N° de série / Serial number
CL 52 D
- 194 - - - - - - -
- 317 - - - - - - -
24
2
3
1
11
10
12
13
14
15
16
4
25
5
26
6
7
8
9
27
28
2930
31
27
40
32
ATTENTION :
appareils dont les 3 premiers
chiffres du N° de série sont :
WARNING :
with the 3 first figures of the
serial number are :
Pour les
For ma ch in es
317194
33
41
12
39
14
42
C
18
19
20
X
M
21
22
23
17
34
35
36
38
37
A
17
C : 03/2004
43
44
Y
B
45
D
REV :
CL52#1
INDEX REF. DESIGNATION Pricelist in USD
1 29694 * (L)Feed Lead Assy 991.20
2 29691 (L)Pusher Bushing 14.10
3 118428 (L)Pusher Assy 418.75
4 29706 (M)Pusher Stop Assy 17.40
5 117321 (M)Pusher Guide Bushing 3.20
6 29705 (M)Magnet Safety Arm 85.30
7 118008 (L)Removable Divider 38.80
8 118427 (L)Feed Lead 374.45
9 29501 (K)Lock for Feed Cover 110.35
10 118420 (Q) Discharge Vane CL60D 27.95
11 29693 (M)Drive Shaft Assy 347.45
12 504219 (K) "O" Ring 42x2, CL50D 0.85
13 39197 Seal Assy 58.60
14 110308 Shaft Pin 5.05
15 118380 (M)Shaft Only 192.90
16 203107 (K)Seal Protector 7.95
17 29630 (K)Bearing Assy, Lower 111.55
18 117689 (K)Motor Support Plate 61.15
19 29532 (M)Motor Pulley-20 Teeth 122.15
20 502768 Motor Shaft Key 4x4x16 (CL50E) 4.75
21 118430 (L)Base Cover 332.05
22 117687 (L)Bottom Cover 94.70
23 500247 Foot (French) 3.20
24 118324 (L)Small Pusher 14.60
25 29692 (M)Cabbage Plate Lock Nut 92.45
26 117200 Washer, Plastic 1.65
27 29058 Hinge Pin Bushing 5.40
28 118436 (M)Lock Nut Wrench 19.05
29 102690 (K)Discharge Plate 24.00
30 29061 Hinge Pin 30.20
31 29451 (K)Magnetic Switch Assy 30.85
32 29628 (M)Upper Housing W/Chute 730.60
33 39200 Upper Housing W/Chute 872.10
34 502170 (K)On Button (Green) 27.30
35 502169 (K)Off Button (Red) 27.85
36 406516 Data Plate, CL52D 31.35
37 117703 (K)Control Board Retaining Pin 1.35
38 29533 (K)Mount Spacer for Control Board 26.70
39 39199 Shaft Kit, CL52D/CL55D 399.40
40 101547 Deflector, CL50D 6.10
41 501678 (M) Seal 24x42x7 16.35
43 515482 Belt 86.65
44 117682 (K)Shaft Pulley,75 Teeth 18.40
45 515515 Strain Relief 8.30
