RocketFish RF-ACU12002 User Manual

Rocketfish Laptop AC Power
Adapter

RF-ACU12002

User Guide

Rocketfish RF-ACU12002

Laptop AC Power Adapter

Contents

Introduction............................................................................2

Safety information................................................................3

Features....................................................................................3

Using the AC power adapter.............................................4

FAQ for Rocketfish Adapters .............................................5

Specifications .........................................................................7

Legal notices...........................................................................8

Three-year limited warranty........................................... 11

Introduction

Thank you for purchasing a Rocketfish laptop AC power
adapter. This adapter plugs into any AC power outlet anywhere
in the world, and provides a reliable power source to run your
laptop computer and charge its internal battery. Rocketfish
adapters are made using the highest quality components and
feature all of the necessary voltage and heat protection circuits
to ensure maximum levels of safety and efficiency.

NOTE: A physical adapter plug may be necessary to plug into
some AC power outlets outside of the United States.

You can go to the Tip Wizard at www.rocketfishproducts.com
for a complete listing of laptops that are compatible with this
Rocketfish adapter.

CAUTION: This AC power adapter is not compatible with Mac
computers or laptops requiring more than 120 watts of power.

2

RF-ACU12002

Safety information

• Do not expose the power adapter to rain, moisture, or
excessive dust. It may cause shock hazards.

• Do not operate the adapter in direct sunlight.

• Operate the adapter in a well ventilated area. Maximum
ambient temperature around the power adapter must not
exceed 105° Fahrenheit (40° Celsius).

• Do not open the power adapter under any circumstances.
The power adapter is not intended to be repaired in case of
failure or component defect. There are no internal
serviceable parts.

• Discontinue use and contact our toll free help line for
assistance [phone] if any of the following should
occur:

• The adapter shuts down when it is plugged into the
device (LED turns off ).

• The adapter's LED light blinks when the adapter is
plugged into an AC power outlet.

• A cord or plug is damaged or frayed.

• Do not use with laptops that require more than 120 watts of
power.

• You can go to the Tip Wizard at
www.rocketfishproducts.com for a complete listing of
compatible models. Do not use a tip that is not listed for
your laptop.

• Keep away from children.

Features

• Provides up to 120 watts of power

• Includes over-voltage, over-temperature, and short circuit
protection

• Powers laptops using a standard AC wall outlet

3

Package contents

• Rocketfish laptop AC power adapter

•AC power cord

•User Guide

Using the AC power adapter

Tip

Output
cable

DC input jack

AC adapter

LED

AC cord

To use the AC power adapter:

1 Connect the AC power cord to the socket on the AC power

adapter.

2 Plug the AC power cord into an AC power outlet or power

strip. The LED on the adapter lights up indicating that the
adapter is powered and ready.

AC
power
outlet

4
