CL 52
11
ENGLISH
SUMMARY
WARRANTY
IMPORTANT WARNING
INTRODUCTION TO YOUR NEW
VEGETABLE PREPARATION MACHINE
CL 52
SWITCHING ON THE MACHINE
• Advice on electrical
ASSEMBLY
USES AND CHOICE OF DISCS
CLEANING
MAINTENANCE
• Blades, plates and graters
TECHNICAL SPECIFICATIONS
• Weight
• Dimensions
• Working height
• Noise level
• Electrical data
SAFETY
STANDARDS
TECHNICAL DATA
• Exploded views
• Electric and wiring diagrams
12
ROBOT-COUPE S.N.
C., LIMITED WARRANTY
Your new ROBOT-COUPE appliance is warranted to the original buyer for a period of
one year from the date of sale if you
bought it from ROBOT-COUPE
S.
N.C.
If you bought your ROBOT-COUPE product
from a distributor your product is covered
by your distributor’s warranty (Please check
with your distributor terms and conditions
of the warranty).
The ROBOT-COUPE
S.N.C. limited warranty
is against defects in material and/or workmanship.
The ROBOT-COUPE S .N.C. warranty is
given expressly and in lieu of all other
warranties, expressed or implied, for
merchantability and for fitness toward a
particular purpose and constitutes the only
warranty made by ROBOT-COUPE
S.N.C.
France.
THE FOLLOWING ARE NOT COVERED
BY THE ROBOT-COUPE
S.N.C
.
WARRANTY:
1 - Damage caused by abuse, misuse, dropping,
or other similar damage caused by or
resulting from failure to follow assembly, operating, cleaning, user maintenance or storage
instructions.
2 - Labour to sharpen and/ or replacements for
blades which have become blunt, chipped or
worn after a normal or excessive period of use.
3 - Materials or labour to replace or repair
scratched, stained, chipped, pitted, dented or
discoloured surfaces, blades, knives, attachments
or accessories.
4 - Any alteration, addition or repair that has
not been carried out by the company or an
approved service agency.
5 - Transportation of the appliance to or from an
approved service agency.
6 - Labour charges to install or test new attach-
ments or accessories (i.e., bowls, discs, blades,
attachments) which have been arbitrarity replaced.
7 - The cost of changing direction-of-rotation of
three-phase electric motors (Installer is responsible).
8 - SHIPPING DAMAGES. Visible and latent
defects are the responsibility of the freight carrier.
The consignee must inform the carrier and consignor immediately, or upon discovery in the case
of latent defects.
KEEP ALL ORIGINAL CONTAINERS AND
PACKING MATERIALS FOR CARRIER INSPECTION.
Neither ROBOT-COUPE
S.N.
C. nor its affiliated
companies or any of its distributors, directors,
agents, employees, or insurers will be liable for
indirect damage, losses, or expenses linked to the
appliance or the inability to use it.
13
ENGLISH
WARNING : In order to limit accidents such as electric shocks or personal injury, and in order to limit material damage due to misuse
of the appliance, please read these instructions carefully and follow them strictly. Reading the operating instructions will help you get
to know your appliance and enable you to use the equipment correctly. Please read these instructions in their entirety and make sure
that anyone else who may use the appliance also reads them beforehand.
IMPORTANT WARNING
UNPACKING
• Carefully remove the equipment from the packaging
and take out all the boxes or packets containing
attachments or specific items.
• WARNING - some of the tools are very sharp e.g.
blades, discs... etc.
INSTALLATION
• We recommend you install your machine on a
perfectly stable solid base.
CONNECTION
• Always check that your mains supply corresponds
to that indicated on the identification plate on the
motor unit and that it can withstand the amperage.
• The machine must be earthed.
HANDLING
• Always take care when handling the blades, as
they are extremely sharp.
ASSEMBLY PROCEDURES
• Follow the various assembly procedures carefully
(see page 14) and make sure that all the attachments
are correctly positioned.
USE
• Never try to override the locking and safety systems.
• Never insert an object into the container where the
food is being processed.
• Never push the ingredients down with your hand.
• Do not overload the appliance.
• Never switch the appliance on when it is empty.
CLEANING
• As a precaution, always unplug your appliance
before cleaning it.
• Always clean the appliance and its attachments at
the end of each cycle.
• Never immerse the motor unit in water.
• For parts made from aluminum, use cleaning fluids
intended for aluminum.
• For plastic parts , do not use detergents that are
too alkaline (e.g., containing too much caustic soda or
ammonia).
• Robot-Coupe can in no way be held responsible
for the user’s failure to follow the basic rules of
cleaning and hygiene.
MAINTENANCE
• Before opening the motor housing, it is absolutely
vital to unplug the appliance.
• Check the seals and washers regularly and ensure
that the safety devices are in good working order.
• It is particularly important to maintain and check the
attachments since certain ingredients contain corrosive
agents, e.g. citric acid.
• Never operate the appliance if the power cord
or plug has been damaged or if the appliance fails to
work properly or has been damaged in any way.
• Do not hesitate to contact your local Maintenance
Service if something appears to be wrong.
14
INTRODUCTION TO
YOUR NEW VEGETABLE
PREPARATION MACHINE
CL 52
The CL 52 is perfectly geared to professional needs.
It can perform any number of tasks, which you will
gradually discover as you use it.
The CL 52 is equipped with a removable lid, metal
bowl an stainless steel motor base. The full moon
hopper is ideal for cutting large products.
The CL 52 is supplied with a wide range of discs
and grids to satisfy even the most demanding chefs
when it comes to cutting up fruit and vegetables, i.e.
slicing, grating, julienne, dicing and french fried
potatoes discs.
Thanks to its simple design, all components requiring frequent handling for maintenance or cleaning
can be fitted and removed in a trice.
To make things easier for you, this manual gives a
breakdown of all the various fitting operations.
This manual contains important information
designed to help the user get the most out of this
vegetable preparation machine.
We therefore recommend that you read it carefully
before using your machine.
We have also included a few examples to help you
get the feel of your new machine and appreciate its
numerous advantages.
ASSEMBLY
1) With the motor base
facing you, place the
discharge plate on the
bottom of the bowl.
Emptying arm for fine grating and
slicing only (cabbage, celery,
carrots, cheese, etc.).
SIDE A facing upwards (ejection rib
downwards) for any vegetables or
citrus fruit which require careful
handling (tomatoes, mushrooms...).
SIDE B facing upwards (ejection rib
upwards) for all other types of fruit or
vegetables.
SWITCHING ON THE MACHINE
Before plugging in, check that your power supply
corresponds to that indicated on the machine’s
identification plate.
Switch on the empty machine, making sure that
the blade is rotating properly in an anti-clockwise
direction.
On the motor base, a red arrow marks the blade
rotation direction. If the blade turns in a clockwise
direction, swap over two wires:
Since GREEN/YELLOW is the earth,
DO NOT DISCONNECT.
Swap either: the and the
the and the
the and the
323
121
• CL 52 SINGLE-PHASE
ROBOT-COUPE CL 52 are fitted with various types
of motors: 230 V / 50 Hz /1
115 V / 60 Hz /1
220 V / 60 Hz /1
The machine comes with a single-phase plug
con-nected to a power cord.
• CL 52 THREE-PHASE
ROBOT-COUPE CL 52 are fitted with various types
of motors: 400 V / 50 Hz /3
220 V / 60 Hz /3
380 V / 60 Hz /3
The machine is supplied with a cable to which you
simply attach the appropriate electrical plug for
your system. The cable has four wires, one earth
wire, plus three phase wires.
If you have a 4-pin plug:
1) Connect the green and yellow earth wire to the
earth pin.
2) Connect the three other wires to the remaining
pins.
If you have more than 4 pins in the plug please
note the ROBOT-COUPE does not require a neutral
wire.
W ARNING
THIS MACHINE MUST BE EARTHED
(RISK OF ELECTROCUTION)
