Rocktron B200 User Manual

MANUAL
May be covered by one or more of the following: U.S. Patents
#4538297, 4647876, 4696044, 4745309, 4881047, 4893099, 5124657, 5263091,
5268527, 5319713, 5333201, 5402498 and 5493617.
Other patents pending. Foreign patents pending.
1
Your UTOPIA B200 has been designed to comply with the following Standards and Directives as set forth by the European Union:
53/EC, 2002/95/EC
Standard(s): EN55022, EN50082-1, EN60065
This means that this product has been designed to meet stringent guidelines on how much RF energy it can emit, and that it should be immune from other sources of interference when properly used. Improper use of this equipment could result in increased RF emissions, which may or may not interfere with other electronic products.
To insure against this possibility, always use good shielded cables for all audio input and output connections. This will help insure compliance with the Directive(s).
Copyright © 2007 GHS Corporation. All rights reserved.
2
CONTENTS
1. Introduction 4
2. Quick Reference 6
3. UTOPIA B200 Top and Back Panels 8
4. Connections 12
5. Operating Format 20
6. UTOPIA B200 Functions and Parameter Description 21 � GLOBAL Function 22 � MIXER Function 23 � PREAMP Function 23 � HUSH® Function 25 � SPEAKER Exciter Function 26 � COMPRESSOR Function 27 � WAH-WAH Function 28 � PHASER Function 29 � MODULATION EFX Function 30 � CHORUS Function 31 � FLANGER Function 33 � TREMOLO Function 34 � PITCH SHIFT Function 35 � PITCH SHIFT INTERVALS 36 � DELAY Function 37 � TAP QUANTIZING Function 39 � REVERB Function 40
7. UTOPIA B200 Block Diagrams 41 � Chorus, Flanger and Pitch Shift 41 � Tremolo 42 � Function and Parameter range list 43
8. Operating the UTOPIA B200 46 � Display Description 46 � Selecting a preset 47 � Preset Banks 48 � Changing preset parameters: 49 � Storing changed preset parameters: 50 � Operation Mode 52 � Selecting a Modulation Effect 53 � MUTE/TUNER Function 54 � USB Connection 56 � MIDI IN 56 � MIDI OUT/THRU 56 � MIDI Channels - Midi Receive 57 � MIDI Channels - Midi Transmit 58 � Program Changes 59 � MIDI DUMP/LOAD 60 � Pedal Controllers 62 � Pedal Status 66 � Footswitch Mapping 69 � Factory Restore 71 � Title Edit Function 73 � Selecting a Power on Preset 75
9. Specifications 76
10. UTOPIA B200 Preset Listing 77
3
1. Introduction
UTOPIA B200 PROVIDES PROFESSIONAL SOUND FOR BASS
Rocktron’s Utopia B200 Professional Bass System provides an arsenal of tone and effects processing. The B200 is packed with plenty of great sounds ready to transform any Bass amplifier into a Power­house of Rock. Simply put the B200 between you and your amp and let your inspiration flow! Rocktron stands alone with amazing tone generation and effects in the B200 - everything you need to create your own signature sound and define a new generation of playing. Play in Utopia where the future is amaz­ing.
Great Tone! � 128 Fully programmable presets � Chorus, Reverb, Delay, Pitch Shift, Flanger, Phaser and Tremolo � Easy to program user controls � Up / Down preset Bank by 3 with instant recall buttons. � 2nd mode with 3 instant access controller switches. � Tap delay note quantization 1/16, 1/8, triplet, ¼, ½ and whole. � Illuminated noiseless footswitches � Glow in the dark markings on pedal board � Rocktron’s state-of-the-art HUSH noise reduction � On board pro-grade expression pedal with integrated footswitch and LED. � Upgradable core processing hardware design [ DSP CARD and CODEC CARD ] � Motorola [Freescale] DSP engine with AKM converters � Easy to read 2 line cool blue LCD display � USB audio recording and playback connectivity � Rocktron’s state of the art Speaker Exciter for recording and live sound. � MIDI IN and MIDI OUT/THRU � Auxiliary CD/Mp3/iPod in 1/8 jack � Stereo headphone out � Built-in tuner � Full Bandwidth effects � Rugged professional grade chassis and expression pedal made from metal � Assignable Effect On/Off � Power supply included
Motorola is a trademark of Motorola Corporation. HUSH is a registered trademark of GHS Corporation. iPod is a trademark of Apple Inc.
4
PRECAUTIONS
NOTE: IT IS VERY IMPORTANT THAT YOU READ THIS SECTION TO PRO­VIDE YEARS OF TROUBLE FREE USE. THIS UNIT REQUIRES CAREFUL HAN­DLING.
• All warnings on this equipment and in the operating instructions should be adhered to and all operating instructions should be followed.
• Do not use this equipment near water. Care should be taken so that objects do not fall and liquids are not spilled into the unit through any openings.
• The power cord/adapter should be unplugged from the outlet when left unused for a long period of time.
• Do not block any ventilation openings (if applicable). Install in accor
-
dance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat.
• Only used attachments/accessories specified by the manufacturer.
• Do not use this product with any case, stand, tripod, bracket or table that is not specified by the manufacturer. Insure that the case, stand, tripod, bracket etc. is properly adjusted and setup (follow all instructions). Extra care and caution should be taken to avoid tip over and injury.
• Unplug this apparatus during lightning storms or when unused during long periods of time.
Refer all service to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply or plug is damaged, liquid has been spilled or objects have fallen into the apparatus or if the apparatus has been exposed to rain or moisture, does not operate nor­mally or has been dropped.
DO NOT ATTEMPT TO SERVICE THIS EQUIPMENT. THIS EQUIPMENT SHOULD BE SERVICED BY QUALIFIED PERSONNEL ONLY. DO NOT MAKE ANY INTERNAL ADJUSTMENTS OR ADDITIONS TO THIS EQUIPMENT AT ANY TIME. DO NOT TAMPER WITH INTERNAL ELECTRONIC COMPONENTS AT ANY TIME. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY VOID THE WARRANTY OF THIS EQUIPMENT, AS WELL AS CAUSING SHOCK HAZARD.
OPERATING TEMPERATURE
Do not expose this unit to excessive heat. This unit is designed to operate between 32° F and 104° F (0° C and 40° C). This unit may not function properly under extreme temperatures.
5
2. Quick Reference
6
Quick Reference....continued...
STEP 1 Turn ON the UTOPIA B200.
STEP 2 Select your desired preset by pressing any button 1-3 to select presets. You
may also do this by following STEP 6. NOTE - the B200 starts with preset
number 1, preset 0 does not exist.
STEP 3 Scroll through the different preset banks by pressing the UP button (Bank by 3).
You may also reach your desired preset by following STEP 6.
STEP 4 Scroll through the different preset banks by pressing the DOWN button (Bank
by 3). You may also reach your desired preset by following STEP 6.
STEP 5 Use the built-in expression pedal to change the parameter(s) in real time that
are assigned to the pedal controllers function.
STEP 6 You may also select a preset by turning the PRESET SELECT knob.
STEP 7 Turn the FUNCTION SELECT knob to the desired effect or utility function.
STEP 8 Turn the PARAMETER SELECT knob to the parameter you wish to alter under
the selected effect or utility function.
STEP 9 Use the PARAMETER ADJUST knob to modify a parameter value.
STEP 10
After editing any function parameter press the STORE button to start the storing procedure. The display will toggle and flash "STORE AT PRESET." If you wish to save the altered preset in the current preset location, press the
STORE button a second time. If you wish to store the altered preset in a differ­ent preset location, turn the PRESET control to the desired preset number, then press STORE a second time. Anytime you wish to cancel the store process just turn the PARAMETER ADJUST one click.
STEP 11 To
enter the "2ND Function" mode, press the "2nd" switch, this will turn on a RED LED above the 2nd button. You can now turn On/Off functions within that preset using the buttons marked 1-3 (Effect On/Off, MUTE/TUNER and TAP). When in 2nd mode, the LEDs above the buttons 1 and 3 will light "yel­low" and the MUTE/TUNER "red". Use the same switch marked "2nd" to cancel and exit the 2nd Function mode.
7
3. UTOPIA B200 Top and Back Panels
8
3. UTOPIA B200 Top and Back Panels....continued.....
1 PRESET SELECT control
Turning this knob scrolls through the successive presets.
2 DISPLAY panel
The DISPLAY shows the preset names, functions and parameters that are selected.
3 PARAMETER ADJUST control
4 PARAMETER SELECT control
When adjusting parameter values, turning this knob will scroll through the available parameters
5 STORE button and STORE LED
This button is used to store values into the B200's memory when altered. See "Storing
This knob is used to adjust a displayed parameter value. Note that this knob is also used as a controller knob and is set to MASTER VOLUME from the factory. So you can use this knob to adjust the overall volume of the B200. However, this knob also can be assigned to other control­ler parameters (see Pedal Controllers section in this manual for more details).
under the current function heading. In the "Title Edit" function, this knob will scroll through the character locations to be edited.
Changed Preset Parameters" for more information on this procedure.
6 FUNCTION SELECT control
This knob allows access to each function of the UTOPIA B200 depending on which configura
-
tion is currently recalled.
7 PEDAL ACTIVE LED
This LED will light when the built-in expression pedal is active or on.
8 EXPRESSION PEDAL
The built-in expression pedal will change parameter(s) that have been assigned to the pedal in the
Pedal Controllers function. Use the pedal to increase or decrease volume levels, or for a pitch shifting wammy effect, or to bring in reverbs and delays. There are many uses for this pedal. Please see the Pedal Controllers section of this manual for information how to program the ex­pression pedal for many cool effects.
9 UP button
This button allows you to scroll UP through the preset banks. Each B200 preset bank has 3 pre
-
sets in it (note there is no Zero (0) preset or Preset 129)
Bank 00 - Presets 1-3 Bank 01 - Presets 4-6 Bank 02 - Presets 7-9 Bank 03- Presets 10-12 Bank 04 - Presets 13-15 Bank 05 - Presets 16-18 Bank 06 - Presets 19-21
Bank 07- Presets 22-24 Bank 08 - Presets 25-27 Bank 09 - Presets 28-30 Bank 10 - Presets 31-33 Bank 11 - Presets 34-36 Bank 12 - Presets 37-39
and so on..........
9
3. UTOPIA B200 Top and Back Panels....continued.....
Press the UP button once to move one preset bank up or press and hold down the button to auto-
scroll UP. Note that once you have reached your desired preset, the preset name on the screen will be flashing but NOT recalled. The original preset will still be active. Now select any preset 1-3 to recall or activate the desired preset.
10 DOWN button
11 PRESET button 1
This button allows you to select presets 1, 4, 7, 10, 13, 16, 19, 22, 25, 28, etc.. When you are in
12 PRESET button 2
This button allows you to select presets 2, 5, 8, 11, 14, 17, 20, 23, 26, 29, etc. When you are
This button allows you to scroll DOWN through the preset banks and functions in the same man­ner as the UP button (point 9).
Bank 01 this button allows you to select preset 4. When you are in Bank 02 this button allows you to select preset 7 and so on. Note that there is no 0 (zero) preset. When in "2nd" mode, this button is used to turn On/Off the EFFECT that has been assigned to the preset selected.
in Bank 00 this button allows you to select preset 2. When you are in Bank 01 this button al
­lows you to select preset 5 and so on. When in "2nd" mode, this button is used to turn On/Off the MUTE/TUNER Function. This will mute the output of the B200 and allow you to tune in silence.
13 PRESET button 3
This button allows you to select presets 3, 6, 9, 12, 15, 18, 21, 24, 30, etc. When you are in Bank
00 this button allows you to select preset 3. When you are in Bank 01 this button allows you to select preset 6 and so on. When in "2nd" mode, this button is used to activate the TAP function and set the DELAY Rate by tapping the button at the desired rate.
14 2nd Button
This button allows you to enter the 2nd Function Mode. In the 2nd Function Mode you can use button 1 (EFFECT ON/OFF) to turn on and off a pre-assigned effect within the preset. You can also access the MUTE/TUNER function using button 2 and set the delay rate within a preset us­ing the TAP button (button 3). To Exit 2nd Function mode, press the 2nd Button.
15 EXPRESSION PEDAL switch
To activate the Expression pedal, apply pressure to the toe of the expression pedal until this
switch is activated. You will know the pedal is active as you should be able to feel the switch activate, but if not, the PEDAL ACTIVE LED will light when the switch is turned ON.
16 INPUT jack
This standard, mono 1/4" jack is used to provide input to the unit.
17 OUTPUT RIGHT jack
This 1/4" jack provides the right output of the UTOPIA B200 for use in stereo situations, such as
direct recording, plugging into a PA system, two Bass amplifiers, etc.
10
3. UTOPIA B200 Top and Back Panels....continued.....
18 OUTPUT LEFT/MONO jack
This 1/4" jack provides the left output of the UTOPIA B200. This output is a MONO output and
should be used in mono situations, such as plugging into the front of an amplifier. For stereo situations you must also use the OUTPUT RIGHT Jack.
19 AUX INPUT Jack
This 1/8" stereo jack provides an auxiliary input allowing you to plug a MP3 Player, CD Player,
etc. so that you can jam along with your favorite tunes.
20 PHONES jack
This 1/8” stereo jack provides a stereo output allowing you to practice in private. Note that you
need to activate the “STEREO” parameter in the GLOBAL Function in order to have a stereo sound. Additionally, it is recommended that you set the Speaker Exciter in the GLOBAL Func­tion to “LOCK BOTH” as well. Note, this setting will be used until you turn OFF the UTOPIA B200. The SPEAKER Exciter setting used in each preset may be modified per preset while in this mode. See page 22 for more information on the GLOBAL Function. Note: Make sure if you edit a preset and plan to store it to turn the SPEAKER EXCITER off if you do not desire to store its current status. All global parameters will be stored during the preset storing process.
21 USB
jack
This standard USB jack allows you to connect to a computer for direct recording and
playback.
22 MIDI IN
jack
This *7-pin DIN connector receives MIDI information from the device which is transmit-
ting the MIDI commands for the B200 to execute.
23 MIDI OUT/THRU jack
This *7-pin DIN connector passes on the MIDI information that is received at the MIDI IN
jack to other MlDI-compatible devices via a MIDI cable. It also outputs MIDI data when performing a memory dump.
*Note a standard 5-pin MIDI cable may be used.
24 POWER jack
This 4-pin DIN connector accepts power from the 9V/AC adaptor supplied with the B200.
25 POWER Switch
Use this switch to turn the UTOPIA B200 On and Off.
11
4. Connections
Standard Connection with a Bass Amplifier
12
4. Connections....continued.....
Connection in Stereo to Two Bass Amplifiers.
13
4. Connections....continued.....
Connection to a PA System
14
4. Connections....continued.....
Connection to a Computer
15
4. Connections....continued.....
Connection to a Recording Workstation
16
4. Connections....continued.....
Connection Using an Outboard Effect and MIDI
17
4. Connections....continued.....
Connection for MIDI IN from a Computer with
MIDI Utility Program
18
4. Connections....continued.....
Connection for MIDI OUT to Computer with MIDI
Utility Program
19
5. Operating Format
The B200 provides 128 stored sounds called presets. Any of the 128 presets can be called up at any time via the PRESET knob, or by using the BANK UP/DOWN buttons and PRESET switches.
Each preset has the following effects available at all times:
Compressor
Wah Wah
Phaser
Preamp
HUSH
Speaker Exciter
One Modulation Effect ( Chorus, Flanger, Tremolo or Pitch Shift)
Delay
Reverb
20
6. UTOPIA B200 Functions and Parameter Descriptions
Each UTOPIA B200 preset is divided up into individual blocks called func­tions (such as "Mixer", "Reverb", etc.). Within each function of each configura­tion is a set of controls which allow you to manipulate various aspects of that function. These controls are called parameters. It is the setting of each of the parameters which determines the overall sound of each preset.
The UTOPIA B200 is set up to allow you to first access each function (via the FUNCTION SELECT knob), then the parameter list for each function (via the PARAMETER SELECT knob) and finally the adjustable value for each parameter (via the PARAMETER ADJUST knob).
The functions available for each preset are dependent upon which effect is currently recalled. The remainder of this section will describe each of the effect­based functions and the associated adjustable parameters they provide.
The remaining functions are utility-based, and are described in the section titled "Operating the UTOPIA B200".
21
6. GLOBAL Function
The first function displayed after turning the FUNCTION SELECT knob is the Global function. The parameters provided in this function affect all presets (i.e. the settings stored for these parameters are the same for all presets).
The PARAMETER SELECT knob will allow you to access these Global parameters:
OUTPUT
EXCITER
HUSH OFFSET
The OUTPUT parameter determines whether the output of the UTOPIA B200 is a stereo (left and right) signal or two mono signals.
This SPEAKER Exciter parameter under the Global function allows you to glob­ally (all presets) set the Speaker Exciter into the following modes:
UNLOCK - Bypasses the Speaker Exciter on all presets leaving the outputs full range.
LOCKOFF - If you have the Speaker Exciter "ON" in the Speaker Exciter Func­tion the Speaker Exciter will turn on when that preset is selected.
LOCK L (LEFT OUTPUT) - Locks the Speaker Exciter "ON" in the LEFT OUTPUT and leaves the Right OUTPUT full range. Allows you to use the left output for direct recording or direct to a PA and the right output to your amp at the same time to perform live.
LOCK B (BOTH OUTPUTS) - Locks the Speaker Exciter "ON" in both Left and Right Outputs. This is the ideal setting to use when using headphones.
The HUSH OFFSET parameter allows you to globally (all presets) adjust the HUSH® Expander Threshold. This means that if this parameter is altered from 0(dB) to +3(dB), the Expander Threshold will be 3dB higher for all presets. This feature can be useful when switching from a quiet bass with passive electronics to a noisy bass with active electronics, as the active bass would require a higher Threshold level in all presets.
22
MASTER VOLUME
NOTE: If you would like to save any changes made to the GLOBAL PARAMETERS you must STORE them at this time, before leaving the GLOBAL FUNCTION.
The *MASTER VOLUME has a range from -40dBu to +6dBu. This control adjusts the overall volume of the output and is extremely useful in adjusting the volume in headphones.
*Note: When the preset title is being displayed the PARAMETER ADJUST con trol will provide instant access to modify the MASTER VOLUME anytime.
-
6. MIXER Function
The next function displayed after turning the FUNCTION SELECT knob clockwise is the Mixer function. The Mixer function parameters are included in all presets -- regardless of which configuration is currently recalled
-- although the parameter values stored in this function are only for the currently recalled preset.
This digital mixer allows you to control most signal levels pertaining to each preset's configuration and stores these levels for each preset.
The PARAMETER SELECT knob will allow you to access these Mixer parameters:
VOLUME
LEFT OUT LVL
RIGHT OUT LVL
MIX DIR/EFF
DIR PAN
DELAY LVL
REVERB LVL
The VOLUME parameter determines the overall signal level of the current preset.
The LEFT OUT LEVEL parameter allows you alter the level of the left channel output of the current preset independent of the right channel.
The RIGHT OUT LEVEL parameter allows you alter the level of the right channel out put of the current preset independent of the left channel.
The DIR/EFF MIX parameter is used to define the ratio of direct signal level to effect (Chorus, Flange, Pitch Shift) signal level.
The DIRECT PAN parameter allows you to pan the direct signal to the left or right.
The DELAY LEVEL parameter determines the overall level of the delayed signal at the output relative to the direct signal and other effect signals. This parameter can also be accessed from the Delay function parameter list.
The REVERB LEVEL parameter determines the level of the reverb signal at the output relative to the direct signal and other effect signals. This parameter can also be accessed from the Reverb function parameter list.
-
6. PREAMP Function
The PREAMP function is accessible in all configurations. The preamp stage offers 4 channel choices ranging from DEEP to high gain for maximum sustain and distortion.
The PARAMETER SELECT knob will allow you to access these PREAMP parameters:
CHANNEL
GAIN
VARIAC ADJUST
The CHANNEL parameter chooses one of the four (4) PREAMP types: DEEP, NORM, BRITE, DIST
The GAIN parameter determines the gain value in the distortion stage.
The VARIAC ADJUST parameter adjusts the level at which the preamp stage in the UTOPIA B200 begins to distort. A Variac is a voltage attenuating device that plugs into an AC wall outlet and adjusts the voltage level to any device which is plugged into it. For years, many guitarists have plugged their amplifier heads into a Variac and reduced the voltage coming into the amplifier from the AC wall outlet. This allows the ampli fier tubes to reach saturation at a lower input level and increases the gain produced. The VARIAC ADJUST parameter operates in a similar manner as a conventional Variac -­where lowering the parameter value lowers the level at which saturation will take place.
-
23
6. PREAMP Function continued.....
BASS
MID
TREBLE
PRESENCE
BRIGHT
SCOOP
MASTER
The BASS parameter adjusts the amount of low frequency information at the output of each preset.
The MID parameter adjusts the amount of mid frequency information at the out­put of each preset.
The TREBLE parameter adjusts the amount of high frequency information at the output of each preset.
The PRESENCE parameter also adjusts the amount of high frequency informa­tion at the output of each preset.
The BRIGHT parameter is displayed only when DEEP, NORM or BRITE pre amps are active. The options you have are IN or OUT.
The SCOOP parameter is displayed only when the DIST (distortion preamp) is active, and provides a fixed scoop of the mid frequencies.
The MASTER parameter determines the overall signal level coming out of the preamp section.
-
SYMMETRY
POLARITY
DX-FILTER
MIX
DIR LPF
The SYMMETRY parameter (only available when the DIST preamp is selected) adjusts the symmetry of the wave form. This may be adjusted from -28dB to +6dB. 0dB is symmetrical. This may be used to approximate a tube bias charac teristic. Depending on the settings and polarity more even or odd harmonics may be produced during the distortion process.
Tip: When using -28dB you will notice a sense of a DEEP tone mixed in with the distortion. This is a direct result of the Asymmetrical waveform transformation process. By using varying amounts of symmetry a “ Tube feel” may be realized.
The POLARITY parameter (only available when the DIST preamp is selected) determines which half of the wave gets processed.
The DX-FILTER parameter (only available when the DIST preamp is selected) filters off the "harsh" high-end content. The lower the number the more high­end cut. Zero (0) is no change.
When DIST channel is being used the MIX parameter provides the ability to blend the Distortion with the Direct input before post EQ and effects processing.
The DIRECT LOW PASS FILTER attenuates frequencies down to lower bass. This is useful when wanting to add only lower bottom end clean ambience into the distortion blend. This provides transparent injection of low end presence without sounding like two channels being mixed together.
-
24
6. HUSH® Function
The HUSH® function is accessible in all presets - regardless of the configuration currently recalled.
HUSH is a patented single-ended noise reduction system. The HUSH system contained in the UTOPIA B200, though modeled after the latest analog HUSH design, is a fully digital implementation achieved through Digital Signal Processing (DSP).
The low level expander of the HUSH system operates like an electronic volume control. The analog version of the HUSH utilizes a voltage-controlled amplifier (VCA) circuit which can control the gain between the input and the output from unity to 30, 40 or even 50(dB) of gain reduction. When the input signal is above the user preset threshold point, the VCA circuit remains at unity gain. (This means that the amplitude of the output signal will be equal to that of the input signal.) As the input signal level drops below the user preset threshold point, downward expansion begins. At this point the expander acts like an electronic volume control and gradually begins to decrease the output signal level relative to the input signal level. As the input signal drops further below the threshold point, downward expansion in­creases. A drop in the input level by 20(dB) would cause the output level to drop approximately 40(dB) (i.e., 20(dB) of gain reduction). In the absence of any input signal, the expander will reduce the gain so that the noise floor becomes inaudible.
The HUSH circuit is located after the A/D converter in the signal chain to reduce any noise gener­ated from the Bass and the A/D converter. This ensures a quiet input signal to the preamp section. Be­cause the preamp section of the UTOPIA B200 is digital, it is virtually noise-free (even for the high-gain
channels). Therefore, a quiet input signal to the preamp will result in a quiet output signal.
The PARAMETER SELECT knob will allow you to access these Hush parameters:
HUSH I/O
EXP
THRESHOLD
The HUSH I/O parameter simply determines whether the HUSH® circuit is ac­tive for the current preset.
The EXP THRESHOLD (Expaner Threshold) parameter determines the level at which downward expansion begins. For example, if the EXP THRESHOLD was set at -20(dB) and the input signal dropped below -20(dB), downward expansion would begin.
25
6. SPEAKER EXCITER Function
The SPEAKER Exciter function is included in all presets and provides a realistic approximation of a miked speaker cabinet for applications involving connecting the UTOPIA B200 directly to a mixing board, recording system or other full range system.
NOTE: The parameters provided in this function are operational
only when the SPKR XTR parameter under the GLOBAL FUNCTION is stored UNLOCK, LOCK L or LOCK B.
The PARAMETER SELECT knob will allow you to access these SPEAKER Exciter parameters:
SPKR XTR
SPKR CURV
DEFINITION
SONIC BOOM
The SPEAKER Exciter parameter allows you to select whether the Speaker Ex­citer is on for BOTH outputs, on for only the LEFT output or OFF.
The SPEAKER CURV (curve) parameter determines the EQ Curve to be simu lated. A, B, C, D and E are available. The range is from A having MORE lows and E having more HIGHs.
The DEFINITION parameter accentuates the middle to upper highs for better imaging of the sound delivered through any speaker whether it is live or used when recording.
The SONIC BOOM parameter adds and extra kick in the pants of smooth ultra lows which gives you a fatter sound. The higher the parameter value selected, the more these characteristics will be apparent.
-
26
6. COMPRESSOR Function
The COMPRESSOR function is available in all configurations. This function allows you to com­press the signal prior to the distortion stage. Compression is often used to maintain an even level when using DEEP tones, and also to increase sustain when using distorted tones.
The PARAMETER SELECT knob will allow you to access these COMPRESSOR parameters:
COMPRESSOR
COMP THRESH
COMP ATTACK
COMP RELEASE
The COMPRESSOR IN/OUT parameter determines whether the compressor is active for the current preset.
The COMPRESSOR THRESHOLD parameter determines the input level (in dB) at which compression will begin. Lower settings of this parameter will result in more compression.
The COMPRESSOR ATTACK parameter determines the speed (in milliseconds) in which the compressor will reach its maximum compression level after the input signal has exceeded the threshold level (set by the COMPRESSOR THRESHOLD parameter).
The COMPRESSOR RELEASE parameter determines the speed in which com­pression will cease after the input signal has dropped below the threshold level.
27
6. WAH-WAH Function
The WAH-WAH function is available only in configurations which display "WAH" in the configura­tion title.
The UTOPIA B200 has an internal wah-wah which allows for the built-in expression pedal to be used as a wah-wah pedal when selected in the Pedal Controllers function. To do this, you will need to activate this in the "PEDAL CONTROLLERS" function and assign the wah frequency sweep parameters (See "PEDAL CONTROLLERS" for more information)
The PARAMETER SELECT knob will allow you to access these WAH-WAH parameters:
WAH-WAH
WAH FREQ
The WAH-WAH parameter determines whether the wah-wah is active for the current preset. You can select IN to make the Wah active or OUT to turn it off.
The WAH FREQUENCY parameter allows you to manually sweep the frequency range of the wah-wah via the PARAMETER ADJUST control. Selecting a frequency for this parameter and storing the WAH-WAH parameter IN allows you to use the wah-wah as a fixed wah. You may also assign the wah to the built-in expression pedal. See section called "PEDAL CONTROLLERS" for more details.
28
6. PHASER Function
The PHASER function is available only in configurations displaying "PHA" in the configuration title.
Phase shifting involves splitting the input signal into two signals, then shifting the phase of different frequencies of one signal and mixing it back with the original signal.
The PARAMETER SELECT knob will allow you to access these PHASER parameters:
PHASER
MIX DIR/EFF
DEPTH
P-RATE
RESONANCE
STAGES
The PHASER IN/OUT parameter determines whether the Phaser is active for the current preset.
The DIR/EFF MIX parameter is used to define the ratio of direct signal level to PHASER signal level.
The DEPTH parameter determines the modulation depth of the phase shift effect. Higher parameter settings result in the sweep of the filtering effect occurring over a wider frequency range.
The RATE parameter determines the speed at which the phase shifted signal is modulated.
The RESONANCE parameter adds feedback to the Phaser so that it has a more pronounced effect.
The STAGES parameter determines how many stages of phase shift are to be active. A parameter setting of "4" produces a result similar to a vintage Phase 90, while a setting of "6" emulates other phaser pedals.
29
6. MODULATION EFX Function
The MODULATION EFX function allows you to select a MODULATION effect for each preset.
The PARAMETER ADJUST knob will allow you to select a Modulation Effect:
Available
Selections
Using the parameter adjust knob you can select one of the following MODULA­TION EFFECT:
CHORUS FLANGER TREMOLO PITCH SHIFT
Once you have made a change in Modulation effect selection the B200 will auto matically turn the effect on and load a preset state for you to start with or just use as it is. You may then further edit the effect by turning the FUNCTION SELECT knob one click to the right to access the FUNCTIONS of the selected Effect. See following pages for details on the functions and parameters of each effect.
-
30
6. CHORUS Function
The CHORUS function is available if you have selected it in the MODULATION EFX Function.
The Chorus effect in the UTOPIA B200 is produced by using two delayed signals (Voice 1 and Voice
2), detuning these delayed signals (slightly changing their pitch), then modulating the detune effect so that the amount of pitch detune is constantly varying. Using different detune amounts, modulation rates, modulation depths and pan settings for each delayed signal will produce a greater perceived spacious­ness.
The PARAMETER SELECT knob will allow you to access these CHORUS parameters:
CHORUS
LEVEL 1
PAN 1
DEPTH 1
RATE 1
DELAY 1
The CHORUS parameter determines whether the Chorus is active or bypassed for the current preset.
The LEVEL 1 parameter determines the volume of Voice 1 in relation to Voice 2. The DIR/EFF MIX parameter in the Mixer function also determines the Chorus level.
PAN 1 parameter allows you to pan Voice 1 to the left or right channel.
The DEPTH 1 parameter adjusts the amount of modulation of the Voice 1 signal. A lower depth setting will produce a more subtle detune effect, while a higher setting will produce a more extreme detuning of Voice 1.
The RATE 1 parameter determines the sweep speed (or the speed at which Voice 1 is modulated). Lower parameter settings will result in slower speeds, while higher settings will result in faster speeds.
The DELAY 1 parameter allows you to select the minimum delay time (in mil liseconds) for Voice 1. This delayed signal (along with Voice 2) is detuned and modulated to produce the chorus effect. Using shorter delay times will result in a tighter sounding chorused signal, while longer delay times will produce a larger ambient effect.
-
31
6. CHORUS Function Continued.....
LEVEL 2
PAN 2
DEPTH 2
RATE 2
DELAY2
The LEVEL 2 parameter determines the volume of Voice 2 in relation to Voice 1
PAN 2 parameter allows you to pan Voice 2 to the left or right channel.
The DEPTH 2 parameter adjusts the amount of modulation of the Voice 2 signal. A lower depth setting will produce a more subtle detune effect, while a higher set ting will produce a more extreme detuning of Voice 2.
The RATE 2 parameter determines the sweep speed (or the speed at which Voice 2 is modulated). Lower parameter settings will result in slower speeds, while higher settings will result in faster speeds.
The DELAY 2 parameter allows you to select the minimum delay time (in mil liseconds) for Voice 2. It is this delayed signal (along with Voice1) that is detuned and modulated to produce the chorus effect. Using shorter delay times will result in a tighter sounding chorused signal, while longer delay times will produce a larger ambient effect.
-
-
32
6. FLANGER Function
The FLANGER function is available if you have selected it in the MODULATION EFX Function.
Flanging involves splitting the input signal into at least two individual delayed signals (Voice 1 and voice 2), then modulating these delayed signals so that, when summed back with the direct signal, phase cancellations will occur at some frequencies while peaks in the response will occur at others.
The PARAMETER SELECT knob will allow you to access these FLANGER parameters:
FLANGER
LEVEL 1
PAN 1
DEPTH 1
RATE 1
LEVEL 2
PAN 2
The Flanger IN/OUT parameter determines whether the Flanger is active for the current preset.
The LEVEL 1 parameter determines the volume of Voice 1 relative to Voice 2.
Tip: Keep the settings of these levels high and use the
DIR/EFF mix parameter in the Mixer function to con­trol the overall amount of flanged signal.
The PAN 1 parameter allows you to pan Voice 1 to the left or right channel.
The DEPTH 1 parameter adjusts the amount of modulation of Voice 1 . Lower DEPTH settings produce more subtle effects, while higher settings will result in a more drastic effect.
The RATE 1 parameter determines the speed at which Voice 1 is modulated.
The LEVEL 2 parameter determines the volume of Voice 2 relative to Voice 1.
The PAN 2 parameter allows you to pan Voice 2 to the left or right channel.
DEPTH 2
RATE 2
REGEN
The DEPTH 2 parameter adjusts the amount of modulation of Voice 2. Lower DEPTH settings produce more subtle effects, while higher settings will result in a more drastic effect.
The RATE 2 parameter determines the speed at which Voice 2 is modulated.
The REGENERATION parameter determines how much of the delayed out put signal is fed back into the input. More regeneration produces a more pro­nounced "jet airplane" type of effect.
-
33
6. TREMOLO Function
The TREMOLO function is available if you have selected it in the MODULATION EFX Function.
The Tremolo effect continuously varies the volume of the signal.
The PARAMETER SELECT knob will allow you to access these TREMOLO parameters:
TREMOLO I/O
LOCATION
DEPTH
T-RATE
SHAPE
The TREMOLO IN/OUT parameter determines whether the Tremolo is active or bypassed for the current preset.
The LOCATION parameter determines whether the Tremolo is located Pre-Re verb or Post-Reverb. Most vintage amplifiers configured the Tremolo (or vibrato) Post-Reverb.
The DEPTH parameter determines the amount of modulation for the Tremolo signal. Lower DEPTH settings produce more subtle tremolo effects, while higher settings will result in a more extreme tremolo effect.
The RATE parameter determines the speed at which the tremolo signal modu lates (or increases and decreases in volume).
The SHAPE parameter determines the wave shape of the tremolo signal. Select­ing a different wave shape produces a different tremolo effect.
-
-
34
6. PITCH SHIFT Function
The PITCH SHIFT function is available if you have selected it in the MODULATION EFX Func­tion.
Pitch Shifting is used to change the pitch of the input signal to produce a harmony note based on the input signal. The harmony voice may be of any fixed interval—up to one octave above the input signal to two octaves below—and is selected in 20-cent increments. Fine adjustment can be made in one cent (1/ 100th semi tone) increments.
The PARAMETER SELECT knob will allow you to access these PITCH SHIFT parameters:
PITCH SHIFT
LEVEL
PAN
PITCH
The PITCH SHIFT IN/OUT parameter determines whether the Pitch Shifter is active or bypassed for the current preset.
The LEVEL parameter determines the volume of the pitch shifted signal. The DIR/EFF MIX parameter in the Mixer function also affects this volume.
The PAN parameter allows you to pan the shifted signal to the left or right chan nel.
The PITCH parameter selects what harmony note the UTOPIA B200 will produce based on the input note. The value displayed for this parameter represents the number of cents that the signal will be shifted (adjustable in 20-cent increments). Each 100 cents (or five 20-cent steps) above or below "0" represents the number of half-steps the shifted signal will be from the input signal.
This parameter is adjustable from "-2400" to "+1200", where "-2400" = two octaves below the input signal, "0" = unison and "+1200' = one octave above the input signal. Refer to the table below to determine the cent value for each fixed interval.
-
FINE
SPEED
The FINE parameter allows for adjustment in 1-cent steps for fine adjustment of the harmony note.
The SPEED parameter determines the amount of time delay used in the shifting process. SLOW results in the longest delay and the highest quality shifted sig­nal (especially at larger amounts of pitch shift), FAST results in the least delay, but the lowest quality shifted signal. This setting should only be used for slight amounts of pitch shift.
35
6. PITCH SHIFT INTERVALS
PARAMETER
VALUE
+1200
+1100
+1000
+900 +800 +700 +600 +500 +400 +300 +200 +100
0
-100
-200
-300
-400
-500
-600
-700
-800
-900
-1000
-1100
-1200
-1300
-1400
-1500
-1600
-1700
-1800
-1900
-2000
-2100
-2200
-2300
-2400
CORRESPONDING INTERVAL
1 Octave Major 7th minor 7th Major 6th minor 6th perfect 5th diminished 5th perfect 4th Major 3rd minor 3rd Major 2nd minor 2nd unison Major 7th minor 7th Major 6th minor 6th perfect 5th diminished 5th perfect 4th Major 3rd minor 3rd Major 2nd minor 2nd 1 octave 1 octave plus a Major 7th 1 octave plus a minor 7th 1 octave plus a Major 6th 1 octave plus a minor 6th 1 octave plus a perfect 5th 1 octave plus a diminished 5th 1 octave plus a perfect 4th 1 octave plus a Major 3rd 1 octave plus a minor 3rd 1 octave plus a Major 2nd 1 octave plus a minor 2nd 2 octaves
Voices above the input signal
Equal to the input signal
Voices below the input signal
36
NOTE: There are 5 steps of the parameter adjust control between each of the intervals shown
above (each step equals 20 cents). This allows for smooth pitch change when used with the built-in expression pedal.
6. DELAY Function
The DELAY function is available in all presets.
Delay is a reproduction of the input signal, occurring at a prescribed time (usually expressed in milli­seconds) following the input signal. The UTOPIA B200 provides two discrete delays (Delay 1 and Delay
2), each of which has its own parameters to determine its particular characteristics.
The PARAMETER SELECT knob will allow you to access these DELAY parameters:
DELAY
MUTE TYPE
The DELAY parameter determines whether the Delay is active or muted for the current preset.
The MUTE TYPE parameter allows for muting the delay at its input (PRE), its output (POST) or BOTH.
Muting the input (PRE) of the delay will not allow any signal to enter the delay section until the delay is switched in. When using a moderate amount of regen­eration, switching out the delay with the input muted will allow you to generate a non-delayed signal which will play over the decaying regenerated signal which continues on after the delay is switched out.
Muting the output (POST) of the delay will result in the delayed signal being im­mediately turned off when the delay is switched out. This means that delays and regeneration will not continue when the delay is switched out. If the output were not muted, signals that were input before the delay was switched out would be allowed to regenerate, even after switching out the delay.
It is also possible to mute both the input and the output (BOTH) so that no signal enters or exits the Delay section when it is not switched in.
DELAY LVL
MIX
The DELAY LEVEL parameter determines the overall level of the delayed signal at the output relative to the direct signal and other effect signals. This parameter can also be accessed from the Delay function parameter list.
The MIX parameter is used to define the ratio of Source 1 signal to Source 2 signal to be input to the Delay section. Source 1 is the Voice 1 output from the previous effect in the signal chain (chorus, flanger, pitch shifter, etc.), while Source 2 may be the Voice 2 output from the previous effect in the signal chain or the direct signal (selectable via the SOURCE 2 parameter).
In configurations where there is no effect immediately preceding the delay, Source 1 and Source 2 will be the preamp output (direct) signal.
37
6. DELAY Function Continued.....
SOURCE 2
DLY HF DAMP
OUT LEVEL 1
PAN 1
DLY TIME 1
REGEN 1
The SOURCE 2 parameter is used to select whether the Source 2 input will be the VOICE 2 output from the previous effect in the signal chain or the direct signal (DIR).
The DELAY HIGH FREQUENCY DAMPING parameter controls the amount of high frequency content in the delayed and regenerated signals. Higher amounts of damping will result in less high frequency information in the delayed signal.
The OUTPUT LEVEL 1 parameter determines the volume of Delay 1 relative to Delay 2.
The PAN 1 parameter allows you to pan the Delay 1 signal to the left or right channel.
The DELAY TIME 1 parameter determines the length of time (in milliseconds) after the input signal that the Delay 1 signal will begin.
The REGENERATION 1 parameter determines the number of times the Delay 1 signal will repeat itself. This is achieved by feeding the delayed output back into the input. Higher parameter settings will result in more repeats. The displayed value represents the attenuation (in dB) that the regeneration signal is subjected to at each repeat.
38
OUT LEVEL 2
The OUTPUT LEVEL 2 parameter determines the volume of Delay 2 relative to Delay 1.
PAN 2
The PAN 2 parameter allows you to pan the Delay 2 signal to the left or right channel.
DLY TIME 2
The DELAY TIME 2 parameter determines the length of time after the input signal that the Delay 2 signal will begin. This length of time is measured in mil liseconds.
REGEN 2
The REGENERATION 2 parameter determines the number of times the Delay 2 signal will repeat itself. This is achieved by feeding the delayed output back into the input. Higher parameter settings will result in more repeats.
* The Delay features a regeneration limiter, since setting both REGEN parameters to high levels would result
in louder and louder echoes until a severe overload occurs. The limiter senses when this condition would occur and automatically turns down both REGEN levels to avoid such an instability. This is especially important when REGEN levels are being adjusted in real-time.
The regeneration levels can be reset by recalling the preset or by accessing the REGEN 1 and REGEN 2
parameters and turning the ADJUST control.
-
6. TAP QUANTIZING Function
The TAP QUANTIZING function allows you to select a TAP rate for the delay preset. When in 2nd Function Mode you can use the Tap Button (Preset button 3) to set the rate of the delay. This is ideal when playing live and you would like to change the delay rate in real time without missing a beat!
The Tap Quantizing can be set (or fixed) for each preset. When pressing the TAP button 4 consecu­tive times at the tempo you want the delay will automatically be quantized to one of the selected TAP Button Parameters as shown below. The Yellow TAP LED will flash to indicate the quantized delay rate.
Here is a table showing what the delay quantizing means::
SIXTEEN One-Quarter of the time between taps (16th Note) EIGHTH One-half of the time between taps (8th Note) TRIPLET Two-thirds of the time between taps (Triplet) QUARTER Equal to the time between taps (1/4 Note) HALF Two times the amount of time between taps (1/2 note) WHOLE Four times the amount of time between taps (Whole Note) NONE No Tapping
The PARAMETER SELECT will allow you to access these TAP QUANTIZING parameters:
DELAY 1
DELAY 2
Select Sixteen, Eighth, Triplet, Quarter, Half, Whole or NONE for Delay 1
Select Sixteen, Eighth, Triplet, Quarter, Half, Whole or NONE for Delay 2
39
6. REVERB Function
Reverb is a multitude of echoes spaced so close together that, to the human ears seem as a single continuous sound. These echoes gradually decrease in intensity until they are ultimately absorbed by the boundaries and obstacles within a room. As the sound waves from the sound source strike the boundar­ies of a room, a portion of the energy is reflected away from the obstacle while another portion is ab­sorbed into it - thereby causing both the continuance of sound as well as the decaying or "dying out' of the sound.
The PARAMETER SELECT knob will allow you to access these REVERB parameters:
REV INPUT
MIX DIR/DLY
REVERB LVL
REV DECAY
REV HF DAMP
The REVERB INPUT parameter determines whether the input to the Reverb sec tion is ACTIVE (passing a signal) or MUTED (will not pass a signal).
The MIX DIRECT/DELAY parameter is used to define the ratio of direct signal to delayed signal to be input to the reverb section.
The REVERB LEVEL parameter allows you to control the level of the reverb signal at the output in relation to the direct signal and other effect signals. This parameter is also accessible from the Mixer function.
The REVERB DECAY parameter determines the length of time that the reverb signal will sound before it has completely died out.
The REVERB HIGH FREQUENCY DAMPING parameter is used to control the decay rate of high frequency information in the reverb signal. Higher parameter settings will result in a faster decay of high frequency information.
-
40
7. UTOPIA B200 Block Diagrams
WITH CHORUS, FLANGER AND PITCH
SHIFT MODULATION EFFECTS
41
7. UTOPIA B200 Blocks Diagrams
WITH TREMOLO
MODULATION EFFECT
42
7. Function - Parameter - Range List
FUNCTION PARAMETER LIST RANGE
(via FUNCTION SELECT) (via PARAMETER SELECT) (via PARAMETER ADJUST)
GLOBAL OUTPUT (Output Level) Stereo, Mono
SPKR XTR (Speaker Exciter Lock) Unlock, Lock Off, Lock L, Lock B
HUSH OFFSET -10(dB) to +30(dB)
MASTER VOLUME -40(dB) to +6(dB)
MIXER VOLUME (Volume Level) 0 to 127
LEFT OUT LVL (Left Channel Output Level) OFF to +4(dB)
RIGHT OUT LVL (Right Channel Output Level) OFF to +4(dB)
MIX (Direct/Effect Mix Level) DIR <0 to 100> EFF
DIR PAN (Direct Signal Panning) L <0 to 100> R
DELAY LVL (Delay Signal Level) OFF to +4(dB)
REVERB LVL (Reverb Signal Level) OFF to +4(dB)
PREAMP CHANNEL DEEP, NORM, BRITE, DIST
GAIN (Gain Level) 0 to 10
VARIAC ADJUST (Variac Level Adjustment) -6(dB) to 0(dB)
BASS (Bass Level) 0 to 10
MID (Midband Level) 0 to 10
TREBLE (Treble Level) 0 to 10
PRESENCE (Presence Level) 0 to 10
BRIGHT In, Out (DEEP, NORM, BRITE)
SCOOP Out, In (DIST Only)
MASTER 0 to 10
SYMMETRY -28(dBu) to +6(dBu) default is
0.0(dBu) (DIST Only)
POLARITY + or - (DIST Only)
DX-FILTER 0 to 49 (DIST Only)
MIX DIR <50> DIS
DIR LPF 0-64
HUSH HUSH (Hush In/Out) Out, In
EXP THRESH (Expander Threshold Level) -90(dB) to -27(dB)
EXCITER EXCITER (Speaker Exciter Status) Off, Left, Both
SPKR CURV (Speaker Curve) A, B, C, D, E
DEFINITION -15 to +15
SONIC BOOM -15(dB) to +15(dB)
COMPRESSOR COMPRESSOR (Compressor In/Out Status) Out, In
COMP THRESH (Compression Threshold) -24(dB) to 0(dB)
COMP ATTACK (Compression Attack) 1MS, 2MS, 4MS, 8MS, 16MS, 25MS, 50MS, 75MS
COMP RELEASE (Compression Release) .05S.to 2.0S
WAH-WAH WAH-WAH (Wah-Wah In/Out Status) Out, In
WAH FREQ (Wah Frequency) 310Hz to 2.6kHz
PHASER PHASER (Phaser In/Out Status) Out, In
DIR/EFF MIX DIR <0 to 100> EFF DEPTH (Amount of Modulation) 0 to 100
P-RATE (Phaser Rate of Modulation) 0 to 254
RESONANCE (Amount of Feedback) 0 to 100
STAGES (Number of Stages) 4, 6
43
7. Function - Parameter - Range List continued.....
FUNCTION PARAMETER LIST RANGE
(via FUNCTION SELECT) (via PARAMETER SELECT) (via PARAMETER ADJUST)
MODULATION MODULATION EFX Chorus, Flanger, Tremolo
EFX Pitch Shift
CHORUS CHORUS (Chorus In/Out Status) Out, In
LEVEL 1 (Voice 1 Level) OFF to +4(dB)
PAN 1 (Voice 1 Panning) L <0 to 100> R
DEPTH 1 (Voice 1 Modulation Depth) 0 to 100
RATE 1 (Voice 1 Modulation Rate) 0 to 254
DELAY 1 (Voice 1 Delay Length) 2ms to 40ms
LEVEL 2 (Voice 2 Level) OFF to +4(dB)
PAN 2 (Voice 2 Panning) L <0 to 100> R
DEPTH 2 (Voice 2 Modulation Depth) 0 to 100
RATE 2 (Voice 2 Modulation Rate) 0 to 254
DELAY 2 (Voice 2 Delay Length) 2ms to 40ms
FLANGER FLANGER (Flanger In/Out Status) Out, In
LEVEL 1 (Voice 1 Level) OFF to +4(dB)
PAN 1 (Voice 1 Panning) L <0 to 100> R
DEPTH 1 (Voice 1 Modulation Depth) 0 to 100
RATE 1 (Voice 1 Modulation Rate) 0 to 254
LEVEL 2 (Voice 2 Level) OFF to +4(dB)
PAN 2 (Voice 2 Panning) L <0 to 100> R
DEPTH 2 (Voice 2 Modulation Depth) 0 to 100
RATE 2 (Voice 2 Modulation Rate) 0 to 254
REGEN (Flanger Regeneration Level) OFF to +4(dB)
TREMOLO TREMOLO (Tremolo In/Out Status) Out, In
LOCATION (Pre or Post Reverb Location) Pre-Rev, Post-Rev
DEPTH (Modulation Depth) 0 to 100
T-RATE (Tremolo Modulation Rate) 0 to 254
SHAPE (Wave Shape) Triangle, Square
PITCH SHIFT PITCH SHIFT (Pitch Shift In/Out Status) Out, In
LEVEL (Pitch Shift Signal Level) OFF to +4(dB)
PAN (Pitch Shift Signal Panning) L <0 to 100> R
PITCH (Pitch Shift in 20-Cent Steps) -2400 to +1200
FINE (Pitch Shift in 1-Cent Steps) -20 to +20
SPEED (Pitch Shift Signal Speed) Slow, Medium, Fast
DELAY DELAY (Delay Status) Muted, Active
MUTE TYPE (Mute Type Status) Pre, Post, Both
DELAY LVL (Delay Level) OFF to +4(dB)
MIX (Source 1/Source 2 Mix Level) S1 <0 to 100> S2
SOURCE 2 (Source 2 Select) DIRECT, Voice 2
DLY HF DAMP (Delay High Frequency Damping) 0 to 99
OUT LEVEL 1 (Delay 1 Level) OFF to +4(dB)
PAN 1 (Delay 1 Panning) L <0 to 100> R
DLY TIME1 (Delay 1 Length) 0 to 2000ms
REGEN 1 (Delay 1 Regeneration) OFF to +4(dB)
OUT LEVEL 2 (Delay 2 Level) OFF to +4(dB)
PAN 2 (Delay 2 Panning) L <0 to 100> R
DLY TIME2 (Delay 2 Length) 0 to 2000ms
REGEN 2 (Delay 2 Regeneration) OFF to +4(dB)
44
7. Function - Parameter - Range List continued.....
FUNCTION PARAMETER LIST RANGE
(via FUNCTION SELECT) (via PARAMETER SELECT) via PARAMETER ADJUST)
TAP QUANTIZING DELAY 1 Sixteen, Eighth, Triplet, Quarter, Half, Whole, None
DELAY 2 Sixteen, Eighth, Triplet, Quarter, Half, Whole, None
REVERB REV INPUT (Reverb Input Status) Muted, Active
MIX (Direct/Delay Mix Level) Dir <0 to 100> Dly
REVERB LVL (Reverb Signal Level) OFF to +4(dB)
REV DECAY (Reverb Decay Length) 0 to 99
REV HF DAMP (Reverb High Frequency Damping) 0 to 99
PEDAL NUMB 1 ADJ, IPED, IPSW, OFF
CONTROLLERS PARA1 Any parameters available in this configuration can be selected.
ULIM C1 Any range in PARA1's selection can be used.
LLIM C1 Any range in PARA1's selection can be used.
NUMB 2 ADJ, IPED, IPSW, OFF
PARA 2 Any parameters available in this configuration can be selected.
ULIM C2 Any range in PARA2's selection can be used.
LLIM C2 Any range in PARA2's selection can be used.
NUMB 3 ADJ, IPED, IPSW, OFF
PARA 3 Any parameters available in this configuration can be selected.
ULIM C3 Any range in PARA3's selection can be used.
LLIM C3 Any range in PARA3's selection can be used.
PEDAL STATUS RUN STAT (Pedal Running Status On or Off) OFF,ON
PEDAL VOLUME 0 to 127
FOOTSWITCH EFX 1 Bypass (Effects bypass), Channel
MAPPING TOGGLE Toggle (Deep, Norm, Brite, Dist),
Solo, Compressor, Modulation
Effect (Chorus, Pitch Shift, Flanger,
Tremolo) Delay, Reverb Input,
TBypass (Bypassing all processing)
MIDI CHANNELS RECEIVE 1-16-OMNI, OFF (default is Omni)
TRANSMIT 1 -16, OFF (default is OFF)
MIDI DUMP/LOAD 1 PR DUMP/LOAD (1 Preset Dump/Load)
BULK DUMP/LOAD
FACTORY RESTR X to X (Restore a single preset) 1 to 1, 2 to 2, 3 to 3, etc.
RESTORE ALL RESTORE (Restore all factory presets) Enter Number 22 - Use caution as this will over-write all presets!
VERSION NUMBER
TITLE EDIT XXXXXXXXX
45
8. Operating the UTOPIA B200
8. Display Description
The LCD display on the Utopia B200 provides you with the information about the preset you are in:
When in PRESET MODE the LEDs will be lit "GREEN" and the display will show the following:
Top line of display will show: BANK - Displays the Preset Bank you have selected. - in the example below - B00 PRESET TITLE - This is the NAME of the preset - in the example below - UTOPIA ROCKS
Bottom line of display will show: PRESET NUMBER - This is the number of the preset - in the example below - 1 EFFECTS USED IN PRESET - in the example below - Psh-Dly-Rev (Pitchshift -Delay-Reverb)
BANK NUMBER
PRESET NAME
B 0 0 u t o p i a r o c k s
1 p s h - d l y - r e v
PRESET NUMBER
When in 2ND FUNCTION MODE the 2nd LED will be lit "RED"
When in PRESET EDIT MODE (accessed by turning the FUNCTION SELECT knob) the display will show the following:
Top line of display will show the FUNCTION selected - in the example below ***PREAMP*** Bottom line of display will show the first PARAMETER of the function - in the example below CHAN NEL BRITE
EFFECTS ON PRESET
-
46
* * * P R E A M P * * *
C H A N N E L B R I T E
8. Selecting a preset:
There are two ways to select a preset on the UTOPIA B200. You can either turn the PRESET knob to the desired preset you wish to recall. The display will show the selected preset number.
1
b 0 4 c o m p r e s s i t !
1 4 c h r - d l y - r e v
The second way to select a preset with the UTOPIA B200 is to use the footswitches. Use the BANK UP and DOWN buttons (points 1 and 2 in the drawing below) to scroll through the BANKS. Then select a preset using the buttons marked 1-3 (see points 3-5 below). For example, if you want to select preset 29, use the bank up button until you reach bank B09 and then press button 2 - this is preset 29. To select preset 37, use the bank up button until you see B12 in the display and then press button 1 - this is preset 37 and it will appear in the window.
You will remain on the current preset until one of the preset buttons, marked 1-3 (points 3-5 below) is pressed. This is a useful feature in a live situation allowing you to be ready to select the next sound you would like to use in a song.
47
8. Preset Banks:
The Utopia B200 has 43 banks of 3 presets each (note that there is no preset "0" or preset "129") for a total of 128 presets. This is an ideal setup for live situations as you can arrange your sounds in each bank to suit your needs. You can use it to set up the 3 sounds you use all the time or set up each bank by particular song. The two line blue display will always show you what bank is selected (or to be select­ed) by the following indications:
48
BANK
B00 B01 B02 B03 B04 B05 B06 B07 B08 B09 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 B31 B32 B33 B34 B35 B36 B37 B38 B39 B40 B41 B42
CONTAINS PRESET NUMBERS
1, 2, 3 4, 5, 6 7, 8, 9 10, 11, 12 13, 14, 15 16, 17, 18 19, 20, 21 22, 23, 24 25, 26, 27 28, 29, 30 31, 32, 33 34, 35, 36 37, 38, 39 40, 41, 42 43, 44, 45 46, 47, 48 49, 50, 51 52, 53, 54 55, 56, 57 58, 59, 60 61, 62, 63 64, 65, 66 67, 68, 69 70, 71, 72 73, 74, 75 76, 77, 78 79, 80, 81 82, 83, 84 85, 86, 87 88, 89, 90 91, 92, 93 94, 95, 96 97, 98, 99 100, 101, 102 103, 104, 105 106, 107, 108 109, 110, 111 112, 113, 114 115, 116, 117 118, 119, 120 121, 122, 123 124, 125, 126 127, 128
8. Changing preset parameters:
Step 1
Step 2
3
Turn the FUNCTION SELECT knob to select the function heading which contains the parameter(s) you wish to change.
2
1
* * * * R E V E R B * * * *
R E V I N P U T M U T E D
Turn the PARAMETER SELECT knob to the specific parameter you wish to change.
* * * * R E V E R B * * * *
R E V D E C A Y 9 4
Step 3
Turn the PARAMETER ADJUST knob to alter the parameter value.
* * * * R E V E R B * * * *
R E V D E C A Y 3 2
NOTE: If you have changed a parameter the "STORE" LED will light. The change(s) that you made will not be stored until you have pressed the "STORE" button. Please follow instructions on the next page for details on how to store changed parameters.
49
8. Storing changed preset parameters:
2
Step 1
While viewing a function or parameter title, press the STORE button to start the store procedure. The display will now alternate between the destination preset number and title and "STORE AT PRESET."
b 1 2 d r e a m d r e a m
3 7 F L A - d l y - r e v
Step 2
Turn the PRESET knob to select the desired preset number to store the new param eter values into. (If you wish to store the new parameter values into the current preset number, this step is not necessary.) The display will now alternate between the new preset number and "STORE AT PRESET".
1,3,4
b 1 2 d r e a m d r e a m
S T O R E A T P R E S E T
-
50
b 1 8 i n v i s i b l e
5 7 T R E - D L Y - R E V
Step 3
Press the STORE button a second time to store the new values into the selected preset number. The display will briefly flash "STORED". Next it will ask you if you would like to also copy the title from the preset. (Turning the PARAMETER ADJUST knob before completing this step will cancel the store procedure.)
B 1 8 i n v i s i b l e
s t o r e d
b 1 8 i n v i s i b l e
S T O R E A T P R E S E T
B 1 8 i n v i s i b l e
C O P Y T I T L E T O O ?
8. Storing changed preset parameters continued...:
Step 4
If you would like to copy the title - press the store button. The display will briefly flash "STORED" and return to PRESET MODE. If you do NOT want to copy the title simply turn the Parameter Adjust one click and the title will not be stored.
B 1 8 d r e a m d r e a m
5 7 T R E - d l y - r e v
NOTE: If a preset with altered parameters is exited before completing Step 3 and 4, all edited
parameter values will be lost. When saving altered parameters, make sure the display flashed "STORED" before exiting the store procedure.
51
8. Operation Mode
The Utopia B200 has two OPERATION MODES - Preset and 2nd. When in Preset mode you can select any preset you would like in the various banks. When in 2nd Mode you are in the 2nd function mode of the selected preset. The 2nd Function mode allows you to turn on and off various aspects of the preset.
PRESET MODE
2ND FUNCTION MODE
BUTTON NUMBER
1
In the PRESET MODE the LEDs on the pedal board will be lit "GREEN". When in this mode you can select any preset in any bank that you would prefer.
To enter into the 2ND FUNCTION MODE, press the "2nd" button. The LED above the 2nd Button will turn "RED". Once in the 2ND FUNCTION MODE you can turn on and off the assigned Effect, MUTE/TUNER and the TAP Delay function with the selected preset.
Here is a list of those effects that can be accessed within each preset in the 2ND FUNCTION MODE:
2ND FUNCTION
EFFECT ON/OFF - turns on or off the assigned effect to that footswitch, either Bypass, Toggle, Solo, Compressor, Modulation Effect, Delay, Reverb Input or Tru-Bypass (one must be set & stored in the Footswitch Mapping Function).
Bypass Effect bypass - turns on or off all the effects and bypasses them completely.
Toggle Channel Toggle - allows you to toggle between two dif­ ferent channels (for example, between Deep and DIST)
SOLO Solo Boost - allows a 4db boost in output, ideal to get a boost when soloing
Compressor Turns on and off the Compressor within the preset.
MOD EFX Turns whatever Modulation Effect (Chorus, Pitch Shift, Flanger, Tremolo) you have assigned on or off.
Delay Turns on and off the Delay within the preset
Reverb Input Turns on and off the Reverb (Active or Muted)
TBypass Tru-Bypass - turns on and off the effects and preamp and allows the signal to pass through the B200 unaffected.
2
MUTE/TUNER - pressing this button will MUTE the output and turn on the built-in Tuner so that you can tune in silence.
3
TAP - this button allows you to set the delay rates by tapping this button at the tempo desired.
52
Exit 2nd Function
2ND - pressing the button again takes you OUT of the 2nd Function mode and return to PRESET MODE
8. Selecting a Modulation Effect
1,32 4
Step 1
Step 2
Turn the FUNCTION SELECT knob to MODULATION EFX.
* m O D U L A T I O N e f x *
* * C H O R U S * *
Turn the PARAMETER ADJUST knob to select Chorus, Flanger, Tremolo or Pitch Shift.
Note: When changed, the EFFECT will turn to a preset starting condition for you to modify further or use directly.
* m O D U L A T I O N e f x *
* * f l a n g e r * *
Step 3
Step 4
Turn FUNCTION SELECT knob to right one click to access the selected effect's function controls.
* * * F l a n g e r * * * *
f l a n g e r i n
Once you have made all of the adjustments to the selected effect and you would like to save the changes you made, press store and follow the instructions under "STOR­ING CHANGED PRESET PARAMETERS" in this manual.
53
8. MUTE/Harmonic Tuner Function
The Utopia B200 provides a built-in harmonic tuner which can be activated by pressing the 2nd button and then the MUTE/TUNER button number 2. This will MUTE the output of the B200 allowing you to tune in silence. Use 12th fret harmonics to tune.
Step 1
Step 2
Enter the turner mode by pressing the 2nd button and then the MUTE/TUNER button number 2.
You will notice the MUTE TUNER red LED is on and the tuner is active.
c
*
Pluck the harmonic at the 12th fret of the string you intend to tune.. The B200 will detect the note and indicate its nearest even tempered pitch at the center of the dis­play. If the note is slightly above or below any of the 12 even-tempered notes, a sharp or flat condition is indicated by an asterisk symbol in the bottom line of the display at either side of the displayed note as shown below:
c
*
FLAT SHARP
Here is a note that is slightly above C (i.e. slightly sharp)
c
*
FLAT SHARP
54
8. MUTE/Tuner F
unction continued.....
Here is a note that is slightly below C (i.e. slightly flat)
c
*
FLAT SHARP
Step 3
Step 4
As you tune the string, the displayed asterisk will move closer to the displayed note on the top line. When the plucked note is perfectly in tune with the note that is dis­played, "TUNED" will display on the bottom line
c
t u n e d - ^ - t u n e d
FLAT
To leave the TUNER and exit the MUTE function simply press button number 2 again. You will return to the preset you were on. Note that the LED will be lit RED to let you know that is the button to use to exit the MUTE/TUNER mode.
SHARP
55
8. USB Connection
You can connect the Utopia 200 directly to a computer via a standard USB cable (not included) and us
­ing standard PC drivers. The USB in the B200 will pass audio and can be used to record directly into a computer based recording system and receive the audio back into the B200. Consult your systems audio interface or recording software documentation for more information.
Note: We suggest changing the Global Parameter to Stereo and turn on the Speaker Exciter for better overall direct audio recording. Use the Master Volume of the B200 to adjust your signal level to the USB host.
8. MIDI IN
The MIDI IN in the Utopia B200 will allow you to update your B200 with new presets directly from a computer using any MIDI interface device. Follow the connection steps in the CONNECTIONS SEC­TION of this manual.
Please note that though the B200 is shipped with 7 Pin din connectors any standard 5 pin MIDI cord may be used for device connections.
8. MIDI OUT/THRU
The MIDI OUT/THRU in the Utopia B200 will allow you to transmit and/or update your B200 with new presets directly from a computer using any MIDI interface device. Follow the connection steps in the CONNECTIONS SECTION of this manual.
You can also use this to connect to a MIDI receiving device that you want to control from the B200.
56
8. MIDI CHANNELS - MIDI RECEIVE
The B200 can receive MIDI commands from other MIDI transmitting devices. In order for this func­tion to operate properly, the B200's MIDI receive channels must be set to correspond to the MIDI Channel that the other devices are sending MIDI messages on. The MIDI RECEIVE channel options are 1-16, OMNI and OFF.
Step 1
Step 2
Step 3
Turn the FUNCTION SELECT knob to MIDI CHANNELS
M I D I C H A N N E L S
Turn the PARAMETER SELECT knob to "Receive Channel"
M I D I c h a n n e l s
r e c e v c h a n l o m n i
Turn PARAMETER ADJUST knob to select the appropriate Receive Channel 1-16, Omni and OFF
Step 4
M i d i c h a n n e l s
r e c e v c h a n l 1 6
Once you have made all of the adjustments to the selected MIDI CHANNEL and you would like to save the changes you made, press store and follow the instructions under "STORING CHANGED PRESET PARAMETERS" in this manual
57
8. MIDI CHANNELS - MIDI Transmit
The B200 can transmit MIDI commands to other MIDI receiving devices. You must however assign a MIDI Transmit channel in order to do so. In the next section [ PROGRAM CHANGES ] you will learn how to send program changes to your favorite piece of rack gear.
Step 1
Step 2
Step 3
Turn the FUNCTION SELECT knob to MIDI CHANNELS.
M I D I C H A N N E L S
Turn the PARAMETER SELECT knob to "Transmit Channel."
m i d i c h a n n e l s
t r a n s c h a n l o f f
Turn PARAMETER ADJUST knob to select the appropriate MIDI Channel 1-16 and OFF.
58
Step 4
M i d i c h a n n e l s
t r a n s m i t 1 6
Once you have made all of the adjustments to the selected MIDI CHANNEL and you would like to save the changes you made, press store and follow the instructions under "STORING CHANGED PRESET PARAMETERS" in this manual.
8. Program Changes:
PROG CH TX ON, MAP, OFF DEFAULT = OFF 1 -TX-PC-> 127 [PROGRAM TRANSMIT MAP]
Note: The TRANSMIT CHANNEL must be assigned found in
MIDI CHANNELS function so the
B200 can send out MIDI MESSAGES.
The B200 can send PROGRAM CHANGES to another MIDI capable device through the MIDI OUT/ THRU jack whenever you recall a preset . You may send any PROGRAM CHANGE number you de­sire adding extra flexibility when controlling a favorite piece of outboard gear.
PROG CH TX
ON The B200 will send PROGRAM CHANGES on a 1 to 1 basis. If you recall PRESET 1 on the B200 it will send PROGRAM CHANGE 1 on the assigned TRANSMIT CHANNEL .
MAP When set to MAP the B200 will send a different PROGRAM CHANGE NUMBER you have selected to be sent using the 1 -TX PC→ 127 mapping ! Default mapping is 1 to 1.
HOW TO MAP PRESETS:
Using the 1 -TX PC→ 1 when you recall preset 1 it could send PROGRAM CHANGE 127 when set as 1 -TX PC→127
To MAP the -TX-PC→ is easy and here’s how you do it.
1. Turn the FUNCTION SELECT to PROGRAM CHAGES FUNCTION.
2. Use the PARAMETER SELECT CONTROL to select the -TX-PC display
3. To pick the preset to be mapped [ The preset you will recall ] TURNING the PARAMETER
SELECT will scroll 1,2,3,4,5,6, etc……
4. Now use the PARAMETER ADJUST to select the PRESET NUMBER you want sent out from the B200.
EXAMPLE:
B200 1 -TX-PC→13 [RECEIVING DEVICE]
5. Once you have set this PRESS STORE to complete the mapping process for that preset. The display will show “ STORED “ to indicate success.
Note: Every changed mapping needs to be stored before advancing to the next B200 preset us­ ing the PARAMETER SELECT.
59
8. MIDI DUMP/LOAD
Any or all of the B200's presets may be dumped to another B200, a sequencer or MIDI utility program using a PC MIDI interface to create a ( .syx ) file. This file may be uploaded to the Rocktron website to share with other users. All the information about the presets you have created will be dumped consist­ing of parameter values, title characters and controller assignments. When dumping a single preset into another B200, the dumped preset can be loaded into any preset location on the receiving unit.
Note: The B200 MIDI data when sent by external means such as a PC MIDI utility program you will need to configure it as stated below.
Buffer size 264 bytes No of buffers 16 both RX and TX 100ms between buffers be used initially as a starting point. 100ms after F7 [ optional ]
If a Midi sequencer is used to store the data record the Sysex data in real-time or adhere to the param­eters given above.
Step 1
Step 2
Step 3
Connect a standard MIDI cable from the MIDI OUT of the transmitting B200 to the MIDI IN of the receiving B200. Consult MIDI Connection drawing for more infor­mation
If you are dumping a single preset to another B200, the transmitting B200 must have that preset selected.
Turn FUNCTION SELECT knob to MIDI DUMP/LOAD.
M I D I D U M P / L O A D
60
Step 4
1 8 P R E D U M P / L O A D
On the receiving B200 use the PRESET Select control to select the preset location where the received preset will be stored. Note that the preset currently stored at the selected location will be lost when the new preset is received.
8. MIDI DUMP/LOAD continued.....:
Step 5
Step 6
On the transmitting B200, press the STORE button to dump the preset. The transmit ting B200 will display "DUMPED"
M I D I D U M P / L O A D
d u m p e d
To BULK DUMP all presets to another B200 or upload them to a Sequencer or Computer using a PC Midi interface along with a MIDI Utility program, use the PARAMETER SELECT knob, select BULK DUMP/LOAD and follow Steps 4 and 5
M I D I D U M P / L O A D
b u l k d u m p / l o a d
-
61
8. Pedal Controllers
The "Pedal Controllers" function allows for specific UTOPIA B200 adjustable parameters to be mapped (or assigned) to three available assignments:
1) PARAMETER ADJUST knob (ADJ)
2) The built-in EXPRESSION PEDAL (IPED - internal pedal)
3) The built-in EXPRESSION PEDAL FOOTSWITCH (IPSW - Pedal/Footswitch)
These controllers will allow for real-time control over the selected parameter.
PARAMETER ADJUST knob (ADJ).
The "ADJ" selection in PEDAL CONTROLLERS section option lets you assign the PARAMETER ADJUST knob for "quick adjust". Many people use this control as a Master volume, but you can assign this to any of the B200's parameters. The default setting of this controller is mapped to MASTER VOLUME.
EXPRESSION PEDAL (IPED) - internal pedal The IPED selection in the PEDAL CONTROLLERS section options lets you assign up to three different parameters that can be adjusted in real time by the built-in EXPRESSION PEDAL . Many people use this for wah, volume, pitchshift and other effects.
EXPRESSION PEDAL FOOTSWITCH (IPSW - internal pedal footswitch)
The ISPW selection in the PEDAL CONTROLLERS section options lets you assign up to three different parameters that can be adjusted in real time by the built-in EXPRESSION PEDAL FOOTSWITCH. The default setting is mapped *Wah On, but it is Off. *Unless preset name relates to WAH then the switch will activate the WAH.
All of these PEDAL CONTROLLERS let you store an "upper" and "lower" parameter value limit which the controller cannot exceed. For example, when using the expression pedal to send continuous control changes to control the "PITCH" parameter, an upper limit of +300 can be set and a lower limit of ­200 can be set — even though the actual parameter range available is from +1200 to -2400. When the expression pedal is at its heel position in this example, the "PITCH" parameter will be at -200, while at its toe position it will be at +300. Up to three controllers can be assigned for each individual preset.
To make adjustment to the PEDAL CONTROLLERS follow these steps:
62
3,5,7,9 122,4,6,8,10 1
8. Pedal Controllers continued........
Step 1
Step 2
Step 3
To access the Pedal Controller function, turn the FUNCTION SELECT knob clockwise to "PEDAL CONTROLERS".
p e d a l c o n t r o l e r s
Turn the PARAMETER SELECT knob for the first parameter of the Controller Assign func tion. This parameter allows you to select a controller number for the NUMB 1 parameter to respond to.
NOTE: This parameter (NUMB 1 only) also gives you the option of selecting "ADJ".
p e d a l c o n t r o l e r s
n u m b 1 a d j
Use the PARAMETER ADJUST knob to select the controller to be assigned to the NUMB 1 parameter (either ADJ, IPED, IPSW or OFF).
-
p e d a l c o n t r o l e r s
n u m b 1 i p e d
When "ADJ" is selected, the parameter assigned to the first controller (PARA 1) can be instantly accessed by turning the PARAMETER ADJUST knob when the preset title is dis played. This allows you to access a parameter that you adjust frequently without paging through function headings and parameters. If you select "IPED" the parameter assigned to the first controller (NUMB 1) will be adjusted by the built-in expression pedal. If you select "OFF" the first controller will not be assigned to either the "ADJ or the IPED".
Step 4
Turn the PARAMETER SELECT knob to select "PARA 1". This parameter allows you to select a parameter for the PARA 1 parameter to respond to.
p e d a l c o n t r o l e r s
p a r a 1 m i x d i r
Step 5
Use the PARAMETER ADJUST knob to scroll through the available parameters to be as­signed to the PARA 1 parameter.
-
p e d a l c o n t r o l e r s
p a r a 1 p e d a l v o l u
63
8. Pedal Controllers......continued..........
NOTE: Parameters available to be assigned may vary depending on what MODULATION effect you have selected for that particular preset.
NOTE: Because character space on the display is limited, you may not see the entire name of a parameter. For example, to choose FLANGER LEVEL 1 or FLANGER PAN 1 (or any of the Flanger's parameters), select "LEVEL 1" or "PAN 1" parameter that immediately follows the "FLANGER" parameter when turning the PARAMETER ADJUST knob clockwise. This is true for some other parameters as well.
Step 6
Turn the PARAMETER SELECT knob one step clockwise to display the Upper Limit parameter (for PARA 1).
p e d a l c o n t r o l e r s
u l i m c 1 1 0 0
NOTE: The UTOPIA B200 allows you to select an upper and lower value limit which the parameter cannot exceed. For example, if a parameter has a value range from 0 to 127, yet you would like the range of the parameter to vary from only 50 to 127, you may set a lower limit of 50 and an upper limit of 127 via the Upper (ULIM) and Lower Limit (LLIM) parameters. When a parameter is stored in the Pedal Controller function (Step 7), the maximum parameter value is automatically stored as the upper limit (expression pedal toe down), while the minimum value is stored as the lower limit (expression pedal heel down).
Step 7
Use the PARAMETER ADJUST knob to choose the highest value that the parameter is not allowed to exceed when the toe of the expression pedal is down.
64
Step 8
Step 9
p e d a l c o n t r o l e r s
u l i m c 1 1 2 7
Turn the PARAMETER SELECT knob one step clockwise to access the Lower Limit parameter (for PARA 1).
p e d a l c o n t r o l e r s
u l i m c 1 0
Use the PARAMETER ADJUST knob to select the lowest value which the parameter is not to fall below through when the heel of the expression pedal is down.
p e d a l c o n t r o l e r s
u l i m c 1 5 0
8. Pedal Controllers......continued.........
Selecting a lower limit value that is greater than the upper limit value will invert the response of the controller - i.e. the toe position of the expression controller will provide the minimum value, while the heel position will provide the maximum value.
Step 10
Step 11
Step 12
To make changes to the second Pedal Controller turn the PARAMETER SELECT knob clockwise one click.
p e d a l c o n t r o l e r s
n u m b 2 I P E d
Repeat steps 3-10 to make changes to NUMB 2, PARA 2, ULIM C2, LLIM C2, NUMB 3, PARA3, ULIM C3, LLIM C3.
You now must store your changes. If you have made any changes to any parameter, the LED above the "STORE" button will light. Press the STORE button to save the changes you have made. "STORE AT PRESET" will flash intermittently with the current preset. If you would like to save this change to the current preset, press the STORE button again. To save this ad­justed preset (and the parameters you have just changed) to a different preset location, use the PRESET SELECT knob to choose the preset and then press the STORE button again. Note that doing this will "over-write" the preset you are saving to.
b 1 2 d r e a m d r e a m
S T O R E A T P R E S E T
NOTE: To exit Pedal Controllers at any time or cancel any changes you have made, turn either the PRESET or FUNCTION SELECT knob. The word CANCEL will flash on the display and then return you to the preset you were working on.
b 1 2 d r e a m d r e a m
c a n c e l
b 1 2 d r e a m d r e a m
3 7 f l a - D L Y - R E V
b 1 2 d r e a m d r e a m
3 7 f l a - D L Y - R E V
65
8. PEDAL STATUS
The PEDAL STATUS is for use with the built-in expression pedal. By setting the RUN STAT pa rameter to ON, the UTOPIA B200 will track the position of the expression pedal (assuming the expres­sion pedal is presently or had been previously assigned to "PEDAL VOLU") and vary the preset volume accordingly from preset to preset. NOTE: When the RUN STAT is ON, the expression pedal will as­sume the last PEDAL VOLUME status received. Please see examples below:
Example 1..... lets assume that you had RUN STAT turned ON and that the preset you are using and
the preset you are switching to both have the expression Pedal Controllers assigned PEDAL VOLUME. If you were to reduce the volume of the current preset with the expression pedal and then changed to another preset, the new preset will assume the present position of the expression pedal. You WILL be able to increase the volume of the new preset with the expression pedal as both presets had the expres­sion Pedal Controllers assigned to PEDAL VOLUME.
Example 2 .... assuming you have RUN STAT turned ON and you have reduced the volume of the
current preset with the expression pedal and changed to a preset where the expression Pedal Control­lers were assigned to control the Pitch Shift or Chorus or Reverb, etc. the new preset will assume the previous preset's pedal volume. However, you will NOT be able to use the pedal to increase the volume as you did in example 1. With RUN STAT turned ON, you would need to switch back to a preset that had the expression Pedal Controllers assigned to pedal volume, use the expression pedal to increase the volume and then switch back to the other preset.
-
This is something you should take into consideration when using the RUN STAT function.
The PEDAL STATUS parameter displays the current preset volume as determined by the pedal posi tion.
NOTE: When the RUN STAT parameter is set to OFF, the UTOPIA B200 only recognizes volume changes from the expression pedal if PEDAL VOLUME is assigned to the pedal and it has been physically moved by the user.
12,43 5
Step 1
Turn the FUNCTION SELECT knob clockwise until PEDAL STATUS is displayed.
-
66
p e d a l s t a t u s
r u n s t a t o f f
8. Pedal Status......continued...........
Step 2
Step 3
Turn the PARAMETER ADJUST knob to select ON for the RUN STAT parameter.
p e d a l s t a t u s
r u n s t a t o n
Turn the PARAMETER SELECT knob one step clockwise to the IPED/VOL param eter.
p e d a l s t a t u s
i p e d / v o l 1 2 7
-
Step 4
The IPED/VOL will only change in real time if the Internal pedal has been assigned to the IPED/VOL parameter. Otherwise to check pedal operation please view the pa­rameter that it is assigned to. I.E.: If assigned to Chorus Rate got to the Chorus Func­tion and look at the RATE parameter and move the pedal. You should see the value changing.
The PEDAL VOLUME parameter displays the current preset volume as determined by the pedal position. Move the expression pedal up and down and you will see the volume values change as the pedal moves.
67
8. Pedal Status......continued.............
Step 5
b 1 2 d r e a m d r e a m
S T O R E A T P R E S E T
NOTE: To exit Pedal Controllers at any time or cancel any changes you have made, turn either the PRESET or FUNCTION SELECT knob. The word CANCEL will flash on the display and then return you to the preset you were working on.
You now must store your changes. If you have made any changes to any parameter, the LED above the "STORE" button will light. Press the STORE button to save the changes you have made. "STORE AT PRESET" will flash intermittently with the current preset. If you would like to save this change to the current preset, press the STORE button again. To save this ad­justed preset (and the parameters you have just changed) to a different preset location, use the PRESET SELECT knob to choose the preset destination and then press the STORE button again. Note that doing this will "over-write" the preset location you are saving to.
b 1 2 d r e a m d r e a m
3 7 f l a - D L Y - R E V
b 1 2 d r e a m d r e a m
c a n c e l
b 1 2 d r e a m d r e a m
3 7 f l a - D L Y - R E V
68
8. Foot SW Mapping (Footswitch Mapping)
The "FOOT SW MAPPING" function allows you to select what effect will be used in the 2ND FUNCTION MODE when accessing the EFFECT ON/OFF (Second Function button number 1)
EFFECT ON/OFF - turns on or off the assigned effect to that footswitch, either Bypass, Toggle, Solo, Compressor, Modulation Effect, Delay, Reverb Input or Tru-Bypass (one must be set & stored in the Footswitch Mapping Function).
Bypass Effect bypass - turns on or off all the effects and bypasses them completely.
Toggle Channel Toggle - allows you to toggle between two different channels (for ex ample, between Deep nd DIST)
SOLO Solo Boost - allows a 4db boost in output, ideal to get a boost when soloing
Compressor Turns on and off the Compressor within the preset.
MOD EFX Turns whatever Modulation Effect (Chorus, Pitch Shift, Flanger, Tremolo) you have assigned on or off.
Delay Turns on and off the Delay within the preset
Reverb Input Turns on and off the Reverb (Active or Muted)
TBypass Tru-Bypass - turns on and off the effects and preamp and allows the signal to pass through the B200 unaffected.
2, 3,5 64 1
Step 1
To access the FOOT SW MAPPING function, turn the FUNCTION SELECT knob clockwise to "FOOT SW MAPPING".
F o o t s w m a p p i n g
e f x 1 b y p a s s
Step 2
Use the PARAMETER ADJUST knob to select Bypass, Toggle, Solo, Compressor, Modula­tion Effect (either Chorus, Flanger, Pitch Shift or Tremolo) , TBypass (Tru-Bypass).
f o o t s w m a p p i n g
e f x 1 s o l o
69
8. Foot SW Mapping (Footswitch Mapping) continued.....
Step 3
Step 4
Turn the PARAMETER ADJUST knob to select TOGGLE.
f o o t s w m a p p i n g
e f x 1 t o g g l e
Use the PARAMETER SELECT knob to access the TOGGLE channel selection for either DEEP, NORM, BRITE or DIST.
f o o t s w m a p p i n g
t o g g l e D E E P
Step 5
Step 6
To pick the desired Channel you want to change to when TOGGLE is performed use the PARAMETER ADJUST control to make your selection.
f o o t s w m a p p i n g
t o g g l e D I S T
Press the STORE button to save the changes. You now have assigned a function to the EFFECT ON/OFF footswitch 1! If you would like to select a different effect for this switch simply follow the same steps above, but choose a different effect.
70
8. Factory Restore
The Factory Restore function allows you to restore presets 1-64 that you may have altered to their original condition as shipped from the factory. Either the entire UTOPIA B200 memory can be restored or a single preset can be restored. Note that you do NOT need to restore presets 65 to 128 as these are factory preset that can not be altered and stored.
Restoring a single factory preset:
32 1
Step 1
Step 2
Turn the FUNCTION SELECT knob clockwise to "FACTORY RESTORE".
f a c t o r y r e s t o r e
Turn the PARAMETER SELECT knob one step clockwise to "RESTR 1 TO 1". The number on the left is the original factory preset number to be restored. The number on the right is the preset location that the preset will be stored into.
f a c t o r y r e s t o r e
r e s t r 1 t o 1
Factory preset to be restored
Current Preset location
Step 3
Press the STORE button to restore the preset. The display will flash "RESTORED" and return to the preset name page.
f a c t o r y r e s t o r e
r e s t o r e d
b 0 0 u t o p i a r o c k s
1 p s h - d l y - r e v
71
8. Restoring all factory presets
This procedure will permanently erase all presets (1-128) and replace them with the original
factory presets. If you have altered and stored presets which you do not want to erase, do not
!! CAUTION !!
perform the following procedure.
Step 1
Step 2
Step 3
4
3
Turn the FUNCTION SELECT knob clockwise to "FACTORY RESTORE".
2
1
f a c t o r y r e s t o r e
Turn the PARAMETER SELECT knob 2 steps clockwise to "ALL RESTORE 0".
f a c t o r y r e s t o r e
A L L R E S T O R E 0
A specific code number must be entered to restore the UTOPIA B200 memory PARAMETER ADJUST knob to enter the number "22".
Use the
f a c t o r y r e s t o r e
72
A L L R E S T O R E 2 2
! ! WARNING ! !
Pressing the STORE button at this time will permanently erase all user presets and replace
them with the original factory presets. If you have altered and stored presets which you do not
want to erase, turn the FUNCTION SELECT control to exit this function.
Step 4
Press the STORE button at this time to initiate the All Restore procedure and erase presets 1-128, replacing them with the original factory presets. The display will flash "RESTORED" as the UTOPIA B200 memory is restored.
f a c t o r y r e s t o r e
r e s t o r e d
The display will return to Preset 1
8. Title Edit Function:
3 52,4 1
Step 1
Step 2
To begin the Title Edit function, turn the FUNCTION SELECT knob clockwise until the UTOPIA B200 displays "TITLE EDIT".
* * t i t l e e d i t * *
b 1 2 d r e a m d r e a m
Turn the PARAMETER SELECT knob clockwise to initiate the Title Edit mode. Turning this knob will also select the character above the part of the current title to be edited. The letter to be adjusted will have a flashing box over the character selected.
(Flashing box)
* * t i t l e e d i t * *
b 1 2 d r e a m d r e a m
Step 3
(Letter to be edited)
Use the PARAMETER ADJUST knob to select the desired character for the current position (flashing box).
(Flashing box)
* * t i t l e e d i t * *
b 1 2 r r e a m d r e a m
(Letter to be edited)
73
8. Title Edit continued......:
Step 4
To edit the next character in the next position, turn the PARAMETER SELECT knob one step clockwise. The flashing box will move to the next character to be adjusted.
(Flashing box)
* * t i t l e e d i t * *
b 1 2 r a a e m d r e a m
(Letter to be edited)
Step 5
After all the characters have been edited as needed, press the STORE button to save the new title to memory. The
UTOPIA B200
will flash "STORED" briefly.
b 1 2 r a m p a g e
3 7 f l a - d l y - r e v
NOTE: The STORE button must be pressed to save the new title. Exiting the Title Edit func­tion before pressing the STORE button will erase any editing that was done in Title Edit. Also, after flashing "STORED", the UTOPIA B200 will exit the title edit mode and return to the main preset number.
74
8. Selecting a Power on Preset:
The UTOPIA B200 allows you to store a Power On preset which will always be recalled when the unit is turned on.
1 2
Step 1
Turn the PRESET knob to the preset number you wish to be recalled each time the unit is turned on.
B 1 1 h i g h s t a r
3 4 p h a - D L Y - R E V
Step 2
b 1 1 h i g h s t a r
P W R O N P R S T O R E D
In the above example, preset 34 has been saved so that when you turn the UTOPIA B200 on in the future, preset 34 will be the preset that is recalled.
Press the STORE button. The screen will flash PWR ON PR STORED and then re­turn to the preset name page.
b 1 1 h i g h s t a r
3 4 p h a - D L Y - R E V
75
9. Specifications
Specifications
Input Impedance 1M Ohm
Input Jack ¼" mono
Maximum Output Level +4 dBu
Important: Listening to any sounds at levels
above 85 dBu may cause hearing damage!
Due to high output capabilities present in
the HEADPHONE OUTPUTS it is recom- mended to only use headphones that have an integrated volume control. You may also
set the volume when the display is showing
a preset name by turning the PARAMETER ADJUST control which is mapped directly to the MASTER VOLUME of the B200.
Maximum Input Level 0 dBu
Output Jacks ¼" Left and Right.
Headphone Jack 1/8" Stereo (Load Impedance 32 Ohm Min)
76
Aux Input Jack
Power Requirements 9VAC / 2.9A min. Depending on where you
are located in the world you may receive a
2 .9A, 3A, 3.5A adapter with USA or Euro style plugs.
15 1/8" Wide x 9" Deep x 3 1/4" Tall
387mm Wide x 228mm Deep x 83mm Tall
With toe of expression pedal up
15 1/8" Wide x 9" Deep x 4 7/8" Tall
387mm Wide x 228mm Deep x 124mm Tall
2.72kg
Dimensions With toe of expression pedal down
Weight 6lbs
1/8" Stereo
10. Utopia B200 Preset Listing
# Preset Name What it does Pedal Heel Toe 1 UTOPIA ROCKS Clean Volume Volume Off Volume Full On 2 B’ChorusED Clean with Chorus Volume Volume Off Volume Full On 3 BASE---EDGE Distortion with Delay Volume Volume Off Volume Full On 4 BIG Wah Wah Light Distortion with Wah Wah and Delay Wah Frequency 150 1290 5 BASE BALLZ Light Distortion with a quick Delay Volume Volume Off Volume Full On 6 B’FLANGED Clean with Flanger Volume Volume Off Volume Full On 7 PINK DAYS 1 Clean with Phaser, Delay and Reverb Volume Volume Off Volume Full On 8 PINK DAYS 2 Clean with Tremolo and Reverb Tremolo Depth 25 100 9 FOOT PHASE Clean with Phaser Phaser Rate 12 190 10 LOW FIVE Clean with Pitch Shifted 5th added Volume Volume Off Volume Full On 11 TAIKA LEAD Distortion with Delay Volume Volume Off Volume Full On 12 BASS CRUNCH Distortion w/Chorus Delay and Reverb Gain 6.6 10 13 LIQUID BASS Clean with Chorus and Reverb Chorus Level OFF +4 14 COMPRESS IT! Clean with Chorus, Delay and Reverb Compressor OUT IN 15 LUCKY MAN Distortion with Pitch Shift and Delay Pitch 0 1200 16 CLEAN WAH Clean with Wah Wah Frequency 300 1290 17 SWEEPING UP Clean with Chorus Treble 0 10 18 PHASE AROUND Clean with Phaser MIX DIR <0 <50> 19 MR. SQUIRE Clean with Tremolo and Reverb Tremolo Depth 0 100 20 FUZZ-O-MATIC Light Distortion with Delay and Reverb Gain 0.33 10 21 STANLEY’S WAY Clean with Chorus and Reverb Reverb Level -45 -6 22 CRYIN BABY Distortion with Wah, Delay and Reverb Wah Frequency 300 1290 23 BLUE PHASE Clean with Phaser, Delay and Reverb Phaser Depth 0 100 24 MONSTER BASS Distortion with Flanger, Delay and Reverb Volume Volume Off Volume Full On 25 HVY STEPDOWN Distortion with Pitch Shift and Delay Pitch Shift One Step Down-200 00 = Normal Pitch 26 CLN STEPDOWN Clean with Pitch Shift and Reverb Pitch Shift One Step Down -200 00 = Normal Pitch 27 PITCH AROUND Clean with Pitch Shift and Reverb MIX DIR <0 <20 28 OVERCOAT Clean with Wah and Delay Wah Frequency 428 1290 29 TOP HAT Light Distortion with Wah and Delay Wah Frequency 338 1290 30 TREM PEDAL Clean with Delay Tremolo RATE 0 254 31 DIST.+Gain Distortion with Delay and Pitch Shift Gain 1.3 10 32 SMOOTH DOWN Clean with Delay and Reverb Volume Volume Off Volume Full On 33 I’M DA WALRS Distortion with HEAVY Delay Volume Volume Off Volume Full On 34 HIGH STAR Distortion with Delay and Reverb Volume Volume Off Volume Full On 35 BLACK PHASE Light Distortion with Phaser and Reverb Phaser Depth 0 100 36 BIG BOTTOM Distortion with Pitch, Delay and Reverb Pitch -1200 0 37 DREAM DREAM Clean with Flanger, Delay and Reverb Flanger Level OFF +4 38 WIDE BASS 1 Clean with Chorus and Reverb Volume Volume Off Volume Full On 39 WIDE BASS 2 Light Distortion with Chorus and Reverb Volume Volume Off Volume Full On 40 DEEP HOLE Clean with LONG Reverb DECAY MIX DIR 100> <1 41 DIRTY-Chorus Distortion with Chorus and Delay Chorus Level OFF +4 42 DIRTY-FLANGE Distortion with Flanger and Delay Flanger Level OFF +4 43 CURRY DINNER Clean with Reverb and Pitch Shift Volume Volume Off Volume Full On 44 VOLUME SWELL Clean with Pitch Shift Delay and Reverb Volume Volume Off Volume Full On 45 DROP IT! Distortion with Pitch Shift and Delay Pitch Shift -1200 0 46 BASS-N-ORGAN Clean with Pitch Shift Delay and Reverb Volume Volume Off Volume Full On 47 MID SWEEP Distortion with Chorus and Delay Preamp Mid 0 10 48 WET BASEMAN Clean with Chorus and Reverb Chorus Level OFF +4 49 DIRTY-D-VERB Distortion w/Pitch Shift Delay and Reverb Delay Out Level OFF +4 50 HI-FRETLEAD1 Distortion with Pitch Shift and Delay Pitch Level OFF +4 51 HI-FRETLEAD2 Distortion with Pitch Shift and Delay Pitch Level OFF +4 52 UP-THE-Gain Distortion Gain 1.3 10 53 FLANGY B100 Clean with Flanger and Reverb Flanger Level OFF +4 54 PHASEY B100 Clean with Phaser and Reverb MIX DIR <0 100> 55 ELECTRIC GTR Distortion with Delay and Reverb MIX DIR <0 <50> 56 TREMOLUX Clean with Tremolo and Reverb Tremolo Depth 0 100 57 INVISIBLE Clean with Tremolo Delay and Reverb Tremolo Depth 0 100 58 WEEPING B100 Clean with Wah and Reverb Wah Frequency 400 1290 59 DIRTY DAY Distortion with Phaser and Reverb MIX DIR <0 100> 60 BOUNCEBASS Clean with Delay Volume Volume Off Volume Full On 61 MEAN LEAD Distortion with Phaser Delay and Reverb Resonance 0 100 62 HEAVY BONES Distortion with Pitch Shift Pitch Level OFF +4 63 BASS JET Distortion with Flanger and Delay Flanger Level OFF +4 64 UNDERTOW Clean with Chorus Delay and Reverb Chorus Level OFF +4
77
10. Utopia B200 Preset Listing
# Preset Name What it does Pedal Heel Toe 65 UTOPIA ROCKS Clean Volume Volume Off Volume Full On 66 B’ChorusED Clean with Chorus Volume Volume Off Volume Full On 67 BASE---EDGE Distortion with Delay Volume Volume Off Volume Full On 68 BIG Wah Wah Light Distortion with Wah Wah and Delay Wah Frequency 150 1290 69 BASE BALLZ Light Distortion with a quick Delay Volume Volume Off Volume Full On 70 B’FLANGED Clean with Flanger Volume Volume Off Volume Full On 71 PINK DAYS 1 Clean with Phaser, Delay and Reverb Volume Volume Off Volume Full On 72 PINK DAYS 2 Clean with Tremolo and Reverb Tremolo Depth 25 100 73 FOOT PHASE Clean with Phaser Phaser Rate 12 190 74 LOW FIVE Clean with Pitch Shifted 5th added Volume Volume Off Volume Full On 75 TAIKA LEAD Distortion with Delay Volume Volume Off Volume Full On 76 BASS CRUNCH Distortion w/Chorus Delay and Reverb Gain 6.6 10 77 LIQUID BASS Clean with Chorus and Reverb Chorus Level OFF +4 78 COMPRESS IT! Clean with Chorus, Delay and Reverb Compressor OUT IN 79 LUCKY MAN Distortion with Pitch Shift and Delay Pitch 0 1200 80 CLEAN WAH Clean with Wah Wah Frequency 300 1290 81 SWEEPING UP Clean with Chorus Treble 0 10 82 PHASE AROUND Clean with Phaser MIX DIR <0 <50> 83 MR. SQUIRE Clean with Tremolo and Reverb Tremolo Depth 0 100 84 FUZZ-O-MATIC Light Distortion with Delay and Reverb Gain 0.33 10 85 STANLEY’S WAY Clean with Chorus and Reverb Reverb Level -45 -6 86 CRYIN BABY Distortion with Wah, Delay and Reverb Wah Frequency 300 1290 87 BLUE PHASE Clean with Phaser, Delay and Reverb Phaser Depth 0 100 88 MONSTER BASS Distortion with Flanger, Delay and Reverb Volume Volume Off Volume Full On 89 HVY STEPDOWN Distortion with Pitch Shift and Delay Pitch Shift One Step Down-200 00 = Normal Pitch 90 CLN STEPDOWN Clean with Pitch Shift and Reverb Pitch Shift One Step Down -200 00 = Normal Pitch 91 PTICH AROUND Clean with Pitch Shift and Reverb MIX DIR <0 <20 92 OVERCOAT Clean with Wah and Delay Wah Frequency 428 1290 93 TOP HAT Light Distortion with Wah and Delay Wah Frequency 338 1290 94 TREM PEDAL Clean with Delay Tremolo RATE 0 254 95 DIST.+Gain Distortion with Delay and Pitch Shift Gain 1.3 10 96 SMOOTH DOWN Clean with Delay and Reverb Volume Volume Off Volume Full On 97 I’M DA WALRS Distortion with HEAVY Delay Volume Volume Off Volume Full On 98 HIGH STAR Distortion with Delay and Reverb Volume Volume Off Volume Full On 99 BLACK PHASE Light Distortion with Phaser and Reverb Phaser Depth 0 100 100 BIG BOTTOM Distortion with Pitch, Delay and Reverb Pitch -1200 0 101 DREAM DREAM Clean with Flanger, Delay and Reverb Flanger Level OFF +4 102 WIDE BASS 1 Clean with Chorus and Reverb Volume Volume Off Volume Full On 103 WIDE BASS 2 Light Distortion with Chorus and Reverb Volume Volume Off Volume Full On 104 DEEP HOLE Clean with LONG Reverb DECAY MIX DIR 100> <1 105 DIRTY-Chorus Distortion with Chorus and Delay Chorus Level OFF +4 106 DIRTY-FLANGE Distortion with Flanger and Delay Flanger Level OFF +4 107 CURRY DINNER Clean with Reverb and Pitch Shift Volume Volume Off Volume Full On 108 VOLUME SWELL Clean with Pitch Shift Delay and Reverb Volume Volume Off Volume Full On 109 DROP IT! Distortion with Pitch Shift and Delay Pitch Shift -1200 0 110 BASS-N-ORGAN Clean with Pitch Shift Delay and Reverb Volume Volume Off Volume Full On 111 MID SWEEP Distortion with Chorus and Delay Preamp Mid 0 10 112 WET BASEMAN Clean with Chorus and Reverb Chorus Level OFF +4 113 DIRTY-D-VERB Distortion w/Pitch Shift Delay and Reverb Delay Out Level OFF +4 114 HI-FRETLEAD1 Distortion with Pitch Shift and Delay Pitch Level OFF +4 115 HI-FRETLEAD2 Distortion with Pitch Shift and Delay Pitch Level OFF +4 116 UP-THE-Gain Distortion Gain 1.3 10 117 FLANGY B100 Clean with Flanger and Reverb Flanger Level OFF +4 118 PHASEY B100 Clean with Phaser and Reverb MIX DIR <0 100> 119 ELECTRIC GTR Distortion with Delay and Reverb MIX DIR <0 <50> 120 TREMOLUX Clean with Tremolo and Reverb Tremolo Depth 0 100 121 INVISIBLE Clean with Tremolo Delay and Reverb Tremolo Depth 0 100 122 WEEPING B100 Clean with Wah and Reverb Wah Frequency 400 1290 123 DIRTY DAY Distortion with Phaser and Reverb MIX DIR <0 100> 124 BOUNCEBASS Clean with Delay Volume Volume Off Volume Full On 125 MEAN LEAD Distortion with Phaser Delay and Reverb Resonance 0 100 126 HEAVY BONES Distortion with Pitch Shift Pitch Level OFF +4 127 BASS JET Distortion with Flanger and Delay Flanger Level OFF +4 128 TEST PRESET
78
79
Rocktron -A Division of GHS Corporation
B
200
2813 Wilber Avenue Battle Creek MI 49037 USA Rocktron Phone: 1-(269)-968-3351 Email: info@rocktron.com
Check us out on the web at:
www.rocktron.com
80
2007-0001 Rev. 12/03/07
Loading...
