RM Italy KL-300 Schematics

40045 Ponte della Venturina (BO) ITALY

Costruzioni Elettroniche

di Marchioni Davide & Daniele s.n.c.

Mod. KL 300 linear amplifier

Via IV Novembre 215/5

Casella postale N° 33

Tel [phone]

Fax [phone]

E-MAIL [e-mail]

http://www.rmitaly.com

Schematic diagram

V ersion 4.10

date 22-02-2005 Page 1 di 2

List of components

C 1 = 33 pF 50 V N750
C 3 = 8,2 pF 50 V N750
C 8 = 10 nF 50 V
C 9 = 4,7 µF 16 V

10 = 33 µF 16 V

C
C

12 = 150 pF 50 V N750

C 13 = 47 nF 50 V
C 14 = 180 pF 500 V N750
C 15 = 47 nF 50 V

16 = 180 pF 500 V N750

C
C

17 = 2 x 220 + 270 pF 500 V N750

C 18 = 47 pF 1000 V N750
C 19 = 100 nF 50 V
C 20 = 100 nF 50 V
C 21 = 470 µF 25V
C 22 = 100 nF 50 V
C 23 = 470 nF 63 V Polyester
C 24 = 100 nF 50 V
R 1 = 2,2 KΩ ¼W
R 4 = 27 Ω 2W
R 5 = 180 Ω 2W
R 6 = 10 Ω ½W
R 7 = 68 Ω 2W
R 8 = 10 Ω ½W
R 9 = 68 Ω 2W
R 10 = 1,0 KΩ ¼W
D 3 = 1N4148
D 4 = 1N4148
D 6 = 1N4007
D 7 = 1N5400
Tr1 = BC 547
Tr4 = SD 1446
Tr5 = SD 1446
L 5 = VK 200 2 Wires
T 1 = Input Transformer
T 2 = Output Transformer
Rl2 = Relè 12 V 3022

Mod KL 300 4.10

date 22-02-2005 Page 2 di 2
