Robinhood STSLIM1 Installation Guide

1

Description: ROBINHOOD SUPERTUB CABINET SLIM
Model Number: STSLIM1

Model pictured: STSLIM1

STSLIM1

Issue: 1

All dimensions in mm
Model may vary slightly from images pictured

2

Overview

Contents of packaging:

1 x Robinhood Supertub (incl waste system, plug)

1 x Installation kit (incl feet)

Pre-installation

Important:

o Please read the entire instructions before installing the laundry tub.

o Ensure the household pipes are thoroughly flushed to remove debris before connecting your laundry tub to

the pipe works. To prevent foreign particles damaging the ceramic cartridge an „in-line‟ filter is
recommended to be installed prior to the mixer.

Regulation compliance

Comply with current Drainage and Plumbing Regulations as required by your local authority. Sanitary
plumbing shall only be carried out by a Registered Plumber. All plumbing work must be done in accordance
with local and national building and plumbing codes as applicable. All electrical work must be done in
accordance with local and national electrical codes as applicable. In some instances this product m ay need to
be earthed.

Determine site

Determine the most suitable position for the laundry tub. It may be used either to the left or right of the
washing machine. Allow 10mm clearance between the units. Mark the position on the floor as reference.

Important safety information

o This Robinhood Supertub is not intended for use by young children or infirm persons without supervision.

o Young children should be supervised to ensure that they do not play with the Robinhood Supertub.

o DO NOT use abrasive household cleaner.

3

Installing the Supertub

Confirm if the door or washing machine waste inlet needs to be moved from right to left before securing the
unit to the wall. If they do need to be changed see page 6 of these installation instructions.

1. Fit the four adjustable feet supplied to the

bottom of the cabinet and adjust to align with
worktop or washing machine height. Use the
lock nut to secure the feet into position. Tilt
laundry tub slightly to assist with access. Check
the top of the laundry tub with a spirit level to
ensure that it is level and check that the cabinet

does not “rock” confirm that the door operates

correctly.

Locknut Bottom of the unit

2. Line up the laundry tub to the installation and confirm enough room, if necessary remove the skirting

board at the require distance 560 mm this will allow the unit to sit flush against the wall. (Check with
your local council for building regulations). Remove the laundry tub away from the wall.

3. Fit the waste adapter from the installation kit this

must be glued in place, allow plenty of time for
the glue to dry before proceeding.

4. Position the laundry tub and cut the house waste pipe (which should already be installed) to the exact

height. The final height will depend on the waste trap dimensions.

5. Fasten the laundry tub to the wall through any of the holes in the rear flanges. Alternative fastening can

be achieved through the floor. Confirm that the door operates correctly.

6. Connect the hot and cold from the tap ware to the 3 way ball valves, connect the waste system and the

trap to the laundry tub.

7. Test the laundry tub for leaks. Check the washing machine and the waste system.

8. Seal the laundry tub to the wall using suitable approved sealant. (Check with your local council for

building regulations).

Installing the washing machine waste outlet

Confirm if the door or washing machine waste inlet needs to be moved from right to left before securing the
unit to the wall. If they do need to be changed see page 6 of these installation instructions.

1. Washing machine waste hose connection through the white plastic washing machine waste inlet and make

sure that the hose is as far down the hose as possible and then to prevent the washing machine waste
hose from coming loose use the cable tie from the installation kit to fasten the hose firmly to the white
plastic washing machine waste connector. (see next page for picture)

Important:

Ensure the washing machine outlet hose is correctly fitted at both ends and that the spring clips are firmly in
place to prevent leaks.

Apply plumbing PVC glue

Waste adapter
