¸SFE Broadcast Tester

Data sheet

Version

02.01

August

2008

Contents

INTRODUCTION ..........................................................................................................................................................................................3

OVERVIEW .................................................................................................................................................................................................3

KEY FEATURES...........................................................................................................................................................................................4

SPECIFICATIONS........................................................................................................................................................................................6

RF CHARACTERISTICS ................................................................................................................................................................................6

Frequency............................................................................................................................................................................................6

Reference frequency ...........................................................................................................................................................................6

Level ....................................................................................................................................................................................................6

Spectral purity......................................................................................................................................................................................7

I/Q MODULATION.........................................................................................................................................................................................7

I/Q modulator.......................................................................................................................................................................................7

Internal baseband I/Q ..........................................................................................................................................................................7

Extended I/Q input (R&S

DIGITAL BASEBAND.....................................................................................................................................................................................8

Internal test signals..............................................................................................................................................................................8

MPEG-2 inputs.....................................................................................................................................................................................8

TS generator (R&S TRP player (R&S

ANALOG BASEBAND ....................................................................................................................................................................................9

Analog video/audio input .....................................................................................................................................................................9

Internal audio signal generator............................................................................................................................................................9

Internal NICAM audio signal generator................................................................................................................................................9

Internal video signal generator (R&S

DIGITAL MODULATION SYSTEMS.................................................................................................................................................................11

DVB-T/H (R&S

SFE-K1 option).........................................................................................................................................................11

DVB-C/ISDB-C (R&S DVB-S/DVB-DSNG (R&S DVB-S2 (R&S

SFE-K8 option)..........................................................................................................................................................12

T-DMB/DAB (R&S ATSC/8VSB (R&S J.83/B (R&S DirecTV legacy modulation (R&S DTMB (R&S

SFE-K5 option).............................................................................................................................................................13

SFE-K12 option)...........................................................................................................................................................13

ISDB-T/ISDB-Tsb/ISDB-TB (R&S MediaFLO™ (R&S

ANALOG MODULATION SYSTEMS ................................................................................................................................................................15

AM/FM/RDS (R&S Standard B/G (R&S Standard D/K (R&S Standard I (R&S Standard M/N (R&S Standard L (R&S ATV multistandard (R&S

Internal NICAM encoder ....................................................................................................................................................................18

ARB/WAVEFORMS ....................................................................................................................................................................................19

Arbitrary waveform generator (R&S

SIMULATION .............................................................................................................................................................................................20

AWGN generator (R&S

ANALYSIS.................................................................................................................................................................................................20

BER measurements (R&S

TRIGGER INPUTS/OUTPUTS .......................................................................................................................................................................20

Triggers and connectors for future use..............................................................................................................................................20

GENERAL DATA.........................................................................................................................................................................................21

System data.......................................................................................................................................................................................21

Operating data...................................................................................................................................................................................21

ORDERING INFORMATION......................................................................................................................................................................22

SFE-K80 option).........................................................................................................................................7

SFE-K20 option)..................................................................................................................................................8

SFE-K22 option).....................................................................................................................................................8

SFE-K23 option).......................................................................................................................9

SFE-K2 option)...............................................................................................................................................11

SFE-K3 option)........................................................................................................................................11

SFE-K11 option)..................................................................................................................................................12

SFE-K4 option) ...................................................................................................................................................12

SFE-K9 option)............................................................................................................................13

SFE-K10 option).................................................................................................................................................14

SFE-K170 option)...............................................................................................................................................15

SFE-K190 option) .............................................................................................................................................16

SFE-K191 option)..............................................................................................................................................16

SFE-K192 option) ..................................................................................................................................................17

SFE-K193 option).............................................................................................................................................17

SFE-K194 option)..................................................................................................................................................18

SFE-K40 option) .........................................................................................................................................20

SFE-K6 option).............................................................................................................................14

SFE-K195 option)......................................................................................................................................18

SFE-K35 option) ......................................................................................................................19

SFE-K60 option).....................................................................................................................................20

2 R&S®SFE Broadcast Tester Version 02.01, August 2008

Introduction

The R&S®SFE is a multistandard-compatible broadcast signal generator that supports all common TV standards and a number of audio broadcasting standards. Whether analog or digital terrestrial TV, cable, satellite or mobile TV, digital and analog audio broadcasting – all these signals can be generated in realtime. For this purpose, the R&S realtime coder, and a baseband signal source in a single instrument.

Owing to its modular concept, the R&S

SFE can be optimally adapted to the specific conditions – e.g. with an integrated noise generator or a BER tester. By installing software options, the R&S new modulation modes. This can be done on-site and without having to open the instrument.

The versatile baseband signal source for digital TV standards allows the generation of test signals from Rohde & Schwarz libraries and the replay of customer-specific transport streams. For analog TV, the R&S Alternatively, both transport streams and analog A/V signals can be fed in by external baseband generators. Irrespective of the realtime coders used, an ARB waveform generator can be used to generate any modulation signal needed and to replay waveform files of the customer.

The R&S

SFE is compact and space-saving in design. It offers the same convenient graphical user interface as the high-end R&S®SFU

as well as comprehensive remote-control options.

Overview

• Broadcast multistandard platform

• Realtime signal generation for digital and analog transmission standards

• Wide frequency range with excellent signal quality

• Integrated transport stream player and video/audio generator

• Arbitrary waveform generator

• Integrated noise generator and BER tester

• Compact cabinet with convenient graphical user interface

• Digital I/Q input

SFE combines a high-performance RF modulator, a universal

SFE can quickly and easily be expanded at a later time to include

SFE offers an integrated video/audio test signal generator.

Version 02.01, August 2008 R&S®SFE Broadcast Tester 3

Key features

Broadcast multistandard platform

• Digital terrestrial TV standards: DVB-T, ISDB-T, ISDB-TB, ATSC/8VSB, DTMB (GB20600-2006)

• Cable TV standards: DVB-C/ISDB-C, J.83/B (up to 1024QAM)

• Satellite TV standards: DVB-S, DVB-S2, DirecTV

• Mobile TV standards: DVB-H, T-DMB, MediaFLO

• Analog TV standards: B/G, D/K, M, N, I, I1, and L for the PAL, SECAM, and NTSC color systems

• Audio broadcasting standards: AM/FM/RDS, DAB, DRM, ISDB-Tsb

• Open for future standards

Realtime signal generation for digital and analog transmission standards

• Universal coder for realtime signal generation

• Settable modulation parameters

• Add-on of transmission standards as software options

Wide frequency range with excellent signal quality

• RF range 100 kHz to 2.5 GHz

• SSB phase noise (at f = 300 MHz) typ. –115 dBc at 20 kHz

• Signal level (PEP) –110 dBm to +15 dBm, 100 dB dynamic range

Integrated transport stream player and video/audio generator

• TS generator

• Transport stream libraries from Rohde & Schwarz

• Compatible with the R&S

• TRP player

• ATV video generator

• ATV video library from Rohde & Schwarz

• Audio generator

DV-ASC Advanced Stream Combiner

Arbitrary waveform generator

• 256 Msample memory

• Sample rate up to 100 Msample/s

• Waveform libraries from Rohde & Schwarz

• Compatible with R&S

WinIQSIM™

Integrated noise generator and BER tester

• Broadband AWGN generator

• BER measurement at transport stream level or bit level

, ISDB-T 1-segment (partial reception)

4 R&S®SFE Broadcast Tester Version 02.01, August 2008

Compact housing with convenient graphical user interface

• Housing: ½ 19’’ × 3 height units

• Large VGA color display with 640 × 480 pixels

• Intuitive user interface under Windows XP Embedded

• Context-sensitive Help system

• User-definable favorites for fast access

• Easy software updates via LAN or USB

• Remote control with Remote Desktop or VNC

• Remote control via LAN

• Command set compatible with the R&S

SFU

Version 02.01, August 2008 R&S®SFE Broadcast Tester 5

Specifications

Specifications apply under the following conditions: 60 minutes warm-up time at ambient temperature, specified environmental conditions met, calibration cycle adhered to, and all internal automatic adjustments performed. "Typical values" are designated with the abbreviation "typ." These values are verified during the final test but are not assured by Rohde & Schwarz. "Nominal values" are design parameters that are not assured by Rohde & Schwarz. These values are verified during product development but are not specifically tested during production.

Rohde & Schwarz equipment is designed for reliable operation up to an altitude of 2000 m above sea level, and for transport up to an altitude of 4500 m above sea level.

RF characteristics

Frequency

Range 100 kHz to 2.5 GHz Uncertainty depending on reference frequency

Resolution of setting 1 Hz

Reference frequency

Uncertainty <1 × 10–6 Aging after 14 days of uninterrupted operation <2.7 × 10–9/day Temperature effect in operating temperature range

0 °C to +50 °C

Input for external reference signal frequency (sinewave)

maximum deviation input level

limits recommended input impedance connector

Output for internal reference signal frequency (sinewave)

level input impedance connector

<6 × 10–8

10 MHz

–6

3 × 10 ≥–5 dBm to ≤19 dBm 0 dBm to 19 dBm 50 Ω BNC female, rear 10 MHz typ. +6 dBm, ±3 dB 50 Ω BNC female, rear, alternative to trigger

OUT

Level

RF output connector

output impedance

Maximum level f ≤ 1 GHz

1 GHz < f ≤ 2 GHz 2 GHz < f

Setting range

resolution

Dynamic range of attenuator 110 dB Level uncertainty "auto" attenuator mode,

Output VSWR in 50 Ω system Uninterruptible level setting “fixed" attenuator mode,

Back-feed (from ≥50 Ω source)

PEP = peak envelope power (CW); for other modulation modes, depending on back-off.

temperature range +18 °C to +33 °C at maximum level

at maximum level – 15 dB

setting range maximum permissible RF power in output

frequency range of RF path

permissible DC voltage

N female, front 50 Ω +15 dBm (PEP) +12 dBm (PEP) +10 dBm (PEP) –110 dBm to +20 dBm

0.1 dB

<±1.0 dB <1.8 (typ. <1.5) <1.5 (typ. <1.3) 18 dB

+30 dBm, permanent ±20 V

6 R&S®SFE Broadcast Tester Version 02.01, August 2008

Spectral purity

Harmonics Nonharmonics level ≥–20 dBm, CW,

Broadband noise carrier offset >10 MHz,

SSB phase noise carrier offset 20 kHz,

level ≤12 dBm, CW

carrier frequency, carrier offset >10 kHz

100 kHz to 87 MHz >87 MHz to 1 GHz >1 GHz to 2.5 GHz

measurement bandwidth 1 Hz

f > 87 MHz f ≤ 87 MHz

measurement bandwidth 1 Hz

f ≤ 87 MHz 87 MHz < f < 375 MHz 375 MHz ≤ f < 750 MHz 750 MHz ≤ f < 1 GHz

f > 1 GHz carrier offset 500 kHz, measurement bandwidth 1 Hz

f ≤ 87 MHz

87 MHz < f < 375 MHz

375 MHz ≤ f < 750 MHz

750 MHz ≤ f < 1 GHz

f > 1 GHz

I/Q modulation

<–30 dBc

reference: signal power

<–50 dBc <–60 dBc <–50 dBc

<–135 dBc <–115 dBc

<–100 dBc <–110 dBc <–100 dBc <–100 dBc <–95 dBc

<–100 dBc <–130 dBc <–130 dBc <–120 dBc <–115 dBc

I/Q modulator

Modulation frequency range DC to 35 MHz Modulation frequency response 2

Carrier leakage without input signal, referenced to

Sideband suppression modulation frequency ≤100 kHz,

I/Q swap I and Q signals swapped ON, OFF

up to 35 MHz up to 5 MHz

full-scale input

referenced to signal power

<±2 dB <±0.4 dB <–55 dBc typ. <–65 dBc after local adjustment <–50 dBc typ. <–60 dBc after local adjustment

Internal baseband I/Q

Signal characteristics see “Digital modulation systems” D/A converter sample rate

resolution sampling rate

Aliasing filter with amplitudes, group delay, and

Si correction

bandwidth 0.1 dB

100 MHz 16 bit 400 MHz (internal interpolation × 4)

35 MHz

Extended I/Q input (R&S®SFE-K80 option)

The R&S®SFE-K80 option allows external digital signals to be fed into the baseband signal processing unit of the R&S®SFE. Noise signals can be superimposed on input signals if the noise option has been installed.

Digital I/Q input connector

level word width analog bandwidth symbol rate

mini D ribbon, 26 pins, rear LVDS 16 bit 0 Hz to 35 MHz 3 ksymbol/s to 100 Msymbol/s

This frequency response is superimposed on all frequency responses of this specification.

Value applies after 1 h warm-up time and recalibration for 4 h of operation as well as temperature variations of less than ±5 °C.

Version 02.01, August 2008 R&S®SFE Broadcast Tester 7

Digital baseband

Internal test signals

MPEG-2 TS packet header + 184 byte payload

PID = 1FFF (hex) MPEG-specific TS packet sync byte + 187 byte payload payload: PRBS DirecTV TS packet header + 127 byte payload payload: PRBS DirecTV TS packet without header 130 byte payload payload: PRBS PRBS PRBS in line with ITU-T O.151 2

MPEG-2 inputs

ASI/SMPTE 310M/ETI serial input connector

ASI input level

SMPTE 310M input level

ETI input level

input impedance

ASI data rate

SMPTE 310M data rate

ETI data rate Stuffing ASI, SMPTE 310M

stuffing packets

Display measured values packet length, input data rate, useful data

TS generator (R&S®SFE-K20 option)

Transport stream files

file format

length of transport stream packets

sequence length

data rate

net data rate

data volume Signal set moving pic t ur e se q u en c e s a n d t e st p at t e rn s

payload: PRBS

– 1, 2

– 1 (selectable)

BNC female, 2 × rear 200 mV to 880 mV 400 mV to 880 mV 0 V to ±2.37 V (HDB3) 75 Ω 270 Mbit/s

19.392658 Mbit/s 2048 kbit/s ON/OFF see MPEG-2 TS packet under "Internal test signals"

rate

Rohde & Schwarz data streams generated transport streams (GTS) format ATSC: 188 DVB: 188 generation of endless and seamless transport streams with repetition of video, audio, and data contents 100 kbit/s to 214 Mbit/s (including null packets) max. 90 Mbit/s max. 80 Mbyte payload

with test tones, for 625 and 525 lines; DVB/ATSC systems, additional signals via options

TRP player (R&S®SFE-K22 option)

Replay file format

length of transport stream packets

replay time/sequence length

data rate

data volume

8 R&S®SFE Broadcast Tester Version 02.01, August 2008

TRP, T10, BIN, DAB/DAB_C, FLO/FLO_C (any recorded data streams) corresponding to externally applied/recorded transport stream endless (but not seamless) replay with cut at transition from end of file to beginning of file corresponding to recording data rate and setting (100 kbit/s to max. 90 Mbit/s) from hard disk limited only by hard disk size

Analog baseband

Analog video/audio input

Video input connector

CCVS input level

input impedance

level clamping Audio inputs 1/2 connector

input level

input impedance BTSC connector

input level

input impedance

Internal audio signal generator

Audio signals number of signals

frequency

level

Internal NICAM audio signal generator

Audio signals number of signals

frequency

level

Internal video signal generator (R&S®SFE-K23 option)

Internal video generator

Video signals ATV video basic test signals COLORBARS_75 (PAL)

Insertion test signal structure in line with country-specific standards PAL color bar 75 %

PAL M color bar 75 %

first field

lines 8, 10 line 16 line 17 line 18 line 19 lines 20, 21

second field

line 329 line 330 line 331 line 332 line 333 lines 334, 335

first field

line 17 line 18

second field

line 17 line 18

BNC female, rear

= 1 V

75 Ω back-porch clamping D-Sub, 9-pin female, rear 100 mV to 1.55 V (V 600 Ω, balanced D-Sub, 9-pin female, rear

0.25 V to 2 V (V 75 Ω

2, can be set separately 30 Hz to 15 kHz, in 1 Hz steps –60 dBu to +12 dBu, in 0.01 dB steps, 6 dBu corresponds to standard deviation

2, can be set separately 30 Hz to 15 kHz, in 1 Hz steps –60 dBu to +12 dBu, in 0.01 dB steps, 6 dBu corresponds to standard headroom

COLORBARS_75 (PAL M) COLORBARS_75 (PAL N) COLORBARS_75 (NTSC) COLORBARS_75 (SECAM) FUBK (PAL)

2T pulse data line 1 CCIR17 CCIR18/1 CCIR18/2 teletext insertion test signal

data line 2 CCIR330/5 2T pulse CCIR331/1 sinx/x teletext insertion test signal

NTC7 composite FCC composite

NTC7 combined sinx/x

rms

)

rms

)

Version 02.01, August 2008 R&S®SFE Broadcast Tester 9

PAL N color bar 75 %

NTSC color bar 75 %

SECAM color bar 75 %

PAL FuBK

Other video signals see R&S®ATV Video

first field

lines 8, 10 line 16 line 17 line 18 line 19 lines 20, 21

second field

line 329 line 330 line 331 line 332 line 333 lines 334, 335

first field

line 17 line 18

second field

line 17 line 18

first field

lines 7 to 15 line 16 line 17 line 18 line 19 lines 20, 21

second field

lines 320 to 328 line 329 line 330 line 331 line 332 line 333 lines 334, 335

first field

lines 8, 10 line 16 line 17 line 18 line 19 lines 20, 21

second field

line 329 line 330 line 331 line 332 line 333

lines 334, 335

2T pulse data line 1 CCIR17 CCIR18/1 CCIR18/2 teletext insertion test signal

data line 2 CCIR330/5 2T pulse CCIR331/1 sinx/x teletext insertion test signal

NTC7 composite FCC composite

NTC7 combined sinx/x

discriminating signal data line 1 CCIR17 CCIR18/1 CCIR18/2 teletext insertion test signal

discriminating signal data line 2 CCIR330/5 2T pulse CCIR331/1 sinx/x teletext insertion test signal

2T pulse data line 1 CCIR17 CCIR18/1 CCIR18/2 teletext insertion test signal

data line 2 CCIR330/5 2T pulse CCIR331/1 sinx/x teletext insertion test signal

10 R&S®SFE Broadcast Tester Version 02.01, August 2008

Digital modulation systems

DVB-T/H (R&S®SFE-K1 option)

DVB-T/H in line with

Modulation modulation

Coding constellation

Special functions Reed-Solomon encoder can be switched off Test signals

EN 300744/EN 302304

bandwidth

MER

modulation frequency response

shoulder distance

back-off

code rate

guard interval

FFT mode

interleaver

TPS

TS test packet (see ”Internal test signals”),

DVB-C/ISDB-C (R&S®SFE-K2 option)

DVB-C

ISDB-C Modulation modulation

Special functions Reed-Solomon encoder can be switched off Test signals TS test packet (see ”Internal test signals”),

in line with ITU-T J.83/A

(EN 300429)

in line with ITU-T J.83/C

symbol rate

pulse filtering

MER

modulation frequency response

shoulder distance

back-off

COFDM 5 MHz, 6 MHz, 7 MHz, 8 MHz

>40 dB <±0.2 dB >48 dB

13.5 dB QPSK, 16QAM, 64QAM, hierarchical

coding 1/2, 2/3, 3/4, 5/6, 7/8 1/4, 1/8, 1/16, 1/32 2k, 4k, and 8k COFDM native and in-depth in line with DVB-T/H

PRBS after convolutional encoder

16QAM, 32QAM, 64QAM, 128QAM, 256QAM 1 Msymbol/s to 8 Msymbol/s, settable root raised cosine roll-off, alpha = 0.13, 0.15 >40 dB ±0.25 dB >48 dB 9 dB

PRBS before mapper

DVB-S/DVB-DSNG (R&S®SFE-K3 option)

DVB-S/DVB-DSNG in line with

Modulation modulation

Coding code rate QPSK: 1/2, 2/3, 3/4, 5/6, 7/8

Special functions Reed-Solomon encoder can be switched off Test signals TS test packet (see ”Internal test signals”),

With internal test signals.

EN 300421/EN 301210

symbol rate

pulse filtering

MER

modulation frequency response

shoulder distance

back-off

QPSK, 8PSK, 16QAM 100 ksymbol/s to 45 Msymbol/s, settable root raised cosine roll-off, alpha = 0.35, 0.25 38 dB (27.5 Msymbol/s) ±0.25 dB >45 dB 9 dB

8PSK: 2/3, 5/6, 8/9 16QAM: 3/4, 7/8

PRBS before convolutional encoder

Version 02.01, August 2008 R&S®SFE Broadcast Tester 11

DVB-S2 (R&S®SFE-K8 option)

DVB-S2 in line with EN 302307,

broadcast services Modulation modulation

symbol rate

QPSK, 8PSK 16APSK

32APSK

pulse filtering

MER

modulation frequency response

shoulder distance

back-off Coding code rate

FEC frame

pilot insertion Special function error insertion after CRC-8, BCH, or LDPC Test signals TS test packet (see ”Internal test signals”)

QPSK, 8PSK, 16APSK, 32APSK

1 Msymbol/s to 35 Msymbol/s (overrange 40 Msymbol/s) 2 Msymbol/s to 30 Msymbol/s 2 Msymbol/s to 25 Msymbol/s root raised cosine roll-off, alpha = 0.20 variable roll-off (0.15, 0.20, 0.25, 0.35) 38 dB (20 Msymbol/s) ±0.25 dB 45 dB 12 dB

QPSK: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10 normal (64800 bit)/short (16200 bit) can be switched off

T-DMB/DAB (R&S®SFE-K11 option)

T-DMB/DAB in line with T-DMB/EN 300401 Korea/Europe Modulation modulation

mode

bandwidth

modulation frequency response

shoulder distance

back-off Single-frequency network network mode

control Special function PRBS

COFDM I, II, III, IV

1.536 MHz <0.2 dB >45 dB 13 dB MFN MID, manual

can be inserted into a subchannel

ATSC/8VSB (R&S®SFE-K4 option)

ATSC/8VSB in line with ATSC Doc. A/53 (8VSB) Modulation modulation

bandwidth

symbol rate

range pilot pulse filtering MER modulation frequency response shoulder distance back-off

Coding input data rate

range

Test signals TS test packet (see ”Internal test signals”)

Can be inserted into an existing, user-selectable subchannel of an incoming, valid ETI data stream.

8VSB 6 MHz

10.762 Msymbol/s settable ±5 %

1.25 root r a i sed c o s i ne roll-off, alpha = 0. 115 >40 dB <±0.25 dB >45 dB 9 dB

19.392658 Mbit/s ±5 % (depending on symbol rate)

12 R&S®SFE Broadcast Tester Version 02.01, August 2008

J.83/B (R&S®SFE-K5 option)

J.83/B in line with ITU-T J.83/B Modulation modulation

bandwidth symbol rate

64QAM

256QAM

1024QAM pulse filtering

MER modulation frequency response shoulder distance

64QAM

256QAM

1024QAM back-off

Coding input data rate

64QAM

256QAM

1024QAM data interleaver

Special functions Reed-Solomon encoder can be switched off Test signals TS test packet (see ”Internal test signals”),

64QAM, 256QAM, 1024QAM 6 MHz

5.0569 Msymbol/s

5.3605 Msymbol/s

5.3605 Msymbol/s root raised cosine roll-off, alpha =

0.18 (64QAM), 0.12 (256/1024QAM) >40 dB ±0.25 dB

> 50 dB >45 dB >45 dB 9 dB

26.97035 Mbit/s

38.81070 Mbit/s

49.02525 Mbit/s level 1 and level 2

PRBS before mapper

DirecTV legacy modulation (R&S®SFE-K9 option)

DirecTV legacy modulation in line with DirecTV transmission

specifications

Modulation modulation

symbol rate

overrange pulse filtering

MER modulation frequency response shoulder distance back-off

Coding code rate 1/2, 2/3, 6/7 Special functions customer-specific DirecTV streams

error insertion

Test signals TS test packet (see ”Internal test signals”)

QPSK 20 Msymbol/s 1 Msymbol/s to 30 Msymbol/s root raised cosine roll-off, alpha = 0.20 variable roll-off (0.15, 0.20, 0.25, 0.35) 38 dB (20 Msymbol/s) <±0.25 dB 45 dB

11.5 dB

can be replayed in 188-byte format, requires R&S after convolutional encoder

SFE-K22 option

DTMB (R&S®SFE-K12 option)

DTMB in line with GB20600-2006 Modulation modulation

bandwidth modulation frequency response shoulder distance back-off

Coding constellation

code rate guard interval guard interval pn time interleaver FFT mode dual pilot tone

Network mode MFN Special functions DMB-TH mode selectable Test signals TS test packet (see ”Internal test signals”)

Version 02.01, August 2008 R&S®SFE Broadcast Tester 13

COFDM/single carrier 6 MHz, 7 MHz, 8 MHz <0.2 dB >50 dB 12 dB 4QAM(QPSK), 4QAM-NR, 16QAM, 32QAM, 64QAM

0.4, 0.6, 0.8 420, 595, 945 symbols variable/constant 240, 720 symbols 4k COFDM/single carrier ON/OFF (single carrier)

ISDB-T/ISDB-Tsb/ISDB-TB (R&S®SFE-K6 option)

ISDB-T, ISDTV

ISDB-Tsb

ISDB-T

in line with ARIB STD-B31 version 1.5 in line with ARIB STD-B29 ISDB-Tsb Brazil

Modulation modulation

bandwidth number of segments

STD-B31

STD-B29 MER modulation frequency response shoulder distance back-off

Coding FFT mode

number of layers constellation code rate guard interval time interleaver

Special function AC information PRBS, all "1" Test signals TS test packet (see ”Internal test signals”)

MediaFLO™ (R&S®SFE-K10 option)

MediaFLO™ in line with

QUALCOMM 80-T0455-1 Rev. E

Modulation modulation

bandwidth modulation frequency response shoulder distance back-off

Coding FFT mode 4k COFDM Test signals PRBS

OFDM 6 MHz (variable: ±1000 ppm)

13 1, 3 >40 dB <0.2 dB >48 dB 13 dB 2k, 4k, and 8k 1 to 3 (1 or 2 in line with ISDB-Tsb) QPSK, DQPSK, 16QAM, 64QAM 1/2, 2/3, 3/4, 5/6, 7/8 1/4, 1/8, 1/16, 1/32 0, 1, 2, 4, 8, 16 (additionally 32 with ISDB-Tsb)

COFDM 5 MHz, 6 MHz, 7 MHz, 8 MHz <0.2 dB 40 dB

15.5 dB

14 R&S®SFE Broadcast Tester Version 02.01, August 2008

Analog modulation systems

AM/FM/RDS (R&S®SFE-K170 option)

FM Audio signals internal

external

AF frequency range

AF frequency response rejection at 19 kHz

Preemphasis OFF, 50 µs, 75 µs Incidental AM at AF = 1 kHz, deviation ±50 kHz <0.1 % FM stereo Stereo modes L, R, L = R, L = –R, L ≠ R

MPX frequency deviation deviation

resolution

Stereo crosstalk attenuation at AF = 30 Hz to 15 kHz >50 dB Distortion at 60 kHz audio frequency deviation,

AF = 1 kHz

S/N ratio (stereo/RDS signal)

at ±40 kHz audio frequency deviation ITU-R weighted (quasi-peak) ITU-R unweighted (rms)

Pilot tone frequency

deviation resolution phase resolution

RDS subcarrier frequency

deviation resolution

FM mono Mono frequency deviation deviation

resolution at ±67.5 kHz audio frequency deviation,

AF = 1 kHz

Distortion

AM Audio signals internal

external

AF frequency range

AF frequency response rejection at 3.15 kHz

Modulation modulation depth

resolution

AM distortion at AF = 1 kHz

m = 30 % m = 80 %

see ”Internal audio signal generator”

see “Analog video/audio input” 30 Hz to 15 kHz <0.2 dB >70 dB

internal generation of RDS signal, simultaneous generation of MPX and RDS signals possible

0 Hz to ±100 kHz 10 Hz

<0.1 %

>64 dB >70 dB 19 kHz ±1 Hz 0 Hz to ±15 kHz 10 Hz 0° to ± 180°

0.1° 57 kHz ±3 Hz 0 Hz to ±10 kHz 10 Hz

0 Hz to ±100 kHz 10 Hz <0.1 %

see ”Internal audio signal generator” see “Analog video/audio input” 30 Hz to 2.25 kHz <0.2 dB >35 dB 0 % to 100 % 1 %

<0.2 % <0.2 %

Generator without preemphasis, receiver with deemphasis.

Generator and receiver without preemphasis/deemphasis.

Version 02.01, August 2008 R&S®SFE Broadcast Tester 15

Standard B/G (R&S®SFE-K190 option)

Standard B/G in line with country-specific standard Vision modulation modulation

group delay

precorrection frequency response

vestigial sideband

filtering

amplitude frequency response signal-to-noise ratio

video

back-off

Sound modulation operating mode

modulation of sound carrier 1, 2

modulation mode frequency deviation preemphasis vision/sound intercarrier frequency

vision/sound carrier power ratio pilot tone signal-to-noise ratio

sound

Video signals internal video signal generator

external video input

Audio signals internal audio generator

external audio input

B/G

CCIR – B/G general half (can be switched off) <20 ns (with/without vestigial sideband filtering)

B/G, can be switched off <0.5 dB (–0.6 MHz to +4.8 MHz) (with/without vestigial sideband filter ing)

>60 dB, weighted 6 dB mono, stereo, dual tone, NICAM, mono/NICAM

FM 30 kHz (settable) 50 µs/75 µs (can be switched off)

5.5 MHz/5.742 MHz (settable) 13 dB/20 dB (settable) in sound carrier 2 (can be switched off)

>60 dB, weighted (CCIR) see R&S®SFE-K23 see “Analog video/audio input” see ”Internal audio signal generator” see ”Internal NICAM audio signal generator” see “Analog video/audio input”

Standard D/K (R&S®SFE-K191 option)

Standard D/K in line with country-specific standard Vision modulation modulation

group delay

precorrection

frequency response vestigial sideband

filtering amplitude frequency response

signal-to-noise ratio

video back-off

Sound modulation operating mode

modulation of sound carrier 1, 2

modulation mode

frequency deviation

preemphasis

vision/sound intercarrier frequency

vision/sound carrier power ratio pilot tone signal-to-noise ratio

sound

Video signals internal video signal generator

external video input

Audio signals internal audio generator

external audio input

D/K

OIRT – D/K half (can be switched off) <20 ns (with/without vestigial sideband filtering)

DK, DK-FM2, DK-NICAM, can be switched off <0.5 dB (–1 MHz to +5.8 MHz) (with/without vestigial sideband filter ing)

>60 dB, weighted 6 dB mono, stereo, dual tone, NICAM, mono/NICAM

FM 30 kHz (settable) 50 µs/75 µs (can be switched off)

6.5 MHz/6.742 MHz (settable) 13 dB/20 dB (settable) in sound carrier 2 (can be switched off)

16 R&S®SFE Broadcast Tester Version 02.01, August 2008

Standard I (R&S®SFE-K192 option)

Standard I in line with country-specific standard Vision modulation modulation

group delay

precorrection

frequency response vestigial sideband

filtering amplitude frequency response

signal-to-noise ratio

video back-off

Sound modulation operating mode

modulation of sound carrier 1

modulation mode

frequency deviation

preemphasis

vision/sound intercarrier frequency

vision/sound carrier power ratio modulation of sound carrier 2

modulation mode

vision/sound intercarrier frequency

vision/sound carrier power ratio signal-to-noise ratio

sound

Video signals internal video signal generator

external video input

Audio signals internal audio generator

external audio input

UK – I (can be switched off) <20 ns (with/without vestigial sideband filtering)

I, I1, can be switched off <0.5 dB (–1 MHz to +4.8 MHz) (with/without vestigial sideband filter ing)

>60 dB, weighted 6 dB mono, NICAM, mono/NICAM

FM 30 kHz (settable) 50 µs/75 µs (can be switched off) 6 MHz (settable) 13 dB (settable)

NICAM

6.552 MHz (settable) 20 dB (settable)

Standard M/N (R&S®SFE-K193 option)

Standard M/N in line with country-specific standard Vision modulation modulation

group delay

precorrection

frequency response vestigial sideband

filtering amplitude frequency response

signal-to-noise ratio

video back-off

Sound modulation operating mode

modulation of sound carrier 1, 2

modulation mode

frequency deviation

preemphasis

vision/sound intercarrier frequency

vision/sound carrier power ratio

pilot tone

signal-to-noise ratio

sound

Video signals internal video signal generator

external video input

Audio signals internal audio generator

external audio input

M/N

FCC – M/N (can be switched off) <20 ns (with/without vestigial sideband filtering)

M, N, can be switched off <0.5 dB (–0.6 MHz to +4 MHz) (with/without vestigial sideband filter ing)

>60 dB, weighted 6 dB BTSC mono, stereo Korea, dual Korea

FM 25 kHz (settable) 50 µs/75 µs (can be switched off)

4.5 MHz/4.742 MHz (settable) 13 dB/20 dB (settable) in sound carrier 2 (can be switched off)

>60 dB, weighted (CCIR) see R&S®SFE-K23 see “Analog video/audio input” see ”Internal audio signal generator” see “Analog video/audio input”

Version 02.01, August 2008 R&S®SFE Broadcast Tester 17

Standard L (R&S®SFE-K194 option)

Standard L in line with country-specific standard Vision modulation modulation

group delay

precorrection

frequency response vestigial sideband

filtering amplitude frequency response

back-off

Sound modulation operating mode

modulation of sound carrier 1

modulation mode

vision/sound intercarrier frequency

vision/sound carrier power ratio modulation of sound carrier 2

modulation mode

frequency deviation

vision/sound intercarrier frequency

vision/sound carrier power ratio

Video signals internal video signal generator

external video input

Audio signals internal audio generator

external audio input

TDF – L (can be switched off) <20 ns (with/without vestigial sideband filtering)

L, L NICAM, can be switched off <0.5 dB (–1 MHz to +5.8 MHz) (with/without vestigial sideband filter ing) 6 dB

mono, NICAM, mono/NICAM

NICAM

5.85 MHz (settable) 27 dB (settable)

AM modulation depth 54 % (settable)

6.5 MHz (settable) 10 dB (settable) see R&S®SFE-K23 see “Analog video/audio input” see ”Internal audio signal generator” see ”Internal NICAM audio signal generator” see “Analog video/audio input”

ATV multistandard (R&S®SFE-K195 option)

Standard B/G see R&S®SFE-K190 Standard D/K see R&S®SFE-K191 Standard I see R&S®SFE-K192 Standard M/N see R&S®SFE-K193 Standard L see R&S®SFE-K194

Internal NICAM encoder

Included in the following options: R&S®SFE-K190, R&S®SFE-K191, R&S®SFE-K192, R&S®SFE-K194, and R&S®SFE-K195.

Audio coding internal audio generator

external audio input operating mode preemphasis headroom (400 Hz)

Encoder data

pulse filtering

NICAM728 data input

connector input level input impedance

see ”Internal NICAM audio signal generator” see “Analog video/audio input” mono, stereo, dual tone J.17, can be switched off –6 dB to +6 dB, can be set different from the standard audio coding, NICAM728 data input, PRBS, NICAM audio generator root raised cosine roll-off, alpha = 0.40 (B/G, D/K, L standards) alpha = 1.00 (I standard) D-Sub, 9-pin female, rear 1 V to 10 V (V 50 Ω

)

18 R&S®SFE Broadcast Tester Version 02.01, August 2008

ARB/waveforms

Arbitrary waveform generator (R&S®SFE-K35 option)

Waveform memory length

resolution loading time for 10 Msample memory location for data

Clock generation clock rate

uncertainty operating mode frequency accuracy (internal)

Interpolation bandwidth

with clock rate = 100 MHz (no

interpolation), bandwidth 0.1 dB

with clock rate <100 MHz,

bandwidth −0.1 dB sampling rate

Triggering modes

source

delay inhibit

Markers item

delay

Special function can be used together with

SFE-K35 supports the same waveform libraries as the ARB generator of the R&S®SFU.

R&S

T-DMB/DAB waveforms (R&S For specifications, see R&S

DVB-H waveforms (R&S For specifications, see R&S

DRM waveforms (R&S For specifications, see R&S

DTV interferers (R&S

For specifications, see R&S

MediaFlo™ waveforms (R&S For specifications, see R&S

Cable interferers (R&S

SFU-K351 option).

SFU.

SFU-K352 option).

SFU.

SFU-K353 option).

SFU.

SFU-K354 option). 9

SFU.

SFU-K355 option).

SFU.

SFU-K356 option).

For specifications, see R&S®SFU.

512 sample to 256 Msample in one-sample steps 2 × 16 bit 3 s hard disk

400 Hz to 100 MHz

0.001 Hz internal accuracy of reference frequency

40 MHz

0.31 × clock rate automatically interpolated to the internal 100 MHz data rate

auto retrigger armed auto armed retrigger internal external

0 to 2

– 1 sample, settable

0 to 2

– 1 sample, settable restart waveform 0 to waveform length, settable in samples

R&S

WinIQSIM

TM 8

(R&S®SFE-K350

option)

With R&S

Realtime signals and interferer signals cannot be used at the same time.

WinIQSIMTM: Software version 4.24 or later supports I/Q data download and R&S®SFE-K35 control.

Version 02.01, August 2008 R&S®SFE Broadcast Tester 19

Simulation

AWGN generator (R&S®SFE-K40 option)

RF bandwidth 3 dB spectrum (AWGN) 96 MHz Noise density distribution function

crest factor

C/N setting range

resolution uncertainty for system bandwidth = symbol rate and C/N < 20 dB

System bandwidth (bandwidth for calculating noise power)

range

Gaussian, statistical, separate for I and Q 18 dB –6 dB to +60 dB

0.1 dB <0.2 dB

100 kHz to 96 MHz

Analysis

BER measurements (R&S®SFE-K60 option)

BER measurements for all digital modulation modes

Display measured value

Start/restart

Serial PRBS measurements

Serial BER measurement is not possible with DVB-S2, DirecTV, DTMB, and MediaFLO Inputs for BER clock, BER data,

BER enable

BER data input data rate

BER clock, BER data polarity normal, inverted BER enable polarity always, active high, active low Output for BER error connector

MPEG-2 TS measurements Input input interfaces

connector input impedance input level

PRBS

output impedance output level

input signal payload (PRBS in line with ITU-T O.151) PID

BER error counter measurement time manual

™

BNC female, rear 50 Ω TTL/LVTTL up to 90 Mbit/s

– 1, 2

– 1

2 (in line with ITU-T O.151)

BNC female, rear 50 Ω LVTTL

ASI, SMPTE 310M (see “MPEG-2 inputs”) TS packet (see ”Internal test signals”)

2 NULL (1FFF (hex))/variable

Trigger inputs/outputs

Triggers and connectors for future use

Trigger IN

Trigger OUT connector

1PPS input connector

20 R&S®SFE Broadcast Tester Version 02.01, August 2008

connector input impedance input level

load impedance output level

input impedance input level

BNC female, rear high impedance LVTTL BNC female, rear, alternative to reference OUT >200 Ω LVTTL BNC female, rear high impedance LVTTL

General data

System data

System operating system

Local control display

control External control control external mouse and keyboard via USB Remote control command set

Ethernet

USB Connectors Ethernet

USB

AC supply input

Operating data

Power supply

Electromagnetic compatibility

Immunity against RF fields up to 10 V/m Environmental conditions operating temperature range

Mechanical resistance

Electrical safety in line with IEC 61010-1,

Dimensions W × H × D 235 mm × 155 mm × 465 mm (3 HU)

Weight fully equipped 6 kg Recommended calibration interval 3 years

Standard warranty period 1 year

input voltage range, AC supply frequency 100 V to 240 V ±10 %

power factor correction

storage temperature range

climatic resistance, cyclic test at

+25 °C/+40 °C

vibration, sinusoidal

vibration, random

shock

PC platform Windows XP Embedded 40 Gbyte internal hard disk VGA 640 × 480 pixels rotary knob, hardkeys, softkeys

SCPI 1999.5 10/100BaseT

2.0 RJ-45, rear USB, front and rear IEC 60320 C14, rear

50 Hz to 60 Hz ±5 %

1.8 A to 0.8 A in line with EN 55011 class A,

EN 61326 in line with EN 61000-3-2

+5 °C to +45 °C in line with EN 60068-2-1, EN 60068-2-2 –20 °C to +60 °C 85 % rel. humidity

5 Hz to 150 Hz, max. 2 g at 55 Hz, 55 Hz to 150 Hz, 0.5 g constant, in line with EN 60068-2-6 10 Hz to 300 Hz, acceleration 1.2 g (rms), in line with EN 60068-2-64 40 g shock spectrum, in line with EN 60068-2-27, MIL-STD-810E

EN 61010-1 and UL 61010-1, CSA C22.2 No. 61010-1

(9.25 in × 6.11 in × 18.3 in)

(13.28 lb)

Reduced LCD brightness at higher operating temperatures.

Version 02.01, August 2008 R&S®SFE Broadcast Tester 21

Ordering information

Option identification: R&S®SFE-Bxy = hardware option, R&S®SFE-Kxy = software option. Delivery of R&S

Order designation Type Order No. Broadcast Tester

including power cable, Quick Start Guide, CD-ROM (includes operating manuals)

Options Digital modulation systems

DVB-T/H Coder R&S®SFE-K1 2113.4010.02 DVB-C/ISDB-C Coder R&S®SFE-K2 2113.4032.02 DVB-S/DVB-DSNG Coder R&S®SFE-K3 2113.4055.02 DVB-S2 Coder R&S®SFE-K8 2113.4132.02 ATSC/8VSB Coder R&S®SFE-K4 2113.4078.02 J.83/B Coder R&S®SFE-K5 2113.4090.02 ISDB-T/ISDB-Tsb/ISDB-TB Coder R&S®SFE-K6 2113.4110.02 MediaFLO™ Coder R&S®SFE-K10 2113.4178.02 T-DMB/DAB Coder R&S®SFE-K11 2113.4190.02 DTMB / DMB-TH Coder R&S®SFE-K12 2113.4210.02 DirecTV Legacy Modulation Coder R&S®SFE-K9 2113.4155.02

Analog modulation systems

AM/FM/RDS Coder R&S®SFE-K170 2113.4432.02 ATV Standard B/G Coder R&S®SFE-K190 2113.4655.02 ATV Standard D/K Coder R&S®SFE-K191 2113.4678.02 ATV Standard I Coder R&S®SFE-K192 2113.4690.02 ATV Standard M/N Coder R&S®SFE-K193 2113.4710.02 ATV Standard L Coder R&S®SFE-K194 2113.4732.02 ATV Multistandard R&S®SFE-K195 2113.4755.02

ARB/waveforms

ARB Waveform Generator requires an installed R&S

Memory Expansion R&S®SFE-B3 2112.4500.02 R&S®WinIQSIM T-DMB/DAB Waveforms can be used with the R&S DVB-H Waveforms can be used with the R&S DRM Waveforms can be used with the R&S DTV Waveforms can be used with the R&S MediaFLO™ Waveforms can be used with the R&S Cable Interferers can be used with the R&S

Simulation

AWGN Generator R&S®SFE-K40 2113.4910.02

SFE base unit only with at least one modulation system (max. 3).

R&S

SFE 2112.4300.02

R&S

SFE-B3 option

Support R&S®SFE-K350 2113.4955.02

SFE-K35 option

SFE-K35 2113.4932.02

SFU-K351 2110.4277.04

R&S

SFU-K352 2110.4425.02

R&S

SFU-K353 2110.4554.02

R&S

SFU-K354 2110.4690.02

R&S

SFU-K355 2110.2974.02

R&S

SFU-K356 2110.3212.02

R&S

22 R&S®SFE Broadcast Tester Version 02.01, August 2008

Baseband inputs/outputs

Extended I/Q Input R&S®SFE-K80 2113.5251.02

Digital baseband TS Generator including SDTV streams R&S®SFE-K20 2113.4878.02

DVB-H Stream Library requires the R&S Test Card M Streams requires the R&S HDTV Sequences requires the R&S H.264 Stream Library requires the R&S ISDB-T Stream Library requires the R&S TRP Player requires an installed R&S

SFE-K20 option

SFE-B6 option Second Hard Disk (Compact Flash) R&S®SFE-B6 2112.4522.02 T-DMB/DAB Streams requires the R&S MediaFLO™ Streams requires the R&S

SFE-K22 option

DV-DVBH 2085.8704.02

R&S

DV-TCM 2085.7708.02

R&S

DV-HDTV 2085.7650.02

R&S

DV-H264 2085.9052.02

R&S

DV-ISDBT 2085.9146.02

R&S

SFE-K22 2113.5274.02

R&S

SFU-K221 2113.4348.02

R&S

SFU-K222 2110.2968.02

R&S

Analog baseband Video Generator R&S®SFE-K23 2113.4890.02

ATV Video Signals R&S®ATV Video 2110.4831.02

Measurement and analysis

BER Measurement

R&S®SFE-K60 2113.5151.02 possible for DVB-S2, DirecTV, DTMB, and MediaFLO™ to a limited extent or not possible at all

Recommended extras

Operating manuals; include Quick Start Guide (English) 2112.4322.12 Documentation of R&S®SFE Calibration Values R&S®SFE-DCV 2082.0490.32 Keyboard with USB Interface (US assignment) R&S®PSL-Z2 1157.6870.03 Mouse with USB Interface, optical R&S®PSL-Z10 1157.7060.02 External USB CD-RW Drive R&S®PSP-B6 1134.8201.12 19" Rackmount Kit for R&S®SFE and second instrument R&S®ZZA-T33 1109.4458.00 19" Rackmount Kit for R&S®SFE and cover R&S®ZZA-T34 1109.4464.00 LVDS cable for digital I/Q interface, length 2 m 1130.1302.00 Service options (can only be ordered in connection with the purchase of an instrument) One-Year Repair Service following the warranty period Two-Year Repair Service following the warranty period Four-Year Repair Service following the warranty period

R&S®RO2SFE please contact your local sales

office

R&S®RO3SFE please contact your local sales

office

R&S®RO5SFE please contact your local sales

office

Two-Year Calibration Service R&S®CO2SFE please contact your local sales

office

Three-Year Calibration Service R&S®CO3SFE please contact your local sales

office

Five-Year Calibration Service R&S®CO5SFE please contact your local sales

office

Version 02.01, August 2008 R&S®SFE Broadcast Tester 23

Certified Quality System

ISO 9001

DQS REG. NO 1954 QM

Certified Environmental System

ISO

14 001

DQS REG. NO 1954 UM

For product brochure, see PD 5213.8596.12

and www.rohde-schwarz.com

(search term: SFE)

¸ is a registered trademark of Rohde & Schwarz GmbH & Co. KG · Trade names are trademarks of the owners · Printed in Germany (bb)

PD 5213.8596.22 · Version 02.01 · August 2008 · ¸SFE · Data without tolerance limits is not binding · Subject to change

Europe, Africa, Middle East: +49 1805 12 42 42* or +49 89 4129 137 74, customersupport@rohde-schwarz.com

www.rohde-schwarz.com

North America: 1-888-TEST-RSA (1-888-837-8772), customer.support@rsa.rohde-schwarz.com

Latin America: +1-410-910-7988, customersupport.la@rohde-schwarz.com Asia/Pacific: +65 65 13 04 88, customersupport.asia@rohde-schwarz.com

Rohde and Schwarz SFE Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
