RocketFish RF-700WPS User Manual

700 Watt Power Supply

RF-700WPS

User Guide

Rocketfish RF-700WPS

700 Watt Power Supply

Contents

Introduction ...................................................................... 2

Features............................................................................... 3

Installing your power supply....................................... 4

Specifications.................................................................... 6

Legal notices ..................................................................... 7

One-Year Limited Warranty.......................................... 9

Introduction

Thank you for choosing this RF-700WPS power supply unit (PSU).
Please read this manual carefully and follow the instructions before
installing the PSU.

The RF-700WPS power supply complies with the newest SSI EPS12V
Version 2.91 and Intel ATX12V version 2.2 specifications. This includes
four +12V output circuits that deliver safer and more reliable output
to your system's components. In addition, this power supply is
energy efficient, reducing power consumption by 80%. It also
includes two PCI-E connectors for SLi. We have also included a variety
of industrial-grade protective circuits, including the following:

• OCP (Over Current Protection)

• OPP (Over Power Protection)

• OVP (Over Voltage Protection)

• SCP (Short Circuit Protection).

2

Safety information

WARN ING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DEVICE TO RAIN OR MOISTURE.

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

Important Safety Instructions

1 Do not place your system near a radiator or other heat source.
2 Do not place your system close to a source of strong magnetic fields.
3 Do not place you system in a moist or dusty environment, or in an area

subject to strong vibration.

4 Do not place your system in direct sunlight.

Features

• Compliant with Intel ATX12V V2.2 and EPS12V V2.91 specifications

• Active Power Factor Correction

•SLi ready

• Supports Intel and AMD Dual- and Multi-core processors

• Four +12V output rails

•80% efficiency performance

• Higher reliability and built-in protection circuits (OCP, OVP, OLP, and SCP)
and line input fuse protection

• Easily moveable connector

3RF-700WPS

• FAN speed auto-controlled by a thermal sensor inside the power supply

• 100% Hi-pot and burn-in tested

• Supports 12-16 SCSI hard drives

•Components include:

Output cables

3.4 inches
(86.0 mm)

5.9 inches
(150.0 mm)

5.5inches
(140.0 mm)

Fan

4.7 inches
12 cm

Installing your power supply

To make sure you connect your power supply correctly, check your
motherboard and graphics card manuals for compatibility before
connecting RF-700WPS to any of your devices.

To install your power supply:

1 Check your local AC voltage before installation (115 VAC voltage is for

USA, Japan, and so on, and 230 VAC voltage is for Europe, South East
Asia, and many other countries).

Caution:
Be sure to connect the PSU (Power Supply Unit) to local input AC voltage only. Setting

the incorrect voltage can damage the power supply and connected equipment, and
may void your warranty. The RF-700WPS is compatible with 115VAC and 230VAC
input voltage.

2 Turn off your computer, then unplug the power cord from your old

power supply.

3 Open your computer case following the directions provided in your case

manual.

AC socket

Power switch

4
