Rohde and Schwarz SMJ100A Data Sheet

Download

¸SMJ100A Vector Signal Generator

Speciﬁcations

Version

04.00

May

2007

Specifications apply under the following conditions: 30 minutes warm-up time at ambient temperature, specified environmental conditions met, calibration cycle adhered to, and all internal adjustments performed. Data designated "overrange" or "underrange" and data without tolerance limits is not binding.

EMC specifications are tested with sufficiently shielded cables and accessories (e.g. mouse and keypad). To prevent degradation of these specifications, the user is responsible for using appropriate equipment.

In compliance with the 3GPP standard, chip rates are specified in Mcps (million chips per second), whereas bit rates and symbol rates are specified in kbps (thousand bits per second) or ksps (thousand symbol per second). Mcps, kbps, and ksps are not SI units.

CONTENT

Key features ...............................................................................................................................................................................................4

Baseband generator options ......................................................................................................................................................................5

Modulation ..................................................................................................................................................................................................5

Possible modulation types ......................................................................................................................................................................5

Simultaneous modulation........................................................................................................................................................................5

RF characteristics.......................................................................................................................................................................................6

Frequency ...............................................................................................................................................................................................6

Frequency sweep....................................................................................................................................................................................6

Reference frequency...............................................................................................................................................................................6

Level .......................................................................................................................................................................................................7

Measured level data................................................................................................................................................................................8

Level sweep ............................................................................................................................................................................................9

Spectral purity .........................................................................................................................................................................................9

List mode ..............................................................................................................................................................................................11

Analog modulation....................................................................................................................................................................................12

Internal modulation generator ...............................................................................................................................................................12

Input for external modulation signals ....................................................................................................................................................12

Amplitude modulation ...........................................................................................................................................................................12

Wideband amplitude modulation...........................................................................................................................................................13

Pulse modulation ..................................................................................................................................................................................13

Frequency modulation (R&S®SMJ-B20 option) ....................................................................................................................................13

Phase modulation (R&S®SMJ-B20 option) ...........................................................................................................................................13

I/Q modulation ..........................................................................................................................................................................................14

I/Q modulator ........................................................................................................................................................................................14

External wideband I/Q...........................................................................................................................................................................14

Internal baseband I/Q (with R&S®SMJ-B13 option) ..............................................................................................................................15

Differential I/Q output (R&S®SMJ-B16 option) ......................................................................................................................................17

I/Q baseband generator (R&S®SMJ-B9/-B10/-B11/-B50/-B51 option) – arbitrary waveform mode...................................................... 18

I/Q baseband generator (R&S®SMJ-B9/-B10/-B11 option) – realtime operation ..................................................................................20

Modulation uncertainty for main standards ...........................................................................................................................................24

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Digital modulation systems.......................................................................................................................................................................25

GSM/EDGE digital standard (R&S®SMJ-K40 option) ...........................................................................................................................25

3GPP FDD digital standard (R&S®SMJ-K42 option) ............................................................................................................................27

3GPP FDD enhanced BS/MS test including HSDPA (R&S®SMJ-K43 option) .....................................................................................33

GPS digital standard (R&S®SMJ-K44 option) .......................................................................................................................................35

3GPP FDD HSUPA (R&S®SMJ-K45 option).........................................................................................................................................36

CDMA2000® digital standard (R&S®SMJ-K46 option) ..........................................................................................................................38

IEEE 802.11 a/b/g digital standard (R&S®SMJ-K48 option) .................................................................................................................41

IEEE 802.16 WiMAX digital standard including IEEE 802.16e (R&S®SMJ-K49 option).......................................................................43

TD-SCDMA digital standard (3GPP TDD LCR, R&S®SMJ-K50 option) ...............................................................................................45

TD-SCDMA (3GPP TDD LCR) enhanced BS/MS test including HSDPA (R&S®SMJ-K51 option).......................................................47

DVB-H digital standard (R&S®SMJ-K52 option) ...................................................................................................................................48

EUTRA/LTE digital standard (R&S®SMJ-K55 option)...........................................................................................................................49

XM RADIO digital standard (R&S®SMJ-K56 option).............................................................................................................................52

Multicarrier CW signal generation (R&S®SMJ-K61 option)...................................................................................................................53

Digital standards with R&S®WinIQSIM2™ (for R&S®SMJ-B9/-B10/-B11/-B50/-B51 ARB) ......................................................................55

Digital standards with R&S®WinIQSIM™ (for R&S®SMJ-B9/-B10/-B11/-B50/-B51 ARB) ........................................................................55

Noise generation ......................................................................................................................................................................................56

Additive white Gaussian noise (AWGN, R&S®SMJ-K62 option)...........................................................................................................56

Other options ............................................................................................................................................................................................57

Bluetooth® digital standard (external PC software, R&S®SMJ-K5 option) ............................................................................................57

Pulse sequencer (external PC software, R&S®SMJ-K6 option)............................................................................................................58

TETRA digital standard (external PC software, R&S®SMJ-K8 option) .................................................................................................59

BER measurement (R&S®SMJ-K80 option)..........................................................................................................................................60

BLER measurement (R&S®SMJ-K80 option)........................................................................................................................................60

General data.............................................................................................................................................................................................61

Remote control......................................................................................................................................................................................61

Operating data ......................................................................................................................................................................................61

Ordering information.................................................................................................................................................................................62

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Key features

Intuitive operation

• Color display with 800 × 600 pixels (SVGA format)

• Intuitive user interface with graphical display of signal flow (block diagram)

• Graphical display of baseband signals through built-in transient recorder

• Context-sensitive help system

Outstanding signal quality

• I/Q modulator with 200 MHz RF bandwidth

• Very low SSB phase noise of typ. –133 dBc (f = 1 GHz, 20 kHz carrier offset, 1 Hz measurement bandwidth)

• Wideband noise of typ. –153 dBc (CW, f = 1 GHz, >10 MHz carrier offset, 1 Hz measurement bandwidth)

• Excellent ACLR performance of typically +69 dB with 3GPP FDD (test model 1, 64 DPCH)

• Very high level repeatability of 0.05 dB

• High-stability reference oscillator as standard

Unrivaled flexibility

• Support of EUTRA/LTE signal generation

• Support of WiMAX IEEE 802.16-2004/Corr1-2005, 802.16e-2005, and WiBro

• Four code channels in realtime for 3GPP FDD, support of HSDPA and HSUPA

• Change of modulation from slot to slot for GSM/EDGE

• Baseband generator with universal coder for realtime signal generation

• Arbitrary waveform generator with 16 Msample, 64 Msample or 128 Msample and multisegment support

• Arbitrary waveform generator supported by R&S

Ideal for production

WinIQSIM2TM and R&S®WinIQSIM

simulation software

• Very short frequency setting times (<2 ms); only 450 µs in List mode

• Electronic attenuator up to 6 GHz over the full level range

• Flexible high speed measurements with RF List mode and multisegment waveforms

Connectivity

• Remote control via LAN (Gigabit Ethernet, VXI11) and GPIB

• Remote operation via Windows Remote Desktop or VNC

• User-selectable trigger and marker signals

• USB connectors for keyboard, mouse, and memory stick

• LXI class C compliance

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Baseband generator options

The R&S®SMJ100A can be equipped with one of the following I/Q baseband generators:

SMJ-B9 Baseband Generator with ARB (128 Msample) and Digital Modulation (realtime)

R&S R&S®SMJ-B10 Baseband Generator with ARB (64 Msample) and Digital Modulation (realtime) R&S®SMJ-B11 Baseband Generator with ARB (16 Msample) and Digital Modulation (realtime) R&S®SMJ-B50 Baseband Generator with ARB (64 Msample) R&S®SMJ-B51 Baseband Generator with ARB (16 Msample)

The R&S generators are installed, the following software options can be added:

• Digital standards and modulation systems running on the instrument (R&S

• Digital standards with R&S

• R&S

The R&S are installed, the following software options can be added:

• Digital standards with R&S

• R&S

SMJ-B9/-B10/-B11 baseband generators include an arbitrary waveform generator and a realtime coder. If these baseband

WinIQSIM2™ (R&S®SMJ-K240 to R&S®SMJ-K262 options); R&S®WinIQSIM2™ runs on an

external PC

SMJ-K5/-K6/-K8 options

SMJ-B50 and R&S®SMJ-B51 baseband generators include an arbitrary waveform generator. If these baseband generators

external PC

SMJ-K6 option

WinIQSIM™ (R&S®SMJ-K11 to R&S®SMJ-K20 options); R&S®WinIQSIM™ runs on an external PC

WinIQSIM2™ (R&S®SMJ-K240 to R&S®SMJ-K262 options); R&S®WinIQSIM2™ runs on an

WinIQSIM™ (R&S®SMJ-K11 to R&S®SMJ-K20 options); R&S®WinIQSIM™ runs on an external PC

SMJ-K40 to R&S®SMJ-K61 options)

Modulation

Possible modulation types

Amplitude modulation, frequency/phase modulation (optional), vector modulation, digital modulation via internal baseband section (optional), pulse modulation, wideband amplitude modulation

Simultaneous modulation

AM FM φM Pulse BB-AM I/Q DM ARB Amplitude modulation (AM) / + + + – – – – Frequency modulation (FM) + / – + + + + + Phase modulation (φM) + – / + + + + + Pulse modulation + + + / + + + + Broadband AM (BB-AM) – + + + / – – – Vector modulation (I/Q) – + + + – / – – Digital modulation (DM) – + + + – – / – ARB – + + + – – – /

+ = compatible, – = not compatible, switches off each other

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

RF characteristics

Frequency

Range

Resolution of setting Resolution of synthesis standard, fundamental frequency range

Setting time1

Phase offset

Frequency sweep

Operating modes digital sweep in discrete steps automatic, step, single,

Sweep range

underrange 100 kHz to <300 kHz R&S®SMJ-B103 up to 3 GHz

SMJ-B106 up to 6 GHz

R&S

0.01 Hz

5 µHz 750 MHz to 1500 MHz to within <1 × 10

−

for f > 200 MHz or <124 Hz for f < 200 MHz, with GUI update stopped after IEC/IEEE bus delimiter <2 ms, typ. 1 ms

in ALC OFF MODE S&H <4 ms, typ. 3 ms

after trigger pulse in List mode <450 µs

adjustable in 0.1° steps

external single, external step, manual or external trigger, linear or logarithmic spacing

full frequency range linear full frequency range Step width logarithmic 0.01 % to 100 % per step

Reference frequency

Aging after 30 days of uninterrupted operation <1 × 10 Temperature effect in operating temperature range <6 × 10 Warm-up time to nominal thermostat temperature ≤10 min Output for internal reference signal

Input for external reference

Electronic tuning from input AUX I/O

frequency (approx. sinewave) 10 MHz or external input frequency level typ. 5 dBm source impedance 50 Ω frequency 5 MHz, 10 MHz or 13 MHz maximum deviation 3 × 10 input level, limits ≥−6 dBm, ≤19 dBm

recommended 0 dBm to 19 dBm input impedance 50 Ω sensitivity typ. 1 × 10 input voltage –10 V to +10 V input impedance 10 kΩ

−

/day, <1 × 10

−

/V to 3 × 10

−

/year

−

Installation of software that is not authorized by Rohde & Schwarz for use on the R&S®SMJ100A or installation of anti-virus software can deteriorate

the setting time performance.

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Level

Setting range Maximum level with R&S®SMJ-B103 option Maximum level with R&S®SMJ-B106 option Resolution Level uncertainty

Additional uncertainty with ALC OFF, S&H Output impedance VSWR in 50 Ω system Setting time3

Back-feed (from ≥50 Ω source) with

R&S

SMJ-B103 option

Back-feed (from ≥50 Ω source) with

R&S

SMJ-B106 option

for levels >–120 dBm, attenuator mode

–145 dBm to +20 dBm +13 dBm (PEP)2

+8 dBm (PEP)

0.01 dB

Auto, temperature range +18 °C to +28 °C

0.3 MHz ≤ f ≤ 3 GHz <0.7 dB

f > 3 GHz <0.9 dB This function is needed only in some

<0.2 dB special applications. ALC state ON, standard, f ≤ 3 GHz

f > 3 GHz

after IEC/IEEE bus delimiter,

<1.6, typ. <1.4

<1.85, typ. <1.6

to <0.3 dB deviation from final value, with GUI update stopped, temperature range +18 °C to +28 °C

f ≤ 5 GHz <3 ms f > 5 GHz typ. 3 ms ALC state OFF

f ≤ 5 GHz <5 ms f > 5 GHz typ. 5 ms

with attenuator mode fixed, ALC state ON Uninterrupted level setting

setting range >20 dB

maximum permissible RF power in output

frequency range 0.5 W continuous maximum permissible DC voltage 36 V maximum permissible RF power in output

frequency range 0.5 W maximum permissible DC voltage 10 V g

PEP = peak envelope power.

Installation of software that is not authorized by Rohde & Schwarz for use on the R&S®SMJ100A or installation of anti-virus software can deteriorate

the setting time performance.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Measured level data

Measured level versus frequency

Level repeatability with random settings between measurements

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Level sweep

Operating modes digital sweep in discrete steps automatic, single, step,

external single, external step,

manual, or external trigger Sweep range Step width logarithmic 0.1 dB to 20 dB per step

range 10 ms to 10 s Dwell time

resolution 0.1 ms

full level range

Spectral purity

with R&S®SMJ-B103 option, unmodulated, level <8 dBm with R&S level <3 dBm

Nonharmonics

Power supply and mechanically related nonharmonics

Wideband noise

SSB phase noise

Residual FM

Residual AM rms value 20 Hz to 23 kHz <0.02 %

level >–50 dBm, CW, vector modulation (full-scale DC input), >10 kHz offset from carrier and outside the modulation spectrum

850 kHz offset from carrier and outside the modulation spectrum

at RF = 1 GHz, 50 Hz to 10 kHz from carrier 1500 MHz < f ≤ 3000 MHz <–74 dBc Subharmonics 3000 MHz < f ≤ 6000 MHz <–50 dBc carrier offset >10 MHz, measurement bandwidth 1 Hz, CW

vector modulation with full-scale DC input

carrier offset 20 kHz, measurement bandwidth 1 Hz, unmodulated

rms value at f = 1 GHz

SMJ-B106 option, unmodulated,

0.3 MHz ≤ f ≤ 200 MHz <–77 dBc 200 MHz < f ≤ 1500 MHz <–80 dBc 1500 MHz < f ≤ 3000 MHz <–74 dBc f > 3000 MHz <–68 dBc

0.3 MHz ≤ f ≤ 200 MHz <–77 dBc 200 MHz < f ≤ 1500 MHz <–86 dBc 1500 MHz < f ≤ 3000 MHz <–80 dBc f > 3000 MHz <–74 dBc

20 MHz ≤ f ≤ 200 MHz <–146 dBc (typ. –149 dBc) 200 MHz < f ≤ 1500 MHz <–150 dBc (typ. –153 dBc)

1.5 GHz < f ≤ 3 GHz <–148 dBc (typ. –151 dBc) f > 3 GHz <–146 dBc (typ. –149 dBc)

20 MHz ≤ f ≤ 200 MHz <–140 dBc (typ. –143 dBc) 200 MHz < f ≤ 1500 MHz <–143 dBc (typ. –146 dBc)

1.5 GHz < f ≤ 3 GHz <–142 dBc (typ. –145 dBc) f > 3 GHz <–140 dBc (typ. –143 dBc)

20 MHz ≤ f ≤ 200 MHz <–126 dBc (typ. –130 dBc) f = 1 GHz <–129 dBc (typ. –133 dBc) f = 2 GHz <–123 dBc (typ. –127 dBc) f = 3 GHz <–119 dBc (typ. –123 dBc) f = 4 GHz <–117 dBc (typ. –121 dBc) f = 6 GHz <–113 dBc (typ. –117 dBc)

300 Hz to 3 kHz <1 Hz 20 Hz to 23 kHz <4 Hz

<–30 dBc Harmonics

<–30 dBc

<–70 dBc

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

List mode

Frequency and level values can be stored in a list and set in an extremely short amount of time. Operating modes

Maximum number of channels Dwell time

Resolution

Setting time after external trigger see frequency and level data

automatic, single sweep, manual or

external trigger

10000

1 ms to 1 s

0.1 ms

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Analog modulation

Internal modulation generator

Frequency range Resolution of setting Frequency uncertainty

Distortion up to 100 kHz at RL >200 Ω, level (Vp) 1 V <0.1 % Output voltage

Output impedance Frequency setting time to within <1 × 10

Sweep

up to 100 kHz <0.1 dB Frequency response up to 1 MHz <1 dB

Vp at LF connector, RL >200 Ω 1 mV to 3 V

resolution 1 mV setting uncertainty at 1 kHz <(1 % of reading + 1 mV)

stopped, after IEC/IEEE bus delimiter digital sweep in discrete steps

operating modes automatic, step, single,

sweep range full frequency range linear step width full frequency range logarithmic step width 0.01 % to 100 % per step

−

, with GUI update

Input for external modulation signals

Modulation input EXT MOD

input impedance high (>100 kΩ), switchable to 50 Ω

input sensitivity (peak value for set modulation depth or deviation) absolute maximum rating 10 V

0.1 Hz to 1 MHz

0.1 Hz

<0.012 Hz +

relative deviation of reference frequency

16 Ω

<3 ms

external single, external step,

manual or external trigger,

linear or logarithmic spacing

with R&S

1 V

SMJ-B20 option

Amplitude modulation

Operating modes Modulation depth At high levels, modulation is clipped if the

Resolution Setting uncertainty attenuator mode Auto,

AM distortion

Modulation frequency range Modulation frequency response AC mode, 20 Hz to 500 kHz <1 dB Incidental φM at AM m = 30 %, f

maximum PEP is reached.

= 1 kHz and m < 80 %

mod

PEP in specified range, attenuator mode Auto f ≤ 3 GHz, at f

m = 30 % <0.5 %

m = 80 % <0.8 %

f > 3 GHz, at f

m = 30 % <1 % m = 80 % <1.6 %

= 1 kHz

mod

= 1 kHz

mod

= 1 kHz, peak value <0.1 rad

mod

internal, external AC/DC

0 % to 100 %

0.1 %

<(1 % of reading + 1 %)

DC, 20 Hz to 500 kHz

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Wideband amplitude modulation

Operating modes modulation input I external DC Modulation frequency response as with I/Q modulation –

external wideband I/Q Input impedance 50 Ω Input sensitivity peak voltage for 100 % AM 0.25 V

Pulse modulation

Operating modes

ON/OFF ratio Rise/fall time 10 %/90 % of RF amplitude typ. 1 µs Pulse repetition frequency Video crosstalk spectral line of fundamental of

Modulation input EXT MOD A/B

100 kHz squarewave modulation

input level rising 1.7 V, falling typ. 1.1 V

input impedance >10 kΩ

polarity selectable

external, internal (duty cycle approx. 1:1) >70 dB

0 Hz to 100 kHz <−30 dBc

Frequency modulation (R&S®SMJ-B20 option)

Operating modes

FM/φM range multiplier

Maximum deviation Resolution Setting uncertainty

FM distortion f

Carrier frequency offset at FM

0.3 MHz ≤ f ≤ 200 MHz rm = 1

200 MHz < f ≤ 375 MHz rm = 0.25

375 MHz < f ≤ 750 MHz rm = 0.5

750 MHz < f ≤ 1500 MHz rm = 1

1500 MHz < f ≤ 3000 MHz rm = 2

f > 3000 MHz rm = 4

= 10 kHz,

mod

deviation ≤ half of maximum deviation

internal <(1.5 % of reading + 20 Hz) external <(2.0 % of reading + 20 Hz) = 10 kHz and 1 MHz deviation <0.1 %

mod

10 Hz to 100 kHz <0.5 dB Modulation frequency response

10 Hz to 10 MHz <3 dB

40 kHz deviation, f

f > 3 GHz <0.2 %

mod

= 1 kHz, f > 5 MHz <0.1 % Synchronous AM

internal, external, internal + external, AC/DC

rm × 10 MHz <200 ppm, min. rm × 0.1 Hz

<0.2 % of set deviation

Phase modulation (R&S®SMJ-B20 option)

Operating mode

Setting uncertainty

φM distortion f

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

High Deviation φM mode rm × 20.0 rad Maximum deviation

High Bandwidth φM mode rm × 1.0 rad

High Deviation φM mode <200 ppm, min. rm × 20 µrad Resolution

High Bandwidth φM mode <0.1 %, min. rm × 20 µrad

= 10 kHz,

mod

deviation ≤ half of maximum deviation

internal <(1.5 % of reading + 0.01 rad) external <(2.0 % of reading + 0.01 rad) = 10 kHz, half of maximum deviation <0.2 %, typ. 0.1 %

mod

High Deviation, 10 Hz to 500 kHz <1 dB Modulation frequency response

High Bandwidth, 10 Hz to 10 MHz <3 dB

internal, external, internal + external, AC/DC, High Bandwidth, High Deviation

I/Q modulation

I/Q modulator

Operating modes external wideband I/Q,

I/Q impairments

I offset, Q offset

setting range −10 % to +10 % resolution 0.01 %

gain imbalance

setting range −1.0 dB to +1.0 dB resolution 0.001 dB

quadrature offset

setting range −10° to +10° resolution 0.01°

I/Q swap I and Q signals swapped ON/OFF

External wideband I/Q

I/Q inputs

Modulation frequency range I/Q wideband ON 100 MHz Carrier leakage without input signal, referenced to full-

Error vector

Delta / dB

input impedance 50 Ω

VSWR up to 50 MHz <1.2

input voltage for full-scale input

minimum input voltage for ALC state ON 0.1 V

scale input

measured with 16QAM, root cosine filter,

α = 0.5, symbol rate 10 kHz

rms value

f ≤ 200 MHz <0.3 % f > 200 MHz <(0.2 % + 0.1 % × f/GHz)

peak value

f ≤ 200 MHz <0.6 % f > 200 MHz <(0.4 % + 0.2 % × f/GHz)

internal baseband I/Q

+= 0.5 V

−55 dBc, typ. <−65 dBc

RF 850 MHz RF 1900 MHz RF 2200 MHz

–1

– 2

– 3

– 4

– 5

– 100 100060– 20– 60 20 40 80– 80 – 40

Frequency offset from carrier / MHz

Measured frequency response of external wideband I/Q modulation

Value applies after 1 hour warm-up and recalibration for 4 hours operation and temperature variations of less than +5 °C.

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Internal baseband I/Q (with R&S®SMJ-B13 option)

The R&S®SMJ-B13 converts the internal digital baseband signals of the R&S®SMJ-B9/-B10/-B11/-B50/-B51 into analog signals for driving the I/Q modulator. It also generates the analog I/Q output signals.

D/A converter

data rate 100 MHz

resolution 16 bit

sampling rate 400 MHz (internal interpolation × 4) Aliasing filter

with amplitude, group-delay and

Si correction

bandwidth, roll-off to −0.1 dB 40 MHz D/A converter interpolation spectra

up to 10 MHz <−80 dBc

I/Q impairment

up to 40 MHz <

carrier leakage

setting range −10 % to +10 %

−73 dBc

resolution 0.01 %

I ≠ Q (imbalance)

setting range −1 dB to +1 dB resolution 0.001 dB

quadrature offset

setting range −10° to +10°

resolution 0.01° RF frequency response for entire instrument in modulation bandwidth

I/Q wideband ON, optimize internal I/Q impairments for RF output ON

up to 10 MHz <1.5 dB, typ 0.7 dB

up to 40 MHz <4.5 dB, typ. 2.0 dB

up to 10 MHz >44 dB, typ. 50 dB Suppression of image sideband for entire up to 40 MHz >34 dB, typ. 44 dB

instrument in modulation bandwidth

Carrier leakage5 referenced to full-scale input <−55 dBc, typ. <−65 dBc Additional level uncertainty referenced to CW

measured at 0 dBm with 16QAM, root cosine filter,

α = 0.5, symbol rate 10 kHz

<0.2 dB

I/Q outputs

Output impedance 50 Ω Output voltage EMF (output voltage depends on set

1 V (Vp)

modulation signal) Offset EMF <1 mV Frequency response6

at RL = 50 Ω

magnitude

up to 10 MHz typ. 0.02 dB up to 40 MHz typ. 0.03 dB

nonlinear phase

up to 10 MHz typ. 0.1° up to 30 MHz typ. 0.2°

I/Q balance6

at RL = 50 Ω

magnitude

up to 10 MHz typ. 0.01 dB up to 40 MHz typ. 0.02 dB

nonlinear phase

up to 10 MHz typ. 0.1° up to 30 MHz typ. 0.2°

Spectral purity

at RL = 50 Ω

SFDR (sine)

up to 2 MHz >70 dB up to 20 MHz typ. 60 dB

phase noise

10 MHz sinewave at 20 kHz offset typ. −150 dBc

wideband noise

10 MHz sinewave at 1 MHz offset typ.

−155 dBc

Value applies after 1 hour warm-up time and recalibration for 4 hours operation and temperature variations of less than +5 °C.

Optimize internal I/Q impairments for RF output switched OFF.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Frequency response of I/Q outputs

SFDR of I/Q outputs

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Differential I/Q output (R&S®SMJ-B16 option)

Additional specifications for I/Q outputs with R&S®SMJ-B16 option

Output impedance

Single-ended 50 Ω Differential 100 Ω

Output voltage output voltage depends on set modulation

signal

Single-ended EMF

Resolution 1 mV

Differential EMF

Resolution 2 mV

Bias voltage (single-ended and differential) EMF –3.6 V to 3.6 V

Resolution 2 mV Uncertainty 1 % + 4 mV

Offset voltage

Differential EMF –300 mV to 300 mV

Resolution 0.2 mV Uncertainty 1 % + 0.1 % × bias voltage + 1 mV

Differential signal balance

at RL = 50 Ω, output voltage >0.5 V (Vp)

magnitude

up to 10 MHz <0.2 dB, typ. 0.05 dB up to 40 MHz typ 0.2 dB

Frequency response7

at RL = 50 Ω, output voltage >0.5 V (Vp)

magnitude

up to 10 MHz typ. 0.02 dB up to 40 MHz typ. 0.03 dB

nonlinear phase

up to 10 MHz typ. 0.1° up to 30 MHz typ. 0.2°

0.02 V to 2 V (V

0.04 V to 4 V (V

)

Optimize internal I/Q impairments for RF output switched OFF.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

I/Q baseband generator (R&S®SMJ-B9/-B10/-B11/-B50/-B51 option) – arbitrary waveform mode

The R&S®SMJ-B13 baseband main module must be installed.

Waveform memory

Multisegment waveform

Multicarrier waveform

Clock generation

Interpolation

output memory

waveform length R&S®SMJ-B9 128 sample to 128 Msample in

waveform length R&S®SMJ-B10/-B50 128 sample to 64 Msample in one-sample

waveform length R&S®SMJ-B11/-B51 128 sample to 16 Msample in one-sample

resolution 16 bit loading time 10 Msample 15 s

nonvolatile memory hard disk number of segments max. 100 segments changeover modes GUI, remote control, external trigger extended trigger modes

changeover time (external trigger, without clock change) seamless changeover output up to end of current segment,

number of carriers max. 32 total RF bandwidth max. 80 MHz crest factor modes maximize, minimize, off signal period modes longest file, shortest file, user (max. 1 s) single carrier gain –80 dB to 0 dB single carrier start phase 0° to 360° single carrier delay 0 s to 1 s clock rate 400 Hz to 100 MHz resolution 0.001 Hz operating mode internal, external frequency uncertainty (internal) <5 × 10

The sampling rate of the waveform is automatically interpolated to the internal 100 MHz data rate. bandwidth

clock rate = 100 MHz (no interpolation),

roll-off to –0.1 dB

clock rate

≤100 MHz, drop to −0.1 dB 0.31 × clock rate

one-sample steps

steps

same segment, next segment, next segment seamless typ. 5 µs at 50 MHz clock rate

followed by changeover to next segment

−

× clock rate +

uncertainty of reference frequency

40 MHz

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Triggering

In internal clock mode, a trigger event restarts the clock generation. The clock phase is then synchronous with the trigger (with a certain timing uncertainty). In external clock mode the trigger event is synchronized to the symbol clock. operating mode internal, external modes Auto, Retrig, Armed Auto, Armed Retrig setting uncertainty for clock phase related

<18 ns to trigger in internal clock mode external trigger delay

setting range 0 sample to (216 – 1) sample resolution

internal clock mode 0.01 sample external clock mode 1 sample

setting uncertainty <5 ns

external trigger inhibit

setting range 0 sample to (226 – 1) sample

resolution 1 sample external trigger pulse width >15 ns external trigger frequency <0.02 × sampling rate

Marker outputs

number 4 level LVTTL operating modes unchanged, restart, pulse, pattern, ratio marker delay

setting range 0 sample to (waveform length − 1) sample

setting range without recalculation 0 sample to 2000 sample

resolution of setting 0.001 sample

setting uncertainty <10 ns

Operation with R&S®WinIQSIM2™: As of version 2.04, the software supports download of I/Q data and control of the

SMJ-B9/-B10/-B11/-B50/-B51.

R&S Operation with R&S®WinIQSIM™: As of version 4.50, the software supports download of I/Q data and control of the

R&S

SMJ-B9/-B10/-B11/-B50/-B51.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

I/Q baseband generator (R&S®SMJ-B9/-B10/-B11 option) – realtime operation

The R&S®SMJ-B13 baseband main module must be installed.

Types of modulation

ASK

modulation index 0 % to 100 %

resolution 0.1 % FSK 2FSK, 4FSK, MSK

deviation

maximum 10 MHz

resolution <0.1 Hz

setting uncertainty <0.5 % variable FSK 4FSK, 8FSK, 16FSK

deviations

maximum 10 MHz

resolution <0.1 Hz PSK BPSK, QPSK, QPSK 45° offset, OQPSK,

QAM 16QAM, 32QAM, 64QAM, 256QAM,

Coding Not all coding methods can be used with

every type of modulation.

Baseband filter

Any filter can be used with any type of modulation. The bandwidth of the modulation signal is max. 25 MHz; the signal is clipped if the bandwidth is exceeded. cosine, root cosine

filter parameter α 0.05 to 1.00 Gaussian

filter parameter B × T 0.15 to 2.50 cdmaOne, cdmaOne + equalizer cdmaOne 705 kHz, cdmaOne 705 kHz + equalizer CDMA2000

3x APCO25 C4FM rectangular split phase

filter parameter B × T 0.15 to 2.5

resolution of filter parameter 0.01

0.1 to 1.5 × f

–1.5 × f

sym

to +1.5 × f

sym

π/4-QPSK, π/2-DBPSK, π/4-DQPSK, π/8-D8PSK, 8PSK, 8PSK EDGE

1024QAM OOFF, Differential, Diff. Phase, Diff.+Gray, Gray, GSM, NADC, PDC, PHS, TETRA, APCO25 (PSK), PWT, TFTS, INMARSAT, VDL, EDGE, APCO25(FSK), ICO, CDMA2000

® 8

WCDMA

CDMA2000® is a registered trademark of the Telecommunications Industry Association (TIA – USA).

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Symbol rate

Frequency offset

Data sources

If an external clock is used, the applied data rate may deviate from the set clock

±2 %. The external clock can be

rate by used for internal and external data. operating mode internal, external setting range

ASK, PSK, and QAM 400 Hz to 25 MHz

FSK 400 Hz to 15 MHz resolution 0.001 Hz frequency uncertainty (internal)

–14

<5 × 10

× symbol rate + reference

frequency uncertainty external clock symbol, K × symbol, bit clock clock divider K 1 to 64 external clock rate max. 100 MHz With the aid of the frequency offset, the center frequency of the modulation signal in the baseband can be shifted. The restrictions caused by the modulation bandwidth apply. setting range −40 MHz to +40 MHz resolution 0.01 Hz frequency uncertainty <5 × 10

−

× frequency offset + reference

frequency error

internal

all 0, all 1 PRBS

sequence length 9, 11, 15, 16, 20, 21, 23

pattern

length 1 bit to 64 bit

data lists

output memory R&S®SMJ-B9 8 bit to 4 Gbit output memory R&S®SMJ-B10 8 bit to 2 Gbit output memory R&S®SMJ-B11 8 bit to 512 Mbit nonvolatile memory hard disk

external

In the case of serial transmission, the symbol strobe marks the LSB of the symbol, and the maximum symbol rate is limited by the data rate of the interface. serial

word width 1 bit to 10 bit bit rate max. 60 MHz

parallel

word width 1 bit to 10 bit symbol rate max. 25 MHz

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Triggering

<18 ns to trigger in internal clock mode external trigger delay

setting range 0 sample to (216 – 1) sample resolution

internal clock mode 0.01 sample external clock mode 1 sample

setting uncertainty <5 ns

external trigger inhibit 0 sample to (226 – 1) sample

setting range

resolution 1 sample external trigger pulse width >15 ns external trigger frequency <0.02 × sampling rate

Marker outputs

number 4 level LVTTL operating modes control list, restart, pulse, pattern, ratio marker delay (in sample)

setting range 0 to (224 – 1) setting range without recalculation 0 to 2000 resolution of setting 0.001 setting uncertainty <10 ns

Level reduction

Internal or external via LEVATT input. The signal switches between nominal and reduced level (without edge shaping). If an internal LEVATT signal is used, the connector is used as an output. setting range 0 dB to 60 dB additional level error in case of reduction

up to 30 dB <1 dB up to 50 dB <3 dB

Burst

Internal or external via BURST input. The signal triggers the beginning of a power ramp. The positive edge starts power ramping from blank to full level, the negative edge ramping in the opposite direction from full level to blanking. If an internal BURST GATE signal is applied, the connector is used as an output. operating range max. 5 MHz rise/fall time

setting range 0.5 symbol to 16 symbol resolution 0.1 symbol

ramp shape cosine, linear

Trigger/clock/data inputs

Input impedance and trigger threshold can be set separately for the trigger and the clock/data inputs. input impedance 1 kΩ, 50 Ω trigger threshold

setting range 0.00 V to 2.50 V resolution 0.01 V

Clock/data outputs level LVTTL

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Modulation errors

Deviation error with 2FSK, 4FSK

Phase error with MSK

EVM with QPSK, OQPSK, π/4-DQPSK, 8PSK, 16QAM, 32QAM, 64QAM

modulation, filter, symbol rate, and coding in line with standard

standards Bluetooth

Predefined settings

® 9

EDGE, NADC, PDC, PHS, TETRA, WCDMA 3GPP, TD-SCDMA, CDMA2000 Forward, CDMA2000 Worldspace

deviation 0.2 to 0.7 × symbol rate Gaussian filter with B × T = 0.2 to 0.7

symbol rate up to 2 MHz <1.2 %, typ. 0.25 % symbol rate up to 10 MHz typ. 0.75 %

Gaussian filter with B × T = 0.2 to 0.7

bit rate up to 2 MHz <0.4°, typ. 0.15° bit rate up to 10 MHz typ. 0.3°

cosine, root cosine filter with α = 0.2 to 0.7

symbol rate up to 5 MHz <0.8 %, typ. 0.2 % symbol rate up to 20 MHz typ. 0.7 %

, DECT, ETC, GSM, GSM

Reverse,

Measured EVM versus symbol rate

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Rohde & Schwarz is under license.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Modulation uncertainty for main standards

Typical values

Standard GSM EDGE WCDMA

3GPP (1DPCH)

Frequency in MHz

EVM in % – 0.2 0.3 0.2 – 0.2 0.2 0.2 0.4 Phase error in ° 0.15 – – – – – – – – Deviation error in kHz Channel spacing 200 kHz 200 kHz 5 MHz 1.25 MHz 1.728 MHz 25 kHz 30 kHz 25 kHz –

Adjacent channel power ratio (ACPR) in dB

In adjacent channel

In alternate channel

In 2nd alternate channel

400 to 2000

– – – – 0.5 – – – –

−37 −38 −72 −80

−71 −71 −76 −93

−85 −85 – – – – – – −66

400 to 2000

1800 to 2200

cdmaOne Reverse

800 to 900 824 to 894 810 to 956 2400 to

1850 to 2000

offset 750 kHz, bandwidth 30 kHz

offset

1.98 MHz, bandwidth 30 kHz

DECT TETRA NADC PDC IEEE

802.11a

1880 to 1990 380 to

– −77 −34 −71 −42

– −80 −78 −77 −64

480

1850 to 2000

1429 to 1501

2485 5150 to 5825

at 11 MHz

at 20 MHz

at 30 MHz

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Digital modulation systems

An R&S®SMJ-B9, R&S®SMJ-B10, or R&S®SMJ-B11 I/Q baseband generator is required. The data specified applies together with the parameters of the respective standard. The entire frequency range as well as filter parameters and symbol rates can be set by the user.

GSM/EDGE digital standard (R&S®SMJ-K40 option)

GSM/EDGE digital standard in line with GSM standard Frequency range

Modes

Modulation MSK,

Baseband filter

Frame structure

frequency bands to GSM 05.05 in uplink and downlink

range as R&S unframed generation of a signal without slot and

framed (single) configuration of a signal via frame

framed (double) configuration of simple multiframe application: simulation of modulation change in a slot versus time

standard 270.833 kHz Symbol rate range 400 Hz to 300 kHz GSM, standard Gaussian with B × T = 0.3

range B × T = 0.15 to 2.5 EDGE, standard Gaussian linearized (EDGE) Change between GSM and EDGE possible from slot to slot and frame to frame; half rate and GPRS at the physical layer. Slots 0 to 7 of the frames are userdefined for uplink and downlink. In the normal burst half-rate mode, the burst parameters can be defined independently for two users that alternate from frame to frame. burst types normal (full rate)

GSM 450 GSM 480 GSM 850 GSM 900 (P-GSM, E-GSM, R-GSM) DCS 1800 PCS 1900

SMJ100A

frame structure and power ramping, with symbol rate and filtering in line with GSM standard; MSK or 8PSK EDGE modulation can be selected

structure (see frame structure below)

scenarios by combining two frames (frame structure see below); a repetition factor can be specified for each of the two frames

switchable to FSK with settable deviation for simulating frequency deviation errors 8PSK EDGE

normal (half rate) EDGE synchronization frequency correction (normal + compact) dummy access all data (GSM) all data (EDGE)

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Burst rise/fall time

standard in line with GSM power time template selectable

ramp time 0.3 symbol to 4 symbol

ramp delay –1.0 symbol to 1.0 symbol

rise delay –9 symbol to 9 symbol

fall delay –9 symbol to 9 symbol

Settable slot attenuation 0.0 dB to 60.0 dB, 8 different levels

simultaneously possible (full level and

7 attenuated levels) Burst ON/OFF ratio >100 dB Data sources

For characteristics of data sources, see section I/Q baseband generator (R&S®SMJ-B9/-B10/-B11 option) – realtime operation. internal data sources all 0

all 1

PRBS 9, 11, 15, 16, 20, 21, 23

pattern (length 1 bit to 64 bit)

data list Training sequence

for normal burst (full rate), normal burst (half rate), EDGE burst

TSC0 to TSC7

user TSC

for sync burst standard

CTS

compact

user

for access burst TS0 to TS2 Triggering see I/Q baseband generator Markers convenient graphics editor for defining

marker signals, and in addition: frame, multiple frame slot, multiple slot pulse pattern ON/OFF ratio

Phase error

MSK, Gaussian filter B × T = 0.3

rms <0.4°, typ. 0.15° peak <1.2°, typ. 0.4°

Error vector magnitude 8PSK EDGE, Gaussian linearized filter,

<0.5 %, typ. 0.2 %

rms Power density spectrum

values measured with 30 kHz resolution

bandwidth, referenced to level in band

center without power ramping

with R&S

SMJ-B103 frequency option

≤10.5 dBm,

level

SMJ-B106 frequency option

level

≤5.5 dBm

frequency 400 MHz to 2 GHz 200 kHz offset <–34 dB, typ. –37 dB 400 kHz offset <–68 dB, typ. –71 dB 600 kHz offset <–80 dB, typ. –85 dB

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

3GPP FDD digital standard (R&S®SMJ-K42 option)

WCDMA 3GPP FDD digital standard in line with 3GPP standard, release 6

frequency bands in line with

3GPP TS 25.101 in uplink and downlink

range as R&S Signal generation modes/sequence length Combination of realtime operation (enhanced channels) and arbitrary waveform mode.

In downlink mode, the P-CCPCH (BCCH with running SFN) and up to three DPCHs can

be generated in realtime. All other channels (frame-cycle control channels such as

SCH, OCNS simulation, other base stations, etc) can be added via the ARB. In uplink

mode, one mobile station can be simulated in realtime (PRACH, PCPCH, or DPCCH

and up to 6 DPDCHs); further mobile stations (three user-configured and up to 64 of

identical mode) can be simulated via the ARB and added to the realtime signal.

The sequence length of the ARB component can be entered in frames (10 ms each);

the max. length depends on chip rate, mode, and in some cases oversampling. Enhanced channels special capabilities in up to 4 channels of base station 1 on downlink and in all channels

of mobile station 1 on uplink:

realtime calculation, optional channel coding, simulation of bit and block errors, data

lists as sources for data and TPC fields Modulation BPSK (uplink)

Test models

downlink (in line with TS 25.141) test model 1 with 16/32/64 channels

uplink (not standardized) DPCCH + 1 DPDCH at 60 ksps

Test case wizard shortcut in line with TS 25.141 test cases Generate waveform file filtering of data generated in ARB mode and saving it as waveform file

Realtime component

WCDMA signal in realtime generation of WCDMA signals with up to 4 active enhanced channels Applications continuous measurement of BER and BLER (with channel coding) in a code channel

with any (PN) data without wrap-around problems

use of user data (data lists) with externally processed long data sequences for

enhanced channels Data lists for data and TPC field The data fields and the transmit power control (TPC) field of the slots of enhanced

channels can be filled from data lists. Externally generated data can thus be fed into the

signal generation process of the R&S

higher layers, on transport or physical layer. Long power control profiles for power

control of the DUT can also be generated. Applications measurement of power control steps of a mobile station (UE power control steps)

measurement of maximum output power of a mobile station (UE max. output power)

UTRA FDD frequency bands I to III Frequency range

SMJ100A

QPSK (downlink) 16QAM (downlink HSDPA)

test model 2 test model 3 with 16/32 channels test model 4 test model 5 with 8/4/2 HS-PDSCH channels

DPCCH + 1 DPDCH at 960 ksps

SMJ100A, e.g. with payload information from

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Channel coding

coding of up to 4 enhanced channels in line with the definition of reference

measurement channels in TS 25.101, TS 25.104, and TS 25.141; in addition, user-

configurable channel coding for each enhanced channel station

predefined channel coding schemes for

uplink and downlink

RMC 12.2 kbps AMR 12.2 kbps RMC 64 kbps RMC 144 kbps

RMC 384 kbps possible settings of user-configurable channel coding

transport channels

1 DCCH

up to 6 DTCHs

transport block size 1 to 4096 transport blocks 1 to 16 rate matching attribute 16 to 1024 transport time interval 10 ms, 20 ms, 40 ms, 80 ms CRC size none, 8, 12, 16, 24 error protection none, convolutional coding rate 1/3,

convolutional coding rate 1/2, turbo coding

rate 1/3 interleaver 1/2 state ON/OFF

Applications BER measurements in line with TS 25.101/104/141 (radio transmission and reception),

e.g. adjacent channel selectivity blocking characteristics intermodulation characteristics BLER measurements in line with TS 25.101/104 (radio transmission and reception), e.g. demodulation of dedicated channel under static propagation conditions (AWGN generation together with R&S

SMJ-K62)

test of decoder in receiver

Bit error insertion

deliberate generation of bit errors by impairing the data stream prior to channel coding or at the physical layer bit error ratio 0.5 to 10

−

Application verification of internal BER calculation in line with TS 25.141 (BS conformance testing) Block error insertion

deliberate generation of block errors by impairing the CRC during coding of enhanced channels block error ratio 0.5 to 10

−

Application verification of internal BLER calculation in line with TS 25.141 (BS conformance testing) Add OCNS

Simulation of orthogonal background and interfering channels of a base station in line with TS 25.101. The power of the OCNS channels is configured automatically so that the total power of the BS is 1.

Applications testing the receiver of the mobile station under real conditions;

measuring the maximum input level in line with TS 25.101

Additional mobile stations Simulation of up to 64 mobile stations in addition to the 4 user-configurable mobile

stations. The additional mobile stations use different scrambling codes.

Parameters

number of additional mobile stations 1 to 50 scrambling code step 1 to 1000 hex power offset

−20 dB to 20 dB

Applications base station tests under real receive conditions

General settings

Triggering see I/Q baseband generator

standard 3.840 Mcps (15 slots/frame) Chip rate range 1 Mcps to 5 Mcps

Link direction uplink (reverse link) and

downlink (forward link)

Baseband filter

standard

other filters

, α = 0.22

cos

, cos, user filters

cos

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Clipping

Setting of clipping value relative to highest peak in percent. Clipping takes place prior to baseband filtering. Clipping reduces the crest factor.

modes

vector |i + j q|

scalar |i|, |q| clipping level 1 % to 100 %

Code channels

downlink up to 512 data channels (plus special

channels) divided among up to 4 base

stations (BS) of 128 code channels each uplink up to 4 user-configurable mobile stations

(MS) and 64 additional MS of identical

configuration in each of the modes

PRACH Only, PCPCH Only, DPCCH +

DPDCHs

Parameters of every BS

State ON/OFF Scrambling code 0 to 5FFF hex 2nd search code group 0 to 63 Page indicators per frame 18, 36, 72, 144 Time delay The signals of the various base stations

0 chips to 38400 chips are delayed against each other.

Transmit diversity The output signal can be generated either

OFF/antenna 1/antenna 2 for antenna 1 or 2, as defined in the standard.

Physical channels in downlink

primary common pilot channel (P-CPICH) secondary common pilot channel (S-CPICH) primary sync channel (P-SCH) secondary sync channel (S-SCH) primary common control physical channel (P-CCPCH) secondary common control physical channel (S-CCPCH) page indication channel (PICH) access preamble acquisition indication channel (AP-AICH) collision detection acquisition indication channel (AICH) physical downlink shared channel (PDSCH) dedicated physical control channel (DL-DPCCH) dedicated physical channel (DPCH) high-speed shared control channel (HS-SCCH) high-speed physical downlink shared channel (HS-PDSCH), modulation QPSK or 16QAM

Parameters of every downlink code channel that can be set independently

State ON/OFF Slot format depending on physical channel type 0 to 16 Symbol rate depending on physical channel type 7.5 ksps to 960 ksps Channelization code value range depending on physical

0 to 511 channel type and symbol rate

Power −80 dB to 0 dB Payload data PRBS: 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit)

data lists

Multicode state ON/OFF Timing offset time offset that can be separately set for

0 to 150 (in units of 256 chips) each code channel

Pilot length depending on symbol rate 2 bit, 4 bit, 8 bit, 16 bit Pilot power offset power offset of pilot field against data

−10 dB to 10 dB

fields

TPC pattern all 0, all 1, pattern (length 1 bit to 32 bit),

data lists

TPC pattern readout mode application mode for TPC pattern continuous, single + all 0, single + all 1,

single + alt. 01, single + alt. 10

Use of TPC for dynamic output power control

If this function is active, the TPC pattern is used to vary the transmit power of the code channels versus time. state ON/OFF output power control step

TPC power offset power offset of TPC field relative to data

−10 dB to +10 dB

−10 to +10 dB

fields

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

TFCI state ON/OFF TFCI 0 dB to 1023 dB TFCI power offset power offset of TFCI field relative to data

−10 dB to +10 dB

fields

Parameters of every MS

State ON/OFF Mode PRACH Only, PCPCH Only, DPCCH +

DPDCHs

Scrambling code 0 to FF FFFF hex Scrambling code mode long, short Time delay The signals of the various mobile stations

0 chips to 38400 chips are delayed against each other.

Physical channels in uplink

physical random access channel (PRACH) physical common packet channel (PCPCH) dedicated physical control channel (DPCCH) dedicated physical data channel (DPDCH)

PRACH Only mode

Submodes

Preamble Only: Only preambles are generated. Application: Detection of RACH preamble in line with TS 25.141. Standard: The message part of the PRACH is generated in addition to a settable number of preambles. It can also be channel-coded. Application: Demodulation of RACH message part in line with TS 25.141.

Frame structure preamble(s), message part consisting of

data and control component

Slot format 0 to 3 Symbol rate 15 ksps, 30 ksps, 60 ksps, 120 ksps Preamble part power −80 dB to 0 dB Preamble power step 0 dB to 10 dB Preamble repetition 1 to 10 Data part power −80 dB to 0 dB Control part power −80 dB to 0 dB Signature 0 to 15 Access slot 0 to 14 AICH transmission timing 0 (3 access slots) or

1 (4 access slots)

Message part length 1 frame, 2 frames TFCI 0 to 1023 Payload data PRBS: 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit),

data lists

Channel coding

reference measurement channel for UL RACH in line with TS 25.141 state ON/OFF transport block size 168, 360

PCPCH Only mode

Submodes

Preamble Only: Only preambles are generated. Application: Detection of CPCH preamble in line with TS 25.141. Standard: The message part of the PCPCH is generated in addition to a settable number of preambles. It can also be channel-coded. Application: Demodulation of CPCH message part in line with TS 25.141.

Frame structure access preamble(s), collision detection

preamble, power control preamble,

message part consisting of data and

control component

Slot format control part 0 to 2 Symbol rate 15 ksps, 30 ksps, 60 ksps, 120 ksps,

240 ksps, 480 ksps, 960 ksps

Preamble part power −80 dB to 0 dB Preamble power step 0 dB to 10 dB Preamble repetition 1 to 10 Data part power −80 dB to 0 dB Control part power −80 dB to 0 dB Signature 0 to 15 Access slot 0 to 14

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

AICH transmisson timing 0 (3 access slots) or

1 (4 access slots)

Message part length 1 frame to 10 frames Power control preamble length 0, 8 slots FBI state OFF/1 bit/2 bit FBI pattern pattern (length 1 bit to 32 bit) Payload data PRBS: 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit)

data lists

Channel coding

reference measurement channel for UL CPCH in line with TS 25.141

state ON/OFF transport block size 168, 360

DPCCH + DPDCH Only mode

DPCCH (dedicated physical control channel)

symbol rate 15 ksps power −80 dB to 0 dB channelization code 0, fixed FBI state OFF/1 bit/2 bit FBI pattern pattern (length 1 bit to 32 bit) TFCI state ON/OFF TFCI 0 to 1023 TPC pattern

TPC pattern readout mode (application mode for TPC pattern)

all 0, all 1, pattern (length 1 bit to 32 bit),

data lists

continuous, single + all 1, single + all 1,

single + alt. 01, single + alt. 10 TPC for dynamic output power control; if this function is active, the TPC pattern is used to vary the transmit power of the code channels of the MS versus time

state ON/OFF

DPDCH (dedicated physical data channel)

output power control step overall symbol rate (total symbol rate of all uplink DPDCHs)

−10 dB to +10 dB

15 ksps, 30 ksps, 60 ksps, 120 ksps, 240 ksps, 480 ksps, 960 ksps, 2 × 960 ksps, 3 × 960 ksps, 4 × 960 ksps, 5 × 960 ksps, 6 × 960 ksps

depending on overall symbol rate:

active DPDCHs 1 to 6

symbol rate fixed for active DPDCHs

channelization code fixed for active DPDCHs

channel power −80 dB to 0 dB payload data PRBS: 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit) data lists

Graphical display domain conflicts, code domain, channel

graph, slot structure, and formats offered

in graphics block Error vector magnitude 1 DPCH, rms <0.8 %, typ. 0.3 % Adjacent-channel leakage ratio (ACLR)

test model 1, 64 DPCHs with R&S

with R&S

SMJ-B103 frequency option

level

≤10.5 dBm PEP

SMJ-B106 frequency option

≤5.5 dBm PEP

level

frequency 1800 MHz to 2200 MHz

offset 5 MHz >66 dB, typ. 69 dB offset 10 MHz >68 dB, typ. 71 dB

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

ACLR (typical values) for 3GPP test model 1, 64 DPCH

ACLR (typical values) for a 3GPP four-carrier signal with test model 1, 64 DPCH on each carrier

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

3GPP FDD enhanced BS/MS test including HSDPA (R&S®SMJ-K43 option)

The R&S®SMJ-K42 option must be installed.

General parameters This option extends the R&S

support and dynamic power control. Therefore, all general parameters of the

R&S

SMJ-K42 such as frequency range or modulation are also valid for the

SMJ-K43.

R&S

Downlink simulation

HSDPA channels (HS-SCCH, HS-PDSCH, and F-DPCH) Enhancements The R&S®SMJ-K42 supports simulation of HDSPA channels in a continuous mode

needed for TX measurements in line with TS 25.141 (test model 5). The R&S now supports simulation of HS-SCCH (high speed shared control channel) and HS-PDSCH (high speed physical downlink shared channel) in line with TS 25.211. This implies the correct timing between these channels as well as the possibility to set start subframe and inter-TTI distance. In addition, several F-DPCHs (fractional dedicated physical channel) can be generated. TX measurements on 3GPP FDD Node Bs with realistic statistics Application RX measurements on 3GPP FDD UEs with correct timing

Ranges (valid for HS-SCCH and

HSDPA mode continuous, subframe 0 to subframe 4

HS-PDSCH)

inter-TTI distance 1 to 16 Burst mode ON: DTX between two HS-PDSCH

Fixed reference channel definition H-Set Enhancements The R&S®SMJ-K43 allows HSDPA downlink channels with channel coding to be

generated in line with the definition of the fixed reference channels (H-Set) in TS 25.101; in addition, user-configurable bit/block error insertion is possible.

Ranges

H-Set H-Set 1 to H-Set 6 slot format QPSK, 16QAM (H-Set 1 to H-Set 3) RV parameter 0 to 7 UEID 0 to 65535 bit error insertion 0.5 to 10

block error insertion 0.5 to 10 Dynamic power control Enhancements

The R&S®SMJ-K42 provides a method to vary the output power of a code channel in

arbitrary waveform mode by misusing its TPC pattern. The R&S

the variation of the output power in realtime mode for up to 3 DPCHs in three

submodes:

external UE provides TPC info to R&S®SMJ100A

by TPC pattern TPC pattern is used to control the output

manual the output power is changed incrementally

RX measurements on 3GPP FDD UEs where closed loop power control is needed Application

RX measurements on 3GPP FDD UEs with varied code channel power without

dropouts in the signal Ranges

mode external, by TPC pattern, manual

direction up, down

power step 0.5 dB to 6 dB

up range 0 dB to 20 dB

down range 0 dB to 20 dB

SMJ-K42 (3GPP FDD digital standard) to full HSDPA

SMJ-K43

(where first packet is sent), H-Set

packets OFF: transmission of dummy data between two HS-PDSCH packets

−

coding or at the physical layer)

(insertion prior to channel

−

SMJ-K43 now allows

by external connector (TTL level)

power

by pressing buttons or sending the corresponding remote control commands

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Uplink simulation

HS-DPCCH (high speed dedicated physical control channel) Enhancements The R&S®SMJ-K42 does not support HSDPA for uplink. The R&S®SMJ-K43 now allows

the simulation of a HS-DPCCH (high speed dedicated physical control channel) in

realtime operation (UE1) and arbitrary waveform mode (UE2 to UE4). Application TX measurements on 3GPP FDD UEs supporting HSDPA

RX measurements on 3GPP FDD Node Bs supporting HDSPA Ranges

power −80 dB to 0 dB

start delay 101 to 250 (in units of 256 chips)

inter-TTI distance 1 subframe to 16 subframes

CQI pattern up to 10 CQI values sent periodically,

support of DTX

ACK/NACK pattern up to 32 ACK/NACK commands sent

periodically, support of DTX Dynamic power control Enhancements

The R&S®SMJ-K42 provides a method to vary the output power of a code channel in arbitrary waveform mode by misusing its TPC pattern. The R&S

SMJ-K43 now allows the variation of the output power in realtime mode for UE1 in three submodes: external

Node B provides TPC info to the

R&S

SMJ100A by external connector

(TTL level)

by TPC pattern TPC pattern is used to control the output

power

manual the output power is changed incrementally

Application RX measurements on 3GPP FDD Node Bs where closed loop power control is needed

RX measurements on 3GPP FDD Node Bs with varied UE power without dropouts in the signal

Ranges

mode external, by TPC pattern, manual direction up, down power step 0.5 dB to 6 dB up range 0 dB to 20 dB down range 0 dB to 20 dB

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

GPS digital standard (R&S®SMJ-K44 option)

GPS digital standard in line with ICD-GPS-200 revision C

General settings

Frequency default L1 = 1575.42 MHz

Output level default –115 dBm

Modulation BPSK (CDMA) Symbol rate (chip rate) 1.023 MHz Baseband filter Gaussian

Simulation modes generic mode

Marker navigation data bit (20460 chips)

Triggering see I/Q baseband generator

Navigation data

Navigation data identical for each satellite all 0

Real navigation data support of SEM-Almanac, any valid date

Navigation data rate 50 bps

Satellite configurations

Number of channels 1 to 4 satellites Use spreading code identical for each satellite ON/OFF State separately settable for each satellite ON/OFF Space vehicle ID separately settable for each satellite C/A codes: 37 Gold codes, 1023 chips

Time shift separately settable for each satellite 0 to 10000000 (C/A code chip)/16 Power separately settable for each satellite ±10 dB Doppler shift separately settable for each satellite ±100 kHz (selectable in steps of 0.01 Hz)

Localization mode

Latitude latitude of simulated location ±90° (selectable in steps of 0.1 s) Longitude longitude of simulated location ±180° (selectable in steps of 0.1 s) Altitude altitude of simulated location ±10000 m

user-selectable in entire frequency range

SMJ100A

of R&S

user-selectable in entire output level range

of R&S

SMJ100A

filter parameter B × T = 1

localization mode

navigation data word (30 data bits) navigation data subframe (10 data words) navigation page (5 data subframes) complete navigation message (25 data pages) pulse pattern ON/OFF radio

all 1 pattern (up to 64 bit) PN 9 to PN 23 data lists real navigation data

and time (GMT)

each

(selectable in steps of 0.1 m)

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

3GPP FDD HSUPA (R&S®SMJ-K45 option)

The R&S®SMJ-K42 option must be installed.

General parameters This option extends the R&S

support. Therefore, all general parameters of the R&S range or modulation are also valid for the R&S

Downlink simulation

HSUPA channels (E-AGCH, E-RGCH, E-HICH) Enhancements The R&S®SMJ-K45 in downlink supports simulation of HSUPA control channels

E-AGCH (E-DCH absolute grant channel), E-RGCH (E-DCH relative grant channel), and E-HICH (E-DCH hybrid ARQ indicator channel) in line with TS 25.211.

Application RX measurements on 3GPP FDD UEs with correct timing Ranges (valid for E-RGCH and E-HICH)

type of cell serving cell, non-serving cell E-DCH TTI 2 ms, 10 ms signature sequence index 0 to 39 (in line with TS 25.211) relative grant pattern

ACK/NACK pattern up to 32 ACK/NACK commands sent

Uplink simulation

E-DPCCH (E-DCH dedicated physical control channel), E-DPDCH (E-DCH dedicated physical data channel) Enhancements The R&S®SMJ-K45 in uplink supports simulation of an E-DPCCH and up to four

E-DPDCHs with channel coding in line with the definition of the fixed reference channels in TS 25.104 and TS 25.141. Furthermore, a method is provided to control the output of the FRC HARQ processes in realtime by means of a feedback line (TTL) sending ACKs and NACKs in order to fulfill the requirements defined in 3GPP TS

25.141, chapters 8.12 and 8.13.

Application RX measurements on 3GPP FDD Node Bs supporting HSUPA E-DPCCH

power −80 dB to 0 dB retransmission sequence number 0 to 3 E-TFCI information 0 to 127 happy bit 0, 1 E-DCH TTI 2 ms, 10 ms DTX pattern up to 32 TX/DTX commands sent

E-DPDCH

overall symbol rate (total symbol rate of all uplink E-DPDCHs) depending on overall symbol rate

active E-DPDCHs 1 to 4 symbol rate fixed for active E-DPDCHs channelization code fixed for active E-DPDCHs

common for all E-DPDCHs

channel power −80 dB to 0 dB

payload data

E-DCH TTI 2 ms, 10 ms DTX pattern up to 32 TX/DTX commands sent

SMJ-K42 (3GPP FDD digital standard) to full HSUPA

SMJ-K45.

SMJ-K42 such as frequency

up to 32 UP/DOWN/HOLD commands sent periodically

periodically

periodically 60 ksps, 120 ksps, 240 ksps, 480 ksps, 960 ksps, 2 × 960 ksps, 2 × 1920 ksps

PRBS: 9, 11, 15, 16, 20, 21, 23 all 0, all 1, pattern (length 1 bit to 64 bit) data lists

periodically

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

HSUPA FRC

channel coding in line with the definition of fixed reference channels in TS 25.104 and TS 25.141; in addition, user-configurable”HARQ feedback simulation”, virtual HARQ mode and bit/block error insertion fixed reference channel (FRC) (predefined

FRC 1 to FRC 7 channel coding schemes) DTX pattern up to 32 TX/DTX commands sent

periodically HARQ feedback simulation: feedback (TTL) connected to LEVATT

always use RV 0 ON/OFF maximum number of retransmissions 0 to 20 ACK definition high, low

additional user delay –50 to +50 (in units of 256 chips) virtual HARQ simulation: HARQ ACK/NACK pattern

up to 32 ACK/NACK commands sent

periodically (individual ACK/NACK pattern for each HARQ process) bit error insertion (deliberate generation of bit errors by impairing the data stream prior to channel coding or at the physical layer)

bit error ratio 0.5 to 10 application

verification of internal BER calculation in

line with TS 25.141 (BS conformance

−

testing) block error insertion (deliberate generation of block errors by impairing the CRC during coding of enhanced channels)

block error ratio 0.5 to 10

−

application verification of internal BLER calculation in

line with TS 25.141 (BS conformance

testing)

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

CDMA2000® digital standard (R&S®SMJ-K46 option)

CDMA2000® digital standard release C in line with 3GPP2 C.S0002-C Frequency band class 0 to band class 12 410 MHz to 2170 MHz

standard 1.2288 MHz (1X) Chip rates range 1 MHz to 5 MHz

Modes 1 × direct spread (spreading rate 1) Link direction forward link and

reverse link

Sequence length sequence length entered in frames (80 ms each), max. length 1022 frames with

Baseband filter

Code channels

Clipping level Setting of a limit value relative to the

Generate waveform file filtering of data generated in ARB mode and saving it as waveform file

Parameters of every BS

State ON/OFF Time delay

PN offset 0 to 511 Transmit diversity If this function is activated, the output

Diversity mode OTD/STS Quasi-orthogonal Walsh sets set 1 to set 3

Parameters of every forward link code channel that can be set independently

State ON/OFF Channel types Forward link

Radio configuration chip rate 1.2288 Mcps (1X) RC 1 to RC 5 and RC 10 Frame length depending on channel type and radio

Data rate depending on channel type and radio

Walsh code depending on channel type and radio

SMJ-B9, 511 frames with R&S®SMJ-B10, 160 frames with R&S®SMJ-B11

R&S standard for reverse link cdmaOne standard for forward link cdmaOne + equalizer for enhanced ACLR:

reverse link cdmaOne 705 kHz forward link cdmaOne 705 kHz + equalizer

forward link 4 base stations with a maximum of

reverse link 4 mobile stations with a maximum of

highest peak in percent. Limitation is effected prior to baseband filtering and reduces the crest factor.

timing offset of signals of individual base stations

BS1 0 chips (fixed) BS2 to BS4 0 chips to 98304 chips

signal can be generated for either antenna 1 or 2, as defined in the standard.

forward pilot (F-PICH) transmit diversity pilot (F-TDPICH) auxiliary pilot (F-APICH) auxiliary transmit diversity pilot (F-ATDPCH) sync (F-SYNC) paging (F-PCH) broadcast (F-BCH) quick paging (F-QPCH) common power control (F-CPCCH) common assignment (F-CACH) common control (F-CCCH) packet data control (F-PDCCH) packet data (F-PDCH) traffic channel:

fundamental (F-FCH) supplemental (F-SCH) dedicated control (F-DCCH)

configuration

78 code channels each (depending on

radio configuration)

8 code channels each (depending on radio

configuration)

value range 1 % to 100 %

OFF

antenna 1

antenna 2

5 ms, 10 ms, 20 ms, 40 ms, 80 ms,

160 ms

1.2 kbps to 1036.8 kbps

0 to 127

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Quasi-orthogonal code ON/OFF Power –80 dB to 0 dB Data all 0

all 1

pattern (up to 64 bit)

PN 9 to PN 23

data lists

Long code mask 0 to 3FF FFFF FFFF hex Power control data source all 0

all 1

pattern (up to 64 bit)

data list

(Mis)use for output power control

If this function is active, the power control data is used to vary the transmit power of the code channels versus time. state ON/OFF output power control step –10 dB to +10 dB

Channel coding

All stages of channel coding specified by IS-2000 (e.g. frame quality indicator, convolutional encoder/turbo coder, symbol puncture, and interleaver) are available. All frame length and data rate combinations are supported. Four options are available:

OFF channel coding OFF complete channel coding completely ON

without interleaving channel coding ON but without interleaver

interleaving only channel coding OFF, only interleaver is

active

Parameters of every MS

State ON/OFF Radio configuration chip rate 1.2288 Mcps (1X) RC 1 to RC 4 Channel coding

All stages of channel coding specified by IS-2000 (e.g. frame quality indicator, convolutional encoder, symbol puncture and interleaver) are available. All frame length and data rate combinations are supported.

Four options are available:

OFF channel coding OFF complete channel coding completely ON without interleaving channel coding ON but without interleaver interleaving only channel coding OFF, only interleaver is

active

Operating mode simulates MS operating mode and defines

available channels

traffic

access

enhanced access

common control

Long code mask 0 to 3FF FFFF FFFF hex Power control data source In reverse link, the power control data is

used only for the misuse mode.

all 0

all 1

pattern (up to 64 bit)

data list

(Mis)use for output power control

If this function is active, the power control data is used to vary the transmit power of the code channels versus time. state OFF/ON output power control step –10 dB to +10 dB

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Parameters of every reverse link code channel that can be set independently

State OFF/ON Channel types Reverse link

reverse pilot (R-PICH) access (R-ACH) enhanced access (R-EACH) reverse common control (R-CCCH) reverse dedicated control (R-DCCH) traffic channel

fundamental (R-FCH) supplemental code (R-SCCH) supplemental (R-SCH)

Frame length depending on channel type and radio

5 ms, 10 ms, 20 ms, 40 ms, 80 ms configuration

Data rate depending on channel type and radio

1.2 kbps to 1036.8 kbps

configuration

Power –80 dB to 0 dB Data all 0

all 1

pattern (up to 64 bit)

PN 9 to PN 23

data lists

Error vector magnitude (EVM) F-PICH, F-SYNC, and one F-FCH, rms <0.8 %, typ. 0.3 % Adjacent-channel leakage ratio (ACLR)

F-PICH, F-SYNC, and one F-FCH carrier frequency 800 MHz

channel spacing 0.75 MHz

typ. 79 dB

(bandwidth 30 kHz) channel spacing 1.98 MHz

typ. 90 dB

(bandwidth 30 kHz)

ACLR (typical values) for a CDMA2000

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

1x signal consisting of F-PICH, F-SYNC, and one F-FCH

IEEE 802.11 a/b/g digital standard (R&S®SMJ-K48 option)

IEEE 802.11 a/b/g digital standard in line with IEEE 802.11a1999,

IEEE 802.11b 1999, IEEE 802.11g 2003

General settings

Modes

Sequence length 1 frame to 511 frames (depending on

Clipping vector or scalar clipping, applied before

Generate waveform file filtering of data generated in ARB mode and saving it as waveform file Marker modes restart, frame start, frame active part,

Triggering see I/Q baseband generator

Parameters in framed mode

Idle time

MAC header activating and configuring the MAC header

Frame check sequence activating or deactivating a 32 bit (4 byte)

Settings for CCK (IEEE 802.11b/IEEE 802.11g)

Baseband filter spectral mask in line with

Parameters in framed mode

Parameters in unframed mode

Settings for OFDM (IEEE 802.11a/IEEE 802.11g)

Baseband filter spectral mask in line with IEEE 802.11b

unframed generation of a non-packet-oriented signal

without frame structure, with the

modulation modes and data rates defined

by the IEEE 802.11 standard. framed generation of a sequence of data packets

with the frame structure defined by the

standard, interrupted by an idle time

frame duration)

filtering

pulse, pattern, ON/OFF ratio

time between two successive packets (PPDUs)

range 0 s to 10000 µs

with the following parameters: frame

control, duration/ID, address 1 to 4, and

sequence control

check sum for protecting MAC header and

user data (frame body)

standard 11 Mcps Chip rate range as R&S

SMJ100A

IEEE 802.11b-1999 – Wireless LAN MAC

and PHY specifications – chapter 18.4.7.3 PLCP preamble and header format long PLCP and short PLCP

PSDU bit rate 1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps

PSDU modulation (depending on PSDU

DBPSK, DQPSK, CCK bit rate) PSDU data length (length of user data field in bytes of the packet to be transferred)

range 0 byte to 4095 byte

scrambling data scrambling can be activated or

deactivated PSDU bit rate 1 Mbps, 2 Mbps, 5.5 Mbps, or 11 Mbps

PSDU modulation (depending on PSDU

DBPSK, DQPSK, CCK bit rate) scrambling data scrambling can be activated or

deactivated

standard 20 Msample/s Kernel sample rate range as R&S

SMJ100A

1999 – Wireless LAN MAC and PHY

specifications – chapter 17.3.9.6.2

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Parameters in framed mode

PLCP preamble and header format long PLCP and short PLCP

PLCP signal field automatically calculated PSDU bit rate

PSDU modulation (depending on PSDU

6 Mbps, 9 Mbps, 12 Mbps, 18 Mbps,

24 Mbps, 36 Mbps, 48 Mbps, or 54 Mbps

BPSK, QPSK, 16QAM, 64QAM bit rate) PSDU data length (length of user data field in bytes of the packet to be transferred)

range 0 byte to 4095 byte

number of data symbols (number of

directly proportional to PSDU data length OFDM symbols in data portion of packet) scrambling

data scrambling can be activated or

deactivated; initial scrambler state can be

set randomly or to a user-defined value interleaver can be activated or deactivated time domain windowing (transition times) 0 s to 1000 ns service field user-defined service field value supported

Parameters in unframed mode

PSDU bit rate

PSDU modulation (depending on PSDU

6 Mbps, 9 Mbps, 12 Mbps, 18 Mbps,

24 Mbps, 36 Mbps, 48 Mbps, or 54 Mbps

BPSK, QPSK, 16QAM, 64QAM bit rate) PSDU data length (length of user data field in bytes of the packet to be transferred

range 0 byte to 2312 byte

number of data symbols (number of

directly proportional to PSDU data length OFDM symbols to be generated) scrambling data scrambling can be activated or

deactivated; initial scrambler state can be

set randomly or to a user-defined value interleaver can be activated or deactivated time domain windowing (transition times) 0 s to 1000 ns service field user-defined service field value supported

Settings for PBCC (IEEE 802.11b/IEEE 802.11g)

standard 11 Mcps Chip rate range as R&S

SMJ100A

Baseband filter spectral mask in line with IEEE 802.11b

1999 – Wireless LAN MAC and PHY

specifications – chapter 18.4.7.3

Parameters in framed mode

PLCP preamble and header format long PLCP and short PLCP

PSDU bit rate

PSDU modulation (depending on PSDU bit rate) PSDU data length (length of user data

1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps,

22 Mbps

DBPSK, DQPSK, PBCC

field in bytes of the packet to be transferred)

range 0 byte to 4095 byte

scrambling data scrambling can be activated or

deactivated

Parameters in unframed mode

PSDU bit rate

PSDU modulation (depending on PSDU

1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps,

22 Mbps

DBPSK, DQPSK, PBCC bit rate) scrambling data scrambling can be activated or

deactivated

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

IEEE 802.16 WiMAX digital standard including IEEE 802.16e

(R&S

IEEE 802.16 digital standard in line with IEEE 802.16™ 2004/Cor1/D5

Link direction forward link and

Physical layer modes OFDM, OFDMA, OFDMA/WiBro Duplexing TDD, FDD Frame durations 2 ms, 2.5 ms, 4 ms, 5 ms, 8 ms, 10 ms,

Sequence length (frames) depending on frame duration, sample rate,

Predefined frames in OFDM mode short, medium, and long test messages for

in OFDMA mode predefined setups for all bandwidths and

Generate waveform file filtering of data generated in ARB mode and saving it as waveform file

Parameters in OFDM mode

Predefined frequency bands ETSI, MMDS, WCS, U-NII, user Channel bandwidth depending on selected frequency band 1.25 MHz to 30 MHz Sampling rate depending on channel bandwidth 1.5 MHz to 32 MHz Tg/Tb settings 1/4, 1/8, 1/16, 1/32 FFT size 256 (fixed) Frame preamble long, short, OFF Modulation and RS-CC rates BPSK 1/2, QPSK 1/2, QPSK 3/4,

Subchannelization (number of possible channels) Number of bursts with different modulation formats per frame Burst types data, DL-MAP, UL-MAP, ranging Data all 0

Midamble repetition in uplink mode OFF, 5, 9, 17

Parameters in OFDMA mode

Predefined frequency bands ETSI, MMDS, WCS, U-NII, WiBro, user Channel bandwidth depending on selected frequency band 1.25 MHz to 30 MHz Sampling rate depending on channel bandwidth 1.5 MHz to 32 MHz Tg/Tb settings 1/4, 1/8, 1/16, 1/32 FFT size 128, 512, 1024, 2048 Preamble modes Auto and User with index 0 to 113 Number of zones/segments 8 Space-time coding modes OFF

Modulation and coding rates QPSK 1/2, QPSK 3/4, 16QAM 1/2,

Channel coding modes OFF, CC, CTC Channel coding parts scrambler, FEC, interleaver can be

Repetition coding 0, 2, 4, 6 Subcarrier permutation FUSC, PUSC Subchannel map user-definable for PUSC Subchannel rotation ON/OFF (for uplink PUSC)

SMJ-K49 option)

and IEEE 802.16e 2005

reverse link

12.5 ms, 20 ms, continuous, user

1 to >2000 and available ARB memory

BPSK, QPSK, 16QAM, and 64QAM

modulation

modulations specified in MRCT 1.0.0,

appendix 2 in OFDM mode FCH/burst or preamble Level reference in OFDMA/WiBro mode preamble or subframe RMS power

16QAM 1/2, 16QAM 3/4, 64QAM 2/3,

64QAM 3/4 1, 2, 4, 8, 16 (all)

all 1

pattern (up to 64 bit)

PN 9 to PN 23

data lists

2 antennas matrix A

2 antennas matrix B

16QAM 3/4, 64QAM 1/2, 64QAM 2/3,

64QAM 3/4

switched ON/OFF independently

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Dedicated pilots ON/OFF (for downlink PUSC and

AMC2×3)

Number of bursts with different modulation

formats Burst types FCH, DL-MAP, UL-MAP, ranging, data Data all 0

all 1

pattern (up to 64 bit)

PN 9 to PN 23

data lists

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

TD-SCDMA digital standard (3GPP TDD LCR, R&S®SMJ-K50 option)

WCDMA 3GPP TDD LCR (TD-SCDMA) digital standard

Signal generation modes/sequence length

Modulation QPSK, 8PSK

General settings

Triggering see I/Q baseband generator

Baseband filter

Clipping

Code channels downlink/uplink: up to 16 data channels (plus special channels) per slot, 7 slots per

Configure cell

Reset all cells all channels are deactivated

Parameters of each cell

State ON/OFF Scrambling code scrambling code can be disabled for

SYNC-DL code automatic selection depending on

SYNC-UL code range depending on SYNC-DL code 0 to 255 Number of users 2, 4, 6, 8, 10, 12, 14, 16 Switching point switchover between uplink and downlink

DwPTS power –80 dB to 10 dB

Parameters for each downlink slot

State ON/OFF Slot mode downlink dedicated: simulation of up to 16

Parameters for each uplink slot

State ON/OFF Slot mode uplink dedicated: simulation of up to 16

in line with 3GPP TDD standard for chip

rate 1.28 Mcps (low chip rate mode) frequency bands in line with 3GPP TS 25.102 in uplink and downlink range as R&S Simulation of up to 4 TD-SCDMA cells with variable switching point of uplink and downlink. User-configurable channel table for each slot and simulation of the downlink and uplink pilot timeslot. In uplink, a PRACH can also be generated. The sequence length can be entered in frames (10 ms each).

filtering of data generated in ARB mode and saving it as waveform file Generate waveform file application: for multicarrier or multisegment scenarios

standard 1.28 Mcps (7 slots/subframe) Chip rate range 1 Mcps to 5 Mcps

standard

other filters

Setting of clipping value relative to highest peak in percent. Clipping takes place prior to baseband filtering. Clipping reduces the crest factor. modes vector |i + j q|

clipping level 1 % to 100 %

subframe, simulation of up to 4 cells

adopting a specific cell configuration to another cell to define multicell scenarios Copy cell parameters: source and destination of copying generation of complex signal scenarios with parameterizable default settings Predefined settings selectable parameters: use of P-CCPCH, number and spreading factors of data channels; crest factor: minimal/average/worst

testing

scrambling code

slots

DPCHs and max. 6 special channels

DPCHs and 1 PUSCH PRACH: simulation of one physical random access channel

UTRA TDD frequency bands a) to d) Frequency range

SMJ100A

uplink (reverse link) Link direction

downlink (forward link)

α = 0.22

cos

, cos, user filters

cos

scalar |i|, |q|

0 to 127

0 to 31

1 to 6

DPCH QPSK/8PSK: 0 to 24

DPCH PDSCH: 0 to 24

S-CCPCH: 0 to 9

DPCH QPSK, PUSCH: 0 to 69

DPCH 8PSK: 0 to 24

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Physical channels in downlink

primary common control physical channel 1 (P-CCPCH 1) primary common control physical channel 2 (P-CCPCH 2) secondary common control physical channel 1 (S-CCPCH 1) secondary common control physical channel 2 (S-CCPCH 2) fast physical access channel (FPACH) physical downlink shared channel (PDSCH) dedicated physical channel modulation QPSK (DPCH QPSK) dedicated physical channel modulation 8PSK (DPCH 8PSK)

Physical channels in uplink

physical uplink shared channel (PUSCH) dedicated physical channel modulation QPSK (DPCH QPSK) dedicated physical channel modulation 8PSK (DPCH 8PSK)

Parameters of every code channel that can be set independently

State ON/OFF Midamble shift time shift of midamble in chips: step width

0 to 120 8 chips controlled via the current user and the number of users

Slot format depending on physical channel type 0 to 69 Spreading factor depending on physical channel type and

1, 2, 4, 8, 16 link direction

Spreading code depending on physical channel type and

1 to 16 spreading factor

Power −80 dB to 0 dB Payload data PRBS 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit),

data lists

Number of TFCI bits

depending on modulation type

QPSK 0, 4, 8, 16, 32

8PSK 0, 6, 12, 24, 48 TFCI value 0 to 1023 Number of sync shift & TPC bits

depending on modulation type

QPSK 0 & 0, 3 & 3, 48 & 48

8PSK 0 & 0, 2 & 2, 32 & 32 Sync shift pattern up to 64 UP/DOWN/HOLD commands

sent periodically

“1” → up: increase sync shift “0” → down: decrease sync shift

“–“ → do nothing Sync shift repetition M 1 to 8 TPC source all 0, all 1, pattern (length 1 bit to 64 bit),

data lists TPC readout mode continuous, single + all 0, single + all 1,

single + alt.01, single + alt. 10

Parameters in uplink PRACH mode

UpPTS start subframe selection of first frame in which UpPTS is

1 subframe to 10 subframes

sent UpPTS power –80 dB to 0 dB UpPTS power step 0 dB to 10 dB Distance UpPTS distance UpPTS to PRACH message part 1 subframe to 4 subframes UpPTS repetition number of UpPTS repetitions 1 to 10 RACH message part state ON/OFF Message part length 1 subframe, 2 subframes, 4 subframes Spreading factor 4, 8, 16 Spreading code 0 to (spreading factor – 1) Message part power −80 dB to 0 dB Payload data PRBS: 9, 11, 15, 16, 20, 21, 23

all 0, all 1, pattern (length 1 bit to 64 bit), data lists

Current user 1 to 16

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

TD-SCDMA (3GPP TDD LCR) enhanced BS/MS test including HSDPA

(R&S

At least one R&S®SMJ-K50 option must be installed.

General parameters This option extends the R&S

Signal generation modes/sequence length

Modulation QPSK, 8PSK, 16QAM HSDPA physical channels

Channel coding

Applications BER measurements in line with TS 25.102/105/142 (radio transmission and reception),

Bit error insertion

Application verification of internal BER calculation in line with TS 25.142 (BS conformance testing)

Application verification of internal BLER calculation in line with TS 25.142 (BS conformance testing)

SMJ-K51 option)

SMJ-K50 (TD-SCDMA digital standard) to full channel coding and HSDPA support. Therefore, all general parameters of the R&S such as frequency range or modulation are also valid for the R&S

SMJ-K51.

SMJ-K50

Simulation of up to 4 TD-SCDMA cells with generation of the coded P-CCPCH (BCH with running SFN) and the reference measurement channels RMC 12.2 kbps up to RMC 2048 kbps. Simulation of the HSDPA channels HS-SCCH, HS-PDSCH (QPSK and 16QAM modulation), HS-SICH, and the channel coded H-RMC 526 kbps and H-RMC 730 kbps. Furthermore, bit and block errors can be inserted.

high speed shared control channel 1 (HS-SCCH 1) high speed shared control channel 2 (HS-SCCH 2) high speed physical downlink shared channel QPSK (HS-PDSCH QPSK) high speed physical downlink shared channel 16QAM (HS-PDSCH 16QAM) high speed shared information channel (HS-SICH) coding of enhanced channels in line with the definition of reference measurement channels in TS 25.102, TS 25.105, and TS 25.142 predefined channel coding schemes for

downlink coded BCH including

SFN RMC 12.2 kbps RMC 64 kbps RMC 144 kbps RMC 384 kbps RMC 2048 kbps H-RMC 526 kbps H-RMC 730 kbps

uplink RMC 12.2 kbps

RMC 64 kbps RMC 144 kbps RMC 384 kbps RMC 2048 kbps

e.g. adjacent channel selectivity blocking characteristics intermodulation characteristics BLER measurements in line with TS 25.102/105 (radio transmission and reception), e.g. demodulation of dedicated channel under static propagation conditions (AWGN generation together with R&S

SMJ-K62)

test of decoder in receiver

deliberate generation of bit errors by impairing the data stream prior to channel coding or at the physical layer

bit error ratio 0.5 to 10

deliberate generation of block errors by

Block error insertion

−

impairing the CRC during coding of enhanced channels

block error ratio 0.5 to 10

−

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

DVB-H digital standard (R&S®SMJ-K52 option)

DVB-H digital standard in line with ETSI EN 300 744 V1.5.1

General settings

Frequency default VHF 212.5 MHz

Output level default –30 dBm

Hierarchy mode hierarchical, non-hierarchical Sequence length number of superframes min: 1

standard cosine, α = 0.1 Baseband filter other see I/Q baseband generator

Clipping

Setting of clipping value relative to highest peak in percent. Clipping takes place prior to baseband filtering. Clipping reduces the crest factor. modes

clipping level 1 % to 100 %

Generate waveform file filtering of data generated in ARB mode and saving it as waveform file Marker restart

Triggering see I/Q baseband generator

Signal path parameters

Input data

Zero packets are generated and filled with desired data.

transport stream transport stream file (.GTS)

Scrambler state ON/OFF

Reed Solomon (204, 188, t = 8) Outer coder state ON/OFF convolutional byte-wise (depth: 12) Outer interleaver state ON/OFF

Inner coder

convolutional, punctured state ON/OFF code rates 1/2, 2/3, 3/4, 5/6, 7/8

Inner interleaver

state ON/OFF symbol interleaving block size 1512 bit in 2K mode

symbol interleaving modes native, in-depth

Modulation QPSK, 16QAM, 64QAM Transmission modes 2K with 1705 carriers

Guard Interval cyclic continuation of useful signal part length: 1/4, 1/8, 1/16, 1/32 of useful signal

Framing and signaling

Super frame size 4 frames Frame size 68 OFDM symbols TPS settings

cell ID 0000 to FFFF (user-defined) time slicing ON/OFF MPE-FEC ON/OFF

standard

user-selectable in entire frequency range

of R&S

SMJ100A

user-selectable in entire output level range

SMJ100A

of R&S

max: depending on baseband generator memory

vector |i + j q| scalar |i|, |q|

superframe start frame start pulse pattern ON/OFF ratio

PN 15, 23 all 0 all 1

bit-wise interleaving symbol interleaving

3024 bit in 4K mode 6048 bit in 8K mode

4K with 3409 carriers 8K with 6817 carriers

part

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

EUTRA/LTE digital standard (R&S®SMJ-K55 option)

EUTRA/LTE digital standard in line with 3GPP standard release 8

General settings

Frequency

Output level

Sequence length number of frames The sequence length can be entered in

standard cosine, α = 0.1 Baseband filter other see I/Q baseband generator

Clipping

Setting of clipping value relative to highest peak in percent. Clipping takes place prior to baseband filtering. Clipping reduces the crest factor. modes

clipping level 1 % to 100 %

Marker

Triggering Duplexing determines Duplexing mode

Note: TDD is not supported in this version.

Link direction determines whether uplink or downlink is

simulated Note: Uplink is not supported in this version.

Physical layer mode fixed value: depends on chosen link direction:

OFDMA in downlink, SC-FDMA in uplink

Frame duration fixed value: 10 ms Subframe duration fixed value: 0.5 ms

Physical settings

Channel bandwidth determines the channel bandwidth used 1.25 MHz, 2.5 MHz, 5 MHz, 10 MHz,

Physical resource block bandwidth determines the size of a physical resource

block; this parameter will be finally determined in the R&S

SMJ-K55 as soon as it is defined in the official 3GPP specification Note: 180 kHz is not supported in this version.

Sampling rate automatically set in line with the selected channel bandwidth FFT size automatically set in line with the selected channel bandwidth Number of occupied subcarriers

automatically set in line with the selected channel bandwidth

Number of left guard subcarriers automatically set in line with the selected FFT size Number of right guard subcarriers automatically set in line with the selected FFT size Number of resource blocks automatically set in line with the selected channel bandwidth and physical resource

block bandwidth

Downlink reference signal structure

Reference symbol configuration simulated antenna configuration

Note: Antennas 2 to 4 are not supported in this version.

First reference symbol position position in subframe of the first reference

symbol

Frequency spacing determines spacing in subcarriers

between two pilots

Subcarrier offset offset in subcarriers within one resource

block

user-selectable in entire frequency range

SMJ100A

of R&S default –30 dBm user-selectable in entire output level range

SMJ100A

of R&S

frames (10 ms each); the max. length depends on sample rate and ARB size.

vector |i + j q| scalar |i|, |q|

subframe radio frame start restart pulse pattern ON/OFF ratio see I/Q baseband generator FDD,TDD

downlink, uplink

15 MHz, 20 MHz 180 kHz, 375 kHz

antennas 1 to 4

1st symbol, 2nd symbol

2/4/6/8 subcarriers

0 to ("subcarrier_interleaving_factor" – 1)

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Reference symbol repetition period determines the period in subframes after

which the sequence for reference symbols

1/2/4/5/10/20 subframes

is repeated Note: The uploaded sequence for the reference symbols should be long enough to fill the period selected.

First reference symbol power power of 1st reference symbol –80 dB to 10 dB

Use second reference symbol determines whether 2nd reference symbol

is used

yes, no

Second reference symbol power power of 2nd reference symbol –80 dB to 10 dB Reference symbol sequence data set for reference symbols to be uploaded (in R&S®SMJ data list format)

Note: QPSK is assumed to be used for reference symbols.

SCH/BCH settings

SCH repetition period determines the period in subframes

2/4/5/10/20 subframes

between two SCH subframes

First SCH subframe determines the subframe in the frame in

which the SCH is initially transmitted

0 to ("SCH_rep_period" – 1)

Note: The SCH is automatically mapped to the endmost symbol of the subframe.

SCH power determines the power of the SCH

–80 dB to 10 dB

allocations

SCH sequence data set for SCH to be uploaded (in R&S®SMJ data list format)

Note: QPSK is assumed to be used for SCH. The first 150 bits are taken from the selected sequence and are mapped to the subcarriers used; therefore, the SCH always consists of the same sequence, regardless of the subframe.

BCH subframe determines the subframe in the frame in

0 to 19 which the BCH is transmitted Note: Must not overlap with SCH subframes. Otherwise, last valid configuration is restored.

BCH length determines the length of the BCH in

1 OFDMA symbols to 4 OFDMA symbols OFDMA symbols Note: The BCH is automatically mapped to the endmost symbols of the subframe

BCH bandwidth determines the bandwidth of the BCH

Note: BCH bandwidth of 5 MHz is only

1.25 MHz, 5 MHz

selectable if channel bandwidth ≥5 MHz

BCH power determines the power of the BCH

allocation

BCH data source determines the data source of the BCH

allocation Note: QPSK is assumed to be used for

–80 dB to 10 dB

PN9, PN11, PN15, …, PN 23, DList,

pattern, all 0, all 1

BCH.

Resource allocation downlink

Number of configurable subframes determines the number of configurable

subframes; the 20 subframes of one frame

1 to 20

are filled periodically with the configured subframes Note: SCH and BCH are configured globally and therefore not copied here. Using this function ensures a valid frame configuration.

Behavior in unscheduled resource blocks determines whether unscheduled resource

blocks and subframes are filled with

dummy data, DTX

dummy data or left DTX

Cyclic prefix determines whether a short or long cyclic

short, long prefix is used for a specific subframe Note: Automatically determines the number of OFDM symbols per subframe.

Number of allocations used determines the number of scheduled

allocations in the selected subframe

0 to (“total number of RBs” + SCH/BCH +

L1/L2CCH)

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Allocation table

Modulation determines the modulation scheme used QPSK, 16QAM, 64QAM CC (channel coding) determines the channel coding scheme

used

TC (turbo coding)/OFF

Note: Turbo coder is not supported in this version.

Transmission determines whether the allocation is

localized, distributed localized or distributed Note:

Distributed is not supported in this

version.

Number of resource blocks (RB) defines size of selected allocation in terms

of resource blocks

Number of symbols defines size of selected allocation in terms

of OFDM symbols

Offset RB defines start resource block of selected

1 to "total number of RBs"

1 to "number of OFDM symbols per sub-

frame"

0 to (“total number of RBs" – 1) allocation Note: This value is read-only if Auto mode is activated for selected allocation.

Offset symbol defines start OFDM symbol of allocation 0 to ("number of OFDM symbols per

subframe" – 1)

Number of bits shows size of selected allocation in bits Data source determines data source of selected

allocation Note: Data sources for users 0 to 3 can be

user 0, user 1, user 2, user 3, PN9, PN11,

PN15, …, PN 23, DList, pattern, all 0, all 1

configured in the Configure User panel.

Power determines power of selected allocation –80 dB to +10 dB

Content type determines type of selected allocation

Note: SCH and BCH will be set

data, L1/L2 CCH

automatically in line with the General E-UTRA DL Settings menu.

Conflict display if an allocation collides with another allocation

Note: If a resource conflict between a data allocation and a control channel occurs, the control channel wins, and no conflict is displayed here.

Configure user

The Configure User dialog offers the possibility to define and configure up to

4 scheduled UEs that can be distributed as required over the whole frame by setting the data source of a specific allocation in the allocation table to User. Thus, subframe allocations that are not adjacent or allocations of a different subframe can be configured to allow the use of a common data source.

TTI determines the transport time interval in

1 subframe subframes of the user currently being configured

Channel coding determines the channel coding scheme of

the user currently being configured

TC (turbo coding)/OFF

Note: Turbo coder is not supported in this version.

Data source determines the data source of the user

currently being configured

Configure dummy data

PN9, PN11, PN15, …, PN 23, DList,

pattern, all 0, all 1

Dummy data modulation determines modulation of dummy data QPSK, 16QAM, 64QAM Dummy data data source determines data source of dummy data PN9, PN11, PN15, …, PN 23, DList,

pattern, all 0, all 1

Dummy data power determines power of dummy data

allocations

–80 dB to +10 dB

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

XM RADIO digital standard (R&S®SMJ-K56 option)

XM RADIO digital standard in line with DARS-FHG-FDSC-608-110000

edition 03/revision 01 for satellite physical

layer and XM-SYS-0-0004-RD revision 1.2

for terrestrial physical layer

General settings

Frequency

Output level

Frequency offset Triggering

Signal path parameters for satellite physical layer

Data sources

Modulation Data rate Data generator (memory size)

standard root cosine, α = 0.15 Baseband filter other see I/Q baseband generator

Marker

Signal path parameters for terrestrial physical layer

Data sources

Modulation

Date rate Data generator (memory size)

standard in line with spectral mask Baseband filter other see I/Q baseband generator

Frequency response

–1.24 MHz < f < +1.24 MHz ±0.5 dB attenuation at 1.25 MHz carrier offset –1 dB attenuation at 1.35 MHz carrier offset –28 dB attenuation at 1.75 MHz carrier offset –35 dB attenuation at 2.25 MHz carrier offset –51 dB attenuation at 2.75 MHz carrier offset –66 dB attenuation at f > 2.75 MHz carrier offset –70 dB

Marker

default carrier frequency for selected

receiver segment

user-selectable in entire frequency range

SMJ100A

of R&S

default –30 dBm

user-selectable in entire output level range

of R&S

SMJ100A see I/Q baseband generator see I/Q baseband generator

all 0 all 1 PRBS 9, 11, 15, 16, 20, 21, 23 pattern (length 1 bit to 64 bit) data list QPSK

1.64 Msps max. 4.29 Gbit (21 minutes before repletion) with R&S

SMJ-B9

pulse pattern user period ON/OFF ratio

all 0 all 1 PRBS 9, 11, 15, 16, 20, 21, 23 pattern (length 1 bit to 64 bit) data list COFDM with 647 active carriers, each DQPSK-modulated

4.06333 Mbps max. 4.29 Gbit (17 minutes before repletion) with R&S

SMJ-B9

TPL frame MCM symbol user period ON/OFF ratio

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Multicarrier CW signal generation (R&S®SMJ-K61 option)

Signal generation simulation of unmodulated multicarrier signals in arbitrary waveform mode Number of carriers 1 to 8192 Carrier spacing user-settable, maximum spacing

depending on number of carriers

Parameters of each carrier

Crest factor

Trigger

Marker

state ON/OFF power –80 dB to 0 dB start phase 0° to +360° optimization of crest factor by varying the start phases of the carrier; available modes:

OFF number optimization, manual entry of

chirp the phases of each carrier are set such

target crest iterative variation of carrier start phases

operating mode internal, external modes Auto, Retrig, Armed Auto, Armed Retrig setting uncertainty for clock phase related to trigger in internal clock mode external trigger delay

setting range 0 sample to 2 resolution

internal clock mode 0.01 sample external clock mode 1 sample

setting uncertainty <5 ns

external trigger inhibit

setting range 0 sample to 226 sample

resolution 1 sample external trigger pulse width >15 ns external trigger frequency <0.02 × sampling rate number 4 level LVTTL operating modes unchanged, restart, pulse, pattern, ratio marker delay (in sample)

setting range 0 to (waveform length − 1)

setting range without recalculation 0 to 2000

resolution of setting 0.001

setting uncertainty <10 ns up to 10 MHz <1.5 dB, typ 0.7 dB RF frequency response up to 40 MHz <4.5 dB, typ. 2.0 dB up to 10 MHz >50 dB, typ. 56 dB Suppression of unwanted carriers up to 40 MHz >40 dB, typ. 50 dB

1 Hz to 80 MHz

phase possible

that a chirp signal is obtained for the I and Q components

until a presettable crest factor is attained

<18 ns

sample

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Example of multicarrier CW with different carrier power and some carriers switched off (left side of spectrum)

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Digital standards with R&S®WinIQSIM2™

(for R&S

GSM/EDGE digital standard R&S 3GPP FDD digital standard R&S®SMJ-K242 option 3GPP FDD enhanced BS/MS tests including HSDPA GPS digital standard R&S®SMJ-K244 option 3GPP FDD enhanced BS/MS tests including HSUPA CDMA2000® digital standard R&S®SMJ-K246 option IEEE 802.11 a/b/g digital standard R&S®SMJ-K248 option IEEE 802.16 WiMAX digital standard including 802.16e TD-SCDMA (3GPP TDD LCR) digital standard TD-SCDMA (3GPP TDD LCR) enhanced BS/MS tests including HSDPA DVB-H digital standard R&S®SMJ-K252 option EUTRA/LTE digital standard R&S®SMJ-K255 option XM RADIO digital standard R&S®SMJ-K256 option Multicarrier CW signal generation R&S®SMJ-K261 option Additive white Gaussian noise (AWGN) R&S®SMJ-K262 option

The options are described in the R&S

SMJ-B9/-B10/-B11/-B50/-B51 ARB)

SMJ-K240 option

R&S®SMJ-K243 option

R&S®SMJ-K245 option

R&S®SMJ-K249 option

R&S®SMJ-K250 option

R&S®SMJ-K251 option

WinIQSIM2™ data sheet (PD 5213.7460.22).

Digital standards with R&S®WinIQSIM™

(for R&S

IS-95 digital standard R&S CDMA2000® digital standard R&S®SMJ-K12 option 3GPP TDD HDR digital standard R&S®SMJ-K13 option 3GPP TDD LDR digital standard (TD-SCDMA) OFDM with WinIQOFDM R&S®SMJ-K15 option 1xEV-DO digital standard R&S®SMJ-K17 option IEEE 802.11 a/b/g digital standard R&S®SMJ-K19 option 3GPP FDD digital standard incl. HSDPA R&S®SMJ-K20 option

The options are described in the R&S

SMJ-B9/-B10/-B11/-B50/-B51 ARB)

SMJ-K11 option

R&S®SMJ-K14 option

WinIQSIM™ data sheet (PD 0758.0680.32).

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Noise generation

Additive white Gaussian noise (AWGN, R&S®SMJ-K62 option)

The R&S®SMJ-B13 baseband main module must be installed.

Addition of an AWGN signal of settable bandwidth and settable C/N ratio or E a frequency offset cannot be added to the wanted signal.

to a wanted signal. If the noise generator is used,

b/N0

Noise

C/N, Eb/N0

System bandwidth

distribution density Gaussian, statistical, separate for I and Q crest factor >18 dB periodicity >48 h setting range −30 dB to +30 dB

resolution 0.1 dB uncertainty for system bandwidth = symbol

rate, symbol rate <4 MHz, –24 dB < C/N <30 dB and crest factor <12 dB bandwidth for determining noise power

range 1 kHz to 80 MHz

resolution 100 Hz

<0.1 dB

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Other options

Bluetooth® digital standard (external PC software, R&S®SMJ-K5 option)

An R&S®SMJ-B9, R&S®SMJ-B10, or R&S®SMJ-B11 I/Q baseband generator must be installed.

Supported packet types DH1, DH3, DH5, AUX1

in all data mode or with packet editor Data sources (in all data mode) all 0, all 1, PRBS 7 to PRBS 23, user data Data whitening supported Packet editor features

Sequence length up to 53687 packets Power ramping

Modulation

access code calculated from entered device address header bits

HEC calculated automatically payload data sources all 0, all 1, PRBS 7 to 23, pattern,

payload CRC calculated automatically

ramp function cos2, linear ramp time 1 symbol to 32 symbol rise offset, fall offset 0 symbol to 32 symbol defaults preset in line with Bluetooth® standard

2FSK frequency deviation 100 kHz to 200 kHz 2FSK symbol rate 400 Hz to 15 MHz filter function Gaussian, rectangle Filter B × T (for Gaussian filter) 0.1 to 2.5

can be set individually, SEQN bit toggles

with each generated packet

user data

2FSK, 160 kHz deviation,

1 MHz symbol rate

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Pulse sequencer (external PC software, R&S®SMJ-K6 option)

The pulse sequencer software generates complex pulses and bursts for use with any of the R&S®SMJ-B9/-B10/-B11/-B50/-B51 baseband generators. This software is a standalone, PC-based application that creates waveform files.

Typical applications

Data structure of project files

Pulse timing parameters

Intrapulse modulation

Marker settings markers 1 to 4 delay, rise, pulse ON, fall, OFF, restart Jitter

Baseband filter

Sequences

Multisegment waveforms sequence entries in MSW up to 64

Graphical display

DFS pulse generation

RFID signal generation ISO/IEC 14443, 18000 radar waveform generation receiver tests component test with pulsed signals amplifiers, mixers, converters pulse library up to 256 pulse definitions sequence library up to 64 sequences multisegment waveforms up to 64 RF lists up to 12 settings delay, rise, pulse ON, fall, pulse OFF, PRI,

resolution 1 ns or 1/ARB clock rate, whichever is

minimum pulse width, internal BB 175 ns (7th harmonic, 40 MHz bandwidth ) minimum pulse width, external wideband I/Q settings attenuation, droop Pulse level parameters ON/OFF ratio >55 dB without pulse modulator

ramp type linear, raised cosine, cos2, custom Other pulse parameters frequency frequency offset, start phase types ASK, FSK, BPSK, QPSK, FM chirp, FM,

data sources user data,

distribution uniform, Gaussian, list, shape number of jitters up to 3, independent affected parameters any timing setting, frequency offset,

filter function rectangular, Gaussian, cosine, root raised

window functions Rife Vincent 2, von Hann, Hamming,

pulse entries in sequence up to 128 pulse data mode append, overlay add, overlay multiply jitter mode versus repetitions all individual, all same, continue, OFF marker mask versus repetitions all, first only, last only, none

number of list entries up to 10000 RF List mode data sources import, all same, uniform, unique I/Q versus time I/Q traces, polar, envelope in dB I/Q plane vector, density plot FFT entire data, view port only cursors t1, t2, Δt, Δf

FCC CFR 47 part 15.407 (06-96A)

ETSI EN 301 893 V1.3.1

PRF

greater

70 ns (7th harmonic, 100 MHz bandwidth)

>70 dB with pulse modulator

AM, user plug-in (custom)

PRBS: 7, 9, 11, 15, 16, 20, 21, 23

phase, all level settings, FM deviation

cosine

Blackman, Blackman-Harris, Flat Top

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

TETRA digital standard (external PC software, R&S®SMJ-K8 option)

An R&S®SMJ-B9, R&S®SMJ -B10, or R&S®SMJ-B11 I/Q baseband generator must be installed.

TETRA digital standard in line with ETS300-392/ETS300-394

standard

Function

R&S®SMJ-K8 R&S®SMJ-K8 is a PC-based software package for generating TETRA T1, T2, or T3 test

signals in line with ETS300-392/ETS300-394. The T1 test signal is generated for the v+d (voice and data) test on MS and BS DUTs; it is designed for putting RF components into operation and supporting ETS300 394-1 tests. The R&S generates all data sequences including all control sequences required to operate the signal generator.

Interfaces R&S®SMJ-K8 software calculates the appropriate TETRA T1 signal and transfers it to

the R&S Additionally, the R&S or R&S

SMJ100A via the GPIB or LAN interface.

SMATE200A signal generator simultaneously for generating a TETRA T2 or T3

SMJ-K8 can operate a second R&S®SMJ100A, R&S®SMU200A,

signal (TETRA T1, T2, T3, T1 and T2 or T1 and T3)-

General settings

Frequency user-selectable in entire frequency range

of R&S

SMJ

the TETRA frequency can be set by

means of frequency band, main carrier

number, offset, duplex spacing, and

reverse operation Output level user-selectable in entire output level range

Channel coding

of R&S

SMJ

channel coding is performed for all

channels; scrambling with base color

code, mobile country code and mobile

network code can be set separately for

each channel Modulation π/4-DQPSK (2 bit per symbol) Baseband filter TETRA filter Symbol rate 18000 symbol/s Marker slot(s), frame(s), multiframe(s),

hyperframe(s) Triggering see I/Q baseband generator

TETRA specific settings

downlink 0 to 4, 15, 17 Channels uplink 7 to 11, 16, 18

Burst type control burst (CB), normal burst (NB),

synchronization burst (SB) Channel types AACH, BSCH, BNCH, TCH, STCH or SCH Data the bit stream can be generated either

from pseudo-random sequences (CCITT

O.153) or from user-selectable sequences Sequence length 1 multiframe to 511 multiframes TETRA T1 the T1 test signal is generated for the v+d

(voice and data) test on MS and BS

SMJ-K8

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

BER measurement (R&S®SMJ-K80 option)

The data supplied by the DUT is compared with a reference pseudo-random bit sequence.

Clock supplied by DUT; a clock pulse is required

for each valid bit Clock rate 100 Hz to 60 MHz Data

Synchronization time 28 clock cycles Interface 9-pin D-Sub connector, D-Sub/BNC cable supplied with option Clock, data, enable, and restart inputs

Polarity data, clock, data enable normal, inverted Measurement time selectable through maximum number of

Measurement result if selected number of data bits or bit errors

Status displays not synchronized, no clock, no data

PRBS

sequence length 9, 11, 15, 16, 20, 21, 23 pattern ignore OFF, all 0, all 1 data enable external

modes OFF, high, low restart external

modes ON/OFF

input impedance 1 kΩ, 50 Ω trigger threshold

setting range 0 V to 2.50 V

resolution 0.01 V

data bits or bit errors (max. 2 continuous measurement BER in ppm, %, or decade values

is attained

bit each),

BLER measurement (R&S®SMJ-K80 option)

In BLER measurement mode, arbitrary data can be provided by the DUT. A signal marking the block’s CRC has to be provided on the data enable connector of the BER/BLER option.

Clock supplied by DUT; a clock pulse is required

for each valid bit Clock rate 100 Hz to 60 MHz Data

Synchronization time 1 block Interface 9-pin D-Sub connector, D-Sub/BNC cable supplied with option Clock, data, and enable inputs

Polarity data, clock, data enable normal, inverted Measurement time selectable through maximum number of received blocks or errors (max. 231 blocks

Measurement result if selected number of received blocks or

Status displays not synchronized, no clock, no data

input data arbitrary data enable (marking the block’s CRC) external

modes high, low CRC type CCITT CRC16 (x16 + x12 + x5 + 1) CRC CRC bit order MSB first, LSB first

input impedance 1 kΩ, 50 Ω trigger threshold

setting range 0 V to 2.50 V

resolution 0.01 V

each), continuous measurement

BLER in ppm, %, or decade values

errors is attained

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

General data

Remote control

Systems IEC/IEEE bus, IEC 60625 (IEEE 488)

Ethernet Command set SCPI 1999.5 Connector

IEC/IEEE 24-contact Amphenol

Ethernet Western IEC/IEEE bus address 0 to 30 Interface functions IEC: SH1, AH1, T6, L4, SR1, RL1, PP1,

DC1, DT1, C0

Operating data

Power supply

EMC in line with EN 55011 class B, EN 61326 Immunity to interfering field strength up to 10 V/m Environmental conditions

Mechanical resistance Vibration sinusoidal 5 Hz to 150 Hz,

random 10 Hz to 300 Hz, acceleration 1.2 g (rms),

Shock in line with EN 60068-2-27

Electrical safety in line with EN 61010-1 Dimensions width × height × depth 435 mm × 192 mm × 460 mm

Weight if fully equipped 18 kg (39.7 lb) Recommended calibration interval 3 years

input voltage range, AC, nominal 100 V to 240 V AC supply frequency 47 Hz to 63 Hz input current 5.0 A to 1.6 A power factor correction in line with EN 61000-3-2

operating temperature range +5 °C to +45 °C

in line with EN 60068-2-1,

EN 60068-2-2 storage temperature range −20 °C to +60 °C climatic resistance

+40 °C/90 % rel. humidity

in line with EN 60068-2-3

max. 2 g at 55 Hz,

55 Hz to 150 Hz,

0.5 g const.,

in line with EN 60068-2-6

in line with EN 60068-2-64

MIL-STD-810E

40 g shock spectrum

(17.1 in × 7.6 in × 18.1 in)

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Ordering information

Designation Type Order No. Vector Signal Generator

including power cable, Quick Start Guide, and CD-ROM (with operating and service manual)

Options

100 kHz to 3 GHz R&S®SMJ-B103 1403.8502.02 100 kHz to 6 GHz R&S®SMJ-B106 1403.8702.02 FM/φM Modulator R&S®SMJ-B20 1403.9209.02

Baseband

Baseband Generator with ARB (128 Msample) and Digital Modulation (realtime) Baseband Generator with ARB (64 Msample) and Digital Modulation (realtime) Baseband Generator with ARB (16 Msample) and Digital Modulation (realtime) Baseband Main Module R&S®SMJ-B13 1403.9109.02 Differential I/Q Output R&S®SMJ-B16 1403.9409.02 Baseband Generator with ARB (64 Msample) Baseband Generator with ARB (16 Msample)

Digital modulation systems

Digital Standard GSM/EDGE R&S®SMJ-K40 1404.0305.02 Digital Standard 3GPP FDD R&S®SMJ-K42 1404.0405.02 3GPP Enhanced MS/BS Tests incl. HSDPA Digital Standard GPS R&S®SMJ-K44 1404.1401.02 3GPP FDD HSUPA R&S®SMJ-K45 1409.1816.02 Digital Standard CDMA2000® R&S®SMJ-K46 1404.0605.02 Digital Standard IEEE 802.11 (a/b/g) R&S®SMJ-K48 1404.1001.02 Digital Standard IEEE 802.16 R&S®SMJ-K49 1404.1101.02 Digital Standard TD-SCDMA R&S®SMJ-K50 1404.1660.02 TD-SCDMA Enhanced BS/MS Tests R&S®SMJ-K51 1404.1760.02 Digital Standard DVB-H R&S®SMJ-K52 1409.2106.02 Digital Standard EUTRA/LTE R&S®SMJ-K55 1409.2206.02 Digital Standard XM RADIO R&S®SMJ-K56 1404.1806.02 Multicarrier CW Signal Generation R&S®SMJ-K61 1404.0705.02

R&S®SMJ100A 1403.4507.02

R&S®SMJ-B9 1404.1501.02

R&S

SMJ-B10 1403.8902.02

SMJ-B11 1403.9009.02

R&S

R&S®SMJ-B50 1410.5505.02

R&S®SMJ-B51 1410.5605.02

R&S®SMJ-K43 1404.0505.02

The base unit can only be ordered with an R&S®SMJ-B10x frequency option.

R&S®SMJ100A Vector Signal Generator Version 04.00, May 2007

Digital modulation systems using R&S®WinIQSIM2™ 11

Digital Standard GSM/EDGE R&S®SMJ-K240 1404.0510.02 Digital Standard 3GPP FDD R&S®SMJ-K242 1404.0610.02 3GPP Enhanced MS/BS Tests incl.

R&S®SMJ-K243 1404.0710.02

HSDPA Digital Standard GPS R&S®SMJ-K244 1404.0810.02 3GPP FDD HSUPA R&S®SMJ-K245 1404.0910.02 Digital Standard CDMA2000®

R&S®SMJ-K246 1404.1016.02

incl. 1xEV-DV Digital Standard IEEE 802.11 (a/b/g) R&S®SMJ-K248 1404.1116.02 Digital Standard IEEE 802.16 R&S®SMJ-K249 1404.1216.02 Digital Standard TD-SCDMA R&S®SMJ-K250 1404.1316.02 TD-SCDMA Enhanced BS/MS Tests R&S®SMJ-K251 1404.1416.02 Digital Standard DVB-H R&S®SMJ-K252 1409.2406.02 Digital Standard EUTRA/LTE R&S®SMJ-K255 1409.2258.02 Digital Standard XM RADIO R&S®SMJ-K256 1409.2606.02 Multicarrier CW Signal Generation R&S®SMJ-K261 1404.1516.02

Digital modulation systems using R&S®WinIQSIM™ 11

Digital Standard IS-95

(with R&S

Digital Standard CDMA2000®

(with R&S

Digital Standard 3GPP TDD

(with R&S

Digital Standard TD-SCDMA

(with R&S

User-Defined OFDM Signals

(with R&S R&S

Digital Standard 1xEV-DO

(with R&S

Digital Standard IEEE 802.11 (a/b/g)

(with R&S Digital Standard 3GPP FDD incl. HSDPA (with R&S

WinIQSIM™)

WinIQSIM™ and

WinIQOFDM)

WinIQSIM™)

SMJ-K11 1403.9509.02

R&S

SMJ-K12 1403.9609.02

R&S

SMJ-K13 1403.9709.02

SMJ-K14 1403.9809.02

R&S

SMJ-K15 1403.9909.02

R&S

SMJ-K17 1404.0005.02

R&S

SMJ-K19 1404.0105.02

SMJ-K20 1404.0205.02

R&S

Digital modulation systems using external PC software

Digital Standard Bluetooth® R&S®SMJ-K5 1404.1301.02 Pulse Sequencer R&S®SMJ-K6 1409.2558.02 Digital Standard TETRA R&S®SMJ-K8 1409.1716.02

Noise generation Additive White Gaussian Noise (AWGN) R&S®SMJ-K62 1404.0805.02

Other options

BER/BLER Measurement R&S®SMJ-K80 1404.0905.02 Rear Connectors R&S®SMJ-B81 1403.9309.02

Recommended extras

Hardcopy manuals (in German) 1403.7458.31 Hardcopy manuals (in English, UK) 1403.7458.32 Hardcopy manuals (in English, USA) 1403.7458.39 19" Rack Adapter R&S®ZZA-411 1096.3283.00 Adapter for Telescopic Sliders R&S®ZZA-T45 1109.3774.00 BNC Adapter for AUX I/O Connector R&S®SMU-Z5 1160.4545.02 Keyboard with USB Interface

R&S®PSL-Z2 1157.6870.04 (US assignment) Mouse with USB Interface, optical R&S®PSL-Z10 1157.7060.03 External USB CD-RW Drive R&S®PSP-B6 1134.8201.22

R&S®WinIQSIM2™ requires an external PC.

Version 04.00, May 2007 R&S®SMJ100A Vector Signal Generator

Certified Quality System

ISO 9001

DQS REG. NO 1954 QM

Certified Environmental System

ISO

14001

DQS REG. NO 1954 UM

For data sheet, see PD 5213.5074.12

and www.rohde-schwarz.com

(search term: SMJ100A)

¸ is a registered trademark of Rohde & Schwarz GmbH & Co. KG · Trade names are trademarks of the owners · Printed in Germany (ch)

PD 5213.5074.22 · Version 04.00 · May 2007 · ¸SMJ100A · Data without tolerance limits is not binding · Subject to change

Europe: +49 1805 12 4242, customersupport@rohde-schwarz.com

www.rohde-schwarz.com

USA and Canada: +1-888-837-8772, customer.support@rsa.rohde-schwarz.com

Asia: +65 65 130 488, customersupport.asia@rohde-schwarz.com

Rohde and Schwarz SMJ100A Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
