AA912/AA912-F - Light Industrial Master Stations
sound level is reached. The call will
be set up to a preprogrammed
number.
Remote Output Card DP997
By installing the optional Remote
Output Card, any user can call this
particular station, and press an
additional number button on his
keypad to operate the Remote Output
circuit. The circuit can be programmed to operate on any number
button. The built-in relay on the
Remote Output Card is activated and
operates the external device (electric
door opener, etc.).
Features.
The AA912 station operates with the
Ring-Master Systems CB901 and
RM5000 and utilizes the following
features (* = only CB901 system):
Standard features:
- Handsfree/loudspeaking
- T-button for simplex control
- Privacy
- Microphone cut-off
- Camp on busy extension
- Conference
- Hurry-up tone
- Call-back
- Remote control circuits
- Data transmission
- Volume control
Individual features:
- Call numbers, free
programmable
- All/Group-call w/ reply back
intercom
F
123
456
789
0#
M
TX
AA960
- Priority
- Call forward/Secretary transfer
- Call transfer
- Hunt
- Speed dialling (*)
- Call reply (*)
- Sectoring (*)
- Direct conference dialling (*)
- Direct dialling
- Direct access
- Central Answering Service (CAS)
- Remote dialling (*)
- Status output (*)
- Open station (line) (*)
Interface features:
- Two-way mobile radio
- Radio paging
- Intersystem tie-line
- Public address
- Telephone public network
- Voice messaging
- Programme distribution (Music)
CE Certification:
AA912/AA912-F are tested and
comply with the EMC (Electromagnetic Compatibility) directive 89/336EEC of the European Community and
meet or exceed the following stand-
TECHNICAL DATA:
Operating voltage, 24V DC +/-20%
Current drain, microphone on: 0.1A
loudspeaker on, max: 0.2A
loudspeaker on. normal: 0.15A
station free 0.015A
Power consumption, approx. 5W
Amplifier output power, max 2W
normal 0.1 - 0.2W
Station sensitivity , 0.3V/uB
Cable requirements:
1 twisted pair for audio and signalling
1 twisted pair for power supply
Temperature range: -20 to +40ºC (4 104ºF)
Line specifications:
Frequency range: 300 - 5000 Hz
Galvanic line: 0 dB (1 mW/600 ohm)
Speech level: normal -12 dBm
Speech level: max +4 dBm
Tone signalling level:-10 dBm
Tone signalling according to CCITT norms
Loudspeaker impedance:
50 ohm, (min.16 ohm)
Switching level: 16 - 27 dB
Volume control regulation: +/-7 dBm
Dimensions/weight AA912: AA9 12-F
Height: 250mm 290 mm
Width: 100mm 140 mm
Depth: 62mm 62 mm
Weight: 1.1 kg 1.1 kg
ards:
EN 50081-1 Emission
EN 50082-1 Immunity
DESK/WALL STATIONS INDUSTRIAL STATIONS DOOR STATI ONS/VANDAL PROOF STATIONS
12
4
3
5
6
7
123
456
789
T0X
F
123
456
789
0#
M
TX
AA904 AA916 AA911 AA961 AB921/AB931AA906 AB933A
AA912 AB923/AB933
8
9
0
X
T
2 PAIR OF CABLE TO EACH STATION
UP TO 240 STATIONS
Closed Radio Network
Tie-Line Interconnection
Layout Ring-Master
system CB901
RING-MASTER SYSTEM CB901-1.
Public Address System
Radio Paging System
Public Telephone Network
Ring-Master
Ring-Master internal communication systems are
manufactured by RingCom ASA, Norway to conform to
Quality System standards BS5750,Part 2, ISO 9002.
The Company reserves the right to modify designs and alter specifications without
notice, in pursuance of a policy of continuous improvement.
Distributor:
WWT-138E
DP979
(D P991 )
DP980
(DP992)
Ring- Master
Ring- Master
POWER SUPPLY
VISICALL STATION
AE111 + AA904
PM
GATE 12
EXPLOSION
PROOF
STA TI ON AF103
123
456
789
X
T0
123
456
789
0#
*
1.10.97
Ring-Master
Internal Communication Systems
AA912 Light industrial master station, Surface
AA912-F Light industrial master station, Flush
The Light Industrial Master Stations
AA912 and AA912-F are compact,
splash and dust resistant units and
very strong in construction.
The AA912 is the surface model
completely delivered with the
backbox BF961.
The AA912-F is for flush mounting
and comes with a light backbox for
EMC protection, MKE3078. When an
optional backbox is needed for
concrete mounting, the unit BF964
must be ordered.
The stations are ideally suited for
applications in loading areas,
garages, repair workshops, warehouses etc. where a lower-cost,
robust wall mounted master station
is often needed.
The keypad is of the membrane
switch type. The station provides full
handsfree voice-controlled (duplex)
communication, the speaker and
microphone allow for normal
handsfree conversation with a range
of approx. 3-5 meters or 10-15 feet.
The membrane keypad section
contains a warning lamp (red LED),
14 buttons for dialling and 1 button
(M) for microphone cut-off, (mute
when pressed during a conversation). The digit buttons (0-9) are for
call number dialling and the T-button
is provided for manual control of a
conversation when desired. The Xbutton is used to cancel the call. The
* (star) and # (pound sign) buttons
are feature buttons.
The station permits the connection
of a parallel loudspeaker where
additional output is required (loudspeaker impedance 50 ohm recommended, min. 16 ohm).
The AA912/AA912-F are designed
for integration with all Ring-Master
master- and/or substations operating
on RM5000 and CB901 centrals and
to utilize all system features.
If softspeaking confidential conversation mode is required, an optional
handset module can be added.
ADDITIONAL FEATURES:
External Lamp Control
The station has an output for controlling an external lamp. When pressing key ”9” or an external parallel
installed CALL button, the external
lamp is switched ON. When the call
is cancelled, the external lamp is
switced off.
Remote Keys
The keys "3", "6" and "9" and also
the cancel key "X" can be activated
remotely. External buttons can be
AA912
