R&S
ESW
EMI Test Receiver
Getting Started
(=LaF2)
1328492202
Version 09
This manual describes the following R&S®ESW models:
●
R&S®ESW8 (1328.4100K08)
●
R&S®ESW8 (1328.4100K09)
●
R&S®ESW26 (1328.4100K26)
●
R&S®ESW26 (1328.4100K27)
●
R&S®ESW44 (1328.4100K44)
●
R&S®ESW44 (1328.4100K45)
The contents of this manual correspond to firmware version 2.10 and higher.
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1328.4922.02 | Version 09 | R&S®ESW
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g.
R&S®ESW is indicated as R&S ESW.
R&S®ESW
Contents
1 Safety and Regulatory Information...................................... 7
1.1 Safety Instructions................................................................................7
1.2 Warning Messages in the Documentation........................................12
1.3 Korea Certification Class B................................................................13
2 Documentation Overview....................................................14
2.1 Getting Started Manual.......................................................................14
2.2 User Manuals and Help...................................................................... 14
2.3 Service Manual....................................................................................15
Contents
2.4 Instrument Security Procedures....................................................... 15
2.5 Basic Safety Instructions................................................................... 15
2.6 Data Sheets and Brochures............................................................... 15
2.7 Release Notes and Open Source Acknowledgment (OSA).............16
2.8 Application Notes, Application Cards, White Papers, etc...............16
3 Conventions Used in the Documentation......................... 17
3.1 Typographical Conventions...............................................................17
3.2 Conventions for Procedure Descriptions.........................................17
3.3 Notes on Screenshots........................................................................ 18
4 Preparing for Use.................................................................19
4.1 Lifting and Carrying............................................................................19
4.2 Unpacking and Checking................................................................... 19
4.3 Choosing the Operating Site............................................................. 20
4.4 Setting Up the Product....................................................................... 20
4.4.1 Placing the Product on a Bench Top.....................................................21
4.4.2 Mounting the R&S ESW in a Rack........................................................22
3Getting Started 1328.4922.02 ─ 09
R&S®ESW
4.5 Connecting the AC Power..................................................................22
4.6 Switching the Instrument On and Off............................................... 23
4.7 Connecting to LAN............................................................................. 24
4.8 Connecting a Keyboard......................................................................26
4.9 Connecting an External Monitor........................................................26
4.10 Windows Operating System...............................................................28
4.11 Logging On..........................................................................................30
4.12 Checking the Supplied Options.........................................................32
4.13 Performing a Self-Alignment............................................................. 33
4.14 Considerations for Test Setup........................................................... 33
4.15 Protecting Data Using the Secure User Mode..................................34
Contents
5 Instrument Tour................................................................... 38
5.1 The Front Panel...................................................................................38
5.1.1 Display (Touchscreen).......................................................................... 39
5.1.2 Power Key.............................................................................................40
5.1.3 System Control Keys............................................................................ 40
5.1.4 USB Ports............................................................................................. 41
5.1.5 Probe Power Connector (3 and 5 Pins)................................................ 41
5.1.6 Headphone Jack and Volume Control.................................................. 42
5.1.7 Fast Access Knobs............................................................................... 42
5.1.8 RF Inputs (50 Ω)................................................................................... 42
5.1.9 Trigger Input and Output.......................................................................43
5.1.10 Navigation Controls...............................................................................44
5.1.11 Keypad..................................................................................................45
5.1.12 The Function Keys................................................................................ 46
5.2 The Rear Panel.................................................................................... 48
5.2.1 Removable Hard Disk........................................................................... 49
4Getting Started 1328.4922.02 ─ 09
R&S®ESW
5.2.2 AC Power Supply Connection and Main Power Switch........................ 49
5.2.3 Display Port and DVI.............................................................................50
5.2.4 LAN Connector..................................................................................... 50
5.2.5 USB Ports............................................................................................. 50
5.2.6 IF / Video / Demod Output.................................................................... 50
5.2.7 Sync Trigger Input and Output..............................................................51
5.2.8 GPIB Interface...................................................................................... 51
5.2.9 Aux. Port............................................................................................... 51
5.2.10 External Generator Control Option (R&S ESW-B10)............................51
5.2.11 OCXO (Optional)...................................................................................52
5.2.12 REF INPUT / REF OUTPUT................................................................. 52
Contents
5.2.13 Labels on R&S ESW.............................................................................53
5.2.14 Device ID.............................................................................................. 53
6 Operating the Instrument....................................................55
6.1 Understanding the Display Information............................................55
6.1.1 Channel Bar.......................................................................................... 57
6.1.2 Window Title Bar...................................................................................59
6.1.3 Marker Information................................................................................61
6.1.4 Frequency and Span Information in Diagram Footer............................62
6.1.5 Instrument and Status Information........................................................62
6.1.6 Error Information................................................................................... 63
6.2 Accessing Functions..........................................................................64
6.2.1 Toolbar.................................................................................................. 65
6.2.2 Softkeys................................................................................................ 67
6.2.3 Context Menus......................................................................................67
6.2.4 On-screen Keyboard.............................................................................68
6.3 Changing the Focus........................................................................... 69
5Getting Started 1328.4922.02 ─ 09
R&S®ESW
6.4 Entering Data.......................................................................................69
6.4.1 Entering Numeric Parameters...............................................................70
6.4.2 Entering Alphanumeric Parameters...................................................... 70
6.5 Touchscreen Gestures....................................................................... 72
6.6 Displaying Results..............................................................................76
6.6.1 Activating and Deactivating Channels.................................................. 76
6.6.2 Laying out the Result Display with the SmartGrid.................................78
6.6.3 Changing the Size of Windows............................................................. 82
6.6.4 Switching Between a Split and Maximized Window Display.................83
6.6.5 Changing the Display............................................................................84
6.7 Getting Help.........................................................................................84
Contents
6.8 Remote Control................................................................................... 85
6.8.1 Remote Desktop Connection................................................................ 86
6.8.2 Connecting a PC via the GPIB Interface...............................................86
7 Contacting Customer Support........................................... 87
Index..................................................................................... 88
6Getting Started 1328.4922.02 ─ 09
R&S®ESW
Safety and Regulatory Information
Safety Instructions
1 Safety and Regulatory Information
The product documentation helps you use the product safely and efficiently. Follow the instructions provided here and in the Chapter 1.1, "Safety Instructions",
on page 7.
Intended use
The product is intended for the development, production and verification of electronic components and devices in industrial, administrative, and laboratory environments. Use the product only for its designated purpose. Observe the operating
conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential
dangers and gives instructions on how to prevent personal injury or damage
caused by dangerous situations. Safety information is provided as follows:
●
In Chapter 1.1, "Safety Instructions", on page 7. The same information is
provided in many languages as printed "Safety Instructions". The printed
"Safety Instructions" are delivered with the product.
●
Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
1.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured
according to the highest technical standards. To use the products safely, follow
the instructions provided here and in the product documentation. Keep the product documentation nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Intended use and limits are described in the product documentation such as the data
sheet, manuals and the printed "Safety Instructions". If you are unsure about the
appropriate use, contact Rohde & Schwarz customer service.
Using the product requires specialists or specially trained personnel. These users
also need sound knowledge of at least one of the languages in which the user
interfaces and the product documentation are available.
7Getting Started 1328.4922.02 ─ 09
R&S®ESW
Never open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. If any part of the product is
damaged or broken, stop using the product. Contact Rohde & Schwarz customer
service at http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The maximum weight of the product is provided in the data sheet. To move the
product safely, you can use lifting or transporting equipment such as lift trucks
and forklifts. Follow the instructions provided by the equipment manufacturer.
The product is heavy. Do not move or carry the product by yourself. A single person can only carry a maximum of 18 kg safely depending on age, gender and
physical condition. Look up the maximum weight in the data sheet. Use the product handles to move or carry the product. Do not lift by the accessories mounted
on the product. Accessories are not designed to carry the weight of the product.
Safety and Regulatory Information
Safety Instructions
To move the product safely, you can use lifting or transporting equipment such as
lift trucks and forklifts. Follow the instructions provided by the equipment manufacturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that
enters can electrically connect the casing with live parts, which can lead to electric shock, serious personal injury or death if you touch the casing. If
Rohde & Schwarz provides accessories designed for your product, e.g. a carrying
bag, you can use the product outdoors.
Unless otherwise specified, you can operate the product up to an altitude of
2000 m above sea level. The product is suitable for pollution degree 2 environments where nonconductive contamination can occur. For more information on
environmental conditions such as ambient temperature and humidity, see the
data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the
product facing down. If the product is designed for different positions, secure the
product so that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure
stability. The feet can collapse if they are not folded out completely or if the prod-
8Getting Started 1328.4922.02 ─ 09
R&S®ESW
uct is moved without lifting it. The foldable feet are designed to carry the weight of
the product, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and
cause injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity
and stability. Observe the specifications of the rack manufacturer. Always install
the products from the bottom shelf to the top shelf so that the rack stands
securely. Secure the product so that it cannot fall off the rack.
Connecting to power
The product is an overvoltage category II product. Connect the product to a fixed
installation used to supply energy-consuming equipment such as household
appliances and similar loads. Keep in mind that electrically powered products
have risks, such as electric shock, fire, personal injury or even death.
Safety and Regulatory Information
Safety Instructions
Take the following measures for your safety:
●
Before switching on the product, ensure that the voltage and frequency indicated on the product match the available power source. If the power adapter
does not adjust automatically, set the correct value and check the rating of the
fuse.
●
If a product has an exchangeable fuse, its type and characteristics are indicated next to the fuse holder. Before changing the fuse, switch off the instrument
and disconnect it from the power source. How to change the fuse is described
in the product documentation.
●
Only use the power cable delivered with the product. It complies with countryspecific safety requirements. Only insert the plug into an outlet with protective
conductor terminal.
●
Only use intact cables and route them carefully so that they cannot be damaged. Check the power cables regularly to ensure that they are undamaged.
Also ensure that nobody can trip over loose cables.
●
If the product needs an external power supply, use the power supply that is
delivered with the product or that is recommended in the product documentation or a power supply that conforms to the country-specific regulations.
●
Only connect the product to a power source with a fuse protection of maximum 20 A.
●
Ensure that you can disconnect the product from the power source at any
time. Pull the power plug to disconnect the product. The power plug must be
easily accessible. If the product is integrated into a system that does not meet
9Getting Started 1328.4922.02 ─ 09
R&S®ESW
these requirements, provide an easily accessible circuit breaker at the system
level.
Using laser products
Lasers are classified according to their potential risk. If exposure to the laser
beam is possible, the product is labeled as shown in the table explaining the
safety labels.
Class 1M lasers
Safe for the naked eye. If you look into the laser beam with optical instruments
such as binoculars or eye loupes, you risk damaging your eyes.
Class 2 lasers
If you stare into the beam, you risk damaging your eyes.
Safety and Regulatory Information
Safety Instructions
Handling batteries safely
The product contains exchangeable or built-in lithium polymer or lithium ion cells
or batteries. The use of the word battery in the following always means all types.
Only the battery contents are potentially hazardous. As long as a battery is
undamaged and the seals remain intact, there is no danger.
Impact, shock or heat can cause damage such as dents, punctures and other
deformations. A damaged battery poses a risk of personal injury. Handle a damaged or leaking battery with extreme care. Immediately ventilate the area since
the battery releases harmful gases. If you come into contact with the battery fluid,
immediately remove all contaminated clothing. Irritation can occur if the battery
fluid comes in contact with your skin or eyes. Immediately and thoroughly rinse
your skin or eyes with water and seek medical aid.
For safe handling, follow these rules:
●
Do not short-circuit the battery.
●
Do not mechanically damage the battery. Do not open or disassemble the battery.
●
Do not expose the battery to high temperatures such as open flames, hot surfaces and sunlight.
●
Only use the battery with the designated Rohde & Schwarz product.
10Getting Started 1328.4922.02 ─ 09
R&S®ESW
Safety and Regulatory Information
Safety Instructions
●
Only use the appropriate Rohde & Schwarz charger to charge the batteries. If
the batteries are improperly charged, there is a risk of explosion. For charging
and discharging temperature ranges, see the product documentation.
●
Replace exchangeable batteries only with the same battery type.
●
Store the battery in the product or use the product packaging.
●
Dispose of exchangeable batteries separately from normal household waste
as specified by the local waste disposal agency.
If you disregard these rules, you risk serious personal injury or even death due to
explosion, fire or hazardous chemical substances. The product documentation
provides further details.
If exchangeable batteries or products with built-in batteries are defective, contact
the Rohde & Schwarz customer service. Rohde & Schwarz classifies the severity
of the defect. When returning batteries or Rohde & Schwarz products containing
batteries, use a carrier qualified to transport dangerous goods and notify the carrier of this classification. Follow the carrier’s transport stipulations in line with
IATA-DGR, IMDG-Code, ADR or RID.
Connecting headphones
Take the following measures to prevent hearing damage. Before using headphones, check the volume and reduce it if necessary. If you monitor varying signal levels, take off the headphones and wait until the signal has settled. Then
adjust the volume.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that
the casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Heavy product
Be careful when lifting, moving or carrying the product. Carrying the product requires
a sufficient number of persons or transport equipment.
11Getting Started 1328.4922.02 ─ 09
R&S®ESW
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This
connection protects you against electric shock if an electric problem occurs.
Warning: laser beam
The product contains a laser.
Avoid exposure to direct or reflected laser beam.
Safety and Regulatory Information
Warning Messages in the Documentation
1.2 Warning Messages in the Documentation
A warning message points out a risk or danger that you need to be aware of. The
signal word indicates the severity of the safety hazard and how likely it will occur
if you do not follow the safety precautions.
WARNING
Potentially hazardous situation. Could result in death or serious injury if not avoided.
CAUTION
Potentially hazardous situation. Could result in minor or moderate injury if not
avoided.
NOTICE
Potential risks of damage. Could result in damage to the supported product or to
other property.
12Getting Started 1328.4922.02 ─ 09
R&S®ESW
Safety and Regulatory Information
Korea Certification Class B
1.3 Korea Certification Class B
이 기기는 가정용(B급) 전자파 적합기기로서 주로 가정에서 사용하는 것을 목적으
로 하며, 모든 지역에서 사용할 수 있습니다.
13Getting Started 1328.4922.02 ─ 09
R&S®ESW
Documentation Overview
User Manuals and Help
2 Documentation Overview
This section provides an overview of the R&S ESW user documentation. You find
it on the product page at:
www.rohde-schwarz.com/manual/esw
2.1 Getting Started Manual
Introduces the R&S ESW and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general
information, e.g. safety instructions, etc.
A printed version is delivered with the instrument. A PDF version is available for
download on the Internet.
2.2 User Manuals and Help
Separate user manuals are provided for the base unit and the firmware applications:
●
Base unit manual
Contains the description of all instrument modes and functions. It also provides an introduction to remote control, a complete description of the remote
control commands with programming examples, and information on maintenance, instrument interfaces and error messages. Includes the contents of the
getting started manual.
●
Manuals for (optional) firmware applications
Contains the description of the specific functions of a firmware application,
including remote control commands. Basic information on operating the
R&S ESW is not included.
The contents of the user manuals are available as help in the R&S ESW. The
help offers quick, context-sensitive access to the complete information for the
base unit and the firmware applications.
All user manuals are also available for download or for immediate display on the
Internet.
14Getting Started 1328.4922.02 ─ 09
R&S®ESW
Documentation Overview
Data Sheets and Brochures
2.3 Service Manual
Describes the performance test for checking the rated specifications, module
replacement and repair, firmware update, troubleshooting and fault elimination,
and contains mechanical drawings and spare part lists.
The service manual is available for download for registered users on the global
Rohde & Schwarz information system (GLORIS):
https://gloris.rohde-schwarz.com
2.4 Instrument Security Procedures
Deals with security issues when working with the R&S ESW in secure areas. It is
available for download on the Internet.
2.5 Basic Safety Instructions
Contains safety instructions, operating conditions and further important information. The printed document is delivered with the instrument.
2.6 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S ESW. It also lists
the options and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/esw
15Getting Started 1328.4922.02 ─ 09
R&S®ESW
Application Notes, Application Cards, White Papers, etc.
Documentation Overview
2.7 Release Notes and Open Source Acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current firmware version, and describe the firmware installation.
The open source acknowledgment document provides verbatim license texts of
the used open source software.
See www.rohde-schwarz.com/firmware/esw
2.8 Application Notes, Application Cards, White Papers, etc.
These documents deal with special applications or background information on
particular topics.
See www.rohde-schwarz.com/application/esw
16Getting Started 1328.4922.02 ─ 09
R&S®ESW
Conventions Used in the Documentation
Conventions for Procedure Descriptions
3 Conventions Used in the Documentation
3.1 Typographical Conventions
The following text markers are used throughout this documentation:
Convention Description
"Graphical user interface
elements"
[Keys] Key and knob names are enclosed by square brackets.
Filenames, commands,
program code
Input Input to be entered by the user is displayed in italics.
Links Links that you can click are displayed in blue font.
"References" References to other parts of the documentation are enclosed by
All names of graphical user interface elements on the screen,
such as dialog boxes, menus, options, buttons, and softkeys are
enclosed by quotation marks.
Filenames, commands, coding samples and screen output are
distinguished by their font.
quotation marks.
3.2 Conventions for Procedure Descriptions
When operating the instrument, several alternative methods may be available to
perform the same task. In this case, the procedure using the touchscreen is
described. Any elements that can be activated by touching can also be clicked
using an additionally connected mouse. The alternative procedure using the keys
on the instrument or the on-screen keyboard is only described if it deviates from
the standard operating procedures.
The term "select" may refer to any of the described methods, i.e. using a finger on
the touchscreen, a mouse pointer in the display, or a key on the instrument or on
a keyboard.
17Getting Started 1328.4922.02 ─ 09
R&S®ESW
Conventions Used in the Documentation
Notes on Screenshots
3.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions
and possible interdependencies between parameters. The shown values may not
represent realistic usage scenarios.
The screenshots usually show a fully equipped product, that is: with all options
installed. Thus, some functions shown in the screenshots may not be available in
your particular product configuration.
18Getting Started 1328.4922.02 ─ 09
R&S®ESW
Unpacking and Checking
Preparing for Use
4 Preparing for Use
Here, you can find basic information about setting up the instrument for the first
time.
● Lifting and Carrying......................................................................................... 19
● Unpacking and Checking................................................................................ 19
● Choosing the Operating Site........................................................................... 20
● Setting Up the Product.................................................................................... 20
● Connecting the AC Power...............................................................................22
● Switching the Instrument On and Off.............................................................. 23
● Connecting to LAN.......................................................................................... 24
● Connecting a Keyboard...................................................................................26
● Connecting an External Monitor......................................................................26
● Windows Operating System............................................................................28
● Logging On......................................................................................................30
● Checking the Supplied Options.......................................................................32
● Performing a Self-Alignment........................................................................... 33
● Considerations for Test Setup......................................................................... 33
● Protecting Data Using the Secure User Mode................................................ 34
4.1 Lifting and Carrying
The carrying handles are designed to lift or carry the instrument. Do not apply
excessive external force to the handles.
See "Lifting and carrying the product" on page 8.
4.2 Unpacking and Checking
1. Unpack the R&S ESW carefully.
2. Retain the original packing material. Use it when transporting or shipping the
R&S ESW later.
3. Using the delivery notes, check the equipment for completeness.
19Getting Started 1328.4922.02 ─ 09
R&S®ESW
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact
Rohde & Schwarz.
Preparing for Use
Setting Up the Product
4.3 Choosing the Operating Site
Specific operating conditions ensure proper operation and avoid damage to the
product and connected devices. For information on environmental conditions
such as ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 8.
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate
the product. The EMC class of the product is given in the data sheet under "General data".
●
Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network
that supplies residential buildings
●
Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and
radiated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
4.4 Setting Up the Product
See also:
●
"Setting up the product" on page 8
●
"Intended use" on page 7
<xref>
20Getting Started 1328.4922.02 ─ 09
R&S®ESW
Preparing for Use
Setting Up the Product
4.4.1 Placing the Product on a Bench Top
To place the product on a bench top
1. Place the product on a stable, flat and level surface. Ensure that the surface
can support the weight of the product. For information on the weight, see the
data sheet.
2. WARNING! A stack of products can fall over and cause injury. Never stack
more than two products. Otherwise, mount them in a rack.
Stack as follows:
● All products must have the same dimensions (width and length).
● Do not exceed a total load of 50 kg placed on the product at the bottom of
the stack.
Left = Stacked correctly
Right = Stacked incorrectly, too many products
3. NOTICE! Overheating can damage the product.
Prevent overheating as follows:
● Keep a minimum distance of 10 cm between the fan openings of the prod-
uct and any object in the vicinity.
● Do not place the product next to heat-generating equipment such as radia-
tors or other products.
21Getting Started 1328.4922.02 ─ 09
R&S®ESW
Connecting the AC Power
Preparing for Use
4.4.2 Mounting the R&S ESW in a Rack
To prepare the rack
1. Observe the requirements and instructions in "Setting up the product"
on page 8.
2. NOTICE! Insufficient airflow can cause overheating and damage the product.
Design and implement an efficient ventilation concept for the rack.
To mount the R&S ESW in a rack
1. Use an adapter kit to prepare the R&S ESW for rack mounting.
a) Order the rack adapter kit designed for the R&S ESW. For the order num-
ber, see the data sheet.
b) Mount the adapter kit. Follow the assembly instructions provided with the
adapter kit.
2. Lift the R&S ESW to shelf height.
3. Grab the handles and push the R&S ESW onto the shelf until the rack brackets fit closely to the rack.
4. Tighten all screws in the rack brackets with a tightening torque of 1.2 Nm to
secure the R&S ESW in the rack.
To unmount the R&S ESW from a rack
1. Loosen the screws at the rack brackets.
2. Remove the R&S ESW from the rack.
3. If placing the R&S ESW on a bench top again, unmount the adapter kit from
the R&S ESW. Follow the instructions provided with the adapter kit.
4.5 Connecting the AC Power
In the standard version, the R&S ESW is equipped with an AC power supply connector.
22Getting Started 1328.4922.02 ─ 09
R&S®ESW
Preparing for Use
Switching the Instrument On and Off
The R&S ESW can be used with different AC power voltages and adapts itself
automatically to it. Refer to the datasheet for the requirements of voltage and frequency.
For safety information, see "Connecting to power" on page 9.
To connect the AC power
1. Plug the AC power cable into the AC power connector on the rear panel of the
instrument. Only use the AC power cable delivered with the R&S ESW.
2. Plug the AC power cable into a power outlet with ground contact.
The required ratings are listed next to the AC power connector and in the data
sheet.
For details on the connector, refer to Chapter 5.2.2, "AC Power Supply Connec-
tion and Main Power Switch", on page 49.
4.6 Switching the Instrument On and Off
Table 4-1: Overview of power states
Status LED on Power key Position of main power switch
Off
Standby
Ready
gray
orange
green
To switch on the R&S ESW
The R&S ESW is off but connected to power.
1. Set the switch on the power supply to position [I].
See Chapter 5.2.2, "AC Power Supply Connection and Main Power Switch",
on page 49.
[0]
[I]
[I]
The LED of the Power key is orange.
See Chapter 5.1.2, "Power Key", on page 40.
23Getting Started 1328.4922.02 ─ 09
R&S®ESW
2. Press the Power key.
See Chapter 5.1.2, "Power Key", on page 40.
The LED changes to green.
The R&S ESW boots.
After booting, the instrument is ready for operation.
To shut down the product
The product is in the ready state.
► Press the [Power] key.
The operating system shuts down. The LED changes to orange.
If the instrument temperature exceeds the limit specified in the data sheet,
the R&S ESW automatically shuts down to protect the instrument from damage.
Preparing for Use
Connecting to LAN
To disconnect from power
The R&S ESW is in the standby state.
1. NOTICE! Risk of data loss. If you disconnect the product from power when it
is in the ready state, you can lose settings and data. Shut it down first.
Set the switch on the power supply to position [0].
See Chapter 5.2.2, "AC Power Supply Connection and Main Power Switch",
on page 49.
The LED of the Power key is switched off.
2. Disconnect the R&S ESW from the power source.
4.7 Connecting to LAN
You can connect the instrument to a LAN for remote operation via a PC.
Provided the network administrator has assigned you the appropriate rights and
adapted the Windows firewall configuration, you can use the interface, for example:
●
To transfer data between a controlling device and the test device, e.g. to run a
remote control program
24Getting Started 1328.4922.02 ─ 09
R&S®ESW
●
To access or control the measurement from a remote computer using the
"Remote Desktop" application (or a similar tool)
●
To connect external network devices (e.g. printers)
●
To transfer data from a remote computer and back, e.g. using network folders
Network environment
Before connecting the product to a local area network (LAN), consider the following:
●
Install the latest firmware to reduce security risks.
●
For internet or remote access, use secured connections, if applicable.
●
Ensure that the network settings comply with the security policies of your company. Contact your local system administrator or IT department before connecting your product to your company LAN.
●
When connected to the LAN, the product may potentially be accessed from
the internet, which may be a security risk. For example, attackers might misuse or damage the product. For more information about IT security and how to
operate the product in a secure LAN environment, see the Rohde & Schwarz
white paper 1EF96: Malware Protection Windows 10.
Preparing for Use
Connecting to LAN
► NOTICE! Risk of network failure.
Consult your network administrator before performing the following tasks:
● Connecting the instrument to the network
● Configuring the network
● Changing IP addresses
● Exchanging hardware
Errors can affect the entire network.
Connect the R&S ESW to the LAN via the LAN interface on the rear panel of
the instrument.
Windows automatically detects the network connection and activates the
required drivers.
By default, the R&S ESW is configured to use DHCP and no static IP address
is configured.
The default instrument name is <Type><variant>-<serial_number>, for
example, ESW26-123456. For information on determining the serial number,
see Chapter 5.2.14, "Device ID", on page 53.
25Getting Started 1328.4922.02 ─ 09
R&S®ESW
Connecting an External Monitor
For more information on LAN configuration, see the R&S ESW user manual.
Preparing for Use
4.8 Connecting a Keyboard
The keyboard is detected automatically when it is connected. The default input
language is English – US.
However, you can also connect foreign language keyboards; currently the following languages are supported for the R&S ESW:
●
German
●
Swiss
●
French
●
Russian
To configure the keyboard language
1. To access the Windows operating system, press the Windows key on the
external keyboard.
2. Select "Start > Settings > Time & language > Region & language > Add a language" .
4.9 Connecting an External Monitor
You can connect an external monitor (or projector) to the "DVI" or "Display port"
connector on the rear panel of the R&S ESW (see also Chapter 5.2.3, "Display
Port and DVI", on page 50).
26Getting Started 1328.4922.02 ─ 09
R&S®ESW
Connecting an External Monitor
Screen resolution and format
The touchscreen of the R&S ESW is calibrated for a 16:10 format. If you
connect a monitor or projector using a different format (e.g. 4:3), the calibration is not correct and the screen does not react to your touch actions properly.
The touchscreen has a screen resolution of 1280x800 pixels. Usually, the
display of the external monitor is a duplicate of the instrument's monitor.
If you configure the external monitor to be used as the only display in the
Windows configuration dialog box ("Show only on 2"), the maximum screen
resolution of the monitor is used. In this case, you can maximize the
R&S ESW application window and see even more details. You cannot
change the monitor's screen resolution via the standard Windows configuration dialog box.
However, you can restore the default instrument resolution (1280x800) on
the monitor using the instrument function "Setup" > "Display" > "Configure
Monitor" > "Screen Resolution: Restore to default".
Preparing for Use
The R&S ESW supports a minimum resolution of 1280x768 pixels.
1. Connect the external monitor to the R&S ESW.
2. Press the [Setup] key.
3. Press the "Display" softkey.
4. Select the "Configure Monitor" tab in the "Display" dialog box.
The standard Windows "Screen Resolution" dialog box is displayed.
27Getting Started 1328.4922.02 ─ 09
R&S®ESW
Preparing for Use
Windows Operating System
5. Select the instrument for display:
● "Display 1" : internal monitor only
● "Display 2" : external monitor only
● "Duplicate" : both internal and external monitor
6. Tap "Apply" to try out the settings before they are accepted permanently, then
you can easily return to the previous settings, if necessary.
7. Select "OK" if the settings are suitable.
4.10 Windows Operating System
The instrument contains the Microsoft Windows operating system which has been
configured according to the instrument's features and needs. Changes in the system setup are only required when peripherals like a keyboard or a printer are
installed or if the network configuration does not comply with the default settings.
After the R&S ESW is started, the operating system boots and the instrument
firmware is started automatically.
28Getting Started 1328.4922.02 ─ 09
