BT-1_RS232 turn bluetooth adapter, FCC ID: 2ANPBBT-1A0
Indicator light
State
Explain
Link indicator light
Red blink
In the communication
Put out
Waiting for
Communication status indicator light
Type
Communication line
Mounting holes
Products introduction
BT-1 is a suitable for our company solar controller extend bluetooth
communication function of the bluetooth module, cooperate with mobile
phone APP can be realized on the system of wireless monitoring, parameters
setting and data view.
Main feature:
1. Realize the solar controller of wireless monitoring function
2. Support mobile phone APP, plug and play, simple setting
3. The use of high performance, low power consumption of the bluetooth
special chip
4. Adopt bluetooth 4.0 and BLE technology, has the characteristics of rapid
communication and strong anti-jamming capability
5. Without external power supply, power supply directly by the
communication port
6. Communication distance of up to 15 meters
Products features
1) COM: RS232 port (RJ12),used to connect with RS232 communication bus
of the solar controller
2) Link: communication status indicator light
Indicator light instruction:
System wiring diagram:
Note: Cable using the standard Ethernet cable (parallel line) connect.
Applicable types
Apply series
The company all controller with RS232 port
Communication
methods
RS232
controller port
RJ12
Type
BT-1
Input voltage
5V-12V
Communication
distance
≤15m
Serial port baud rate
Fixed baud rate 9600bps
Communication
methods
RS232
Interface type
RJ12
Connecting line
Standard Ethernet cable(parallel line)
Size
66*51*15.5mm
Installation dimension
57.5,φ3.2mm
Operating temperature
-20℃-75℃
Level of protection
IP67
Net weight
120g
FCC warnings:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This modular complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Technical parameters
If there are any changes, without further notice.
Mobile terminal bluetooth software download path:
1. In our company website to download: service support—download center—
bluetooth apps, can sweep the code download to mobile phone client and can
also be download to the client computer.
2. Mobile application download: input “SRNE” search to “Solar app” in the
APP store, APP download can be achieved.
The administrator password of apps: 135790123
