * * * * * * * * * * *
LOCAL * * * * * * * * * * * *
LVLADJUST * * * * *
MARKNXTPK * * * * * *
MARKPK * * * * * *
MARKMIN * * * * * *
MARKTOCENT * * * * *
LIMDEL * * * * * * * * * *
MARKTOLVL * * * * * *
PRESET * * * * * * * * * * * *
PWRTOREF *
RECALL * * * * * * * * * * * *
REMOTE * * * * * * * * * * * *
SAVE * * * * * * * * * * * *
THROFF *
TRACETOMEM *
WAIT * * * * * * * * * * *
ZERO *
VVTOREF *
Vector Voltmeter
Isotropic Antenna
Carrier Noise
Power Sensor
Channel Power
Occupied BW
TDMA Power
Distance to Fault
WCDMA BTS CDP
Note: When the instrument is in the state standby (Off) only the parameters IDN?, BAUD and
MEAS are available.
1157.3564.12 12 E-10
R&S FSH-K1 Command Description
Command Description
General Commands
Command Parameters Unit Comment
IDN? GET command only
BAUD 0...4 SET command only
REMOTE
LOCAL
PRESETSET 0...1
PRESET
INIT
WAIT
STB? GET command only
EXTINPUT 0, 1
SAVE <string>
RECALL <string>
EXTREF 0…3 GET command only
DISPLAY 0...1
TEMP GET command only
IDN?
This command returns the instrument ID string.
This string contains: <manufacturer>,<model number>,<serial number>,<software version>.
<model number>: 03, 13, 23 for the according R&S FSH3 model
06, 26 for the according R&S FSH6 model
18 for the according R&S FSH18 model
Example: get<cr>
0<cr>
idn?<cr> ‘query ID string
0<cr> ‘responds parameter ok
Rohde&Schwarz,23,100212,V11.0 ‘instrument ID string
1157.3564.12 13 E-10
Command Description R&S FSH-K1
BAUD (Serial baud rate)
This command sets the serial interface baud rate. The default baud rate is 19.200 Baud.
Value Baud rate
0 19.200
1 38.400
2 57.600
3 115.200
4 9.600
Example: set<cr>
0<cr>
baud,3<cr> ‘set baud rate on 115.200
0<cr> ‘responds ok with current baud rate
‘instrument is set to new baud rate
REMOTE
This command sets the instrument to remote state. Front panel interaction is disabled.
Example: cmd<cr>
0<cr>
remote<cr> ‘set instrument to remote
0<cr> ‘responds parameter ok
LOCAL
This command sets the instrument to local state. Front panel operation is enabled.
Example: cmd<cr>
0<cr>
local<cr> ‘set instrument to local
0<cr> ‘responds parameter ok
1157.3564.12 14 E-10
R&S FSH-K1 Command Description
PRESETSET (Preset Setting)
This command selects the preset settings. When selecting the Custom Preset Setting a Preset Dataset
must be available.
Value Preset Setting
0 Default
1 Custom
Example: set<cr>
0<cr>
presetset,1<cr> ‘use custom preset settings’
0<cr> ‘responds parameter ok’
PRESET
This command sets the instrument to the preset settings.
Example: cmd<cr>
0<cr>
preset<cr> ‘set instrument to preset
0<cr> ‘responds parameter ok
INIT
This command starts / re-starts a new sweep.
Example: cmd<cr>
0<cr>
init<cr> ‘start new sweep
0<cr> ‘responds parameter ok
WAIT
This command is used to synchronize with the end of a sweep. After sending the WAIT command the
<ack> acknowledge is holdoff until the sweep is complete.
Example: cmd<cr>
0<cr>
wait<cr> ‘wait for end of sweep
0<cr> ‘responds parameter ok, sweep complete
STB?
This command returns the instrument status. The status indicates any settings/conditions that causes
measurements to be questionable (response: ‘1’) or not (response ‘0’).
Example: get<cr>
0<cr>
stb?<cr> ‘query status
0<cr> ‘responds parameter ok
0<cr> ‘status: o.k.
1157.3564.12 15 E-10
Command Description R&S FSH-K1
EXTINPUT (External Input)
This command switches between external trigger input and external reference input on the external
input connector. Default is ‘External Trigger’.
Value External Input Connector
0 External Trigger
1 External Reference
Example: set<cr>
0<cr>
extinput,1<cr> ‘enable external reference on input connector
0<cr> ‘responds parameter ok
SAVE
This command saves the current setting and measurement in the specified dataset. If the dataset exists
it will be overwritten. Dataset names are not case sensitive.
Example: cmd<cr>
0<cr>
save,mydata.001<cr> ‘save settings to dataset “MYDATA.001”
0<cr> ‘responds parameter ok
RECALL
This command recalls a stored dataset. Dataset names are not case sensitive.
Example: cmd<cr>
0<cr>
recall,mydata.001<cr> ‘recall settings from dataset “MYDATA”
0<cr> ‘responds parameter ok
EXTREF (External Reference status)
This command returns the external reference status.
Value Status external reference
0 Disabled
1 Out of range
2 Catching
3 Locked
Example: get<cr>
0<cr>
extref<cr> ‘get status of external reference
0<cr> ‘responds parameter ok
1<cr> ‘response status out of range
1157.3564.12 16 E-10
R&S FSH-K1 Command Description
DISPLAY
This command turns the display on or off.
Value
0 Off
1 On
Example: set<cr>
0<cr>
display,0<cr> ‘turn display off
0<cr> ‘responds parameter ok
TEMP (Temperature)
This command returns the current temperature inside the instrument.
Example: get<cr>
0<cr>
temp<cr> ‘query temperature
0<cr> ‘responds parameter ok
32.6 ‘instrument temperature (Celsius)
1157.3564.12 17 E-10
Command Description R&S FSH-K1
Frequency and Span Settings
Command Parameters Unit Comment
REQ <numeric value> Hz
F
FREQOFFS <numeric value> Hz
SPAN <numeric value> Hz
AUTOSPAN 0, 1
CHANNEL <numeric value>
CHTABLE <string>
CTRFREQOFFS <numeric value> Hz
FREQ (Frequency)
This command sets the center frequency.
The start and stop frequency of the instrument is defined by the current center frequency and span.
Example: set<cr>
0<cr>
freq,950E6<cr> ‘set center frequency to 950 MHz
0<cr> ‘responds parameter ok
FREQOFFS (Frequency Offset)
This command sets the frequency offset.
The new center frequency is the current frequency plus the frequency offset.
Example: set<cr>
0<cr>
freqoffs,10E6<cr> ‘set frequency offset to 10 MHz
0<cr> ‘responds parameter ok
SPAN
This command sets the span.
The start and stop frequency of the instrument is defined by the current center frequency and span.
The <numeric value> = 0 is used for Zero Span.
Example: set<cr>
0<cr>
span,20E6<cr> ‘set span to 20 MHz
0<cr> ‘responds parameter ok
1157.3564.12 18 E-10
R&S FSH-K1 Command Description
AUTOSPAN
This command switches span mode AUTO on/off (Measure Mode: Channel Power or Occupied BW)
Value Span Mode
0 Auto Off
1 Auto On
Example: set<cr>
0<cr>
autospan,1<cr> ‘set Auto span On
0<cr> ‘responds parameter ok
CHANNEL (Channel Number)
This command defines the channel number. Use CHTABLE command to select a channel table first.
Example: set<cr>
0<cr>
channel,55<cr> ‘selects channel no. 55
CHTABLE (Channel Table)
This command selects a channel table for the channel mode.
Example: set<cr>
0<cr>
chtable,FMBand<cr> ‘selects channel table “FMBand”
0<cr> ‘responds parameter ok
CTRFREQOFFS (Coupled To Reference channel - FREQuency OFFSet)
This command couples the frequency of the noise channel in Carrier / Noise measurements to the
frequency of the reference channel. The command sets the frequency offset of the noise channel from
the reference channel.
Example: set<cr>
0<cr>
ctrfreqoffs,16E6<cr> ‘set frequency offset from ref. channel to 16 MHz
0<cr> ‘responds parameter ok
1157.3564.12 19 E-10
Command Description R&S FSH-K1
COUPLEDTOREF (Coupled To Reference channel)
This command couples the frequency of the noise channel in Carrier / Noise measurements to the
frequency of the reference channel.
Value CoupledToRef
0 Off
1 On
Example: set<cr>
0<cr>
coupledtoref,1<cr> ‘set coupled to on
0<cr> ‘responds parameter ok
1157.3564.12 20 E-10
R&S FSH-K1 Command Description
Amplitude Settings
Command Parameters Unit Comment
REFLVL <numeric value> Uses current unit
REFLVLOFFS <numeric value> dB
RANGE 0...36
DYNRANGE 0, 1
UNIT 0...8
RFINPUT 0, 1
PREAMP 0, 1
REFLVL (Reference Level)
This command sets the reference level using the current unit.
Example: set<cr>
0<cr>
reflvl,-30<cr> ‘set reference level to –30dBm
0<cr> ‘responds parameter ok
REFLVLOFFS (Reference Level Offset)
This command sets the reference level offset in dB.
The new reference level is the current reference level plus the reference level offset.
Example: set<cr>
0<cr>
reflvloffs,-6<cr> ‘set reference level offset to –6 dB
0<cr> ‘responds parameter ok
1157.3564.12 21 E-10
Command Description R&S FSH-K1
RANGE
This command defines the range.
Value Range
0 10 dB/DIV
1 5 dB/DIV
2 2 dB/DIV
3 1 dB/DIV
4 LIN 0-100%
5 VSWR 1-6 (Tracking Gen, DTF)
6 VSWR 1-2 (Tracking Gen, DTF)
7 VSWR 1-1.5 (Tracking Gen, DTF)
8 VSWR 1-1.1 (Tracking Gen, DTF)
9 Smith Chart
10 0,001 Rho/DIV
11 0,01 Rho/DIV
12 0,1 Rho/DIV
13 1 Rho/DIV
14 1 mRho/DIV
15 10 mRho/DIV
16 100 mRho/DIV
17 1000 mRho/DIV
18 0,1 dB/DIV
19 VSWR 1-10 (Tracking Gen, DTF)
20 VSWR 1-20 (Tracking Gen, DTF)
21 Degrees
22 1 ns/DIV
23 2 ns/DIV
24 5 ns/DIV
25 10 ns/DIV
26 20 ns/DIV
27 50 ns/DIV
28 100 ns/DIV
29 0,003 Rho/DIV
30 0,03 Rho/DIV
31 0,3 Rho/DIV
32 3 mRho/DIV
33 30 mRho/DIV
34 300 mRho/DIV
35 0,2 dB/DIV
36 0,5 dB/DIV
Example: set<cr>
0<cr>
range,2<cr> ‘set range to 2 dB/DIV
0<cr> ‘responds parameter ok
1157.3564.12 22 E-10
R&S FSH-K1 Command Description
DYNRANGE (Dynamic Range)
This command defines the dynamic range. Default on Preset is ‘Low Distortion’.
Value Range
0 Low Distortion
1 Low Noise
Example: set<cr>
0<cr>
dynrange,1<cr> ‘set dynamic range to ‘Low Noise’
0<cr> ‘responds parameter ok
UNIT
This command defines the unit of the level.
Value Unit
0 dBm
1 dBmV
2 dB\V
3 dB\V/m
4 dB\A/m
5 dB
6 Volt
7 Watt
8 V/m
Example: set<cr>
0<cr>
unit,2<cr> ‘set unit to dB\V
0<cr> ‘responds parameter ok
RFINPUT (RF Input Impedance)
This command defines the input impedance.
Value Input Impedance
0 50 ]
1 75 ]
Example: set<cr>
0<cr>
rfinput,1<cr> ‘set input impedance to 75 ]
0<cr> ‘responds parameter ok
1157.3564.12 23 E-10
Command Description R&S FSH-K1
PREAMP (Preamplifier)
This command switches the preamplifier on/off. Default on Preset is ‘Preamp OFF’
Value Preamp
0 OFF
1 ON
Example: set<cr>
0<cr>
preamp,1<cr> ‘turns the preamp on
0<cr> ‘responds parameter ok
1157.3564.12 24 E-10
R&S FSH-K1 Command Description
Bandwidth Settings
Command Parameters Unit Comment
AUTORBW 0, 1
RBW 0...10
AUTOVBW 0, 1
VBW 0...12
AUTOCISPRBW 0, 1 Receiver Mode only
(R&S FSH-K3)
CISPRBW 0…3 Receiver Mode only
(R&S FSH-K3)
AUTORBW (Auto Resolution Bandwidth )
This command switches the auto coupling of the resolution bandwidth on/off. If AUTORBW is active the
current setting of the resolution bandwidth can be queried with the GET RBW command.
Value Auto Resolution Bandwidth
0 OFF
1 ON
Example: set<cr>
0<cr>
autorbw,1<cr> ‘turns the RBW auto coupling on
0<cr> ‘responds parameter ok
RBW (Resolution Bandwidth)
This command sets the resolution bandwidth.
Value Resolution Bandwidth
0 Auto (Set only)
1 100 Hz (Not available for model 13)
2 300 Hz (Not available for model 13)
3 1 kHz
4 3 kHz
5 10 kHz
6 30 kHz
7 100 kHz
8 300 kHz
9 1 MHz
10 200 kHz
Example: set<cr>
0<cr>
rbw,4<cr> ‘set resolution bandwidth to 3 kHz
0<cr> ‘responds parameter ok
1157.3564.12 25 E-10
Command Description R&S FSH-K1
AUTOVBW (Auto Video Bandwidth )
This command switches the auto coupling of the video bandwidth on/off. If AUTOVBW is active the
current setting of the video bandwidth can be queried with the GET VBW command.
Value Auto Video Bandwidth
0 OFF
1 ON
Example: set<cr>
0<cr>
autovbw,1<cr> ‘turns the VBW auto coupling on
0<cr> ‘responds parameter ok
VBW (Video Bandwidth)
This command sets the video bandwidth.
Value Video Bandwidth
0 Auto (Set only)
1 10 Hz
2 30 Hz
3 100 Hz
4 300 Hz
5 1 kHz
6 3 kHz
7 10 kHz
8 30 kHz
9 100 kHz
10 300 kHz
11 1 MHz
12 3 MHz
Example: set<cr>
0<cr>
vbw,5<cr> ‘set video bandwidth to 1 kHz
0<cr> ‘responds parameter ok
1157.3564.12 26 E-10
R&S FSH-K1 Command Description
AUTOCISPRBW (Auto CISPR Bandwidth )
This command switches the auto setting of the CISPR bandwidth on/off. If AUTOCISPRBW is active
the current setting of the CISPR bandwidth can be queried with the GET CISPRBW command. This
command is available in Receiver Mode only (R&S FSH-K3).
Value Auto CISPR Bandwidth
0 OFF
1 ON
Example: set<cr>
0<cr>
autocisprbw,1<cr> ‘turns the CISPRBW auto coupling on
0<cr> ‘responds parameter ok
CISRBW (CISPR Bandwidth)
This command sets the CISPR bandwidth. This command is available in Receiver Mode only
(R&S FSH-K3).
Value CISPR Bandwidth
0 200 Hz
1 9 kHz
2 120 kHz
3 1 MHz
Example: set<cr>
0<cr>
cisprbw,2<cr> ‘set CISPR bandwidth to 120 kHz
0<cr> ‘responds parameter ok
1157.3564.12 27 E-10
Command Description R&S FSH-K1
Sweep Settings
Command Parameters Unit Comment
AUTOSWPTIME 0, 1
SWPTIME <numeric value> s Value 0: Auto
SWPCONT 0, 1
TRIGSRC 0...3
TRIGLVL <numeric value> %
TRIGDEL <numeric value> s
AUTOSWPTIME (Auto Sweep Time )
This command switches the auto coupling of the sweep time on/off. If AUTOSWPTIME is active the
current setting of the sweep time can be queried with the GET SWPTIME command.
Value Auto Sweep Time
0 OFF
1 ON
Example: set<cr>
0<cr>
autoswptime,1<cr> ‘turns the sweep time auto on
0<cr> ‘responds parameter ok
SWPTIME (Sweep Time)
This command sets the sweep time. The value 0 sets the sweep time to Auto.
Example: set<cr>
0<cr>
swptime,0.2<cr> ‘set resolution bandwidth to 200 ms
0<cr> ‘responds parameter ok
SWPCONT (Sweep Continuous)
This command sets the instrument to single sweep or continuous sweep.
Value Sweep
0 Single
1 Continuous
Example: set<cr>
0<cr>
swpcont,0<cr> ‘set to single sweep
0<cr> ‘responds parameter ok
1157.3564.12 28 E-10
R&S FSH-K1 Command Description
TRIGSRC (Trigger Source)
This command selects the trigger source.
Value Trigger Source
0 Free run
1 Video
2 External - Rise
3 External - Fall
Example: set<cr>
0<cr>
trigsrc,1<cr> ‘set to video trigger
0<cr> ‘responds parameter ok
TRIGLVL (Trigger Level)
This command defines the video trigger level (0…100%).
Example: set<cr>
0<cr>
trigLVL,50<cr> ‘set video trigger level to 50%
0<cr> ‘responds parameter ok
TRIGDEL (Trigger Delay)
This command defines the trigger delay.
Example: set<cr>
0<cr>
trigdel,100E-6<cr> ‘set trigger delay to 100 \s
0<cr> ‘responds parameter ok
1157.3564.12 29 E-10
Command Description R&S FSH-K1
Trace Settings
Command Parameters Unit Comment
TRACEMODE 0..4
WRAPPHASE 0,1
RACEDET 0...6
T
TRACEAVG 2…999
TRACE <numeric value>,.... GET command only
TRACEBIN <value>,... GET command only
TRACETOMEM CMD command only
CCORRTRACE <numeric value>,.... GET command only
CCORRTRACEBIN <value>,... GET command only
CTRACE <numeric value>,.... GET command only
CTRACEBIN <value>,... GET command only
MATHMODE <numeric value>
MTRACE <string> GET command only
MTRACEBIN <string> GET command only
TRACEMODE
This command defines the trace mode.
Value Trace Mode
0 Clear Write
1 Average
2 Max Hold
3 Min Hold
4 View
Example: set<cr>
0<cr>
tracemode,2<cr> ‘set trace mode to “Max Hold”
0<cr> ‘responds parameter ok
WRAPPHASE (Phase Wrapping)
This command defines the phase wrapping.
Value Phase Wrapping
0 Unwrap
1 Wrap
Example: set<cr>
0<cr>
wrapphase,0<cr> ‘set wrap phase to unwrap
0<cr> ‘responds parameter ok
Note: This command is available in Tracking Genarator only with measurement modes Smith Chart,
Phase or Vector Magnitude active.
1157.3564.12 30 E-10
R&S FSH-K1 Command Description
TRACEDET (Trace Detector)
This command defines the detector used. The Average and Quasi-Peak detector are available in
Receiver Mode (R&S FSH-K3) only.
Value Detector
0 Auto Peak
1 Min Peak
2 Max Peak / Peak
3 Sample
4 RMS
5 Average
6 Quasi-Peak
Example: set<cr>
0<cr> ‘responds parameter ok
tracedet,3<cr> ‘selects sample detector
0<cr> ‘responds parameter ok
TRACEAVG (Trace Average)
This command sets the number of traces used to calculate the trace average
Example: set<cr>
0<cr>
traceavg,50<cr> ‘calculate trace average over 50 traces
0<cr> ‘responds parameter ok
TRACE (Trace Data)
This command reads out the trace data in alphanumeric format.
The current unit is used for the values. A trace consists of 301 data values. If the Auto Peak detector is
used, both max and min values are returned (602 values: 301 min values then 301 max values).
Example: get<cr>
0<cr>
trace<cr> ‘readout trace data
0<cr> ‘responds parameter ok
-103.22,-106.88,-96.27,.....
Note: In case of TRG measurement mode Phase, the phase data in unit radiants is returned.
Dependent on the wrap mode the wrapped or unwrapped phase values are provided.
1157.3564.12 31 E-10
Command Description R&S FSH-K1
TRACEBIN (Trace Data Binary)
This command reads out the trace data in binary format.
Each sample consists of 4 bytes with the LSB send first. The 4 bytes represent the measured power in
the current unit. The sample values are multiplied to provide the highest resolution possible.
Value Binary values
0 dBm * 1000
1 dBmV * 1000
2 dB\V * 1000
3 dB\V/m * 1000
4 dB\A/m * 1000
5 dB * 1000
6 Volt * 1000000
7 Watt * 1000000000
8 Degrees * 1000
9 Seconds * 1000000
A trace consists of 301 samples. If the Auto Peak detector is used, both Max and Min values are
returned (602 samples: 301 min values then 301 max values).
Example: get<cr>
0<cr>
tracebin<cr> ‘readout binary trace data
0<cr> ‘responds parameter ok
<sample><sample>....
TRACETOMEM (Copy current trace to memory)
This command stores the current trace to memory.
Example: cmd<cr>
0<cr> ‘responds parameter ok
tracetomem<cr> ‘store the current trace to memory
0<cr> ‘responds parameter ok
CCORRTRACE (Complex Corrected Trace Data)
This command reads out the corrected magnitude and phase values in alphanumeric format. The
magnitude unit is dB, the phase unit is radiants. Dependent on the wrap mode the wrapped or
unwrapped phase values are provided.
A complex trace consists of 301 magnitude and 301 phase values.
Example: get<cr>
0<cr>
ccorrtrace<cr> ‘readout corrected trace data
0<cr> ‘responds parameter ok
-103.22,-106.88,-96.27,.....
Note: This command is only supported in Tracking Generator Measurement when vector calibrated
and not in measurement mode groupDelay.
1157.3564.12 32 E-10
R&S FSH-K1 Command Description
CCORRTRACEBIN (Complex Corrected Trace Data Binary)
This command reads out the corrected magnitude and phase values in binary format. Dependent on
the wrap mode the wrapped or unwrapped phase values are provided.
Value Binary values
0 dB * 1000
1 Radiants * 1000
A complex trace consists of 301 magnitude and 301 phase values.
Example: get<cr>
0<cr>
ccorrtracebin<cr> ‘readout corrected binary trace data
0<cr> ‘responds parameter ok
<sample><sample>....
Note: This command is only supported in Tracking Generator Measurement when vector calibrated
and not in measurement mode groupDelay.
CTRACE (Complex Trace Data)
This command reads out the magnitude and phase values in alphanumeric format.
The magnitude unit is dBm, the phase unit is radiants. A complex trace consists of 301 magnitude and
301 phase values. If In DTF mode CTRACE will return 1024 magnitude and 1024 phase values.
Example: get<cr>
0<cr>
ctrace<cr> ‘readout magnitude and phase values
0<cr> ‘responds parameter ok
-103.22,-106.88,-96.27,.....
Note: This command is only supported in DTF measurement and in Tracking Generator
Measurement when vector calibrated.
1157.3564.12 33 E-10
Command Description R&S FSH-K1
CTRACEBIN (Complex Trace Data Binary)
This command reads out the magnitude and phase values in binary format.
A complex trace consists of 301 magnitude and 301 phase sample values. If In DTF mode CTRACE
will return 1024 magnitude and 1024 phase sample values.
Each sample consists of 4 bytes with the LSB send first.
Value Binary values
0 dB * 1000
1 Radiants * 1000000
Example: get<cr>
0<cr>
ctracebin<cr> ‘readout binary complex trace data
0<cr> ‘responds parameter ok
<sample><sample>....
Note: This command is only supported in DTF measurement and in Tracking Generator
Measurement when vector calibrated.
MATHMODE (Math Mode)
This command defines the math mode used for analyzer measurements.
Value Math Mode
0 Math mode OFF
1 Memory trace – Trace
2 Trace – Memory trace
Example: set<cr>
0<cr>
mathmode,1<cr> ‘set math mode to “mem. trace – trace”
0<cr> ‘responds parameter ok
MTRACE (Trace Data from saved Data Set)
This command reads out the trace data in alphanumeric format from a previously saved data set.
The current unit is used for the values. A trace consists of 301 data values. If the Auto Peak detector is
used, both max and min values are returned (602 values: 301 min values then 301 max values).
Example: get<cr>
0<cr>
mtrace,mydata.001<cr> ‘readout trace data from data set “mydata.001”
0<cr> ‘responds parameter ok
-103.22,-106.88,-96.27,.....
Note: In case of TG measurement mode, the phase data in unit radiants is returned. Dependent on
the wrap mode the wrapped or unwrapped phase values are provided.
1157.3564.12 34 E-10
R&S FSH-K1 Command Description
MTRACEBIN (Trace Data Binary from saved Data Set)
This command reads out the trace data in binary format from a previously saved data set..
Each sample consists of 4 bytes with the LSB send first. The 4 bytes represent the measured power in
the current unit. The sample values are multiplied to provide the highest resolution possible.
Value Binary values
0 dBm * 1000
1 dBmV * 1000
2 dB\V * 1000
3 dB\V/m * 1000
4 dB\A/m * 1000
5 dB * 1000
6 Volt * 1000000
7 Watt * 1000000000
8 Degrees * 1000
9 Seconds * 1000000
A trace consists of 301 samples. If the Auto Peak detector is used, both Max and Min values are
returned (602 samples: 301 min values then 301 max values).
Example: get<cr>
0<cr>
mtracebin,mydata.001<cr> ‘readout binary trace data from data set
0<cr> ‘responds parameter ok
<sample><sample>....
1157.3564.12 35 E-10
Command Description R&S FSH-K1
Marker
Command Parameters Unit Comment
MARK1ON 0, 1
MARK1 <numeric value>
MARKON <1…6>, 0, 1
MARK <1…6>, <numeric value>
DELTA1ON 0, 1
DELTA1 <numeric value>
DELTAON <1…6>, 0, 1
DELTA <2…6>, <numeric value>
MARKALLON 0, 1 SET command only
DELTAALLON 0, 1 SET command only
MARKALL? GET command only
DELTAALL? GET command only
MARKPK [1…6] CMD command only
MARKNXTPK [1…6] CMD command only
MARKMIN [1…6] CMD command only
MARKTOCENT [1…6] CMD command only
MARKTOLVL [1…6] CMD command only
MARKMODE 0...4
MARKDEMOD 0…2
MARKTIME < numeric value> s
MARKVOL 0…100 %
MARKIMPREF < numeric value> ]
MARKMEASY [0…6]
NDBDOWN GET command only
NDBDOWNVAL < numeric value > dB
1157.3564.12 36 E-10
R&S FSH-K1 Command Description
MARK1ON (Marker On)
This command turns the marker on / off.
Value Marker
0 OFF
1 ON
Example: set<cr>
0<cr>
mark1on,1<cr> ‘turns marker on
0<cr> ‘responds parameter ok
MARK1 (Marker)
This command sets the marker to the specified position or queries the current marker value.
The marker unit depends on the unit of the x-axis which can be Hz, seconds or meter/feet depending of
the measurement mode. The unit of the second value in the GET command response depends on the
current unit of the y-axis.
If Smith Chart is active, the second and third values are the complex impedance.
Example: set<cr>
0<cr>
mark1,100E6<cr> ‘set marker to 100 MHz
0<cr> ‘responds parameter ok
Example 2: get<cr>
0<cr>
mark1<cr> ‘query current marker value
0<cr> ‘responds parameter ok
947.25e6,-79.28<cr> ‘returns Marker frequency and level
MARKON (Multimarker On)
This command turns the corresponding (multi) marker on / off. MARKON,1 is used for the marker in
normal and in multi marker mode. MARKON,2 to MARKON,6 are available in multi marker mode only.
Param 1 Param 2
Value Marker No Value Marker Mode
1…6 Marker 1 … 6
Example: set<cr>
0<cr>
markon,3,1<cr> ‘turns multi marker 3 on
0<cr> ‘responds parameter ok
0 OFF
1 ON
1157.3564.12 37 E-10
Command Description R&S FSH-K1
MARK (Multimarker)
This command sets the corresponding (multi) marker to the specified position or queries the current
marker value.
The marker unit depends on the unit of the x-axis which can be Hz, seconds or meter/feet depending of
the measurement mode. The unit of the second value in the GET command response depends on the
current unit of the y-axis.
If Smith Chart is active, the second and third values are the complex impedance.
Value Multimarker
1…6 Marker 1…6
MARK,1 is used for the marker in normal and multi marker mode, MARK,2 to MARK,6 are available in
multi marker mode only.
Example: set<cr>
0<cr>
mark,2,100E6<cr> ‘set multi marker 2 to 100 MHz
0<cr> ‘responds parameter ok
Example 2: get<cr>
0<cr>
mark,2<cr> ‘query multi marker 2 value
0<cr> ‘responds parameter ok
947.25e6,-79.28<cr> ‘returns Marker frequency and level
DELTA1ON (Deltamarker On)
This command turns the marker on / off.
Value Deltamarker
0 OFF
1 ON
Example: set<cr>
0<cr>
delta1on,1<cr> ‘turns deltamarker on
0<cr> ‘responds parameter ok
1157.3564.12 38 E-10
R&S FSH-K1 Command Description
DELTA1 (Deltamarker)
This command sets the deltamarker to the specified position in relation to the marker or queries the
current deltamarker value.
The deltamarker unit depends on the unit of the x-axis which can be Hz, seconds or meter/feet
depending of the measurement mode. The unit of the second value in the GET command response
depends on the current unit of the y-axis.
If Smith Chart is active, the second and third values are the complex impedance.
Example: set<cr>
0<cr>
delta1,-100E3<cr> ‘set deltamarker to 100 kHz below the marker
0<cr> ‘responds parameter ok
Example 2: get<cr>
0<cr>
delta1<cr> ‘query current marker value
0<cr> ‘responds parameter ok
-100e3,-8.23<cr> ‘returns deltamarker frequency and relative level
DELTAON (Delta Multimarker On)
This command turns the corresponding deltamarker on / off. DELTAON,1 is used for the deltamarker in
normal and in multi marker mode. DELTAON,2 to DELTAON,6 are available in multi marker mode only
Param 1 Param 2
Value Deltamarker No Value Deltamarker
1…6 Deltamarker 1…6
Example: set<cr>
0<cr>
deltaon,2,1<cr> ‘turns deltamarker 2 on
0<cr> ‘responds parameter ok
0 OFF
1 ON
1157.3564.12 39 E-10
Command Description R&S FSH-K1
DELTA (Delta Multimarker)
This command sets the corresponding deltamarker to the specified position in relation to the marker or
queries the current deltamarker value.
The deltamarker unit depends on the unit of the x-axis which can be Hz, seconds or meter/feet
depending of the measurement mode. The unit of the second value in the GET command response
depends on the current unit of the y-axis.
If Smith Chart is active, the second and third values are the complex impedance.
Value Deltamarker
2…6 Deltamarker 2…6
DELTA,2 is used for the deltamarker in normal and multi marker mode, DELTA,3 to DELTA,6 are
available in multi marker mode only.
Example: set<cr>
0<cr>
delta,2,-100E3<cr> ‘set deltamarker 2 to 100 kHz below the marker
0<cr> ‘responds parameter ok
Example 2: get<cr>
0<cr>
delta,2<cr> ‘query delta marker 2 value
0<cr> ‘responds parameter ok
-100e3,-8.23<cr> ‘returns deltamarker frequency and relative level
MARKALLON (All Multimarker On)
This command turns all multimarker on / off. This command is available in multi marker mode only.
Value All Marker
0 OFF
1 ON
Example: set<cr>
0<cr>
markallon,1<cr> ‘turns all multi marker on
0<cr> ‘responds parameter ok
DELTAALLON (All Deltamarker On)
This command turns all deltamarker on / off. This command is available in multi marker mode only.
Value All Deltamarker
0 OFF
1 ON
Example: set<cr>
0<cr>
deltaallon,1<cr> ‘turns all deltamarker on
0<cr> ‘responds parameter ok
1157.3564.12 40 E-10
R&S FSH-K1 Command Description
MARKALL? (Multimarker)
This command queries the current list of multimarkers. Each multimarker returns three numbers:
multimarker number, x-axis value, y-axis value. This GET command is available in multi marker mode
only.
The unit of the second number in the GET command response depends on the unit of the x-axis which
can be Hz, seconds or meter/feet depending of the measurement mode. The unit of the third value in
the GET command response depends on the current unit of the y-axis.
Example: get<cr>
0<cr>
markall?<cr> ‘query multi marker list (e.g. 2 multimarkers)
0<cr> ‘responds parameter ok
1,103.4e6,-45.66,2,110.8e6,-23.67<cr>
DELTAALL? (Multi Deltamarker)
This command queries the current list of multi deltamarker values. Each delta multimarker returns three
numbers: delta multimarker number, x-axis value, y-axis value. This GET command is available in multi
marker mode only.
The unit of the second number in the GET command response depends on the unit of the x-axis which
can be Hz, seconds or meter/feet depending of the measurement mode. The unit of the third value in
the GET command response depends on the current unit of the y-axis.
Example: get<cr>
0<cr>
deltaall?<cr> ‘query delta marker list (e.g. 3 delta multimarker)
0<cr> ‘responds parameter ok
1,-100.0e3,-6.02,2,100.5e3,-3.67,3,300.4e6,-12.5<cr>
MARKPK (Marker Peak)
This command sets the current or corresponding marker to the peak (highest signal).
Optional Value Marker
1…6 Marker 1…6
Example: cmd<cr>
0<cr>
markpk<cr> ‘set marker to peak
0<cr> ‘responds parameter ok
Example 2: cmd<cr>
0<cr>
markpk,4<cr> ‘set multi marker 4 to peak
0<cr> ‘responds parameter ok
1157.3564.12 41 E-10
Command Description R&S FSH-K1
MARKNXTPK (Marker Next Peak)
This command sets the current or corresponding marker to the next peak.
Optional Value Marker
1…6 Marker 1…6
Example: cmd<cr>
0<cr>
marknxtpk<cr> ‘set marker to next peak
0<cr> ‘responds parameter ok
MARKMIN (Marker Minimum)
This command sets the current or corresponding marker to the minimum (lowest signal).
Optional Value Marker
1…6 Marker 1…6
Example: cmd<cr>
0<cr>
markmin<cr> ‘set marker to minimum
0<cr> ‘responds parameter ok
MARKTOCENT (Marker Frequency To Center Frequency)
This command sets the current or corresponding marker as center frequency.
Optional Value Marker
1…6 Marker 1…6
Example: cmd<cr>
0<cr>
marktocent<cr> ‘set marker frequency to center frequency
0<cr> ‘responds parameter ok
MARKTOLVL (Marker Level To Reference Level)
This command sets the current or corresponding marker level as reference level.
Optional Value Marker
1…6 Marker 1…6
Example: cmd<cr>
0<cr>
marktolvl<cr> ‘set marker level to reference level
0<cr> ‘responds parameter ok
Example 2: cmd<cr>
0<cr>
marktolvl,4<cr> ‘set multi marker 4 level to reference level
0<cr> ‘responds parameter ok
1157.3564.12 42 E-10
R&S FSH-K1 Command Description
MARKMODE (Marker Mode)
This command defines the marker mode.
Value Marker Mode
0 Normal
1 Noise
2 Frequency Count
3 Multimarker
4 n dB Down
Example: set<cr>
0<cr>
markmode,2<cr> ‘turns on frequency count
0<cr> ‘responds parameter ok
MARKDEMOD (Marker Demodulation)
This command defines the marker demodulation mode.
Value Demodulation
0 OFF
1 AM
2 FM
Example: set<cr>
0<cr>
markdemod,2<cr> ‘turns on FM demodulation
0<cr> ‘responds parameter ok
MARKTIME (Marker Demodulation Time)
This command defines the demodulation time at the current marker position. The demodulation time
range is 0.1 sec to 500 sec.
Example: set<cr>
0<cr>
marktime,2.5<cr> ‘set demod time at marker position to 2.5 sec
0<cr> ‘responds parameter ok
MARKVOL (Marker Demodulation Volume)
This command sets the volume of the demodulation AF output.The range is 1 to 100% in 1% steps.
Example: set<cr>
0<cr>
markvol,50<cr> ‘set volume of AF output to 50%
0<cr> ‘responds parameter ok
1157.3564.12 43 E-10
Command Description R&S FSH-K1
MARKIMPREF (Marker Impedance Reference)
This command sets or gets the impedance reference in Ohm.
Example: set<cr>
0<cr>
markimpref,50000<cr> ‘set impedance reference to 50 k]
0<cr> ‘responds parameter ok
MARKMEASY (Marker Measurement Mode)
This command sets or gets the Marker Format.
Value Marker Meas Mode
0 dB MAG AND PHASE
1 LIN MAG AND PHASE
2 REAL AND IMG
3 R+jX
4 G+jB
5 (R+jX)/Z0
6 (G+jB)/Y0
Example: set<cr>
0<cr>
markmeasy,4<cr> ‘set impedance G+jB.
0<cr> ‘responds parameter ok
NDBDOWN
This command returns the measured ‘n dB down’ bandwidth value.
Example: get<cr>
0<cr>
ndbdown<cr> ‘get n dB down value
0<cr> ‘responds parameter ok
123.456e3 ‘bandwidth is 123.456 kHz
NDBDOWNVAL
This command defines the ‘n dB down’ value. The range is -100.0 dB to 100.0 dB with a resolution of
0.1 dB. This command will automatically set the marker mode to ‘n db down’.
Example: set<cr>
0<cr>
ndbdownval,5<cr> ‘set n dB down on 5 dB
0<cr> ‘responds parameter ok
1157.3564.12 44 E-10
R&S FSH-K1 Command Description
Measurement
Command Parameters Unit Comment
MEAS 0…11
TRD1 <string> Not in Isotropic
Antenna mode
TRD1X <string> Isotropic Antenna
mode only
TRD1Y <string> Isotropic Antenna
mode only
TRD1Z <string> Isotropic Antenna
mode only
TRD2 <string>
ACCESSORY <numeric value>
LIMDEF
LIMDEL <name> CMD command only
<name>,<description>,
<x-unit>,<x-scale>,<yunit>,<x0>,<y0>[,<xn>,
<yn>]
LIMLIST GET command only
LIMLOW <string>
LIMUPP <string>
LIMPASS GET command only
LIMCHKREMOTE 0, 1 Receiver Mode only
(R&S FSH-K3)
THRLOW <numeric value> Receiver Mode only
(R&S FSH-K3)
THRUPP <numeric value> Receiver Mode only
(R&S FSH-K3)
THRPASS Receiver Mode only
(R&S FSH-K3)
GET command only
THROFF Receiver Mode only
(R&S FSH-K3)
CMD command only
1157.3564.12 45 E-10
Command Description R&S FSH-K1
MEAS (Measurement Mode)
This command defines the measurement mode.
Value Measurement
0 Off
1 Analyzer
2 Tracking Generator (Model 13, 23 and 26)
3 Power Sensor
4 Channel Power
5 Occupied Bandwidth
6 TDMA Power
7 Distance to Fault (R&S FSH-B1)
8 Receiver Mode (R&S FSH-K3)
9 Carrier / Noise
10 Isotropic Antenna
11 WCDMA BTS CDP
Using the value 0 the instrument can turned off if the power adapter is connected. If the instrument is
OFF it can be turned on programmatically by selecting one of the measurement modes.
Example: set<cr>
0<cr>
meas,4<cr> ‘selects channel power measurement
0<cr> ‘responds parameter ok
TRD1 (Transducer)
This command selects a transducer. To turn a transducer off, use the string ‘NONE’:
Example: set<cr>
0<cr>
trd1,hl223<cr> ‘selects transducer table “HL223”
0<cr> ‘responds parameter ok
Example 2: set<cr>
0<cr>
trd1,none<cr> ‘de-activates any transducer
0<cr> ‘responds parameter ok
TRD1X (Transducer X – dBµV/m)
This command selects an X-direction transducer (dBµV/m only) for the Isotropic Antenna
measurement. To turn a transducer off, use the string ‘NONE’:
Example: set<cr>
0<cr>
trd1x,ts-emf-x<cr> ‘selects transducer table “TS-EMF-X”
0<cr> ‘responds parameter ok
Example 2: set<cr>
0<cr>
trd1x,none<cr> ‘de-activates any transducer
0<cr> ‘responds parameter ok
1157.3564.12 46 E-10
R&S FSH-K1 Command Description
TRD1Y (Transducer Y – dBµV/m)
This command selects a Y-direction transducer (dBµV/m only) for the Isotropic Antenna measurement.
To turn a transducer off, use the string ‘NONE’:
Example: set<cr>
0<cr>
trd1y,ts-emf-y<cr> ‘selects transducer table “TS-EMF-Y”
0<cr> ‘responds parameter ok
Example 2: set<cr>
0<cr>
trd1y,none<cr> ‘de-activates any transducer
0<cr> ‘responds parameter ok
TRD1Z (Transducer Z – dBµV/m)
This command selects a Z-direction transducer (dBµV/m only) for the Isotropic Antenna measurement.
To turn a transducer off, use the string ‘NONE’:
Example: set<cr>
0<cr>
trd1z,ts-emf-z<cr> ‘selects transducer table “TS-EMF-Z”
0<cr> ‘responds parameter ok
Example 2: set<cr>
0<cr>
trd1z,none<cr> ‘de-activates any transducer
0<cr> ‘responds parameter ok
TRD2 (Transducer – dB )
This command selects a transducer (dB only). To turn a transducer off, use the string ‘NONE’.
Example: set<cr>
0<cr>
trd1,preamp<cr> ‘selects transducer table “preamp”
0<cr> ‘responds parameter ok
ACCESSORY (Connected Accessory)
This command gets or sets the connected accessory.
Value Accessory
0 Auto Detect
1 None
2 Bridge R&S FSH-Z2
3 Bridge R&S FSH-Z3
4 Power sensor
5 Isotropic Antenna
Example: set<cr>
0<cr>
accessory,0<cr> ‘Sets auto detection of accessory”
0<cr> ‘responds parameter ok
1157.3564.12 47 E-10
Command Description R&S FSH-K1
LIMDEF (Define Limit Line)
This command defines a limit line.The list of parameters are the following:
<name>,<description>,<x-unit>,<x-scale>,<y-unit>,<x0>,<y0>[,...<xn>,<yn>]
The parameter <name> and <description> are strings. The parameters x-unit and y-unit are listed in the
tables below:
Parameter x-unit:
Value Unit
0 Hz
1 Seconds
2 Meter
The parameter x-scale defines whether the x values are absolute values or relative values according to
the center x value:
Value x-scale
0 Absolute
1 Relative
Parameter y-unit:
Value Unit
0 dB
1 dBm
2 dBµV
3 dBmV
4 dBµV/m
5 dBµA/m
6 VSWR
7 Rho
8 Volt
9 Watt
10 Volt/m
11 Watt/m
12 Seconds
13 Degrees
The following example defines the limit line “LIMIT”, with description “Max” in dBm on the frequency
axis (Hz) as an absolute limit line with 4 values (100MHz -30dBm, 200MHz -10dBm, 300MHz -10dBm,
400MHz -30dBm):
Example: set<cr>
0<cr> ‘responds parameter ok
2
0<cr>
limdef,LIMIT,Max,0,0,1,100e6,-30,200e6,-10,300e6,
-10,400e6,-30<cr>
‘defines limit line “LIMIT”
Note: To replace an existing limit line in the instrument it has to be deleted first by using the LIMDEL
command described below.
1157.3564.12 48 E-10
R&S FSH-K1 Command Description
LIMDEL (Delete Limit Line)
This command deletes a limit line.
Example: cmd<cr>
0<cr>
limdel,LIMIT<cr> ‘deletes limit line “LIMIT”
0<cr> ‘responds parameter ok
LIMLIST (Available Limit Line List)
This command returns the list with available limit lines
Example: get<cr>
0<cr>
limlist<cr> ‘gets the limit line list
0<cr> ‘responds parameter ok
upper limit, lower limit, absolute limit<cr>
LIMLOW (Lower Limit Line)
This command selects the lower limit line. To turn a limit line off, use the string ‘NONE’.
Example: set<cr>
0<cr>
limlow,lowtest<cr> ‘selects lower limit line “LOWTEST”
0<cr> ‘responds parameter ok
LIMUPP (Upper Limit Line)
This command selects the upper limit line. To turn a limit line off, use the string ‘NONE’.
Example: set<cr>
0<cr>
limupp,hightest<cr> ‘selects upper limit line “HIGHTEST”
0<cr> ‘responds parameter ok
LIMPASS (Limits Passed Query)
This command returns the limit check status.
Value Limit Check
0 Unkown
1 Failed
2 Passed
Example: get<cr>
0<cr>
limpass<cr> ‘query limit check
0<cr> ‘responds parameter ok
2<cr> ‘limit check passed
1157.3564.12 49 E-10
Command Description R&S FSH-K1
LIMCHKREMOTE (Limit Check Remote Message)
This command enables the remote message (frequency/channel + level) on limit check and/or on
threshold limit fail. The instrument will send a message (frequency/channel and level) every time the
limit is exceeded.
Value Limit Check Remote
0 OFF
1
Example: get<cr>
0<cr> ‘responds parameter ok
123.456E6,23.5<cr> ‘limit exceeded
130.567E6,22.0<cr> ‘limit exceeded…..
…
Limit Check – Remote message on
fail
0<cr>
limchkremote,1<cr> ‘enable remote massage on limit fail
0<cr> ‘remote message on limit fail OFF
LIMBEEP
This command turns the limit line beep on or off.
Value
0 Off
1 On
Example: get<cr>
0<cr>
limbeep<cr> ‘query if limit line beep is switched on’
0<cr> ‘responds parameter ok’
1<cr> ‘limit beep is switched on’
LIMMSG
This command turns the limit line message on or off.
Value
0 Off
1 On
Example: set<cr>
0<cr>
limmsg,1<cr> ‘switch limit line message on’
0<cr> ‘responds parameter ok’
1157.3564.12 50 E-10
R&S FSH-K1 Command Description
THRLOW (Lower Threshold Line)
This command defines the lower threshold line (value). The unit of the threshold value is specified with
the Unit parameter. This command is available in Receiver / Scan Mode only.
Example: set<cr>
0<cr>
thrlow,30<cr> ‘specifies lower threshold line to -30 dBuV
0<cr> ‘responds parameter ok
THRUPP (Upper Threshold Line)
This command defines the upper threshold line (value). The unit of the threshold value is specified with
the Unit parameter. Available in Receiver / Scan Mode only.
Example: set<cr>
0<cr>
thrupp,70<cr> ‘specifies upper threshold line to 70 dBuV
0<cr> ‘responds parameter ok
THRPASS (Threshold Line Passed Query)
This command returns the threshold line check status. Available in Receiver / Scan Mode only.
Value Threshold Line Check
0 Unkown
1 Failed
2 Passed
Example: get<cr>
0<cr>
thrpass<cr> ‘query threshold line check
0<cr> ‘responds parameter ok‘
2<cr> ‘threshold check passed
1157.3564.12 51 E-10
Command Description R&S FSH-K1
Tracking Generator
This command set applies to model 13, model 23 and model 26 only.
Command Parameters Unit Comment
CALKIT [0…1]
CALKITLEN <numeric value> m
OFFSETLEN <numeric value> m
CAL_TGSCLRFL CMD command only
CAL_TGSCLTRN CMD command only
CAL_TGVECRFL CMD command only
CAL_TGVECTRN CMD command only
TRANSCAL GET command only
REFLCAL GET command only
TRANSVECTCAL GET command only
Option R&S FSH-K2
REFLVECTCAL GET command only
Option R&S FSH-K2
TGATT <numeric value> Model 23 & Model 26
(Serial No 100500 or higher)
TGLVL <numeric value> Model 23 only
TGMODE [0…4] Option R&S FSH-K2
CABLELOSS GET command only
Option R&S FSH-K2
ELCABLENVAL <numeric value> m / feet GET command only
Option R&S FSH-K2
VECTVOLT < numeric value>
VVREF
VVTOREF CMD command only
CALKIT
This command sets the tracking generator CalKit.
Value Reflection Vector Cal
0 FSH Calkit
1 User CalKit
Example: get<cr>
0<cr>
calkit<cr> ‘query the calkit
0<cr> ‘responds parameter ok
0<cr> ‘response: FSH CalKit selected
1157.3564.12 52 E-10
R&S FSH-K1 Command Description
CALKITLEN
This command defines the user calkit length. When set, also the user calkit will be selected. The
numeric values must be between 0 and 1 m with resolution of 0.01 mm.
Example: set<cr>
0<cr>
calkitlen,1e-4<cr> ‘sets the user calkit length to 0.1 mm
0<cr> ‘responds parameter ok
OFFSETLEN
This command defines the offset length. The numeric values must be between 0 and 100 m with
resolution of 0.01 mm.
Example: set<cr>
0<cr>
offsetlen,1<cr> ‘sets the offset length to 1 m
0<cr> ‘responds parameter ok
CAL_TGSCLRFL (Calibrate Tracking Generator Scalar Reflection)
This command initiates a scalar reflection calibration. This calibration contains two phases; OPEN
phase and SHORT phase. Connect OPEN before initiating calibration command, after first phase
reports ready connect SHORT and continue by issuing the command again.
Example: cmd<cr>
0<cr>
cal_tgsclrfl<cr> ‘initiate scalar reflection calibration (OPEN)
0<cr> ‘responds parameter ok
0<cr> ‘first phase ready
cal_tgsclrfl<cr> ‘continue scalar reflection calibration (SHORT)
0<cr> ‘responds parameter ok
0<cr> ‘scalar reflection calibration ready
CAL_TGSCLTRN (Calibrate Tracking Generator Scalar Transmission)
This command initiates a scalar transmission calibration. This calibration contains one phase;
calibrating THROUGH. Connect THROUGH before initiating calibration command.
Example: cmd<cr>
0<cr>
cal_tgscltrn<cr> ‘initiate scalar transmission calibration
0<cr> ‘responds parameter ok
0<cr> ‘scalar transmission calibration ready
1157.3564.12 53 E-10
Command Description R&S FSH-K1
CAL_TGVECRFL (Calibrate Tracking Generator Vector Reflection)
This command initiates a vector reflection calibration. This calibration contains three phases; OPEN
phase, SHORT phase and a LOAD phase. Connect OPEN before initiating calibration command, after
first phase reports ready connect SHORT and continue by issuing the command again. When OPEN
calibration reports ready connect LOAD and resume calibration by issuing the command again.
Example: cmd<cr>
0<cr>
cal_tgvecrfl<cr> ‘initiate vector reflection calibration (OPEN)
0<cr> ‘responds parameter ok
0<cr> ‘first phase ready
cal_tgsclrfl<cr> ‘continue scalar reflection calibration (SHORT)
0<cr> ‘responds parameter ok
0<cr> ‘second phase ready
cal_tgsclrfl<cr> ‘continue scalar reflection calibration (LOAD)
0<cr> ‘responds parameter ok
0<cr> ‘vector reflection calibration ready
CAL_TGVECTRN (Calibrate Tracking Generator Vector Transmission)
This command initiates a vector transmission calibration. This calibration contains two phases;
THROUGH phase and LOAD phase. Connect THROUGH before initiating calibration command, after
first phase reports ready connect LOAD and continue by issuing the command again.
Example: cmd<cr>
0<cr>
cal_tgvectrn<cr>
0<cr> ‘responds parameter ok
0<cr> ‘first phase ready
cal_tgvectrn<cr> ‘continue vector transmission calibration (LOAD)
0<cr> ‘responds parameter ok
0<cr> ‘vector transmission calibration ready
‘initiate vector transmission calibration (THROUGH)
TRANSCAL (Transmission Calibrated)
This command queries the state of the transmission calibration.
Value Transmission Cal
0 Not calibrated
1 Calibrated
Example: get<cr>
0<cr>
transcal<cr> ‘query state of transmission calibration
0<cr> ‘responds parameter ok
1<cr> ‘response: transmission calibrated
1157.3564.12 54 E-10
R&S FSH-K1 Command Description
REFLCAL (Reflection Calibrated)
This command queries the state of the reflection calibration.
Value Reflection Cal
0 Not calibrated
1 Calibrated
Example: get<cr>
0<cr>
reflcal<cr> ‘query state of reflection calibration
0<cr> ‘responds parameter ok
1<cr> ‘response: reflection calibrated
TRANSVECTCAL (Transmission Vector Calibrated)
This command queries the state of the transmission vector calibration. Applies to option R&S FSH-K2
only.
Value Transmission Vector Cal
0 Not calibrated
1 Calibrated
Example: get<cr>
0<cr>
transvectcal<cr> ‘query state of transmission vector calibration
0<cr> ‘responds parameter ok
1<cr> ‘response: transmission vector calibrated
REFLVECTCAL (Reflection Vector Calibrated)
This command queries the state of the reflection vector calibration. Applies to option R&S FSH-K2 only
Value Reflection Vector Cal
0 Not calibrated
1 Calibrated
Example: get<cr>
0<cr>
reflvectcal<cr> ‘query state of reflection vector calibration
0<cr> ‘responds parameter ok
1<cr> ‘response: reflection vector calibrated
TGATT (Tracking Generator Level Attenuation)
This command defines the tracking generator output level attenuation. Applies to model 23 & 26 only.
The numeric values vary between 0 dB and 20 dB in 1 db steps.
Example: set<cr>
0<cr>
tgatt,6<cr> ‘sets tracking generator attenuation to 6dB
0<cr> ‘responds parameter ok
1157.3564.12 55 E-10
Command Description R&S FSH-K1
TGLVL (Tracking Generator Level)
This command defines the tracking generator output level. Applies to model 23 only.
The only two numeric values which are valid are 0 and –20.
Example: set<cr>
0<cr>
tglvl,-20<cr> ‘sets tracking generator output level to –20 dBm
0<cr> ‘responds parameter ok
Example 2: set<cr>
0<cr>
tglvl,0<cr> ‘sets tracking generator output level to 0 dBm
0<cr> ‘responds parameter ok
TGMODE (Tracking Generator Mode)
This command defines the tracking generator mode. Applies to option R&S FSH-K2 only. This
command is only available when Vector calibrated.
Value Tracking Generator Mode
0 Magnitude
1 Cable loss meas
2 Phase
3 Smith Chart
4 Group Delay
5 Vector Voltage
Example: set<cr>
0<cr>
tgmode, 1<cr> ‘set tracking generator mode to cable loss meas
0<cr> ‘responds parameter ok
CABLELOSS (Cable Loss)
This command queries the measured cable loss
Example: get<cr>
0<cr>
cableloss<cr> ‘query cable loss measurement result
0<cr> ‘responds parameter ok
0.7<cr> ‘response: cable loss
1157.3564.12 56 E-10
R&S FSH-K1 Command Description
ELCABLENVAL (Electrical Cable Length)
This command queries the electrical cable length
Example: get<cr>
0<cr>
elcablenval<cr> ‘query electrical cable length measurement result
0<cr> ‘responds parameter ok
5.12<cr> ‘response: electrical cable length
Note: This command is only available when measurement mode is Phase and zero span is not active.
VECTVOLT (Vector Voltage)
This command queries the measured vector voltage values.
Example: get<cr>
0<cr>
vectvolt<cr> ‘query vector voltage measurement result
0<cr> ‘responds parameter ok
3.0,45<cr> ‘response: magnitude (dB), phase (degrees)
VVREF (Vector Voltage Reference)
This command queries the vector voltage reference values. To disable the vector voltage reference set
it to 0.
Example 1: get<cr>
0<cr>
vvref<cr> ‘query vector voltage reference
0<cr> ‘responds parameter ok
3.0,45<cr> ‘response: magnitude (dB), phase (degrees)
Example 2: set<cr>
0<cr>
vvref,0<cr> ‘disable vector voltage reference
0<cr> ‘responds parameter ok
VVTOREF (Vector Voltage To Reference)
This command will set the current vector voltage values as vector voltage reference. To disable the
vector voltage reference use VECTVOLTREF.
Example get: cmd<cr>
0<cr>
vvtoref<cr> ‘set vector voltage reference
0<cr> ‘responds parameter ok
1157.3564.12 57 E-10
Command Description R&S FSH-K1
Power Sensor
Command Parameters Unit Comment
PWR <numeric value> GET command only
REFL <numeric value> GET command only
ZERO CMD command only
PWRTOREF CMD command only
MEASTIME 0...2
REFLUNIT 0, 1 R&S FSH-Z44 only
PWRSSTD 0…7 R&S FSH-Z44 only
PWR (Power Level)
This command queries the power level measured by the sensor.
Example: get<cr>
0<cr>
pwr<cr> ‘query power level from sensor
0<cr> ‘responds parameter ok
-33.45<cr> ‘response: power
REFL (Reflection)
This command queries the reflection measured by the power sensor R&S FSH-Z44. The unit (dB or
VSWR ) depends on the setting of reflection unit (SET REFLUNIT command).
Example: get<cr>
0<cr>
refl<cr> ‘query reflection from sensor
0<cr> ‘responds parameter ok
2.54<cr> ‘response: reflection value
ZERO (Power Sensor Zeroing)
This command initiates the power sensor zeroing.
Example: cmd<cr>
0<cr>
zero<cr> ‘query power level from sensor
0<cr> ‘responds parameter ok
PWRTOREF (Power to Reference)
This command defines the current power level as the reference value.
Example: cmd<cr>
0<cr>
pwrtoref<cr> ‘defines power level as reference value
0<cr> ‘responds parameter ok
1157.3564.12 58 E-10
R&S FSH-K1 Command Description
MEASTIME (Measurement Time)
This command defines the measurement time for the power sensor (R&S FSH-Z1 and R&S FSH-Z18).
Value Measurement Time
0 Short
1 Normal
2 Long
Example: set<cr>
0<cr>
meastime,2<cr> ‘sets measurement time to “long”
0<cr> ‘responds parameter ok
REFLUNIT (Reflection Unit)
This command defines the reflection unit for the power sensor R&S FSH-Z44.
Value Reflection Unit
0 dB
1 VSWR
Example: set<cr>
0<cr>
reflunit,1<cr> ‘sets reflection unit to VSWR
0<cr> ‘responds parameter ok
PWRSSTD (Power Sensor Standard)
This command defines the standard used for the power sensor R&S FSH-Z44 measurements.
Value Channel Power Standard
0 User
1 GSM
2 EDGE
3 3GPP WCDMA
4 cdmaOne
5 cdma2000 1x
6 DVB-T
7 DAB
Example: set<cr>
0<cr>
pwrsstd,2<cr> ‘select EDGE as standard
0<cr> ‘responds parameter ok
1157.3564.12 59 E-10
Command Description R&S FSH-K1
Channel Power
Command Parameters Unit Comment
CHPWR <numeric value> GET command only
CHPWRSTD 0…3
CHPWRCSTD <string>
CHPWRUNIT 0…2
CHPWRBW <numeric value> Hz
LVLADJUST CMD command only
CHPWR (Channel Power)
This command queries the measured channel power.
Example: get<cr>
0<cr>
chpwr<cr> ‘query power level from sensor
0<cr> ‘responds parameter ok
-47.45<cr> ‘response: channel power
CHPWRSTD (Channel Power Standard)
This command defines the standard used for the channel power measurement.
Value Channel Power Standard
0 User
1 3GPP WCDMA
2 cdmaOne
3 cdma2000 1x
Example: set<cr>
0<cr>
chpwrstd,2<cr> ‘select cdmaOne as standard
0<cr> ‘responds parameter ok
Note: If any customized standard was previously selected a value of ‘4’ will be returned as a response
to a GET CHPWRSTD query.
CHPWRCSTD (Channel Power Customized Standard)
This command selects the customized standard for the channel power measurement previously loaded
with R&S FSHView software.
Example: set<cr>
0<cr>
chpwrcstd,MyStd<cr> ‘select MyStd as standard
0<cr> ‘responds parameter ok
1157.3564.12 60 E-10
R&S FSH-K1 Command Description
CHPWRUNIT (Channel Power Unit)
This command defines the unit used for the channel power measurement.
Value Channel Power Unit
0 dBm
1 dBmV
2 dB\V
Example: set<cr>
0<cr>
chpwrunit,1<cr> ‘set unit to dBmV
0<cr> ‘responds parameter ok
CHPWRBW (Channel Power Bandwidth)
This command defines the bandwidth used for channel power measurements.
Example: set<cr>
0<cr>
chpwrbw,3.5E6<cr> ‘set channel power bandwidth to 3.5 MHz
0<cr> ‘responds parameter ok
LVLADJUST (Level Adjust)
This command initiates a level adjustment for the channel power measurement.
Example: cmd<cr>
0<cr>
lvladjust<cr> ‘initiates level adjustment
0<cr> ‘responds parameter ok
Note: To check if the level adjustment is ready, the WAIT command can be used
1157.3564.12 61 E-10
Command Description R&S FSH-K1
Occupied Bandwidth
Command Parameters Unit Comment
OBW <numeric value> GET command only
OBWSTD 0…3
OBWCSTD <string>
OBWCHBW <numeric value> Hz
LVLADJUST CMD command only
OBW (Occupied Bandwidth)
This command queries the measured occupied bandwidth.
Example: get<cr>
0<cr>
obw<cr> ‘query power level from sensor
0<cr> ‘responds parameter ok
-22E6<cr> ‘response: occupied bandwidth
OBWSTD (Occupied Bandwidth Standard)
This command defines the standard used for the occupied bandwidth measurement.
Value Occupied Bandwidth Standard
0 User
1 3GPP WCDMA
2 cdmaOne
3 cdma2000 1x
Example: set<cr>
0<cr>
obwstd,1<cr> ‘select 3GPP WCDMA as standard
0<cr> ‘responds parameter ok
Note: If any customized standard was previously selected a value of ‘4’ will be returned as a response
to a GET OBWSTD query.
OBWCSTD (Occupied Bandwidth Customized Standard)
This command selects the customized standard for the occupied bandwidth measurement previously
loaded with R&S FSHView software.
Example: set<cr>
0<cr>
obwcstd,MyStd<cr> ‘select MyStd as standard
0<cr> ‘responds parameter ok
1157.3564.12 62 E-10
R&S FSH-K1 Command Description
OBWCHBW (Occupied Bandwidth Channel Bandwidth)
This command defines the bandwidth used for occupied bandwidth measurements.
Example: set<cr>
0<cr>
obwchbw,5E6<cr> ‘set channel bandwidth to 5 MHz
0<cr> ‘responds parameter ok
LVLADJUST (Level Adjust)
This command initiates a level adjustment for the occupied bandwidth measurement.
Example: cmd<cr>
0<cr>
lvladjust<cr> ‘initiates level adjustment
0<cr> ‘responds parameter ok
Note: To check if the level adjustment is ready, the WAIT command can be used
1157.3564.12 63 E-10
Command Description R&S FSH-K1
TDMA Power
Command Parameters Unit Comment
TDMAPWR <numeric value> GET command only
TDMASTD 0…1
MEASTIME <numeric value> s
LVLADJUST CMD command only
TDMAPWR (TDMA Power)
This command queries the measured TDMA power.
Example: get<cr>
0<cr>
tdmapwr<cr> ‘query power level from sensor
0<cr> ‘responds parameter ok
-32.45<cr> ‘response: TDMA power
TDMASTD (TDMA Power Standard)
This command defines the standard used for the TDMA power measurement.
Value TDMA Power Standard
0 User
1 GSM / EDGE
Example: set<cr>
0<cr>
tdmastd,1<cr> ‘select GSM/EDGE as standard
0<cr> ‘responds parameter ok
Note: If any customized standard was previously selected a value of ‘2’ will be returned as a response
to a GET TDMASTD query.
TDMACSTD (TDMA Customized Standard)
This command selects the customized standard for the TDMA power measurement previously loaded
with R&S FSHView software.
Example: set<cr>
0<cr>
tdmacstd,MyStd<cr> ‘select MyStd as standard
0<cr> ‘responds parameter ok
1157.3564.12 64 E-10
R&S FSH-K1 Command Description
MEASTIME (Measurement Time)
This command defines the measurement time for the TDMA power measurement.
Example: set<cr>
0<cr>
meastime,500E-6<cr> ‘sets measurement time to 500 \s
0<cr> ‘responds parameter ok
LVLADJUST (Level Adjust)
This command initiates a level adjustment for the TDMA power measurement.
Example: cmd<cr>
0<cr>
lvladjust<cr> ‘initiates level adjustment
0<cr> ‘responds parameter ok
Note: To check if the level adjustment is ready, the WAIT command can be used
1157.3564.12 65 E-10
Command Description R&S FSH-K1
Distance To Fault Measurement
The DTF Measurement requires the option R&S FSH-B1.
Command Parameters Unit Comment
CABLEMOD <string>
CABLELEN <numeric value> m / feet
CAL_DTF
DTFMODE 0...2
LENUNIT <meter> | <feet>
CABLEMOD (Cable Model)
This command selects the cable model.
To turn cable model selection off, use the string ‘NONE’.
Example: set<cr>
0<cr>
cablemod,rg58c<cr> ‘selects cable model “RG58C”
0<cr> ‘responds parameter ok
CABLELEN (Cable Length)
This command defines the cable length.
The unit of the length can either be Meter or Feet depending on the Length Unit setting. The cable
length is converted and rounded to meters internally.
Example: set<cr>
0<cr>
cablelen,12<cr> ‘sets cable length to 12 meter
0<cr> ‘responds parameter ok
CAL_DTF (Calibrate Distance To Fault)
This command calibrates the distance to fault measurement.
Example: cmd<cr>
0<cr>
cal_dtf<cr> ‘Initiates the actual calibration
0<cr> ‘responds parameter ok
0<cr> ‘calibration ready
1157.3564.12 66 E-10
R&S FSH-K1 Command Description
DTFMODE (DTF Measurement Mode) Power)
This command defines the measurement mode in DTF.
Value Channel Power Standard
0 DTF
1 Reflection
2 Spectrum
Example: set<cr>
0<cr>
dtfmode,2<cr> ‘set DTF mode to “Spectrum”
0<cr> ‘responds parameter ok
LENUNIT (Cable Length Unit)
This command sets the cable length unit to meters or feet.
Example: set<cr>
0<cr>
lenunit,feet<cr> ‘sets cable length unit to Feet
0<cr> ‘responds parameter ok
1157.3564.12 67 E-10
Command Description R&S FSH-K1
Receiver Mode
The Receiver Mode requires the option R&S FSH-K3.
Command Parameters Unit Comment
CHANNEL <numeric value>
CHMODE 0, 1 Fixed Channel Mode
CHTABLE <string>
LEVEL GET command only
MEASTIME <numeric value> s
SCANMODE 0, 1
SCANSTART <numeric value> Freq Scan Mode
SCANSTOP <numeric value> Freq Scan Mode
SCANSTEP <numeric value> Freq Scan Mode
FREQSTART <numeric value> Channel Scan Mode
FREQSTOP <numeric value> Channel Scan Mode
CHMODE (Channel Mode)
This command switches between the channel mode and frequency mode. Use the command
CHTABLE to define a channel table for the channel mode.
Value Channel Mode
0 Frequency Mode
1 Channel Mode
Example: set<cr>
0<cr>
chmode,1<cr> ‘selects channel mode
0<cr> ‘responds parameter ok
CHANNEL (Channel Number)
This command defines the channel number. Use CHTABLE command to select a channel table first.
Example: set<cr>
0<cr>
channel,55<cr> ‘selects channel no. 55
CHTABLE (Channel Table)
This command selects a channel table for the channel mode.
Example: set<cr>
0<cr>
chtable,FMBand<cr> ‘selects channel table “FMBand”
0<cr> ‘responds parameter ok
1157.3564.12 68 E-10
R&S FSH-K1 Command Description
LEVEL (Signal Level)
This command queries the signal level measured (fixed frequency/channel mode only).
Example: get<cr>
0<cr>
level<cr> ‘query signal level
0<cr> ‘responds parameter ok
45.6<cr> ‘response: signal level
MEASTIME (Measurement Time)
This command defines the measurement time for the receiver mode.
Example: set<cr>
0<cr>
meastime,5E-3<cr> ‘sets measurement time to 5 ms
0<cr> ‘responds parameter ok
SCANMODE (Scan Mode)
This command switches between frequency/channel scan mode and fixed frequency/channel mode.
Use the command CHMODE to toggle between frequency and channel mode.
Value Scan Mode
0 Fixed Freq/Channel Mode
1 Feq/Channel Scan Mode
Example: set<cr>
0<cr>
scanmode,1<cr> ‘selects scan mode
0<cr> ‘responds parameter ok
SCANSTART (Frequency Scan Start)
This command defines the scan start frequency for the frequency scan mode.
Example: set<cr>
0<cr>
scanstart,88E6<cr> ‘sets scan start frequency to 88 MHz
0<cr> ‘responds parameter ok
SCANSTOP (Frequency Scan Stop)
This command defines the scan stop frequency for the frequency scan mode.
Example: set<cr>
0<cr>
scanstop,108E6<cr> ‘sets scan stop frequency to 108 MHz
0<cr> ‘responds parameter ok
1157.3564.12 69 E-10
Command Description R&S FSH-K1
SCANSTEP (Frequency Scan Step)
This command defines the scan step frequency for the frequency scan mode.
Example: set<cr>
0<cr>
scanstep,200E3<cr> ‘sets scan step frequency to 200 kHz
0<cr> ‘responds parameter ok
FREQSTART (Channel Scan Start Frequency)
This command defines the start frequency for the channel scan mode.
Example: set<cr>
0<cr>
freqstart,100E6<cr> ‘sets scan start frequency to 100 MHz
0<cr> ‘responds parameter ok
FREQSTOP (Channel Scan Stop Frequency)
This command defines the stop frequency for the channel scan mode.
Example: set<cr>
0<cr>
freqstop,1E9<cr> ‘sets scan stop frequency to 1 GHz
0<cr> ‘responds parameter ok
1157.3564.12 70 E-10
R&S FSH-K1 Command Description
Carrier / Noise Measurement
Command Parameters Unit Comment
CNCHBW <numeric value> Hz
CNCSTD <string>
CNMANREFPWR 0, 1
CNMEASMODE 0...2
CNMODE 0, 1
CNNOISECOR 0, 1
CNNORM 0, 1
CNPILOTFRQ <numeric value> Hz
CNPWRDISP 0, 1
CNRATIOCHBW <numeric value> Hz
CNREFMEASMODE 0, 1, 2
CNREFPWR <numeric value>
CNUNIT 0...2
CNVALUE GET command only
CNVISIONFRQ <numeric value> Hz
LVLADJUST
CMD command only
CNCHBW (Carrier Noise Channel Bandwidth)
This command defines the bandwidth used for carrier noise measurements. It defines the channel
bandwidth of the reference measurement if the C/N reference measurement is selected and it defines
the channel bandwidth of the noise measurement if the C/N noise measurement is selected. The
measurement mode is selected by the command CNMODE.
Example: set<cr>
0<cr>
cnchbw,5E6<cr> ‘set channel bandwidth to 5 MHz
0<cr> ‘responds parameter ok
1157.3564.12 71 E-10
Command Description R&S FSH-K1
CNCSTD (Carrier Noise Customized Standard)
This command selects the customized standard for the carrier noise measurement previously loaded
with R&S FSHView software.
Example: set<cr>
0<cr>
cncstd,MyStd<cr> ‘select MyStd as standard
0<cr> ‘responds parameter ok
CNMANREFPWR (Carrier Noise Manual Ref Power Active)
This command defines if the manual ref power is active. If the manual reference power is selected a
reference power must be set (CNREFPWR). Otherwise the reference power of the reference power
measurement is applied.
Value Manual Ref Power Active
0 OFF
1 ON
Example: set<cr>
0<cr>
cnmanrefpwr,1<cr> ‘select manual reference power
0<cr> ‘responds parameter ok
CNMEASMODE (Carrier Noise Measurement Mode)
This command defines the kind of reference measurement mode if the reference measurement mode is
selected. It is used for the carrier noise measurement.
Value Measurement Mode
0 Digital Tx
1 Analog TV
2 CW Tx
Example: set<cr>
0<cr>
cnmeasmode,1<cr> ‘select Analog TV as measurement mode
0<cr> ‘responds parameter ok
CNMODE (Carrier Noise Mode)
This command defines if the C/N reference measurement or the C/N noise measurement is active.
Value C/N Noise Measurement Active
0 OFF
1 ON
Example: set<cr>
0<cr>
cnmode,0<cr> ‘select C/N reference measurement
0<cr> ‘responds parameter ok
1157.3564.12 72 E-10
R&S FSH-K1 Command Description
CNNOISECOR (Carrier Noise NOISE CORrection)
This command defines if the C/N noise correction mode.
Value C/N Noise Correction
0 OFF
1 ON
Example: set<cr>
0<cr>
cnnoisecor,0<cr> ‘disable C/N noise correction
0<cr> ‘responds parameter ok
CNNORM (Carrier Noise Norm)
This command defines the norm used for the noise measurement.
Value Norm
0 C/N
1 C/No
Example: set<cr>
0<cr>
cnnorm,1<cr> ‘select C/No as norm
0<cr> ‘responds parameter ok
CNPILOTFRQ (Carrier Noise Pilot Frequency)
This command defines the pilot frequency used for digital TV carrier noise measurements. It is only
available if the Digital TV standard 8-VSB/ATSC is selected. It defines the pilot frequency of the
reference measurement if the C/N reference measurement is selected and it defines the pilot frequency
of the noise measurement if the C/N noise measurement is selected. The measurement mode is
selected by the command CNMODE.
Example: set<cr>
0<cr>
cnpilotfrq,450E6<cr> ‘set pilot frequency to 450 MHz
0<cr> ‘responds parameter ok
1157.3564.12 73 E-10
Command Description R&S FSH-K1
CNPWRDISP (Carrier Noise Power Display)
This command turns the C/N power display on or off.
Value Power Display
0 OFF
1 ON
Example: set<cr>
0<cr>
cnpwrdisp,1<cr>
0<cr> ‘responds parameter ok
CNRATIOCHBW (Carrier Noise Ratio Channel Bandwidth)
This command defines the ratio channel bandwidth used for carrier noise measurements.
Example: set<cr>
0<cr>
cnratiochbw,5E6<cr> ‘set ratio channel bandwidth to 5 MHz
0<cr> ‘responds parameter ok
CNREFMEASMODE (Carrier Noise Reference measurement mode)
This command sets the reference measurement mode.
Value Reference Measurement Mode
0 Peak Power
1 Channel Power
2 Manual
Example: set<cr>
0<cr>
cnrefmeasmode,2<cr> ‘set reference measurement mode to manual
0<cr> ‘responds parameter ok
CNREFPWR (Carrier Noise Ref Power)
This command defines the reference power used for carrier noise measurements.
Example: set<cr>
0<cr>
cnrefpwr,400E-3<cr> ‘set ref power to 0.4
0<cr> ‘responds parameter ok
1157.3564.12 74 E-10
R&S FSH-K1 Command Description
CNUNIT (Carrier Noise Unit)
This command defines the unit used for the reference.
Value Unit
0 dBm
1 dBmV
2 dBuV
Example: set<cr>
0<cr>
cnunit,1<cr> ‘select dBmV as unit
0<cr> ‘responds parameter ok
CNVALUE (Carrier Noise Measurement Value)
This command queries the measured C/N value. The value depends on the CNMODE selected (either
C/N reference measurement or C/N Noise measurement).
Example: get<cr>
0<cr>
cnvalue<cr> ‘query C/N measurement
0<cr> ‘responds parameter ok
-20.3<cr> ‘response: C/N result
CNVISIONFRQ (Carrier Noise Vision Frequency)
This command defines the vision carrier frequency used for analog TV carrier noise measurements.
Example: set<cr>
0<cr>
cnvisionfrq,450E6<cr> ‘set vision carrier frequency to 450 MHz
0<cr> ‘responds parameter ok
LVLADJUST (Level Adjust)
This command initiates a level adjustment for carrier noise measurement. It is applied to the reference
channel if the reference measurement is selected and it is applied to the noise channel if the noise
measurement is selected.
Example: cmd<cr>
0<cr>
lvladjust<cr> ‘initiates level adjustment
0<cr> ‘responds parameter ok
Note: To check if the level adjustment is ready, the WAIT command can be used
1157.3564.12 75 E-10
Command Description R&S FSH-K1
WCDMA BTS CDP Measurement
The WCDMA Measurement requires the option R&S FSH-K4.
Command Parameters Unit Comment
ANTDIV <numeric value>
CARRFREQERR Hz GET command only
CPICHPWR <1…6> dBm
CPICHSLOTNR GET command only
CPICHSYMEVM % rms GET command only
PCCPCHPWR dBm GET command only
PCCPCHPWRREL dB GET command only
PCCPCHSYMEVM % rms GET command only
PSCHPWR dBm GET command only
PSCHPWRREL dB GET command only
PSCRCD <1…6>,<numeric value>
SSCHPWR dBm GET command only
SSCHPWRREL dB GET command only
SSCRCD <1…6>,<numeric value>
SYNCRESULT GET command only
TOTPWR dBm GET command only
AUTOSDSNGL CMD command only
AUTOSDMUL CMD command only
CPICHEIRAT dB GET command only
PCCPCHEIRAT dB GET command only
1157.3564.12 76 E-10
R&S FSH-K1 Command Description
ANTDIV (Antenna diversity)
This command defines the antenna diversity mode used for WCDMA measurements.
Value Antenna Diversity Mode
0 Antenna Div. mode OFF
1 Antenna Div. mode no. 1
2 Antenna Div. mode no. 2
Example: set<cr>
0<cr>
antdiv,1<cr> ‘set antenna diversity to type No. 1
0<cr> ‘responds parameter ok
CARRFREQERR (Carrier Frequency Error)
This command retrieves the carrier frequency error for WCDMA measurements. Unit is Hz.
Example: get<cr>
0<cr>
carrfreqerr<cr> ‘get carrier frequency error
0<cr> ‘responds parameter ok
0<cr> ‘Carrier frequency error is zero Hz
CPICHPWR (CPICH Power)
This command retrieves the P-CPICH Power measurement result for WCDMA measurements. Unit is
the current unit.
Optional Value Scrambling Code id
1…6 id 1…6
Example: get<cr>
0<cr>
cpichpwr<cr> ‘get CPICH power of scrambling code nr id 1
0<cr> ‘responds parameter ok
-9.5<cr> ‘CPICH power is -9.5 dBm
If an auto scrambling detection multiple has been performed successfully the command allows an
option parameter.
Example: get<cr>
0<cr>
cpichpwr,4<cr> ‘get CPICH Power of scrambling code id 4
0<cr> ‘responds parameter ok
13<cr> ‘CPICH Power is 13 dBm
CPICHSLOTNR (CPICH Slot Number)
This command retrieves the CPI slot number for WCDMA measurements.
Example: get<cr>
0<cr>
cpichslotnr<cr> ‘get CPICH Slot Number
0<cr> ‘responds parameter ok
0<cr> ‘CPICH slot number is ‘0’
1157.3564.12 77 E-10
Command Description R&S FSH-K1
CPICHSYMEVM (CPICH Symbol EVM)
This command retrieves the P-CPICH Symbol EVM measurement result for WCDMA measurements.
Unit is % rms.
Example: get<cr>
0<cr>
cpichsymevm<cr> ‘get CPICH Symbol EVM
0<cr> ‘responds parameter ok
23<cr> ‘CPICH Symbol EVM is 23 % rms
PCCPCHPWR (P-CCPCH Power)
This command retrieves the P-CCPCH Power measurement result for WCDMA measurements. Unit is
the current unit.
Example: get<cr>
0<cr>
pccpchpwr<cr> ‘get P-CCPCH Power
0<cr> ‘responds parameter ok
-26.8<cr> ‘P-CCPCH Power is -26.8 dBm
PCCPCHPWRREL (P-CCPCH Power relative to CPICH)
This command retrieves the P-CCPCH Power relative to the CPICH Power measurement result for
WCDMA measurements. Unit is in dB.
Example: get<cr>
0<cr>
pccpchpwrrel<cr> ‘get P-CCPCH Power relative to CPICH
0<cr> ‘responds parameter ok
-2.8<cr> ‘P-CCPCH Power is -2.8 dB lower then CPICH Power
PCCPCHSYMEVM (P-CCPCH Symbol EVM)
This command retrieves the P-CCPCH Symbol EVM measurement result for WCDMA measurements.
Unit is % rms.
Example: get<cr>
0<cr>
pccpchsymevm<cr> ‘get P-CCPCH Symbol EVM
0<cr> ‘responds parameter ok
63.9<cr> ‘P-CCPCH Symbol EVM is 63.9 % rms
PSCHPWR (P-SCH Power)
This command retrieves the P-SCH Power measurement result for WCDMA measurements. Unit is the
current unit
Example: get<cr>
0<cr>
pschpwr<cr> ‘get P-SCH Power
0<cr> ‘responds parameter ok
13<cr> ‘P-SCH Power is 13 dBm
1157.3564.12 78 E-10
R&S FSH-K1 Command Description
PSCHPWRREL (P-SCH Power relative to CPICH)
This command retrieves the P-SCH Power relative to CPICH measurement result for WCDMA
measurements. Unit is in dB
Example: get<cr>
0<cr>
pschpwrrel<cr> ‘get P-SCH Power relative to CPICH
0<cr> ‘responds parameter ok
3.2<cr> ‘P-SCH Power is 3.2 dB higher then CPICH
PSCRCD (Primary Scramble Code)
This command defines the primary part of the scrambling code. The scrambling code is divided into 2
parts, a primary and a secondary part.
Valid input for primary scrambling code varies from 0 to 1535 (0x00 – 0x600-1). From the primary and
secondary scrambling codes the common scrambling code can be calculated as follows.
ScrScrScr
16 +=
Example: set<cr>
0<cr>
pscrcd,123<cr> ‘set prim. scramb. code to 123
0<cr> ‘responds parameter ok
If an auto scrambling detection multiple has been performed successfully the get command allows an
option parameter.
Optional Value Scrambling Code id
1…6 id 1…6
sec
ondaryprimaryBS
Example: get<cr>
0<cr>
pscrcd,4<cr> ‘get prim scrambling code of id 4
0<cr> ‘responds parameter ok
1<cr> ‘prim scambling code number is 1
SSCHPWR (S-SCH Power)
This command retrieves the S-SCH Power measurement result for WCDMA measurements. Unit is the
current unit.
Example: get<cr>
0<cr>
sschpwr<cr> ‘get S-SCH Power
0<cr> ‘responds parameter ok
-87.1<cr> ‘S-SCH Power is -87.1 dBm
SSCHPWRREL (S-SCH Power relative to CPICH)
This command retrieves the S-SCH Power relative to CPICH measurement result for WCDMA
measurements. Unit is dB.
Example: get<cr>
0<cr>
sschpwrrel<cr> ‘get S-SCH Power relative to CPICH
0<cr> ‘responds parameter ok
-7.1<cr> ‘S-SCH Power is -7.1 dB lower then CPICH
1157.3564.12 79 E-10
Command Description R&S FSH-K1
SSCRCD (Secondary Scramble Code)
This command defines the secondary part of the scrambling code. The scrambling code is divided into
2 parts, a primary and a secondary part.
Valid input for secondary code varies from 0 to 15 (0x0 – 0x10-1). From the primary and secondary
scrambling codes the common scrambling code can be calculated as follows:
ScrScrScr
16 +=
Example: set<cr>
0<cr>
sscrcd,8<cr> ‘set sec. scrambling code nr to 8
0<cr> ‘responds parameter ok
If an auto scrambling detection multiple has been performed successfully the get command allows an
option parameter.
Optional Value Scrambling Code id
1…6 id 1…6
Example: get<cr>
0<cr>
sscrcd,4<cr> ‘get sec scrambling code nr of id 4
0<cr> ‘responds parameter ok
0<cr> ‘sec scambling code number is 0
sec
ondaryprimaryBS
SYNCRESULT (Synchronization result)
This command retrieves the synchronization result for the WDMA measurement.
Value Synchronization result
0 Synchronization OK
1 Invalid synchronization
2 Incorrect antenna diversity setting
3 Incorrect sent CPICH symbols
4 Incorrect center frequency
5 Incorrect primary or secondary scrambling code
Example: get<cr>
0<cr>
syncresult<cr> ‘get synchronization result
0<cr> ‘responds parameter ok
2<cr> ‘sync. result: SYNC_RESULT_INCORR_ANTENNA_DIV
1157.3564.12 80 E-10
R&S FSH-K1 Command Description
TOTPWR (Total Power)
This command retrieves the total power measurement result for WCDMA measurements. Unit is the
current unit.
Example: get<cr>
0<cr>
totpwr<cr> ‘get total power
0<cr> ‘responds parameter ok
-87<cr> ‘Total power is -87 dBm
AUTOSDSNGL (Auto Scrambling Detection Single)
This command starts the auto scrambling detection single.
Example: cmd<cr>
0<cr>
autosdsngl<cr> ‘start auto scrambling detection single
0<cr> ‘responds parameter ok
AUTOSDMUL (Auto Scrambling Detection Multiple)
This command starts the auto scrambling detection multiple.
Example: cmd<cr>
0<cr>
autosdsngl<cr> ‘start auto scrambling detection multiple
0<cr> ‘responds parameter ok
CPICHEIRAT (P-CPICH Ec/Io)
This command retrieves the CPICH Ec/Io measurement result for WCDMA measurements. Unit is dB.
Example: get<cr>
0<cr>
cpicheirat<cr> ‘get CPICH Ec/Io
0<cr> ‘responds parameter ok
-26.8<cr> ‘CPICH Ec/Io is -26.8 dB
PCCPCHEIRAT (P-CCPCH Ec/Io)
This command retrieves the P-CCPCH Ec/Io measurement result for WCDMA measurements. Unit is
dB.
Example: get<cr>
0<cr>
pccpcheirat<cr> ‘get P-CCPCH Ec/Io
0<cr> ‘responds parameter ok
-26.8<cr> ‘P-CCPCH Ec/Io is -26.8 dB
1157.3564.12 81 E-10
Programming Examples R&S FSH-K1
Programming Examples
The following examples are code snippets in Visual Basic (VB6).
Initialize Communication with R&S FSH
Public Function FSHInit(ByVal Port As Integer, ByVal Speed As Long,
Optional ByVal ErrorCode As String) As Boolean
Rem Initialize communication with FSH
Rem Return TRUE if device initialization was successful
Rem Return FALSE otherwise e.g. the device was not found
With MainForm.FSHCommC
.CommPort = Port
.Settings = Trim$(Str$(Speed)) + ",N,8,1"
.InBufferSize = 1000
.PortOpen = True
.InBufferCount = 0
End With
InBuffer = vbNullString
End Function
‘-------------------------------------------
Poll R&S FSH until <cr> received
Public Function PollFSH() As String
Dim CrPos As Long
With MainForm.FSHCommC
Do
InBuffer = InBuffer + .Input
DoEvents
CrPos = InStr(1, InBuffer, vbCr)
Loop Until CrPos > 0
PollFSH = Left$(InBuffer, CrPos - 1)
InBuffer = Mid$(InBuffer, CrPos + 1)
End With
End Function
‘-------------------------------------------
Send CMD Command to R&S FSH
Public Function FSHCmd(ByVal Command As String) As Boolean
Dim TempError As Integer
InBuffer = vbNullString
FSHCmd = False
With MainForm.FSHCommC
.Output = "cmd" + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
.Output = Command + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
FSHCmd = True
Else
DebugMsg "CMD error" + Str(TempError) + " for command <" + Command + ">"
End If
Else
DebugMsg "CMD error" + Str(TempError) + " for command <" + Command + ">"
End If
End With
End Function
‘-------------------------------------------
1157.3564.12 82 E-10
R&S FSH-K1 Programming Examples
Send SET Command to R&S FSH
Public Function FSHSet(ByVal Command As String) As Boolean
Dim TempError As Integer
InBuffer = vbNullString
FSHSet = False
With MainForm.FSHCommC
.Output = "set" + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
.Output = Command + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
FSHSet = True
Else
ErrorMsg "SET error" + Str(TempError) + " for command <" + Command + ">"
End If
Else
ErrorMsg "SET error" + Str(TempError) + " for command <" + Command + ">"
End If
End With
End Function
‘-------------------------------------------
Send GET Command to R&S FSH and Read Response
Public Function FSHGet(ByVal Command As String, ByRef Buffer As String) As Boolean
Dim TempError As Integer
InBuffer = vbNullString
FSHGet = False
With MainForm.FSHCommC
.Output = "get" + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
.Output = Command + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
Sleep 50
Buffer = PollFSH
FSHGet = True
Else
ErrorMsg "GET error" + Str(TempError) + " for command <" + Command + ">"
End If
Else
ErrorMsg "GET error" + Str(TempError) + " for command <" + Command + ">"
End If
End With
End Function
‘-------------------------------------------
Example: Program Instrument Setup
Private Sub FSHSetup ()
Dim Buffer As String
FSHCmd "REMOTE" ‘ Set FSH to Remote State
FSHGet "IDN?", Buffer ‘ Query instrument ID
FSHCmd "PRESET" ‘ Preset FSH settings
FSHSet "FREQ,950E6" ‘ Set Center Frequency to 950 MHz
FSHSet "SPAN,5E6" ‘ Set Span to 5 MHz
FSHCmd "LOCAL" ‘ Return to Local Mode
End Sub
‘-------------------------------------------
1157.3564.12 83 E-10
Programming Examples R&S FSH-K1
Read Binary Trace Data from R&S FSH
Public Function FSHGetTraceBin(ByRef Values() As Long) As Boolean
Dim InBuffer As String
Dim TempError As Integer
InBuffer = vbNullString
FSHGetTraceBin = False
With MainForm.FSHCommC
.Output = "GET" + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
.Output = "TRACEBIN" + vbCr
TempError = Val(PollFSH)
If TempError = 0 Then
InBuffer = PollFSHBin(1205) ‘ 4 x 301 bins with 4 bytes
AsString.Buffer = StrConv(InBuffer, vbFromUnicode)
LSet AsValues = AsString
Values = AsValues.SValues
ReDim Preserve Values(0 To 300)
FSHGetTraceBin = True
Else
ErrorMsg "GET error" + Str(TempError) + " for command <TRACEBIN>"
End If
Else
ErrorMsg "GET error" + Str(TempError) + " for command <TRACEBIN>"
End If
End With
End Function
‘-------------------------------------------
Poll Input Buffer until Number of Bytes are Received
Public Function PollFSHBin(ByVal BufferLen As Long) As String
Dim CrPos As Long
With MainForm.FSHCommC
Do
InBuffer = InBuffer + .Input
DoEvents
DebugMsg "BIN-BUFFER-LEN: " + Str(Len(InBuffer))
Loop Until Len(InBuffer) >= BufferLen
PollFSHBin = Left$(InBuffer, BufferLen)
InBuffer = Mid$(InBuffer, BufferLen + 1)
End With
End Function
1157.3564.12 84 E-10
Loading...
