Universal Radio Communication Tester CMU200

THE multi protocol tester for current and future mobile radio networks

◆ Extremely high speed testing

◆ Highly accurate measurements

◆ Modular future-proof design

◆ Comprehensive spectrum analyzer

◆ Fast switching between networks

Testing the 3rd generation

For more than 60 years Rohde&Schwarz has always been at the forefront of mobile radio technology. We continue this tradition of RF test and measurement with Universal Radio Communication Tester CMU200. The CMU200 is a third generation platform design, that offers true scalable multimode functionality.

CMU200 reflects the long-standing expertise Rohde&Schwarz has gained in the world of mobile radio. In recent years, the company has helped to launch overwhelmingly successful mobile radio systems.

Rohde &Schwarz is a preferred supplier to many of the leading mobile equipment manufacturers and is the market leader for mobile radio test sets.

The CMU200 is part of a complete range of mobile radio test equipment, encompassing everything from conformance test systems, to system simulators, turnkey functional board test / final test systems and simple sales counter Go/NoGo testers.

Low cost of ownership

Selecting the CMU 200 is a decision for the future and results in a total cost of ownership which is sure to be among the lowest due to the following factors:

◆ Completely modular design of hard-

ware and software components avoids unnecessary investments right from the start just because there is a possibility of a feature being needed sometime in the future. You only pay for what you need

◆ Should an extension become nec-

essary because your needs widen after some time – the modularity of the CMU200 concept will cater for that. Many extensions to the unit may be installed onsite. You only pay for it when you need it

◆ The concept allows two complete

channels (RF, signalling and evaluation) to be installed in one CMU200 unit

◆ Maximum production output in a

compact 4-rackunit-height package with minimum power dissipation allows compact production space layout

◆ With the CMU200 user interface even

less experienced users will intuitively get it right without the need for extensive training

◆ A new remote interface syntax re-

flects the inherent modularity of this real multimode tester

The base unit with its standard-independent module test provides many general purpose measurement facilities for the development of all kinds of standards within its wide and continuous frequency range. If extended by the relevant options, the CMU200 offers the hardware and software necessary to handle your 3G, “2.5G“ and previous generation testing applications including analog.

2 Universal Radio Communication Tester CMU200

The CMU200 targets a wide range of applications, but is primarily optimized for the high accuracy and speed demanded in an ever more quality-conscious manufacturing process. Shown here, the frontpanel for desktop use.

Applications

•RF development

•Module design

• Module test in production

• Adjustment of mobiles

• Final test in production

• Functional test

• Feature test

• High-end service

• Quality inspections

• Basis for test systems

• Base station simulation

Usability

The CMU200 key strengths

The Radio Communication Tester CMU200 brings premium cost effectiveness through a variety of features, with extremely fast measurement speed and very high accuracy being the two most important ones. In addition, the secondary remote addressing of the unit's modular architecture makes for intelligent and autonomous processing of complete measurement tasks and fast control program design.

Greatest accuracy

In a production environment the unit’s high accuracy allows DUTs (Device under Test) to be trimmed for maximum battery lifetime without compromising quality. In the lab, CMU200 enables the development engineer to partly replace conventional, dedicated premium-quality instruments and save desktop space at the same time. High precision measurement correction over the whole frequency and dynamic range as well as compensation for temperature effects in real time are critical factors for achieving the CMU200’s excellent accuracy. The globally standardized Rohde& Schwarz calibration system can check CMU 200 accuracy in a service center close to you or, volume permitting, on your site. A worldwide network of these standardized automatic calibration systems has been implemented in our service centers. Highly accurate and repeatable calibration can be performed wherever you are. Your local Rohde&Schwarz representative offers customized service contracts for the unit. For large scale users of CMU200 a compact level verification system is available,

addition

Thanks to the high resolution of the extremely bright high-contrast TFT display even the finest details can be displayed

Direct branching to all associated menus makes for a uniquely flat menu structure

Greatest speed

The high processing speed is due to extensive use of ProbeDSP™ measurements and innovative remote command processing.

◆ ProbeDSP™ technology

The modular architecture relies on decentralized ProbeDSP™ processing coordinated by a powerful central processor. Like an oscilloscope probe, DSPs dedicated to a specific local data acquisition and evaluation workload help to keep subsystem performance at an uncompromising maximum even if additional modules are fitted to the CMU200 mainframe.

◆ Parallel measurements

Several RX and TX measurements can be performed in parallel. This is achieved by the fast response of the CMU200's modular hardware as well as the high overall processing power of the unit and the avoidance of bottlenecks by dedicated operation of

technology, parallel

the ProbeDSP™ technology employed. Examples of parallel operation are measurements of BER and simultaneous Phase/Frequency error, EVM, Magnitude Error and audio or the various spectrum measurements.

◆ Innovative remote processing

The novel secondary addressing mode can address similar functions of each of the CMU200 subsystems (different mobile radio standard) in an almost identical way. Using this type of addressing, new remote test sequences can be programmed by a simple cut and paste operation followed by editing specific commands to adapt the control program to the new application. Secondary addressing is fully SCPI-compliant which means that a subsystem address, for example “WCDMA-FDD“, can be replaced by a string denoting a different subsystem, another mobile radio standard.

4 Universal Radio Communication Tester CMU200

As the CMU200 offers many of its measurements in signalling and non-signalling mode, this easy visual indication of the signalling state is provided as part of the status line

This symbol shows the instrument status, i.e. remote or manual operation

Key advantages of the CMU200

Speed

Greatest reliability

CMU200 employs an ultra effective heat management between housings and individual components as well as between heat sinks and the air flow. Together with the independent cooling cycles for different modules, this adds up to an optimized cooling system.

The base unit

The base unit without any options installed can be used for testing general parameters of 1st, 2nd or 3rd generation mobile phones. The CMU200 base unit is the ideal solution for tasks at module level, i.e. at the early production stages of all cellular standards.

For increased speed, not required measurements can be switched off to free resources for the measurements you want to focus on

Measurements are configured by pressing the softkey marked with the yellow triangle two times

Constituent parts of the CMU200 base unit are the RF generator and RF analyzer which are complemented by a versatile network-independent time domain menu and a comprehensive spectrum analyzer. As an example power versus time measurement is shown above.

By combining graphical and numerical overview menus the optimal view can be chosen when the CMU200 is in manual mode.

The menu structure of the CMU200 is very flat and uses context-sensitive selection, entry and configuration pop-up menus.

Advanced operational ergonomics have been incorporated into a most compact and lightweight, 4 rack units high package.

◆ Unrivalled speed of single measurements

Accuracy

◆ Incomparable accuracy

◆ Excellent result repeatability

Modularity

◆ Modular hardware and software concept provides easy extension to further functionality

Reliability

◆ Extremely low power consumption, and effective heat conduction result in unparalleled reliability

Future-proof

◆ Easy migration to emerging standards

Universal Radio Communication Tester CMU200 5Universal Radio Communication Tester CMU200 5

Optimized solutions for your production test requirements

Rohde&Schwarz supports CMU200 based production test solutions through a comprehensive net of application engineering sites. The backbone to this network is the four system integration centers located in Asia, North America and Europe.

System Integration Services

Regional center project teams offer local system integration, service and support. A team of experts is ready to provide turnkey solutions including test case programming. Custom-tailored project solutions and site process optimization are major aspects of our services. For fully automated production environments we offer inline solutions together with our partners in the field of automation. As an example a fully automated final test fixture including RF test, audio test, keypad test and optical inspection is shown on the picture.

Time to Market

The key to commercial success resides in the time required to get a new product to market in large volume. The crucial point is the fast transition from product development stage to mass production. The TS7100 Cellular Phone Production Test Platform featuring the CMU200 meets this challenge.

TSVP (Test System Versatile Platform)

The test platform is based on the industry standard Compact PCI/PXI. of bus is up to 6 times faster than previous industry bus standards. CompactPCI frame is 100% compatible to the industry standard but features 14 up to 31 slots. It comprises a state-of-the-art

controller PC, digital multimeter and selectable switching and test modules. each DUT the test hardware for switching and stimulus functions is implemented as a dedicated set of modules.

This new type

The TSVP´s

For

The TSVP takes up all modules used for control and additional measurements.

Off-the-shelf CompactPCI/PXI modules can be added. Up to 4 sets of modules for testing DUTs can be inserted. The software can thus simultaneously use the resources of the parallel instrumentation to maximize speed in highly automated production. We can offer optimal configured test systems customized to your production environment.

Test Executive & Generic Test Software Library Features

The parallel hardware is fully supported by TestStand, the industry-wide test executive from National Instruments. A userfriendly connection to the available device drivers has been created to provide faster use of the test executive. This connection is established by the Generic Test Software Library (GTSL). At the same time the toolkit concept provides readyto-run test cases, which can be customized by the user as required.

GTSL in action

TS7100 Description in Brief

The stringent requirements in the production environment of mobile phones make it necessary to implement new strategies in the specification of test systems. The test system architecture is based on two CMU200s to provide the optimum throughput solution.

6 Universal Radio Communication Tester CMU200

TS7100

Example of a

2-channel ultra-

low-profile config-

uration. PSU and

switch matrix fit-

ted to the rear of

rack

TS7100 Features in Brief

◆ High throughput by parallel testing

of cellular phones

◆ All hardware and software components

based on industrial standards

◆ System controller based on

CompactPCI/PXI bus arcitecture

◆ One system for functional board test,

phone calibration and final test

◆ One system for all major cellular phone

standards

◆ Easy expansion to 3rd generation

technologies

◆ Ready-to-run Rohde& Schwarz test

library for immediate use or customization

◆ Provides modular and versatile hardware/

software platform

◆ Reduced costs due to generic concept

Software concept in brief

◆ Software platform based on LabWin-

dows/CVI and TestStand from National Instruments

◆ GTSL includes ready-to-run test cases

for the standards supported by CMU200

◆ Functional test sequences for RF test,

calibration, signalling test and audio and acoustic test of mobile phones are supported

DUT 1

DUT fixtures

• manual

• semi-automatic

• automatic

Blockdiagram

for a 2-channel

configuration

of TS7100

◆ Transparent and open library can be

extended by the user

◆ Operator interface and test cases can

be easily customized

◆ Parallel test of multiple cellular

phones is fully supported

◆ GTSL supports multi-threading and in-

strument sharing if needed

◆ Test development time is reduced by

as much as 80 %

DUT 2

DUT 1

RF 1

Radio Communication Tester CMU200

DUT channel card TS-PRL 1

Cellular test power supply

For more detailed information see separate data sheet TS7100 (PD 757.5737)

TSVP based on CompactPCI, controlled by state-of-the art computer

Dedicated CompactPCI modules include …

General purpose and AF switching Digital I/O Power Relays

Digital multimeter RS-232 GPIB (IEEE 488.2)

Universal Radio Communication Tester CMU200 7

Ready for today‘s networks …

GSM today

Since its introduction in the early nineties, the GSM system has won acceptance and undergone an evolution that no one could have foreseen. The applications of the GSM system are numerous and are currently:

◆ GSM400

◆ GSM850

◆ GSM900 including

– P-GSM (primary GSM) – E-GSM (extended GSM) – R-GSM (railway GSM)

◆ GSM1800 (DCS)

◆ GSM1900 (PCS)

Whether the application is in production, service or development, the flexible concept of the CMU 200 from basic RF signal generation, frequency, power and spectrum analyzer measurements for alignment of modules in production or development applications, to an instrument with full GSM-specific signalling in any of the above-mentioned bands, as well as module tests on frequencies anywhere in the range from 10 MHz to 2700 MHz.

Signalling mode

The CMU200 simulates a GSM base station RF interface with the signalling flexibility necessary to test the behaviour of the mobile under the influence of different signalling parameters. These parameters are normally set by the network operator but can be reproduced by the CMU200 for test purposes. The unit supports the latest fast location update and direct paging features.

8 Universal Radio Communication Tester CMU200

Reduced signalling synchronized mode

The CMU200 provides the same functionality as in the Signalling mode, but discards any signalling reaction from the mobile connected. This mode of operation enables both testing of modules that only have layer 1 operation and very fast RF testing in production environments. It can also skip the location update procedure in order to save time.

Non-signalling mode

This mode serves for generating a signal with GSM-specific midambles and modulation in the entire frequency range from 10 MHz to 2.7 GHz. The analyzer offers the same flexibility for GSM-specific transmitter measurements such as

◆ modulation analysis

◆ average and peak burst power

◆ power versus time, power versus slot,

power versus frame

◆ spectrum due to switching /modula-

tion

GSM development

As an all-round tool for GSM development engineers, the CMU 200 is an unsurpassed solution. The RF interface provides four input and output connectors offering a wide range of signal levels for generation and analysis of RF signals. Input only, as well as combined input/ output connectors, can analyze mobiles or modules with a sensitivity down to dBm and up to +47 dBm for the power meter. RF signals can be generated with levels from depending on the selected connector. All measurement tolerances are set by default according to the GSM 11.10 and GSM 05.05 recommendations but may of course be altered to suit individual needs.

−130 dBm up to +13 dBm,

−80

Production of mobile phones

Production is a process that calls for cost effectiveness. The CMU200 concept is optimized for IEC/IEEE-bus speed, measurement accuracy and reproducibility as well as cost of ownership. Thanks to the multitasking feature and parallel measurements, previously unobtainable test times can be achieved.

The ability to process BER data and perform transmitter measurements at the same time, allows phase / frequency error, power versus time and average power (PCL accuracy) to be measured during the time-consuming receiver test.

The accuracy and reproducibility ensure correct and steady measurement results and thus contribute to the quality and reliability of the end product.

GSM Evolution – 2.5G

The amount of data transfer in GSM networks is growing rapidly. Multislot applications such as HSCSD or GPRS together with the innovative 8 PSK modulation scheme EDGE are needed to cater for the evolving data traffic. The CMU200 platform is not only able to meet today’s standards and systems but is also designed for the needs of tomorrow.

Multislot

In the future, mobile phones will be able to use several timeslots simultaneously for data transmission and reception to further increase the data rate. The simultaneous transmission and reception of several timeslots (multislot) is the technological

challenge for circuit-switched and packet-switched applications. The following extensions of the GSM single-slot measurements enable maximum flexibility in development, and, due to minimum measurement times, maximum throughput in production.

◆ Individual levels for all time-

slots used in the down link (DL). The CMU generates up to eight timeslots per frame in the down link; each timeslot can be assigned a separate level. The excellent level stability of the CMU200 generators is not impaired by multislot transmission using different levels, and allows the most accurate measurements of receiver sensitivity (BER/DBLER).

◆ Transmitter and receiver meas-

urements are possible on every timeslot used. The new multislot concept allows independent measurements on any timeslot (TS 0-7) and thus covers the current and future multislot combinations without restrictions.

◆ Power-versus-time measure-

ment (graphical display) for up to four timeslots in the UL. The templates of this application are evaluated independently for each timeslot - in line with standards and according to recommendations. Both GMSK- and 8PSK-modulated signals are recognized, and the templates of the relevant

timeslot are set in realtime. Multislot measurements are required for HSCSD and ECSD technologies as well as for GPRS and EGPRS.

GSM-specific

non-signalling test provides generation and analy-

sis of RF signals

for testing of RX/

TX modules or mobiles in service

mode

The overview

menu provides fast comprehensive information

on the mobile’s

RF performance.

The hotkeys at the

bottom of the

screen give

immediate access

to specific and

detailed GSM

measurements

In the GSM non signalling func-

tion groups the

possibility to

switch between

GMSK and 8PSK

(EDGE) is already

implemented.

Thus EDGE bursts

as shown here

can easily be ana-

lyzed

Universal Radio Communication Tester CMU200 9

8PSK modulation – EDGE

8PSK is besides multislot a further step towards increasing the mobile radio data rate. By using the available GSM frame structure, the gross data rate is three times that obtained with GMSK. The CMU200 can already perform 8PSK on GSM bursts and analyze them thanks to advanced measurement applications. Error vector magnitude and magnitude error have been added to the range of modulation measurements. New templates for power-versus-time measurements ensure compliance with the specifications, as do the modified tolerances for spectrum measurements. 8PSK will transform HSCSD technologies into ECSD and GPRS into EGPRS. As with all measurements provided by the CMU200, special attention has been given to achieving maximum measurement accuracy and speed for EDGE too.

GPRS/EGPRS

Thanks to the new, future-oriented method of packet data transmission, the radio resources of existing GSM mobile radio networks can be utilized efficiently for data services. As with circuit-switched services, GPRS will also use a combina-

In the 8PSK mode the modulation analysis is subdivided. The error vector magnitude, the magnitude error and the phase error can be displayed both numerical as shown above, or graphical.

tion of several timeslots (multislots) and higher-level modulation in the form of 8PSK (EGPRS) to push up the data rate. The introduction of packet-oriented transmission and the associated temporary assignment of radio resources require new test concepts. The CMU 200 provides the following test modes:

◆ ETSI Test Mode A: In test mode A, the

mobile is induced to continuously transmit the associated UL timeslots. The CMU 200 can carry out all TX

power ramp measurement of up to four adjacent timeslots simultaneously, or modulation and spectrum measurements.

◆ ETSI Test Mode B: Test mode B cre-

ates a loop back in the telephone so that the mobile retransmits data blocks received from the CMU 200. In addition to the measurments available in the ETSI test mode A, test mode B enables bit and block error rate measurements (BER/DBLER).

measurements available, such as the

GSM specifications – Mobile station test

RF generator

Modulation GMSK, BxT = 0.3

Frequency range

GSM 400 band 460 MHz to 468 MHz / 488 MHz to 496 MHz GSM850 band 869 MHz to 894 MHz GSM900 band 921 MHz to 960 MHz GSM1800 band 1805 MHz to 1880 MHz GSM1900 band 1930 MHz to 1990 MHz

Attenuation of inband spurious emissions

Inherent phase error (GMSK)

Inherent EVM (8PSK)<2%, rms

Frequency settling time

Output level range (GMSK)

RF1 RF2 RF3OUT

10 Universal Radio Communication Tester CMU200

8PSK

>50 dB

<1°, rms <4°, peak

<500 µs to res. phase of 4°

−130 dBm to −27 dBm

−130 dBm to −10 dBm

−90 dBm to +13 dBm

Output level range (8PSK)

RF1 RF2 RF3OUT

Output level resolution 0.1 dB

Output level uncertainty

RF1, RF2

>–117 dBm

RF3OUT

−90 dBm to +10 dBm (GMSK)

−90 dBm to +6 dBm (8PSK)

−130 dBm to −31 dBm

−130 dBm to −14 dBm

−90 dBm to +9 dBm

+23°C to +35°C

<0.5 dB <0.7 dB

<0.7 dB <0.9 dB

+5°C to +45°C

RF analyzer

Frequency range

GSM 400 band 450 MHz to 458 MHz / 478 MHz to 486 MHz GSM850 band 824 MHz to 849 MHz GSM900 band 876 MHz to 915 MHz GSM1800 band 1710 MHz to 1785 MHz GSM1900 band 1850 MHz to 1910 MHz

Measurement bandwidth

in measurement menus 500 kHz

The Power-versus-Time Multislot application can graphically display up to 4 adjacent timeslots, automatically detects GMSK- and 8PSK-modulated signals and activates the associated templates in realtime. A new zoom function allows full-screen display of each slot.

Reduced signalling synchronized mode

Extremely fast adjustment and testing of RF parameters during GPRS mobile phone production is ensured by deactivating the GPRS protocol stack. Without using the higher protocol layer (RLC/MAC layer), the CMU 200 synchronizes the mobile (camping), the data channel (PDCH) is then set up directly.

The GPRS and EGPRS data coders are already available to determine Bit Error Rates (BER) and Data Block Error Rates (DBLER).

GSM highlights of CMU200

Benchmark-breaking IEEE-bus speed due to

◆ Parallel measurements

◆ Secondary addressing

◆ Optimized processing power

High flexibility for R&D

◆ Assignment on up to 8 DL slots (TS 0 to 7)

◆

Tx/Rx on any transmit slot

◆

Individual level generation on any used DL slot

GMSK/8PSK Measurements

◆ Phase/frequency error, EVM, magnitude

error, origin offset, I/Q imbalance for I/Q modulator tuning

◆ Power vs time

◆ On up to 4 UL slots

◆ normal/access

◆ Peak power/average, power vs frame,

power vs slot

◆ General spectrum measurements

◆ Timing error

◆ BER/DBLER, RBER/FER, FastBER

◆ Power vs PCL (on 3 or 7 channels)

Power meter (frequency-selective)

Level range

RF1

continuous power Peak Envelope Power

RF2

continuous power Peak Envelope Power

RF4IN (continuous power and PEP)

Level uncertainty

RF1, RF2, RF4IN

in temperature range +23°C to +35 °C in temperature range +5°C to +45 °C

Level resolution 0.1 dB (0.01 dB via remote control)

(PEP) +53 dBm (200 W)

(PEP) +39 dBm (8 W)

−40 dBm to +47 dBm (50 W)

−54 dBm to +33 dBm (2 W)

−80 dBm to 0 dBm

<0.5 dB <0.7 dB

Modulation analysis

Level range (PEP)

RF1

RF2 RF4IN

50 W from +5 °C to +3 0 °C, line ar de grad atio n dow n to 2 5 W at 45 °C.

Mean value of power vs time must be equal or less than allowed continuous power.

−6 dBm to +53 dBm

−20 dBm to +39 dBm

−60 dBm to 0 dBm

Inherent phase error (GMSK) <0.6°, rms

Inherent EVM (8PSK) <1,0 %, rms

Frequency measurement uncertainty

<2°, peak

≤10 Hz + drift of time base

Burst power measurement

Reference level for full dynamic range (GMSK, low noise mode)

RF1

RF2 RF4IN Dynamic range (GMSK) >72 dB (BW=500 kHz, rms)

Reference level for full dynamic range (8PSK, low noise mode)

RF1

RF2 RF4IN Dynamic range >69 dB (BW = 500 kHz, rms)

Relative measurement uncertainty

> −40 dB <0.1 dB

Result

−60 dB ≤result≤−40 dB <0.5 dB

Resolution 0.1 dB in active part of burst

+10 dBm to +53 dBm

−4 dBm to +39 dBm

−22 dBm to 0 dBm

+6 dBm to +49 dBm

−8 dBm to +35 dBm

−26 dBm to –4 dBm

Universal Radio Communication Tester CMU200 11

TDMA in CMU200

CMU200 does it all. The TDMA part takes care of your requirements to cope with this fast progressing mobile technology. The CMU200 concept with its multistandard platform architecture provides for further extensions such as Bluetooth and cdma2000.

TDMA

The wide acceptance of TDMA (IS-136) is based on a very flexible and powerful technology as well as on its compatibility with AMPS, which is widespread and one of the major wireless communication standards. Derived from analog AMPS, the TDMA standard is now ready for a step-by-step evolution into the third generation of mobile technology. This fact shows the need for a test instrument that is flexible enough to cover all future needs as well as the current standards.

For TDMA (IS-136) signalling functionality, the CMU200 requires the versatile signalling unit (CMU-B21) as well as the software option CMU-K27 for the cellular band or CMU-K28 for the PCS band.

Due to the highly user-friendly menu concept, the CMU200 provides quick access to all measurements desired, optimizing handling and consequently efficiency.

Signalling mode

The CMU200 simulates a TDMA basestation RF interface including the signalling protocol so that a mobile can be tested with regard to different signalling parameters. All necessary network and base-station parameters can be set, such as control and traffic channel configuration, neighbouring channels setup etc. You can also generate a MAHO report.

Non-signalling mode

The non-signalling mode is for generating and analyzing TDMA (IS-136) signals within the frequency range from 10 MHz to 2.7 GHz. CMU200 provides TDMA-specific measurements such as:

◆ Power

◆ Modulation

◆ Spectrum

◆ Power versus time

◆ BER

TDMA (IS-136) development

With its great versatility the CMU 200 is the most suitable tool for the development of mobile phones. Four configurable RF connectors are provided to enable flexible signal generation and analysis. The power meter can evaluate signals within a range from 47 dBm, whereas the generator outputs signals from

−130 dBm to +13 dBm. The clearly struc-

tured and user-friendly menu design together with the clear-cut screen layout provides quick access to all features and ensures trouble-free monitoring of the device under test.

−80 dBm to+

Quality assurance

Due to its high measurement repeatability and accuracy, the CMU200 is the right choice to ensure a consistently high quality standard from production. TDMAspecific measurements such as BER, Error Vector Magnitude (EVM) and EVM10, where only the first 10 symbols are taken into account, provide an excellent test platform to guarantee the production of high-quality devices.

Production of mobile phones

The production of mobile phones requires time-efficient and cost-effective means that ensure both high throughput and state-of-the-art accuracy. Thanks to the unique IEC/IEEE-bus concept of the CMU200, these two goals can be easily achieved in your production line. The intelligent handling of the received GPIB commands optimizes the measurement speed for all TDMA-specific measurements. In practice, this will mean drastically enhanced test time and test yield.

Acoustic Measurements

The newly implemented ACELP speech coder is able to encode and decode real audio signals and allows you to use the CMU200 also in real acoustic measurement applications. Equivalent to the GSM implementation of the CMU200 the TDMA speech coder provides analog inputs and outputs and a connector for an external handset. The speech coder requires the hardware option CMU-B52 and can also be combined with the internal Audio Analyzer/Generator option CMU-B41.

12 Universal Radio Communication Tester CMU200

The mobile reports the

received signal strength

(RSSI) of the observed

channels back to the CMU

where the RSSI is displayed in the MAHO report list. It is possible to config-

ure the neighbouring channels in the network setup. The reported BER

can also be monitored

In the modulation menu it

is possible to measure the

phase error, frequency

error and the error vector

magnitude. The mesure-

ments results are dis-

played graphically. Addi-

tional measurements such

as amplitude droop and

timing error are taken as

well and displayed numer-

ically in the same screen

In the power menu, the

mobile output power of the

short burst or the normal

burst is displayed. CMU

also enables leakage

power measurements

which inform on the

mobile power output in

unused time slots

Universal Radio Communication Tester CMU200 13

TDMA in CMU200

Handoffs

Handoffs are part of the IS-136 specification. Handoffs between PCS and cellular bands as well as from and to AMPS are defined and have to be tested. CMU200 supports handoffs from IS-136 800 MHz to 1900 MHz (inter-band handoff) and vice versa. Handoffs from 1900 MHz or 800 MHz to AMPS and back are also possible (inter-mode handoff) with CMU200.

Switching standards

The flexibility of CMU200 makes for quick and simple switching between two different standards. This is very important for IS-136, which is a dual-mode standard containing a digital (TDMA) and an analog mode (AMPS). The handoff between TDMA and AMPS can be achieved by simply pressing a button. This results in a very versatile test concept to improve the flexibility and throughput of your production line.

In the modulation overview menu, error vector magnitude (EVM), phase error and magnitude error are measured simultaneously and displayed in a numerical table It is possible to choose either EVM, where the whole burst is considered, or EVM10, where only the first ten symbols are taken into account

TDMA specifications – Mobile station test

RF generator

Frequency range signalling mode

US Cellular 869 MHz to 894 MHz PCS (US) 1930 MHz to 1990 MHz

Frequency range non-signalling mode 10 MHz to 2200 MHz

Frequency resolution 1 Hz

Frequency uncertainty same as time base

Output level range

RF1 RF2 RF3OUT −90 dBm to +8 dBm

Output level resolution 0.1 dB

Output level uncertainty see CMU200 base unit

14 Universal Radio Communication Tester CMU200

−130 dBm to −32 dBm

−130 dBm to −15 dBm

Modulation

π/4 DQPSK or unmodulated (non-signalling mode)

Uncertainty <2.5% (EVM rms) Carrier suppression

>40 dB

RF analyzer

Frequency range signalling mode

US Cellular 824 MHz to 849 MHz PCS (US) 1850 MHz to 1910 MHz

Frequency range non-signalling mode 10 MHz to 2200 MHz

Frequency resolution 1 Hz

Frequency uncertainty same as time base

Modulation analyzer

824 MHz to 849 MHz and 1850 MHz to 1910 MHz EVM, rms (residual) EVM, peak (residual) I/Q offset (residual) I/Q imbalance (residual) <–50 dB (0.3%) Frequency measurement range Frequency measurement error

<2% <4% <–50 dB (0.3%)

−2 kHz to +2 kHz ≤5 Hz + drift of time base

TDMA highlights of CMU200

Basic features

◆ Call to / from mobile

◆ Handoff to AMPS

◆ Dual-band handoff

Signalling measurements

◆ MAHO report

◆ Power versus time

–Short burst –Normal burst

◆ Modulation

–Phase error –Magnitude error – EVM/EVM10 – Overview of phase / magnitude and

EVM simultaneously

◆ Spectrum

– Adjacent channel power due to

switching/due to modulation

◆ Overview

– Signalling information

Handoffs from cellular band (800 MHz) to PCS band (1900 MHz) can be tested as well as to and from AMPS. Before handing off to a new network the parameters for the target network can be set. This results in a large variety of different test scenarios

Power meter (frequency-selective)

Level uncertainty see CMU200 base unit

Power versus time measurement

Reference level for full dynamic range (low noise mode)

RF1 +4 dBm to +47 dBm RF2 RF4IN Dynamic range >74 dB (BW=100 kHz, rms)

Relative measurement uncertainty

Result >

−40 dB <0.1 dB

−60 dB≤ Result ≤−40 dB <0.5 dB

Residual leakage power level

Adjacent channel power measurement

Dynamic range

1st adjacent channel 2nd and 3rd adjacent channel

−10 dBm to +33 dBm

−28 dBm to −6 dBm

<−65 dBm

>45 dB >55 dB

Non-signalling measurements

◆ Modulation

◆ Spectrum

◆ Power versus time

◆ BER

Universal Radio Communication Tester CMU200 15

AMPS in CMU200

AMPS overview

Analog AMPS (advanced mobile phone system) is a standard system for analog cellular telephone service in the United States and is also used in other countries. It is based on the frequency spectrum allocation for cellular service by the Federal Communications Commission (FCC) in 1970. Introduced by AT&T in 1983, AMPS became the most widely deployed cellular system in the United States.

AMPS options

Although AMPS is a 1st generation analog standard, a great demand for mobile radio testers covering this standard will continue to exist in the future. Especially in the United States, dual-mode CDMA/ AMPS and TDMA/AMPS phones are very common. By combining the digital standards with analog AMPS, the network operators offer their customers the advantages of the digital standards and ensure nearly 100% coverage in North America. As a consequence, Rohde& Schwarz is extending the range of CMU200 options by introducing analog AMPS in addition to the digital standards TDMA and CDMA. These options add analog AMPS functionality to the CMU200 base unit:

◆ CMU-B21 (versatile link handler)

◆ CMU-B41 (audio generator/analyzer)

◆ CMU-K29 (AMPS test software)

The hardware options CMU-B21 (versatile link handler) and CMU-B41 (audio generator/analyzer) are suited for other standards as well.

AMPS measurements and features

As for other standards, there are two categories of AMPS measurements:

◆ Transmitter tests for assessing the

transmit part of a mobile

◆ Receiver tests for assessing the

receive part of a mobile

◆ AF Level Search routine

◆ Sensitivity Search routine

The AF Level Search routine in the TX test menu allows the user to set the desired frequency deviation of the mobile transmitter at a keystroke, the level of the CMU200 modulation generator is automatically corrected.

The Sensitivity Search routine in the RX test menu automatically searches the receiver input level at which a selectable SINAD of the demodulated signal can still be attained. The following list provides an overview of the most important tests implemented in option CMU-K29.

AMPS specifications – Mobile station test

RF Generator

Frequency range signalling mode

US Cellular 869 MHz to 894 MHz

Frequency range non-signalling mode 10 MHz to 2200 MHz

Frequency resolution 1 Hz

Frequency uncertainty same as time base

Output level range

RF1 RF2 RF3OUT

Output level resolution 0.1 dB

Output level uncertainty see CMU200 base unit

Modulation

FM deviation range 100 Hz to 20 kHz FM resolution 1 Hz AF range 100 Hz to 15.999 kHz

Transmitter measurements

◆ Carrier power

◆ Carrier frequency error

◆ SAT frequency error/peak deviation

◆ ST frequency error/peak deviation

◆ Modulation noise and distortion

◆ Hum and noise

◆ Electrical audio frequency response

◆ Modulation distortion

◆ Residual AM

Receiver measurements

◆ Sensitivity

◆ Hum and noise

◆ SINAD

◆ Distortion

◆ AF voltage

◆ Electrical audio frequency response

◆ Residual AM

◆ Audio deviation

−130 dBm to −27 dBm

−130 dBm to −10 dBm

−90 dBm to +13 dBm

(add 0.1 dB)

16 Universal Radio Communication Tester CMU200

TX audio frequency response measurement. The pre-emphasis characteristic of the mobile transmitter is verified by a single-shot measurement

All the filters required for the measurements are of course preconfigured in line with specifications, but their settings can be modified for individual measurements. The RX and TX electrical audio frequency response measurements in AMPS are usually defined as frequency sweep ver-

alternative. Using the TX and RX audio frequency response menus of CMU200, the AF frequency response is measured simultaneously at 20 test points with user-programmable level and frequency and then checked against specified toler-

ances (see screenshot above). sus AF frequency range. The CMU 200 offers a much faster and more modern

AMPS highlights of CMU200

Benefits of base unit

◆ Platform supporting CDMA, TDMA and

AMPS within one box

◆ Wide frequency range allowing dual

mode/dual band testing required for CDMA and TDMA

◆ See base unit section

AMPS features

◆ Powerful signalling capabilities

◆ Base station simulation

◆ Mobile or base station originated call

connect/disconnect

◆ Short measurement time ensuring high

throughput

◆ Combined measurements

◆ Benchmark-breaking IEEE-bus speed

(see GSM highlights)

◆ Simple interactive operation, standard-

ized MMI

◆ No specialized network knowledge

required

◆ Various handoffs from CDMA/TDMA and

to TDMA supported

FM distortion (SINAD; dev. 8 kHz, AF 1 kHz, BW 30 Hz to 15 kHz) Residual FM (rms, BW 300 Hz to 3 kHz) Deviation uncertainty at 1kHz AF, 8kHz dev.(measurement bandwidth 30 Hz to 15 kHz) <2 % of setting + residual FM Deviation frequency response at 300 Hz to 15.999 kHz AF

≥40 dB

≤10 Hz

≤1 dB

RF analyzer

Frequency range signalling mode

US Cellular 824 MHz to 849 MHz

Frequency range non-signalling mode 10 MHz to 2200 MHz

Frequency resolution 1 Hz

Frequency uncertainty same as time base

Power meter (frequency-selective)

Reference Level Range

RF1 0 dBm to +53 dBm RF2 RF4IN

Level uncertainty see CMU200 base unit Level resolution 0.1 dB

−14 dBm to +39 dBm

−37 dBm to 0 dBm

FM measurement

Dynamic range 30 dB below reference level RF bandwidth

(2 x deviation + 4 x AF) 136 kHz

Deviation range 0 kHz to 47 kHz Resolution 1 Hz AF range 100 Hz to 18 kHz Residual FM

BW 300 Hz to 3 kHz, rms

BW 6 Hz to 20 kHz, rms Uncertainty (BW 6 Hz to 20 kHz) <1% of reading + residual FM Carrier frequency error measurement range Carrier frequency error measurement uncertainty

≤5 Hz ≤18 Hz

−47 kHz to +47 kHz

≤2 kHz + drift of time base

AF generator

see CMU200 base unit (Audio option CMU-B41)

AF analyzer

see CMU200 base unit (Audio option CMU-B41)

Universal Radio Communication Tester CMU200 17

cdmaOne in CMU200

CDMA overview

Code division multiple access (CDMA) – once a radically new concept in wireless communication – has meanwhile become a well established standard in the world of mobile communication. CDMA has proven its advantages and capabilities and has gained widespread international acceptance.

Instead of using frequencies or timeslots as traditional technologies like TDMA and AMPS do, CDMA uses mathematical codes to transmit and distinguish between multiple wireless conversations. Depending on the level of mobility, CDMA provides 8 to 10 times the capacity of AMPS and 4 to 5 times the capacity of TDMA systems. CDMA can efficiently utilize the spectrum and serve many subscribers without requiring extensive frequency planning.

History

Since the startup of the first commercial CDMA network in Hong Kong in September 1995 CDMA has established itself as a worldwide mobile radio standard. It has not only been successful in its country of origin, the USA, as well as in Korea and Japan, but all over the world. With its still booming growth rates CDMA today is – besides GSM – one of the most important digital 2nd generation mobile radio standards. CDMA is therefore also suited as the leading-edge technology on the way to 3rd generation mobile radio.

cdmaOne options

Taking the current development on the market into account, Rohde& Schwarz has extended the proven modular concept of the CMU200 with cdmaOne functionality. The following options make the CMU 200 a compact radio communication tester for all TIA/EIA-95-based cdmaOne mobile phones:

◆ CMU-B81 (cdmaOne signalling unit)

◆ CMU-K81 (cdmaOne test software for

cellular band)

◆ CMU-K82 (cdmaOne test software for

PCS band)

CMU 200 is also the first choice as a tester for cdmaOne – especially in harsh production environments – because of its outstanding measurement speed, ultrahigh accuracy and unrivalled reliability which is also a result of the innovative ventilation concept. Thanks to the modular concept of CMU200, cdmaOne functionality plus GSM, TDMA (TIA/EIA-136), AMPS and other standards such as Blue- tooth can be implemented in a single unit. Which other radio communication tester can boast such superior features?

cdmaOne functionality

In cdmaOne mode, the tests are based on the TIA/EIA-95A, TSB-74, and J-STD-008 cdmaOne airlink standards. In addition, the cdmaOne option supports also the standards ARIB-T53 and Korean PCS. The tester emulates a code division multiple access base station, makes a call to the mobile, and tests all essential parameters of a cdmaOne mobile station. The tester can measure the following key parameters among other tests:

◆ Power measurements:

– Open-loop time response – Gated output power – Minimum output power –Maximum output power – Side band suppression

◆ Receiver quality measurements:

– Frame error rate (FER) – With additional AWGN generator

to simulate noise caused by other cdmaOne calls at the same frequency

– Predefined configurations for sen-

sitivity and dynamic range

◆ Transmitter quality measurements:

–Waveform quality – Error vector magnitude –Phase error –Magnitude error – Carrier feed through and

I/Q imbalance

– Frequency accuracy

◆ Handoffs:

–RF channel –CDMA inter band – Handoff to AMPS – PN offset – Frame offset

◆ Non signalling Measurements:

–Power –Waveform quality – Frequency error – Carrier feed through – I/Q imbalance

All measurements are implemented according to test specification IS-98C. Parameters and limits are predefined to meet the IS-98C test requirements. This allows easy pass/fail decisions without the need of reconfiguring the test setup.

Graphical representation of transmitter measurements like open loop time response, gated output power and modulation measurements are helpful tools especially in R&D environments.

18 Universal Radio Communication Tester CMU200

Open-loop time response

The open-loop power con-

trol test shows the

response of the mobile sta-

tion to an increase or

decrease in base-station

total power. The default

increase or decrease for

this test is 20 dB. Power

stepping and cdmaOne

levels are user-definable

Gated output power

The gated output power

can be displayed in several

formats. Select FULL DIS-

PLAY to show the total

period of the IS-98 gated

output template. The

period of the full display is

approx. 1500 µs. Select

RISING EDGE (see figure)

or FALLING EDGE to zoom

in to display the 17 ms period of the rising or falling edge of the waveform.

In each of these displays, a MARKER may be activated

to display both power

amplitude and relative

time

Modulation measure-

ments: magnitude error

Modulation measurements

serve for assessing the

quality of the mobile’s

transmit part. In addition

to phase error, error vector

magnitude and magnitude

error can be shown graph-

ically at the push of a but-

ton. A clearly arranged

table lists carrier

feedthrough, IQ imbal-

ance, frequency error and

waveform quality with cur-

rent measurement results,

average and minimum/

maximum values

Universal Radio Communication Tester CMU200 19

cdmaOne in CMU200

CDMA know-how

Rohde&Schwarz is not a newcomer in the field of CDMA, but has many years of experience. As early as 1996 Rohde& Schwarz and Tektronix launched a professional radio tester for CDMA mobiles. Worldwide this extremely successful tester sold thousands of units and has undergone permanent enhancement and adaptation to remain state-of-the-art. CMU200 builds on this success and is able to perform cdmaOne mobile station tests using thoroughly proven test and measurement methods, and also offers the possibility of enhancements for future technologies

CMU200 offers a separate menu for handoffs. In addition to handoff targets such as operating status or network to which CMU200 is to switch, the required target parameters as for example channel number etc can be configured. This enables handoff to AMPS as well as handoff to and from the voice loopback mode

cdmaOne specifications – Mobile station test

Standards

cdmaOne standards TIA/EIA-95, J-STD-008, ARIB T53,

cdmaOne test standards TIA/EIA-98, J-STD-018

RF generator

Frequency range

Option CMU-K81

US Cellular 869 MHz to 894 MHz China Cellular 934 MHz to 969 MHz Japan Cellular 832 MHz to 870 MHz

Option CMU-K82

PCS (US) 1930 MHz to 1990 MHz PCS (Korea) 1805 MHz to 1870 MHz

Frequency resolution channel spacing according to standard

Frequency uncertainty same as time base

Output level range (modulated signal)

RF1 –120 dBm to –33 dBm RF2 –120 dBm to –16 dBm RF3OUT –80 dBm to +7 dBm

Output level resolution (modulated signal) 0.1 dB

20 Universal Radio Communication Tester CMU200

Korean, Chinese

Output level uncertainty

+23°C to +35°C

RF1, RF2:

≥ –108 dBm

RF3OUT: –80 dBm to +4 dBm <0.7 dB <0.9 dB

Modulation

QPSK, multiple QPSK 1.2288 Mcps AWGN see AW GN generator Carrier suppression >35 dB Waveform quality factor (

AWGN generator

Selectable bandwidth 1.23 MHz or 1.8 MHz Output level resolution 0.1 dB

ρ)>0.99

<0.5 dB <0.7 dB

+5°C to +45°C

RF analyzer

Frequency range

Option CMU-K81

US Cellular 824 MHz to 849 MHz China Cellular 889 MHz to 924 MHz Japan Cellular 887 MHz to 925 MHz

Option CMU-K82

PCS (US) 1850 MHz to 1910 MHz PCS (Korea) 1715 MHz to 1780 MHz

Measurement filter according to standard (1.23 MHz bandwidth)

The overview menu shows the most important parameters in a clear form. These include BS settings as well as MS test results such as power, frequency error and waveform quality. The overview menu also gives access to other test modules (power control, modulation, receiver quality)

cdmaOne highlights of CMU200

◆ Voice loopback and comprehensive test-

ing of mobiles

◆ Powerful signalling capabilities

◆ Built-in AWGN generator for simulating

noise generated by other cdmaOne calls

◆ Base station simulation

◆ Mobile or base station originated call

connect/disconnect

◆ Short measurement time ensuring high

throughput

◆ Combined measurements

(RX/TX in parallel)

◆ Benchmark-breaking IEEE-bus speed

(see GSM highlights)

◆ Simple interactive operation, standard-

ized MMI

◆ No specialized network knowledge

required

◆ Various handoffs supported

(e.g. cdmaOne to analog AMPS)

◆ Dual-band/dual-mode testing

◆ Signalling and non-signalling mode

Frequency resolution channel spacing according to standard

Level range (O-QPSK signal)

RF1 –40 dBm to +47 dBm RF2 –54 dBm to +33 dBm RF4IN –80 dBm to –6 dBm

Power meter (frequency-selective)

Level uncertainty

RF1, RF2, RF4IN

in temperature range +23°C to +35°C <0.5 dB in temperature range +5°C to +45°C <0.7 dB

Level resolution 0.1 dB

Modulation analyzer

ρ uncertainty (for ρ 0.9 to 1) <0.003

Frequency measurement range –3 kHz to +3 kHz Frequency measurement uncertainty Timing measurement uncertainty <60 ns

≤30 Hz + drift of timebase

Supported CDMA standards

Frequency band Airlink standard

US Cellular (800 MHz) TIA/EIA-95

Japan Cellular ARIB-T53/-95

China Cellular TIA/EIA-95

US PCS (1900 MHz)

Korea PCS (1800 MHz) J-STD008, UB-IS-95

Universal Radio Communication Tester CMU200 21

ANSI-J-STD008, UB-IS-95

CDMA2000-1X im CMU

CDMA2000 overview

CDMA2000 arose from the further development of cdmaOne (TIA/EIA-95) and is an enormous step towards 3G. Besides higher data rates and considerably improved efficiency, CDMA2000 is particularly noteworthy for its downward compatibility to cdmaOne. Nine different configurations (radio configurations RC1 to RC9) in the forward link and six radio configurations in the reverse link define the different connections which are specified in the IS-2000 standard.

◆ RC1 and RC2 define cdmaOne con-

nections for rate set 1 and rate set 2

◆ RC3 to RC5 in the forward link (or RC3

to RC4 in the reverse link) define CDMA2000 connections for spreading rate 1 (CDMA2000-1X)

◆ RC6 to RC9 in the forward link (or RC5

to RC6 in the reverse link) are CDMA2000 connections for spreading rate 3 (CDMA2000-3X) only.

Compared to cdmaOne, CDMA2000-1X doubles the capacity for pure voice transmission and provides a maximum packet data rate of 307 kps on a single 1.25 MHz carrier. CDMA2000-1X is a recognized IMT-2000 3G standard, already successfully established in Korea – and will soon be implemented in Japan, the USA, Canada, Mexico and Brazil. Its application in Eastern Europe is planned as well.

CMU CDMA2000-1X options:

The CDMA2000 standards will be implemented in conjunction with our proven cooperation partner Tektronix. By supporting the CDMA2000 standard, Rohde&Schwarz consequently enhances the functionality of the CMU200 multimode platform.

The central component of the CDMA2000-1X option is the signalling Unit CMU-B83, which is a prerequisite for enhancing the CDMA2000-1X functionality in the CMU200. The CMU-B83 is designed for maximum conformity to the standard. The CMU-B83, of course, does not only support pure CDMA2000-1X high-speed data links, but also enables the links of the previous TIA/EIA-95A/B standards.

All tests, which could be performed with the cdmaOne option in conjunction with the CMU-B81, are also available in the new CDMA2000 option. The CMU-U83 upgrade option is a cost-efficient upgrade solution from Rohde&Schwarz for customers who have already acquired the cdmaOne option in the CMU200.

CDMA2000-1X is used in diverse frequency ranges. The standard currently prescribes ten different band classes all of which are supported by the CMU200 with its universal hardware concept.

The following options are available for the CDMA2000-1X:

◆ CMU-B83: CDMA2000 signalling unit

(essential)

◆ CMU-U83: cost-efficient hardware

upgrade from CMU-B81 to CMU-B83

◆ CMU-U65: 3G DDC (additional DSP for

the digital board, essential)

◆ CMU-K83: CDMA2000-1X software

for the 450 MHz band (band class 5)

◆ CMU-K84: CDMA2000-1X software

for cellular bands

◆ CMU-K85: CDMA2000-1X software

for PCS bands

◆ CMU-K86: CDMA2000-1X software

for IMT2000 band (band class 6)

The universal hardware and software concept of the CMU200 represents the optimum solution for the future development and challenges of the CDMA standard over the next few years.

CDMA2000-1X functionality

The similarities with cdmaOne (same physical conditions and downward compatibility), makes the CDMA2000-1X T&M concept very similar to that of cdmaOne. There are, however, major differences as to the protocols.

The CMU200 supports connections in all radio configurations defined for the CDMA2000-1X, i.e. TIA/EIA-95 combinations as well as the usual CDMA2000-1X high-speed connections.

Code Domain Power is a new and highly important measurement for mobile phones in CDMA2000. Since several code channels are now transmitted simultaneously in the reverse link, it is necessary to check whether the power distribution of the different channels complies with the test specification (TIA/EIA-IS-98-D) for CDMA2000. The measurement technology in the CMU200 is based on the ProbeDSP high-speed measurement of the code domain power. The emphasis is on fast measurement technology and clear and concise representation.

Of course, the CMU200 also supports the requirements placed on the gpsOne test application; the CMU200 meets the high demands for frequency and phase accuracy.

The CDMA2000-1X implementation in the CMU200 is based on the TIA/EIA IS-2000 Rev. 0 standard; the measurements comply with the TIA/EIA IS-98-D standard.

technology, which permits

22 Universal Radio Communication Tester CMU200

The CMU200 currently supports the service options 2, 9, (loopback service options) and 1, 3, 17, 0x8000 (speech service options).

All relevant base station parameters and

connection

settings can be configured in user-friendly menus.

As with all mobile radio networks supported by the CMU 200, two different measurement modes are basically available:

On the one hand, there are tests in the “non-signalling-mode”, which permit an analysis of the mobile without registration in the base station and without actual call setup. For this purpose, the CMU generates a base station signal with all the physical channels required, which are user-configurable. This measurement mode complies in particular with the demands for high measurement speed in production lines.

CDMA2000 Connection

Control

CDMA2000 Connection Control Service Configu-

ration

On the other hand, there are tests with complete signalling.

CDMA2000 Modulation

Measurements

Universal Radio Communication Tester CMU200 23

Signalling mode

The following describes the range of functions in detail:

◆ Power measurements

◆ Minimum/maximum output power

◆ Gated output power

◆ Receiver quality measurements

◆ Frame error rate (FER)

Dynamic range, sensitivity and other user-settable test environments

◆ Modulation (both RC1/2 and RC3/4)

◆ Error vector magnitude (EVM), magni-

tude error, phase error, waveform quality, carrier feedthrough, frequency error

◆ Code domain power, peak code do-

main error power, channel power

◆ Implicit handoffs (RF channel, Walsh

code, PN offset, frame offset)

◆ Interband handoff

◆ Handoff to AMPS

◆ Sideband suppression

All relevant TX parameters such as power, frequency error, waveform quality (both for RC1/2 and RC3/4) as well as sideband suppression, reported pilot power and frame error rate (FER)

Non-Signalling

◆ Carrier feedthrough

◆ Transmit time error

◆ High-speed power measurement

◆ Sideband suppression

◆ Frequency error

◆ Waveform quality (both RC1/2 and

RC3/4)

CDMA2000 specifications – Mobile Station Test

Standards

CDMA2000 standards: TIA/EIA IS-2000 Rev. 0 CDMA2000 test standards: TIA/EIA IS-98-D

RF generator

Frequency range

Option CMU-K83:

NMT-450 (band class 5) 421.675 MHz to 494.480 MHz

Option CMU-K84:

US/Korean cellular (band class 0) 869.025 MHz to 893.985 MHz TACS band (band class 2) 917.0125 MHz to 959.9875 MHz JTACS band (band class 3) 832.0125 MHz to 869.9875 MHz North American 700 MHz cellular band (band class 7) 746.000 MHz to 764.000 MHz 900 MHz band (band class 9) 925.000 MHz to 958.750 MHz Secondary 800 MHz Band (band class 10) 851.000 MHz to 939.975 MHz

Option CMU-K85:

North American PCS (band class 1) 1930 MHz to 1990 MHz Korean PCS (band class 4) 1840 MHz to 1870 MHz 1800 MHz Band (band class 8) 1805.000 MHz to 1879.950 MHz

Option CMU-K86:

IMT-2000 (band class 6) 2110.000 MHz to 2169.950 MHz

Frequency resolution Channel spacing according to standard

Frequency uncertainty same as time base

Output level range (modulated signal)

RF1 –120 dBm to –33 dBm RF2 –120 dBm to –16 dBm RF3OUT –80 dBm to +7 dBm

Output level resolution (modulated signal) 0.1 dB

Output level uncertainty

+23°C to +35°C

RF1, RF2:

≥–108 dBm

RF3OUT: –80 dBm to +4 dBm

Modulation

Dual BPSK, multiple QPSK 1.2288 Mcps AWGN see AW GN Generator Carrier suppression >35 dB Waveform quality factor (Rho) >0.99 Code channel level uncertainty (relative to the total CDMA power) F-PICH, F- PCH, F-FCH, F-SCH1, F-SCH 2 0.1 dB typ. all other channels 0.25 dB typ. Code channel resolution 0.1 dB

AWGN Ge nerator

Bandwidth >1.8 MHz Output level resolution 0.1 dB Output level uncertainty 0.2 dB typ.

Output level range

Relative to total CDMA output power –20 dB to +4 dB

Supported Service Options

Loopback Service Options SO 2, 9 Speech Service Options SO 1, 3, 17, 0x8000

<0.5 dB

<0.7 dB <0.9dB

+5°C to +45°C

<0.7 dB

24 Universal Radio Communication Tester CMU200

The channel power measurement displays the power in the channels used by the reverse link, separated into I and Q signal

CDMA2000 Highlights of CMU 200

◆ Voice loopback and coprehensive

testing of mobiles

◆ Full support of RC1/RC2 (cdmaOne

measurements)

◆ Support of all band classes specified

in IS-2000

◆ Innovative measurement of code do-

main power, code domain peak error power, channel power

◆ Parallel Rx/Tx measurements ensure

high throughput in production environments

◆ Graphical representation of measure-

ment results best suited for R& D labs

◆ Readout and display of many mobile

specific parameters (ESN, Slot-cycleindex, etc)

◆ Extremly fast measurments

◆ Non-signalling and signalling mode

◆ Various handoffs supported (e.g.

handoff to AMPS, interband handoff)

RF Analyzer

Frequency range

Option CMU-K83:

NMT-450 (Bandclass 5) 411.675 MHz to 483.480 MHz

Option CMU-K84:

US/Korean cellular (band class 0) 824.025 MHz to 848.985 MHz TACS band (band class 2) 872.0125 MHz to 914.9875 MHz JTACS band (band class 3) 887.0125 MHz to 924.9875 MHz North American 700 MHz cellular band (band class 7) 776.000 MHz to 794.000 MHz 900 MHz band (band class 9) 880.000 MHz to 913.750 MHz Secondary 800 MHz band (band class 10) 806.000 MHz to 900.975 MHz

Option CMU-K85:

North American PCS (band class 1) 1850 MHz to 1910 MHz z Korean PCS (band class 4) 1750 MHz to 1780 MHz 1800 MHz band (band class 8) 1710.000 MHz to 1784.950 MHz

Option CMU-K86:

IMT-2000 (band class 6) 1920.000 MHz to 1979.950 MHz

Measurement filter according to standard (1.23 MHz bandwidth)

Frequency resolution channel spacing according to standard

Level range (HPSK, O-QPSK signal)

RF1 –43 dBm to +44 dBm RF2 –57 dBm to +30 dBm RF4IN –83 dBm to –9 dBm

Power meter (frequency-selective)

Level uncertainty

RF1, RF2, RF4IN

in temperature range +23° to +35°C <0.5 dB in temperature range +5° to +45°C <0.7 dB

Level resolution 0.1 dB

Modulation analyzer

RC1, RC2 (O-QPSK):

Waveform quality, error vector magnitude, magnitude error, phase error

Rho uncertainty ( for Rho 0.9 to 1 ) <0.003 Frequency measurement range –3 kHz to +3 kHz Frequency measurement uncertainty <30 Hz + drift of time base

RC3, RC4 (HPSK):

Waveform quality, error vector magnitude, magnitude error, phase error, code domain power, peak code domain error power, channel power

Rho uncertainty ( for Rho 0.9 to 1 ) <0.003 Frequency measurement range –3 kHz to +3 kHz Frequency measurement uncertainty <10 Hz + drift of time base Relative measurement uncertainty result > –33 dB <0.1dB

Universal Radio Communication Tester CMU200 25

Bluetooth™ measurements in CMU200

General

The CMU200 with the Bluetooth option can set up a Bluetooth connection to a Device Under Test (DUT) via the RF interface. The CMU200 switches the DUT into test mode and performs a number of basic RF measurements (TX and RX). According to the Bluetooth Test Mode Specification the DUT has to be locally enabled for the test mode operation. All measurements can be performed in hopping-, reduced hopping- or non-hoppingmode. The CMU200 supports measurements using DH1, DH3 and DH5 packets.

The coupling between the CMU200 and the DUT can be either via a cable or a coupler, depending on the implementation of the DUT.

Applications

The Universal Radio Communication Tester CMU200 with the Bluetooth option is the ideal instrument for production, development and maintenance of any kind of devices with integrated Bluetooth wireless technology.

The CMU200 can also be equipped with additional options for cellular standards like GSM, AMPS, TDMA or CDMA. Therefore the CMU200 is an ideal tester for mobile phone production, as it offers measurements in line with Bluetooth wireless technology and cellular standards in one instrument. With a further extension, which is already in development, the CMU200 will be able to run Bluetooth measurements and cellular measurements simultaneously. This means the total test time for a mobile phone will not be increased by the Blue- tooth tests because the two types of tests can take place at the same time.

Parallel operation for high measurement speed

Due to the high measurement speed and large memory capacity of the CMU, transmitter and receiver measurements can be carried out in parallel. When measurements are performed during frequency

hopping, a great test depth is rapidly attained. Only a few seconds are required between call setup, transmitter and receiver measurements and call detach.

Many convenient measurement functions

The CMU offers a great number of statistical monitoring and measurement functions. It is possible, for instance, to define individual tolerances for each measured value and to stop a measurement sequence after a certain number of measurements or when a tolerance has been exceeded. Besides the common traces for power and modulation versus time, averaged minimum or maximum traces can also be displayed over a userdefined number of packages.

Compliance with existing Bluetooth standards

The CMU200 is compliant with the Bluetooth core specifications Ver. 1.0 B and

1.1. The Bluetooth Test Mode (Core Spec. Part I:1) is implemented with all commands needed to perform the TX/RX measurements.

The Bluetooth RF Test Specification Ver. 0.9 describes RF test cases for the Bluetooth qualification process. Rohde&Schwarz offers the Test System TS8960 for Bluetooth qualification tests, which is fully compliant with the RF Test

Specification. Although the CMU 200 was not designed for qualification tests, the RF test specification was taken as a guideline for the implementation of the CMU200´s Bluetooth measurements.

Signalling

Setting up a Bluetooth connection

The CMU200 acts as the master of a Bluetooth piconet, the DUT as a slave. The

CMU200 is able to perform the inquiry procedure for the identification of all Bluetooth devices within range of the CMU200. All devices found are listed on the display and one of them can be selected for the paging procedure. The CMU 200 then establishes the connection to the DUT and switches it into test mode operation.

The inquiry procedure can be skipped, if the Bluetooth device address of the DUT is already known. In this case a shorter setup time for the connection can be achieved. This is important for production tests of Bluetooth devices to increase the maximum throughput of a production line.

Signalling information from the DUT

The CMU200 is able to display a variety of information which is received from the DUT (eg device name, version numbers, service class, supported features).

26 Universal Radio Communication Tester CMU200

The connection control menu allows to inquire

addresses of all Bluetooth

devices in range. The

“Device to page” softkey

then selects the DUT for

the measurements tests. Alternatively the input of a known address is possible

The power menu shows

the results in graphical and

scalar form. Statistical

functions as well as con-

venient markers aid fur-

ther evaluation. The timing

measurement comple-

ments the numerical

power results

The graphical display of

the modulation results

may be spread between 1/

1 and 1/8 of a burst for indepth analysis. The “Max.

Freq. Dev.” and “Min Freq.

Dev.” results allow the highest and lowest values for 10 bit long fractions of

a payload to be evaluated

individually

Universal Radio Communication Tester CMU200 27

Bluetooth wireless technology in CMU200

TX measurements

The current measurement values for each parameter are displayed on the CMU200 screen. Additionally average, maximum and minimum values are displayed as a result of a statistical evaluation of a settable number of Bluetooth packets (bursts).

Power measurements

Measurement parameters:

◆ Nominal power (measured as the part

of the burst starting at the detected 1st bit of the preamble (bit 0) to the last bit of the burst)

◆ Peak power (shows the highest pow-

erlevel within a burst)

◆ Leakage power (measured within de-

fined areas before and after the burst)

Timing measurements

Measurement parameter:

◆ Packet alignment (distance between

ideal master receiver slot and detect-

ed bit 0 of the received burst) This measurement is displayed on the “Power“ screen.

Modulation measurements

Measurement parameters:

◆ Frequency accuracy (difference be-

tween measured frequency and in-

The device under test can be connected to the CMU200 via a RF coupler (antenna) or a cable

tended transmitted frequency, meas-

RX measurements

ured in the preamble at the beginning of a packet)

◆ Frequency drift (difference between

the frequency at the start of the packet and the frequency in the payload)

◆ Maximum drift rate (maximum drift

rate anywhere within the packet payload)

◆ Average, maximum and minimum fre-

quency deviation (calculated over the packet payload)

For RX measurements, the built-in signal generator generates a selectable bit sequence, which is looped back in the DUT and demodulated and processed by the CMU200 again. The TX level of the CMU200 can be adjusted for this measurement. The BER application supports defining up to five test programs. Each program can independently set settings such as control parameters, limits, repetition or statistical cycles.

Bluetooth specifications

Standards Bluetooth Specifications Version 1.0 b and 1.1

RF generator

Frequency range

Europe (except Spain and France),

USA and Japan 2.4000 GHz to 2.4835 GHz France 2.4465 GHz to 2.4835 GHz Spain 2.4450 GHz to 2.475 GHz

Frequency resolution channel spacing 1 MHz according to standard

Frequency hopping all modes according to standard

Output level range (modulated signal)

RF1 –106 dBm to –33 dBm RF2 –106 dBm to –12 dBm RF3OUT –90 dBm to +5 dBm

28 Universal Radio Communication Tester CMU200

Output level resolution 0.1 dB

Output level uncertainty

RF1

in temperature range +23°C to +35°C <0.9 dB in temperature range +5°C to +45°C <1.6 dB

RF2

in temperature range +23°C to +35°C <0.9 dB in temperature range +5°C to +45°C <1.6 dB

RF3OUT

in temperature range +23°C to +35°C <1.1 dB in temperature range +5°C to +45°C <1.6 dB

Modulation

GFSK

(AC coupling cut off frequency 100Hz) 1 Mbps, B*T=0.5

Modulation index (11110000 pattern

in temperature range +23°C to +35°C) 0.304 to 0.336 plus residual FM (see base unit)

Bluetooth wireless technology highlights of CMU200

◆ Bluetooth test mode signalling

◆ High measurement accuracy and speed

◆ Parallel TX and RX measurement of the

RF interface in loopback mode

◆ Output of Bluetooth specific clock signal

◆ IF signal output

◆ Graphical and scalar result output

Supported Standards

◆ Bluetooth Specification Version 1.0 b and

1.1

The receiver quality measurement includes output of BER and PER values. Supports three modes, single shot, continuous and search of a target BER value by automatic variation of CMU200 output level. Up to 5 different best scenarios can be configured.

Sensitivity

tistical cycle, where an errored packet is a packet with a header which can-

Measurement parameters

not be corrected)

◆ BER (percentage of bit errors that

have occurred within the current statistical cycle)

◆ PER (percentage of packet errors that

BLUETOOTH is a trademark owned by Bluetooth SIG, Inc., USA and licensed to Rohde & Schwarz

have occurred within the current sta-

RF analyzer

Frequency range Europe (except Spain and France),

USA and Japan 2.4000 GHz to 2.4835 GHz France 2.4465 GHz to 2.4835 GHz Spain 2.4450 GHz to 2.475 GHz

Frequency resolution channel spacing 1 MHz according to standard

Frequency hopping all modes according to standard

Power meter (frequency selective) and power versus time

Level Resolution 0.1 dB

Reference level for full dynamic range (GFSK signal)

RF1 0 dBm to +41 dBm RF2 –14 dBm to +33 dBm RF4IN –32 dBm to 0 dBm

Level uncertainty from full scale down to –25 dB

RF1, RF2

in temperature range +23°C to +35°C <0.7 dB in temperature range +5°C to +45°C <1.0 dB

RF4IN

in temperature range +23°C to +35°C <0.9 dB in temperature range +5°C to +45°C <1.1 dB

Dynamic range >55 dB (BW= 3 MHz, rms)

Modulation analyzer (BW= 3 MHz)

Level range (GFSK signal)

RF1, RF2, RF4IN from full–scale setting down to –25 dB

Frequency offset error in preamble

Frequency deviation error in payload (for deviation for 11110000 pattern ≤2 % for 10101010 pattern

Total measurement range for frequency offset and frequency deviation –250 kHz to +250 kHz

≤200 kHz)

Timing measurement

Range ±20 µs Uncertainty

≤2 kHz

≤4 %

≤0.25 µs

Universal Radio Communication Tester CMU200 29

WCDMA in CMU200

The need for higher data rates is the trend in our information-oriented society in the new millennium. The enhancement of mobile phones takes this need into account on the way to the next generation of wireless communication. How to cover these future challenges? Driven by ideas of the first and second generation (SIM, global roaming, military CDMA technology, data services), WCDMA will take all of these fundamentals to unprecedented levels and add new applications and higher data security. Derived from Asian, American and European ideas, "3G" is getting ready to be the mobile solution for future needs as well as the current applications.

WCDMA

Depending on the level of mobility, WCDMA provides several times the capacity of 2nd generation CDMA or TDMA systems.

Thanks to the modular concept of CMU200, WCDMA functionality plus e.g. GSM, TDMA (TIA/EIA-136), AMPS and other wireless standards such as Bluetooth, can be implemented in a single unit at the same time.

WCDMA FDD functionality

The tests are based on the 3GPP/FDD, release 99 WCDMA radio link standards version June 2001. The CMU200 can easily be upgraded to different functionality steps by means of hardware and software options for non-signalling Tx/Rx measurements and signalling measurements. All measurements are following the 3GPP specification TS 34.121. This is especially interesting due to the variety of different filter bandwidth and shapes for ACLR, SEM, MIN power, MAX power, etc that are to be used according to the specifica-

tion. Due to the highly user-friendly menu concept, the CMU200 provides quick access to all measurements desired and optimizes handling and consequently efficiency.

Non-signalling mode

The non-signalling mode is for generating and analyzing WCDMA (3GPP/FDD) signals within the frequency range from of the CMU200 base unit. CMU200 provides WCDMA-specific TX measurements on signals with up to 6 DPDCHs such as

◆ ACLR (Adjacent Channel Leakage

Power Ratio): Two measurement modes, Filter (Bargraph) and FFT (cont. spectrum) method: Absolute or relative readout

◆ OBW (Occupied Bandwidth)

◆ SEM (Spectrum Emission Mask)

◆ CDP (Code Domain Power): CDP vs all

codes, CDP vs DCH channels, RHO vs all codes, RHO vs DCH channels. All measurements in relative or absolute readout, splitted into I and Q parts

◆ Modulation (for 3GPP or general

QPSK): EVM (Error Vector Magnitude), Magnitude Error, Phase Error, Frequency Error, I/Q Offset, I/Q Imbalance, Peak Code Domain Error, RHO (Waveform Quality)

◆

Power: MAX, MIN, OFF (UE test mode)

◆ Autoranging for received UE signal

The non-signalling mode allows tests of all essential RF parameters of the connected UE (User Equipment). The measurements work in unsynchronized mode. No time consuming call setup is done to evaluate UE performance using these measurements.

RX measurements

A synchronization (but still no call setup) is needed for the RX evaluation and some additional TX measurements, such as

◆ Inner Loop Power Control with TPC

commands: TPC stepping measurement (UE receives TPC commands from CMU200 generator)

◆

Receiver Quality: BER, BLER, (with UEassisted evaluation, no RF loopback)

The generated channels and functions available are

◆ P-CPICH/P-SCH/S-SCH/P-CCPCH/

DPCCH/DPDCH

◆ TPC profiles

In conjunction with the Rohde&Schwarz Baseband Fading Simulator ABFS and the planned option CMU-B17, conditions of fading may be simulated and evaluated with CMU200.

FDD signalling mode (planned)

The CMU200 simulates a WCDMA basestation RF interface including the signalling protocol so that a mobile can be tested with regard to different signalling parameters. All necessary network and Node B (base station) parameters such as control and data channel configurations ca n b e s et. This mo de wi ll be su ppor ted i n a next step. In addition to the non-signalling tests it provides features such as

◆

Power: MAX, MIN, OFF (UE signalling mode)

◆

Power control: ON/OFF time mask, open loop power control, inner loop power control (3GPP mode)

◆ Receiver Quality: BER, BLER, (with RF

loopback)

◆ Call setup and release / paging

30 Universal Radio Communication Tester CMU200

◆ Test mode connection

Signalling test allows tests in an environment closer to a real live network. However in a production context they might not be absolutely neccessary.

WCDMA development

With its great versatility the CMU200 is also a suitable tool for the development of mobile phones. Four configurable RF connectors are provided to enable flexible signal levels. The clearly structured and userfriendly menu design together with the clear-cut screen layout provides quick access to all features and ensures trouble-free monitoring of the device under test. The tester can be switched between 3GPP and general QPSK modes to increase the usability with DUTs under development.

The overview

menu provides fast comprehensive information

on the UE´s RF

performance. The

hotkeys at the

bottom of the

screen give

immediate access

to specific and

detailed measure-

ments

The screenshot

shown here is just

one of the 4 com-

prehensive ways

to display the UE

Code Domain

Power in non-sig-

nalling mode

Quality assurance

Due to its high measurement repeatability and accuracy, the CMU200 is the right choice to ensure a consistently high quality standard of all your deliveries. WCDMA-specific measurements such as BER, EVM , and full implementation of complimentary (i.e. ACLR- and OBW-) measurements provide an excellent test platform to guarantee

The ACLR menu

shows all adja-

cent channel related information in graphical

as well as in sca-

lar numerical

form. Since the

ACLR-FFT and

OBW measure-

ment methods are

closely related,

results for Occu-

pied Bandwidth

are displayed

simultaneously.

The scalar display

except center

channel (0MHz) may be switched to absolute read-

out as well

Universal Radio Communication Tester CMU200 31

WCDMA in CMU200

the production of high-quality devices.

Production of mobile phones

The production of mobile phones requires time-efficient and cost-effective means that ensure both high throughput and state-of-the-art accuracy. Thanks to the unique IEC/IEEE-bus concept of the CMU200, these two goals can be easily achieved in your production line. The intelligent handling of the received GPIB commands thoroughly optimizes the measurement speed for WCDMA-specific measurements. In practice, this will mean reduced test time and enhanced test yield.

Switching standards

ACLR measurements are available using two differing measurement methods and corresponding displays. In this screenshot, the ACLR is measured using the filter method to obtain results for 5 channels. The scalar display except center channel (0MHz) may be switched to absolute readout as well

The flexibility of CMU200 makes for quick and simple switching between different standards. This is very important for e.g.

TIA-136 (TDMA) and TIA-95 (CDMA) use as many 3GPP UEs for markets with networks of these second generation stand-

WCDMA specifications – Mobile station (UE) test

Standard 3GPP-FDD Symbol rate 3.84 MHz Synchronization output 2 BNC connector REFOUT2

Frequency 30.72 MHz

RF Generator

Channels P-CPICH, P-SCH, S-SCH, P-CCPCH, DPCH Channel levels –30 dB to 0 dB relative to CPICH Reference measurement channel RMC 12.2 kbps, 64 kbps, 144kbps, 384 kbps

Frequency range 2110 MHz to 2170 MHz Resolution 0.1 Hz

Output level range

RF1 –120 dBm to –40 dBm RF2 –120 dBm to –23 dBm RF3OUT –80 dBm to 0 dBm

Output level uncertainty

RF1, RF2:

≥–80 dBm

RF3:

Signal quality

Error Vector Magnitude (EVM) <8%

+23°C to +35°C

≥–110 dBm

RF Analyzer (TX Measurements)

Frequency range 1920 MHz to 1980 MHz Resolution 1 Hz

Reference level for full dynamic range

RF1

Continuous power Peak envelope power (PEP)

For crest factor ≤13 dB.

For reference measurement channel 384 ksps (TS34.121 C3.4).

50 W in temperature range +5°C to +30 °C, linear degradation down to 25 W at 45°C.

Mea n val ue of powe r vs. time must be eq ual or less than allowed continuous power.

32 Universal Radio Communication Tester CMU200

(3GPP TS34.121)

<0.6 dB <1.0 dB <0.9 dB <1.0 dB

0 dBm to +47 dBm 0 dBm to +53 dBm

+5°C to +45°C

ards are going to be dual-mode even without a handover being defined. Switching between WCDMA and other

RF2

Continuous power –14 dBm to +33 dBm Peak envelope power (PEP)

RF4IN

Continuous power and PEP –37 dBm to +0 dBm

Modulation analysis

Measurement filter receiver filter according to standard

Analysis modes QPSK, WCDMA uplink

Error Vector Magnitude (EVM)

Measurement range up to 25 % Inherent EVM, rms <2.5 % Resolution 0.1 %

Frequency error

Measurement range Uncertainty <10 Hz + drift of time base Resolution 1 Hz

IQ offset

Inherent IQ offset <–55 dB Resolution 0.01 dB

IQ imbalance

Inherent IQ imbalance <–30 dB Resolution 0.01 dB

Waveform quality

Measurement range 0.9 to 1.0 Uncertainty <0.002 Resolution 0.0001

Peak Code Domain Error (PCDE)

Uncertainty <0.5 dB Resolution 0.01 dB

The specified data is valid for “Low Noise Mode“ operation.

with CMU-Z6 typ<1.5%

At 12.2 kbps Reference measurement channel.

–14 dBm to +39 dBm

3.84 MHz, RRC, a=0.22

±3 kHz

WCDMA highlights of CMU200

WCDMA-related features

◆ Shortest measurement time ensuring

high throughput

◆ Benchmark-breaking IEEE-bus speed

(see highlights of base unit)

◆ Combined measurements, many different

measurement modes

◆ Multi-band/multi-mode testing

◆ Powerful signalling capabilities part of a

clear upgrade path

◆ Mobile- or base-station originated call

connect/disconnect will be available in a next functionality step

◆ Simple interactive operation, standard-

ized MMI

◆ No specialized network knowledge

required

This screenshot shows the independent generator settings for the various channels

standards can be achieved by a simple remote command or by pressing a button. It allows a very versatile production test

Spectrum Measurements

Measurement filter receiver filter according to standard

ACLR(FFT)

Resolution bandwidth 20 kHz Frequency offsets

First adjacent channel ±5 MHz Second adjacent channel ±10 MHz

Dynamic range

First adjacent channel >54 dB Second adjacent channel >62 dB

Resolution 0.1 dB

ACLR (Filter)

Frequency offsets

First adjacent channel ±5 MHz Second adjacent channel ±10 MHz

Dynamic range

First adjacent channel >54 dB Second adjacent channel >62 dB

Resolution 0.1 dB

Occupied bandwidth

Range 1 MHz to 6 MHz Uncertainty <100 kHz Resolution 20 kHz

Spectrum emission mask

Measurement filter

± 2.515 MHz to ± 3.485 MHz 30 kHz gaussian filter ± 4.0 MHz to ± 12.0 MHz 1 MHz gaussian filter

Dynamic range

± 2.515 MHz to ± 3.485 MHz tbd ± 4.0 MHz to ± 7.5 MHz tbd ± 7.5 MHz to ± 8.5 MHz tbd ± 8.5 MHz to ± 12.0 MHz tbd

Resolution 0.1 dB

The specified data is valid for “High Dynamic Mode“ operation.

Valid for instruments since 3/2000.

7)8)

3.84 MHz, RRC, a=0.22

layout and improves the flexibility and throughput of your multimode UE application.

Supported WCDMA standards

Frequency band Radio link standard

2000 MHz and 2200 MHz paired spectrum

Power Measurements

Maximum power wide band filter

Minimum/Off power receiver filter acc. to standard 3.84 MHz, RRC,

Level range

Continuous power Peak envelope power

(PEP)

Upper limit is depending on crest factor

Level uncertainty

RF1

–10 dBm to +47 dBm, rms <0.5 dB <0.7dB –52 dBm to –10 dBm, rms <0.7 dB <0.9 dB

RF2

–24 dBm to +33 dBm, rms <0.9 dB <1.0 dB –66 dBm to –24 dBm, rms

RF4IN

–24 dBm to 0 dBm, rms <0.5 dB – –89 dBm to –24 dBm, rms <0.7 dB – –57 dBm to 0 dBm, rms – <0.7 dB –89 dBm to –57 dBm, rms – <0.9 dB

Level resolution 0.01 dB

Code domain power

Measurement filter receiver filter according to standard

Level range

RF1 –8 dBm to +47 dBm RF2 –22 dBm to +33 dBm RF4IN –45 dBm to 0 dBm Level resolution 0.01 dB

a=0.22

RF1

–52 dBm to +47 dBm3)–66 dBm to +33 dBm 10–89 dBm to 0 dBm –42 dBm to +53 dBm4)–56 dBm to +39 dBm4)–79 dBm to 0 dBm

+23°C to +35°C

Universal Radio Communication Tester CMU200 33

RF2 RF4IN

3.84 MHz, RRC, a=0.22

3GPP-FDD

+5°C to +45°C

A)A)

Base unit specifications

Please see standard-specific data on the previous pages for more details and improved accuracy

Timebase TCXO

Max. frequency drift

in temperature range +5°C to +45 °C

Max. aging ±1 x 10−6/year

Timebase OCXO – option CMU-B11

Max. frequency drift

in temperature range +5°C to+45 °C

Max. aging ±2 x 10−7/year,

Warmup time (at +25°C) approx. 5 min

Timebase OCXO – option CMU-B12

Max. frequency drift

in temperature range +5°C to +45 °C with instrument orientation referred to turn-off frequency after 2 h warmup time following a 24 h off time at +25°C

Max. aging ±3.5 x 10−8/year,

Warmup time (at +25°C) approx. 10 min

Reference frequency inputs/outputs

Synchronization input BNC connector REFIN

Frequency Sinewave 1 MHz to 52 MHz, step 1 kHz Squarewave (TTL level) 10 kHz to 52 MHz, step 1 kHz Max. frequency variation Input voltage range 0.5 V to 2 V, rms Impedance 50

Synchronization output 1 BNC connector REFOUT1

Frequency 10 MHz from internal reference or frequency

Output voltage Impedance 50

Synchronization output 2 BNC connector REFOUT2

Frequency net-specific frequencies in range

Output voltage (f Impedance 50

≤13 MHz) >1.0 V, peak-peak

RF generator

Frequency range 100 kHz to 2700 MHz Frequency resolution 0.1 Hz Frequency uncertainty same as timebase + resolution Frequency settling time

Output level range

RF1

100 kHz to 2200 MHz

2200 MHz to 2700 MHz

RF2

100 kHz to 2200 MHz

2200 MHz to 2700 MHz

RF3OUT

100 kHz to 2200 MHz

2200 MHz to 2700 MHz

Output level uncertainty

RF1, RF2

in temperature range +23°C to +35°C

10 MHz to 450 MHz <0.6 dB

450 MHz to 2200 MHz

2200 MHz to 2700 MHz <0.8 dB <0.8 dB

in temperature range +5°C to +45 °C

10 MHz to 450 MHz <1.0 dB

450 MHz to 2200 MHz <1.0 dB <1.0 dB

2200 MHz to 2700 MHz <1.5 dB <1.5 dB

Valid for RF1 only.

Not valid at frequencies of netclock harmonics

−6

±1 x 10

−7

±1 x 10

−9

±5 x 10

/day

after 30 days of operation

−9

±5 x 10

, referred to +25°C

−9

±3 x 10

−9

±5 x 10

−10

±5 x 10

/day

after 30 days of operation

−6

±5 x 10

Ω

at synchronization input

>1.4 V, peak-peak

Ω

100 kHz to 40 MHz

Ω

<400 µs to ∆f <1kHz

−130 dBm to −27 dBm

−130 dBm to −33 dBm

−130 dBm to −10 dBm

−130 dBm to −16 dBm

−90 dBm to +13 dBm

−90 dBm to +5 dBm

≥−

106 dBm>−117 dBm−117 to −130 dBm

<0.6 dB <0.6 dB

≥−

106 dBm>−117 dBm−117 to −130 dBm

<1.5 dB

RF3OUT

+23°C to +35°C +5°C to +45°C

10 MHz to 450 MHz:

−80 dBm to +10 dBm

450 MHz to 2200 MHz:

−90 dBm to +10 dBm

2200 MHz to 2700 MHz:

−90 dBm to +5 dBm

<0.8 dB <1.0 dB

<1.0 dB <1.5 dB

Output level settling time <4 µs

Output level resolution 0.1 dB

Generator RF level repeatability

(RF1, RF2, RF3OUT, typical values after 1h warm-up) Output

≥–80 dBm <0.01 dB

Output <–80 dBm <0.1 dB

VSWR

RF1

10 MHz to 2000 MHz 2000 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF2

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF3OUT

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

Attenuation of harmonics (f

RF1, RF2 RF3OUT (P

≤ +10 dBm) >20 dB

Attenuation of nonharmonics

10 MHz to 2200 MHz at

Phase noise (single sideband, f

Carrier offset

20 kHz to 250 kHz

≥250 kHz <−110 dBc(1 Hz)

= 10 MHz to 2200 MHz, up to 7 GHz)

>5 kHz from carrier >40 dB

< 2.2 GHz)

<1.2 <1.3 <1.6

<1.2 <1.6

<1.5 <1.7

>30 dB

<−100 dBc(1 Hz)

Residual FM

30 Hz to 15 kHz CCITT

Residual AM

CCITT

IQ modulation

Data for frequency offset range 0 kHz to Carrier suppression

<50 Hz (rms), <200 Hz (peak) <5 Hz (rms)

<0.02% (rms)

±135 kHz

>40 dB

RF analyzer

VSWR

RF1

10 MHz to 2000 MHz 2000 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF2

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF4IN

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

<1.2 <1.3 <1.6

<1.2 <1.6

<1.5 <1.6

Power meter (wideband)

1)2)

Frequency range 100 kHz to 2700 MHz

Level range

RF1

continuous power

100 kHz to 2200 MHz +6 dBm to +47 dBm (50 W) 2200 MHz to 2700 MHz +10 dBm to +47 dBm (50 W) Peak envelope power

RF2

continuous power

100 kHz to 2200 MHz 2200 MHz to 2700 MHz Peak envelope power

RF4IN (continuous power and PEP)

100 kHz to 2200 MHz 2200 MHz to 2700 MHz

(PEP) +53 dBm (200 W)

−8 dBm to +33 dBm (2 W)

(PEP) +39 dBm (8 W)

−4 dBm to +33 dBm (2 W)

−33 dBm to 0 dBm

−29 dBm to 0 dBm

34 Universal Radio Communication Tester CMU200

50 W in temperature range +5 °C to +30 °C, linear degradation down to 25 W at 45 °C.

Mea n val ue of powe r vs t ime m ust b e equ al or less than allowed continuous power.

Level uncertainty

RF1 +10 dBm to +20dBm +20 dBm to +47 dBm

50 MHz to 2700 MHz

RF2 −4 dBm to +6dBm +6 dBm to +33 dBm

50 MHz to 2700 MHz <1.0 dB

RF4IN −29 dBm to −19dBm −19 dBm to 0 dBm

50 MHz to 2700 MHz

<1.0 dB6)<0.5 dB

<1.5 dB<0.8 dB

<0.5 dB

5) 6)

Level resolution 0.1 dB (0.01 dB via remote control)

Power meter (frequency-selective)

Frequency range 10 MHz to 2700 MHz Frequency resolution 0.1 Hz Resolution bandwidths 10 Hz to 1 MHz in 1/2/3/5 steps

Level range

RF1

continuous power

10 MHz to 2200 MHz −40 dBm to +47 dBm (50 W)

2200 MHz to 2700 MHz Peak envelope power

RF2

continuous power

10 MHz to 2200 MHz 2200 MHz to 2700 MHz Peak envelope power

RF4IN (continuous power and PEP)

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

(PEP) +53 dBm (200 W)

(PEP) +39 dBm (8 W)

−34 dBm to +47 dBm (50 W)

−54 dBm to +33 dBm (2 W)

−48 dBm to +33 dBm (2 W)

−80 dBm to 0 dBm

−74 dBm to 0 dBm

Level uncertainty

RF1, RF2

in temperature range +23°C to +35°C

50 MHz to 2200 MHz 2200 MHz to 2700 MHz in temperature range +5°C to +45 °C

50 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF4IN

in temperature range +23°C to +35°C

50 MHz to 2200 MHz 2200 MHz to 2700 MHz in temperature range +5°C to +45 °C

50 MHz to 2200 MHz 2200 MHz to 2700 MHz

<0.5 dB <0.7 dB

<1.0 dB <1.0 dB

<0.7 dB <0.9 dB

<1.0 dB <1.1 dB

Level resolution 0.1 dB (0.01 dB via remote control)

RF level measurement repeatability

(RF1, RF2, RF4IN, typical values after 1h warm-up)

≥ –40 dBm <0.01 dB

Input Input < –40 dBm <0.03 dB

Demodulation (data of hardware paths)

Phase noise (single sideband, f <2.2 GHz)

Carrier offset

20 kHz to 250 kHz 250 kHz to 400 kHz

<−100 dBc(1 Hz) <−110 dBc(1 Hz)

≥400 kHz <−118 dBc(1 Hz)

Residual FM

30 Hz to 15 kHz CCITT

<50 Hz (rms), <200 Hz (peak) <5 Hz (rms)

Residual AM

CCITT

<0.02% (rms)

Spectrum analyzer

Frequency range 10 MHz to 2.7 GHz Span zero span to full span Frequency resolution 0.1 Hz Resolution bandwidths 10 Hz to 1 MHz in 1/2/3/5 steps Sweep time Display 560 dots, horizontal Marker up to 3, absolute/relative Display line 1 Display scale 10/20/30/50/80/100 dB

Calibrated for P>33 dBm only in frequency range 800 MHz to 2000 MHz.

Temperature range +5°C to +23 °C or +35 °C to +45 °C and f>2200 MHz: add 0.2 dB.

≥100 ms, depending on RBW

Level range

RF1

continuous power Peak envelope power

RF2

continuous power up to +33 dBm (2 W) Peak envelope power

RF4IN (continuous power and PEP) up to 0 dBm

up to +47 dBm (50 W)

(PEP) up to +53 dBm (200 W)

(PEP) up to +39 dBm (8 W)

Level uncertainty

+23°C to +35°C +5°C to +45°C

RF1, RF2

50 MHz to 2200 MHz

2200 MHz to 2700 MHz

<0.5 dB <1.0 dB <0.7 dB <1.0 dB

RF4IN

50 MHz to 2200 MHz 2200 MHz to 2700 MHz

Reference level for full dynamic range (low noise mode)

Logarithmic level display RF1 +10 dBm to +47 dBm RF2 RF4IN

Displayed average noise level (RBW 1 kHz, low noise mode)

RF1/RF2/RF4IN

10 MHz to 2200 MHz

2200 MHz to 2700 MHz

Inherent spurious response

Low distortion mode, 20 MHz to 2200 MHz, except 1816.115 MHz

<0.7 dB <1.0 dB <0.9 dB <1.1 dB

−4 dBm to +33 dBm

−22 dBm to 0 dBm

<−100 dBc <−95 dBc

<−50 dB

Inherent harmonics

= 50 MHz to 2200 MHz, up to 7 GHz)

RF1, RF2 RF4IN <−20 dB

<−30 dB

Audio option CMU-B41

AF generator

Output impedance <4 Ω Maximum output current 20 mA peak

AF sine generator

Frequency range 20 Hz to 20 kHz Frequency uncertainty same as time base + half resolution Frequency resolution 0.1 Hz Output level range 10 µV to 5 V Output level resolution

at level

<10 mV 10 µV ≥10 mV 0.1%

at level

Output level uncertainty

at level

≥1 mV and frequency ≤10 kHz ≤1.5% + resolution

THD+N

at level ≥100 mV into load ≥600 Ω≤0.05%

THD

at level ≥100 mV into load ≥600 Ω≤0.025%

AF analyzer

Input impedance 1MΩ100 pF

AF voltmeter

Frequency range 50 Hz to 20 kHz Level Range 50 µV to 30 V Level Resolution

<1 mV 1 µV

at level at level

≥1 mV 0.1%

Level uncertainty

≤level≤ 2 V <1.0% + resolution

at 1 mV at 2 V

<level≤20 V <2.0% + resolution

THD+N meter

Measurement bandwidth 21 kHz

Frequency range 100 Hz to 10 kHz Level Range 10 mV to 30 V Resolution 0.01% THD+N Inherent distortion

at 100 mV

Uncertainty

≤ level≤ 20 V <0.05% THD+N

≤ level≤ 2V <1% + inherent distortion

at 100 mV at 2 V

<level≤20 V <2% + inherent distortion

Measurement bandwidth: 21.9 kHz

Universal Radio Communication Tester CMU200 35

General data

Inputs and outputs (rear panel)

Rated temperature range +5 °C to +45 °C Storage temperature range Humidity +40 °C, 80% rh, non-condensing;

Display 21 cm TFT color display (8.4”) Resolution 640 x 480 pixels (VGA resolution) Pixel failure rate <2 x 10

Electromagnetic compatibility meets requirements of

Mechanical resistance (non operating mode)

Vibration, sinusoidal meets IEC68-2-6, IEC1010-1, EN61010-1,

Vibration, rand om meets DIN IEC 68-2-36, DIN 40046 T24

Shock meets DIN IEC 68-2-27, MIL-STD-810D

Electrical safety IEC1010-1, DIN EN61010-1, UL3111-1,

Power supply 100 V to 240 V

Dimensions (W x H x D) 465 mm x 193 mm x 517 mm

Weight

Base unit 14 kg With typical options 18 kg

−25 °C to +60°C

complies with IEC 68-2-3

–5

EMC Directive 89/336/EEC (EN50081-1 and EN50082-2)

MIL-T-28800 D class 5, 5 Hz to 150 Hz, max. 2 g at 55 Hz, 55 Hz to 150 Hz, 0.5 g const.

10 Hz to 300 Hz, acceleration 1.2 g rms

40 g shock spectrum

CSA22.2 No. 1010-1

50 Hz to 400 Hz power factor correction, EN61000-3-2 power consumption, max. 500 VA, base unit typical 130 W with options typical 180 W

(19“; 4 height units)

± 10% (AC),

−5% to +10%

IF3 RX CH1 Z

Remote control interfaces

IEC/IEEE-bus IEC 625-2 (IEEE 488.2)

Serial interface COM1, COM2 RS-232-C (COM), 9 pin sub-D connector

Printer interface LPT parallel (Centronics compatible),

Keyboard PS/2 connector

Exernal monitor (VGA) 15 pin sub-D connector

= 50 Ω, BNC female,

out

max level –2 dBm, 10.7 MHz

24-pin Amphenol connector

25 pin sub-D connector

Rohde& Schwarz specifications are a conservative view of what a product has to offer. As a n example, this diag ram presents the accuracy of the CMU200 frequency selective power measurement. This is shown here for 10 randomly chosen instruments at 25°C and 0 dBm on RF2 without taking additional measurement uncertainty rom the test system itself into account. The tolerances marked above and below (green and red line) indicate the data stated in this data sheet´s general data section.

36 Universal Radio Communication Tester CMU200

Models and options

Instruments, options and ordering information

Type/Option Description

CMU200

Base unit with following accessories: power cord, operating manual, service manual instrument

GSM

TDMA

AMPS

cdmaOne

Bluetooth

á á á á á á á 1100.0008.02

WCDMA

CDMA2000

Order number

Reference OCXO, aging 2 x 10−7/year. Ensures high absolute accuracy, minimum tem-

CMU-B111)

perature-dependent drift and especially high long-term stability. Used for

J J J J J J J 1100.5000.02

measurements with exact frequency stability requirements High-stability OCXO, aging 3.5 x 10−8/year. Oven crystal with highest long-term stabil-

CMU-B121)

ity. Ensures compliance with tolerances specified by GSM. Used for highly demand-

J J J J J J J 1100.5100.02

ing frequency stability requirements to GSM 11.20

CMU-B17 I/Q IF Interface J J J – J J J 1100.6906.02 CMU-B21 Versatile signalling unit. Provides multistandard signalling hardware á á á – á – – 1100.5200.02

CMU-B41

Audio generator and analyzer. Includes audio frequency (AF) generator, voltmeter, distortion meter

J J á – – – – 1100.5300.02

Internal versatile multimode speech coder/decoder. This option converts digital

CMU-B522)

speech signals into analog signals and vice versa. The option allows separate uplink

J J – – – – – 1100.5400.02

and downlink audio application measurements on mobile phones.

CMU-B532) Bluetooth extension, factory installation only – – – – á – – 1100.5700.02 CMU-B66 Versatile base band board – – – – – á – 1149.9509.02 CMU-B81 cdmaOne signalling unit – – – á – – – 1100.6506.02 CMU-B83 CDMA2000 (1x) signalling unit – – – – – – á 1150.0301.02 CMU-B99 RF1 level range identical to RF2 J J J – – – J 1150.1250.02 CMU-U532) Bluetooth upgrade kit for CMU – – – – á7) – – 1100.7302.02 CMU-U61 Modification kit: floppy disk drive 3½“ instead of PCMCIA J J J J J J J 1100.5500.02 CMU-U65 3G Measurement DSP – – – – – á – 1100.7402.02 CMU-U66 Upgrade kit versatile base band board – – – – – á14) – 1149.9609.02 CMU-U83 Upgrade kit to CMU-B83 in exchange with CMU-B81 – – – – – – á14) 1150.0401.02 CMU-U99 Modification kit RF1 level range identical to RF2 J J J – – – J 1150.1350.02 CMU-K202) GSM400 mobile station signalling/non-signalling test á8) – – – – – – 1115.5900.02 CMU-K212) GSM900, R-GSM and E-GSM mobile station signalling/non-signalling test á8) – – – – – – 1115.6007.02 CMU-K222) GSM1800 (DCS) mobile station signalling/non-signalling test á8) – – – – – – 1115.6107.02 CMU-K232) GSM1900 (PCS) mobile station signalling/non-signalling test á8) – – – – – – 1115.6207.02 CMU-K242) GSM850 mobile station signalling/non-signalling test á8) – – – – – – 1115.6307.02 CMU-K272) IS-136/Cellular (800 MHz band) mobile station signalling/non-signalling test – á8) – – – – – 1115.6607.02 CMU-K282) IS-136/PCS (1900 MHz band) mobile station signalling/non- signalling test – á8) – – – – – 1115.6707.02 CMU-K293) AMPS mobile station signalling/non-signalling test – – á – – – – 1115.6807.02 CMU-K4212) GPRS software extension for all GSM software packages á – – – – – – 1115.4691.02 CMU-K532)5) Bluetooth test software – – – – á – – 1115.5000.02 CMU-K659) WCDMA (3GPP/FDD, UL) User Equipment Tx-Test, non-signalling – – – – – á – 1115.4891.02 CMU-K669)10) WCDMA (3GPP/FDD, DL) Generator software – – – – – á – 1115.5100.02 CMU-K814) cdmaOne cellular (800 MHz band) mobile station signalling/non-signalling test – – – á8) – – – 1115.5500.02 CMU-K824) cdmaOne PCS (1700/1900 MHz band) mobile station signalling/non-signalling test – – – á8) – – – 1115.5600.02 CMU-K8311)4) CDMA2000 (1x) (450 MHz band) mobile station signalling/non-signalling test – – – – – – á 8) 1150.3500.02 CMU-K8411)4) CDMA2000 (1x) (cellular band) mobile station signalling/non-signalling test – – – – – – á 8) 1150.3600.02 CMU-K8511)4) CDMA2000 (1x) (PCS band) mobile station signalling/non-signalling test – – – – – – á 8) 1150.3700.02 CMU-K8611)4) CDMA2000 (1x) (IMT2000 band) mobile station signalling/non-signalling test – – – – – – á 8) 1150.3800.02 BW2-C1 Corner cover 1 (2 pieces required) J J J J J J J 1096.2593.00 BW2-C2 Corner cover 2 (2 pieces required) J J J J J J J 1096.2602.00 CMU-DCV Documentation of calibration values J J J J J J J 0240.2193.08 CRT-Z2

GSM/GPRS test SIM for loopback mode, required for BER and other applications

J – – – – – – 1039.9005.02

CMU-Z1 30 MByte memory card for use with PCMCIA interface J J J J J J J 1100.7490.02 CMU-Z6 Enhancement of wideband modulation – – – – – J – 1150.0001.02 PSM-B9 PCMCIA 500 MByte hard disk J J J J J J J 1064.5700.02 ZZA-411 19“ rack adapter J J J J J J J 1096.3283.00

Comments on table:

mandatory; J optional; – not applicable

) CMU -B11 or CM U-B1 2 pos sibl e. On e of tw o OCX Os sh ould be in stal led t o ens ure h igh f requ ency

accuracy or external frequency reference may be used, if available.

) CMU-B21 necessary.

) CMU-B21 and CMU-B41 necessary

) CMU-B81 necessary.

) CMU-B53 necessary.

) CMU-K53 necessary.

) For upgrade only if factory installation is not applicable. Includes CMU-B53 and CMU-K53.

) Depending on the required frequency band.

) CMU-U65 necessary.

) CMU-U66 or CMU-B66 necessary.

) CMU-B83 or CMU-U83 necessary.

) at least on of CMU-K20...K24 necessary.

) Factory installation only.

) For upgrade only if factory installation is not applicable.

Universal Radio Communication Tester CMU200 37

Printed in Germany 0901 (U as)

Data without tolerances: typical values

⋅

Subject to change

⋅

Trade names are trademarks of the owners

⋅

Universal Radio Communication Tester CMU200

⋅

PD757.4318.25

ROHDE& SCHWARZ GmbH & Co. KG ⋅ Mühldorfstraße 15 ⋅ 81671 München ⋅ Germany ⋅ P.O.B. 8014 69 ⋅ 81614 München ⋅ Germany ⋅ Telephone +49 89 41 29-0

www.rohde-schwarz.com ⋅ Customer Support: Tel. +49 18051242 42, Fax +49 89 41 29-13777, E-mail: CustomerSupport@rohde-schwarz.com

Value-added services

◆ Rohde&Schwarz offers a wide range

of training programs not only on products but also on new technical developments

◆ Rohde&Schwarz application engi-

neers help to optimize the use of CMU200 and the overall performance of your local environment

◆ Over 70 representative offices and a

tight worldwide network of service and calibration centers ensure Rohde&Schwarz support where you need it

Quality management at Rohde&Schwarz

Lasting customer satisfaction is our primary objective. The quality management system of Rohde&Schwarz meets the requirements of ISO 9001 and encompasses virtually all fields of activity of the company.

Certified Quality System

ISO 9001

DQS REG. NO 1954

Certified Environmental System

ISO 14001

REG. NO 1954

Rohde and Schwarz CMU200v10 Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
