RM Italy BLA600 Input Voltage and Fuse Information

RM Italy BLA-600

Disassembly Procedure

With a TORX (TX10) screwdriver unscrew the right had
side screw underneath the warranty seal.

With a TORX (TX10) screwdriver, unscrew the left hand
screw near the AC input connector.

Pull out the panel to extract the voltage change system
with the corresponding cables.

With pliers, remove all the numbered cables from the
panel. Do not pull the cables to disconnect the
connector.

At this point you should find the panel as in the
picture. Now you are ready to set the AC input voltage
of the amplifier.

RM Italy BLA-600

115VAC Setup

At this point you should find the panel as in the photo.
Now you are ready to set the AC input voltage of the
amplifier.

Connect cable "1" to one of the spade lugs labelled "A"
Connect cable "2" to one of the spade lugs labelled "D"

Connect cable "3" to one of the spade lugs labelled "A"
Connect cable "4" to one of the spade lugs labelled "D"

Connect cable "5" to one of the spade lugs labelled "B"
Connect cable "6" to one of the spade lugs labelled "C"

RM Italy BLA-600

230VAC Setup

At this point you should find the panel as in the photo.
Now you are ready to set the AC input voltage of the
amplifier.

Connect cable "1" to one of the spade lugs labelled "A"
Connect cable "2" to one of the spade lugs labelled "B"

Connect cable "3" to one of the spade lugs labelled "B"
Connect cable "4" to one of the spade lugs labelled "D"

Connect cable "5" to one of the spade lugs labelled "C"
Connect cable "6" to one of the spade lugs labelled "D"

RM Italy BLA-600

240VAC Setup

At this point you should find the panel as in the photo.
Now you are ready to set the AC input voltage of the
amplifier.

Connect cable "1" to one of the spade lugs labelled "A"
Connect cable "2" to one of the spade lugs labelled "B"

Connect cable "3" to one of the spade lugs labelled "B"
Connect cable "4" to one of the spade lugs labelled "C"

Connect cable "5" to one of the spade lugs labelled "C"
Connect cable "6" to one of the spade lugs labelled "D"

Supply Voltage 50/60 Hz 1200VA max

120 Vac +/- 5%

230 Vac +6%, -10%

240 Vac +10%, -6%

AC Input Fuse 5 x 20 mm F LBC 250V (Fast Blow)

115 Vac Supply 10A

230 Vac Supply 6A

240 Vac Supply 5A

RM Italy BLA-600

Supply Voltage and Fuse Information

Supply Voltage information:

When making a change to the input voltage, the input Fuse must also be changed:

RM Italy BLA-600 Input Voltage Set Up and Voltage/Fuse Information

Courtesy of DX Engineering - 16 August 2018
