TrustedTM
PD-T8850
TM
Trusted
40 Channel Analogue or
Digital Output FTA
Introduction
The TrustedTM 40 Channel Analogue Output or Digital Output FTA is designed to act as the main
interface between the TrustedTM TMR 24V dc Digital Output Module T8451 or TrustedTM TMR
Analogue Output Module T8480 and TrustedTM the field device. The signal from the output modules
are 24V dc and 0-20mA respectively.
Features
• 40 output channels per FTA.
• Industry standard field device connections (2-wire).
• Standard DIN rail compatibility.
• Screw clamp terminals on both field and power.
• Simple installation and connection.
• 24V dc operation.
• SmartSlot connection for ‘one to many’ hot replacement of output modules.
• Field power supply arranged in five groups of eight channels, with OV
isolation between groups.
• On-board LED indication field power supply integrity.
• Field terminal wire size allowance 12 to 28 AWG
Issue 10 Apr 12 PD-T8850 1
Trusted
Issue Record
Issue
Number Date Revised by Technical Check Authorised by Modification
8 Sep 05 J W Clark Format
9 Apr 10 S Blackett A Holgate N Owens TBF1 changed to TB2
10 Apr 2012 S Blackett A Holgate N Owens T8850 layout changes
TM
Analogue or Digital Output FTA T8850
Fig 1
Issue 10 Apr 12 PD-T8850 2
Trusted
TM
Analogue or Digital Output FTA T8850
PWR TB
SK1
Not
Fitted
TB2
Figure 1 T8850 Layout
Issue 10 Apr 12 PD-T8850 3
Trusted
TM
Analogue or Digital Output FTA T8850
Table of Contents
1. Description ................................................................................................................................... 7
2. Installation .................................................................................................................................... 8
3. Associated Cable Selection ......................................................................................................... 8
4. Assembly Pinout Connections ..................................................................................................... 9
4.1. PWR TB Connections .................................................................................................................. 9
4.2. TB2 (Field Terminals) ................................................................................................................ 10
4.3. SK1 ........................................................................................................................................... 11
5. Specifications ............................................................................................................................. 12
Figures
Figure 1 T8850 Layout .............................................................................................................................. 3
Figure 2 Two Channel Schematic ............................................................................................................ 7
Tables
Table 1 PWR TB Connections ................................................................................................................. 9
Table 2 TB2 (Field Terminals) Connections .......................................................................................... 10
Table 3 SK1 Connections ....................................................................................................................... 11
Issue 10 Apr 12 PD-T8850 4
Trusted
TM
Analogue or Digital Output FTA T8850
Notice
The content of this document is confidential to ICS Triplex Technology Ltd. companies and their
partners. It may not be given away, lent, resold, hired out or made available to a third party for any
purpose without the written consent of ICS Triplex Technology Ltd.
This document contains proprietary information that is protected by copyright. All rights are reserved.
Microsoft, Windows, Windows 95, Windows NT, Windows 2000, and Windows XP are registered
trademarks of Microsoft Corporation.
The information contained in this document is subject to change without notice. The reader should, in
all cases, consult ICS Triplex Technology Ltd. to determine whether any such changes have been
made. From time to time, amendments to this document will be made as necessary and will be
distributed by ICS Triplex Technology Ltd.
Information in this documentation set may be subject to change without notice and does not represent
a commitment on the part of ICS Triplex Technology Ltd.
The contents of this document, which may also include the loan of software tools, are subject to the
confidentiality and other clause(s) within the Integrator Agreement and Software License Agreement.
No part of this documentation may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying and recording, for any purpose, without the express
written permission of ICS Triplex Technology Ltd.
Disclaimer
The illustrations, figures, charts, and layout examples in this manual are intended solely to illustrate the
text of this manual.
The user of, and those responsible for applying this equipment, must satisfy themselves as to the
acceptability of each application and use of this equipment.
This document is based on information available at the time of its publication. While efforts have been
made to be accurate, the information contained herein does not purport to cover all details or variations
in hardware or software, nor to provide for every possible contingency in connection with installation,
operation, or maintenance. Features may be described herein which are present in all hardware or
software systems. ICS Triplex Technology Ltd. assumes no obligation of notice to holders of this
document with respect to changes subsequently made.
ICS Triplex Technology Ltd. makes no representation or warranty, expressed, implied, or statutory with
respect to, and assumes no responsibility for the accuracy, completeness, sufficiency, or usefulness of
the information contained herein. No warranties of merchantability or fitness for purpose shall apply.
Issue 10 Apr 12 PD-T8850 5
Trusted
TM
Analogue or Digital Output FTA T8850
Revision and Updating Policy
All new and revised information pertinent to this document shall be issued by ICS Triplex Technology
Ltd. and shall be incorporated into this document in accordance with the enclosed instructions. The
change is to be recorded on the Amendment Record of this document.
Precautionary Information
WARNING
Warning notices call attention to the use of materials, processes, methods, procedures or limits which
must be followed precisely to avoid personal injury or death.
CAUTION
Caution notices call attention to methods and procedures which must be followed to avoid damage to
the equipment.
Notes:
Notes highlight procedures and contain information to assist the user in the understanding of the
information contained in this document
Warning
RADIO FREQUENCY INTERFERENCE
Most electronic equipment is influenced by Radio Frequency Interference (RFI). Caution should be
exercised with regard to the use of portable communications equipment around such equipment.
Signs should be posted in the vicinity of the equipment cautioning against the use of portable
communications equipment.
MAINTENANCE
Maintenance must be performed only by qualified personnel, otherwise personal injury or death, or
damage to the system may be caused.
Caution
HANDLING
Under no circumstances should the module housing be removed.
Associated Documents
Product Descriptions (PD) provide product specific information.
The Safety Manual contains the recommended safety requirements for the safety system design.
The PD8082B – Toolset Suite provides specific guidance on system configuration and application
generation.
The Operator and Maintenance Manual contains general guidelines on maintenance and diagnostic
procedures.
For technical support email: support@icstriplex.com
Issue 10 Apr 12 PD-T8850 6
Trusted
TM
Analogue or Digital Output FTA T8850
1. Description
The TrustedTM 40 Channel Analogue Output or Digital Output FTA T8850 provides termination for a
maximum of 40 output field loops. The 40 channels are arranged in five groups each comprising eight
identical channels. Figure 2 below shows the configuration of two channels within a group.
V_FIELD_GRP1
PWR
TERMINALS
V_FIELD_RTN_GRP1
V_FIELD_GRP1
CONNECTIONS TO
OUTPUT MODULE
V_FIELD_RTN_GRP1 ( SK1 AND 2 )
F
I
E
L
D
T
E
R
M
I
N
A
L
S
CONNECTIONS
FROM
OUTPUT
MODULE
TO
THE
FIELD
CHAN _1_V_FIELD_GRP1
CHAN _1_V_FIELD_RTN_GRP1
CHAN _2_V_FIELD_GRP1
CHAN _2_V_FIELD_RTN_GRP1
Figure 2 Two Channel Schematic
Indication of of the presence of the field power supply is provided by a green LED (one for each power
group). The supply is then fed to each channel within the power group.
The signal to the field device is fed directly from the output module.
The cable linking the 40 channels on the output module to the FTA is terminated at the 96-way socket
SK1. SmartSlot (Version 1) signals from the module are connected to SK1. The dc field power
supplies can be connected to the FTA via a 10-way terminal block PWR TB. The output signals to the
field (40-off) are connected by 2-wire arrangements terminated on the dual height terminal blocks.
Issue 10 Apr 12 PD-T8850 7
Trusted
TM
Analogue or Digital Output FTA T8850
2. Installation
TrustedTM 40 Channel Analogue Output or Digital Output FTA T8850 is designed to be mounted on
either of the TS32 or TS35 DIN rails in the horizontal or vertical positions as required.
3. Associated Cable Selection
Refer to the product descriptions detailed below:
PD-TC000 TrustedTM Power Cables
PD-TC200 TrustedTM I/O Companion Slot Cables
PD-TC500 TrustedTM I/O SmartSlot Cables
Issue 10 Apr 12 PD-T8850 8
Trusted
TM
Analogue or Digital Output FTA T8850
4. Assembly Pinout Connections
4.1. PWR TB Connections
