Simply the Right Choice

™

Thermostat Catalog

Innovative designs that set the standard for simplicity and performance

Page 2

Simply the Right Choice

Robertshaw makes it easy.

™

Value SeriesDeluxe Series

Page 3

Economy Series

Robertshaw® thermostats are designed for both simplicity and performance. Now you can easily choose the perfect product for any heating and cooling application.

No matter what series you choose, Robertshaw products will make your customer’s home or business more comfortable, more efﬁcient, and more attractive.

Here’s why Robertshaw thermostats are the right choice for both you and your customers:

• Thermostats with more features at more attractive prices

• Universal controls that work with multiple systems to reduce

your inventory and make selection simple

• Programmable thermostats with humidity and fresh air controls

• Robertshaw products are Energy Star® compliant to reduce

heating and cooling costs

• A full range of products to satisfy any application…easy to

select, order, install, and program!

As you review these products, please contact us at 1-800-304-6563 with your ideas, suggestions, and questions. Our designs are a product of your feedback, and your input is valued as we continue to bring new innovations to the market.

Page 4

Simply the Right Choice

i2 Series Deluxe

Programmable Thermostats

™

Get the competitive edge with Robertshaw

thermostats. Our patent pending Set-up Wizard could reduce your installation time by up to 50% over competitive models. Program your contact information with a service schedule to remind your customers to call you. Of course, everything is easy to program with no complicated codes or button combinations to memorize. Robertshaw – Simply the Right Choice™.

All i2 Series Programmable Thermostats Feature:

Set-Up Wizard• 7-Day, 5-2, 5-1-1 or 24 Hour Programming• 2, 4, 6 Events Per Day• Programmable Service Reminders• Trilingual Display Options (not on Fresh air models)•

Indoor/Outdoor Remote Sensor Capability• Adjustable Temperature Differential• Adjustable Timed Upstaging• Energy Star• California Title 24 Compliant•

Worry-free Memory Storage •

9800i2 Series with Humidity Control

Have These Additional Features:

Adjustable Humidiﬁcation and Dehumidiﬁcation Set • Points Automatic Humidiﬁcation Control (When coupled with • the remote outdoor sensor)

9900i Series with Fresh Air Control

Have These Additional Features:

Bilingual Display Option• Adjustable Damper Control for Occupied and • Unoccupied Settings

Customizable Purge Control• Adjustable Overcooling Limits• Customizable Dew Point Control•

GAS

ELECTRIC

Rated

OIL

HEAT PUMP

7-Day

Control

Humidity

Control

Fresh Air

Robertshaw Part Number

9701i2

9725i2

9801i2

9825i2

9901i

9915i

9920i

Canadian Part Number

C9701i2 Heat/Cool/Heat Pump 1/1 Hardwired C, G, Y1, B, W1, O, R, IS, OS

C9725i2 Heat/Cool/Heat Pump 3/2 Hardwired C, G, Y1, B, E/W1, O, R, W2, Y2, L, IS, OS

C9801i2 Heat/Cool/Heat Pump 1/1 Hardwired C, G, Y1, B, W1, O, R, H, D, IS, OS

C9825i2 Heat/Cool/Heat Pump 3/2 Hardwired C, G, Y1, B, E/W1, O, R, W2, Y2, L, H, D, IS, OS

NA Heat/Cool/Heat Pump 1/1 Hardwired C, G, Y1, B, W1, O, R, IS, OS, Aux1, Aux2

NA Multi-Stage Excluding Heat Pump 2/2 Hardwired C, G, Y1, B, E/W1, O, R, W2, Y2, IS, OS, Aux1, Aux2

NA Heat Pump 2/2 Hardwired C, G, Y1, B, E/W1, O, R, W2, Y2, IS, OS, Aux1, Aux2

System Application Stages, Heat/

Cool

Power Method Terminal Designations

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number

9701i2 1F90-51, 1F90-71, 1F90-371, 1F95-

9725i2 1F92-71, 1F93-380, 1F94-71, 1F95-377 TH8320U1006 5300 TX9100E,

9801i2 1F95-1271, 1F97-391 TH8110 NA PSPA711 P274-1100, P374-1100, P474-1100,TP-PRH, TP-PAC, TP-PHP

9825i2 1F95-391, 1F95-1277, 1F95-1291,

9901i NA T7300D NA NA P374-2300, 33CS071-01

9915i NA T7300F NA NA P374-2300, 33CS071-01

9920i NA T7300F NA NA P374-2300, 33CS071-01

White-Rodgers Honeywell Braeburn Lux Carrier

1271, 1F97-51, 1F97-71, 1F97-371

1F97-391

TH8110U1003 5000 PSPA711 P274-1100, P374-1100, P474-1100, TC-PAC, TC-PHP

PSPA722

TH8321 5400 TX1500E,

PSPA732

P274-1300, P274-2100, P374-1000, P374-1100, P474-1050, TC-PAC, TC-PHP

P274-1300, P274-2100, P374-1000, P374-1100, P474-1050, TP-PRH, TP-PAC, TP-PHP

www.RobertshawTstats.com

Page 5

Value Series

Programmable Thermostats

Simply the Right Choice

™

GASEELECTRICOOILHHEAT PUMPMMILLIVOLT

The Robertshaw models. You’ll be thankful for fewer SKUs, enhanced features and value pricing. When powered-up, the thermostat initiates the Pop-up Wizard to walk the installer through the set-up in simple language. Five models cover a wide range of applications that are fully compatible with gas and electric furnaces, and heat pumps. Each model can be powered with either two AA batteries or 24 V AC Common. Robertshaw – Simply the Right Choice™.

Features:

Pop-up Wizard• Auto Changeover• Bigger, Brighter Backlight with Nightlight Option• Easy Change Battery Access• Circulating Fan •

Value Series Programmable Thermostats offer 7 Day and 5-2 Day

Low Temperature Freeze Protection• Adjustable Temperature Differential and Upstaging• Energy Star• California Title 24 Compliant•

Rated

RS6000 Series 7 Day

Have These Additional Features:

Universal Control Available on RS6220 and RS6320• Copy Command for Easy Programming•

Robertshaw Part Number

RS5110

RS5220

5-2 Day

RS6110

RS6220

7 Day

RS6320

Canadian Part Number

NA Heat/Cool/Heat Pump 1/1 Hardwired with

RS5220C Heat/Cool/Heat Pump 2/2 C, G, B, Y1, Y2, W1, W2, O, RH/R, RC, E, L

NA Heat/Cool/Heat Pump 1/1 C, G, B, Y1, W1, O, RH/R, RC

NA Heat/Cool/Heat Pump 2/2 C, G, B, Y1, Y2, W1, W2, O, RH/R, RC, E, L

RS6320C Heat/Cool/Heat Pump 3/2 C, G, B, Y1, Y2, W1, W2, O, RH/R, RC, E, L

System Application Stages,

Heat/Cool

RS5000 Series 5-2 Day

Have These Additional Features:

Universal Control Available on RS5220• Vacation Setpoint •

Power Method Terminal Designations

C, G, B, Y1, W1, O, RH/R, RC battery back-up or battery operated

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number White-Rodgers Honeywell Braeburn Lux Robertshaw

RS5110 1F78-151, 1F78H-151,

1F80-0471

RS5220 1F85-0471 TH2210D, T8001, T8024,

RS6110 1F80-0471, 1F97-1271,

1F80-361, 1F80-241, 1F87-361, 1F78-167

RS6220 1F85-0471, 1F85-277,

1F85-278

RS6320 1F85-0471, 1F95-1271 TH6320D 5400 NA NA

T8002, T8112, T8132, TH2110D, TH4110D

TH4210D

TH6110D 5000, 5050 NA 9600, 9610

TH6220D 5200, 5300 PSPA722E, TX9100E 9615, 9620

5000, 5050 TX500E 9600, 9610

5100, 5200 HP2110, PSPA722E 9615, 9620

www.RobertshawTstats.com

Page 6

Programmable Thermostats

Simply the Right Choice

™

GASEELECTRICOOILHHEAT PUMPMMILLIVOLT

The Robertshaw programmable thermostat. All models are fully compatible with all standard 24V AC heating and cooling systems. With the comfort, convenience and efﬁciency features that contractors and homeowners want, our Economy Series is a perfect cost effective solution. Robertshaw – Simply the Right Choice™.

Features:

Bigger, Brighter Backlight • Adjustable Temperature Differential• Filter Monitor• O and B Terminals• Automatic Compressor Short Cycle Protection• Zone System Compatible •

Economy Series provides affordable temperature control in a

Quick Wire Terminal Block • Multi-Stage 2 Heat/1 Cool on RS3210 only• Worry-Free Memory Retention on RS3210 only• Low Temperature Freeze Protection on RS3110 only• Energy Star• California Title 24 Compliant•

Economy Series

RS3110 only

Rated

Robertshaw Part Number

RS3110

RS3210

5-2 Day

Canadian Part Number

RS3110C Heat/Cool 1/1 Battery

RS3210C Heat/Cool/Heat Pump 2/1 Hardwired

System Application Stages, Heat/Cool Power Method Terminal Designations

operated

with battery back-up

G, RC, RH, Y/O, W/B, Y1

O, B, Y1, G, W2, W/W1, C, L, R

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number White-Rodgers Honeywell Braeburn Lux Robertshaw

RS3110 1F78-151 TH2110D 2000, 2010, 2000NC TX500, TX500E 8600, 8601

RS3210 1F72-151 TH2210D, TH4210D,

T8001C, T8001F, T8011F

2100, 2110, 2200 HP2110 8625

www.RobertshawTstats.com

Page 7

300 Series

Programmable Thermostats

™

The Robertshaw

Simply the Right Choice

300 Series Programmable Thermostats offer a contemporary design with a large, easy to read LCD display. The 300 Series has features that users need like a lockable key pad and door that offer security against unwanted tampering. Select models have O and B terminals for use with heat pumps or controlling dampers and fresh air economizers. Also remote sensor capable allows for connecting to remote indoor and outdoor sensors for added indoor comfort. The compressor short cycle protection reduces wear and tear to HVAC equipment with this system safeguard. Robertshaw – Simply the Right Choice

™

Features:

3-hour Override Allows Temporary Adjustment of Temperature• Automatic Compressor Short Cycle Protection• O and B Terminals on Select Models• Remote Sensor Capable•

Robertshaw Part Number

300-224

System Application Stages, Heat/

Cool

Heat/Cool 1/1 Hardwired RH, W, RC, Y, G, RS2, RS1, RS+Vz

Power Method Terminal Designations

GASEELECTRICHHEAT PUMP

7 Day

300-225

300-226

300-227

300-229

300-230

Heat/Cool 1/1 Hardwired W1, Y1, G, R, 24V, 24V(C), RS1, RS2, RS+V

Heat/Cool/Heat Pump, Auto Changeover

Heat/Cool 2/2 Hardwired W2, Y2, W1, Y1, G, R, 24V, 24V(C), O, B, LED1, LED2, RS1, RS2, RS+V, NO, COM, NC

Cool 1 Hardwired RC, Y, G

2/1 Hardwired W1, Y1, G, R, 24V, 24V(C), LED1, LED2, RS1, RS2, RS+V, O, B

3/2 or 2/1 Heat Pump

Hardwired W2, Y2, W1, Y1, G, R, 24V, 24V(C), O, B, LED1, LED2, RS1, RS2, RS+V, NO, COM, NC

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number White-Rodgers Honeywell Braeburn

300-224 1F90 NA NA

300-225 1F97 T7200D NA

300-226 NA NA NA

300-227 1F91, 1F92, 1F94, 1F97 T7300D2002, T7300F2010 NA

300-229 1F97 T7300D2007 5300

300-230 NA NA NA

www.RobertshawTstats.com

Page 8

Value Series

Non-Programmable

Simply the Right Choice

™

GASEELECTRICOOILHHEAT PUMPMMILLIVOLT

Thermostats

The Robertshaw Choice™ when it comes to automatic temperature control. You’ll be thankful for fewer SKUs, enhanced features and value pricing. When powered-up, the thermostat initiates the Pop-up Wizard to walk the installer through the set-up in simple language. Three models cover a wide range of applications that are fully compatible with gas and electric furnaces, and heat pumps. Each model can be powered with either two AA batteries or 24 V AC Common. Robertshaw – Simply the Right Choice.

Features:

Pop-up Wizard• Auto Changeover• Bigger, Brighter Backlight with Nightlight Option• Easy Change Battery Access •

RS4220 and RS4320 Thermostats

Have This Additional Feature:

Universal Control with Compatibility to Multi-stage Gas/• Electric Furnaces and Heat Pumps

Value Series Non-Programmable Thermostats are Simply the Right

Circulating Fan• Low Temperature Freeze Protection• Adjustable Temperature Differential and Upstaging•

Robertshaw Part Number

RS4110

RS4220

Non-Programmable

RS4320

Canadian Part Number

NA Heat/Cool/Heat Pump 1/1 Hardwired with

RS4220C Heat/Cool/Heat Pump 2/2 Hardwired with

RS4320C Heat/Cool/Heat Pump 3/2 Hardwired with

System Application Stages,

Heat/Cool

Power Method Terminal Designations

battery back-up or battery operated

C, G, B, Y1, W1, O, RH/R, RC

C, G, B, Y1, Y2, W1, W2, O, RH/R, RC, E, L

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number White-Rodgers Honeywell Braeburn Lux Robertshaw

RS4110 1F86-0471, 1F86-344,

1F86-241, 1F78-144, 1F78H-144

RS4220 1F73-174, 1F83-0471,

1F83-277

RS4320 1F83-0471 TH5320D 3300 NA NA

T8775C, T8401C, TH1110D, TH3110D, TH5110D

TH1210D, TH3210D, TH5220D, TH8411R

1005, 3000 DMH110, PDS111 9400, 9401

1200, 3100, 3200 DHP2120, PSDH121 9415, 9420

www.RobertshawTstats.com

Page 9

Economy Series

Non-Programmable

Simply the Right Choice

™

GASEELECTRICOOILHHEAT PUMPMMILLIVOLT

The Robertshaw fully compatible with all standard 24V AC heating and cooling systems. With the comfort, convenience and efﬁciency features that contractors and homeowners want, our Economy Series is a perfect cost effective solution. Robertshaw – Simply the Right Choice™.

Features:

Bigger, Brighter Backlight • Adjustable Temperature Differential• Filter Monitor• Automatic Compressor Short Cycle Protection• O and B Terminals •

Robertshaw Part Number

RS2110

Economy Series Non-Programmable Thermostat models are

Zone System Compatible• Quick Wire Terminal Block• Multi-Stage 2 Heat/1 Cool on RS2210 Only• Worry-Free Memory Retention on RS2210 Only• Low Temperature Freeze Protection on RS2110 Only•

Canadian Part Number

RS2110C Heat/Cool/Heat Pump 1/1 Battery operated R, G, W, Y, RH/B, RC/O

System Application Stages,

Heat/Cool

Power Method Terminal Designations

Thermostats

RS2110 only

RS2210

Non-Programmable

RS2210C Heat/Cool 2/1 Hardwired with

battery back-up

O, B, Y1, G, W2, E/W1, C, L, R

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number White-Rodgers Honeywell Braeburn Lux Robertshaw

RS2110 1F78-144, 1F86-344 TH1110D, TH8775C 1000, 1000NC, 1000TL,

RS2210 1F72-174 T8411R, TH1210D,

TH3210D

1005NC, 1010

1100, 1200NC, 1210 DMP2110 8425

DMH110 8400, 8401

www.RobertshawTstats.com

Page 10

300 Series

Non-Programmable

Simply the Right Choice

™

GASEELECTRICHHEAT PUMP

The Robertshaw® 300 Series Non-Programmable Thermostats offer a contemporary design with a large, easy to read LCD display. The 300 Series has features that users need like a lockable key pad and door that offer security against unwanted tampering. Select models have O and B terminals for use with heat pumps or controlling dampers and fresh air economizers. Also remote sensor capable allows for connecting to remote indoor and outdoor sensors for added indoor comfort. The compressor short cycle protection

Thermostats

reduces wear and tear to HVAC equipment with this system safeguard. Robertshaw – Simply the Right Choice

Features:

Occupied and Unoccupied Mode Allows for • Different Setting for Day and Night Automatic Compressor Short Cycle • Protection O and B Terminals on Select Models• Remote Sensor Capable•

™

300-201

300-202

300-203

300-204

300-205

300-206

300-207

300-208

Robertshaw Part Number

300-201

300-202

300-203

300-204

300-205

300-206

Non-Programmable

300-207

300-208

System Application Stages,

Heat/Cool

Heat/Cool, Auto Changeover 1/1 Hardwired W1, Y1, G, R, 24V, 24V(C),CLK1, CLK2, RS2, RS1, RS+V

Heat/Cool/Heat Pump, Auto Changeover 3/2 or 2/1 Hardwired Y2, W1, Y1, G, R, 24V, 24V(C), O, B, LED1, LED2, CLK1, CLK2, RS2, RS1, RS+V

Heat/Cool, Auto Changeover 2/2 Hardwired Y2, W1, Y1, G, R, 24V, 24V(C), W2, LED1, LED2, CLK1, CLK2, RS2, RS1, RS+V

Heat Only 1 Hardwired RH, W

Cool Only 1 Hardwired RC, Y, G, CLK1, RS2, RS1, RS+V

Heat/Cool 1/1 Hardwired RH, W, RC, Y, G, CLK1, CLK2, RS2, RS1, RS+V

Heat/Cool/Heat Pump, Auto Changeover 1/1 Hardwired Y1, G, R, 24V, 24V(C), O, B, RS2, RS1, RS+V, CLK1, CLK2

Heat/Cool/Heat Pump, Auto Changeover 2/1 Hardwired W1, Y1, G, R, 24V, 24V(C), O, B, LED1, LED2, CLK1, CLK2, RS2, RS1, RS+V

Power Method

Terminal Designations

Cross Reference (Verify speciﬁc application requirements before substitution.)

Robertshaw Part Number Honeywell

300-201 T7100D

300-202 T7100E, T7100F

300-203 T7100D, T7100F

300-204 NA

300-205 NA

300-206 NA

300-207 NA

300-208 T7100E, T7100F

www.RobertshawTstats.com

Page 11

Simply the Right Choice

9020i and 9025i Features:

Designed to Sense Air Temperature at a Remote Location up • to 300 Feet from Thermostat Automatic Conﬁguration with i2 and i Series Thermostats• Installs with a Simple Twisted Pair Wiring• Temperature Range for Outdoor Sensor 9025i is -40°F to 158°F • (-40° to 70°C)

10-528 and 10-529 Features:

Designed to Sense Air Temperature at a Remote Location and • Send this Information to the Thermostat Can be Interconnected with Up to Six Indoor Sensors for • Temperature Averaging

Remote Indoor and

Outdoor Sensors

™

Robertshaw Part Number Canadian Part Number Description For Use With

9020i C9020i

9025i C9025i

Robertshaw Part Number Description For Use With

10-528

10-529

Indoor Sensor 300 Series

Outdoor Sensor 300 Series

Indoor Sensor i Series and i2 Series Thermostats

Outdoor Sensor i Series and i2 Series Thermostats

www.RobertshawTstats.com

Page 12

Simply the Right Choice

™

Providing Value Beyond Thermostats

Dedicated Customer Service

Phone 1.800.304.6563 Facsimile 1.800.426.0804 Email [email protected]

Knowledgeable Technical Service

Phone 1.800.445.8299 Facsimile 1.630.260.7294 Email [email protected]

Customer Toolbox for 24/7 Real Time Information and Support

This user name and password protected site enables you access to track order status, accounts receivable, pricing, invoicing, sales tools, online literature orders, training resources and much more.

http://toolbox.InvensysControls.com

Enhanced Websites and Tools

Visit the sites below for complete Robertshaw® and Uni-Line® product information as well as a continuously updated cross reference tool.

www.RobertshawTstats.com www.Uni-Line.com www.InvensysControls.com

191 E. North Avenue Carol Stream Illinois 60188 USA Customer Service Telephone 1.800.304.6563 Customer Service Facsimile 1.800.426.0804 [email protected]

For Technical Service Telephone 1.800.445.8299 Facsimile 1.630.260.7294 [email protected]

Invensys

, Robertshaw®, Simply the Right Choice™ and Uni-Line® are trademarks of Invensys plc., its subsidiaries and/or affiliated companies. All other brands mentioned in this report may be the trademarks of their respective owners.

8/09 – 150-2206

Page 13

Thermostat

Simply the Right Choice

Value Series

™

Quick Reference Chart

Economy Series

Deluxe Series

Page 14

Model Program Application Staging Power Functions and Features Terminations

RS2110

RS2210

RS3110

RS3210

RS4110*

RS4220

RS4320*

RS5110*

RS5220

RS6110*

RS6220*

RS6320*

9701i2

9725i2

9801i2

9825i2

9901i

9915i

9920i

300-224

300-226

300-230

300-225

300-227

Non-

Programmable

Non-

Programmable

5-2 Day

Non-

Programmable

Non-

Programmable

Non-

Programmable

5-2 Day

7 Day

PLUS

7 Day

PLUS

7 Day

PLUS

7 Day

PLUS

7 Day

PLUS

7 Day

PLUS

7 Day

PLUS

7 Day

5-2 Day

7 Day

Electric Gas Oil

Heat

Pump

8 8 8 8 8

8 8 8 8

8 8 8 8 8

8 8 8 8

8 8 8 8 8

8 8 8 8

8 8 8 8 8

8 8 8 8

8 8 8 8 8

8 8 8 8

8 8 8 8 8

8 8 8 8

8 8 8

8 8

8 8 8

Millivolt Heat Cool

1 1 battery

2 1

1 1 battery

2 1

1 1

2 2

3 2

1 1

2 2

1 1

2 2

3 2

1 1 24V AC

3 2 24V AC

1 1 24V AC

3 2 24V AC

1 1 24V AC

2 2 24V AC

1 1

2 1 24V AC

1 1 24V AC

3 2 24V AC

24V AC

with battery

back-up

24V AC

with battery

back-up

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

24V AC

or battery

operated

power

stealing

power

stealing

Auto

Changeover

Memory Reserve

Adjustable Differential

8 8 8

EEPROM

8 8 8

8 8 8 8 8

EEPROM

8 8 8 8 8

8 8 8 8 8 8 8

8 8 8 8 8 8 8 8

8 8 8 8 8 8

8 8 8 8 8 8 8

EEPROM ﬁxed

Energy

Efﬁcient

Recovery

selectable

Back

Lighting

300-229

300-204

300-205

300-206

300-207

300-201

300-202

300-203

300-208

Currently not available in Canada.

7 Day

Non-

Programmable

Non-

Programmable

Non-

Programmable

Non-

Programmable

Non-

Programmable

Non-

Programmable

Non-

Programmable

Non-

Programmable

8 8

8 8 8 8

8 8

Programming options of 5-1-1, 5-2, 7 Day, 24 Hours, Individual or Manual

2 2 24V AC

1 1

power

stealing

power

stealing

power

stealing

1 1 24V AC

3 2 24V AC

2 2 24V AC

2 1 24V AC

EEPROM ﬁxed

EEPROM ﬁxed Rh, W

EEPROM ﬁxed 6 indoor/1 outdoor 10-528 10-529 Rc, Y, G, CLK1, CLK2, RS2, RS1, RS+V

EEPROM ﬁxed 6 indoor/1 outdoor 10-528 10-529 Rh, Rc, W, Y, G, CLK1, CLK2, RS2, RS1, RS+V

EEPROM ﬁxed 6 indoor/1 outdoor 10-528 10-529 Y1, G, R, 24V, 24V (c), O, B, CLK1, CLK2, RS+V, RS1, RS2

EEPROM ﬁxed 6 indoor/1 outdoor 10-528 10-529

Page 15

Remote

Sensors

Indoor Sensor

Outdoor

Sensor

Programmable

Fan

Energy

Star

Keypad

Lockout

Filter

Monitor

Vacation

Hold

Special

Features

R, G, W, Y, RC/O, RH/B

C, L, R, Y1, E/W1, W2, G, O, B

G, RC, RH, Y/O, W/B, Y1

O, B, Y1, G, W2, E/W1, C, L, R

RH/R, RC, C, G, B, O, Y1, W1

RH/R, W2, Y1, Y2, C, L, RC, G, E, O, B, W1

RH/R, RC, C, G, B, O, Y1, W1

RH/R, RC, C, G, B, O, Y1, W1, Y2, W2, E, L

RH/R, RC, C, G, B, O, Y1, W1

RH/R, RC, C, G, B, O, Y1, W1, Y2, W2, E, L

1 indoor/1 outdoor 9020i 9025i

6 indoor/1 outdoor 10-528 10-529

8 8 8 8 8

8 8

8 8 8

RH/R, RC, C, G, B, O, Y1, W1, Y2, W2, E, L

W1, Y1, C, R, G, O, B, IS, OS

R, W2, Y1, Y2, B, O, G, C, L, E/W1, IS, OS

Humidiﬁcation

Dehumidiﬁcation

Humidiﬁcation

Dehumidiﬁcation

E/W1, Y1, C, R, G, H, D, O, B, L, IS, OS

R, W2, Y1, Y2, H, D, B, O, G, C, L, E/W1, IS, OS

Fresh Air Control W1, Y1, C, R, G, O, B, 1, 2, IS, OS

Fresh Air Control E/W1, W2, Y1, Y2, C, R, G, O, B, 1, 2, IS, OS

Fresh Air Control R, W2, Y1, Y2, 1, 2, B, O, G, C, L, E/W1, IS, OS

W, Y, G, Rh, Rc, RS+V, RS1, RS2

W1, Y1, G, R, 24V, 24V (c), O, B, LED1, LED2, RS+V, RS1, RS2

Y, G, Rc, RS+V, RS1, RS2

W1, Y1, G, R, 24V, 24V (c), RS+V, RS1, RS2

W1, W2, Y1, Y2, G, R, 24V, 24V (c), O, B, LED1, LED2, COM, NO, NC, RS+V, RS1, RS2

W1, Y1, G, R, 24V, 24V (c), CLK1, CLK2, RS+V, RS1, RS2

W1, Y1, Y2, G, R, 24V, 24V (c), O, B, LED1, LED2, CLK1, CLK2, RS+V, RS1, RS2

W1, W2, Y1, Y2, G, R, 24V, 24V (c), LED1, LED2, CLK1, CLK2, RS+V, RS1, RS2

W1, Y1, G, R, 24V, 24V (c), O, B, LED1, LED2, CLK1, CLK2, RS+V, RS1, RS2

Page 16

Deluxe Series

Programmable Thermostats

9701i2 – 1 Heat / 1 Cool – Fully Programmable 9725i2 – 3 Heat / 2 Cool – Universal Staging

Programmable Thermostats With Humidity Control

9801i2 – 1 Heat / 1 Cool – Fully Programmable 9825i2 – 3 Heat / 2 Cool – Universal Staging

Set-up Wizard Menu Driven Display Humidify / Dehumidify Control (9801i2 and 9825i2 only) Brighter Adjustable Backlight Nightlight Option Auto Changeover Automatic Daylight Saving Time 24 VAC with Worry-Free Memory Storage English, Spanish or French Display Option

Value Series

Economy Series

Non-Programmable Thermostats

RS4110 – 1 Heat / 1 Cool RS4220 – Universal Control up to 2 Heat / 2 Cool RS4320 – Universal Control up to 3 Heat / 2 Cool

Auto Changeover Pop-Up Wizard Bigger Brighter Backlight with Nightlight Option Worry-Free Memory Retention Easy Battery Access

Programmable Thermostats

5-2 Day Programmable RS5110 – 1 Heat / 1 Cool RS5220 – Universal Control up to 2 Heat / 2 Cool

7 Day Programmable RS6110 – 1 Heat / 1 Cool RS6220 – Universal Control up to 2 Heat / 2 Cool RS6320 – Universal Control up to 3 Heat / 2 Cool

Auto Changeover Pop-Up Wizard Bigger Brighter Backlight with Nightlight Option Worry-Free Memory Retention Easy Battery Access

Non-Programmable Thermostats

RS2110 – 1 Heat / 1 Cool RS2210 – Multi-Stage 2 Heat / 1 Cool

Bigger Brighter Backlight Adjustable Temperature Differential Worry-Free Memory Retention (RS2210 only) Filter Monitor Low Temperature Freeze Protection (RS2110 only)

Programmable Thermostats

5 – 2 Day Programmable RS3110 – 1 Heat / 1 Cool RS3210 – Multi-Stage 2 Heat / 1 Cool

Bigger Brighter Backlight Adjustable Temperature Differential Worry-Free Memory Retention (RS3210 only) Filter Monitor Low Temperature Freeze Protection (RS3110 only)

191 E. North Avenue Carol Stream, IL 60188 USA 1.800.304.6563 www.InvensysControls.com

Invensys®, Simply the Right Choice™, and Robertshaw® are trademarks of Invensys plc., its subsidiaries and/or afﬁliated companies. All other brands mentioned in this chart may be the trademarks of their respective owners. ©2009 Invensys Controls. All rights reserved.

www.RobertshawTstats.com

Thermostat Overview 150-2122E
