Robobo base user guide
Instruction icons
Copyright
Robobo base elements
Battery charge
Smartphone insertion in the Robobo base
Switching the Robobo base on and off
Security information
Specific Robobo base warnings
Electrical warnings
Battery warnings
General warnings
Correct disposal of this product
Declaration of Conformity
Manufacturer
Model
4
5
5
5
5
8
9
9
11
11
11
12
12
13
13
13
13
EN
Quick start guide
Robobo base user guide:
This robotic base offers entertainment services under the high standards and
technological experience of Manufactura de Ingenios Tecnol ógicos S.L.
The content may differ from t he final product or software provided by the service
providers, and it is subject to change withou t notice.
The items that come with the robotic base and any available accessories may vary by
region or service provider.
The supplied items are designed only for this robotic base and may not be compatible
with others.
Instruction icons:
Warning: Situations that may cause in jury to you or others.
Caution: Situations t hat may cause damage to the robotic base or other
equipment.
Note: Suggestions for use or additional information.
Copyright:
Copyright© 2018 Manufactura de Ingenios Tecnológicos S.L. This guide is protected by
international copyright laws.
No part of this guide may be reproduced, distributed, transl ated or transmitted in any
form or by any means, electronic or mechanic al, including photocopying, recording or
storage in any information storage and retrieval system, without prior permission
provided by Manufactura de Ingenios Tecnológicos S.L.
Robotic base elements:
The robotic base contai ns the followi ng basic el ements, shown i n the foll owing
images:
• 2 wheel drives
• 1 Pan-Tilt unit, where the Smartphone is a ttached
• 5 frontal leds
• 2 rear leds
• 5 front infrared sensors
• 3 rear infrared sensors
• 1 micro USB connector (type B)
The LEDs are illuminated depending on the base state. Their meaning can be checked
in user-guide.theroboboproject.com
images are for guidance only.
• 1 power button
The im ages may not exactly match the original model of the Robobo base. The
5
Quick start guide
EN
2
4
3
Robotic base elements:
1. Front leds
1
2
6
6
3
5
2. Wheel
3. Led
4. Power button
5. USB connector
6. Pan-Tilt unit
7. Infrared sensors
EN
Quick start guide
7 7 7 77 7 77
7
Battery charge:
EN
Before usin g the robotic base for the first time, or if you ha ve not used it for a long
time, the battery should be charged.
To do this, connect the micro USB connector (type B) to the multifunction plug or
charging port of the robotic base (see figure below), and then connect the USB end
(type A) to an USB current adapter (maximum 2A).
To visualize the charge voltage of the battery it is necessary to connect a
Smartphone to the robotic base and follow the ins tructions shown in
user-guide.theroboboproject.com
If you connect the cable incorrectly, i t could cause serious damage to the b ase.
The warranty does not cover any damage caused by misuse.
After fully charging the robotic base, disconnect it from the power supply. First
disconnect the micro USB cable from the base, and then from the electrical outlet.
8
Quick start guide
Quick start guide
EN
Smartphone insertion in the Robobo base:
To attach the smartphone to the Robobo base holder, you must insert it softly
between the two levers of the holder, separat ing them with your fingers if necessary
(*), and slide it down until i t is fixed in its lower part.
(*) Supported dimensions are between 160x7 8x9.5 mm and 134x67x6.5 mm
approximately depending on the specific s martphone's geometry.
Switching the Robobo base on and off:
To turn the robotic base on, place it on a flat surface free of obstacles. Press the
button located on the back, as shown in t he following image:
Power button
USB connector
9
Quick start guide
EN
During sta rt up, t he robotic base can perform a calibration movement of the pan-tilt
unit, which will rotate around its axis as indicated in the following image. Do not
obstruct or touch the pan-tilt u nit until this movement is completed.
Tilt Axis
Pan Axis
10
Once the pan-tilt calibrat ion movement has been completed, the robotic base will be
ready for use.
Information on how to connect the Smartphone to the base and on how to use both
can be found at user-guide.theroboboproject.com.
Once you have finished using Robobo, remember to turn off the robotic ba se by
pressing the on/off button again. This will increase the duration of both the b attery
and the base itself.
Quick start guide
EN
Security information:
This sec tion contains information on securit y. In order to avoid injury to yourself and
others, or damage to the robotic base, read the safet y information before using this
product.
In case of n ot complying with these safety regulations and warnings, the user could
suffer serious injuries.
Specific Robobo warnings:
Robobo is not indicated for children under 8 years old.
It must be used under the supervision of an adult.
Choking hazard.
This device contains small parts that coul d cause asphyxia in the case of being
ingested by a ch ild. The packaging is not part of the robotic base, do not leave it within
reach of children. Keep it away from children under 3 years old .
The use of the robotic base may not be allowed in public places.
Check that its use is allowed in t he place where it will be used.
It is recommended to use Robobo indoors or in cle an and low exposed outdoor
environments.
Subjecting the robotic base to dust, sand, water, sun or other elem ents present
outdoor can damage it irreversibly.
Do not allow the robotic base to fall or subject it to strong impacts.
The base may be damaged or malfunction.
If it bend s or deforms, th e robotic base may be damaged and its p arts may
malfunction.
The use of the roboti c base to perform movements on a table or on any other raised
surface that lacks protecti ons at its edges at is edges is n ot recommended to prevent it
from falling off. In c ase it is used this way, extreme precautions should be taken so
that the robotic base cannot fall off from any of th e edges of the surface.
Any damage suffered by the Smartphone coupled to the robotic base due to
improper use will not be the responsibility of Manufactura de Ingenios
Tecnológicos S.L.
Avoid, therefore, excessive speeds, shocks and the use in heights or over irregular
surfaces that may cause falls that da mage the Smartphone.
Do not use the robotic base if it is brok en.
Take the base to Manufactura de Ingenios Tecnológicos S.L. service center for its
repair.
If you n otice that the ro botic base emits odd smells or sounds, or if you see smoke
or liqu ids coming out of the robotic base, stop using it immediately and take it to
Manufactura de Ingenios Tecnológicos S.L. service center.
If you do not do it, it could cause a fire or an explosion.
Do not disassemble, modify or repair the robot ic base.
Any change or modi fication to the robotic base m ay void the manufacturer's warranty.
If you need to repair t he robotic base and take it to a Manu factura de Ingenios
Tecnológicos S.L. official service center.
Do not disassemble or puncture the battery, this m ay cause an explosion or fire.
Electrical warnings:
Do not use damaged power cords or con nectors or loose plugs.
Unsafe connections can cause an electric shock or fire.
Do not touch the power co rd with wet hands or pull the cord to disconnect it.
Doing this may cause electrocution.
Do not bend or damage the power co rd.
Doing so could cause an electric shock or fire.
Do not use the robotic base while it is ch arging or touch it with wet hands.
Doing so could cause an electric shock.
11
Quick start guide
EN
Do not short-circuit the ro botic base.
Doing so may cause an electric shock or fire, or the battery may malfunction or
explode.
Do not use the robotic base outdoo rs during a lightning storm.
Doing so may cause an electric shock, or the robotic base may not work properly.
Do not use the r obotic base in a hospital, on an airplane or in a car that could suffer
interference caused by radiofrequency.
If possible, avoid using the robotic base at a distance of less tha n 15 cm from a
pacemaker, as it may interfere with it.
To minimize possible interference with a pacemaker, use the robotic base only on the
opposite side of the body from the position of the p acemaker.
If you use medical equipment, contact the manufacturer of the equipment before
using the robotic base, i n order to d etermine if the equipment will be affected by the
radiofrequency emitted by the robotic base.
If electronic devices are used in an airplane, they can interfere wit h electronic flight
instruments.
Do not keep the robotic base near m agnetic fields.
It may start to malfunction and th e battery may discharge.
Battery warnings:
Use batteries, cables, accessories and supplies approved by the manufacturer.
Use only b atteries approved by Manufa ctura de Ingenios Tecnológicos S.L., specifically
designed for the robotic base. Unsupported batteries and connectors can cause
serious physical injury or damage to the base.
Manufactura de Ingenios Tecnológicos S.L. is not responsib le for the user's safety in
cases where accessories or supplies that are not approved by th e brand are used.
Guarantee maximum battery life.
Avoid charging the base for more than a week, since overcharging can shorten battery
12
life.
Over time, the unused robotic base is discharged and it is necessary t o recharge it for
use.
Disconnect the robotic base from the power sources when not in u se.
Follow all instructions in thi s guide to ensure the longest possible life of the base and
battery. Damage or malfunction c aused by failure to comply with these warnings and
instructions could void the manufa cturer's warranty.
Over time, the robotic b ase can wear out. Some parts and repairs are covered by t he
warranty within the period of validity, however, dama ge or deterioration caused by
the use of non-approved accessories do not have coverage.
Do not handle damaged lithium ion batter ies or leaking batteries.
To safely dispose of the Lithium-ion bat tery contact an authorized service center.
General warnings:
Keep the robotic base dry.
Moisture and liquids can damage elect ronic parts or circuits of the robotic base.
Do not turn on the robotic base if it is wet. If it is already on, turn it off.
Next, dry the robotic base with a soft towel or cloth and t ake it to the service center.
Do not store the robotic base in h ot or cold areas.
It is recommended to use it in temperatu res between 5° C and 35° C
Consider the following informatio n when cleaning the robotic base
Use a towel or a soft, dry cloth to clean the robotic base.
Do not use chemicals or detergents. Doing so m ay cause discoloration or corrosion on
the outside of the robotic base, or it may cause an elec tric shock or fire.
Do not use it for any purpose other than that for which it was designed.
The robotic base may not work correctly.
Quick start guide
EN
http://www.theroboboproject.com/
Correct disposal of this product:
(Waste electrical and electronic equipmen t)
(Applies in countries with separate c ollection systems)
The presence of this symbol on th e product, accessories or accompanying information
material indicates that neither the product nor its electronic accessories (such as the
USB cable) should be disposed together with other household waste.
To avoid possible damage to the environment or hum an health from the uncontrolled
disposal of waste, separate these produc ts from other types of waste and recycle them
correctly. This way, the sustainable reuse of material resources is promoted.
Private u sers can cont act the establishment where they purchased the product or the
relevant local authorities to find out how and where they can take it to be subjected to
an ecological and safe recycling.
Commercial users can contact their supplier and check the conditions of the purchase
contract. T his product and its electronic accessories must not be disposed of together
with other commercial waste.
Declaration of Conformity:
Manufactura de Ingenios Tecnológicos S.L. declares, under its responsibility, that th is
device complies with the p rovisions of Directive 99/05/EC of the E uropean Parliament
and of the Counci l of March 9, 1999, transposed into Spanish legislation by Royal
Decree 1890/2000, of November 20.
Printed in UE
Manufacturer:
Manufactura de Ingenios Tecnológicos S.L.
Edificio Servicios Centrales de Investigación s/n
Campus de Elviña, 15071, A C oruña
mint@mintforpeople.com
Spain
Model:
RBE-X
English. 03/2018. Rev. 1.0
13
14
www.theroboboproject.com
Loading...
