Robe 1200 Color Spot, 1200E Color Spot, 1200 AT, 1200E AT, Color Spot 1200 AT User Manual

Color

Spot

1200

AT

Color

Spot

1200

AT

USER MANUAL

Version: 5.7

ROBE® Show Lighting s.r.o. Czech Republic www.robe.cz

3

Table of contents

1. Unpacking 4

2. Safety instructions 4

3. Operating determinations 5

4. Description of the xture 6

5. Installation 8

5.1 Connection to the mains 8

5.2 Changing the power supply settings 8

5.3 Fitting the lamp 9

5.4 Lamp adjustment 10

5.5 Inserting/Exchanging gobos, colours and effects 10

5.6 Rigging the xture 11

5.7 DMX-512 connection/connection between xtures 13

5.8 Ethernet connection 13

6. DMX protocol 15

7. Controller mode 21

7.1 DMX addressing 21

7.2 Remotely controllable functions 21

8. Control menu map 22

9. Control menu 25

9.1 Fixture Address 25

9.2 Fixture informations 25

9.3 Personality 27

9.4 Lamp On/Off 30

9.5 Test sequences 30

9.6 Manual mode 30

9.7 Stand-alone setting 30

9.8 Reset functions 31

9.9 Special functions 31

10. Low power mode 32

11. Error and information messages 32

12. Technical specications 33

13. Maintenance and cleaning 37

Color

Spot

1200

AT

Color

Spot

1200

AT

4

5

1. Unpacking

The ColorSpot 1200 AT (ColorSpot 1200E AT) cardboard box included items:

- Colorspot 1200 AT(magetic ballast) or Colorspot 1200E AT (electronic ballast)

- User manual (1piece)

- Small paper box with:

- Gobo-set 10 (1 piece)

- Mounting bracket Omega CL assembled (2 pieces)

The small paper box is situated in the top part of the cardboard box.

CAUTION! Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!

2. Safety instructions

Every person involved with installation and maintenance of this device have to:

- be qualiled

- follow the instructions of this manual

CAUTION! Be careful with your operations.
With a high voltage you can suffer a dangerous electric shock
when touching the wires!

This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe op­eration, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this manual.

Important:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any
unauthorized modication to the device.

Please consider that damages caused by manual modications to the device are not subject to warranty.

Never let the power-cord come into contact with other cables! Handle the power-cord and all connections with the mains
with particular caution!

Make sure that the available voltage is not higher than stated on the rear panel.

Always plug in the power plug least. Make sure that the power-switch is set to off-position before you connect the device
to the mains. The power-plug has to be accessable after installing the device.

Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and the power-cord from
time to time.

Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power-cord by the
plug. Never pull out the plug by tugging the power-cord.

This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to earth.

5

The electric connection, repairs and servicing must be carried out by a qualied employee.
Do not connect this device to a dimmer pack.

Do not switch the xture on and off in short intervals as this would reduce the lamp’s life.

During the initial start-up some smoke or smell may arise. This is a normal process and does not necessarily mean that
the device is defective.

Do not touch the device’s housing bare hands during its operation (housing becomes hot)!
For replacement use lamps and fuses of same type and rating only.

CAUTION ! Avoid looking directly into the light source
EYEDAMAGES ! (meant especially for epileptics) !

3. Operating determinations

This device is a moving-head spot for creating decorative effects and was designed for indoor use only.

If the device has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on immedi­ately. The arising condensation water might damage your device. Leave the device switched off until it has reached room
temperature.

Never run the device without lamp!

Do not shake the device. Avoid brute force when installing or operating the device.

Never lift the xture by holding it at the projector-head, as the mechanics may be damaged. Always hold the xture at the
transport handles.

When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture or dust.
There should not be any cables lying around. You endanger your own and the safety of others!

The minimum distance between light-output and the illuminated surface must be more than 2.5 meters.

Make sure that the area below the installation place is blocked Always x the xture with an appropriate safety-rope. Fix
the safety-rope at the correct holes only.

Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fastened.

The lamp must never be ignited if the objective-lens or any housing-cover is open, as discharge lamps may explose and
emit a high ultraviolet radiation, which may cause burns.

The maximum ambient temperature 40° C must never be exceeded. Otherwise, the lamp is switched off and the xture
is out of operation for 5 minutes.

CAUTION! The lens has to be replaced when it is obviously damaged,

so that its function is impaired, e. g. due to cracks or deep scratches!

Operate the device only after having familiarized with its functions. Do not permit operation by persons not qualied for
operating the device. Most damages are the result of unprofessional operation!

CAUTION! The lamp has to be replaced when it is damaged or deformed
due to the heat!

Please use the original packaging if the device is to be transported.

Please consider that unauthorized modications on the device are forbidden due to safety reasons!

If this device will be operated in any way different to the one described in this manual, the product may suffer damages
and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-circuit, burns, electric
shock, burns due to ultraviolet radiation, lamp explosion, crash etc.

CAUTION! The head and yoke must be unlocked before operation!
Check the pan/tilt locks!

6

7

4. Description of the xture

The head can be locked for transportation- the tilt lock button (4) is pushed and the pan lock/unlock lever (6) is in lock
position. To unlock the head, press the tilt unlock button (5) and move the pan lock/unlock lever (6) to unlock position.

1 - Yoke
2 - Front panel
3 - Moving head
4 - Tilt lock button (red)
5 - Tilt unlock button (green)
6 - Pan lock/unlock lever
7 - Handle
8 - Base

Rear panel of the base
1 - Neutral fuse holder
2 - Live fuse holder
3 - Power cord
4 - Power switch
5 - 5-pin DMX output
6 - 5-pin DMX input
7 - 3-pin DMX output
8 - 3-pin DMX input
9 - Ethernet input

Front panel of the base

1 - Network indicator
2 - Display

3 - Infra-red sensor
4 - Data-transfer indicator
5 - RNS encoder wheel
6 - Escape button
7 - Enter button

7

Head inside-top side
1 - Gobo wheel 2
2 - Colour wheel
3 - CMY/conver.lter module
4 - Objective
5 - Effect wheel
6 - Gobo wheel 1
7 - Lamp chamber

Head inside-bottom side
8 - Frost lamellas
9 - Iris
10 - Termostat
11 - Zoom/Focus module
12 - Igniter
13 - Lamp cover

8

9

5. Installation

5.1 Connection to the mains

Verify the power supply settings before applying power!

The factory settings are printed next to the power switch. If you wish to change the power supply settings, see the next
chapter.
Installl a 3-prong grounding-type plug on the power cable (only for US version 208V AC/60Hz). The earth has to be con­nected!
If you have any doubts about proper installation, consult a qualied electrician.

The occupation of the connection-cables is as follows:

Cable (EU) Cable (US)-208V Pin International

Brown Black Live L

Liht blue White Neutral N

Yellow/
Green

Green Earth

5.2 Changing the power supply settings

Magnetic ballast

The wrong settings can cause poor performance or demage of the moving head.

Note: The US-version settings is 208V AC interphase, 60Hz.

If you want to change the power supply settings, follow the instructions:

1. Disconnect the xture from AC power.

2. Remove the both top base covers by loosening the 12 screws.

3. Move both wires (1) and both wires (2) on
the ballast connection block to the position according to the desired voltage.
(The xture contains 2 magnetics ballast connected in parallel). Move the wire (3) on the transformer connection block
to the position according to the desired voltage.

4. Close the base before applying AC power.

Ballast/transformer connection block:

Power supply settings: 230V/50Hz

9

Electronic ballast

The operating range of the electronic ballast is 95 VAC-255 VAC. The transformer has to be set to the local AC voltage.

If you want to change the power supply settings, follow the instructions:

1. Disconnect the xture from AC power.

2. Remove the both top base covers by loosening
the 12 screws.

3. Move the wire (3) on the transformer connec­tion block to the position according to the desired
voltage.

4. Close the base before applying AC power.

5.3 Fitting the lamp

DANGER ! Install the lamps with the device switched off only.
Unplug from mains before !

To insert the lamp (MSR 1200 SA):

1. Disconnect the xture from power and allow it to cool.

2. Loosen the 2 quarter-turn fasteners marked „X, Y,”

on the lamp cover at the back of the head.

3. Gently pull the lamp cover with lamp holder out of
the head.

4. Holding the lamp by its ceramic base, carefully pull
the lamp straight out of the lamp socket.

5. Holding the new lamp by its ceramics base, gently
insert the lamp to the lamp socket. Make sure that the
lamp is installed tightly into the lamp socket.
Do not install a lamp with a higher wattage! A lamp
like this generates temperatures the device is not
designed for. Damages caused by non-observance
are not subject to warranty. Please follow the lamp
manufacturer‘s notes! Do not touch the glass bulb
bare hand during the installation!

6. Reinsert the lamp cover with the lamp holder and

installed lamp back to the head and tighten
the 2 quarter-turn

fasteners again.
Warning:if you feel any resistance during this action
, check the lamp electrode position and use „A,B,C“
screws to adjust right lamp position.Never put the
lamp in by force otherwise you will bend the lamp
electrode by the adge of the reector! (See picture bellow)

7. Align the new lamp.

8. Reset „Lamp On Time” and „Lamp Strikes” counters
in „Fixture information” menu.

Do not operate this xture with opened housing-cover!

Transformer connection:

Power supply settins: 120V/60Hz

1 - Lamp
2 - Lamp holder
3 - 2 quater-turn fasteners
4 - Lamp cover

10

11

5.4 Lamp adjustment

The lamp holder is aligned at the factory.
Due to differences between lamps, ne adjustment may improve light performance:

1. Switch on the xture and after reset turn on the lamp.

2. Cancel all effects, open the shutter and focus the light on a
at surface (wall) using either DMX controller or function
„Lamp adjustment” in „Special functions menu”.

3. Center the hot-spot (the brightest part of the beam) using the
3 adjustment screws „A, B, C”. Turn one screw at a time to
drag the hot-spot, diagonally across the projected image. If
you cannot detect a hot -spot, adjust the lamp until the light
is even.
To reduce a hot-spot, pull the lamp in by turning all three
screws „A, B, C” clockwise 1/4-turn at a time until the light is
evenly distributed.
If the light is brighter around the edge than it is in the center,
or if light output is low, the lamp is too far back in the reector.
„Push” the lamp out by turning the screws „A, B, C” counter­clockwise 1/4-turn at a time until the light is bright and evenly
distributed.

5.5 Inserting/Exchanging gobos, colours and effects

DANGER!

Install the gobos, colours and prisms with the device switched off only.

Unplug from mains before!

Turn off the lamp and allow it to cool for at least 10 minutes.
Disconnect the xture from power.

Open the top cover of the moving head by loosening the
4 quarter-turn fasteners on the top cover and follow the
instructions below:

Rotating gobo-wheels:

1. Gently bend out the gobo holder to release it from the xative
holes and eject it from the pressing snap.

2. Press the ends of the spring gobo-lock together with an appro­priate tool and remove it.
Do not touch the surface of the pattern of the glass gobos as
the oils from your hands can damage the pattern.

3. Remove the distance ring and gobo and insert the new gobo
(glazy side towards the lamp)with distance ring. Press the
ends of the spring gobo-lock

together and insert it in the front

of the gobo.

4. Put the gobo holder back under the pressing snap and push it
to the 3 xative notches.

CAUTION! The gobo holder with the magnet must be placed in the same
gobo position as it was placed before gobo replacement!

3 adjustment scews „A, B, C”

Reector

Lamp electrode-check its position before insertion
to the reector

11

Colour-wheel:

1. Gently bend out the colour module to release it
from the xative holes and eject it from the pres­sing snap.

2. Put the new colour module back under the pressing
snap and push it to the 3 xative notches.

Effect-wheel:

1. Gently bend out the effect glass holder to release
it from the xative holes and eject it from the
pressing snap.

2. Press the ends of the spring glass-lock together
with an appropriate tool and remove it. Remove
the glass and insert

the new one.

3. Press the ends of the spring glass-lock together
and insert it in the front of the glass.

4. Put the glass effect holder back under the pressing

snap and push it to the 3 xative notches.

CAUTION! The effect glass holder with the magnet must be placed in the same
glass position as it was placed before glass replacement!

5.6 Rigging the xture

DANGER TO LIFE!
Please consider the respective national norms during the installation!
The installation must only be carried out by an authorized dealer!

The installation of the xture has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without
any harming deformation.

The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. This secondary
safety attachment must be constructed in a way that no part of the installation can fall down if the main attachment fails.

When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges, under high
working places and other endangered areas is forbidden.

The operator has to make sure that safety-relating and machine-technical installations are approved by an expert before
taking into operation for the rst time and after changes before taking into operation another time.

The operator has to make sure that safety-relating and machine-technical installations are approved by an expert after
every four year in the course of an acceptance test.

The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled person
once a year.
Allow the xture to cool for ten minutes before handling.
The projector should be installed outside areas where persons may walk by or be seated.

IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to) calculating
working load limits, installation material being used, and periodic safety inspection of all installation material and the

12

13

projector. If you lack these qualications, do not attempt the installation yourself, but instead use a professional structural
rigger. Improper installation can result in bodily injury and or damage to property.
The xture has to be installed out of the reach of people.
If the xture shall be lowered from the ceiling or high joists, professional trussing systems have to be used. The xture
must never be xed swinging freely in the room.

Caution: Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety of a possible
installation, do not install the xture!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the xture’s weight.

Danger of re!
When installing the device, make sure there is no highly inamma

ble material (decoration articles, etc.) in between a distance of min. 1,2 m.

CAUTION! Use 2 appropriate clamps to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly!
Ensure that the structure (truss)
to which you are attaching the xtures is secure.

The moving-head can be placed directly on the stage oor or rigged in any orientation on a truss without altering its ope­ration characteristics .
The Omega holders can be placed in 4 positions on the bottom of the base. Use the clamps (not included in delivery)
with screws M12.
For overhead use, always install a safety-rope that can hold at least 10 times the weight of the xture. You must only use
safety ropes with screw-on carabines. Pull the safety rope through the two apertures on the bottom of the base and over
the trussing system etc. Insert the end in the carabine and tighten the xation screw.

Fixation via the omega holders

1. Bolt each clamp (1) to the omega
holder (4) with M12 bolt and lock nut
through the hole in the holder.

2. Fasten the omega holders on the

bottom of the base by inserting both
quick-l ock fastener s (3) into the
holes of the base and tighten fully
clockwise.

3

. Fasten the safety-rope (2) through the

two apertures on the bottom of the
base and over the trussing system.

1 - Clamp
2 - Safety-rope
3 - Quick-lock fastener
4 - Omega holder

Possible omega holder 4 positions:

When installing xtures side-by-side, avoid illuminating one xture with another!

DANGER TO LIFE! Before taking into operation for the rst time,
the installation has to be approved by an expert!

13

5.7 DMX-512 connection/connection between xtures

The xture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired in parallel.
Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in order to
connect the controller with the xture or one xture with another.

Occupation of the XLR-connection:

DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):

If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with the DMX
input of the rst xture in the DMX chain. If you wishhht to connect DMX controllers with other XLR outputs, you need to
use adapter-cables.

Building a serial DMX chain:

Connect the DMX output of the rst xture in the DMX chain with the DMX input of the next xture. Always connect one
output with the input of the next xture until all xtures are connected.

Caution: At the last xture, the DMX cable has to be terminated with a terminator. Solder a 120 Ω resistor between Signal
(–) and Signal (+) into a XLR plug and plug it in the DMX output of the last xture.

5.8 Ethernet connection

The xtures on a data link are connected to the Ethernet with Art-Net communication protocol. The controlling software
from PC (or lighting console) has to support Art-Net protocol.
Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP. Its purpose is to allow transfer of
large amounts of DMX 512 data over a wide area using standard network technology.

IP address is the Internet protocol address. The IP uniquely identies any node (xture) on a network.
The Universe is a single DMX 512 frame of 512 channels.

The ColorSpot 1200 AT is equipped with 8-pin RJ- 45 socket for Ethernet input.Use a network cable category 5 (with four
„twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.

RJ-45 socket (front view):

1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected

Patch cables that connect xtures to the hubs or
LAN sockets are wired 1:1, that is, pins with the
same numbers are connected together:

1 - Shield
2 - Signal (-)

3 - Signal (+)
4 - Not connected
5 - Not connected

If only the xture and the computer are to be inter­connected, no hubs or other active components are
needed. A cross-cable has to be used:

pin 1 2 3 4 5 6 7 8
pin 3 6 1 8 7 2 5 4

pin 1 2 3 4 5 6 7 8
pin 1 2 3 4 5 6 7 8

14

15

Ethernet connection

Connect the Ethernet-inputs of all xtures in the xture chain with the network.
Option “Ethernet” has to be selected from „Set Ethernet Mode” menu on the xture.
Set IP address (002.xxx.xxx.xxx / 010.xxx.xxx.xxx) and the Universe.

Example:

(DMX address=49)
IP addres=002.168.002.003
Universe=1

An advised PC setting: IP address: 002.xxx.xxx.xxx / 010.xxx.xxx.xxx (Different from xture IP addresses)
NET mask: 255.0.0.0

Ethernet / DMX connection

Options „Ethernet/DMX” has to be selected from „Set Ethernet Mode” menu on the rst xture (connected to the network)
in the xture chain, next xtures have standard DMX addresses.
Connect the Ethernet-input of the rst xture in the data chain with the network. Connect the DMX output of this xture
with the input of the next xture until all xtures are connected to the DMX chain.

Caution: At the last xture, the DMX chain has to be terminated with a terminator. Solder a 120 Ω resistor between Signal
(–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last xture.

Example:

(DMX address=1)
IP addres=002.168.002.001
Universe=1

(DMX address=25)
IP addres=002.168.002.002
Universe=1

DMX address=73

IP address=002.168.002.002
Universe=0

DMX address=25

DMX address=217

DMX address=25

DMX address=1

DMX address=1

IP address=002.168.002.003
Universe=1

15

6. DMX protocol

Mode / Channel

1 2 3

Value Function Type of control

1 1 19 0 - 255

Pan

Pan movement by 530°

proportional

2 2 20 0 - 255

Pan Fine

Fine control of pan movement

proportional

3 3 21 0 - 255

Tilt

Tilt movement by 280°

proportional

4 4 22 0 - 255

Tilt ne

Fine control of tilt movement

proportional

5 5 23

0

1 - 255

1 - 255

Pan/Tilt speed , Pan/Tilt time

Max. speed (tracking mode)*

P./T. speed-set Speed Mode in menu: Pan/Tilt Mode

Speed from max. to min. (vector mode)**

P./T. time - set Time Mode in menu: Pan/Tilt Mode

Time from 0,1 s to 25,5 s. ***

step

proportional

proportional

6 6 24

0 - 9

10 - 19
20 - 29
30 - 49
50 - 59
60 - 69
70 - 79
80 - 89

90 - 99
100 - 109
110 - 119
120 - 129

130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 199
200 - 209
210 - 229
230 - 239
240 - 255

Power/Special functions

Reserved
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 s. („Shutter,Strobe” channel
23 (30,1) must be at range: 0-31 DMX).****
Autofocus On
Autofocus Off
Reserved
Pan/Tilt speed mode
Pan/Tilt time mode
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Blackout while colour wheel moving
Disabled blackout while colour wheel moving
Blackout while gobo 1/gobo 2 moving
Disabled blackout while gobo 1/gobo 2 moving

To activate following functions,
stop in DMX value for at least 3 s.

Lamp On,reset(total reset except pan/tilt reset)
Pan/Tilt reset
Colour system reset
Gobo system reset
Dimmer/Strobe reset
Focus/Zoom/Frost reset
Iris/Effect/ reset
Total reset
Reserved
Lamp Off
Reserved

step

step
step
step
step
step
step
step
step
step
step
step

step
step
step
step
step
step
step
step
step
step
step

Notes: * Range 0-255 DMX at max.speed (0 DMX): pan=4.5 s
tilt=2.6 s
** Range 0-255 DMX at min. speed (255 DMX): pan=37min.10 s
tilt=19 min.34 s
*** Short times are not used for long tracks (e.g. 0.5s for track 0-255 DMX). Times are restricted by mechanical
parameters of the xture.
**** The switch-functions have priority to the equivalent functions in menu „Personality” but the setting by DMX

is not saved to the memory (after switching the xture on,the setting from menu „Personality” is loaded and
after that can by changed with DMX value on the channel 6).
DMX protocol menu „Personality”

10 - 19 Autofocus On Autofocus -->On
20 - 29 Autofocus Off Autofocus -->Off
50 - 59 Pan/Tilt speed mode Pan/Tilt mode--->Speed Mode
60 - 69 Pan/Tilt time mode Pan/Tilt mode--->Time Mode
70 - 79 Blackout while pan/tilt moving Active blackout While-->Pan/Tilt Moving-->On
80 - 89 Disabled blackout while pan/tilt moving Active blackout While-->Pan/Tilt Moving-->Off
90 - 99 Blackout while colour wheel moving Active blackout While-->Colour Wheel Moving-->On
100 - 109 Disabled blackout while colour wheel moving Active blackout While-->Colour Wheel Moving-->Off
110 - 119 Blackout while gobo1/gobo2 moving Active blackout While-->Gobo Wheels Moving-->On
120 - 129 Disabled blackout while gobo1/gobo2moving Active blackout While-->Gobo Wheels Moving-->Off

16

17

Mode / Channel

1 2 3

Value Function Type of control

7

0 - 9
10 - 31
32 - 63
64 - 95

96 - 127
128 - 159
160 - 191
192 - 223
224 - 255

Pan/Tilt macro selection

Disabled pan/tilt macro
Reserved
Figure of circle (from small to large)
Figure of horizontal eight (from small to large)
Figure of vertical eight (from small to large)
Figure of rectangle (from small to large)
Figure of triangle (from small to large)
Figure of star (from small to large)
Figure of cross (from small to large)

step

step
proportional
proportional
proportional
proportional
proportional
proportional
proportional

8

0

1 - 127
128 - 129
130 - 255

Pan/Tilt macro speed

No macro generation
Macro generation from fast to slow-forwards
No macro generation
Macro generation from slow to fast-backwards

step

proportional

step

proportional

7 9 7

0
18
37
55
73
91

110
128 - 129
130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 215
216 - 217
218 - 243
244 - 249

250 - 255

Colour wheel

Open/white
Deep red
Deep blue
Green
Orange
6000 K temperature lter
UV lter
White
Deep red
Deep blue
Green
Orange
6000 K temperature lter
UV lter
Forwards rainbow effect from fast to slow
No rotation
Backwards rainbow effect from slow to fast
Random colour selection by audio control
(Set microphone sensitivity in menu „Personality”)
Auto random colour selection from fast to slow

proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional

step
step
step
step
step
step

proportional

step

proportional

step

proportional

8 10 3

0 - 255

Cyan

Cyan (0-white, 255-full cyan) proportional

9 11 4

0 - 255

Magenta

Magenta (0-white, 255-full magenta) proportional

10 12 5

0 - 255

Yellow

Yellow (0-white, 255-full yellow) proportional

11 13 6

0 - 255

Conversion temperature lter 3200K

(0-5600K, 255-3200K) proportional

14

0 - 3
4 - 7

8 - 11
12 - 15
16 - 19
20 - 23
24 - 27
28 - 31
32 - 35
36 - 39
40 - 43
44 - 47
48 - 51
52 - 55
56 - 59
60 - 63
64 - 67
68 - 71

CMY Colour macros

No function
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17

step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step

17

Mode / Channel

1 2 3

Value Function Type of control

14

72 - 75
76 - 79
80 - 83
84 - 87
88 - 91
92 - 95

96 - 99
100 - 103
104 - 107
108 - 111
112 - 115
116 - 119
120 - 123
124 - 127
128 - 131
132 - 135
136 - 139
140 - 143
144 - 147
148 - 151
152 - 155
156 - 159
160 - 163
164 - 167
168 - 171
172 - 175
176 - 179
180 - 183
184 - 187
188 - 191
192 - 195
196 - 199
200 - 203
204 - 207
208 - 211

212 - 215
216 - 219
220 - 223
224 - 227
228 - 231
232 - 235
236 - 239
240 - 243
244 - 247
248 - 251
252 - 255

Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
Macro 23
Macro 24
Macro 25
Macro 26
Macro 27
Macro 28
Macro 29
Macro 30
Macro 31
Macro 32
Macro 33
Macro 34
Macro 35
Macro 36
Macro 37
Macro 38
Macro 39
Macro 40
Macro 41
Macro 42
Macro 43
Macro 44
Macro 45
Macro 46
Macro 47
Macro 48
Macro 49
Macro 50
Macro 51
Macro 52
Macro 53
Macro 54
Macro 55
Macro 56
Macro 57
Macro 58
Macro 59
Macro 60
Macro 61
Macro 62
Macro 63

step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step

12 15

0 -255

Effect speed

From max. speed to min.speed ***** proportional

16

0 - 31
32 - 63
64 - 95

96 - 255

Effect speed assigning

Dimmer + CMY lters + correction lter
Dimmer
CMY lters + correction lter
No function

step
step
step
step

13 17 8

0 - 9
10 - 13
14 - 17
18 - 21
22 - 25
26 - 29
30 - 33

Rotating gobo wheel 1
Index - set indexing on channel(s) 14 (18,19;9,10)

Open/hole
Gobo 1 - Rainbow Chips (15030012)
Gobo 2 - Sun Man (15030013)
Gobo 3 - Water Drops (15030014)
Gobo 4 - Triangle Floating (15020123)
Gobo 5 - Laser (15020124)
Gobo 6 - Swirl Electric (15020125)

step
step
step
step
step
step
step

*****Standard speed: Range 0-255 DMX at min. speed (0 DMX): Cyan (magenta/yellow) = 3min, 35 s

18

19

Mode / Channel

1 2 3

Value Function Type of control

13 17

34 - 37
38 - 41
42 - 45
46 - 49
50 - 53
54 - 57

58 - 69
70 - 81
82 - 93

94 - 105
106 - 117
118 - 129

130 - 141
142 - 153
154 - 165
166 - 177
178 - 189
190 - 201
202 - 221
222 - 223
224 - 243
244 - 249

250 - 255

Rotation - set rotation on channel(s) 14 (18,19;9,10)

Gobo 1 - Rainbow Chips (15030012)
Gobo 2 - Sun Man (15030013)
Gobo 3 - Water Drops (15030014)
Gobo 4 - Triangle Floating (15020123)
Gobo 5 - Laser (15020124)
Gobo 6 - Swirl Electric (15020125)

Shaking gobos from slow to fast
Index - set indexing on channel(s) 14 (18, 19;9,10)

Gobo 1 - Rainbow Chips (15030012)
Gobo 2 - Sun Man (15030013)
Gobo 3 - Water Drops (15030014)
Gobo 4 - Triangle Floating (15020123)
Gobo 5 - Laser (15020124)
Gobo 6 - Swirl Electric (15020125)

Shaking gobos from slow to fast
Rotation - set rotation on channel(s) 14 (18,19;9,10)

Gobo 1 - Rainbow Chips (15030012)
Gobo 2 - Sun Man (15030013)
Gobo 3 - Water Drops (15030014)
Gobo 4 - Triangle Floating (15020123)
Gobo 5 - Laser (15020124)
Gobo 6 - Swirl Electric (15020125)
Forwards gobo wheel 1 rotation from fast to slow
No rotation
Backwards gobo wheel 1 rotation from slow to fast
Random gobo 1 selection by audio control
(Set microphone sensitivity in menu „Personality”)
Auto random gobo 1 selection from fast to slow

step
step
step
step
step
step

proportional
proportional
proportional
proportional
proportional
proportional

proportional
proportional
proportional
proportional
proportional
proportional
proportional

proportional

step

proportional

14 18 9

0 - 255

0

1 - 127
128 - 129
130 - 255

Gobo 1 indexing and rotation
Gobo indexing - set position on channel 13 (17;8)

Gobo indexing

Gobo rotation - set position on channel 13 (17;8)

No rotation
Forwards gobo rotation from fast to slow
No rotation
Backwards gobo rotation from slow to fast

proportional

step

proportional

step

proportional

19 10

0 - 255

Gobo 1 ne indexing and rotation
(set position on channel 13 (17;8))

Fine indexing (rotating) proportional

15 20 11

0 - 9
10 - 13
14 - 17
18 - 21
22 - 25
26 - 29
30 - 33

34 - 37
38 - 41
42 - 45
46 - 49
50 - 53
54 - 57

58 - 69
70 - 81
82 - 93

94 - 105
106 - 117
118 - 129

Rotating gobo wheel 2
Index - set indexing on channel(s) 16 (21, 22;12,13)

Open/hole
Gobo 1 - Diamante Spot(15040020)
Gobo 2 - Wheel (15020126)
Gobo 3 - Space Tunel (15020127)
Gobo 4 - Bubbles 1 (15020128)
Gobo 5 - 12 Dots (15020129)
Gobo 6 - Radial Dashes (15020130)

Rotation - set rotation on channel(s) 16 (21, 22;12,13)

Gobo 1 - Diamante Spot (15040020)
Gobo 2 - Wheel (15020126)
Gobo 3 - Space Tunel (15020127)
Gobo 4 - Bubbles 1 (15020128)
Gobo 5 - 12 Dots (15020129)
Gobo 6 - Radial Dashes (15020130)

Shaking gobos from slow to fast
Index - set indexing on channel(s) 16 (21, 22;12,13)

Gobo 1 - Diamente Spot (15040020)
Gobo 2 - Wheel (15020126)
Gobo 3 - Space Tunel (15020127)
Gobo 4 - Bubbles 1 (15020128)
Gobo 5 - 12 Dots (15020129)
Gobo 6 - Radial Dashes(15020130)

step
step
step
step
step
step

step
step
step
step
step
step

proportional
proportional
proportional
proportional
proportional
proportional

19

Mode / Channel

1 2 3

Value Function Type of control

15 20 11

130 - 141
142 - 153
154 - 165
166 - 177
178 - 189
190 - 201
202 - 221
222 - 223
224 - 243
244 - 249

250 - 255

Shaking gobos from slow to fast
Rotation - set rotation on channel(s) 16(21,22;12,13)

Gobo 1 - Diamante Spot (15040020)
Gobo 2 - Wheel (15020126)
Gobo 3 - Space Tunel (15020127)
Gobo 4 - Bubbless (15020128)
Gobo 5 - 12 Dots (15020129)
Gobo 6 - Radial Dashes (15020130)
Forwards gobo wheel 2 rotation from fast to slow
No rotation
Backwards gobo wheel 2 rotation from slow to fast
Random gobo 2 selection by audio control
(Set microphone sensitivity in menu „Personality”)
Auto random gobo 2 selection from fast to slow

proportional
proportional
proportional
proportional
proportional
proportional
proportional

step

proportional

step

proportional

16 21 12

0 - 255

0

1 - 127
128 - 129
130 - 255

Gobo 2 indexing and rotation
Gobo indexing - set position on channel 15 (20;11)

Gobo indexing

Gobo rotation - set position on channel 15 (20;11)

No rotation
Forwards gobo rotation from fast to slow
No rotation
Backwards gobo rotation from slow to fast

proportional

step

proportional

step

proportional

22 13

0 - 255

Gobo 2 ne indexing and rotation
(set position on channel 15 (20))

Fine indexing (rotating) proportional

17 23 14

0 - 19
20 - 39
40 - 59
60 - 79
80 - 99

100 - 119
120 - 139
140 - 159
160 - 179

180 - 183
184 - 187
188 - 191
192 - 195
196 - 199
200 - 203
204 - 207
208 - 211
212 - 215
216 - 219
220 - 223
224 - 227
228 - 231
232 - 235
236 - 239
240 - 243
244 - 249

250 - 255

Effect wheel
Index - set indexing on channel(s) 18 (24, 25;15)

Open/hole
3-facet prism
5-facet prism
Estriado
Diamante

Rotation - set rotation on channel(s) 18 (24, 25;15)

3-facet prism
5-facet prism
Estriado
Diamante

Prism/gobo macros

Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Random Effect selection by audio control (Set microph.sensit.)
Auto random Effect selection from fast to slow

step
step
step
step
step

step
step
step
step

step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step

proportional

18 24 15

0 - 255

0
1 - 127
128 - 129
130 - 255

Effect indexing and rotation
Effect indexing - set position on channel 17 (23;14)

Effect indexing

Effect rotation - set position on channel 17 (23;14)

No rotation
Forwards Effect rotation from fast to slow
No rotation
Backwards Effect rotation from slow to fast

proportional

step
proportional
step
proportional

20

21

Mode / Channel

1 2 3

Value Function Type of control

25

0 - 255

Fine effect indexing and rotation
(set position on channel 17 (23))

Fine indexing (rotating) proportional

19 26

0

1 - 179
180 - 189
190 - 211
212 - 233
234 - 255

Frost

Open
Frost from 0% to 100%
100% frost
Pulse closing from slow to fast
Pulse opening from fast to slow
Ramping from fast to slow

step
proportional
proportional
proportional
proportional
proportional

20 27 16

0

1 - 179

180 - 191

192 - 203
204 - 215
216 - 217
218 - 219
220 - 221
222 - 223

224 - 239
240 - 255

Iris

Open
From max. diameter to min. diameter
Closed

Pulse effects with Iris blackout

Pulse opening from slow to fast
Pulse closing from fast to slow
Random pulse opening (fast)
Random pulse opening (slow)
Random pulse closing (fast)
Random pulse closing (slow)

Pulse effects with Iris blackout and zoom

Pulse opening from slow to fast
Pulse closing from fast to slow

step
proportional

step

proportional
proportional

step

step

step

step

proportional
proportional

21 28 18

0 - 255

Zoom

Zoom from 42° to 13° proportional

22 29 17

0 - 255

Focus

Continuous adjustment from far to near proportional

23 30 1

0 - 31
32 - 63
64 - 95

96 - 127
128 - 143
144 - 159
160 - 191

192 - 223
224 - 255

Shutter, strobe

Shutter closed, Lamp power reduced after 10 s to 700W
Shutter open, Full lamp power
Strobe-effect from slow to fast (max.15 ashes/s)
Shutter open, Lamp power reduced to 700 W
Opening pulse in sequences from slow to fast
Closing pulse in sequences from fast to slow
Shutter open, Electronic strobing „ZAP” from slow to fast
(from 7 to 33 ashes/s)
Random strobe-effect from slow to fast
Shutter open, Full lamp power
Note: underlined characters - ColorSpot 1200E AT only

step
step

proportional

step
proportional
proportional
proportional

proportional

step

24 31 2

0 - 255

Dimmer intensity

Dimmer intensity from 0% to 100%
(In range 0-3 DMX, lamp power reduced to 700 W after 10 s)

proportional

32

0 - 255

Fine dimmer intensity

Dimmer intensity ne

proportional

21

7. Controller mode

The xtures are individually addressed on a data link and connected to the controller. The xtures respond to the DMX
signal from the controller.

7.1 DMX addressing

There are 512 available channels on DMX link. Every xture on DMX link must have a DMX start address, which is dened
as the rst channel from which the xture will respond to the controller.
If you set, for example, for the ColorSpot 1200 AT the start address to channel 25, the ColorSpot 1200 AT will use the
channels 25 to 48 for control (if Mode 1 is selected from „DMX Preseting” menu).
Please, be sure that you don’t have any overlapping channels in order to control each ColorSpot 1200 AT correctly and
independently from any other xture on the DMX data link.
If two, three or more ColorSpot 1200 AT are addressed similarly, they will work similarly.

Controlling:

After having addressed all ColorSpot 1200 AT , you may now start operating these via your lighting controller.

Note:

After switching on, the ColorSpot 1200 AT will automatically detect whether DMX 512 data is received or not. If there
is no data received at the DMX-input, the display will start to ash with actually address.

7.2 Remotely controllable functions

Lamp

The ColorSpot 1200 AT is to be operated with a Philips MSR 1200 SA lamp.
A relay inside of the ColorSpot 1200 AT allows you to switch on and off the lamp via the control panel or via your DMX­controller without affecting the rest of the lighting.
Note: It is also important to note, that the discharge lamp is cold restrike types, that means, that they have to be cold

before re-striking. For this reason, you have to wait at least 5 minutes after having switched off the lamp before you
can switch it back on again. If you try to switch On the lamp within 5 minutes after having switched it Off, the Color­Spot 1200 AT will store this information and automatically ignite the lamp when the 5 minutes period has expired.

CMY-colours mixing system

The CMY color mixing system is based on graduated cyan, magenta, and yellow color lters. A continuous range of colors
may be achieved by varying the amount of each lter from 0 to 100%.
Colour temperature correction ltre lowers the colour temperature from 5600K to 3200 K.

Colour wheel

The ColorSpot 1200 AT features a colour wheel with 4 colour positions, UV lter and 6000 K temp. lter and the hole
(open). It is also possible to rotate the colour wheel continuously at different speeds, the so-called „Rainbow effect“ is
created. Auto random colour selection,random colour selection by audio control is possible.

Rotating gobo wheel 1

The rotating gobo wheel includes 6 dichroic glass gobos rotating in both directions at different speeds. All rotating gobos
are replaceable and ne indexable.
Rotating gobo wheel can continuously rotate in both directions from slow to fast speed.

Rotating gobo wheel 2

The rotating gobo wheel includes 1 glass gobo and 5 dichroic glass gobos rotating in both directions at different speeds.
All rotating gobos are replaceable and ne indexable.
Rotating gobo wheel can continuously rotate in both directions from slow to fast speed.

Effect wheel

This wheel provides 3-facet prism,5-facet prism and 2 glass effects rotating in both directions at different speeds.Prism/
gobo macros are possible.

Iris

Motorized adjustable iris,wide range of variable pulse effects.

Frost

Frost module provides variable frost for ne frosting.

Focus-multistep zoom

Motorized focus enables the beam to be focused anywhere on stage, provided by the special multistep zoom with range
13°- 42°.

Dimmer/Shutter/Strobe

Smooth 0 - 100 % dimming is provided by the combined mechanical dimmer/shutter unit. This unit may also be used for
strobe effect (1 - 15 ashes per second)

22

23

Fans

By the Control Board using the „Fan Modes” function you can choose the 2 types of the fan speed operating modes.

8. Control menu map

Note: Default settings = Bold print

Fixture Address

DMX Address
001
:
512
Ethernet Settings
Set Ethernet Mode
Disable Ethernet
Ethernet
Ethernet/DMX
Set IP Address
Default IP Address
Custom IP Address
Set ArtNet Universe (0 -255)

Fixture information

Power On Time
Total Hours
Resetable Hours
Lamp On Time
Total Hours
Resetable Hours
Lamp Strikes
Total Hours
Resetable Hours
Air lters

Set Alert period (10...50....300 hours)

Elapsed time [hours]

Fixture Temperatures
Current
Board Temp. [°C]
Ambient Temp. [°C]
Near Lamp Temp. [°C]
Maximum Nonresetable
Board Temp. [°C]
Ambient Temp. [°C]
Near Lamp Temp. [°C]
Maximum Resetable
Board Temp. [°C]
Ambient Temp. [°C]
Near Lamp Temp. [°C]
Fans Speed
Fan 1
:
Fan 9
DMX Values
Pan (0-255)
:
Dimmer Fine (0-255)
Software Version
IC1 MB
IC2 MB
IC3 MB
IC4 MB
IC1 B1
:
IC1 DS
IC2 DS
Product IDs
Mac Adr.
Code

23

Personality

User Mode
User A Settings,User B Settings,User C Settings
DMX Presetting
Mode 1
Ch.1 Pan
:
Ch. 24 Dimmer
Set Active
Mode 2
Ch.1 Pan
:
Ch. 32 Dimmer Fine
Set Active
Mode 3
Ch.1 Shutter
:
Ch.24 Power
Set Active
Pan Reverse (On, Off)
Tilt Reverse (On, Off)
Lamp Presetting
Lamp On/Power On (On, Off)
Lamp Off via DMX (On, Off)
Lamp On if DMX Present (On, Off)
Lamp Off if not DMX (On, Off)

Lamp Ignition Delay (0..1..90) s

Lamp Low Power Delay (10....600) s

Lamp Light Sensor (On, Off)
Display Adjusting
Display Permanent On (On, Off)
Display Intensity (1..10)
Display Backlight (1..5..10)
Display Turned (On, Off)
Blackout d.M.C. (On, Off)
Pan/Tilt Feedback (On, Off)
Microphone Sensitivity (1..10..20)
Fan Modes
Auto Cooling
High Cooling
Autofocus (On, Off)
Pan/Tilt mode (Time mode, Speed Mode)
Active Blackout While
Pan/Tilt Moving (On, Off)
Colour Wheel Moving (On, Off)
Gobo Wheels Moving (On, Off)
IR Sensor (On, Off)
Init Effect Positions
Pan, (0..1..225)
:
Dimmer (0..1..255)
Save
Dimmer Curve (Curve 1, Curve 2)

CMY+CTF Speed (Standard speed,High speed)
Focus/Zoom Curve (Compatible,New)

Temperature Unit (°C,°F)
Default Setting

Lamp On/Off (On, Off)

Test sequences

Mode 1
Pan,Tilt,Zoom,Focus (0-255)
Run Test Program
Mode 2
Run Test Program

24

25

Manual Mode

Presetted Effect Control
Pan (Position 1,..., Position 6)
:
Dimmer (Position 1,..., Position 5)
Manual Effect Control
Pan (0-255)
:
Dimmer Fine (0-255)

Stand- alone setting

Music Trigger (On, Off)
Presetting Playback
Disabled
Test Program
Program 1
Program 2
Program 3
Playing Program
Test Program In Loop
Program 1 In Loop
Program 2 In Loop
Program 3 In Loop
Editing Program
Program 1
Program 2
Program 3
Edit Steps
Step1
:
Step 99
Pan (0-255)
:
Dimmer ne (0-255)

Step Time (0,1-25,5s)
Save
Save and copy
Start Step (1-99)
End Step (1-99)

Reset functions

Reset All
Pan/Tilt
:
Iris/Effect

Special functions

Lamp Adjustment
Pan (0-255)
Tilt (0-255)
Zoom (0-255)
Focus (0-255)

Effect Adjustment
DMX Values
Pan (0-255)
:
Dimmer ne (0-255)

Calibrate Values
Pan (0-225)
:
Dimmer (0-255)
Updating software Save and Reset
Load Default Values

25

9. Control menu

The control panel situated on the front panel of the base offers several features. You can simply set the DMX address,
read the number of the lamp or unit hours, switch On and Off the lamp, run test, make a reset and also use many func­tions for setting xture behaviour.

Control elements on the control board:

[RNS] encoder wheel-moves between menu items on the the same level, scrolls between values.
[ESC] button-leaves menu without saving changes
[ENTER] button-enters menu, conrms adjusted values and leaves menu

After switching the xture on, Press [ENTER],
the display shows the initial screen: the display shows current address:

The main menu of the control panel is accessed by pressing [ENTER] button. To browse through the menu, rotate [RNS]
wheel. To select a function or submenu, press [ENTER] button. Presetted options are displayed negative.

9.1 Fixture Address

Use this menu to set the DMX address.

DMX Address - Select this submenu to set DMX start address.

Ethernet Settings - Select this submenu to set the xture for Ethernet operating.
Set Ethernet Mode - Select this submenu to select Ethernet operating mode:

Disable Ethernet - disables network operating.
Ethernet -

Data are received to the Ethernet input of the xture - every xture from xture chain has to
be connected to the network.

Ethernet/DMX -

Data go from Ethernet input „through” the xture to the DMX output of the xture- it is

possible to connect the next xture to DMX output and to make a DMX chain.

Set IP Address - Select this submenu to set IP address.IP address is the Internet protocol address.

The IP uniquely identies any node (xture) on a network. There can't be 2 xtures with the
same IP address on the network!

Default IP Address - Presetted IP address, you can edit only rst number of IP address (2 or 10)

e.g. 002.019.052.086.

Custom IP Address - The option enables edit all numbers of IP address e.g. 002.019.052.086.

To set the custom IP address:

1. Select „Custom IP Address” and press [ENTER].

2. Use RNS wheel to set the rst number of IP addres

3. Press [ENTER] to move on the second number of IP address

4. Repeat steps 2 and 3 for the third and the fourth number of IP address.
If you want to return back on the previouly editted number, press [ESC].
Set ArtNet Universe -

Select this submenu to set a Universe (0-255). The Universe is a single DMX 512 frame

of 512 channels.

9.2 Fixture informations

Use this menu to read an useful information about the xture.

Power On Time - Select this submenu to read the number of operation hours.
Total Hours -

The function shows the total number of the operation hours since the ColorSpot 1200 AT

has been fabricated.

Resetable Hours -

The function shows the number of the operation hours that the ColorSpot 1200 AT
has been powered on since the counter was last reset. In order to reset this counter to 0,
press [ENTER] twice.

Lamp On Time - Select this submenu to read the number of the operation hours with the lamp on.
Total Hours -

The function shows the total number of the operation hours with the lamp on since

the ColorSpot 1200 AT has been fabricated.

Resetable Hours -

The function shows the number of the operation hours with the lamp on that
the ColorSpot 1200 AT has been powered on since the counter was last reset. In order to
reset this counter to 0, press [ENTER] twice.

Lamp Strikes - Select this submenu to read the total number of the lamp strikes.
Total Hours - The function shows the total number of the lamp strikes since the ColorSpot 1200 AT has been

fabricated.
Resetable Hours - The function shows the number of the lamp strikes since the counter was last reset. In order
to reset this counter to 0, press [ENTER] twice.

26

27

Air Filters --- Regular cleaning of the air lters is very important for the xture´s life and performance.Bildup of dust,dirt
and fog uid residues reduces the xture´s light output and cooling ability.The two items of this menu help you to keep
cleaning peeriod of the air lters.
Set alert period - Cleaning schedule for the xture depends on the operating enviroment.
It is therefore imposible to specify accurate cleaning interval.This function allows
you to change the cleaning interval of the air lters.This "alert" value is 50 hours and it
is set as default.Inspect the xture within its 50 hours of operation to see whether cleaning
is necessary.If clening is required,clean all air lters and change the value in this menu
on acceptable level.Min. level of alert period is 10 hours, max. is 300 hours.
Elapsed Time - The option allows you to read the time which remains to cleaning air lters.
The time period is set in the menu mentioned above.
Expired time period is signalized by a negative mark at the time value and a warning icon
(triangle) on the display with the following message: "Clean Air Filters"
Clean the lters and reset this menu item (by pressing "Enter" button twice while this menu
is highlighted) to start the new time countdown.

Fixture Temperatures - Select this submenu to read the temperatures of the xture:
Current - Select this function to read the current temperatures of the xture inside (Board
Temp., Ambient Temp.,Near Lamp Temp.)
Maximum nonresetable -

The function shows the max.temperatures of the xture inside (Board Temp., Ambient
Temp., Near Lamp Temp.) since the ColorSpot 1200 AT has been fabricated.
Maximum resetable -

The function shows the maximum temperatures of the xture inside (Board Temp., Ambient
Temp., Near Lamp Temp.) since the respective counter was last reset. In order to reset desired counter to
0, press [ENTER] twice.
Measurement points:
Board Temp. - temperature on the main board in the xture base.
Ambient Temp. -

temperature of the air which is sucked to the xture base. This temperature can be different
from the real ambient temperature due to e.g. suction of the hot air from the xture head to the base if the xture
is hanging at the ceiling. Please note that the ambient temperature should not exceed 40°C.
Near Lamp Temp. - temperature in the lamp chamber.

Fans Speed - Select this function to read the actual speed of the fans(speeds per minute):
Fan1 - The fan cools the lamp peak
Fan 3 - The fan on the rear left side of the head
Fan 5 - The left fan at the CMY module
Fan 6 - The right fan at the CMY module
Fan 7 - The Fan iside the head
Fan 9 - The fan on the front right side of the head

Location of the fans:

(Top view)

27

DMX Values - Select this function to read DMX values of each channel received by the xture.

Product IDs - Select this function to read the MAC address or xture code.
Software Version - Select this function to read the software version of the xture modules:

IC1 MB - Main processor on the main board in the xture base
IC2 MB - Tilt processor on the main board in the xture base
IC3 MB - Pan procesor on the main board in the xture base
IC4 MB - EEprom on the main board in the xture base
IC1 B1 - Shutter/conversion lter 3200K processor on the board 1 in the xture head
IC2 B1 - Gobo wheel 1/gobo rotation/colour wheel processor on the board 1 in the xture head
IC1 B2 - CMY processor on the board 2 in the xture head
IC2 B2 - Effect wheel/effect rotation processor on the board 2 in the xture head
IC1 B3 - Zoom/focus/frost processor on the board 3 in the xture head
IC2 B3 - Gobo wheel 2/gobo rotation/iris processor on the board 3 in the xture head
IC1 DS - Display processor on the display module in the xture base
IC2 DS - Memory on the display module in the xture base

Location of the fans, processors and temperature measuring points:

(Top view)

Display module

(Rear view)

9.3 Personality

Use this menu to to modify ColorSpot 1200 AT operating behavior.

User mode -

ColorSpot 1200 AT allows you to recall up to 3 user settings. After switching the xture on for the rst time,

the User A settings are active. All changes made in „Personality” menu, „Fixture Address” menu and Music

Trigger and Presetting Playback functions from „Stand-alone setting” menu are saved to the User A settings. If

you now set the User B settings active, from this moment these changes are saved to the User B settings. After
switching the xture off and on, the User B setting is active. In this way you may use 3 xture operating behaviour.
User A Settings - The function recall the user A settings.
User B Settings - The function recall the user B settings.
User C Settings - The function recall the user C settings.

Pan Reverse - Select this function to invert the pan movement.

Tilt Reverse - Select this function to invert the tilt movement.

DMX Preseting - Select this function to set desired effects assigning to the channels. You can choose 2 effects orders

(Mode 1-24 channels, Mode 2-32 chanels,Mode 3-24 channels).

28

29

Mode 1 - Default channel setting:

Channel Effect Channel Effect

1 Pan 13 Gobo Wheel 1

2 Pan Fine 14 Gobo 1 Indexing

3 Tilt 15 Gobo Wheel 2

4 Tilt Fine 16 Gobo 2 Indexing

5 Pan/Tilt Speed 17 Effect Wheel

6 Spec. Func. 18 Effect Indexing

7 Colour Wheel 19 Frost

8 Cyan 20 Iris

9 Magenta 21 Zoom

10 Yellow 22 Focus

11 Conversion Filter 23 Shutter/Strobe

12 Effect Speed 24 Dimmer

Mode 2

Channel Effect Channel Effect

1 Pan 17 Gobo Wheel 1

2 Pan Fine 18 Gobo 1 Indexing

3 Tilt 19 Gobo 1 F. Indexing

4 Tilt Fine 20 Gobo Wheel 2

5 Pan/Tilt Speed 21 Gobo 2 Indexing

6 Special Functions 22 Gobo 2 F. Indexing

7 Pan/Tilt Macro 23 Effect Wheel

8 P./T. Macro Speed 24 Effect Indexing

9 Colour Wheel 25 Effect F. Index.

10 Cyan 26 Frost

11 Magenta 27 Iris

12 Yellow 28 Zoom

13 Conversion Filter 29 Focus

14 CMY Colour Macro 30 Shutter/Strobe

15 Effect Speed 31 Dimmer

16 Effect Spd Assig. 32 Dimmer Fine

Mode 3

Channel Effect Channel Effect

1 Shutter/Strobe 13 Gobo 2 F. Indexing

2 Dimmer 14 Effect Wheel

3 Cyan 15 Effect Indexing

4 Magenta 16 Iris

5 Yellow 17 Focus

6 Conversion Filter 18 Zoom

7 Colour Wheel 19 Pan

8 Gobo Wheel 1 20 Pan Fine

9 Gobo 1 Indexing 21 Tilt

10 Gobo 1 F. Indexing 22 Tilt Fine

11 Gobo Wheel 2 23 Pan/Tilt Speed

12 Gobo 2 Indexing 24 Spec. Func.

Please refer to the chapter „DMX - protocol” for detail description.
Lamp Presetting - Select this menu to change the lamp „behaviour”.

29

Lamp On/Power On - Select this function to turn the lamp on automatically after switching the xture on.
Lamp Off via DMX - Select this function to switch off the lamp via DMX.
Lamp On if DMX Present - This function allows you to strike the lamp automatically after 26 seconds if DMX

signal is present on the data link.If the ignition is unsuccessfull (e.g.lamp is too hot), the xture will try to ignite
the lamp after next 26 s. This process will repeat until the lamp lights.
Lamp Off if not DMX -

This function allows you to switch Off the lamp automatically after 2 minutes if DMX signal
is missing on the data link.
Lamp Ignition Delay

- This function allows you to set the time delay( 0-90s) before the lamp will be ignited. This
setting will not affect starting the lamp direct from the control panel (menu "Lamp On/Off").
Lamp Low Power Delay

-

This function enables set the time period after that the lamp power will be reduced

if the shutter/dimmer is closed.The delay time can be set up to 600seconds.Default setting is10s.

Lamp Light Sensor - Select this function to switch the lamp light sensor on or off. The option „On” is for the standard
operation.
Important: The option „Off” is for „emergency operation” only if the lamp light sensor is defective and you will wait for
a service intervertion! If the lamp light sensor is switched off and at switching the lamp on the electronics will still try to
ignite the lamp until it shines (even when the lamp is damaged or absent), on this account some electronics parts could
be damaged!

Display Adjusting - This function allows you to change the display settings.
Display Permanent On - This function allows you to keep the display on or to turn off automatically 2 minutes
after last pressing any button(or a wheel movement) on the control panel.
Display Intensity - Select this function to adjust the display intensity (1-min.,10-max.).
Display Backlight - Select this function to adjust the display backlight (1-min.,10-max.).
Display Turned - Select this function to turn the display by 180°.

Blackout d.M.C. - Select this function to enable the blackout during the head movement correction (if the moving head
lost its right pan/tilt position for a short moment).

Pan/Tilt Feedback - This function allows to return the mowing head to the required pan/tilt position after changing the
position by external force (e.g.by stroke).

Be careful, the Pan/Tilt Feedback OFF is not the standard operation and the head of the xture can be demaged!
Note: If the feedback was switched off, the pan/tilt-position is changed by an external force and the feedback is switched

on again, the moving head might not to be synchronized with the DMX signal. You have to make a reset in order
to synchronize the moving head with the DMX signal.

Microphone Sensitivity - Select this function to adjust the microphone sensitivity from 1(maximum) to 20 (minimum). If
the sensitivity is correctly adjusted, the mark will appear (blinking in the bass beat.)

Fan Modes - By using this function you can choose 2 types of the fan speed operating modes.
Auto Cooling - The fans automatically raise their speed in order to control inside temperature of the lighting,
if the temperature inside increases about certain level (the low fan speed reduces the cooling of the lighting).
This cycle can repeat several times until the temperature inside is on a suitable level.
High Cooling - The cooling fans work on max. speed (max. cooling). This mode we recommend for high ambient
temperature (30 °C and more).

Autofocus - The function improves the image on the wall if the zoom changes (its effect is the best for gobos from gobo
wheel 2 and for distance cca 6 m). If you want to focus the image on the long distance (more than 15 m), this
function should be set off.

Pan/Tilt mode - Use this menu to set the character of the pan/tilt movement.
Time mode - Pan and tilt will move with different speeds and they will come at the same time to end point (pan
and tilt sets its optimal speed).
Speed Mode - Pan and tilt will move with the same speed as adjusted by the channel 5 (Pan/Tilt speed). E.g.
pan will come to the end point and wait for tilt, which has longer track.

Active Blackout while: - Use this function if you wish to close the light output during effect changes.
Pan/Tilt Moving - This function closes the light output during pan/tilt changes.
Colour Wheel Moving - This function closes the light output during colour changes.
Gobo Wheels Moving - This function closes the light output during gobo wheel 1/gobo wheel 2 changes.

IR Sensor - Select this function to switch on/off infra-red remote control.

Init Effect Positions - Select this function to set all effects to the desired positions. After switching the xture on (if DMX

is not connected), all effects will move to this init positions.

Note: If you operate 24 channels pre-setting (Mode 1) and you adjust DMX values for channels which are not
included in this mode, you will not be able to change these effects from the controller !
For example: You operate the Mode 1 and in „Init Effect Positions” menu is adjusted CMY Colour Macro =150, this value

shoud be 0 or you will not abble to control cyan, magenta and yellow because these effects are used in CMY
macros and the macros have a priority.

30

31

Dimmer Curve - Select desired dimmer running.
Curve 1 Curve 2

CMY-CTF Speed - Select this option to select desired speed of movement of CMY and CTF lamelas:Standard speed or
High speed.Default setting is High Speed.

Focus/Zoom Curve - Compatible - The behaviour of focus/zoom module is compatible with previous versions of
the Colorspot 1200 AT/1200E AT.
New - Increases possibilities of focus/zoom module.

Temperature Unit --- Select this menu in order to display xture temperatures in °C or °F.

Default Settings - Select this option to reset all xture personalities to the default values.

9.4 Lamp On/Off

Use this option in order to switch on/off the lamp. It is also important to note, that the lamp is cold restrike type, that means,
that it has to be cold before striking.

9.5 Test sequences

Use this menu to to run a special demo-test sequences without an external controller, which will show you some pos­sibilities of using ColorSpot 1200 AT.
Mode 1 - This mode is suitable for projections on the wall, ceiling or ground without any head movement.
Mode 2 - This mode uses all ColorSpot 1200 AT functions including pan/tilt movement and therefore is good for
a complete introduction of the xture.

9.6 Manual mode

Presetted Effects - Select this menu to call up presetted positions of channel effects.
Manual Effect control - Select this menu to control channels by control elements on the control board.

9.7 Stand-alone setting

Use this menu to set options for stand-alone mode as a selection of the playing program,programming and modifying
current programs.
Music Trigger - Select this function to enable the sound control of the running programs via the built-in microphone.
Presetting Playback - This function allows you to select the program which will be played in the
stand-alone mode after switching the xture on.Selected program will be played continuously in a loop.
Disabled - The option disables „Presetting playback” function.
Test Program - The option will start built-in test program.
Program 1 - The option will start created program No.1
Program 2 - The option will start created program No. 2
Program 3 - The option will start created program No. 3
Note: If the xture operates in the controller mode (DMX controller is connected) and any program from this menu is
selected, in this case the xture will not respond to the DMX controller after switching on and will play selected program.

Playing program -Select this menu to run a built-in program or the 3 freely-programmable programs in a loop.
Test Program In Loop - The option starts built-in test program.
Program 1 In Loop - The option starts created program No. 1
Program 2 In Loop - The option starts created program No. 2
Program 3 In Loop - The option starts created program No. 3
Select the program you wish and press [ENTER]. The selected program starts running. By Pressing [ENTER] again is
possible to pause the program running.

Editing Program - Select this menu to edit or create the program. The ColorSpot 1200 AT has one built-in program and
the 3 free programs, each up to 99 steps. Each program step has a step time.
Step time-the time, during which effects last in the current step.

Procedure:

1. Select the program you want to edit („Program 1” - „Program 3”) and press [ENTER].

2. Select „Edit Steps” menu and press [ENTER].

3. Select the desired program step („Step 01” - „Step 99”) and press [ENTER].
4 Select the desired item and press [ENTER]. Now you can edit DMX value for selected item:
"Pan"- a coarse pan, value 0-255

31

"Pan Fine" - a ne pan, value 0-255
"Tilt" - a coarse tilt, value 0-255
"Tilt Fine" - a ne tilt, value 0-255
"Pan/Tilt Speed " - a speed of pan/tilt movement, value 0-255
"Spec. Func." - a special functions, lamp on/off, reset, value 0-255
"Pan/Tilt Macro" - a pan/tilt macro, value 0-255
"P./T.Macro Speed" - a pan/tilt macro speed, value 0-255
"Colour Wheel" - a colour wheel, value 0-255
"Cyan" - a cyan, value 0-255
"Magenta" - a magenta, value 0-255

"Yelow" - an yellow, value 0-255
"Conversion Filter" - a conversion temperature lter, value 0-255
"CMY Colour Macro" - a CMYcolour macro, value 0-255
"Effect Speed" - a effect speed, value 0-255

"Effect Speed. Assig." - a effect speed assigning,value 0-255
"Gobo Wheel 1" - a rotating gobo wheel 1, value 0-255

"Gobo 1 Indexing" - a gobo 1 - coarse indexing and rotation, value 0-255
"Gobo 1 F. Indexing " - a gobo 1 - ne indexing and rotation, value 0-255
"Gobo Wheel 2" - a rotating gobo wheel 2, value 0-255
"Gobo 2 Indexing" - a gobo 2 - coarse indexing and rotation, value 0-255
"Gobo 2 F. Indexing " - a gobo 2 - ne indexing and rotation, value 0-255

"Effect Wheel " - an effect wheel and prism/gobo macro, value 0-255

"Effect Indexing" - an effect - coarse indexing and rotation, value 0-255
"Effect F. Index. " - an effect - ne indexing and rotation, value 0-255
"Frost" - a frost, value 0-255
"Iris" - an iris, value 0-255

"Zoom" - a zoom, value 0-255
"Focus" - a focus, value 0-255
"Shutter/Strobe" - a shutter and strobe,value 0-255
"Dimmer" - a dimmer intensity-coarse, value 0-255

"Dimmer Fine" - a dimmer intensity-ne, value 0-255

5. Select „Save” or „Save and Copy” and press [Enter] to conrm adjusted values:
"Save" - saving the current prog. step
"Save and Copy" - saving and copying the current prog. step to the next prog. step.

6. Go on next prog. step and repeat this procedure (steps 4 and 5).
After creation the program, you can simply reduced its length (by changing the start/end steps) using the „Start Step” and
„End Step” menu.

9.8 Reset functions

The ColorSpot 1200 AT can be reset totally or by function modules. Select relevant function to run a reset:

Reset All - This function enables the xture to index all effects and return to their standard positions.
Pan/Tilt - This function resets pan and tilt.
Colour System - This function resets colour wheel and CMY/conversion lter module.
Gobo System - This function resets both rotating gobo wheels 1 and 2.
Dimmer/Strobe - This function resets dimmer/strobe module.
Focus/Zoom/Frost - This function resets focus,zoom and frost.
Iris/Effect - This function resets iris and effect wheel.

9.9 Special functions

Use this menu for special services like adjusting lamp or adjusting effects.
Lamp Adjustment - This function can be used when you make the ne adjustment of the lamp. If you select this function,
all effects will be canceled, shutter will be opened and the dimmer intensity will be set onto 100%. By using the

options „PAn, Tilt, Zoom, Focus” you can focus the light on a at surface (wall) and perform the ne lamp
adjustment.
Effect Adjustment - By this function you can calibrate and adjust the effects to their standard/right positions. Disconnect
the DMX controller from the xture and select „DMX Values” menu. The display shows step by step effects by
which you can adjust the xture to the required position before the function calibration. When the positioning is
nished, select „Calibrate Values” and press [ENTER]:

1. Calibration via the control board

Select desired effect, press [ENTER] and adjust its right value (0 - 255). This can be repeated for each calibred effect if it
is required. When the calibration is nished, it is necessary to use the „Save and Reset” function to write the calibration
values to the memory and to make a reset in order to check the newly adjusted positions of the calibrated effects.

List of the calibrated effects:

Pan Yellow Gobo 2 Indexing
Tilt Conversion Filter Effect Wheel
Colour Wheel Gobo Wheel 1 Effect Indexing
Cyan Gobo 1 Indexing Iris
Magenta Gobo Wheel 2 Dimmer

32

33

2. Calibration via the DMX controller

Connect the DMX controller to the xture. Select desired effect and press [ENTER]. Now you can calibrate the selected
effect by your controller.
DMX calibration protocol for Mode 1and Mode 3 (24 control channels):

Pan ................... channel 25 Yellow ................... channel 30 Gobo 2 Indexing ..... channel 35

Tilt .................... channel 26 Conversion Filter ... channel 31 Effect Wheel ........... channel 36

Colour Wheel ... channel 27 Gobo Wheel 1 ....... channel 32 Effect Indexing ........ channel 37

Cyan ............. channel 28 Gobo 1 Indexing ....channel 33 Iris .......................... channel 38

Magenta ........ channel 29 Gobo Wheel 2 ....... channel 34 Dimmer ................... channel 39

DMX calibration protocol for Mode 2 (32 control channels):

Pan .................. channel 33 Yellow .................... channel 38 Gobo 2 Indexing ..... channel 43

Tilt .................... channel 34 Conversion Filter ... channel 39 Effect Wheel ........... channel 44

Colour Wheel ... channel 35 Gobo Wheel 1 ....... channel 40 Effect Indexing ........ channel 45

Cyan ................ channel 36 Gobo 1 Indexing .... channel 41 Iris ........................... channel 46

Magenta ........... channel 37 Gobo Wheel 2 ....... channel 42 Dimmer ................... channel 47

After having calibrated required effects ,use the „Save and Reset” function to write the calibration values to the memory
and to make a reset in order to check the newly adjusted positions of the calibrated effects.
Item „Load Default Values” enables to load default factory calibration values.

Updating software - This option is available in the xture with software version 3.0 or higher.Using this function you can
update software in the xture via PC and serial link.
The following are required in order to update software:

- PC running Windows 95/98/2000/XP or Linux

- DMX Software Uploader

- Flash cable RS232/DMX (No.13050624)

Note1:Software update should execute a qualied person.If you lack qualication, do not attempt the update
yourself and ask for help your ROBE distributor.

Note 2:DMX address, IP address ,programs 1-3 and all functions in menu Personality will be set to their default values.

To update software in the xture:

1.Installation of DMX Software Uploader.

1.DMX Software Uploader program is available from the ROBE web site at WWW.robe.cz.

2.Make a new directory ( e.g. Robe_Uploader) on your hard disk and download the software to it.

3.Unpack the program from the archive. Program le has name:DSU_name of corresponding
xture_SoftwareID.If the Robe xture is produced in magnetic and electronic ballast version, name
of DMX Software Uploader is the same for both versions.SoftwareID describes the versions of xture
software included in DMX Software Uploader. Higher number means later software versions.

2.Fixture software updating.

1.Determine which of your COM port is available on your PC and connect it with to the DMX input of the
xture using the Flash cable. Do not extend this cable! Disconnect the xture from the other xtures
in DMX chain! Turn on the computer and the xture. Make sure that the lamp is switched off.

2.Switch the xture to the update mode by selecting the option Updating Software in menu Special Functions
on the xture control panel.(From this option you cannot return back to the main menu. If you do not want to
continue in software update, you have to switch off and on the xture to leave this option!)

3.It is recommended that you exit all programs before running this Software Uploader.

4.Start the Software Uploader program. Select desired COM and then click Connect button.
If the conection is OK, click Start Uploading button to start uploading. It will take several minutes to perform
software update.If the option "Incremental Update"isn´t checked ,all processors will be updated (including
processors with the same software version).
If you wish to update only later versions of processors, enable the Incremental Update check box.
Avoid interrupting the process. Update status is being displayed in the list window.
When the update is nished, the line with the text “The xture is successfuly updated‘ will appear in this
window and the xture will reset with the new software.
Note: In the case of interruption of the upload process (e.g. power cut), the xture remains in the update mode and you
have to repeat the software update again.
For example: The xture was switched off before nishing software upload. After switching the xture on again, the xture
is still in the update mode and the display is dark. Restart the Software Uploader program and repeat software update
from your PC.

10. Low power mode

This mode omits xture reset after switching the xture on and lowers motor powers of the xture. „Low power mode” is
useful in special casech.g. if the xture is in a ight case and you want to set its DMX address without taking it out from
the case. To enter „Low power mode”:
Press and hold [ENTER] and at the same time switch on the Power switch. The following message appears:
Realy Skip Initial Reset?
Escape/Enter
Press [ENTER] to activate „Low power mode” without xture reset.Now you can set features and behaviour of the xture
by using „Fixture Address” menu and „Personality” menu.It is expected,that this mode will be exited by switching the xture

33

off, but if you want to go directly to „normal operation mode”, execute any xture reset.

Note: All motors in „Low power mode” are deactivated and switching the lamp on from the control panel is blocked.

11. Error and information messages

Occured errors during xture operation are signalized by warning icon on the display:

Press [ESC] to see the current error messages.

Description of the error messages:

Active Lamp Timer

This message appears if you try to switch on the lamp within 5 minutes after having switched it off (the lamp is too hot).
The message will appear on the display if the lamp doesn't ignite within 28 seconds. The ColorSpot 1200 AT will store
this information and automatically ignite the lamp when the 5 minutes period has expired.
Caution: The message is disabled if the lamp light sensor (function „Lamp Sensor” in menu Personality) is switched Off.

Lamp Error

The ignition of the lamp is seven times unsuccessful (the "Active Lamp Timer" message appeared six times before), and
the display shows "Lamp Error", meaning that the lamp could be damaged or even missed or there could be a failure on
the ignitor or ballast.
Please place or replace the lamp and contact your dealer if the situation was not caused by the lamp.
Caution: The message is disabled if the lamp light sensor (function „Lamp Sensor” in menu Personality) is switched off.

Overheated ->Lamp low

This message informs that the xture head is overheated and the lamp power was reduced to 700 W.After 10 minutes the
lamp power will be switched to the full power.

Overheated ->Lamp Off

This message informs that the xture head is overheated and the lamp was switched off by its temperature sensor.

Lamp Sensor Error

This message informs the lamp light sensor is failed.
Caution: The message is disabled if the lamp sensor (function Lamp Sensor in menu Personality) is switched Off.

Short Power Error

This message will appear if the xture was shortly disconnected from the main.

Supply Frequency Error

This message will appear if the frequency of the main is not standard 50 or 60 Hz.This message can appear as a result
of the interference during the lamp starting (if the lamp or igniter is old) or as a result of the interference by neighbouring
devices. In these cases the message does not affect the xture operating!

The following error messages are separated into 2 groups:

xxxx xxxx Error 1 (e.g. Colour Wheel Error 1, Gobo 2 Index Error 1)
xxxx xxxx Error 2 (e.g. Colour Wheel Error 2, Gobo 2 Index Error 2)

There are some possible reasons of faults:

Message Characteristic fault
xxxx xxxx Error 1 Magnetic sensor is permanently On (e.g. leading wire is short-

circulated,defective stepping motor, defective control circuit on the PCB)

xxxx xxxx Error 1/xxxx xxxx Error 2 Magnetic sensor is permanently Off (e.g. leading wire is disconnected,
(together) defective magnetic sensor, missing magnet), defective stepping motor.

Colour Wheel Error 1 (Colour Wheel Error 2)

The messages will appear after the reset of the colour wheel if this wheel is not located in the default position.

Gobo 1 Wheel Error 1 (Gobo 1 Wheel Error 2)

The messages will appear after the reset of the gobo wheel 1 if this wheel is not located in the default position.

34

35

Gobo 1 Index Error 1 (Gobo 1 Index Error 2)

The messages will appear after the reset of the gobo wheel 1 if the rotating gobo wheels are not located in the default
positions.

Gobo 2 Wheel Error 1 (Gobo 2 Wheel Error 2)

The messages will appear after the reset of the gobo wheel 2 if this wheel is not located in the default position.

Gobo 2 Index Error 1 (Gobo 2 Index Error 2)

The messages will appear after the reset of the gobo wheel 2 if the rotating gobo wheels are not located in the default
positions.

Effect Wheel Error 1 (Effect Wheel Error 2)

The messages will appear after the reset of the effect wheel if this wheel is not located in the default position.

Effect Index Error 1 (Effect Index Error 2)

The messages will appear after the reset of the effect wheel if the rotating effect wheels are not located in the default
positions.

Iris Error 1 (Iris Error 2)

The messages will appear after the reset of the iris if the iris lamellas are not located in the default positions.

Cyan Lamella Error 1 (Cyan Lamella Error 2)

The messages will appear after the reset of the CMY module if the cyan lamellas are not located in the default positions.

Magenta Lamella Error 1 (Magenta Lamella Error 2)

The messages will appear after the reset of the CMY module if the magenta lamellas are not located in the default positions.

Yellow Lamella Error 1 (Yellow Lamella Error 2)

The messages will appear after the reset of the CMY module if the yellow lamellas are not located in the default positions.

CTO Lamella Error 1 (CTO Lamella Error 2)

The messages will appear after the reset of the CTO module if the CTO lamellas are not located in the default positions.

Zoom Error 1 (Zoom Error 2)

The messages will appear after the reset of the zoom module if the module is not located in the default position.

Focus Error 1 (Focus Error 2)

The messages will appear after the reset of the focus module if the module is not located in the default position.

Pan Error 1 (Pan Error 2)

The messages will appear after the reset of the yoke if the yoke is not located in the default position.

Tilt Error 1 (Tilt Error 2)

The messages will appear after the reset of the head if the head is not located in the default position.

12. Technical specications

Power supply:

Magnetic ballast - ColorSpot 1200 AT:

Voltage: ........................................ 208/230/250V AC, 50/60Hz ~

Main fuses: Live fuse: ......... T10A@230V

Neutral fuse: .... T10A@230V

Electronic ballast - Colorspot 1200E AT:

Voltage: ....................................... 100/120/208/230/250V AC, 50/60Hz ~

Main fuses: Live fuse: ......... T10A@230V

Neutral fuse: .... T10A@230V

Live fuse: ......... T20A@120V

Neutral fuse: .... T20A@120V

Power consumption: ..................... 1600 VA

Lamp:

Philips MSR 1200 SA, base: GY22, colour temperature: 5600 K, average lamp life: 750 h

Optical System:

- High luminous-efciency parabolic reector

35

- Focus lens and multistep zoom lenses system

- Beam angle: 13°- 42°

- All lenses are anti-reection coated

CMY-colours mixing module

- Smooth CMY colour mixing system

- Colour temperature correction ltre lowers the colour temperature from 5600K to 3200 K

- 63 colour macros

Colour wheel

- 4 dichroic lters, UV lter, 6000K temp. lter plus white

- Colour wheel with variable rotation speed in both directions

- All colour-modules are interchangeable

- Random colour selection by audio control

- Auto random colour selection

Rotating gobo wheel 1

- 6 replaceable dichroic glass gobos plus an open position rotating in both directions at different speeds

- Fine gobo indexing and rotation

- Rotating gobo-wheel cont. rotation

- Shaking gobos with variable speed

- Random gobo selection by audio

- Auto random gobo selection

- Dichroic glass gobos: outside diameter= 37.3 mm, image diameter =31.5 mm,
high temperature borooat or better glass, thickness=1.1mm up to 5 mm, coating:
dichroic or enhanced aluminium

Rotating gobo wheel 2

- 6 replaceable gobos (1glass gobo,5 dicroic glass gobos plus an open position)
rotating in both directions at different speeds

- Fine gobo indexing and rotation

- Rotating gobo-wheel cont. rotation

- Shaking gobos with variable speed

- Random gobo selection by audio

- Auto random gobo selection

- Rotating gobo-wheel cont. rotation

- Dichroic glass gobos: outside diameter= 37.3 mm, maximum image diameter=31.5 mm,
high temperature borooat or better glass, thickness=1.1mm up to 5mm, coating:
dichroic or enhanced aluminium - Glass gobo: outside diameter= 37 mm,
high temperature borooat or better glass, thickness=1.1mm up to 5 mm

Effect wheel

- 3-facet prism, 5-facet prism and 2 glass effects rotating in both directions at different speeds.

- Prism outside diameter= 46,8 mm

- Fine prism indexing and rotation

-16 Prism/gobo macros

Strobe

- Strobe effect with variable speed (1 - 15 ashes per second)

- Preprogrammed macros with variable/random pulse effects

Dimmer

- Smooth micro-step driven dimming

Frost

- Separate variable frost for ne frosting

Focus/Zoom

- Remotely controllable motorized focus

- Motorized zoom with range 13°- 42°

Iris

- Motorized (steplessly adjustable) iris for different beam diameters

Motors

- 17 high quality stepping-motors controlled by microprocessors

36

37

Electronics

- control via control panel with graphic LCD display and 2 buttons/rotating wheel

- Readout xture and lamp usage,receiving DMX values, temperature, etc

- Built-in analyzer for easy fault nding,error messages

- Remotely switching on/off the lamp by DMX

- Bilt-in demo sequences

- Silent fans cooling

- Stand alone operation

- Self-resetable thermo-fuse

- Digital serial input DMX-512

- Ethernet connector

- Magnetic or electronics ballast

- 3 control-channels presettings (24 and 32 control channels)

Data input/output

- 3-pin and 5-pin XLR male sockets for DMX data input

- 3-pin and 5-pin XLR female sockets for DMX data output

- RJ- 45 male socket for Ethernet connection

Pan/Tilt

- Pan movement range 530°

- Tilt movement range 280°

- 16 bit movement resolution

- Automatic Pan/Tilt position correction

- Remotely controllable speed of Pan/Tilt movement for easy programming

- Maximum Pan movement 530° in 4,5 s

- Maximum Tilt movement 280° in 2,6 s

Rigging

- Stands directly on the oor

- Mounts horizontally or vertically with 2 clamps

- fastening of the clamp brackets in 4 positions

- Safety chain/cord attachment apertures

Bempath

Beam angle 13°- min. zoom

Beam angle 42° - max. zoom

Beam angle 13° with frost

Beam angle 42° with frost

Bam angle 13° with frost, distance=5 m Beam angle 42° with frost, distance=5 m

37

Tempeatures

- Maximum ambient temperature: 40° C

- Maximum housing temperature of the head: 130° C

Minimum distances

- Min. distance from ammable surfaces: 1.2 m

- Min. distance to lighted object: 2 m

Dimensions and weight

- Weight - Colorspot 1200 AT (magnetic ballast): 51,5 kg

- Weight - Colorspot 1200E AT (electronic ballast): 42 kg

Accessories:

Gobo-set 10 (No. 15050019) ....................................................... 1 piece

Mounting bracket Omega CL assembled (No. 99010420) .......... 2 pieces

Optional acesories:

Remote control IR (No. 13050419)
Flash Cable RS232/DMX (No. 13050624)

13. Maintenance and cleaning

It is absolutely essential that the xture is kept clean and that dust, dirt and smoke-uid residues must not build up on or
within the xture. Otherwise, the xture‘s light-output will be signicantly reduced. Regular cleaning will not only ensure the
maximum light-output, but will also allow the xture to function reliably throughout its life.
A soft lint-free cloth moistened with any good glass cleaning uid is recommended, under no circumstances should alcohol
or solvents be used!

DANGER ! Disconnect from the mains before starting any maintenance work

The front objective lens will require weekly cleaning as smoke-uid tends to building up residues, reducing the light-output
very quickly. The cooling-fans should be cleaned monthly.
The interior of the xture should be cleaned at least annually using a vacuum-cleaner or an air-jet.
Dichroic colour lters, CMY lamelas,gobo wheels and the internal lenses should be cleaned monthly.
Remove dust and dirt from the fans and cooling vents using a soft brush and vacuum-cleaner.

Important! Check the air lters periodically and clean before they become
clogged!

Clean the air lters from the front fans with a vacuum cleaner, compressed air or you can wash them and put back dry.

Replacing the air lters.

1)Disconect the xture from power.

2)Remove both top and bottom cover of the head (by loosening the 4 quarter-turn fasteners on each cover)

3)Remove the air lters (they are xed with a velcro fastener) from grids.

4)Clean or replace the air lters.

5)Place the lters on the grid and put head cover back.

6)Reset the elapsed time counter in menu Fixture information (Fixture Information--->Air Filters---> Elapsed
Time.

38

39

There are no serviceable parts inside the device except for the lamp and the main fuse.
For replacing lamp,please refer to the instructions under „Fitting/Exchanging the lamp”.

Replacing the fuse

If the lamp burns out, the ne-wire fuse of the device might fuse, too. Only replace the fuse by a fuse of the same type
and rating.
Before replacing the fuse, unplug mains lead.

Procedure:

1) Unscrew the fuseholder on the rear panel of the base with a tting screwdriver from the housing (anti-clockwise).

2) Remove the old fuse from the fuseholder.

3) Install the new fuse in the fuseholder.

4) Replace the fuseholder in the housing and x it.

More complicated maintenance and service operations are only to be carried out by authorized dealers.

grid

air lter

Velcro fastener

Specications are subject to change without notice.

39
