R&S®SMBV100A Vector Signal Generator
Generating signals for today and tomorrow
Test & Measurement
Product Brochure | 01.00
2
R&S®SMBV100A Vector Signal Generator
At a glance
A state-of-the-art vector signal generator must be flexible and offer good signal characteristics along with an outstanding cost/benefit ratio. In all of these areas, the R&S®SMBV100A sets new standards in the mid-range class of instruments.
The R&S®SMBV100A offers excellent RF performance along with very high output level and short setting times. At the same time, the R&S®SMBV100A can be equipped with an internal baseband generator to allow generation of a number of digital standards (e.g. WiMAX, HSPA+, LTE). The wide frequency range from 9 kHz to 6 GHz covers all of the important bands for digital modulation.
Due to its optimal scalability, the R&S®SMBV100A is easy to customize to meet specific customer requirements. For production applications, a cost-effective solution for play­ing back predefined test sequences is available with the optional baseband arbitrary waveform generator (ARB). And where it really matters, the optional baseband coder provides impressive realtime capabilities. It allows the gen­eration of even complex signals directly in the instrument – no external signal generation software is required.
The R&S®SMBV100A has also been designed for ease of servicing. Together with its scalability, this helps to ensure very low cost of ownership. The instrument’s compact size and graphical user interface for intuitive operation help to fulfill all possible requirements.
J
Internal signal generation for all major digital radio stan­dards with optional integrated baseband source
J
Highest output level in its class up to 6 GHz, combined with excellent RF characteristics
J
Lowest cost of ownership due to outstanding price/ performance ratio and on-site service capabilities
J
Ideal adaptation to customer applications
These features make the R&S®SMBV100A ideal in devel­opment applications as well as in production and service. This instrument truly does the job wherever signals with digital modulation are needed.
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 3
R&S®SMBV100A Vector Signal Generator
Benefits and key features
Support for all important state-of-the-art digital standards
J
Straightforward signal conguration due to easy-to-use
GUI
J
2G/3G/LTE mobile radio standards Wireless standards including mobile WiMAX and J WLAN IEEE 802.11n
Page 8
High-performance RF for all types of applications
J
Excellent phase noise ensures low EVM with digital signals
J
High output level compensates for losses in test/system setup
J
Fast settling time for quicker measurements Analog modulation for basic measurements J
Page 10
Flexible signal processing and baseband connectivity
J
CW interference and AWGN simulation Analog and digital baseband outputs J Support for R&S®EX-IQ-Box digital interface adapter J
Page 12
Ready for future applications today
J
Future-proof hardware concept RF section with high output level up to 6 GHz J Wide RF signal bandwidth of up to 120 MHz with internal J signal generation
J
Maximum RF bandwidth of I/Q modulator exceeds 500 MHz
J
Always up-to-date with software upgrades
Page 4
Customized internal signal generation with optional baseband generator
J
Baseband coder with realtime capabilities for direct signal generation
J
Integrated ARB for playback of precalculated waveforms Availability of ARB-only versions with different bandwidths J Memory depth of up to 256 Msamples for long test J sequences
Page 6
Low cost of ownership due to simple service concept
J
Fast on-site servicing Long calibration interval (three years) minimizes service J costs
J
Straightforward modular design for short repair times
Page 13
Allrounder and specialist at the same time
J
Optimized for high production throughput
Multisegment waveform mode for fast switchover between test sequences
High level repeatability ensures stable test conditions
Prepared for aerospace and defense applications J
Versatile capabilities for generating unmodulated as well as complex modulated pulses
Coupling of multiple instruments for phase-coherent RF generation
Page 14
4
Ready for future
I/Q modulator
RF section
up to 6 GHz
Up to 120 MHz RF bandwidth
I/Q test vectors from e.g. ¸WinIQSIM2
or
MATLAB
External I/Q input for more than 500 MHz RF bandwidth
TM
Digital standards
(optional) such as
LTE
WiMAX
3GPP
Baseband generator
Signal calculation and realtime encoding
(e.g. custom digital modulation) with ¸SMBV-B10
Arbitrary waveform generator (ARB)
Waveform playback with ¸SMBV-B10/-B50/-B51
Baseband section
¸SMBV100A
®
applications today
With constantly rising cost pressures, investments made today must also be able to meet future re­quirements. The R&S®SMBV100A was developed to satisfy this objective and is setting new standards for this class of instrument.
Key features
Frequency range 9 kHz to 3.2 GHz or 6 GHz
Level range typ. –120 dBm to +24 dBm
Customized instrument configuration
Internal signal generation for various standards (optional)
Internal bandwidth up to 120 MHz in RF range
External bandwidth >500 MHz in RF range
– suitable for UWB
Future-proof hardware concept
The R&S®SMBV100A vector signal generator benefits from a carefully planned instrument concept. Depending on the configuration, the instrument can function as a pure I/Q upconverter, a cost-effective signal generator with inte­grated ARB or an advanced vector signal generator with internal signal generation and realtime capabilities. The in­strument concept allows the signal generator to be adapt­ed to the individual task at hand, thereby reducing the investment required. At the same time, the performance of the individual hardware components provides ample ca­pacity for future applications as well.
RF section with high output level up to 6 GHz
The R&S®SMBV100A is available with options for a maxi­mum frequency of 3.2 GHz or 6 GHz, covering all major frequency bands for wireless communications and other radio applications.
The standard electronic attenuator with integrated over­voltage protection ensures dependable operation of the R&S®SMBV100A – even in challenging production environ­ments. The maximum output level is typ. +24 dBm over the entire frequency range above 1 MHz.
Instrument overview
Wide RF signal bandwidth of up to 120 MHz with
Center
4.488 GHz
Span
1 GHz
100 MHz/
-90
-80
-70
-60
-50
-40
internal signal generation
The wide R&S®SMBV100A RF bandwidth extending up to 120 MHz with internal signal generation is more than adequate for the latest broadband digital standards such as LTE and WiMAX. This bandwidth also offers ample ca­pacity for future standards. Since it is easy to import test signals you create on your own, e.g. with MATLAB®, the R&S®SMBV100A is well prepared to generate the signals you will also need in the future.
Frequency response of the I/Q modulator with bandwidth of over 500 MHz
R&S®SMBV100A and R&S®AFQ100B
Maximum RF bandwidth of I/Q modulator exceeds 500 MHz
The integrated I/Q modulator provides a maximum RF bandwidth of over 500 MHz for externally supplied I/Q sig­nals. For example, this wide bandwidth allows upconver­sion of UWB signals, which can be generated as I/Q sig­nals by the R&S®AFQ100B baseband signal generator. This wide bandwidth is also available for use with frequency agility or steep-edged pulse modulation with a flexible ex­ternal I/Q source such as the R&S®AFQ100B.
Always up-to-date with software upgrades
The powerful baseband generator is already prepared to handle future applications. The flexible software architec­ture allows the integration of new standards and extension of existing standards based on simple software updates, requiring no investment in new hardware.
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 5
6
Customized internal
The one aspect that truly makes the R&S®SMBV100A stand out is its optional baseband generator, which is available in three different versions for different applications:
signal generation with optional baseband generator
Key features
Internal signal generation (optional)
Choice of three different baseband generators (internal signal generation with realtime capabilities or two ARB-only versions)
ARB with 32 Msamples, extendable up to 256 Msamples
ARB supported by R&S®WinIQSIM2™
Easy interaction with MATLAB®
Optional 80 Gbyte mass memory for storage of signals
Version Option Baseband
generator
1 R&S®SMBV-B10 Baseband coder with
realtime capabilities and ARB (32 Msample or 256 Msample)
2 R&S®SMBV-B50 ARB only (32 Msample
or 256 Msample)
3 R&S®SMBV-B51 ARB only (32 Msample
or 256 Msample)
Baseband coder with realtime capabilities for direct signal generation
The most powerful baseband generator (R&S®SMBV-B10) includes an integrated arbitrary waveform generator as well as a baseband coder that allows signal generation directly in the instrument. Besides realtime generation of signals for user-configurable digital modulation, a multi­tude of digital standards such as HSPA+, LTE, WLAN and WiMAX are also supported (option). All signal parameters are configured directly on the instrument. Even complex signals can be generated with only a few keystrokes. Mul­ticarrier test scenarios can also be defined on the instru­ment itself no matter whether working with different or the same digital standards. Multicarrier power amplifier (MCPA) tests and interoperability tests are very easy to perform.
RF bandwidth
120 MHz
120 MHz
60 MHz
The R&S®SMBV-B10 baseband generator thus totally elimi­nates the need to generate test signals using an external computer and transfer them to the vector signal generator. This is especially beneficial in a development environment where fast, easy access to signal parameters is critical during both manual operation and remote operation. This helps to speed up the work flow and minimize develop­ment time.
The realtime coder also enables the user to generate test sequences with a theoretically infinite length, e.g. with simple digitally modulated signals or internally generated digital standards such as 3GPP FDD (downlink) and GSM. This makes bit error rate tests reliable in cases where a sufficiently long test sequence is needed for statistical as­sessment.
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 7
Integrated ARB for playback of precalculated waveforms
Precalculated test sequences are common especially in production environments. The R&S®SMBV100A is also well equipped in this area: All three versions of the baseband generator are capable of playing back precalculated wave­forms. When it comes to generating standard-compliant signals, the external R&S®WinIQSIM2™ waveform genera­tion software is also available. It supports standards such as LTE, HSPA+ and WiMAX. Proprietary signals and spe­cial test vectors (e.g. generated using MATLAB®) can also be played back from the integrated ARB with no problem. The two ARB-only versions (R&S®SMBV-B50/-B51) are rec­ommended in all instances where a cost-saving solution is needed and there is no need to set signal parameters di­rectly on the instrument.
Memory depth of up to 256 Msamples for long test sequences
The ARB memory can be extended from the standard size of 32 Msamples to 256 Msamples. This makes it possible to play back long test sequences for realistic measure­ments on DUTs.
A dream team: R&S®SMBV100A and R&S®FSV for generating and
analyzing digitally modulated signals
If the optional mass memory (R&S®SMBV-B92) is installed in the R&S®SMBV100A, it is easy to save test sequences in the instrument and recall them for later use without hav­ing to retransfer them. This speeds up manual tests and is of course also useful in production applications where numerous test sequences typically must be kept ready for use.
8
Support for all important state-of-the-art
Straightforward signal configuration due to easy-to­use GUI
During internal signal generation, the R&S®SMBV100A of­fers clear benefits due to its straightforward display and graphical user interface. The signal generator allows intui­tive operation via the block diagram. The context-sensitive help system assists users during everyday work, e.g. when information is needed about individual parameters in the digital standards.
digital standards
With its internal baseband coder (R&S®SMBV-B10), the R&S®SMBV100A optionally allows users to gen­erate all major digital communications standards – and without needing any external signal genera­tion software. Alternatively, waveforms can be gen­erated for the digital standards using the external R&S®WinIQSIM2™ software. Besides applying pre­defined test signals, users also have free access to individual signal parameters. Users can thus gener­ate standard-compliant cellular or wireless signals.
2G/3G/LTE mobile radio standards
Signals used in second- and third-generation mobile ra­dio are as easy to generate with the R&S®SMBV100A as broadband LTE signals.
GSM/EDGE
J
Framed and unframed signals Realtime signal generation (with R&S®SMBV-K40 only) J Up to eight time slots with different modulation formats, J training sequences and power levels
J
All important burst types supported
CDMA2000®1)/1×EV-DO
Conguration of up to four base stations or four mobile
J
stations
J
Downlink CDMA2000® signal generation including all special channels, up to 78 user channels
J
Operating modes “Trafc”, “Access”, “Enhanced Access” and “Common Control” on the CDMA2000®
uplink
J
Channel coding 1×EV-DO physical layer subtypes 0&1 or 2 supported J
GUI of the R&S®SMBV100A showing the large variety of internally
available digital standards (option)
1)
CDMA2000® is a registered trademark of the Telecommunications Industry
Association (TIA - USA).
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 9
3GPP FDD/HSDPA/HSUPA/HSPA+
Support of all physical channels of 3GPP FDD, HSDPA,
J
HSUPA and HSPA+
J
HSDPA H-sets 1 to 10 with channel coding plus user-
denable H-sets
J
HSUPA xed reference channels with channel coding
Realtime generation of P-CCPCH and up to three DPCHs J in downlink (with R&S®SMBV-K42 only)
J
One UE in realtime in uplink (with R&S®SMBV-K42 only), up to 67 additional mobile stations via ARB
J
MIMO and transmit diversity coding
EUTRA/LTE
Physical layer modes OFDMA and SC-FDMA for down-
J
link and uplink supported
J
Supported physical channels include P-SYNC/S-SYNC, PDSCH, PBCH, PCFICH, PHICH, PDCCH, PUSCH and PUCCH
J
MIMO and transmit diversity coding Channel coding J
Wireless standards including mobile WiMAX and WLAN IEEE 802.11n
The trend toward higher and higher data rates is raising the test requirements placed even on wireless systems. Here too, the R&S®SMBV100A provides all test signals needed.
WiMAX IEEE 802.16
J
Support for xed and mobile WiMAX
Physical layer modes: OFDM, OFDMA, OFDMA/WiBro J Burst types including FCH, DL-MAP, UL-MAP, DCD, UCD, J HARQ, ranging, fast feedback, data
J
Multiple zones and segments (e.g. PUSC, FUSC, AMC, sounding)
J
Diversity and MIMO coding (DL, UL)
WLAN IEE 802.11
Signal generation in line with IEEE 802.11a/b/g/n
J
PDCC, CCK and OFDM modulation J Bandwidths of up to 40 MHz supported J Channel coding J
Legacy, Mixed and Greeneld modes as well as MIMO J
coding for IEEE 802.11n
Graphical display of settings for digital standards, e.g. EUTRA/LTE
Additional information
For detailed information on all supported digital standards, please refer to the digital standards data sheet (PB 5213.9434.22) available on the Rohde & Schwarz website (www.rohde-schwarz.com).
10
High-performance
1 MHz 10 MHz10 kHz1 kHz 100 kHz10 Hz1 Hz 100 Hz
–160
–140
–120
–100
–80
–60
–40
–150
–130
–110
–90
–70
–50
–30
–20
Frequency
SSB phase noise dBc/Hz
6 GHz
3 GHz
1 GHz
100 MHz
10 MHz
0 654321
20
30
29
28
27
26
25
24
23
22
21
RF/GHz
Level/dBm
I/Q
CW
RF for all types of applications
Excellent phase noise ensures low EVM with digital signals
SSB phase noise is a key parameter when it comes to RF generator signal quality. This parameter is important not only in CW applications, but also particularly with digital signals. It has a direct influence on the error vector magni­tude (EVM) of digital signals, which is an important param­eter especially with today’s OFDM-based communications systems such as WiMAX and LTE.
A well-designed RF unit provides a solid basis for fast, clean digital signal generation. This is neces­sary to allow reproducible measurements with the digital signals used in development and production environments.
The good signal characteristics provided by the R&S®SMBV100A also include excellent figures for nonhar­monics, which are important when making interference measurements.
High output level compensates for losses in test/ system setup
Test signals not only need to be pure; they must have suf­ficient power levels as well. This becomes obvious par­ticularly when working with more complex systems in which the actual test setup (cables, switches, couplers, etc.) introduces losses between the generator and DUT. The R&S®SMBV100A can easily compensate for such losses with its high output power. With a specified output power of greater than +18 dBm (PEP) and typically even +24 dBm over a wide frequency range of 1 MHz to 6 GHz, the instrument delivers unparalleled performance in the mid-range class. This eliminates the need for external am­plifiers, which not only drive up costs but also increase the system’s level uncertainty.
Measured SSB phase noise with internal OCXO (R&S®SMBV-B1 option)
Measured maximum output power vs. frequency
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 11
Fast settling time for quicker measurements
0 54.543.532.521.510.5
0
10000
9000
8000
7000
6000
5000
4000
3000
2000
1000
Setting time/ms
Occurrence
ALC = on
ALC = Table
ALC = Sample & Hold
List mode
In production as well as in module characterization, nu­merous test points in the frequency and level domain are scanned. However, scans of this sort are only as fast as the slowest element in the chain. The R&S®SMBV100A makes a solid contribution with switching times of less than 1 ms in the standard List mode, thus helping to reduce the test time. This speeds up tests in development and helps to achieve throughput objectives in production at minimum costs.
Analog modulation for basic measurements
Analog modulation modes are also required in order to make the R&S®SMBV100A an all-purpose generator. This is why amplitude, frequency and phase modulation are all standard features. The R&S®SMBV100A also offers an inter­nal LF source that can be used as a modulation generator.
The analog modulation capabilities can be enhanced even further with an optional pulse modulator and generator that offers an impressive rise/fall time of typically only 4 ns and a maximum on/off ratio of typically 90 dB.
Key features
Low SSB phase noise typ. –128 dBc (1Hz) at 1 GHz
Very low nonharmonics typ. –85 dBc up to 1.5 GHz
Maximum output power typ. +24 dBm
Fast frequency changes <1 ms in List mode
Standard modulation modes AM, FM, φM
Pulse modulation optional
Histogram of measured level setting times in I/Q mode
Flexible signal
–100
–110
–30
–40
–50
–60
–70
–80
–90
–20
–10
Center 2.14 GHz 5 MHz/ Span 50 MHz
–100
–110
–30
–40
–50
–60
–70
–80
–90
–20
–10
Center 2.14 GHz 5 MHz/ Span 50 MHz
–100
–110
–30
–40
–50
–60
–70
–80
–90
–20
–10
Center 2.14 GHz 5 MHz/ Span 50 MHz
processing and baseband connectivity
Key features
Realistic scenarios with AWGN or CW interferer simulation
Flexible baseband outputs
Support for R&S®EX-IQ-Box digital interface adapter
CW interference and AWGN simulation
The baseband section can also be enhanced with an op­tion for additive white Gaussian noise (AWGN), which per­mits realistic tests involving noisy signals.
The Noise Only and CW Interferer modes extend the gen­erator’s range of applications. In the Noise Only mode, the R&S®SMBV100A behaves like a defined noise source with adjustable bandwidth and level. The CW Interferer mode allows the internal addition of a CW carrier to the wanted signal, eliminating the need for an additional signal gen­erator. This function is very useful for measuring adjacent channel suppression on receivers.
Analog and digital baseband outputs
To extend the range of applications of the optional inter­nal baseband generators, they have analog differential I/Q outputs as a standard feature. This means that the R&S®SMBV100A can test the baseband section as well as the RF input of a DUT via its analog interface.
Support for R&S®EX-IQ-Box digital interface adapter
The baseband interface also offers an optional digi-
1)
tal signal output
that operates together with the R&S®EX-IQ-Box. The R&S®EX-IQ-Box makes adaptation to the device under test an easy task because it supports numerous common digital formats. The R&S®EX-IQ-Box is conveniently operated via the user interface of the R&S®SMBV100A.
Superposition of LTE signal with AWGN
12
1)
Available star ting in Januar y 2009 (enabled via software).
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 13
Low cost of owner­ship due to simple service concept
Key features
Choice between on-site service and Rohde & Schwarz service center
Long calibration interval of three years
Modular design allows fast repairs
Fast on-site servicing
The R&S®SMBV100A has been designed for maximum de­pendability and easy servicing. This helps to maximize up­time in a wide variety of applications, which in turn means lower cost of ownership for the customer.
In addition, customers can choose between calibrating or repairing the instrument themselves or having a certified Rohde & Schwarz service center do the work. This helps customers to minimize downtime and to return the instru­ment to operation again as fast as possible. This is espe­cially critical in production applications.
Long calibration interval (three years) minimizes service costs
Due to the stability of the components and modules that are used, the recommended calibration interval is three years. This minimizes the frequency of servicing, helping to save costs and ensure maximum uptime for the instru­ment.
Straightforward modular design for short repair times
In cases where repairs are actually necessary, internal er­ror diagnostics help to pinpoint the problem. The design uses a minimum number of modules to simplify and speed up the exchange process. Since all modules have already been fully adjusted, a brief functional check is all that is necessary in order to restore the outstanding characteris­tics of the R&S®SMBV100A. If you also use a power sen­sor such as the R&S®NRP-Z92 to perform a new power level adjustment for the entire instrument, you can further increase the level accuracy.
Allrounder and
Waveform 2
Waveform 1
Waveform 3
Resulting waveform in output RAM
Segment 1 Segment 2
Segment 3
Output signal
Automatic repetition of partial waveform
Segment switching by ¸SMBV100A user interface, IEC/IEEE bus, external trigger line
specialist at the same time
Key features
Short switching times of <1 ms in List mode
Multisegment waveform mode for fast switchover between test sequences
High level repeatability ensures stable test conditions
High output power allows substitution of additional power amplifiers
Optimized for high production throughput
Several characteristics are important for achieving high throughput in production. The fast frequency and level switching times provided by the R&S®SMBV100A (<1 ms in List mode) provide a solid foundation. How­ever, to allow fast switching of digital signals as well, the R&S®SMBV100A supports the multisegment waveform (MSW) mode. The MSW mode makes it possible to switch between multiple test sequences that are kept stored in memory simultaneously. Switching is controlled based on a user-specified schedule or by external triggering. With a memory depth of up to 256 Msamples, it is possible to switch between a number of different signals without having to waste time loading the data. Typical switching times are a brief 5 µs at a clock rate of 50 MHz. This is im­portant when testing the advanced multimode modules that are used to process the different signals in GSM and 3GPP FDD.
Another important item is the level repeatability, which de­termines whether it is possible to obtain stable test condi­tions. The R&S®SMBV100A offers performance that makes it possible to set tighter measurement limits and thus in­crease the test yield.
Multisegment waveform concept
Since higher level losses typically occur in more complex production systems, the R&S®SMBV100A offers a high output power of >+18 dBm, and typically even +24 dBm over the entire frequency range above 1 MHz. This elimi­nates the need for additional amplifiers, thereby saving space and money and helping to avoid loss of level accu­racy on the DUT due to drift.
Level repeatability
14
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 15
Screenshot of the R&S®SMBV-K6
Key features
Optional pulse modulator with 90 dB on/off ratio
Support for R&S®SMBV-K6 pulse sequencer software
Optional coupling of multiple instruments for generation of phase­ coherent RF signals
Prepared for aerospace and defense applications
The R&S®SMBV100A offers two choices when it comes to generating typical pulse scenarios. The classic method uses an optional pulse generator and RF pulse modulator for a maximum on/off ratio of typically 90 dB. The other choice involves pulse generation using an I/Q modula­tor and an ARB signal for maximum flexibility in terms of pulse shapes and sequences. The optional R&S®SMBV-K6 pulse sequencer allows the easy generation of a wide range of realistic pulse sequences. With a high clock rate of up to 150 MHz, it generates pulses with steep edges while also supporting standard frequency hopping tech­niques with up to 120 MHz bandwidth.
During measurements on phased array antenna systems, the phase coherence option provides useful support. Mul­tiple generators can be coupled to a common local oscilla­tor to generate the signals needed for beamforming.
If the generator is used in a secure area, sanitizing pro­cedures help to support the clearance procedure. The optional hard disk used to store signal data can be easily removed without opening the instrument.
Rear view of the R&S®SMBV100A
16
Specifications in brief
Base unit
Frequency
Range R&S®SMBV-B103
CW mode 9 kHz to 3.2 GHz
I/Q mode 1 MHz to 3.2 GHz
R&S®SMBV-B106
CW mode 9 kHz to 6 GHz
I/Q mode 1 MHz to 6 GHz
Setting time SCPI mode, ALC state ON, CW mode <3 ms
SCPI mode, ALC state ON, I/Q mode <5 ms
SCPI mode, ALC state Table <2 ms
SCPI mode, ALC state S&H <7 ms
List mode <1 ms
Level
Maximum output power 1 MHz < f ≤ 6 GHz >+18 dBm (PEP)
Absolute level error 1 MHz < f ≤ 3 GHz <0.5 dB
Additional level error with ALC OFF, S&H This mode is used with I/Q modulation and pulse
modulation.
Output impedance VSWR in 50 Ω system 200 kHz < f ≤ 6 GHz <1.8
Setting time SCPI mode, ALC state ON, CW mode <2.5 ms
SCPI mode, ALC state ON, I/Q mode <5 ms
SCPI mode, ALC state Table <2 ms
SCPI mode, ALC state S&H <7 ms
List mode <1 ms
Reverse power 1 MHz < f ≤ 1 GHz 50 W
1 GHz < f ≤ 2 GHz 25 W
2 GHz < f ≤ 6 GHz 10 W
Spectral purity
Harmonics f > 1 MHz; CW, level ≤ 8 dBm <–30 dBc
Nonharmonics CW, level > –10 dBm, >10 kHz carrier offset,
f ≤ 1500 MHz
SSB phase noise 20 kHz carrier offset, 1 Hz measurement band-
width, CW
f = 100 MHz <–141 dBc (nominal –147 dBc)
f = 1 GHz <–122 dBc (nominal –128 dBc)
f = 6 GHz <–106 dBc (nominal –112 dBc)
Wideband noise attenuator mode AUTO
for level > 5 dBm, >10 MHz carrier offset, 1 Hz measurement bandwidth, CW
Supported analog modulation modes
Amplitude modulation standard
Frequency/phase modulation standard
Maximum FM deviation f > 3 GHz 16 MHz
Maximum φM f > 3 GHz 160 rad
Pulse modulation optional, with R&S®SMBV-K22
On/off ratio >80 dB
Rise/fall time 10 % to 90 % of RF amplitude <20 ns, typ. 4 ns
Minimum pulse width using the optional R&S®SMBV-K23 pulse
generator
<0.25 dB
<–70 dBc (nominal <–85 dBc)
<–142 dBc (nominal –152 dBc)
10 ns
2)
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 17
Base unit
I/Q modulation
Internally supported systems (with additional options)
Realtime custom digital modulation R&S®SMBV-B10 baseband generator required ASK, FSK, BPSK, QPSK, QPSK 45° offset,
I/Q modulator bandwidth internal 60 MHz or 120 MHz, depending on baseband
Maximum waveform length 32 Msamples
DAC resolution 16 bit
ACLR WCDMA 3GPP FDD, TM 1/64 typ. 67 dBc
EVM WCDMA 3GPP FDD, TM 1/64 typ. 0.6 %
Connectivity
Remote control IEC/IEEE, Ethernet (LAN), USB
Peripherals USB 2.0
2)
PEP = peak envelope power.
3)
HD Radio™ is a proprietary trademark of iBiquity Digital Corp.
R&S®SMBV-B10 baseband generator required GSM/EDGE, 3GPP FDD incl. HSPA/HSPA+,
TD-SCDMA, CDMA2000®, 1×EV-DO, EUTRA/ LTE, WiMAX, WLAN IEEE 802.11a/b/g/n, GPS, XM Radio, HD Radio™
3)
, DVB-H/DVB-T, multicar-
rier CW
OQPSK, π/4-QPSK, π/2-DBPSK, π/4-DQPSK, π/8-D8PSK, 8PSK, 8PSK EDGE, 16QAM,
32QAM, 64QAM, 256QAM, 1024QAM
option
external >500 MHz
with R&S®SMBV-B55 option 256 Msamples
WiMAX IEEE 802.16e typ. 0.4 %
EUTRA/LTE typ. 0.4 %
18
Ordering information
Designation Type Order No.
Base unit (including power cable, Quick Start Guide and CD-ROM, with operating and service manual)
Vector Signal Generator R&S®SMBV100A 1407.6004.02
Options
RF
9 kHz to 3.2 GHz R&S®SMBV-B103 1407.9603.02
9 kHz to 6 GHz R&S®SMBV-B106 1407.9703.02
Reference Oscillator OCXO R&S®SMBV-B1 1407.8407.02
Phase Coherence R&S®SMBV-B90 1407.9303.02
Pulse Modulator R&S®SMBV-K22 1415.8019.02
Pulse Generator R&S®SMBV-K23 1415.8025.02
Baseband
Baseband Generator with Digital Modulation (realtime) and ARB (32 Msample), 120 MHz RF bandwidth
R&S®SMBV-B10 1407.8607.02
Baseband Generator with ARB (32 Msample), 120 MHz RF bandwidth
Baseband Generator with ARB (32 Msample), 60 MHz RF bandwidth
Memory Extension for ARB to 256 Msample R&S®SMBV-B55 1407.9203.02
Hard Disk (removable) R&S®SMBV-B92 1407.9403.02
Digital Baseband Connectivity
Digital modulation systems
Digital Standard GSM/EDGE R&S®SMBV-K40 1415.8031.02
Digital Standard 3GPP FDD R&S®SMBV-K42 1415.8048.02
3GPP FDD Enhanced MS/BS Tests incl. HSDPA R&S®SMBV-K43 1415.8054.02
3GPP FDD HSUPA R&S®SMBV-K45 1415.8077.02
Digital Standard CDMA2000® incl. 1×EV-DV R&S®SMBV-K46 1415.8083.02
Digital Standard 1×EV-DO Rev. A R&S®SMBV-K47 1415.8090.02
Digital Standard IEEE 802.11 (a/b/g) R&S®SMBV-K48 1415.8102.02
Digital Standard IEEE 802.16 R&S®SMBV-K49 1415.8119.02
Digital Standard TD-SCDMA R&S®SMBV-K50 1415.8125.02
TD-SCDMA Enhanced BS/MS Tests R&S®SMBV-K51 1415.8131.02
Digital Standard DVB-H/DVB-T R&S®SMBV-K52 1415.8148.02
Digital Standard IEEE 802.11n R&S®SMBV-K54 1415.8160.02
Digital Standard EUTRA/LTE R&S®SMBV-K55 1415.8177.02
Digital Standard HSPA+ R&S®SMBV-K59 1415.8219.02
Multicarrier CW Signal Generation R&S®SMBV-K61 1415.8225.02
Digital modulation systems using R&S®WinIQSIM2™
Digital Standard GSM/EDGE R&S®SMBV-K240 1415.8231.02
Digital Standard 3GPP FDD R&S®SMBV-K242 1415.8248.02
3GPP FDD Enhanced MS/BS Tests incl. HSDPA R&S®SMBV-K243 1415.8254.02
Digital Standard GPS R&S®SMBV-K244 1415.8260.02
3GPP FDD HSUPA R&S®SMBV-K245 1415.8277.02
Digital Standard CDMA2000® incl. 1×EV-DV R&S®SMBV-K246 1415.8283.02
Digital Standard 1×EV-DO Rev. A R&S®SMBV-K247 1415.8290.02
Digital Standard IEEE 802.11 (a/b/g) R&S®SMBV-K248 1415.8302.02
Digital Standard IEEE 802.16 R&S®SMBV-K249 1415.8319.02
4)
3)
R&S®SMBV-B50 1407.8907.02
R&S®SMBV-B51 1407.9003.02
R&S®SMBV-K18 1415.8002.02
Rohde & Schwarz R&S®SMBV100A Vector Signal Generator 19
Designation Type Order No.
Digital Standard TD-SCDMA R&S®SMBV-K250 1415.8325.02
TD-SCDMA Enhanced BS/MS Tests R&S®SMBV-K251 1415.8331.02
Digital Standard DVB-H/DVB-T R&S®SMBV-K252 1415.8348.02
Digital Standard IEEE 802.11n R&S®SMBV-K254 1415.8354.02
Digital Standard EUTRA/LTE R&S®SMBV-K255 1415.8360.02
Digital Standard HSPA+ R&S®SMBV-K259 1415.8377.02
Multicarrier CW Signal Generation R&S®SMBV-K261 1415.8383.02
Additive White Gaussian Noise (AWGN) R&S®SMBV-K262 1415.8425.02
Digital modulation systems using an external PC software or waveforms
Pulse Sequencer
Playback of XM Radio Waveforms
5)
6)
Playback of HD Radio™ Waveforms R&S®SMBV-K352 1415.8431.02
Noise generation
Additive White Gaussian Noise (AWGN) R&S®SMBV-K62 1415.8419.02
Recommended extras
Hardcopy manuals (in English, UK) 1407.6062.32
Hardcopy manuals (in English, US) 1407.6062.39
19" Rack Adapter R&S®ZZA-S334 1109.4487.00
Power Sensor 9 kHz to 6 GHz R&S®NRP-Z92 1171.7005.02
Keyboard with USB Interface (US character set) R&S®PSL-Z2 1157.6870.04
Mouse with USB Interface, optical R&S®PSL-Z10 1157.7060.03
3)
Available starting in January 2009 (enabled via sof tware).
4)
R&S®WinIQSIM2™ requires an external PC.
5)
The pulse sequencer requires an ex ternal PC.
6)
Signal generation requires waveforms from XM Radio.
R&S®SMBV-K6 1415.8390.02
R&S®SMBV-K256 1415.8402.02
Your local Rohde & Schwarz expert will help you to find the solution that is optimally suited to your requirements and will be glad to prepare a custom offer for you. To find your nearest Rohde & Schwarz representative visit: www.sales.rohde-schwarz.com
Service you can rely on
J In 70 countries J Person-to-person J Customized and exible J Quality with a warranty J No hidden terms
About Rohde & Schwarz
Rohde & Schwarz is an independent group of companies specializing in electronics. It is a leading supplier of solu­tions in the fields of test and measurement, broadcasting, radiomonitoring and radiolocation, as well as secure com­munications. Established 75 years ago, Rohde & Schwarz has a global presence and a dedicated service network in over 70 countries. Company headquarters are in Munich, Germany.
Regional contact
Europe, Africa, Middle East +49 1805 12 42 42* or +49 89 4129 137 74 customersupport@rohde-schwarz.com North America 1-888-TEST-RSA (1-888-837-8772) customer.support@rsa.rohde-schwarz.com Latin America +1-410-910-7988 customersupport.la@rohde-schwarz.com Asia/Pacific +65 65 13 04 88 customersupport.asia@rohde-schwarz.com
Cert ied Quali ty Syste m
ISO 9001
DQS REG . NO 1954 QM
For data sheet, see
PD 5214.1114.22
and www.rohde-schwarz.com
Cert ied Envir onmental S ystem
ISO 14001
DQS REG . NO 1954 UM
Rohde & Schwarz GmbH & Co. KG
Mühldorfstraße 15 | 81671 München Phone +49 89 41 290 | Fax +49 89 41 29 121 64
www.rohde-schwarz.com
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG Trade names are trademarks of the owners | Printed in Germany (ed) PD 5214.1114.12 | Version 01.00 | August 2008 | R&S®SMBV100A Data without tolerance limits is not binding | Subject to change
*0.14 €/min within German wireline network; rates may vary in other networks (wireline and mobile) and countries.
Loading...
