Rockford Fosgate Prime R1L-1X10, Prime R1L-1X12, Prime R1L-2X10, Prime R1L-2X12 Installation And Operation Manual

R1L – LOADED ENCLOSURES

SVC - SINGLE VOICE COIL SUBWOOFERS

Serial Number: Date of Purchase:

R1L 10" 12"

Single R1L-1X10 R1L-1X12

Dual R1L-2X10 R1L-2X12

Installation & Operation

INSTALLATION – ENGLISH

Strip 5/8"

(16mm)

From

Amplifier

From

Amplifier

16 AW G

-to-

12 AW G

CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.

Run the speaker cable from the amp. When routing the speaker cable from the amplifier, avoid running it close to any sources of high current

(wiring harnesses).
black terminal.

INSTALLATION – FRANÇAIS

MISE EN GARDE : a

Branchement du câble du haut-parleur de l’amplificateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de l’approcher d’une source

de courant important. La sortie positive de l’ampli se branche sur le terminal rouge du caisson, et le négatif se branche sur le terminal noir.

INSTALACIÓN – ESPAÑOL

PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio

Recorrido del Cable de Altavoz Desde el Amplificador. Al llevar el cable de altavoz desde el amplificador, evite que pase cerca de cualquier

fuente de alto corriente (cables de alimentacion). El terminal positive (+) de las salida de rojo, y el terminal negativo (-) al terminal negro.

EINBAU – DEUTSCH

VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu

Anschluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel

kreuzt, um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherkabels kommt in die rote Klemme des Terminals, die Negativ-Leitung in die
schwarze Klemme des Terminals.

The positive (+) speaker output from the amp connects to the red terminal of the enclosure, and the negative (-) connects to the

vant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de

blessures, d’incendie ou de dommages à l'appareil.

y/o posibles lesiones.

vermeiden.

INSTALLAZIONE – ITALIANO

ATTENZIONE: Prima dell’installazione, scollegate il terminale negativo (-) della batteria per evitare danni all’unità,

pericoli d’incendio e/o potenziali lesioni personali.

Far correre il cavo dell’altoparlante all’amplificatore. Quando fate correre il cavo dell’altoparlante all’amplificatore non
fatelo passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto. Il segnale positivo dell’altoparlante (+) in uscita dall’amplificatore á col­legato al terminale rosso del diffusore, e il negativo (-) al terminale nero.

R1L-1X10 / R1L-1X12

Amplifier 4Ω Mono
Amplificador 4Ω Mono
Amplificateur de 4Ω Mono
Amplifier 4Ω Mono
Amplificator

e 4Ω Mono

R1L-2X10 / R1L-2X12

Amplifier 2Ω Mono
Amplificador 2Ω Mono
Amplificateur de 2Ω Mono
Amplifier 2Ω Mono
Amplificator

e 2Ω Mono

Black
Negro
Noir
Schwarz
Nero

Red
Rojo
Rouge
Rot
Rosso

FEATURES

Enclosure Features

• High Current Binding Posts

• Constructed with 5/8" MDF
Covered with High Density Carpet

•

Speaker Features

• Parabolic polypropylene cone.

• 12 AWG compression terminals.

• 18 gauge stamped steel frame.

• Optimized for sealed enclosures.

SPECIFICATIONS

R1L-1X10 Single 10" SVC

Nominal Impedance (Ohms) 4 Ω
Replacement Woofer R1S410
Power Handling (Watts) 150 RMS / 300 Max
Overall Dimensions (HxWxD) 12.0” x 15.825” x 12.25”

(30.5cm x 40.1cm x 31.1cm)

R1L-1X12 Single 12" SVC

Nominal Impedance (Ohms) 4 Ω
Replacement Woofer R1S412
Power Handling (Watts) 150 RMS / 300 Max
Overall Dimensions (HxWxD) 14.0” x 17.5” x 12.25”

(35.6cm x 44.5cm x 31.1cm)

R1L-2X10 Dual 10" SVC

Nominal Impedance (Ohms) 2 Ω
Replacement Woofer R1S410 (wired internally)
Power Handling (Watts) 300 RMS / 600 Max
Overall Dimensions (HxWxD) 12.0” x 30.0” x 12.25”

(30.5cm x 76.2cm x 31.1cm)

R1L-2X12 Dual 12" SVC

Nominal Impedance (Ohms) 2Ω
Replacement Woofer R1S412 (wired internally)
Power Handling (Watts) 300 RMS / 600 Max
Overall Dimensions (HxWxD) 14.0” x 33.75” x 12.25”

(35.6cm x 85.7cm x 31.1cm)

Specifications subject to change without notice
