Rival RO230, RO180, RO160, RO170 Owner's Manual

ROASTER OVEN

RO160, RO170,

RO180 & RO230 Series

Owner’s Guide

READ AND SAVE THESE INSTRUCTIONS

Visit us at www.rivalproducts.com

1-800-557-4825

IMPORTANT SAFEGUARDS FOR

ROASTER OVENS

When using electrical appliances, basic safety precautions should
always be followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock do not immerse roaster base,
cord, or plug in water or other liquid.

4. Close supervision is necessary when any appliance is used by or
near children.

5. Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts and before cleaning.

6. Do not operate roaster oven with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Contact Rival’s Consumer Service Department (see warranty) to
return for examination, repair or adjustment.

7. The use of accessory attachments not recommended by Rival may
cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot
surfaces, including the stove.

10. Do not place on or near a hot gas or electric burner or in a heated oven.

11. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.

12. CAUTION: Steam escaping from under cover or food warming pans
is hot and can cause burns.

13. Do not use appliance for other than its intended use.

14. Use oven mitts to remove the REMOVABLE ROASTING PAN from the
roaster oven; or to remove a baking pan or cooked food from the
REMOVABLE ROASTING PAN.

-2-

15. To disconnect, turn TEMPERATURE CONTROL to OFF, then remove plug
from wall outlet.

16. Some countertop surfaces such as Corian®and other surfaces are not
designed to withstand the prolonged heat generated by certain
appliances. We recommend placing a hot plate or trivet under your Rival

®

product to prevent possible damage to the surface.

SAVE THESE INSTRUCTIONS

• These appliances are for HOUSEHOLD USE ONLY.

• No user-serviceable parts inside. Do NOT attempt to repair or adjust

any electrical or mechanical functions on this unit. Doing so will void
the Warranty.

• Do not immerse base in water or other liquid.

• A short power supply cord is provided to reduce the hazards

resulting from entanglement or tripping over a longer cord. AN

EXTENSION CORD MAY BE USED WITH CARE; HOWEVER, THE MARKED
ELECTRICAL RATING SHOULD BE AT LEAST AS GREAT AS THE ELECTRICAL
RATING OF THE ROASTER OVEN. The extension cord should not be

allowed to drape over the counter or tabletop where it can be pulled
on by children or tripped over.

POLARIZED PLUG

These appliances have polarized plugs (one blade
is wider than the other). To reduce the risk of
electric shock, these plugs are intended to fit into a
polarized outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug. If it still

does not fit, contact a qualified electrician.
Do not attempt to modify the plugs in any way. If
the plugs fits loosely into the AC outlet or if the
AC outlet feels warm do not use that outlet.

-3-

R

o

a

s

t

e

r

O

v

e

n

LID

KNOW YOUR ROASTER OVEN

BUFFET SERVER
FRAME

(SELECT MODELS)

INDICATOR LIGHT

(SELECT MODELS)

TEMPERATURE
CONTROL

REMOVABLE
SERVING DISHES

(SELECT MODELS)

REMOVABLE
ROASTING PAN

LID REST

ROASTER OVEN BODY

REMOVABLE
ROASTING RACK

-4-

PREPARING YOUR ROASTER OVEN FOR USE

1. Carefully unpack the Roaster Oven and remove all packaging materials.

2. Wash the REMOVABLE ROASTING PAN, REMOVABLE ROASTING RACK,
REMOVABLE SERVING DISHES (select models only), REMOVABLE
SERVING DISH FRAME (select models only), and LID in hot, soapy water
using a sponge or soft cloth. Rinse thoroughly. Wipe dry.

3. Clean the outside of the ROASTER OVEN BODY with a soft cloth and
warm, soapy water. Wipe dry. Do not use abrasive cleaners.

NOTE: Due to the manufacturing process, some smoke and odor may be
noticed during the first use. This should disappear after the first heating of the
Roaster Oven.

TIPS FOR ROASTING

• Always use the REMOVABLE ROASTING PAN in the roaster oven
when cooking.

NOTE:

Never place food or liquid directly into the ROASTER OVEN BODY.

• Use caution when removing or lifting the LID as steam is vented
along the seam on the top of the LID.

• Significant amounts of heat escape whenever the LID is removed.
Instead of removing the LID to check on your food, grasp LID
HANDLE and lift just enough to check on or taste the food.

Exercise caution when using this feature, as steam may escape.

• To use the LID REST feature, hold the LID upright by the HANDLE
and place the edge of the LID under the metal tabs just above
either side HANDLE.

• Convenience foods can be baked in the Roaster Oven. Place
container on ROASTING RACK. Follow package directions.

-5-

TIPS FOR ROASTING (CONT.)

• Meats roasted in your Roaster Oven will be moist and tender.
For additional browning, brush oil or butter over the meat before
cooking.In addition, cooking the meat in a traditional oven at
450°. For on Broil for the last 20-30 minutes will result in
better browning.

• To create a darker roasted, crispier skin poultry, do not add liquids
(with the exception of the basting butter or oil) until there are only
30 minutes left of cooking. Cooking at a higher temperature will
result in a faster cooking time, i.e. 375 °F instead of 325 °F.

TIPS FOR USING THE REMOVABLE SERVING DISHES

(SELECT MODELS)

CAUTION: Temperature of foods should be kept at 150 °F or above.

• The REMOVABLE ROASTING PAN and REMOVABLE SERVING
DISH FRAME must be in place when using the REMOVABLE
SERVING DISHES.

• Use only to keep cooked foods warm.

• REMOVABLE SERVING DISHES and REMOVABLE SERVING DISH
FRAME are not to be used on the stove top, in an oven, or in a
microwave oven.

• When filling REMOVABLE SERVING DISHES with foods that may
stick, spray the inside with a non-stick cooking spray.

• If food is dry, add broth or juice to help keep warm.

• NEVER pick-up hot REMOVABLE SERVING DISHES using the
REMOVABLE SERVING DISH FRAME.

-6-

USING YOUR ROASTER OVEN

1. Place the REMOVABLE ROASTING PAN into the ROASTER OVEN BODY.

2. Turn the TEMPERATURE CONTROL to OFF, then plug cord into
a 120V AC outlet.

3. Turn the TEMPERATURE CONTROL to the desired temperature
and preheat for 15 to 20 minutes. Indicator light will shut off
when temperature is reached (indicator light is on select
models only).

4. Place ROASTING RACK into the REMOVABLE ROASTING PAN,
arrange food on the ROASTING RACK, and secure the LID on
the Roaster Oven. NOTE: Some foods or recipes do not require
the ROASTING RACK to be used.

5. When finished, turn the TEMPERATURE CONTROL to OFF and
unplug Roaster Oven from outlet.

6. Use oven mitts or hot pads to remove LID and ROASTING
RACK, or when grasping unit by side handles, surfaces are hot
during operation.

USING THE REMOVABLE SERVING DISHES

(SELECT MODELS)

1. Fill the REMOVABLE ROASTING PAN with 8 quarts of water
(or 1/2 - 3/4 full) and place inside ROASTER OVEN BODY.
CAUTION: Never add water directly inside the ROASTER OVEN
BODY.

2. Place REMOVABLE SERVING DISH FRAME on top of the
REMOVABLE ROASTING PAN. Make sure the REMOVABLE
SERVING DISH FRAME is secure and level.

3. Add empty REMOVABLE SERVING DISHES, making sure they fit
securely in REMOVABLE SERVING DISH FRAME.

-7-

USING THE REMOVABLE SERVING DISHES

(SELECT MODELS) (CONT.)

4. Cover with LID and plug Roaster Oven into a 120V outlet.
Preheat on 350 °F for 30 minutes or until water is very hot.

5. Remove LID and carefully add hot, cooked food into
REMOVABLE SERVING DISHES.

6. Cover and turn control to 250 °F setting to keep foods warm. If
necessary, adjust temperature.

7. Stir occasionally and keep food covered to maintain
temperature.

8. Periodically, check water level and carefully add more hot
water if necessary

.

CLEANING YOUR ROASTER OVEN

NOTE: Do not immerse the ROASTER OVEN BODY in water
or other liquid. Do not put REMOVABLE ROASTING PAN,
REMOVABLE SERVING DISHES (select models), or REMOVABLE
SERVING DISH FRAME (select models) in dishwasher.

1. Turn TEMPERATURE CONTROL to OFF.

2. Unplug the Roaster Oven from outlet and allow unit to cool
completely before cleaning.

3. Wash the REMOVABLE ROASTING PAN, REMOVABLE SERVING
DISHES (select models), REMOVABLE SERVING DISH FRAME
(select models), LID, and ROASTING RACK in hot, soapy water
– using a sponge or cloth. Rinse thoroughly in hot water, then
towel dry.

4. Wipe the inside and outside of the ROASTER OVEN BODY with
a damp cloth.

-8-

COOKING TIME AND TEMPERATURE

DETERMINING MEAT DONENESS

It is recommended that you use a meat thermometer to determine
doneness when cooking meat and poultry. Insert the thermometer
into the center of the thickest portion of the meat. Cook until
temperature for desired doneness is reached.

MEAT RARE MEDIUM WELL DONE

BEEF
PORK
LAMB
SMOKED HAM

Cook before eating
Fully cooked

POULTRY

Roasting Chicken
Turkey

140° F

*

140° F

*

*

160° F
160° F
160° F

170° F
170° F
170° F

160° F
140° F

180° F
180° F

*Rare pork, ham or poultry is not recommended.

ROASTING MEATS AND POULTRY

Meats will cook more rapidly in the Roaster Oven than a conventional
oven. Reducing temperature and increasing time will result in a
browner, crispier crust. Times indicated below are approximate and
should be used as a guideline only.

MEAT WEIGHT (LBS.) TEMP. MIN./LB.

BEEF ROASTS

Standing Rib 4 – 6 325 °F 17 to 21
Sirloin Tip 3 – 5 350 °F 17 to 21
Tenderloin 31⁄2 – 4 450 °F 7 to 10
Pot Roast 4 – 6 300 °F 26 to 34

1

Corned Beef 3

⁄2 – 4 300 °F 15 to 17

-9-

MEAT WEIGHT (LBS.) TEMP. MIN./LB.

LAMB

Leg 5 – 8 350 °F 20 to 22
Shoulder, boneless 3 – 4 350 °F 20 to 22

PORK

Loin Roast 3 – 5 350 °F 21 to 26
Rolled Shoulder 4 – 6 350 °F 30 to 34
Chops 4 – 5 325 °F 15 to 17
Country-Style Ribs 8 – 10 450 °F to brown,

then decrease temp. to 250 °F 15 to 17

SMOKED HAM

Bone-in, shank 10 – 15 325 °F 17 to 21
Boneless 8 – 12 325 °F 15 to 17
Fully cooked 5 – 10 325 °F 13 to 24

VEAL

Loin 4 – 6 325 °F 26 to 30
Shoulder 3 – 5 325 °F 26 to 30

POULTRY

1

Chicken, whole 3
Chicken, whole 6 – 8 350 °F 15 to 17
Chicken, pieces 6 – 8 350 °F 7 to 9
Turkey, prebasted 10 – 14 375 °F 12 to 15
Turkey, fresh 14 – 22 375 °F 13 to 15
Turkey, fresh 10 – 14 350 °F 12 to 15

⁄2 – 5 350 °F 13 to 15

SLOW COOKING

Slow cooking is best for less tender cuts of meat. Heat is gradual with
slow cooking and stirring is not necessary. Avoid removing the LID
during slow cooking, because heat escapes and may increase the
cooking time. When using a standard roasting recipe, slow cook 1 1/2
hours at the 250 °F setting for every 30 minutes of roasting.

-10-

BAKING*

• Always place baking pans on the ROASTING RACK. Do not place pans
on bottom of REMOVABLE ROASTING PAN.

• We recommend that you use metal pans in the Roaster Oven, because
they provide better heat transfer and browning.

FOOD TEMP. SETTING BAKING TIME (MIN)

MUFFINS 425° F 15 to 20

QUICK BREAD 375° F 65 to 75

YEAST BREAD 400° F 40 to 45

YEAST ROLLS 400° F 18 to 20

COOKIES 350° F 11 to 13

BROWNIES 350° F 25 to 30

CUPCAKES 350° F 25 to 30

SHEET CAKE 350° F 40 to 45

POUND CAKE 350° F 50 to 60

BUNDT CAKE 350° F 50 to 60

CHEESECAKE 325° F 50 to 60

FRUIT PIE 425° F 45 to 50

CUSTARD PIE 350° F 50 to 60

PASTRY SHELL 425° F 10 to 13

PIZZA (9-inch) 425° F 20 to 25

BAKED POTATOES 350° to 400° F 50 to 60

SWEET POTATOES 350° to 400° F 55 to 65

SCALLOPED POTATOES 350° F 75 to 90

WINTER SQUASH 400° F 45 to 60

BAKED APPLES 350° F 35 to 45

* Always preheat roaster prior to baking

-11-

RECIPES

LEMON GARLIC ROAST CHICKEN

4 to 5-lb. chicken 2 tablespoons lemon juice
3 cloves garlic, minced
1 teaspoon salt

Rinse chicken in cold water. Combine remaining ingredients and rub over skin and
between skin and meat of chicken. Place roasting rack in cooking pan. Place chicken
on roasting rack and cover. Bake at 350°F for 1

BAKED POTATOES

8 to 12 baking potatoes

Wash potatoes and pierce with a fork. Place rack in the pan. Stack potatoes on
roasting rack, making sure that they don’t touch the sides of cooking pan. Cover
and bake at 400°F for 1 to 1

1

⁄2 hours.

POT LUCK BEEF STEW

1

⁄2 teaspoon ground black pepper

1

⁄4 cup butter, softened

1

⁄2 hours or until chicken is done.

8 -lbs. beef stew meat 15 potatoes, peeled and cubed
2 cups dry bread crumbs 2 tablespoons basil
2 teaspoons salt 2 cups quick-cooking tapioca

1

⁄2 teaspoon pepper 8 cans (4 ounces) sliced mushrooms, undrained
4 large onions, cut into eighths 15 cans (101⁄2-oz. each) condensed tomato soup
4 pounds baby carrots 8 cups beef broth
7 stalks celery

Toss stew meat with bread crumbs, salt and pepper. Place beef in pan and add
remaining ingredients; stir well. Cover and roast at 250° F. for 4 to 5 hours or until
meat and vegetables are tender.

CHILI FOR A CROWD

3 pounds dry pinto beans, soaked and drained 5 cloves garlic, minced
1 can (28-oz. ) diced tomatoes 2 jalapeno peppers, finely chopped
10 pounds ground chuck, browned and drained 3 tablespoons cumin
12 cups water
2 onions, chopped 3 cups tomato juice
2 green peppers, chopped 3 cans (101⁄2-oz. each) tomatoes and chilies

3

⁄4 cup chili powder

Preheat roaster to 350° F. Combine first 8 ingredients in roaster. Cover, cook for 21⁄2
hours. Add remaining ingredients. Cover and cook an additional 30 minutes to
1 hour.

-12-

RECIPES

MEATBALLS

5 pounds ground beef 11⁄2 teaspoons salt
1 cup Italian seasoned fine, dry bread crumbs
5 eggs

Preheat roaster with pan in place to 425° F. Combine all ingredients. Form into 1­inch balls. Place meatballs in pan. Cover; Bake 30 to 45 minutes or until done. Stir
occasionally to brown on all sides. Makes approximately 75 meatballs.

PEPPER CRUSTED BRAISED SHORT RIBS

6 - 9 pounds beef short ribs 15 cloves garlic, minced

1

⁄4 cup freshly cracked black pepper 5 (141⁄2-oz.) cans beef broth

2 teaspoons salt 1 cup red wine, optional

Preheat roaster to 450° F. Rub ribs on all sides with pepper and garlic. Sprinkle with
salt. Place ribs in cooking pan and cover. Cook 15-30 minutes, turning to brown
on all sides. Pour broth over ribs. Cover, reduce heat to 300° F and cook until
tender, 2 to 2

1

⁄2 hours.

1

⁄2 teaspoon pepper

PORK ROAST

4 - 5 lb. pork loin roast
4 cloves garlic, minced
1 teaspoon salt

Preheat roaster to 350° F. Place roast on rack. Press minced garlic into surface of
the roast. Place rack in roaster. Combine dressing and Worcestershire sauce. Brush
roast with marinade. Cover; cook for 2 to 2

1

⁄2 teaspoon pepper

1

⁄2 cup Italian dressing

1

⁄4 cup Worcestershire sauce

1

⁄2 hours or until done.

SPAGHETTI SAUCE

1 can (48-oz.) tomato juice
4 cans (28-oz.) diced tomatoes
2 cans (12-oz.) tomato paste 11⁄2 tablespoons parsley
2 tablespoons Worcestershire sauce 1 tablespoon thyme
6 cups water 1 tablespoon salt
5 cloves garlic, minced 1 teaspoon pepper

Turn roaster to 350° F. Add all ingredients to an oven safe dish, stirring well to
combine. Cover, cook 3 to 4 hours until thick, adding meatballs during last 1 to 1
hours. Stir occasionally.

1

⁄3 cup basil leaves

1

⁄4 cup oregano leaves

1

⁄2

-13-

RECIPES

SPICY BEEF ROAST

2 (21⁄2 to 3-lb.) beef tip or rump roast
2 - 3 tablespoons cracked black peppercorns 2 tablespoons Worcestershire sauce
4 cloves garlic, minced 11⁄2 teaspoons dry mustard
3 tablespoons balsamic vinegar

Preheat roaster to 350° F. Make several slits in top of roasts. Place roasts on rack. Set
rack in roaster. Combine vinegar, soy sauce, Worcestershire sauce and mustard.
Brush marinade over roasts. Combine cracked pepper and garlic. Rub over meat.
Sprinkle with salt. Cover; roast 20 to 25 minutes per pound or until roast reaches
desired doneness.

BAKED BEANS

2 cans (7-lbs. each) pork and beans
11⁄2 cup molasses 2 tablespoons dry mustard powder
11⁄4 cup ketchup 1 pound bacon, cooked until just crisp and cut up

3

⁄4 cup prepared barbecue sauce

1

⁄4 cup soy sauce

1

⁄2 teaspoon salt

1

⁄2 cup Worcestershire sauce

Combine all ingredients in an oven safe dish and place in roaster pan. Cover and
cook at 300° F for 2 hours or until heated through. Stir occasionally.

-14-

1 YEAR LIMITED WARRANTY

Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation
(Canada) Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of
one year from the date of purchase, this product will be free from defects in material and workmanship. JCS, at
its option, will repair or replace this product or any component of the product found to be defective during the
warranty period. Replacement will be made with a new or remanufactured product or component. If the product
is no longer available, replacement may be made with a similar product of equal or greater value. This is your
exclusive warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product.
Doing so will void this warranty.

This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS
dealers, service centers, or retail stores selling JCS products do not have the right to alter, modify or any way
change the terms and conditions of this warranty.

This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent
use or misuse of the product, use on improper voltage or current, use contrary to the operating instructions,
disassembly, repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the
warranty does not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.

What are the limits on JCS’s Liability?

JCS shall not be liable for any incidental or consequential damages caused by the breach of any express,
implied or statutory warranty or condition.

Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or
fitness for a particular purpose is limited in duration to the duration of the above warranty.

JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.

JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability
to use the product including incidental, special, consequential or similar damages or loss of profits, or for any
breach of contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.

Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not
apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from province to
province, state to state or jurisdiction to jurisdiction.

How to Obtain Warranty Service
In the U.S.A.

If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-557-4825
and a convenient service center address will be provided to you.

In Canada

If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-557-4825
and a convenient service center address will be provided to you.

In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business Jarden Consumer Solutions located
in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have
any other problem or claim in connection with this product, please write our Consumer Service Department.

PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.

Printed in China SPR032508 PN 128010

For product questions:

®

Jarden Consumer Service

USA: 1.800.557.4825

www.rivalproducts.com

©2008 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions.

All rights reserved. Distributed by Sunbeam, Products, Inc.

doing business as Jarden Consumer Solutions, Boca Raton, FL 33431

In Canada, imported and distributed by Sunbeam Corporation (Canada) Limited, doing

business as Jarden Consumer Solutions,

20 B Hereford Street, Brampton, Ontario L6Y 0M1.

Printed in China SPR-042908 PN 128010
