CD-650UMP/FM
Service Manual
Service Manual
Bill of Materials
NO ITEM CODE DESCRIPTION QTY SYMBOL
1 001-3300S-E20 P.C.B MAIN BOARD 1
2 001-0000S-B90 P.C.B FILTER BOX 1
3 002-0790R-H00 I.C DSC-790R 1 IC1
4 002-1923F-G07 I.C BU1923F 1 IC403
5 002-2313L-B00 I.C PT2313L 1 IC601
6 002-04558-G00 I.C TJM4558 2 IC3.2
7 002-01140-A09 I.C LA1140 1 U1
8 002-03370-A09 I.C LA3370 1 U2
9 002-07384-J06 I.C TDA7384 1 IC401
10 002-07035-T00 I.C KIA7035 1 Q30
11 002-78L05-F00 I.C KIA78L05 1 Q29
12 003-BD435-B00 TRANSISTOR-NPN TO-126 BD435 1 Q1
Q27.14.13.4.2.20.33.18.19.
13 003-3199Y-H03 TRANSISTOR C3199 NPN TO-92S 14
14 003-01303-D00 TRANSISTOR D1303 5 Q5.6.7.8.10
15 003-01368-C00 TRANSISTOR B1368 1 Q23
16 003-0966Y-A02 TRANSISTOR A966 1 Q11
17 003-1267Y-A00 TRANSISTOR KTA1267Y 2 Q3.9
18 003-1271Y-A03 TRANSISTOR A1271 1 Q34
19 003-3203Y-D03 TRANSISTOR C3203 2 Q26.15
17.21.12.24.25
20 003-01923-A00 TRANSISTOR C1923 1 Q16
21 004-04001-000 DIODE IN4001 1 FILTER BOX
D4.28.30.27.25.24.44.21.38.39.
22 004-04148-000 DIODE IN4148 21
23 005-00033-A00 ZENER DIODE 1/2W 3.3V 1 ZD10
9.10.11.5.16.3.41.6.33.23.8
PAGE 1 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
24 005-00039-A00 ZENER DIODE 1/2W 3.9V 1 ZD7
25 005-00051-A00 ZENER DIODE 1/2W 5.1V 4 ZD1.4.11.8
26 005-00056-A00 ZENER DIODE 1/2W 5.6V 1 ZD2
27 005-00075-A00 ZENER DIODE 1/2W 7.5V 1 ZD6
28 005-00100-A00 ZENER DIODE 1/2W 10V 2 ZD5.3
29 006-04330-000 CRYSTAL 4.33MHz 1 XT2
30 006-04500-000 CRYSTAL 4.5MHz 1 XT1
31 007-05046-7GY I.F.T 7x7mm K5046 GREY 1
32 009-0201V-A02 TUNER (FM) KCF-201V 1
33 010-A0222-000 CHOCK COIL 22mH 1 L1
34 011-A010F-200 RES 1/2W +-5% 1 OHM 1 R168
35 011-A100A-200 RES 1/16W +-5% 10 OHM 3 R116.75.98
36 011-A101A-200 RES 1/16W +-5% 100 OHM 4 R117.118.119.83
37 011-A102A-200 RES 1/16W +-5% 1K OHM 7 R32.37.38.88.135.81.122
R86.101.61.56.93.3.15.14.68.41.
94.70.46.47.48.49.76.78.104.77.
38 011-A103A-200 RES 1/16W +-5% 10K OHM 29
60.40.123.124.163.92.33.25.39
39 011-A104A-200 RES 1/16W +-5% 100K OHM 4 R136.139.97.99
40 011-A105A-200 RES 1/16W +-5% 1M OHM 2 R107.103
41 011-A123A-200 RES 1/16W +-5% 12K OHM 2 R43.44
42 011-A122A-200 RES 1/16W +-5% 1.2K OHM 2 R110.111
43 011-A152A-200 RES 1/16W +-5% 1.5K OHM 4 R85.87.79.82
44 011-A153A-200 RES 1/16W +-5% 15K OHM 2 R127.133
45 011-A151A-200 RES 1/16W +-5% 150 OHM 1 R80
46 011-A182A-200 RES 1/16W +-5% 1.8K OHM 1 R113
47 011-A181A-200 RES 1/16W +-5% 180 OHM 1 R53
48 011-A221A-200 RES 1/16W +-5% 220 OHM 1 R90
49 011-A222A-200 RES 1/16W +-5% 2.2K OHM 4 R125.126.59.6
50 011-A272A-200 RES 1/16W +-5% 2.7K OHM 1 R4
R130.134.42.137.96.
51 011-A223A-200 RES 1/16W +-5% 22K OHM 11
5.129.1.115.34.63
PAGE 2 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
52 011-A224A-200 RES 1/16W +-5% 220K OHM 1 R102
53 011-A330A-200 RES 1/16W +-5% 33 OHM 3 R120.7.121
54 011-A331A-200 RES 1/16W +-5% 330 OHM 3 R71.2.114
55 011-A332A-200 RES 1/16W +-5% 3.3K OHM 7 R112.9.11.10.8.66.13
56 011-A333A-200 RES 1/16W +-5% 33K OHM 1 R138
57 011-A393A-200 RES 1/16W +-5% 39K OHM 1 R128
58 011-A334A-200 RES 1/16W +-5% 330K OHM 2 R57.58
59 011-A470A-200 RES 1/16W +-5% 47 OHM 2 R17.18
60 011-A471A-200 RES 1/16W +-5% 470 OHM 2 R91.84
61 011-A472A-200 RES 1/16W +-5% 4.7K OHM 3 R54.132.16
R31.27.29.20.21.22.131.12.
62 011-A473A-200 RES 1/16W +-5% 47K OHM 17
106.24.69.65.64.89.28.73.74
63 011-A562A-200 RES 1/16W +-5% 5.6K OHM 7 R50.52.51.55.100.35.36
64 011-A561A-200 RES 1/16W +-5% 560 OHM 3 R95.105.72
65 011-A681A-200 RES 1/16W +-5% 680 OHM 1 R159
66 011-A822A-200 RES 1/16W +-5% 8.2K OHM 4 R26.30.19.23
67 011-A821A-200 RES 1/16W +-5% 820 OHM 2 R67.62
68 012-C107C-300 ELEC CAP 100uF 16V 5x11mm 9 C20.15.74.50.24.41.55.57.39
69 012-C105F-300 ELEC CAP 1uF 50V 5x11mm 11 C99.19.6.54.56.82.113.61.67.1.83
70 012-C106C-300 ELEC CAP 10uF 16V 5x11mm 3 C2.63.103
71 012-C335F-300 ELEC CAP 3.3uF 50V 5x11mm 2 C100.14
72 012-B224F-300 ELEC CAP 0.22uF 50V 4x7mm 1 C79
73 012-B474F-300 ELEC CAP 0.47uF 50V 4x7mm 4 C96.97.98.95
C33.34.105.47.48.51.42.53.49.
74 012-C475F-300 ELEC CAP 4.7uF 50V 5x11mm 18
64.32.31.27.123.124.28.29.75
75 012-C476C-300 ELEC CAP 47uF 16V 5x11mm 5 C81.94.86.35.70
76 012-J108C-300 ELEC CAP 1000uF 16V 10x16mm 1 C87
77 012-P108D-300 ELEC CAP 1000uF 25V 13x20mm 1 FILTER BOX
78 012-U228C-300 ELEC CAP 2200uF 16V 10x30mm 1 C62
79 013-A103A-400 MYLAR CAP +-10% 0.01uF 1 C78
80 013-A272A-400 MYLAR CAP +-10% 0.0027uF 2 C30.36
PAGE 3 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
81 013-B102A-400 POLY.CAP 1000PF 50V 1 C102
82 014-A102C-500 CRE CAP +-10% 0.001uF 50V 4 C80.58.77.59
83 014-A103C-500 CRE CAP +-10% 0.01uF 50V 5 C40.12.13.60.104
C112.114.69.111.89.71.18.110.21.
84 014-A104C-500 CRE CAP +-10% 0.1uF 50V 21
5.
85 014-A121C-500 CRE CAP +-10% 120PF 50V 4 C25.26.22.23
86 014-A473C-500 CRE CAP +-10% 0.047uF 50V 1 C9
87 014-A222C-500 CRE CAP +-10% 0.0022uF 50V 1 C16
88 014-A223C-500 CRE CAP +-10% 0.022uF 50V 9 C10.11.91.93.92.84.90.109.88
89 014-A150C-500 CRE CAP +-10% 15PF 50V 1 C106
90 014-A101C-500 CRE CAP +-10% 100PF 50V 2 C7.108
91 014-A271C-500 CRE CAP +-10% 270PF 50V 1 C17
92 014-A300C-500 CRE CAP +-10% 30PF 50V 4 C72.73.101.3
93 014-A561C-500 CRE CAP +-10% 560PF 50V 1 C68
94 016-C0300-000 TRIMMER CAP 30PF 1 C8
95 015-H0103-E00 SEMI-FIXED 10KB 1 L3
96 015-H0203-E00 SEMI-FIXED 20KB 1 L6
97 015-H0502-E00 SEMI-FIXED 50KB 1 L7
98 017-B0107-400 CER FILTER 10.7MJA 2 C76.4
99 022-C7000-000 FAUSE 7A 1
100 023-A0050-RD0 LED RED 5mm 1 D20
101 025-TA040-385 4P TACT SW 3.85mm 169G/F 1
102 029-B0000-000 ANTENNA JACK DOUBLE SCREW 1
103 033-S0800-BN0 28# 1P SHIELD 80mm 1
104 033-S1200-BN0 28# 1P SHIELD 120mm 1
105 034-A1612-006 I.S.O 16P W/WIRE 12P 1
106 034-A0808-105 I.S.O MAIN CON 8PIN WITH 8P WIRE 1
107 035-B0400-BK1 JUMPER WIRE #20 40mm BLACK 1
108 036-D0125-250 25P CONNECTOR PITCH P=1.25mm 1
109 036-J0250-120 DETACHABLE CON 12P SOCKET 1
PAGE 4 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
110 037-A5220-3B0 3PIN H'ING P=2.5mm #26 3x220mm 1
111 037-G0450-201 RCA 2xSH L=450mm Black W/O H'ING 1
112 037-G0300-203 RCA 2xSH L=300mm GREY W/O H'ING 1
113 042-30010-000 FUSE HOLDER 2
114 201-EI240-000 CHOKE TRANS EI-24 1
115 221-S0040-040 BARE WIRE D=0.4x40mm 70
116 230-100BK-100 PLASTICTIE L=100mm 2
117 231-P0060-130 RUBBER TUBE PVC D=13 L=60mm 1.0mm 1
FRONT PCB
118 001-3300D-S20 P.C.B FRONT BOARD 1
119 001-3990D-A60 P.C.B LED BOARD 1
120 002-75823-H00 I.C LC75823ED 1 U1
121 008-80235-C00 LCD DISPLAY 80235BMTTN 1
122 011-S000A-200 0805 RES CHIP +-5% 0 OHM 1 R33
123 011-S102A-200 0805 RES CHIP +-5% 1K OHM 2 R21.10
124 011-S122A-200 0805 RES CHIP +-5% 1.2K OHM 1 R14
125 011-S152A-200 0805 RES CHIP +-5% 1.5K OHM 2 R11.22
126 011-S181A-200 0805 RES CHIP +-5% 180 OHM 1 R5
127 011-S221A-200 0805 RES CHIP +-5% 220 OHM 2 R17.6 (3.044)
128 011-S222A-200 0805 RES CHIP +-5% 2.2K OHM 2 R23.12
129 011-S331A-200 0805 RES CHIP +-5% 330 OHM 2 R7.18
130 011-S332A-200 0805 RES CHIP +-5% 3.3K OHM 2 R13.24
131 011-S471A-200 0805 RES CHIP +-5% 470 OHM 2 R8.19
132 011-S472A-200 0805 RES CHIP +-5% 4.7K OHM 3 R30.25.31
133 011-S513A-200 0805 RES CHIP +-5% 51K OHM 1 R15
134 011-S681A-200 0805 RES CHIP +-5% 680 OHM 8 R27.28.9.2.1.20.4.29
135 011-S822A-200 0805 RES CHIP +-5% 8.2K OHM 1 R26
136 014-S104C-500 0805 CRE CAP +-10% 0.1uF 1 C1 (2.044)
137 014-S681C-500 0805 CRE CAP +-10% 680PF 1 C3
PAGE 5 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
138 023-D0000-BE0 0603 LED BJS170TS-JPH BLUE 10
SMD LED RF-WNA30TS-N WHITE
139 023-F2835-WE2
800-1000mcd 2.8x3.5x1.9
1
140 025-TA020-430 TACT SW 2P 4.3mm 180G 15
141 025-TA02S-430 TACT SW 2P 4.3mm SMD 180G 3
142 036-H0250-120 DETACHABLE CON 12P PLUG P=2.5mm 1
VOL 12mm Encoder Sw 30DET 15PUS
143 049-E1141-050
E1141A3A L=11.5mm
1
USB BOARD
144 001-3300D-C01 P.C.B USB BOARD 1
145 002-00720-H00 I.C TCC720C01T 1 U1
146 002-39010-G00 I.C ROM SST39VF010-90-4C-WH TSOP-28 1 U2
147 002-00043-G00 I.C CS43L43KZ 1 U4
148 002-28163-G00 I.C K4S281632D-TC75 128M SDRAM 1 U3
149 002-00331-C00 I.C R111N331B 1 U5
150 002-00251-C00 I.C R111N251B 1 U6
151 002-07029-C00 I.C KIA7029 1 NC3
152 003-02202-S00 TRANSISTOR SRA2202SF SMD 1 Q3
153 003-01304-S00 TRANSISTOR KTD-1304 SOT-23 SMD 2 Q1.2
154 005-00520-S00 CHIP DIODE MBR0520L 1 D2
155 006-12000-100 CRYSTAL 12MFFGLCA-39 (16PF) 1 Y1
156 011-B000A-200 0603 RES CHIP +-5% 0 OHM 2 R31.52
157 011-B100A-200 0603 RES CHIP +-5% 10 OHM 2 R45.46
158 011-B102A-200 0603 RES CHIP +-5% 1K OHM 2 R54.55
R16.17.18.24.8.9.10.11.12.
159 011-B103A-200 0603 RES CHIP +-5% 10K OHM 20
14.48.19.20.21.7.13.15.1.23.33
160 011-B104A-200 0603 RES CHIP +-5% 100K OHM 2 R41.34
161 011-B150A-200 0603 RES CHIP +-5% 15 OHM 1 R44
162 011-B152A-200 0603 RES CHIP +-5% 1.5K OHM 1 R40
163 011-B153A-200 0603 RES CHIP +-5% 15K OHM 2 R27.30
164 011-B220A-200 0603 RES CHIP +-5% 22 OHM 2 R28.29
165 011-B223A-200 0603 RES CHIP +-5% 22K OHM 1 R5
PAGE 6 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
166 011-B301A-200 0603 RES CHIP +-5% 300 OHM 1 R6
167 011-B331A-200 0603 RES CHIP +-5% 330 OHM 2 R2.3
168 011-B433A-200 0603 RES CHIP +-5% 43K OHM 1 R4
169 011-B472A-200 0603 RES CHIP +-5% 4.7K OHM 1 R42
170 011-B473A-200 0603 RES CHIP +-5% 47K OHM 5 R35.36.37.38.39
171 011-B512A-200 0603 RES CHIP +-5% 5.1K OHM 3 R49.50.51
172 011-B625A-200 0603 RES CHIP +-5% 6.2M OHM 1 R25
173 011-B822A-200 0603 RES CHIP +-5% 8.2K OHM 1 R26
174 013-D105J-50A Tantal Chip CAP 1uF 6.3V +-20% "A-Size" 2 TC7.6
175 013-D106J-50A Tantal Chip CAP 10uF 6.3V +-20% "A-Size" 3 BC27.TC1.2
176 013-D107M-50B Tantal Chip CAP 100uF 4V +-20% "B-Size" 1 TC9
177 013-D107M-50C Tantal Chip CAP 100uF 4V +-20% "C-Size" 2 TC4.5
178 013-D476M-50A Tantal Chip CAP 47uF 4V +-20% "A-Size" 3 TC11.10.8
179 014-B100C-500 CER CAP CHIP ±10% 0603 10PF 50V 1 C8
180 014-B101C-500 CER CAP CHIP ±10% 0603 100PF 50V 3 C4.5.BC34
R47.C1.7.5.BC19.20.24.17.18.22.4
. 28.31.30.32.29.33.2.5.3.7.13.25.
181 014-B104C-500 CER CAP CHIP ±10% 0603 0.1uF 50V 36
12.23.14.6.10.21.9.11.16.1.8.15.26
182 014-B105C-500 CER CAP CHIP ±10% 0603 105PF 50V 1 C6
183 014-B390C-500 CER CAP CHIP ±10% 0603 39PF 50V 1 C2
184 014-B681C-500 CER CAP CHIP ±10% 0603 680PF 50V 1 C3
185 023-B0234-RG0 LED 2x3x4 MSGB75W (RED+GREEN) 1 SW1
186 025-PS22A-250 PUSH SLIDE SWITCH (2P2T) PS-22E50L 1 D1
TACT SW ANGLE TYPE 4.3mm HCT-1112A
187 025-TA02D-430
SMD 3 S1.2.3
188 029-F0836-00C USB 4P SOCKET 1 J1
189 036-K0250-090 9Pin P=2.5mm PCB Connector Right Angle 1 CN1
190 057-121T0-S02 BEAD CHIP 0603 FCM1608K-121T02 6 BD5.6.4.2.3.1
191 057-102T0-S02 BEAD CHIP 0603 FCM1608K-102T02 7 BD11.12.13.9.10.7.8
192 062-33000-000 USB DRIVER 64MB 1 成品USB
CDP BOARD
PAGE 7 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
193 001-7806D-C20 P.C.B CDP BOARD MP3 1
194 002-0016M-P00 I.C 16M DRAM 1 U5
195 002-09226-S01 I.C SIL9226X 1
196 002-09276-H00 I.C S5L9276 1
197 002-09290-G01 I.C S5L9290 1
198 002-04001-A01 I.C KA9259D/IP4001 1
199 003-01504-B03 TRANSISTOR KTA1504S GR (SMD) 1 Q1
200 003-01576-S07 TRANSISTOR 2SA1576 SMD 5 Q2.5.6.3.4
201 004-04148-000 DIODE IN4148 5 D3.4.5.1.2
202 004-SR23G-000 PHOTO DIODE SR-23G 2 LED3.4
203 006-16934-000 CRYSTAL 16.9344MHz (2PIN) 1 晶振
204 011-S000A-200 RES CHIP ±5% 0805 0 OHM 1 R112
R127.111.56.113.114.
205 011-S102A-200 RES CHIP ±5% 0805 1K OHM 9
115.102.101.116
R125.124.105.107.106.219.129.13
206 011-S103A-200 RES CHIP ±5% 0805 10K OHM 8
0
R103.104.218.220.
207 011-S104A-200 RES CHIP ±5% 0805 100K OHM 8
228.223.226.227
208 011-S105A-200 RES CHIP ±5% 0805 1M OHM 5 R1.117.118.27.215
209 011-S124A-200 RES CHIP ±5% 0805 120K OHM 2 R202.207
210 011-S153A-200 RES CHIP ±5% 0805 15K OHM 4 R213.212.209.221
211 011-S151A-200 RES CHIP ±5% 0805 150 OHM 1 R34
212 011-S184A-200 RES CHIP ±5% 0805 180K OHM 1 R211
213 011-S203A-200 RES CHIP ±5% 0805 20K OHM 1 R216
214 011-S204A-200 RES CHIP ±5% 0805 200K OHM 1 R126
215 011-S220A-200 RES CHIP ±5% 0805 22 OHM 1 R201
216 011-S222A-200 RES CHIP ±5% 0805 2.2K OHM 5 R119.120.121.122.123
217 011-S392A-200 RES CHIP ±5% 0805 3.9K OHM 1 R210
218 011-S473A-200 RES CHIP ±5% 0805 47K OHM 4 R131.222.217.128
219 011-S683A-200 RES CHIP ±5% 0805 68K OHM 5 R204.206.203.205.225
220 011-S820A-200 RES CHIP ±5% 0805 82 OHM 1 R208
221 011-S822A-200 RES CHIP ±5% 0805 8.2K OHM 1 R214
PAGE 8 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
222 011-S913A-200 RES CHIP ±5% 0805 91K OHM 1 R224
223 012-1107B-300 ELECT CAP 100uF 10V +-20% 5x7mm 3 C102.1.124
224 013-D106L-50A Tantal Chip CAP 10uF 10V ±20% "A-Size" 6 C109.110.211.222.?.?
225 013-D476L-50B Tantal Chip CAP 47uF 10V ±20% "B-Size" 2 Q7.C202
226 014-S050C-500 CER CAP CHIP ±10% 0805 5PF 50V 1 C208
227 014-S102C-500 CER CAP CHIP ±10% 0805 0.001uF 50V 4 C205.210.121.201
228 014-S103C-500 CER CAP CHIP ±10% 0805 0.01uF 50V 6 C206.204.216.221.220.108
C123.113.112.114.53.203.234.
229 014-S104C-500 CER CAP CHIP ±10% 0805 0.1uF 50V 19
214.215.212.229.228.115.104.
230 014-S152C-500 CER CAP CHIP ±10% 0805 0.0015uF 50V 2 C111.112
231 014-S222C-500 CER CAP CHIP ±10% 0805 0.0022uF 50V 4 C101.107.213.226
232 014-S330C-500 CER CAP CHIP ±10% 0805 33PF 50V 2 C117.118
233 014-S333C-500 CER CAP CHIP ±10% 0805 0.033uF 50V 2 C230.217
234 014-S391C-500 CER CAP CHIP ±10% 0805 390PF 50V 2 C225.227
235 014-S472C-500 CER CAP CHIP ±10% 0805 0.0047uF 50V 2 C209.233
236 014-S474C-500 CER CAP CHIP ±10% 0805 0.47uF 50V 2 C218.219
237 014-S560C-500 CER CAP CHIP ±10% 0805 56PF 50V 1 C231
238 014-S683C-500 CER CAP CHIP ±10% 0805 0.068uF 50V 1 C223
239 014-S821C-500 CER CAP CHIP ±10% 0805 820PF 50V 1 C119
240 025-TA020-330 SWITCH 2P 3.3mm SW-111 HC-49S 1 SW1 (small type)
241 031-0140U-250 FFC CABLE 25P 140mm 1.25P ITCH 1 140mm
242 032-E1000-031 RAINBOW WIRE 3P 1 3+100+3
243 036-B0200-041 4P SOCKET 53015-0410 (ROHM) 1 J4
244 036-G0100-171 17P SMD SOCKET P=1.0mm 1 J1
245 203-8008S-C2E CD DECK CDM-211 1
246 209-11880-K00 RELEASE SPRING 1
247 209-39870-T00 PUSH SPRING 1 SUS T0.35
248 209-30910-V00 HOOK-SPRING 1 SUS T=0.4
249 212-52090-14S SPRING WASHER (Ф5.2) 2 ACC:2
PAGE 9 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
250 212-52100-05P PLATE WASHER (Ф5.2) 2 ACC:2
251 214-18880-C00 MAIN FIBER 1 FIBER T0.5
252 214-DECK0-A00 CD FIBER 105x95x0.5mm 1 FOR CD KMC DECK
253 216-3909H-C00 HEAT-SINK 1 AL DIE CASTING
254 216-3300B-C00 HEAT SINK-S 1 AL WHITE
255 217-1001E-E12 MOUNTING STRIP 1 EGI T1.2
AL T=0.5 FOR REMOTE
256 217-3300K-C05 AL-ORNAMENT 0
VERSION
257 217-3300P-C05 AL-ORNAMENT 1 AL T=0.5
258 218-3300C-E10 DECK-BRACKET-F 1 EGI T=1.0
259 218-3300L-E10 DECK-BRACKET-L 1 EGI T=1.0
260 218-3300R-E10 DECK-BRACKET-R 1 EGI T=1.0
261 218-3909R-E10 REAR-BRACKET 1 EGI T=1.0mm
262 222-3896S-E06 SLEEVE-CASE-3896 1 EGI T=0.6mm
263 222-3300T-E06 TOP-COVR 1 EGI T=0.6
264 222-3501B-H06 BOTTOM COVER A/R 1 EGI T0.6
265 222-3888R-E10 SIDE CHASSIS "R" 1 EGI T1.0
266 223-3300L-E10 SIDE-CHASSIS-L 1 EGI T=1.0
267 225-09007-400 CUSHION BOTTOM 3
268 225-38970-A00 RUBBER-BAND 1 RUBBER BLACK (049)
269 227-78030-EA5 CASE CUSHION (BLACK) (WITH STIKER TAPE) 1 SPONGE T=15mm
270 228-3888A-000 CD FELT 1 CLOTH BLACK
271 228-3896D-000 DUSTPROOF-FABRIC 1
272 230-100WE-200 WIRE CLIP 2
273 233-N050W-H00 HEX NUT: M5 1 ACC:1
274 234-BMT20-040 SCREW: TTP 2x4 BM TAP TYPE 4 SUB PCB:4
275 234-HEX50-120 HEX BOLT: 5x12mm 1 SET:1
276 234-MS030-050 SCREW: MS 3x5 (5.5x1x5) 4 BASE PANEL:4
277 234-PA020-10B SCREW: TS 2x10 PA BLACK 4 NOSE PIECE N-PIECE BACK:4
278 234-PA050-160 SCREW: TS 5x16 PA 1 ACC:1
PAGE 10 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
279 234-PB017-040 SCREW: TS 1.7x4 PB 2 USB-REFLECTOR:2
280 234-PT026-040 SCREW: TS 2.6x4 TAP TYPE 5 DECK BRT:5
281 234-PT030-040 SCREW: TS 3x6 TTP 1 IC:1
DECK BKT+HEAT SINK:3
282 234-PT030-050 SCREW: TS 3x5 TAP TYPE C 7
MAIN/PCB:4
283 234-PT030-080 SCREW: TS 3x8 TAP TYPE C 2 HEAT-SINK/REAR:2
284 234-PT030-100 SCREW: TS 3x10 TTP 1 HEAT-SINK:1
285 234-PT030-130 SCREW: MS 3x13 TTP 2 HEAT-SINK:2
ANTENNA/JACK:2 DECK
286 234-PTT30-050 SCREW: TS 3x5 TAP TYPE B 7
BKT+HEAT SINK:1
287 234-PTT30-080 SCREW: TS 3x8 TAP TYPE B 2 CORD CLAMPER:2
288 235-38960-E10 SET KEY 2 EGI T=1.0mm
289 236-65220-E10 CORD CLAMER (B) 1 EGI T1.0 (LINE OUT)
290 301-0C025-060 POLY BAG 1 OPEN 2.5"x6"XT0.04
291 301-0C070-105 POLY BAG 1 OPEN 7"x10.5"XT0.05
292 301-0C110-140 POLY BAG 1 OPEN 11"x14"XTo.04
293 301-0C040-090 POLY BAG 1 OPEN 4x9xT0.04
294 303-0000A-A10 POLYFOAM BOX 2
295 304-3300A-A10 GIFT BOX 1
296 305-3300A-A10 INSTRUCTION MANUAL 1
297 306-33000-A00 CARTON BOX 1/6 1
298 313-38880-A00 P.V.C CD GUIDE SHEET BLACK 1 T1.0
299 313-38960-Q00 VFD-SIDE-COVER-L 1 PVC T=0.3 BLACK
300 313-38960-R00 VFD-SIDE-COVER-W 2 PVC T=0.3 BLACK
301 316-WE142-044 SIDE-REFLECTIONAL-PAPER 2 GLOSS SILVER
302 314-3300A-000 AZIMUTH LABEL 0
303 314-3300T-000 TOP LABEL 1
304 314-3300W-000 WARRANTY LABEL 1
305 315-33000-A00 LCD-FILTER 1 DRAW PAPER T=0.1
306 315-33000-B00 LED-SIDE-COVER 1 REFLECTOR-PAPER
REFLECTOR PAPER WHITE
307 315-33000-CWE REFLECTOR-PAPER 1
T=0.1
PAGE 11 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
308 315-33000-DWE REFLECTOR-PAPER 2 REFLECTOR PAPER T=0.1
309 315-33000-EWE KNOB-FILT-PAPER 2 WHITE PAPER T=0.1mm
310 319-00000-010 SILICA GEL 1 PACK 1GM
INSTALL CD-ROM (8CM)
311 322-33000-000
FOR USB FLASH MEMORY DRIVER
1
312 402-3300A-1BK BASE-PANEL 1 ABS BLACK
313 402-3300B-1BK NOSE-PIECE 1 ABS BLACK
314 402-3300C-1BK NOSE-PIECE-BACK 1 ABS BLACK
315 402-7803S-4BK NOSE PIECE CASE 1 PP BLACK
316 413-3300A-2CR WINDOW 1 ACRYL CLEAR
ACRYL (SKY BLUE) FOR
317 413-3300D-2SE SENSOR-LENS 1
REOMTE ONLY
318 414-33001-2SE REFLECTOR-CIRCLE 1 ACRYL (SKY BLUE)
319 414-3300L-2CR EQ-BAND-SOURCE-KNOB-REFLECTOR 1 ACRYL CLEAR
320 414-3300P-2CR LCD-REFLECTOR 1 ACRYL CLEAR
321 414-3300R-2CR EJ-TA-AF-KNOB-REFLECTOR 1 ACRY CLEAR
322 414-3300T-2CR USB-REFLECTOR 1 ACRY CLEAR
323 414-3300V-2CR MEMERY-KNOB-REFLECTOR 1 ACRY CLEAR
324 419-3300A-INL REW-KNOB 1 ABS NATURAL
325 425-3300A-2SE EQ-KNOB 1 ACRYL (SKY BLUE)
326 425-3300B-3WR EQ-SOURCE-KNOB-BASE 1 PC ( WHITE CLEAR)
327 426-3987A-3BK PUSH-KNOB 1 PC BLACK
328 427-3300A-1NL PWR-KNOB 1 ABS NATURAL
329 427-3300B-3CR PWR-BAND-KNOB-BASE 1 PC CLEAR
330 428-7801C-1BK VOLUME-KNOB 1 ABS (BLACK D.CR)
331 430-3300A-2SE EJ-KNOB 1 ACRYL (SKY BLUE)
332 430-3300B-3WR EJ-AF-KNOB-BASE 1 PC (WHITE CLEAR)
333 431-33001-1NL MEMERY-KNOB-1 1 ABS NATURAL
334 431-33002-1NL MEMERY-KNOB-2 1 ABS NATURAL
335 431-33003-1NL MEMERY-KNOB-3 1 ABS NATURAL
336 431-33004-1NL MEMERY-KNOB-4 1 ABS NATURAL
PAGE 12 OF 13
NO ITEM CODE DESCRIPTION QTY SYMBOL
337 431-33005-1NL MEMERY-KNOB-5 1 ABS NATURAL
338 431-33006-1NL MEMERY-KNOB-6 1 ABS NATURAL
339 431-3300B-3CR MEMERY-A-PS-KNOB-BASE 1 PC CLEAR
340 439-3300A-1NL RELEASE-KNOB 1 ABS NATURAL
341 440-3987A-3BK HOOK 1 PC BLACK
342 441-3989A-1BK TRIM COVER 1 ABS BLACK
343 442-3300A-1NL A/PS-KNOB 1 ABS NATURAL
344 446-3300A-1NL TA-KNOB 1 ABS NATURAL
345 446-3300B-3CR TA-KNOB-BASE 1 PC CLEAR
346 446-3300C-2SE AF-KNOB 1 ACRYL (SKY BLUE)
ABS NATURAL
347 457-3300A-1NL TRACK-UP-KNOB 2
(PTY/KNOB:1 TRACK/UP/KNOB)
348 457-3300B-3CR TRACK-UP-DOWN-KNOB-BASE 1 PC CLEAR
ABS NATURAL(TRACK/DOWN:1
349 457-3300C-1NL TRACK-DOWN-KNOB 2
ST/KNOB:1
ABS BLACK (SILVER-HOT
350 495-0000R-000 ROADSTAR BADGE 1
STAMPING)
351 463-0000C-4BK FILTER & FUSE BOX 1 P.P BLACK
352 472-6522B-3BK CONNECTOR GUIDE 1 PC BLACK
353 492-3300A-1NL PLAY-STOP-KNOB 1 ABS NATURAL
354 492-3300B-3CR PLAY-FF-REW-KNOB-BASE 1 PC CLEAR
355 493-3300A-2SE SOURCE-KNOB 1 ACRYL (SKY BLUE)
356 511-3300A-1NL LINE-USB-KNOB 1 ABS NATURAL
PAGE 13 OF 13
Loading...
