Rohde and Schwarz CMU200v10 Data Sheet

¸CMU200 Universal Radio Communication Tester

Data sheet

Version

08.01

July

2007

CONTENTS

BASE UNIT SPECIFICATIONS ................................................................................................................................................................... 4

TIMEBASE TCXO ....................................................................................................................................................................................... 4

TIMEBASE OCXO – R&S®CMU-B11 OPTION .............................................................................................................................................. 4

TIMEBASE OCXO – R&S®CMU-B12 OPTION .............................................................................................................................................. 4

REFERENCE FREQUENCY INPUTS/OUTPUTS ................................................................................................................................................. 4

RF GENERATOR ......................................................................................................................................................................................... 5

RF ANALYZER ............................................................................................................................................................................................ 6

Power meter (wideband) ..................................................................................................................................................................... 7

Power meter (frequency-selective)...................................................................................................................................................... 7

SPECTRUM ANALYZER ................................................................................................................................................................................ 8

GENERAL SPECIFICATIONS ......................................................................................................................................................................... 9

INPUTS AND OUTPUTS (REAR PANEL)......................................................................................................................................................... 10

GSM SPECIFICATIONS – MOBILE STATION TEST ...............................................................................................................................11

RF GENERATOR ....................................................................................................................................................................................... 11

R&S®CMU-B95 OPTION ADDITIONAL RF GENERATOR ............................................................................................................................... 12

R&S®CMU-B96 OPTION ADDITIONAL RF GENERATOR ............................................................................................................................... 12

Path 1 for GSM.................................................................................................................................................................................. 12

Influence on RF interface .................................................................................................................................................................. 13

RF ANALYZER .......................................................................................................................................................................................... 13

Power meter (frequency-selective).................................................................................................................................................... 13

Modulation analysis ........................................................................................................................................................................... 14

Burst power measurement ................................................................................................................................................................ 14

Spectrum due to modulation.............................................................................................................................................................. 15

Spectrum due to switching ................................................................................................................................................................ 15

R&S®CMU-B52 OPTION SPEECH CODEC .................................................................................................................................................. 15

TDMA SPECIFICATIONS – MOBILE STATION TEST ............................................................................................................................. 16

RF GENERATOR ....................................................................................................................................................................................... 16

RF ANALYZER .......................................................................................................................................................................................... 16

Modulation analysis ........................................................................................................................................................................... 16

Power meter (frequency-selective).................................................................................................................................................... 17

Power versus time measurement ...................................................................................................................................................... 17

Adjacent channel power measurement ............................................................................................................................................. 17

AMPS SPECIFICATIONS – MOBILE STATION TEST ............................................................................................................................. 18

RF GENERATOR ....................................................................................................................................................................................... 18

RF ANALYZER .......................................................................................................................................................................................... 18

Power meter (frequency-selective).................................................................................................................................................... 19

FM measurement .............................................................................................................................................................................. 19

AF GENERATOR ....................................................................................................................................................................................... 19

AF ANALYZER .......................................................................................................................................................................................... 19

CDMA2000® SPECIFICATIONS – MOBILE STATION TEST ................................................................................................................... 20

RF GENERATOR ....................................................................................................................................................................................... 20

RF ANALYZER .......................................................................................................................................................................................... 21

Power meter (frequency-selective).................................................................................................................................................... 22

Modulation analyzer .......................................................................................................................................................................... 22

R&S®CMU-B85 OPTION SPEECH CODEC .................................................................................................................................................. 23

2 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

1XEV-DO SPECIFICATIONS – ACCESS TERMINAL TEST.................................................................................................................... 24

RF GENERATOR ....................................................................................................................................................................................... 24

RF ANALYZER .......................................................................................................................................................................................... 26

Power meter (frequency-selective).................................................................................................................................................... 26

Modulation analyzer .......................................................................................................................................................................... 27

WCDMA SPECIFICATIONS – MOBILE STATION (UE) TEST................................................................................................................. 28

RF GENERATOR ....................................................................................................................................................................................... 28

R&S®CMU-B96 ADDITIONAL RF GENERATOR OPTION ...............................................................................................................................30

Path 2 for WCDMA ............................................................................................................................................................................ 30

Influence on RF interface .................................................................................................................................................................. 30

RF ANALYZER (TX MEASUREMENTS)......................................................................................................................................................... 31

Modulation analysis ........................................................................................................................................................................... 32

Spectrum measurements .................................................................................................................................................................. 33

Power meter (frequency-selective).................................................................................................................................................... 34

Code domain power .......................................................................................................................................................................... 35

Receiver quality (bit error rate measurements) ................................................................................................................................. 35

R&S®CMU-B52 OPTION SPEECH CODEC .................................................................................................................................................. 36

BLUETOOTH® SPECIFICATIONS ............................................................................................................................................................ 37

RF GENERATOR ....................................................................................................................................................................................... 37

RF ANALYZER .......................................................................................................................................................................................... 38

Power meter (frequency-selective) and power versus time............................................................................................................... 38

Modulation analyzer .......................................................................................................................................................................... 38

Timing measurement......................................................................................................................................................................... 39

R&S®CMU-B52 OPTION SPEECH CODEC .................................................................................................................................................. 39

R&S®CMU-B17 OPTION I/Q/IF INTERFACE ............................................................................................................................................ 40

I/Q INTERFACE ......................................................................................................................................................................................... 40

INFLUENCE ON RF INTERFACE .................................................................................................................................................................. 40

IF INTERFACE........................................................................................................................................................................................... 41

REMARKS ................................................................................................................................................................................................ 42

Additional information for GSM:......................................................................................................................................................... 42

Aspects to be considered if TX or RX signal paths are interrupted: .................................................................................................. 42

Notes for measuring I/Q/IF signals applied to inputs of the R&S®CMU-B17 option on the R&S®CMU200 RX path:....................... 42

R&S®CMU-B41 OPTION AUDIO GENERATOR/ANALYZER .................................................................................................................. 43

AF GENERATOR ....................................................................................................................................................................................... 43

AF ANALYZER .......................................................................................................................................................................................... 43

R&S®CMU-U99/B99 OPTION RF1 LEVEL RANGE IDENTICAL TO RF2 ............................................................................................... 43

®

The specifications for the R&S

CMU200 (Order No. 1100.0008.02/10/30/53) refer to a fully equipped unit with all relevant options

installed.

CDMA2000® is a registered trademark of the Telecommunications Industry Association (TIA -USA).

The Bluetooth

®

word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Rohde&Schwarz is under license.

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 3

Base unit specifications

Timebase TCXO

Max. frequency drift

Max. aging

Timebase OCXO – R&S®CMU-B11 option

Max. frequency drift

Max. aging

Warmup time

Timebase OCXO – R&S®CMU-B12 option

in temperature range +5 °C to +45 °C ±1 × 10

±1 × 10

in temperature range +5 °C to +45 °C ±1 × 10

after 30 days of operation ±2 × 10

at +25 °C approx. 5 min

±5 × 10

–6

/year

–7

/year

–9

/day

Max. frequency drift

in temperature range +5°C to +45 °C,

with instrument orientation ±3 × 10–9 referred to turn-off frequency

Max. aging

Warmup time

–9

–10

–8

/day

/year

referred to +25 °C

after 2 h warmup time following a 24 h off time at +25 °C

after 30 days of operation ±3.5 × 10

at +25 °C approx. 10 min

±5 × 10

Reference frequency inputs/outputs

Synchronization input

Frequency sinewave

Max. frequency variation

Input voltage range

Impedance

Synchronization output 1

Frequency 10 MHz from internal reference or

Output voltage >1.4 V, peak-peak Impedance 50 Ω

Synchronization output 2

Frequency net-specific frequencies in range

Output voltage f ≤ 13 MHz >1.0 V, peak-peak Impedance 50 Ω

BNC connector REF IN

1 MHz to 52 MHz, step 1 kHz

squarewave (TTL level)

BNC connector REF OUT 1

BNC connector REF OUT 2

10 kHz to 52 MHz, step 1 kHz ±5 × 10–6

0.5 V to 2 V, rms

50 Ω

frequency at synchronization input

100 kHz to 40 MHz

4 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

RF generator

Frequency range

Frequency resolution

Frequency uncertainty

Frequency settling time

100 kHz to 2700 MHz

0.1 Hz

same as timebase + frequency resolution

Output level range

RF 1 100 kHz to 2200 MHz

2200 MHz to 2700 MHz

RF 2 100 kHz to 2200 MHz

2200 MHz to 2700 MHz

RF 3 OUT 100 kHz to 2200 MHz

2200 MHz to 2700 MHz

Output level uncertainty

in temperature range +20 °C to +35 °C

RF 1, RF 2 output level ≥ –106 dBm

10 MHz to 450 MHz 450 MHz to 2200 MHz 2200 MHz to 2700 MHz

output level > –117 dBm

450 MHz to 2200 MHz 2200 MHz to 2700 MHz

output level –117 dBm to –130 dBm

450 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF 3 OUT 10 MHz to 450 MHz

output level –80 dBm to +10 dBm

450 MHz to 2200 MHz

output level –90 dBm to +10 dBm

2200 MHz to 2700 MHz

output level –90 dBm to +5 dBm

Output level uncertainty

in temperature range +5 °C to +45 °C

RF 1, RF 2 output level ≥ –106 dBm

10 MHz to 450 MHz 450 MHz to 2200 MHz 2200 MHz to 2700 MHz

output level > –117 dBm

450 MHz to 2200 MHz 2200 MHz to 2700 MHz

output level –117 dBm to –130 dBm

450 MHz to 2200 MHz 2200 MHz to 2700 MHz

RF 3 OUT 10 MHz to 450 MHz

output level –80 dBm to +10 dBm

450 MHz to 2200 MHz

output level –90 dBm to +10 dBm

2200 MHz to 2700 MHz

output level –90 dBm to +5 dBm

Output level settling time

<4 µs

Output level resolution

0.1 dB

<400 µs to Δf < 1 kHz

–130 dBm to –27 dBm –130 dBm to –33 dBm –130 dBm to –10 dBm –130 dBm to –16 dBm –90 dBm to +13 dBm –90 dBm to +5 dBm

<0.6 dB <0.6 dB <0.8 dB

1

<0.6 dB <0.8 dB

1

1, 2

<1.5 dB <1.5 dB

<0.8 dB

<1.0 dB

<1.0 dB <1.0 dB <1.5 dB

1

1, 2

<1.0 dB <1.5 dB

<1.5 dB <1.5 dB

<1.0 dB

<1.5 dB

1

Not valid at frequencies of net-clock harmonics.

2

Valid for RF1 only.

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 5

Generator RF level repeatability

VSWR

RF 1 10 MHz to 2000 MHz

RF 2 10 MHz to 2200 MHz

RF 3 OUT 10 MHz to 2200 MHz

Attenuation of harmonics

RF 1, RF 2 f0 = 10 MHz to 200 MHz >20 dB RF 1, RF 2 f0 = 200 MHz to 2200 MHz >30 dB RF 3 OUT f0 = 10 MHz to 2200 MHz

Attenuation of nonharmonics

Phase noise

Carrier offset 20 kHz to 250 kHz

Residual FM

Residual AM

I/Q modulation

Carrier suppression data for frequency offset range

FM modulation

Deviation range 10 kHz to 440 kHz Deviation resolution 1 Hz Modulation frequency range 100 Hz to 50 kHz Modulation distortion modulation frequency 1 kHz,

Deviation uncertainty <5 % + resolution + residual FM

typical values after 1 h warmup time

output level ≥–80 dBm output level <–80 dBm

2000 MHz to 2200 MHz 2200 MHz to 2700 MHz

2200 MHz to 2700 MHz

up to 7 GHz

output level ≤+10 dBm

10 MHz to 2200 MHz, at f > 5 kHz from carrier

single sideband, f < 2.2 GHz

≥250 kHz

f < 2.2 GHz 30 Hz to 15 kHz ITU-T (formerly CCITT)

f < 2.2 GHz ITU-T (formerly CCITT)

0 Hz to ±135 kHz

deviation 80 kHz

<0.01 dB <0.1 dB

<1.2 <1.3 <1.6 <1.2 <1.6 <1.5 <1.7

>20 dB

>40 dB

<–100 dBc, 1 Hz <–110 dBc, 1 Hz

<50 Hz, rms, <200 Hz, peak <5 Hz, rms

<0.02%, rms

>40 dB

<2 %

RF analyzer

VSWR

RF 1 10 MHz to 2000 MHz

RF 2 10 MHz to 2200 MHz

RF 4 IN 10 MHz to 2200 MHz

Inherent spurious response

6 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

<1.2 2000 MHz to 2200 MHz 2200 MHz to 2700 MHz

2200 MHz to 2700 MHz

RF Attenuation

20 MHz to 2200 MHz, except 1816.115 MHz

→

Low Distortion,

<1.3

<1.6

<1.2

<1.6

<1.5

<1.6

<–50 dB

f

Inherent harmonics

RF 1, RF 2 RF 4 IN

= 50 MHz to 1100 MHz,

in

100 MHz to 2200 MHz

f

selected =

Phase noise

single sideband, f < 2.2 GHz

Carrier offset 20 kHz to 250 kHz

250 kHz to 400 kHz ≥400 kHz

Residual FM

f < 2.2 GHz 30 Hz to 15 kHz ITU-T (formerly CCITT)

Residual AM

f < 2.2 GHz ITU-T (formerly CCITT)

Power meter (wideband)

Frequency range

Level range

RF 1

RF 2

RF 4 IN

Level uncertainty

RF 1

RF 2

RF 4 IN

Level resolution

100 kHz to 2700 MHz

continuous power3

100 kHz to 2200 MHz +6 dBm to +47 dBm (50 W) 2200 MHz to 2700 MHz +10 dBm to +47 dBm (50 W) peak envelope power

continuous power

100 kHz to 2200 MHz –8 dBm to +33 dBm (2 W) 2200 MHz to 2700 MHz –4 dBm to +33 dBm (2 W) peak envelope power

continuous power and PEP

100 kHz to 2200 MHz –33 dBm to 0 dBm 2200 MHz to 2700 MHz –29 dBm to 0 dBm

input level +10 dBm to +20 dBm

50 MHz to 2700 MHz

input level +20 dBm to +47 dBm

50 MHz to 2700 MHz

input level –4 dBm to +6 dBm

50 MHz to 2700 MHz <1.0 dB5

input level +6 dBm to +33 dBm

50 MHz to 2700 MHz <0.5 dB

input level –29 dBm to –19 dBm

50 MHz to 2700 MHz <1.5 dB

input level –19 dBm to 0 dBm

50 MHz to 2700 MHz <0.8 dB

in manual mode 0.1 dB in remote control mode 0.01 dB

<–30 dB

<–20 dB

<–100 dBc, 1 Hz

<–110 dBc, 1 Hz

<–118 dBc, 1 Hz

<50 Hz, rms, <200 Hz, peak

<5 Hz, rms

<0.02%, rms

4

(PEP) +53 dBm (200 W)

4

(PEP) +39 dBm (8 W)

<1.0 dB

<0.5 dB

5

5, 6

5

Power meter (frequency-selective)

Frequency range

Frequency resolution

3

50 W in temperature range +5 °C to +30 °C, linear degradation down to 25 W at +45 °C.

4

Mean value of power versus time must be equal to or less than allowed continuous power.

5

Temperature range +5 °C to +20 °C or +35 °C to +45 °C and f > 2200 MHz: add 0.2 dB.

6

Calibrated for input level >+33 dBm only in frequency range 800 MHz to 2000 MHz.

Version 08.01, July 2007 R&S

10 MHz to 2700 MHz

0.1 Hz

®

CMU200 Universal Radio Communication Tester 7

Resolution bandwidths

10 Hz to 1 MHz in 1/2/3/5 steps

Level range

RF 1 continuous power3

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

peak envelope power

4

(PEP)

RF 2 continuous power

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

peak envelope power

4

(PEP)

RF 4 IN continuous power and PEP

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

Level uncertainty

in temperature range +20 °C to +35 °C

RF 1, RF 2 50 MHz to 2200 MHz

2200 MHz to 2700 MHz

RF 4 IN 50 MHz to 2200 MHz

2200 MHz to 2700 MHz

Level uncertainty

in temperature range +5 °C to +45 °C

RF 1, RF 2 50 MHz to 2200 MHz

2200 MHz to 2700 MHz

RF 4 IN 50 MHz to 2200 MHz

2200 MHz to 2700 MHz

Level resolution

in manual mode in remote control mode

RF level measurement repeatability

typical values after 1 h warmup

input level ≥–40 dBm input level <–40 dBm

–40 dBm to +47 dBm (50 W)

–34 dBm to +47 dBm (50 W)

+53 dBm (200 W)

–54 dBm to +33 dBm (2 W)

–48 dBm to +33 dBm (2 W)

+39 dBm (8 W)

–80 dBm to 0 dBm

–74 dBm to 0 dBm

<0.5 dB

<0.7 dB

<0.9 dB

<1.0 dB

<1.1 dB

0.1 dB

0.01 dB

<0.01 dB

<0.03 dB

Spectrum analyzer

Frequency range

Span

Frequency resolution

Resolution bandwidths

Sweep time

Display

Marker

Display line

Display scale

Level range

RF 1 continuous power3

RF 2 continuous power

RF 4 IN continuous power and PEP up to 0 dBm

Level uncertainty

RF 1, RF 2 50 MHz to 2200 MHz

RF 4 IN 50 MHz to 2200 MHz

10 MHz to 2.7 GHz

zero span to full span

0.1 Hz

10 Hz to 1 MHz in 1/2/3/5 steps

depending on resolution bandwidth (RBW) ≥100 ms

560 dots, horizontal

up to 3, absolute/relative

1

10/20/30/50/80/100 dB

up to +47 dBm (50 W)

up to +53 dBm (200 W)

up to +33 dBm (2 W)

up to +39 dBm (8 W)

peak envelope power

4

(PEP)

4

(PEP)

in temperature range +20 °C to +35 °C

<0.5 dB 2200 MHz to 2700 MHz

<0.7 dB

<0.7 dB 2200 MHz to 2700 MHz

<0.9 dB

8 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Level uncertainty

RF 1, RF 2 50 MHz to 2200 MHz

RF 4 IN 50 MHz to 2200 MHz

in temperature range +5 °C to +45 °C

2200 MHz to 2700 MHz

<1.0 dB

<1.1 dB

Reference level for full dynamic range

RF Attenuation

→

Low Noise,

logarithmic level display

RF 1 +10 dBm to +47 dBm RF 2

–4 dBm to +33 dBm

RF 4 IN –22 dBm to 0 dBm

Displayed average noise level

RF Attenuation

→

Low Noise,

RBW → 1 kHz,

10 MHz to 2200 MHz 2200 MHz to 2700 MHz

<–100 dBc

<–95 dBc

Inherent spurious response

RF Attenuation

→

Low Distortion,

20 MHz to 2200 MHz, except 1816.115 MHz

<–50 dB

Inherent harmonics

RF 1, RF 2 RF 4 IN

f

= 50 MHz to 1100 MHz,

in

100 MHz to 2200 MHz

f

selected =

<–30 dB

<–20 dB

General specifications

Operating temperature range

Storage temperature range

Humidity

Electromagnetic compatibility

Electrical safety

Mechanical resistance

Vibration sinusoidal in line with EN 60068-2-6, EN 61010-1,

Vibration random in line with EN 60068-2-64

Shock in line with EN 60068-2-27, MIL-STD-

Power supply

Input

Power consumption base unit

+5 °C to +45 °C,

in line with EN60068-2-1 and -2 –25 °C to +60 °C,

in line with EN60068-2-1 and -2 +40 °C, non-condensing 80 % relative humidity,

in line with EN 60068-2-3

in line with EMC Directive 89/336/EEC,

applied standard: EN 61326

(immunity for industrial environment;

class B emissions)

IEC 61010-1, EN 61010-1, UL3111-1,

CAN/CSA-C22.2 No. 1010.1

non-operating mode

MIL-T-28800 D class 5,

5 Hz to 150 Hz, max. 2 g at 55 Hz,

55 Hz to 150 Hz, 0.5 g const

10 Hz to 300 Hz, acceleration 1.2 g rms

810D

40 g shock spectrum

power factor correction,

in line with EN61000-3-2

100 V to 240 V ±10 % (AC), max. 500 VA,

50 Hz to 400 Hz –5 % to +10 %

approx. 130 W with typical options

approx. 180 W

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 9

Display

Resolution 640 × 480 pixels (VGA resolution) Pixel failure rate <2 × 10–5

Dimensions

Weight

21 cm TFT color display (8.4”)

W × H × D, overall 465.1 mm × 197.3 mm × 517.0 mm

18.31 in × 7.77 in × 20.35 in

(19” 1/1, 4 HU, 450)

base unit approx. 14 kg

approx. 30.86 lb with typical options approx. 18 kg

approx. 39.68 lb

Inputs and outputs (rear panel)

IF 3 RX CH1

Frequency WCDMA

Max. output level 0 dBm Impedance 50 Ω

Remote control interfaces

IEC/IEEE bus IEC 60625-2 (IEEE 488.2) 24-pin Amphenol connector Serial interface COM 1, COM 2 RS-232-C (COM) 9-pin D-Sub connector

Printer interface LPT

Keyboard

External monitor (VGA)

BNC female

7.68 MHz

other networks/RF

parallel (Centronics compatible) 25-pin D-Sub connector

PS/2 connector

15-pin D-Sub connector

10.7 MHz

10 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

GSM specifications – mobile station test

RF generator

Modulation

Frequency range

Attenuation of inband spurious emissions

Inherent phase error

Inherent EVM

Frequency settling time

Output level range

RF 1 –130 dBm to –27 dBm RF 2 –130 dBm to –10 dBm RF 3 OUT –90 dBm to +13 dBm

Output level range

RF 1 –130 dBm to –31 dBm RF 2 –130 dBm to –14 dBm RF 3 OUT –90 dBm to +9 dBm

Output level resolution

Output level uncertainty

RF 1, RF 2 output level >–117 dBm <0.5 dB RF 3 OUT –90 dBm to +10 dBm (GMSK)

Output level uncertainty

RF 1, RF 2 output level >–117 dBm <0.7 dB RF 3 OUT –90 dBm to +10 dBm (GMSK)

GMSK, B × T = 0.3

8PSK

GSM400 band 460 MHz to 468 MHz

GSM850 band 869 MHz to 894 MHz GSM900 band 921 MHz to 960 MHz GSM1800 band 1805 MHz to 1880 MHz GSM1900 band 1930 MHz to 1990 MHz

>50 dB

GMSK <1°, rms

8PSK <2 %, rms

to residual phase of 4°

GMSK

8PSK

0.1 dB

in temperature range +20 °C to 35 °C

–90 dBm to +6 dBm (8PSK)

in temperature range +5 °C to 45 °C

–90 dBm to +6 dBm (8PSK)

488 MHz to 496 MHz

<4°, peak

<500 μs

<0.7 dB

<0.9 dB

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 11

R&S®CMU-B95 option additional RF generator

Modulation

Frequency range

Frequency resolution

Frequency uncertainty

Inherent phase error

Output level range

RF 1 without R&S®CMU-U99

RF 2 –110 dBm to –60 dBm

Output level range

RF 1 without R&S®CMU-U99

RF 2 –110 dBm to –64 dBm

Output level resolution

Reduced input level range

RF 1 continuous input power max. 2 W

GMSK, B × T = 0.3

8PSK

GSM400 band 460 MHz to 468 MHz

488 MHz to 496 MHz GSM850 band 869 MHz to 894 MHz GSM900 band 921 MHz to 960 MHz GSM1800 band 1805 MHz to 1880 MHz GSM1900 band 1930 MHz to 1990 MHz

200 kHz

same as time base,

see base unit specifications

GMSK <5°, rms

GMSK

®

with R&S

8PSK

with R&S

1 dB

if R&S

CMU-U99

®

CMU-U99

®

CMU-B95 is installed

–122 dBm to –72 dBm

–110 dBm to –60 dBm

–122 dBm to –76 dBm

–110 dBm to –64 dBm

R&S®CMU-B96 option additional RF generator

Path 1 for GSM

Modulation

Frequency range

Frequency resolution

Frequency uncertainty

Inherent phase error

12 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

GMSK, B × T = 0.3

8PSK

GSM400 band 460 MHz to 468 MHz

488 MHz to 496 MHz GSM850 band 869 MHz to 894 MHz GSM900 band 921 MHz to 960 MHz GSM1800 band 1805 MHz to 1880 MHz GSM1900 band 1930 MHz to 1990 MHz

2.5 kHz

same as time base,

see base unit specifications

GMSK <5°, rms

Output level range

RF 1 without R&S®CMU-U99

GMSK

–115 dBm to –72 dBm

–103 dBm to –60 dBm

with R&S

®

CMU-U99

RF 2 –103 dBm to –60 dBm

Output level range

RF 1 without R&S®CMU-U99

8PSK

–115 dBm to –76 dBm

–103 dBm to –64 dBm

with R&S

®

CMU-U99

RF 2 –103 dBm to –64 dBm

Output level range

RF 1 without R&S®CMU-U99

GMSK overrange mode

®

with R&S

CMU-U99

–110 dBm to –28 dBm

–90 dBm to –14 dBm

RF 2 –90 dBm to –14 dBm RF 3 OUT –70 dBm to +9 dBm

Output level range

RF 1 without R&S®CMU-U99

8PSK overrange mode

®

with R&S

CMU-U99

–110 dBm to –32 dBm

–90 dBm to –18 dBm

RF 2 –90 dBm to –18 dBm RF 3 OUT –70 dBm to +5 dBm

Output level resolution

1 dB

Influence on RF interface

®

CMU-B96 is installed

Reduced input level range

RF 1 continuous input power max. 2 W

RF level uncertainty

if R&S

®

usage of R&S

CMU-B96 in overrange mode may influence all RF signal levels and their quality

RF analyzer

Frequency range

Power meter (frequency-selective)

Level range

RF 4 IN continuous power and PEP –80 dBm to 0 dBm

Level uncertainty

Level resolution

Measurement bandwidth

GSM400 band 450 MHz to 458 MHz

478 MHz to 486 MHz GSM850 band 824 MHz to 849 MHz GSM900 band 876 MHz to 915 MHz GSM1800 band 1710 MHz to 1785 MHz GSM1900 band 1850 MHz to 1910 MHz

continuous power3 –40 dBm to +47 dBm (50 W) RF 1 peak envelope power continuous power –54 dBm to +33 dBm (2 W) RF 2 peak envelope power

4

(PEP) +53 dBm (200 W)

4

(PEP) +39 dBm (8 W)

in temperature range +20 °C to +35 °C <0.5 dB in temperature range +5 °C to +45 °C <0.7 dB

in manual mode 0.1 dB in remote control mode 0.01 dB

selectable 500 kHz or 600 kHz

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 13

Modulation analysis

Level range

RF 1 see footnote4 –6 dBm to +53 dBm RF 2 see footnote4 –20 dBm to +39 dBm RF 4 IN –60 dBm to 0 dBm

Inherent phase error

Inherent EVM

Frequency measurement uncertainty

Measurement bandwidth

peak envelope power (PEP)

GMSK <0.6°, rms

<2°, peak

8PSK ≤1.0 %, rms

≤10 Hz + drift of time base,

see base unit specifications

selectable 500 kHz or 600 kHz

Burst power measurement

→

Reference level for full dynamic range

RF 1 see footnote4 +10 dBm to +53 dBm RF 2 see footnote4 –4 dBm to +39 dBm RF 4 IN –22 dBm to 0 dBm

Reference level for full dynamic range

RF 1 see footnote4 +6 dBm to +49 dBm RF 2 see footnote4 –8 dBm to +35 dBm RF 4 IN –26 dBm to –4 dBm

Dynamic range

Relative measurement uncertainty

Resolution

Measurement bandwidth

GMSK, RF Attenuation

8PSK, RF Attenuation

Filter → 500 kHz, rms,

RF Attenuation

GMSK >72 dB 8PSK >69 dB

result > –40 dB <0.1 dB –60 dB ≤ result ≤ –40 dB <0.5 dB

in active part of burst 0.1 dB

selectable 500 kHz or 600 kHz

→

Low Noise

→

Low Noise

14 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Spectrum due to modulation

→

Reference level for full dynamic range

RF 1 +10 dBm to +47 dBm RF 2 –4 dBm to +33 dBm RF 4 IN –22 dBm to 0 dBm

Test method

Filter bandwidth

Measurement

Dynamic range

GMSK, RF Attenuation

relative measurement, averaging

30 kHz resolution filter, 5 pole

at an offset of 100, 200, 250, 400, 600, 800, 1000, 1200,

with offset ≥1200 kHz >74 dB

Low Noise

1400, 1600, 1800 kHz

Spectrum due to switching

→

Reference level for full dynamic range

RF 1 +10 dBm to +47 dBm RF 2 –4 dBm to +33 dBm RF 4 IN –22 dBm to 0 dBm

Test method

Filter bandwidth

Measurement

Dynamic range

GMSK, RF Attenuation

absolute measurement, max. hold over

30 kHz resolution filter, 5 pole

at an offset of 400, 600, 800, 1200, 1800 kHz

with offset ≥1200 kHz >72 dB

Low Noise

several measurements

R&S®CMU-B52 option speech codec

Speech decoder output

Output impedance <10 Ω Maximum output current 20 mA, peak Full-range output level 1 V, peak

Speech coder input

Input impedance 100 kΩ Full-range input level low sensitivity

SPEECH HANDSET OUT 9-pin D-Sub connector

SPEECH HANDSET IN 9-pin D-Sub connector

1.4 V, peak

high sensitivity

0.1 V, peak

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 15

TDMA specifications – mobile station test

RF generator

Frequency range

Frequency resolution

Frequency uncertainty

Output level range

RF 1 –130 dBm to –32 dBm RF 2 –130 dBm to –15 dBm RF 3 OUT –90 dBm to +8 dBm

Output level resolution

Output level uncertainty

Modulation

Uncertainty EVM <2.5 %, rms Carrier suppression >40 dB

signaling mode

US Cellular 869 MHz to 894 MHz PCS (US) 1930 MHz to 1990 MHz

non-signaling mode 10 MHz to 2200 MHz

non-signaling mode 1 Hz

same as time base,

see base unit specifications

0.1 dB

see base unit specifications

π/4 DQPSK or unmodulated (non-signaling mode)

RF analyzer

Frequency range

Frequency resolution

Frequency uncertainty

Modulation analysis

Frequency range

EVM

I/Q offset

I/Q imbalance

16 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

signaling mode

US Cellular 824 MHz to 849 MHz PCS (US) 1850 MHz to 1910 MHz

non-signaling mode 10 MHz to 2200 MHz

non-signaling mode 1 Hz

same as time base,

see base unit specifications

signaling mode

US Cellular 824 MHz to 849 MHz PCS (US) 1850 MHz to 1910 MHz

residual <2.0 %, rms residual <4 %, peak

residual <–50 dB (0.3%)

Frequency measurement range

Frequency measurement uncertainty

–2 kHz to +2 kHz

≤5 Hz + drift of time base,

see base unit specifications

Power meter (frequency-selective)

Level range

Level uncertainty

see base unit specifications

Power versus time measurement

Reference level for full dynamic range

RF 1 +4 dBm to +47 dBm RF 2 –10 dBm to +33 dBm RF 4 IN –28 dBm to –6 dBm

Dynamic range

Relative measurement uncertainty

Residual leakage power level

Filter

→

100 kHz, rms,

→

RF Attenuation

result > –40 dB <0.1 dB –60 dB ≤ result ≤ –40 dB <0.5 dB

<–65 dBm

Low Noise

>74 dB

Adjacent channel power measurement

Dynamic range

first adjacent channel >45 dB second and third adjacent channel >55 dB

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 17

AMPS specifications – mobile station test

RF generator

Frequency range

US Cellular 869 MHz to 894 MHz

Frequency range

Frequency resolution

Frequency uncertainty

Output level range

RF 1 –130 dBm to –27 dBm RF 2 –130 dBm to –10 dBm RF 3 OUT –99 dBm to +13 dBm

Output level resolution

Output level uncertainty

FM modulation

Deviation range 100 Hz to 20 kHz Deviation resolution 1 Hz Modulation frequency range 100 Hz to 15.999 kHz Modulation distortion SINAD, modulation frequency 1 kHz,

Residual FM BW 300 Hz to 3 kHz <10 Hz, rms Deviation uncertainty modulation frequency 1 kHz,

Deviation frequency response modulation frequency

signaling mode

non-signaling mode 10 MHz to 2200 MHz

non-signaling mode 1 Hz

same as time base,

see base unit specifications

0.1 dB

see base unit specifications and

deviation 8 kHz, BW 30 Hz to 15 kHz

300 Hz to 15.999 kHz

add 0.1 dB

≥40 dB

<2 % of setting + residual FM

≤1 dB

RF analyzer

Frequency range

US Cellular 824 MHz to 849 MHz

Frequency range

Frequency resolution

Frequency uncertainty

18 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

signaling mode

non-signaling mode 10 MHz to 2200 MHz

non-signaling mode 1 Hz

same as time base,

see base unit specifications

Power meter (frequency-selective)

Max. level range

RF 1 0 dBm to +53 dBm RF 2 –14 dBm to +39 dBm RF 4 IN –37 dBm to +0 dBm

Level uncertainty

Level resolution

see base unit specifications

0.1 dB

FM measurement

Dynamic range

RF bandwidth

Deviation range

Resolution

Modulation frequency range

Residual FM

Deviation uncertainty

Carrier frequency error

Measurement range –47 kHz to +47 kHz Measurement uncertainty ≤2 kHz + drift of time base,

30 dB below max. level

2 × deviation + 4 × modulation frequency 136 kHz

0 Hz to 47 kHz

1 Hz

100 Hz to 18 kHz

BW 300 Hz to 3 kHz <5 Hz, rms BW 6 Hz to 20 kHz <18 Hz, rms

BW 6 Hz to 20 kHz <1 % of reading + residual FM

see base unit specifications

AF generator

See specifications of R&S®CMU-B41 option audio generator/analyzer

AF analyzer

See specifications of R&S®CMU-B41 option audio generator/analyzer

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 19

CDMA2000® specifications – mobile station test

Standards

RF generator

CDMA2000 CDMA2000

®

standards

®

test standards

TIA/EIA IS-2000 Rev. 0

TIA/EIA IS-98-F

Frequency range

Frequency resolution

Frequency uncertainty

Output level range

Output level resolution

Output level uncertainty

RF 1, RF 2

RF 3 OUT

Output level uncertainty

RF 1, RF 2

RF 3 OUT

US/Korean Cellular (band class 0) 860.025 MHz to 893.985 MHz North American PCS (band class 1) 1930.000 MHz to 1990.000 MHz TACS band (band class 2) 917.0125 MHz to 959.9875 MHz JTACS band (band class 3) 832.0125 MHz to 869.9875 MHz Korean PCS (band class 4) 1840.000 MHz to 1870.000 MHz NMT-450 (band class 5) 421.675 MHz to 493.480 MHz IMT-2000 (band class 6) 2110.000 MHz to 2169.950 MHz North American 700 MHz Cellular band

(band class 7) 1800 MHz band (band class 8) 1805.000 MHz to 1879.950 MHz 900 MHz band (band class 9) 925.000 MHz to 958.750 MHz secondary 800 MHz band (band class 10) 851.000 MHz to 939.975 MHz 400 MHz european PAMR (band class 11) 421.675 MHz to 493.475 MHz 800 MHz PAMR band (band class 12) 915.0125 MHz to 920.9875 MHz

2.5 GHz IMT-2000 extension (band class 13)

US PCS 1.9 GHz band (band class 14) 1930.000 MHz to 1995.000 MHz AWS band (band class 15) 2110.000 MHz to 2155.000 MHz US 2.5 GHz band (band class 16) 2624.000 MHz to 2690.000 MHz US 2.5 GHz forward link only band

(band class 17)

channel spacing in line with standard

same as time base,

modulated signal

f < 2200 MHz –120 dBm to –33 dBm RF 1 f ≥ 2200 MHz –120 dBm to –39 dBm f < 2200 MHz –120 dBm to –16 dBm RF 2 f ≥ 2200 MHz –120 dBm to –22 dBm f < 2200 MHz –99 dBm to +5 dBm RF 3 OUT f ≥ 2200 MHz –99 dBm to –1 dBm

modulated signal 0.1 dB

in temperature range +20 °C to +35 °C

output level ≥ –108 dBm f < 2200 MHz <0.5 dB f ≥ 2200 MHz <0.7 dB –80 dBm to +4 dBm f < 2200 MHz <0.7 dB f ≥ 2200 MHz <0.9 dB

in temperature range +5 °C to +45 °C

output level ≥ –108 dBm f < 2200 MHz <0.7 dB f ≥ 2200 MHz <1.5 dB –80 dBm to +4 dBm f < 2200 MHz <0.9 dB f ≥ 2200 MHz <1.5 dB

746.000 MHz to 764.000 MHz

2620.000 MHz to 2690 MHz

2624.000 MHz to 2690.000 MHz

see base unit specifications

20 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Modulation

Dual BPSK, multiple QPSK 1.2288 Mcps AWGN see AWGN generator Carrier suppression >35 dB Waveform quality factor (ρ) Code channel level uncertainty relative to the total CDMA output power

Code channel resolution 0.1 dB Code channel level range relative to the total CDMA output power

AWGN generator

Bandwidth >1.8 MHz Output level resolution 0.1 dB Output level uncertainty bandwidth 1.23 MHz approx. 0.2 dB Output level range relative to total CDMA output power –20 dB to +4 dB

Supported service options

Loopback service options SO 2, 9, 55 Speech service options SO 1, 3, 17, 0x8000 Test data service option SO 32 Packet data service option SO 33 Messaging tele service option SO 6, 14

>0.985

F-PICH, F-PCH, F-FCH, F-SCH1, F-SCH2 all other channels

PICH, SYNC, FCH, SCH0, SCH1, PCH QPCH (relative to PICH level)

in signaling mode

approx. 0.1 dB

approx. 0.25 dB

–20 dB to –1 dB

–5 dB to +2 dB

RF analyzer

Frequency range

Measurement filter

Frequency resolution

Frequency uncertainty

US/Korean Cellular (band class 0) 815.025 MHz to 848.985 MHz North American PCS (band class 1) 1850.000 MHz to 1910.000 MHz TACS band (band class 2) 872.0125 MHz to 914.9875 MHz JTACS band (band class 3) 887.0125 MHz to 924.9875 MHz Korean PCS (band class 4) 1750.000 MHz to 1780.000 MHz NMT-450 (band class 5) 411.675 MHz to 483.480 MHz IMT-2000 (band class 6) 1920.000 MHz to 1979.950 MHz North American 700 MHz Cellular band

(band class 7) 1800 MHz band (band class 8) 1710.000 MHz to 1784.950 MHz 900 MHz band (band class 9) 880.000 MHz to 913.750 MHz secondary 800 MHz band (band class 10) 806.000 MHz to 900.975 MHz 400 MHz european PAMR (band class 11) 411.675 MHz to 483.475 MHz 800 MHz PAMR band (band class 12) 870.0125 MHz to 875.9875 MHz

2.5 GHz IMT-2000 extension (band class 13)

US PCS 1.9 GHz band (band class 14) 1850.000 MHz to 1915.000 MHz AWS band (band class 15) 1710.000 MHz to 1755.000 MHz US 2.5 GHz band (band class 16) 2502.000 MHz to 2568.000 MHz

in line with standard bandwidth 1.23 MHz

channel spacing in line with standard

same as time base,

776.000 MHz to 794.000 MHz

2500.000 MHz to 2570.000 MHz

see base unit specifications

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 21

Power meter (frequency-selective)

Level range

RF 1 f < 2200 MHz

RF 2 f < 2200 MHz

RF 4 IN f < 2200 MHz

Level uncertainty

RF 1, RF 2, RF 4 IN

Level resolution

HPSK, O-QPSK signal

–40 dBm to +44 dBm f ≥ 2200 MHz

f ≥ 2200 MHz

in temperature range +20 °C to +35 °C

f < 2200 MHz f ≥ 2200 MHz

in temperature range +5 °C to +45 °C

f < 2200 MHz f ≥ 2200 MHz

0.1 dB

–34 dBm to +44 dBm

–54 dBm to +30 dBm

–48 dBm to +30 dBm

–80 dBm to –9 dBm

–74 dBm to –9 dBm

<0.5 dB

<0.7 dB

<0.9 dB

Modulation analyzer

Level range

RF 1 f < 2200 MHz

RF 2 f < 2200 MHz

RF 4 IN f < 2200 MHz

RC1, RC2 (O-QPSK)

ρ uncertainty Frequency measurement range –3 kHz to +3 kHz Frequency measurement uncertainty f < 2200 MHz

RC3, RC4 (HPSK)

ρ uncertainty Frequency measurement range –3 kHz to +3 kHz Frequency measurement uncertainty <10 Hz + drift of time base,

Relative measurement uncertainty result >–33 dB <0.1 dB

HPSK, O-QPSK signal

–40 dBm to +44 dBm f ≥ 2200 MHz

f ≥ 2200 MHz

waveform quality, error vector magnitude, magnitude error, phase error

for ρ 0.9 to 1 <0.003

f ≥ 2200 MHz

waveform quality, error vector magnitude, magnitude error, phase error, channel power, code domain power, peak code domain error power,

for ρ 0.9 to 1 <0.003

–34 dBm to +44 dBm

–54 dBm to +30 dBm

–48 dBm to +30 dBm

–80 dBm to –9 dBm

–74 dBm to –9 dBm

<10 Hz + drift of time base,

<15 Hz + drift of time base,

see base unit specifications

22 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Measurements

Modulation overview

Power standby/access-probe power

Spectrum Code Domain Power code domain power

Receiver FER for FCH, SCH

EVM versus time, graphical

ME versus time, graphical

PE versus time, graphical

I/Q analyzer

open loop time response

gated output power

maximum output power

minimum output power

code domain error power

channel power

time/phase offset relative to pilot

RLP/throughput statistics

forward power control

R&S®CMU-B85 option speech codec

Speech decoder output

Output impedance <10 Ω Maximum output current 20 mA, peak Full-range output level 1 V, peak

Speech coder input

Input impedance 100 kΩ Full-range input level low sensitivity

SPEECH HANDSET OUT 9-pin D-Sub connector

SPEECH HANDSET IN 9-pin D-Sub connector

1.4 V, peak

high sensitivity

0.1 V, peak

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 23

1xEV-DO specifications – access terminal test

Standards

1xEV-DO standards TIA/EIA IS-856-2 1xEV-DO test standards (access terminal) TIA/EIA IS-866-A

RF generator

Frequency range

Frequency resolution

Frequency uncertainty

Statistics

Statistic count 1 to 1000 Values current, average, min/max

Trigger

Trigger sources free run, internal, external, IF power,

Trigger output 24-pin D-Sub connector AUX 3 super frame, power control frame, paging

Output level range

RF 1 f < 2200 MHz

RF 2 f < 2200 MHz

RF 3 OUT f < 2200 MHz

Output level resolution

US/Korean Cellular (band class 0) 860.025 MHz to 893.985 MHz North American PCS (band class 1) 1930.000 MHz to 1990.000 MHz Public Safety Bands (PSB) 772.000 MHz to 802.000 MHz TACS band (band class 2) 917.0125 MHz to 959.9875 MHz JTACS band (band class 3) 832.0125 MHz to 869.9875 MHz Korean PCS (band class 4) 1840.000 MHz to 1870.000 MHz NMT-450 (band class 5) 421.675 MHz to 493.480 MHz IMT-2000 (band class 6) 2110.000 MHz to 2169.950 MHz North American 700 MHz cellular band

(band class 7) 1800 MHz band (band class 8) 1805.000 MHz to 1879.950 MHz 900 MHz band (band class 9) 925.000 MHz to 958.750 MHz secondary 800 MHz band (band class 10) 851.000 MHz to 939.975 MHz 400 MHz european PAMR (band class 11) 421.675 MHz to 493.475 MHz 800 MHz PAMR band (band class 12) 915.0125 MHz to 920.9875 MHz

2.5 GHz IMT-2000 extension (band class 13)

US PCS 1.9 GHz band (band class 14) 1930.000 MHz to 1995.000 MHz AWS band (band class 15) 2110.000 MHz to 2155.000 MHz US 2.5 GHz band (band class 16) 2624.000 MHz to 2690.000 MHz US 2.5 GHz forward link only band

(band class 17)

channel spacing in line with standard

same as time base,

modulated signal

f ≥ 2200 MHz

modulated signal 0.1 dB

746.000 MHz to 764.000 MHz

2620.000 MHz to 2690 MHz

2624.000 MHz to 2690.000 MHz

see base unit specifications

RF power

frame, sync frame, PP2S

–120 dBm to –33 dBm

–120 dBm to –39 dBm

–120 dBm to –16 dBm

–120 dBm to –22 dBm

–99 dBm to +5 dBm

–99 dBm to –1 dBm

24 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Output level uncertainty

RF 1, RF 2 output level ≥–108 dBm

RF 3 OUT –80 dBm to +4 dBm

in temperature range +20 °C to +35 °C

f < 2200 MHz f ≥ 2200 MHz

<0.5 dB

<0.7 dB

<0.9 dB

Output level uncertainty

RF 1, RF 2 output level ≥–108 dBm

RF 3 OUT –80 dBm to +4 dBm

in temperature range +5 °C to +45 °C

f < 2200 MHz f ≥ 2200 MHz

<0.7 dB

<1.5 dB

<0.9 dB

<1.5 dB

Modulation

Dual BPSK 1.2288 Mcps AWGN see AWGN generator Carrier suppression >35 dB Waveform quality factor (ρ) >0.985 Code channel level uncertainty relative to total 1xEV-DO output power approx. 0.1 dB Code channel resolution 0.1 dB Code channel level range relative to the total 1xEV-DO output power

PICH, SYNC, FCH, SCH0, SCH1, PCH QPCH (relative to PICH level)

–20 dB to –1 dB

–5 dB to +2 dB

AWGN generator

Bandwidth >1.8 MHz Output level resolution 0.1 dB Output level uncertainty bandwidth 1.23 MHz approx. 0.2 dB Output level range relative to total 1xEV-DO output power –20 dB to +4 dB

Supported applications

in signaling mode

Test applications FTAP/RTAP, FETAP/RETAP Default signaling application Default packet application

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 25

RF analyzer

Frequency range

Measurement filter

Frequency resolution

Frequency uncertainty

Statistics

Statistic count 1 to 1000 Values current, average, min/max

Trigger

Trigger sources free run, internal, external, IF power, RF

Trigger output 24-pin D-Sub connector AUX 3 ControlSlot, ControlChannel, slot, PP2S

US/Korean Cellular (band class 0) 815.025 MHz to 848.985 MHz North American PCS (band class 1) 1850.000 MHz to 1910.000 MHz Public Safety Bands (PSB) 742.000 MHz to 772.000 MHz TACS band (band class 2) 872.0125 MHz to 914.9875 MHz JTACS band (band class 3) 887.0125 MHz to 924.9875 MHz Korean PCS (band class 4) 1750.000 MHz to 1780.000 MHz NMT-450 (band class 5) 411.675 MHz to 483.480 MHz IMT-2000 (band class 6) 1920.000 MHz to 1979.950 MHz North American 700 MHz Cellular band

(band class 7) 1800 MHz band (band class 8) 1710.000 MHz to 1784.950 MHz 900 MHz band (band class 9) 880.000 MHz to 913.750 MHz secondary 800 MHz band (band class 10) 806.000 MHz to 900.975 MHz 400 MHz european PAMR (band class 11) 411.675 MHz to 483.475 MHz 800 MHz PAMR band (band class 12) 870.0125 MHz to 875.9875 MHz

2.5 GHz IMT-2000 extension (band class 13)

US PCS 1.9 GHz band (band class 14) 1850.000 MHz to 1915.000 MHz AWS band (band class 15) 1710.000 MHz to 1755.000 MHz US 2.5 GHz band (band class 16) 2502.000 MHz to 2568.000 MHz

in line with standard bandwidth 1.23 MHz

channel spacing in line with standard

same as time base,

776.000 MHz to 794.000 MHz

2500.000 MHz to 2570.000 MHz

see base unit specifications

power

Power meter (frequency-selective)

Level range

RF 1 f < 2200 MHz

RF 2 f < 2200 MHz

RF 4 IN f < 2200 MHz

Level uncertainty

RF 1, RF 2, RF 4 IN in temperature range +20 °C to +35 °C

Level resolution

26 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

modulated signal

f ≥ 2200 MHz

f < 2200 MHz f ≥ 2200 MHz

in temperature range +5 °C to +45 °C

f < 2200 MHz f ≥ 2200 MHz

0.1 dB

–40 dBm to +44 dBm

–34 dBm to +44 dBm

–54 dBm to +30 dBm

–48 dBm to +30 dBm

–80 dBm to –9 dBm

–74 dBm to –9 dBm

<0.5 dB

<0.7 dB

<0.9 dB

Modulation analyzer

Level range

RF 1 f < 2200 MHz

RF 2 f < 2200 MHz

RF 4 IN f < 2200 MHz

Waveform quality (ρ) uncertainty

Frequency measurement range

Frequency measurement uncertainty

Relative measurement uncertainty

Measurements

Modulation overview

Power Spectrum Code domain power code domain power

Receiver in signaling mode FTAP/RTAP, FETAP/RETAP

modulated signal

–40 dBm to +44 dBm f ≥ 2200 MHz

–34 dBm to +44 dBm

–54 dBm to +30 dBm f ≥ 2200 MHz

–48 dBm to +30 dBm

–80 dBm to –9 dBm f ≥ 2200 MHz

for ρ 0.9 to 1

–74 dBm to –9 dBm

<0.003

–3 kHz to +3 kHz

<10 Hz + drift of time base,

see base unit specifications result >–33 dB <0.1 dB

EVM versus time, graphical

ME versus time, graphical

PE versus time, graphical

I/Q analyzer

code domain error power

channel power

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 27

WCDMA specifications – mobile station (UE) test

Standard

Symbol rate

Synchronization output 2

Frequency 30.72 MHz / n, n = 1 to 32

3GPP FDD

3.84 MHz

BNC connector REF OUT 2

RF generator

Channels

reference measurement channels (RMC)

Channels

DPCH signaling radio bearer (SRB) 1.7 kbit/s, 2.5 kbit/s, 3.4 kbit/s, 13.6 kbit/s DPCH reference measurement channels

DPCH voice (echo or speech codec) 4.75 kbit/s, 5.15 kbit/s, 5.9 kbit/s,

Frequency range

Frequency offset

non-signaling mode

P-CPICH, P-SCH, S-SCH, P-CCPCH, PICH, DPCH, up to 4 HS-SCCHs, HSPDSCH, E-AGCH, E-RGCH/E-HICH

OCNS R99 OCNS R5 AWGN bandwidth ≥5.76 MHz

in line with 3GPP TS 34.121

signaling mode, codes selectable until conflict in code space occurs

P-CPICH, P-SCH, S-SCH, P-CCPCH, S-CCPCH, AICH, PICH, up to 4 HSSCCHs, HS-PDSCH OCNS R99 OCNS R5 AWGN

(RMC) in line with 3GPP TS 34.121

DL and UL DL/UL

BTFD

non-signaling mode

869 MHz to 894 MHz

signaling mode

band 1 band 2 band 3 band 4 band 5 band 6 band 7 band 8 band 9

–100 kHz to +100 kHz

16-channel orthogonal channel noise

6-channel orthogonal channel noise

12.2 kbit/s, 64 kbit/s, 144 kbit/s, 384 kbit/s

16-channel orthogonal channel noise

6-channel orthogonal channel noise

bandwidth ≥ 5.76 MHz

12.2 kbit/s, 64 kbit/s, 144 kbit/s, 384 kbit/s

144 kbit/s / 64 kbit/s, 384 kbit/s / 64 kbit/s,

384 kbit/s / 144 kbit/s

1.95 kbit/s, 4.75 kbit/s, 5.15 kbit/s,

5.9 kbit/s, 6.7 kbit/s, 7.4 kbit/s, 7.95 kbit/s

10.2 kbit/s, 12.2 kbit/s

6.7 kbit/s, 7.4 kbit/s, 7.95 kbit/s 10.2 kbit/s,

12.2 kbit/s

925 MHz to 960 MHz

1805 MHz to 1880 MHz

1930 MHz to 1990 MHz

2110 MHz to 2170 MHz

2620 MHz to 2690 MHz

2110 MHz to 2170 MHz

1930 MHz to 1990 MHz

1805 MHz to 1880 MHz

2110 MHz to 2155 MHz

869 MHz to 894 MHz

875 MHz to 885 MHz

2620 MHz to 2690 MHz

925 MHz to 960 MHz

1844.9 MHz to 1874.9 MHz

28 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Frequency resolution

Frequency setting

Output level range

RF 1 –120 dBm to –37 dBm RF 2 –120 dBm to –20 dBm RF 3 OUT –100 dBm to 0 dBm

Output level resolution

Output level uncertainty

RF 1, RF 2 output level ≥–120 dBm

RF 3 OUT output level ≥–80 dBm

Output level uncertainty

RF 1, RF 2 output level ≥–120 dBm

RF 3 OUT output level ≥–80 dBm

Output level setting

Channel levels

P-CPICH, P-SCH, S-SCH, P-CCPCH,

Channel levels

P-CPICH, P-SCH, S-SCH, P-CCPCH,

Signal quality

Error vector magnitude (EVM) global EVM for DL RMC in line with 3GPP

Signal quality

Error vector magnitude (EVM) global EVM for 16QAM

0.1 Hz

by channel number or frequency

manual mode 0.1 dB remote mode 0.01 dB

in temperature range +20 °C to +35 °C

f < 2200 MHz f ≥ 2200 MHz

in temperature range +5 °C to +45 °C

f < 2200 MHz f ≥ 2200 MHz

setting reference relative to CPICH or

non-signaling mode

PICH, DPCH, OCNS, HS-SCCH, HSPDSCH, E-AGCH, E-RGCH/E-HICH

signaling mode

S-CCPCH, PICH, AICH, DPCH, OCNS, HS-SCCH, HS-PDSCH

TS 34.121 C3.1 to C3.4 with DPCH/CPICH = 0 dB

16QAM

reference setup: 3GPP TS34.121 FRC H-Set3 for 16 QAM

<0.6 dB

<0.8 dB

<1.0 dB

<0.9 dB

<1.5 dB

<1.0 dB

<1.5dB

total output power

–30 dB to +15 dB relative to CPICH

<8 %, rms

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 29

R&S®CMU-B96 additional RF generator option

Path 2 for WCDMA

Standard

Frequency range

869 MHz to 894 MHz

Frequency range

band 1

Frequency resolution

Frequency uncertainty

Error vector magnitude (EVM)

Output level range

RF 1 without R&S®CMU-U99

RF 2 –103 dBm to –70 dBm

Output level resolution

Output level range

RF 1 without R&S®CMU-U99

RF 2 –90 dBm to –24 dBm RF 3 OUT –70 dBm to –1 dBm

Output level resolution

3GPP FDD

non-signaling mode

925 MHz to 960 MHz

1805 MHz to 1880 MHz

1930 MHz to 1990 MHz

2110 MHz to 2170 MHz

WCDMA signaling mode

2110 MHz to 2170 MHz band 2 band 3 band 4 band 5 band 6 band 8 band 9

2.5 kHz

same as time base,

global EVM for DL RMC in line with 3GPP TS 34.121 C3.1 to C3.4 with DPCH/CPICH = 0 dB

®

with R&S

RF1 and RF2 0.1 dB

overrange mode

with R&S

for overrange mode 1 dB

CMU-U99

®

CMU-U99

1930 MHz to 1990 MHz

1805 MHz to 1880 MHz

2110 MHz to 2170 MHz

869 MHz to 894 MHz

875 MHz to 885 MHz

925 MHz to 960 MHz

1844.9 MHz to 1874.9 MHz

see base unit specifications

<8 %, rms

–115 dBm to –82 dBm

–103 dBm to –70 dBm

–110 dBm to –38 dBm

–90 dBm to –24 dBm

Influence on RF interface

®

CMU-B96 is installed

Reduced input level range

RF 1 continuous input power max. 2 W

RF level uncertainty

if R&S

®

the usage of R&S mode may influence all RF signal levels and quality

CMU-B96 in overrange

30 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

RF analyzer (TX measurements)

Frequency range

Frequency offset

Frequency resolution

Frequency setting

Level setting

Max. level setting range

RF 1 peak envelope power4 (PEP) –38 dBm to +53 dBm RF 2 peak envelope power4 (PEP) –52 dBm to +39 dBm RF 4 IN peak envelope power (PEP) –77 dBm to +0 dBm

Statistics

Statistic count 1 to 1000 Values current, average, min/max

Trigger

Trigger sources free run, internal, external, IF power, slot,

Trigger input 15-pin D-Sub connector AUX 3 pin 8 external Trigger slot delay 0 to 14 slots Trigger delay offset –10239 to + 10239 × 1/4 chip Trigger output 15-pin D-Sub connector AUX 3 pin 2 to 5 frame, slot, TPC, HSDPCCH

Trigger

Trigger sources free run, external, slot, frame,signaling, IF

Trigger input 15-pin D-Sub connector AUX 3 pin 8 external Trigger slot delay 0 to 14 slots Trigger delay offset –10239 to + 10239 × 1/4 chip Trigger output 15-pin D-Sub connector AUX 3 pin 2 to 4

non-signaling mode

824 MHz to 849 MHz

880 MHz to 915 MHz

1710 MHz to 1785 MHz

1850 MHz to 1910 MHz

1920 MHz to 1980 MHz

2500 MHz to 2570 MHz

signaling mode

band 1 band 2 band 3 band 4 band 5 band 6 band 7 band 8 band 9

–100 kHz to +100 kHz

1 Hz

by channel number or frequency

by autoranging or manual mode

non-signaling mode

signaling mode

15-pin D-Sub connector AUX 3 pin 5, depending on signaling state and trigger source

1920 MHz to 1980 MHz

1850 MHz to 1910 MHz

1710 MHz to 1785 MHz

1710 MHz to 1755 MHz

824 MHz to 849 MHz

830 MHz to 840 MHz

2500 MHz to 2570 MHz

880 MHz to 915 MHz

1749.9 MHz to 1784.9 MHz

frame, TPC, HSDPCCH, auto

power, TPC, preamble, PRACH-MSG part,

compressed mode, change of TFC,

HSDPCCH, auto

frame, slot, TPC

preamble, PRACH-MSG part, compressed

mode,change of TFC, HSDPCCH

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 31

Modulation analysis

Measurement filter

Analysis modes

Input level range

RF 1 continuous power3

RF 2 continuous power

RF 4 IN continuous power and PEP –50 dBm to 0 dBm

Error vector magnitude (EVM)

Measurement range up to 25% Applications

Measured parameters error vector magnitude

Inherent EVM

Resolution 0.1% Measurement length QPSK mode

Marker in graphical menus reference , Abs1, Abs2, D-line

Frequency error

Measurement range ±3 kHz Uncertainty f < 2200 MHz and max. value of 10 slots

Resolution 1 Hz

I/Q offset

Inherent I/Q offset <–55 dB Resolution 0.01 dB

I/Q imbalance

Inherent I/Q imbalance <–30 dB Resolution 0.01 dB

Peak code domain error (PCDE)

Inherent PCDE for SF = 4 <–40 dB Resolution 0.01 dB

receiver filter in line with standard

3.84 MHz, RRC,

α = 0.22

QPSK, WCDMA uplink

–21 dBm to +47 dBm

–16 dBm to +53 dBm

–35 dBm to +33 dBm

–30 dBm to +39 dBm

peak envelope power

4

(PEP)

4

(PEP)

overview

non-signaling mode

EVM versus time, graphical

ME versus time, graphical

PE versus time, graphical

I/Q analyzer

magnitude error

phase error

I/Q origin offset

I/Q imbalance

peak code domain error

waveform quality

RF Attenuation RF Attenuation

with R&S

→ →

®

CMU-Z6 calibration

and f < 2200 MHz

RF Attenuation

with R&S

→

®

CMU-Z6 calibration and

f ≥ 2200 MHz

Low Noise Low Noise,

Low Noise,

<2.5 %, rms

<1.5 %, rms

<2.5 %, rms

1 timeslot (2560 chips)

WCDMA mode

1/4 timeslot (640 chips)

1 timeslot

<10 Hz + drift of time base, f ≥ 2200 MHz and average value of 10 slots

<10 Hz + drift of time base,

see base unit specifications

32 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

I/Q analyzer

Display QPSK mode and WCDMA mode

non-signaling mode

waveform type

zoom rotation measurement length

graphical display

constellation diagram,

vector diagram,

eye diagram I, Q, I/Q

1, 2, 5, 10, 20

0°, 45°

1 timeslot (2560 chips),

1/4 timeslot (640 chips)

Spectrum measurements

Reference level for full dynamic range

RF 1 rms

RF 2 rms

RF 4 IN rms

Adjacent channel leakage ratio (ACLR filter application)

Measurement filter receiver filter in line with standard Display bar graphs of rms and peak values,

Frequency offsets first adjacent channel

Uncertainty for –33 dBc first adjacent channel level

Dynamic range

(High dynamic mode

→

On)

Resolution 0.1 dB Measurement length 1 timeslot (2560 chips)

Adjacent channel leakage ratio (ACLR FFT/OBW application)

Measurement filter receiver filter in line with standard Display

Frequency offsets first adjacent channel

Resolution bandwidth 20 kHz,

Dynamic range

(High dynamic mode

→

On)

Occupied bandwidth measurement range 1 MHz to 6 MHz measurement uncertainty <50 kHz measurement resolution 20 kHz Measurement length ≥1 timeslot (2560 chips)

Spectrum emission mask (SEM application)

Measurement filter receiver filter in line with standard Display graphical and numerical values of current,

Version 08.01, July 2007 R&S

+14 dBm to +47 dBm

up to +53 dBm

+0 dBm to +33 dBm

up to +39 dBm

peak envelope power

4

(PEP)

4

(PEP)

–18 dBm to 0 dBm peak envelope power (PEP)

up to 0 dBm

3.84 MHz, RRC, α = 0.22

numerical values rms and peak of current,

average and max. values

±5 MHz second adjacent channel

±10 MHz

<0.5 dB for –43 dBc second adjacent channel level first adjacent channel second adjacent channel

<0.5 dB

>54 dB

>64 dB

1/2 timeslot (1280 chips)

1/4 timeslot (640 chips)

1/8 timeslot (320 chips)

3.84 MHz, RRC, α = 0.22

continuous spectrum with 25 MHz

bandwidth, numerical values rms and peak

of current, average and max. values

±5 MHz second adjacent channel

±10 MHz

3.84 MHz first adjacent channel second adjacent channel

>54 dB >64 dB

≥1/2 timeslot (1280 chips) ≥1/4 timeslot (640 chips) ≥1/8 timeslot (320 chips)

3.84 MHz, RRC, α = 0.22

average and max values

®

CMU200 Universal Radio Communication Tester 33

Resolution bandwidth frequency offset

2.5 MHz to 3.5 MHz

3.5 MHz to 7.5 MHz

7.5 MHz to 8.5 MHz

8.5 MHz to 12.5 MHz

30 kHz 1 MHz 1 MHz 1 MHz

Measurement interval ≥1 timeslot (2560 chips)

≥1/2 timeslot (1280 chips) ≥1/4 timeslot (640 chips) ≥1/8 timeslot (320 chips)

Power meter (frequency-selective)7

Measurement applications

maximum power, minimum power off power power versus slot inner loop power

Power versus slot

measurement width step width step count step delay

Level range

RF 1 continuous power3

RF 2 continuous power

RF 4 IN

peak envelope power

continuous power

4

8

peak envelope power (PEP)

Level uncertainty

in temperature range +20 °C to +35 °C

RF 1 –10 dBm to +47 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

–44 dBm to –10 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

RF 2 –24 dBm to +33 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

–60 dBm to –24 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

RF 4 IN –24 dBm to 0 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

–85 dBm to –24 dBm, rms

f < 2200 MHz

–83 dBm to –24 dBm, rms

f ≥ 2200 MHz

(PEP)

bandwidth approx. 7 MHz

3.84 MHz, RRC, α = 0.22

bandwidth approx. 7 MHz

3.84 MHz, RRC, α = 0.22

0.25, 0.5, 1 slot

1 slot to 30 slots 1 to 100 0 to 100

–52 dBm to +47 dBm –42 dBm to +53 dBm –66 dBm to +33 dBm –56 dBm to +39 dBm –89 dBm to 0 dBm –79 dBm to 0 dBm

<0.5 dB <0.7 dB

<0.7 dB <0.9dB

<0.5 dB <0.7 dB

<0.7 dB <0.9 dB

<0.5 dB <0.7 dB

<0.7 dB

<0.9 dB

7

The specified data is valid for RF Attenuation set to Low Noise.

8

Upper limit depends on crest factor.

34 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Level uncertainty

RF 1 –10 dBm to +47 dBm, rms

RF 2 –24 dBm to +33 dBm, rms

RF 4 IN –24 dBm to 0 dBm, rms

Level resolution

in temperature range +5 °C to +45 °C

f < 2200 MHz f ≥ 2200 MHz

–44 dBm to –10 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

–60 dBm to –24 dBm, rms

f < 2200 MHz f ≥ 2200 MHz

–85 dBm to –24 dBm, rms

f < 2200 MHz

–83 dBm to –24 dBm, rms

f ≥ 2200 MHz

0.01 dB

<0.7 dB <0.9 dB

<0.9 dB <1.1 dB

<0.7 dB <0.9 dB

<0.9 dB <1.1 dB

<0.7 dB <0.9 dB

<0.9 dB

<1.1 dB

Code domain power7

Measurement filter

Display modes

Spreading Factor (SF)

Level range

RF 1 –8 dBm to +47 dBm RF 2 –22 dBm to +33 dBm RF 4 IN –45 dBm to 0 dBm

Level uncertainty

Level resolution

receiver filter in line with standard 3.84 MHz, RRC, α = 0.22

auto mode manual setting 4, 8, 16, 32, 64, 128, 256

<0.5 dB

0.01 dB

CDP/code auto CDP/code manual CDP/code Rho auto CDP/code Rho manual

Receiver quality (bit error rate measurements)

Measurement types

Measurement method loopback mode 2,

Number of transport blocks 1 to 50000 DL/UL transport block size symmetric, asymmetric DL/UL timing 876 chips to 1172 chips

BER, BLER, DBLER, FDR

loopback mode 1 with RLC transparent

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 35

R&S®CMU-B52 option speech codec

Speech decoder output

Output impedance <10 Ω Maximum output current 20 mA, peak Full-range output level 1 V, peak

Speech coder input

Input impedance 100 kΩ

SPEECH HANDSET OUT 9-pin D-Sub connector

SPEECH HANDSET IN 9-pin D-Sub connector

low sensitivity 1.4 V, peak Full-range input level high sensitivity 0.1 V, peak

36 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Bluetooth® specifications

Standards

RF generator

Bluetooth

®

Version 1.1

Core Specifications

RF channel definition

Frequency range

Frequency resolution

Frequency offset range

Frequency offset resolution

Frequency uncertainty

Hopping scheme

Output level range

RF 1 –106 dBm to –33 dBm RF 2 –106 dBm to –12 dBm RF 3 OUT –90 dBm to +5 dBm

Output level uncertainty

RF 1, RF 2 <0.9 dB RF 3 OUT <1.1 dB

Output level uncertainty

RF 1, RF 2 <1.6 dB RF 3 OUT <1.6 dB

Output level resolution

Modulation

GFSK AC coupling cut-off frequency 100 Hz 1 Mbps, B × T = 0.5 Modulation index 11110000 pattern,

Modulation index range frequency deviation 100 kHz to 220 kHz 0.20 to 0.44 Modulation index resolution 0.01 Modulation index uncertainty 11110000 pattern,

2402 MHz + k × 1 MHz, k = 0 to 93

2402 MHz to 2495 MHz

channel spacing in line with standard 1 MHz

±500 kHz

1 kHz

±1 Hz + drift of time base,

see base unit specifications

modes in line with standard

modulated signal

in temperature range +20 °C to +35 °C

in temperature range +5 °C to +45 °C

0.1 dB

frequency deviation 160 kHz

Europe (except France), USA France RX/TX single frequency Reduced hopping

0.32

±5 %

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 37

RF analyzer

RF channel definition

Frequency range

Frequency resolution

Frequency uncertainty

Hopping scheme

2402 MHz + k × 1 MHz, k = 0 to 93

2402 MHz to 2495 MHz

channel spacing in line with standard 1 MHz

±1 Hz + drift of time base,

see base unit specifications

modes in line with standard

Europe (except France), USA France RX/TX single frequency reduced hopping

Power meter (frequency-selective) and power versus time

Measurement bandwidth

Reference level for full dynamic range

RF 1 0 dBm to +41 dBm RF 2 –14 dBm to +33 dBm RF 4 IN –32 dBm to 0 dBm

Dynamic range

Level uncertainty

RF 1, RF 2 from full scale setting down to –25 dB <0.7 dB RF 4 IN from full scale setting down to –25 dB <0.9 dB

Level uncertainty

RF1, RF2 from full scale setting down to –25 dB <1.0 dB RF4IN from full scale setting down to –25 dB <1.1 dB

Level resolution

filter definition: passband

Filter Bandwidth → wide Filter Bandwidth → narrow

GFSK signal

Filter Bandwidth → wide

in temperature range +20 °C to +35 °C

in temperature range +5 °C to +45 °C

in manual mode 0.1 dB in remote control mode 0.01 dB

2.0 MHz

1.3 MHz

>55 dB, rms

Modulation analyzer

Measurement bandwidth

Level range

RF 1, RF 2, RF 4 IN from full scale setting down to –25 dB

Total measurement range for frequency offset and frequency deviation

Frequency offset uncertainty in preamble

Frequency deviation uncertainty in payload

11110000 pattern ≤2 % 10101010 pattern ≤4 %

38 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

filter definition: passband

Filter Bandwidth → wide Filter Bandwidth → narrow

GFSK signal

–250 kHz to +250 kHz

for deviation ≤160 kHz ≤2 kHz

for 100 kHz < deviation ≤ 200 kHz

2.0 MHz

1.3 MHz

Frequency drift uncertainty

Frequency resolution

measured in burst related to frequency offset value in preamble

10101010 pattern maximum ≤2 kHz typically ≤1 kHz

in manual mode 1 kHz in remote control mode 1 Hz

Timing measurement

Range

Resolution

Uncertainty

R&S®CMU-B52 option speech codec

±20 μs

≤0.25 μs ≤0.25 μs + resolution

Speech decoder output

Output impedance <10 Ω Maximum output current 20 mA, peak Full-range output level 1 V, peak

Speech coder input

Input impedance 100 kΩ

SPEECH HANDSET OUT 9-pin D-Sub connector

SPEECH HANDSET IN 9-pin D-Sub connector

low sensitivity 1.4 V, peak Full-range input level high sensitivity 0.1 V, peak

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 39

R&S®CMU-B17 option I/Q/IF interface

I/Q interface

Analog I/Q outputs

IF → I/Q; TX and RX paths, analog I/Q

connector I/Q CH1

output

I/Q bandwidth 0 MHz to 2.5 MHz

–1 V to +1 V, peak Max. output voltage range EMF

22

= 1 V, peak

QI +

Output impedance 50 Ω

<2 % I and Q amplitude imbalance for WCDMA function group <2.5 %

Offset voltage

in temperature range +20 °C to +35 °C <4 mV

in temperature range +20 °C to +35 °C

<5 mV

for WCDMA function group in temperature range +5 °C to +45 °C <8 mV

Analog I/Q inputs

I/Q → IF; TX–path, analog I/Q input

connector I/Q CH1

I/Q bandwidth 0 MHz to 2.5 MHz

–0.5 V to +0.5 V, peak Max. input voltage range

22

= 0.5 V, peak

QI +

Input impedance 50 Ω

in temperature range +20 °C to +35 °C >40 dB Carrier suppression in temperature range +5 °C to +45 °C >35 dB f

< 1 MHz >45 dB Sideband suppression

I/Q

1 MHz < f

< 2.5 MHz >40 dB

I/Q

Analog I/Q inputs

I/Q → IF; RX path, analog I/Q input

connector I/Q CH1

I/Q bandwidth 0 MHz to 2.5 MHz

–0.5 V to +0.5 V, peak Max. input voltage range

22

= 0.5 V, peak

QI +

Input impedance 50 Ω Carrier suppression

in temperature range +20 °C to +35 °C

in temperature range +5 °C to +45 °C >35 dB f

< 1 MHz >45 dB Sideband suppression

I/Q

1 MHz < f

< 2.5 MHz >40 dB

I/Q

>35 dB

9

Influence on RF interface

GSM/EDGE measurements

Additional influence on signal quality analog I/Q input and output considered;

Phase error GMSK <3°, peak

EVM 8PSK <5 %, rms

WCDMA measurements

Additional influence on signal quality analog I/Q input and output considered;

EVM <5 %, rms

RF level uncertainty

Output level uncertainty at RF 1, RF 2, RF 3 OUT add 0.3 dB to R&S®CMU200 base unit

Input level uncertainty of frequencyselective power meter

9

For GSMK modulation and max. input voltage at I/Q inputs.

40 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

for TX and RX paths

<1°, rms

3GPP FDD, UE test

for TX and RX paths

bypass with I/Q IF OUT, I/Q IN/OUT, IF IN/OUT

specifications

at RF 1, RF 2, RF 4 IN add 0.3 dB to R&S®CMU200 base unit

specifications

IF interface

IF inputs, TX path

connector IF3 TX CH1 IN

IF level range up to –5 dBm, PEP Standard IF frequencies RF/GSM (GMSK and 8PSK)/

TDMA/CDMA2000

®

WCDMA

13.85 MHz

15.36 MHz

IF inputs, RX path

connector IF3 RX CH1 IN

IF level range up to +2 dBm, PEP Standard IF frequencies RF/GSM (GMSK and 8PSK)/

TDMA/CDMA2000

®

WCDMA

10.7 MHz

7.68 MHz

IF outputs, TX path

connector IF3 TX CH1 OUT

IF level range up to –5 dBm, PEP Standard IF frequencies RF/GSM (GMSK and 8PSK)/

TDMA/CDMA2000

®

WCDMA

13.85 MHz

15.36 MHz

IF outputs, RX path

connector IF3 RX CH1 OUT

IF level range up to +6 dBm, PEP Standard IF frequencies RF/GSM (GMSK and 8PSK)/

TDMA/CDMA2000

®

WCDMA

10.7 MHz

7.68 MHz

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 41

Remarks

• Due to the modulation schemes used Bluetooth and AMPS standards will not be supported.

• The options R&S

Therefore either the R&S

Additional information for GSM:

To avoid influences on the fading profile, the following is highly recommended:

• To set all timeslots to the same level.

• To use for the TX signal of the R&S

• To switch hopping off.

Aspects to be considered if TX or RX signal paths are interrupted:

The RF frequency of the R&S®CMU200 influences the rotating direction of the I/Q vector. The direction is inverted for f < 1200.1 MHz; this can be compensated for by changing I and Q.

R&S®CMU200 I/Q output vector

R&S®CMU200 I/Q input vector

The rotating direction must be considered if the R&S interrupted, i.e. if the signal is not returned to the same R&S

Examples:

• The rotating direction must not be taken into account if the transmitted signal is routed from the I/Q output of the R&S

to an external fading simulator and then returned to the R&S Fading Simulator R&S

• The rotating direction must be considered if the transmitted signal is forwarded to an external fading simulator and is not returned

to the I/Q input of the R&S®CMU200 (the R&S®CMU200 in combination with the R&S®SMIQ, the R&S®SMIQ providing the faded RF signal).

®

CMU-B17 and R&S®CMU-B73 use the same mainboard connector of the R&S®CMU200.

®

CMU-B17 or the R&S®CMU-B73 can be ordered for a single instrument.

®

CMU200 the same RF frequencies and RF levels for both TCH and BCCH.

®

R&S

CMU200 generator or analyzer RF frequency 100 kHz to 1200.0999999 MHz 1200.1 MHz to 2700.0 MHz inverted rotation

normal rotation swap I output with Q output for proper operation inverted rotation

normal rotation swap I input with Q input for proper operation

®

CMU200 signal path from the link handler board to the frontend and vice versa is

®

CMU200 block after external handling.

®

ABFS or R&S®SMIQ/SMIQB14, the R&S®CMU200 providing the faded RF signal).

CMU200 I/Q input (the R&S®CMU200 in combination with the

®

CMU-B17

Notes for measuring I/Q/IF signals applied to inputs of the R&S®CMU-B17 option on the

®

R&S

CMU200 RX path:

• The RF spectrum analyzer function (RF function group) cannot be used.

• The displayed RF power levels are not related directly to the applied I/Q/IF voltages. The analyzer settings of the R&S

→

RF interface (RF 1, RF 2, RF 4 IN) have to be considered additionally (Analyzer Level

RF Max. Level).

®

CMU200

• I/Q inputs have a fixed attenuation of 2 dB; e.g. the RF power meter readout for an applied 500 mV I/Q peak voltage will be 2 dB

below the value set in RF Max. Level.

• IF inputs do not have a fixed attenuation. The max. IF input level is 2 dBm. The RF power meter readout for the mentioned

max. IF signal level (2 dBm) will be 2 dB below the value set in RF Max. Level.

• We recommend switching off the autoranging function.

• RF and IF trigger functions are not possible.

• The WCDMA RF compensation filter is switched off (I/Q IN/OUT, IF IN/OUT, IFIN_I/Q IN/OUT).

• WCDMA UE test: ACLR/SEM measurement is not applicable.

42 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

R&S®CMU-B41 option audio generator/analyzer

AF generator

Output impedance

Maximum output current

AF sine generator

Frequency range Frequency uncertainty same as time base + half resolution,

Frequency resolution 0.1 Hz Output level range 10 µV to 5 V

Output level uncertainty at level ≥1 mV and frequency ≤10 kHz ≤1.5 % + resolution

THD+N10 THD10 at level ≥100 mV into load ≥600 Ω ≤0.025 %

<4 Ω

20 mA, peak

at level <10 mV 10 µV Output level resolution at level ≥10 mV 0.1 %

at level ≥100 mV into load ≥600 Ω ≤0.05 %

20 Hz to 20 kHz

see base unit specifications

AF analyzer

Input impedance

AF voltmeter

Frequency range 50 Hz to 20 kHz Level range 50 µV to 30 V

Level uncertainty

THD+N meter

Measurement bandwidth 21 kHz Frequency range 100 Hz to 10 kHz Level range 10 mV to 30 V Resolution 0.01 % THD+N Inherent distortion

at level <1 mV 1 µV Level resolution at level ≥1 mV 0.1 % at 1 mV ≤ level ≤ 2 V at 2 V < level ≤ 20 V

at 100 mV ≤ level ≤ 20 V at 100 mV ≤ level ≤ 2 V <1 % + inherent resolution Uncertainty at 2 V < level ≤ 20 V <2 % + inherent resolution

1 MΩ ⏐⏐ 100 pF

<1 % + resolution

<2 % + resolution

<0.05 % THD+N

R&S®CMU-U99/B99 option RF1 level range identical to RF2

With the R&S®CMU-U99/B99 option installed, the input/output level range and the input/output level uncertainty for RF 1 are the same as for RF 2.

With the R&S

VSWR

RF1

10

Measurement bandwidth 21.9 kHz

Version 08.01, July 2007 R&S

®

CMU-U99/B99 option installed, the VSWR of the RF generator and analyzer at RF 1 is as follows:

RF generator and RF analyzer

10 MHz to 2000 MHz <1.2 2000 MHz to 2200 MHz <1.4 2200 MHz to 2700 MHz <1.6

®

CMU200 Universal Radio Communication Tester 43

The specifications for the R&S

®

CMU200 (Order No. 1100.0008.02/10/30/53) refer to a fully equipped unit with all relevant

options installed.

Specifications are valid under the following conditions:

Data without tolerance limits is not binding.

In compliance with the 3GPP/3GPP2 standard, chip rates are specified in Mcps (million chips per second), whereas bit rates and symbol rates are specified in kbps (thousand bits per second) or ksps (thousand symbols per second).

Mcps, kbps and ksps are not SI units.

®

For more general information about the R&S

CMU200 please refer to the product brochure PD 0758.0039.12, version ≥07.00.

44 R&S®CMU200 Universal Radio Communication Tester Version 08.01, July 2007

Version 08.01, July 2007 R&S

®

CMU200 Universal Radio Communication Tester 45

Certified Quality System

ISO 9001

DQS REG. NO 1954 QM

Certified Environmental System

ISO

14001

DQS REG. NO 1954 UM

For product brochure, see PD 0758.0039.12

and www.rohde-schwarz.com

(search term: CMU200)

July 2007 · Dat a without tolerance l imits is not bi nding · Subjec t to change

¸ is a regi stered tr ademark of Rohde & Schwarz GmbH & Co. KG · Trade names are trademarks o f the owners · Printed i n Germany (as)

PD 0758.00 39.22 · ¸CM U 200 · Version 08.01 ·

Europe: +49 1805 12 4242, cus tomersupport@rohde-schwarz .com

www.rohde-schwarz.com

USA and Canada: 1- 888-837-8772, c ustomer.support@rsa.rohde- schwarz.com

Asia: +65 65 130 488, cus tomersupport.asia@rohde-s chwarz.com

Rohde and Schwarz CMU200v10 Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
