RKI Instruments 65-2405RK-04 User manual

Combustible Gas Transmitter

Part Number: 71-0280RK
Revision: P1

65-2405RK-04

Operator’s Manual

Released: 5/30/13

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

WARNING

Read and understand this instruction manual before
operating transmitter. Improper use of the transmitter could
result in bodily harm or death.

Periodic calibration and maintenance of the transmitter is
essential for proper operation and correct readings. Please
calibrate and maintain this transmitter regularly! Frequency
of calibration depends upon the type of use you have and
the sensor types. Typical calibration frequencies for most
applications are between 3 and 6 months, but can be
required more often or less often based on your usage.

65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Product Warranty

RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in
materials, workmanship, and performance for a period of one year fr o m date of shipment
from RKI Instruments, Inc. Any parts found defective within that period will be repaired
or replaced, at our option, free of charge. This warranty does not apply to those items
which by their nature are subject to deterioration or consumption in no r mal service, and
which must be cleaned, repaired, or replaced on a routine basis. Examples of such items
are:

W arranty is voided by abuse including mechanical damage, alteration, rough handling, or
repair procedures not in accordance with th e operator’s manual. This warranty indicates
the full extent of our liability , a nd we are not responsible for r emoval or replacement costs,
local repair costs, transportation costs, or contingent expenses incurred without our prior
approval.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER
WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED,
AND ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF
RKI INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO, THE
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL RKI INSTRUMENTS,
INC. BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
LOSS OR DAMAGE OF ANY KIND CONNECTED WITH THE USE OF
ITS PRODUCTS OR FAILURE OF ITS PRODUCTS TO FUNCTION OR
OPERATE PROPERLY.

a) Absorbent cartridges d) Batteries
b) Pump diaphragms and valves e) Filter elements
c) Fuses

This warranty covers instruments and parts sold to users by authorized distributors,
dealers, and representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for a ny accident or damage ca u s e d by the operation of
this gas monitor, and our warranty is limited to the replacement of parts or our complete
goods.

65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Table of Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Combustible Gas Detector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Calibration Cup/Splash Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Amplifier Junction Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Detector Junction Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Mounting the Combustible Gas Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Wiring the Detector to the Amplifier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Wiring the Amplifier to a Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the Zero Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Replacing Components of the Combustible Gas Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Determining Response Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Preparing for Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the Zero Reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the Response Reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Returning to Normal Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Overview

This manual describes the 65-2405RK-04 combustible gas transm itter. This manual also
describes how to install, start up, configure, maintain, and calibrate the transmitter w hen
it is used with a gas monitoring controller. A parts list at the end of this manual lists
replacement parts and accessories for the combustible gas transmitter.

Specifications

Table 1 lists specification s for the combustible gas transmitter.

Table 1:Specifications

Description Specification

Target Gas Methane (CH

Area Classification Explosionproof for Class I, Groups B, C, and D
Sampling Method Diffusion
Signal Output 4 to 20 mA
Detection Range 0 to 100% LEL
Response Time 90% in 45 seconds
Operating Temperature -4°F to 122°F (-20°C to 50°C)
Accuracy ± 5% of readin g or ± 2% of full scale (whichever is greater)

)

4

WARNING: When using the 65-2405RK-04, you must follow the instructions and

warnings in this manual to assure proper and safe operation of the
65-2405RK-04 and to minimize the risk of personal injury. Be sure to
maintain and periodically calibrate the 65-2405RK-04 as described in this
manual.

65-2405RK-04 Combustible Gas Transmitter • 1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Description

Controller Term inal
Strip

Amplif ier

LEL PWR / SIG

G

S2 00 1

S

57-105 3RK

BR W

Combustible G as Detector

Amp lifie r J-Box

DetectorJ-Box

Terminal Strip

Jumper Pi n s,

Facto ry Use

Only

Factory Adjust

Pot

Factory Adjust P ot

Span Pot

Zero Pot

SPAN

ZERO

Sensor

Current

m A

+ Test Point

- TestPoint
DetectorTerminal

Strip

Calibration Cup/S plash Guard

This section describes the components of the combustible gas transmitter. The transmitter
is a 4 - 20 mA type detector head. It consists of the combustible gas detector, calibration
cup/splash guard, amplifier, the amplifier junction box, and the detector junction box.
The two junction box configuration is intended for situations where the detector needs to
be installed at an inaccessible location. The detector junctio n box can be installed at the
inaccessible location and the amplif ier junction box can be installed in a more readily
accessible area.

Figure 1: Combustible Gas Transmitter Component Location

2 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Combustible Gas Detector

The combustible gas detector is a catalytic type detector that produces an electrical output
that corresponds to the detection range. It is packaged in a 1/2 inch NPT nipple with a
sintered metal flame arrestor on one end allowing ambient air to diffuse into the detector.
The flame arrest or al so co ntai n s any s park s whi ch may occur within the detector. The 1/2
inch NPT mounting threads at the top of the detector allow you to mount it into the
bottom conduit hub of the junction box. A rainshield screws onto the bottom of the
detector (flame arrestor end). The rainshield helps protect the detector from rain and
debris in the monitoring environment. Four color-coded leads extend from the top of the
detector. The lea ds allow you to connect the detector to the amplifier.

Calibration Cup/Splash Guard

A calibration cup/splash guard is installed on the rain shield of the combustible gas
detector. A fitt ing at the bottom of the calibration cup/splash guard allows a length of
tubing to be connected for calibration and routed to a more easily accessible location. The
calibration cup/splash guard also protects the detector.

Amplifier

The amplifier is located in the amplifier junction box. The amplifier converts the electrical
output from the detector to a 4 to 20 mA signal that corresponds to the detection range
and transmits the signal to a gas monitoring controller. A foam gasket that ori ents the
amplifier and keeps it from rotating is installed on the bottom of the am plifier. A label on
the amplifier indicates the detector drive current. This drive current is factory set and is
dictated by the combustible gas to which the detector is calibrated. Consult RKI
Instruments, Inc. if you plan to change the calibration gas for the transmitter, for example
from a methane calibration to a hexane calibration. The amplifier includes the detector
terminal strip, controller terminal strip, span pot, zero pot, and test points (see Figure 1).

Controller Terminal Strip

The controller terminal strip is a three position plug-in style terminal strip located near the
top of the amplifier. Use the controller terminal strip to wire the combustible gas
transmitter to a controller.

Detector Terminal Strip

The detector terminal strip is a four position plug-in style terminal strip located below the
controller terminal strip. Use the detector terminal strip to connect the combustible gas
detector to the amplifier.

NOTE: See “Wiring the Detector to the Amplifier” on page 6 for all wiring procedures

related to the transmitter.

Zero Pot

The zero pot is located in the upper left corner of the amplifier (see Figure 1). Use a small
flat blade screwdriver to turn the zero pot’s adjustment screw and ad just the amplifier’s
zero (fresh air) output during the start-up and calibration pro cedures. Turn the adjust­ment screw clockwise to increase the zero output and counterclockwise to decrease the
zero output.

Span Pot

The span pot is located to the right of the zero pot (see Figure 1). Use a small flat blade
screwdriver to turn the span pot’s adjustment screw and adjust the amplifier’s gas
response output during the calibration procedure. Turn the adjustment screw clockwise to

65-2405RK-04 Combustible Gas Transmitter • 3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

increase the gas response and counterclockwise to decrease the gas response.

CAUTION: The amplifier includes two additional potentiometers. They are factory-set. Do not

adjust them.

Test Points

The test points are on the left side of the amplifier (see Figure 1). The test points produce a
100 mV to 500 mV output that corresponds to the transmitter’s 4 to 20 mA output. Use the
test points and a voltmeter to measure the amplifier’s output during the start-up and
calibration procedures. The black test point in the lower left corner is the negative (-) test
point and the red test point below the zero pot is the positive (+) test point.

Amplifier Junction Box

The amplifier junction box protects the amplifier and wiring connections made to the
amplifier. Use the top 3/4’’ conduit hub to connect wiring from the amplifier to the
controller. Use the bottom 3/4” conduit hub to wire the remotely installed combustible
gas detector. Use the cover on the front of the junction box to access the interior of the
junction box. The amplifier is factory installed in the junction box. Th ree spacers installed
on the back of the junction box controls the distance of the junction box from a mounting
surface.

Detector Junction Box

The detector junction box is intended to be installed remotely from the amplifier junction
box. The combustible gas detector is factory installed in the bottom 3/4” conduit hub. A
terminal strip is provided for wiring connections and the detector is factory wired to one
side of this terminal strip. The other side of the terminal strip is for user-supplied wiring
to the detector terminal strip located in the amplifier junction box. This wi ri ng should go
through the top 3/4” conduit hub. Three spacers installed on the back of the junction box
controls the distance of the junction box from a mounting surface.

Installation

This section describes procedures to mount the combustible gas transmitter in the
monitoring environment and wire the transmitter to a controller.

Mounting the Combustible Gas Transmitter

1. Select a mounting site that is representative of the monitoring environment. Consider
the following when you select the mounting site.

• For the amplifier junction box, select a site where the junction box is not likely to

be bumped or disturbed. Make sure there is sufficient room to perform start-up,
maintenance, and calibration procedures. The site should be easily accessible.

• For the detector junction box, select a site where the target gas is likely to be found

first. For lighter gases, mount the detector near the ceiling; for heavier gases,
mount the detector near the floor.

• The junction boxes should be mounted no further than 200 feet from each other.

4 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Rubber
Spacer,
3X

2.70 .38

J-Box

Combustible

Gas Detector

3.65

3/4 NPT

Female

Calibration

Cup/Splash

Guard

10.30 MAX

5.25

1.13

Figure 2: Mounting the Combustible Gas Transmitter

2. At the monitoring site you select, hang or mount the detector junction box with the
detector facing down (see Figure 2).

3. Install 3/16 inch I.D. flexible polyurethane tubing to the fitting at the bottom of the
calibration cup/splash guard and route it to an accessible area that is close to the
amplifier junc tion box. See the “Parts List” on page 19 for avai lable tubing.

Find Quality Products Online at: [e-mail]

65-2405RK-04 Combustible Gas Transmitter • 5

www.GlobalTestSupply.com

Wiring the Detector to the Amplifier

WARNING: Always verify that the power to the controller is off before you make

wiring connections.

1. Confirm that n o power is being applied to the amplifier. If the amplifier has already
been connected to a controller , turn of f the contr oller and turn off or unplug power to
the controller.

2. Remove the detector junction box’s cover from the junction box.

3. Remove the amplifier junction box’s cover from the junction box.

4. Guide a four-conductor, shielded cable or four wires in conduit through the top
conduit hub of the detector junction box. To make wiring more convenient, use wire
colors that correspond to the detector wire colors: red, white, green, and black.

NOTE: Consult RKI Instruments, Inc. for cable lengths longer than 200 feet.

5. Connect the detector leads to the terminal block in the detector junction box.

6. Secure the detector junction box’s cover to the junction box.

7. Guide the other end of the four-conductor, shielded cable or four wires in conduit
through the bottom conduit hub of the amplifier junction bo x.

8. To gain access to a plug-in terminal strip for wiring, pull it out of its socket by
grasping the terminal strip and pulling. The detector strip is keyed so that the
controller and detector terminal strips cannot be reversed inadvertently.

9. Pull out the detector terminal strip and connect the four wires to the terminal strip as
follows (see Figure 3).

• Connect the wire corresponding to the detector’s red wire to the LEL “R”

terminal.

• Connect the wire corresponding to the detector’s white wire to the LEL “W”

terminal.

• Connect the wire corresponding to the detector ’s green wire to the LEL “G”

terminal.

• Connect the wire corresponding to the detector’s black wire to the LEL “B”

terminal.

CAUTION: If shielded cable is used, leave the cable shield’s drain wire disconnected and

insulated at the detector junction box. Y ou will connect the opposite end of the cable’s
drain wire to the amplifier junction box’s chassis (earth) ground.

6 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

GRB

PWR / SIG

W

LEL

S

Amp lifier

Black
Green
White
Red

IR LELDetector

Cable

Shield

Detector
Terminal

Strip

Black
Green
Whit e

Red

Amplifie r
J-Box

Detector J - Bo x

Calibration Cup/Splash G uard

Figure 3: Wiring the Detector to the Amplifier

10. Reinstall the detector terminal strip into its socket.

11. If shielded cable is used, connect the cable’s drain wire to an available chassis (earth)
ground at the amplifier junction box. The amplifier mounting screw is a convenient
grounding location. Install a lug on the shield drain wire or wrap the shield drain wire
around the mounting screw. Do not conn ect the sh ield drai n wire at the detector
junction box.

65-2405RK-04 Combustible Gas Transmitter • 7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Wiring the Amplifier to a Controller

1. Turn off the controller.

2. Turn off or unplug power to the controller.

3. Remove the amplifier junction box’s cover from the junction box.

4. Guide a three-conductor, shielded cable, or three wires in co nduit through the top
conduit hub of the amplifier junction box.

5. Pull out the controller terminal strip, and connect the three wires to the terminal strip
as follows (see Figure 4).

• Connect the positive wire to the PWR/SIG “+”terminal.

• Connect the signal wire to the PWR/SIG “S” terminal.

• Connect the negative wire to the PWR/SIG “-” terminal.

CAUTION: If shielded cable is used, leave the cable shield’s drain wire disconnected and

insulated at the amplifier junction box. You will connect the opposite end of the
cable’s drain wire to the controller’s chassis (earth) ground.

6. Reinstall the controller terminal strip into its socket.

7. Secure the amplifier junction box’s cover to the junction box.

8. Route the cable or wires leading from the amplifier junction box through one of the
conduit hubs at the controller housing.

CAUTION: Do not route power and transmitter wiring through the same controller conduit hub.

The power cabl e may disrupt the tra n smission of the transmitter signal to the
controller.

9. Connect the wires to the applicable detector/transmitter terminal strip at the
controller as shown in Figure 4.

8 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Amplifier (Transmitter)

Cable Shield

- (DC Ground)

+ 24 VDC
4 - 20 mA In (S)

Cont r o ller or

Recording Device

Detector Wires

Gree n
White
Red

B

Amplifier

J-Box

R W G

PWR / SIG

Black

LEL

S

Figure 4: Wiring the Amplifier to a Controller

10. If shielded cable is used, connect the cable’s drain wire to an available chassis (earth)
ground at the controller. RKI controllers typically have a ground stud that can be used
to ground the cable’s drain wire.

65-2405RK-04 Combustible Gas Transmitter • 9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Start Up

This section describes procedures to start up the combustible gas transmitter and place the
transmitter into normal operation.

Introducing Incoming Power

1. Complete the installation procedures described earlier in this manual.

2. Verify tha t the power wiring to the controller is correct and secure. Refer to the
controller operator’s manual.

3. Turn on power to the controller.

4. Turn on the controller.

5. Verify that the controller is on and operating properly. Refer to the controller
operator’s manu al.

NOTE: When first powered up, the transmitter will enter about a one minute period

when the 4-20 mA output is stabiliz ing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The combustibl e gas transmitter’s 4-20 mA signal should be
stable by the time the controller’s w armup period is over.

CAUTION: Allow the detector to warm up for 5 minutes before you continue with the next

section, “Setting the Zero Signal”.

Setting the Zero Signal

WARNING: Do not rem ove the junction box cover while the circuits are energized

unless the area is determined to be non-hazardous. Keep the junction box
cover tightly closed during operation.

NOTE: If you can verify that the combustible gas transmitter is in a fresh air

environment, you do not need to apply zero air to the detector before adjusting
the zero reading.

The procedure below describes applying zero emission air, usually called zero air, using a
calibration kit that includes a calibra tion cup, calibration gas, sample tubing, and a fixed
flow regulator with an on/off knob. RKI Instruments, Inc. recommends using a 0.5 LPM
(liters per minute) fixed flow regulator.

1. Unscrew and remove the amplifier junction box’s cover from the junction box.

2. Set a voltmeter to mea sure in the milli volt (mV) range.

3. Plug the voltmet er leads in to the test points on the amplifier. P lug the positive lead
into the red (+) test point; plug the negative lead into the black (-) test point.

4. Screw the regulator into the zero air calibration cylinder.

5. Use the flexible tubing coming from the calibration cup/splash guard to connect the
regulator to the calibration cup.

10 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

6. Turn the regulator’s on/off knob coun terclockwise to open it. Gas will begin to flow.

7. Allow the gas to flow for the length of time determined in “Determining Response

8. Verify a voltmeter reading of 100 mV (±2 mV).

9. If necessary, use a s mall flat-blade screwdriver to adjust the zero pot until the

10. Turn the regulator’s on/off knob clockwise to close it.

11. Disconnect the calibration cup/splash guard’s flexible tubing from the regulator.

NOTE: Do not disconnect the flexible tubing from the calibration cup/splash guard.

12. Unscrew the regulator from the zero air calibration cylinder.

13. Store the components of the calibrat ion kit in a safe and convenient place.

14. Remove the voltmeter leads from the test points.

15. Secure the junction box cover to the junction box.

Maintenance

This section describes maintenance procedures. It includes preventive maintenance,
troubleshooting, and component replacement procedures.

Tim e” on page 16.

voltmeter reading is 100 mV (±2 mV).

Preventive Maintenance

This section describes a preventive maintenance schedule to ensure the optimum
performance of the combustible gas transmitter. It includes daily, monthly, and quarterly
procedures.

Daily

Verify a display reading of 0 %LEL at the controller. Investigate significant changes in the
display reading.

Monthly

This procedure describes a test to verify that the combustible gas transmitter responds
properly to the target gas.

WARNING: The controller is not an active gas monitoring device during the response

test procedure.

NOTE: Performing a response test on the combustible gas transmitter may cause alarms.

Be sure to put the controller into its calibration mode or disable external alarms
befor e per f o r ming this test.

NOTE: The fol lowing procedure assumes the use of a calibration kit which includes a

calibration gas cylinder, a 0.5 LPM fixed flow regulator with an on/off knob, a
calibration cup for the detector, and a length of sample tubing.

65-2405RK-04 Combustible Gas Transmitter • 11

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Preparing for the response test

1. Place the controller into its calibration mode or disable external alarms.

2. Verify that the controller display reading for the channel you are testing is 0 %LEL.
If the display reading is not 0 %LEL, set the zero reading of the transmitter as

described in “Start Up” on page 10, then continue this procedure.

3. Screw the regulator into the calibration cylinder.

4. Use the flexible tubing coming from the calibration cup/splash guard to connect the
regulator to the calibration cup.

5. Unscrew and remove the amplifier junction box’s cover from the junction box.

6. Set a voltmeter to mea sure in the milli volt (mV) range.

7. Plug the voltmet er leads in to the test points on the amplifier. P lug the positive lead
into the red (+) test point; plug the negative lead into the black (-) test point.

8. Use the following formula to determine the correct test points output for the test
sample.

Output (mV) = (calibrating sample/fullscale) X 400 + 100

For example, with a test sample of 50 %LEL and a fullscale setting of 100 %LEL, the
correct output is 300 mV.

300 (mV) = (50/100) X 400 +100

Performing the response test

1. Turn the regulator’s on/off knob counterclockwise to open the regulator. Gas will
begin to flow.

2. Allow the gas to flow for the length of time determined in “Determining Response
Tim e” on page 16.

3. Verify that the reading is within ± 20% of the response reading you determined earlier.

NOTE: If the reading is not within ± 20% of the correct response reading, calibrate the

transmitter as described in “Calibration” on page 17 of this manual.

4. Turn the regulator’s on/off knob clockwise to close the regulator.

5. Unscrew the regulator from the calibration cylinder.

6. Disconnect the calibration cup/splash guard’s flexible tubing from the regulator.

NOTE: Do not disconnect the flexible tubing from the calibration cup/splash guard.

7. Remove the voltmeter leads from the amplif ier test points.

8. Reinstall the amplifier junction box’s cover.

9. When the controller disp lay reading falls below the alarm setpoints, return the
controller to normal operation.

10. Store the components of the calibration kit in a safe place.

Quarterly

Calibrate the combustible gas transmitter as described in “Calibration” on page 17 of this
manual.

12 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Troubleshooting

The troubleshooting guide describes symptoms, probable causes, and recommended
action for problems you may encounter with the combustible gas transmitter.

NOTE: This troubleshoo ting guide describes transmitter problems only. See the

controller operator’s manual for problems you m ay encounter with the
controller.

Table 2:Troubleshooting the Combustible Gas Transmitter

Condition Symptom(s) Probable Causes Recommended Action

Fail Condition • Controller indicates a

Slow or No
Response/
Difficult or
Unable to
Calibrate

fail condition.

• Transmitter resp onds
slowly or does not
respond to response
test.

• Unable to accurately
set the zero or
response reading
during cali bration.

• Transmitter requires
frequent calibration.

Note: Under “normal”
circumstances, the
transmitter requires
calibration once every 3
months.

Some applications
may require a more
frequent calibration
schedule.

• The detector-to­amplifier or amplifier­to-controller wiring is
disconnect ed or
misconnected.

• The transmitter’s zero
reading is low enough
to cause a fail
condition.

• The transmitter is
malfunctioning.

• The calibration cylinder
is low, out-dated, or
defective.

• The ca libration gas
flow rate is too low.

• The ca libration gas is
not an appr opriate
concentration.

• The transmitter is
malfunctioning.

• The flexible tubing to
the calibration cup/
splash guard has
become kinked,
blocked, or
disconnected.

1. Verify that the detector-to-amplifier
and amplifier-to-controller wiring is
correct and secure.

2. Calibrate the transmitter.

3. If the fail condition continues, replace
the detector.

4. If the fail condition continues, contact
RKI for further instruction.

1. Verify that the calibration cylinder
contains an adequate supply of a
fresh test sample.

2. Verify that the regulator used for
calibration is a 0.5 LPM regulator.

3. Verify that the calibration gas
concentration is appropriate for the
transmitter. The concentration should
be in the detection range, preferably
about half of the detection range.

4. Verify that the flexible tubing to the
calibration cup/splash guard is clear
and connected to the calibration cup/
splash guard.

5. If the calibration/response difficulties
continue, replace the detector.

6. If the calibration/response difficulties
continue, contact RKI for further
instruction.

Replacing Components of the Combustible Gas Transmitter

This section includes procedures to replace the combustible gas detector and amplifier.

Replacing the Combustible Gas Detector

NOTE: The combustible gas detector is installed on the junction box that does not house

the amplifier. This junction box was likely installed somewhere difficult to
access.

1. Turn off the controller.

2. Turn off or unplug power to the controller.

3. Unscrew the calibration cup/splash guard from the detector.

65-2405RK-04 Combustible Gas Transmitter • 13

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

4. Remove the detector junction box’s cover from the junction box.

5. Disconnect the detector leads from the terminal block in th e detector jun ction box.
Note the position of the color-coded leads as you remove them.

6. Unscrew the detector from the detector junction box.

7. Guide the detector leads of the replacement detector through the bottom conduit hub
of the detector junction box, then screw the mounting threads of the detector into the
conduit hub. If necessary for environmental conditions, apply thread sealant or teflon
tape to the hub and/or detector threads to seal them.

8. Connect the detector leads to the terminal block the same way the old detector was
wired (see Figure 3 on page 7).

9. Screw the calibration cup/splas h guard onto the new detector.

10. Reinstall the detector junction box cover.

11. Turn on or plug in power to the controller.

12. Turn on the controller and place it into normal operation.

NOTE: When first powered up, the transmitter will enter about a one minute period

when the 4-20 mA output is stabiliz ing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The combustibl e gas transmitter’s 4-20 mA signal should be
stable by the time the controller’s w armup period is over.

CAUTION: Allow the replacement detector to warm up for 5 minutes before you continue with

the next step.

13. Calibrate the transmitter as described in “Calibration” on page 17 of this manual.

Replacing the Amplifier

NOTE: The amplifier is not housed in the same junctio n box as the combusti ble gas

detector. The a mplifier junction box should be somewhere accessible.

1. Turn off the controller.

2. Turn off or unplug power to the controller.

3. Remove the amplifier junction box’s cover from the junction box.

4. Unplug the detector terminal strip an d controller terminal strip from their sockets.
You may leave the wires connected to the terminal strips.

5. Unscrew and remove the screw with the flat and lock washers that secures the
amplifier to the junction box.

6. Remove the old amplifier.

7. Place the new amplifier in the same position as the old amplifier. A foam gasket that
orients the amplifier and keeps it from rotating is installed on the bottom of the
amplifier. Make sure th e amplifier is seated flat in the junction box.

8. Install the new amplifier into the junction box with the screw, lock washer, and flat
washer you removed in step 5 above.

9. Install the detector and controller terminals strips into their sockets on the new

14 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

amplifier as shown in Figure 4 on page 9 of this manual. If controller leads or detector
leads were removed during this procedure, refer to Table 3 and Table 4 below.

Table 3:Reconnecting the Amplifier

to the Controller

Amplifier Controller

Terminal Strip

PWR/SIG “-” - (DC -)
PWR/SIG “S” S (4 - 20 mA In)
PWR/SIG “+” + 24V

Table 4:Reconnecting the LEL

Detector to the Amplifier

Amplifier Detector

T erminal Strip

DETECTOR “R” RED
DETECTOR “W” WHT
DETECTOR “G” GREEN

DETECTOR “B” BLK

Controller

Transm itte r Terminal

Strip (typical)

Detector Lead

NOTE: When a transmitter is first powered up with a new amplifier, the initial output

may be either high or below zero depending on the setting of the zero pot. Be
sure to make arrangements so that this does not cause unwanted alarms.

10. Turn on power to the controller.

11. Turn on the controller and place it into normal operation.

NOTE: When first powered up, the transmitter will enter about a one minute period

when the 4-20 mA output is stabiliz ing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The combustibl e gas transmitter’s 4-20 mA signal should be
stable by the time the controller’s w armup period is over.

12. Allow the transmitter to warm-up for 5 minutes.

13. Calibrate the transmitter as described in “Calibration” on page 17 of this manual.

Calibration Frequency

Although there is no particular calibration frequency that is correct for all applications, a
calibration frequency of every 3 to 6 months is adequate for most combustible gas
transmitter applications. Unless experience in a particular application dictates otherwise,
RKI Instruments, Inc. recommends a calibration frequency of every 3 months.

65-2405RK-04 Combustible Gas Transmitter • 15

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

If an application is not very demanding, for example detection in a clean, temperature
controlled environment where combustible gas is not normally present and calibration
adjustments are minimal at calibration, then a calibration frequency of every 6 months is
adequate.

If an application is very demanding, for example if combustible gas is present often and in
significant concentrations or the environment is not well controlled, then more frequent
calibration than every 3 months may be necessary. If potential catalyst poisons are known
or likely to be present, more frequent calibration than every 3 months will be necessary.

Determining Response Time

Since the detector junction box is installed remotely from the amplifier, the response time
of the detector will depend on the length of flexible tubing that is attached to the
calibration cup/splash guard. To determine the response time based on the length of
tubing connected:

1. Place the controller into its calibration mode or disable external alarms.

2. Note the current gas reading displayed at the controller.

3. Screw the regulator into the calibration cylinder . Do not use a zer o air cylinder for this
operation.

4. Use the flexible tubing coming from the calibration cup/splash guard to connect the
regulator to the calibration cup.

5. Turn the regulator’s on/off knob counterclockwise to open the regulator. Gas will
begin to flow. Take note of the time or start a stopwatch.

6. When you first start to notice an increase in the gas reading, note how much time
passed between starting the gas flow and noticing a reading response.

7. Turn the regulator’s on/off knob clockwise to close the regulator.

8. Unscrew the regulator from the calibration cylinder.

9. Disconnect the calibration cup/splash guard’s flexible tubing from the regulator.

NOTE: Do not disconnect the flexible tubing from the calibration cup/splash guard.

10. Add 1 minute to the length of time determined in step 6. This is the response time for
the detector. When performing a response test, zero adjustment, or span adjustment,
gas must be applied for this length of time.

16 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Calibration

This section describes how to calibrate the combustible gas transmitter. It includes
procedures to prepare for calibration, set the zero reading, set the response reading, and
return to normal operation.

W ARNING: The controller is not an active gas monitoring device during the calibration

procedure.

NOTE: The fol lowing procedure assumes the use of a calibration kit which includes a

calibration gas cylinder, a 0.5 LPM fixed flow regulator with an on/off knob, a
calibration cup for the detector, and a short piece of sample tubing to connect the
regulator to the calibration cup.

Prepari ng for Ca libra t ion

1. Unscrew and remove the amplifier junction box’s cover from the junction box.

2. Set a voltmeter to mea sure in the milli volt (mV) range.

3. Plug the voltmet er leads in to the test points on the amplifier. P lug the positive lead
into the red (+) test point; plug the negative lead into the black (-) test point.

4. Use the following formula to determine the correct test points output for the
calibrating sample.

Output (mV) = (calibrating sample/fullscale) X 400 + 100

For example, with a calibrating sample of 50 %LEL and a fullscale setting of
100 %LEL, the correct output is 300 mV.

300(mV) = (50/100) X 400 +100

5. Place the controller into its calibration mode or disable external alarms.

NOTE: Calibrating the combustible gas transmitter may cause alarms. Be sure to put the

controller into its calibration mode or disable external alarms before continuing.

Setting the Zero Reading

NOTE: If you can verify that the combustible gas transmitter is in a fresh air

environment, you do not need to apply zero air to the detector before adjusting
the zero reading.

1. Screw the regulator into the zero air calibration cylinder.

2. Use the flexible tubing coming from the calibration cup/splash guard to connect the
regulator to the calibration cup.

3. Turn the regulator’s on/off knob counterclockwise to open the regulator.

4. Allow the gas to flow for the length of time determined in “Determining Response
Time” on page 16 and verify a reading of 100 mV (±2 mV). If necessary, use the zero
pot on the amplifier to adjust the reading to 100 mV (±2 mV).

5. Turn the regulator’s on/off knob clockwise to close the regulator.

65-2405RK-04 Combustible Gas Transmitter • 17

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

6. Unscrew the regulator from the zero air calibration cylinder.

7. Leave the calibration cup/spl as h guard’s flexible tubing connected to the regulator.

Setting the Response Reading

1. Screw the regulator into the calibration cylinder. Verify that the calibration gas is
representative of the transmitter’s target gas.

2. Turn the regulator’s on/off knob counterclockwise to open the regulator.

3. Allow the calibration gas to flow for the length of time determined in “Determining
Response Time” on page 16 and verify that the reading matches the response reading
(±2 mV) you determined earlier. If necessary, use the span pot on the amplifier to
adjust the reading to match the correct response reading.

4. Turn the regulator’s on/off knob clockwise to close the regulator.

5. Unscrew the regulator from the calibration cylinder.

Returning to Normal Operation

1. Remove the voltmeter leads from the amplif ier test points.

2. Disconnect the calibration cup/splash guard’s flexible tubing from the regulator.

NOTE: Do not disconnect the flexible tubing from the calibration cup/splash guard.

3. Secure the amplifier junction box cover to the junction box.

4. When the controller disp lay reading falls below the alarm setpoints, return the
controller to normal operation.

5. Verify tha t the controller display reading decreases and stabilizes at 0 %LEL.

6. Store the components of the calibration kit in a saf e and convenient plac e.

18 • 65-2405RK-04 Combustible Gas Transmitter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Parts List

Table 5 lists replacement parts and accessories for the combustible gas transmitter.

Table 5:Parts List

Part Number Description

06-1248RK Sample tubing (3/16 in. x 5/16 in.; specify length when ordering)
18-0400RK-01 Junction box with spacers
57-1053RK Amplifier with gasket (specify detector part number when ordering)
61-0140RK Combustible gas sensor
65-2405RK-04 Methane transmitter (includes detector, two junction boxes, and amplifier)
71-0280RK 65-2405RK-04 Combustible Gas Transmitter Operator’s Manual

81-0004RK-01 Steel calibration cylinder, 50% LEL propane in air, 34-liter
81-0012RK-01 Steel calibration cylinder, 50% LEL methane in air, 34-liter
81-0076RK-01 Steel calibration cylinder, zero emission air, 34-liter
81-1050RK Regulator, 0.5 liter/minute; with pressure gauge and flow c ontr ol kn ob , for 17

81-1116RK Calibration cup/splash guard
81-F002RK-LV Calibration kit, includes regulator, samp le tubing, calibration cup, and 34 liter

81-F006RK-LV Calibration kit, includes regulator, samp le tubing, calibration cup, and 34 liter

82-0006RK Pot adjust screwdriver, for calibration

(this document)

liter and 34 liter steel calibration cylinders

50 %LEL methane in air steel calibration cylinder

50 %LEL propane in air steel calibration cylinder

65-2405RK-04 Combustible Gas Transmitter • 19

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com
