User Guide
RSA5000 Series Real-time
Spectrum Analyzer
Sept. 30, 2018
RIGOL TECHNOLOGIES CO., LTD.
RIGOL
RSA5000 User Guide I
Guaranty and Declaration
Copyright
© 2020 RIGOL TECHNOLOGIES CO., LTD. All Rights Reserved.
Trademark Information
RIGOL® is the trademark of RIGOL TECHNOLOGIES CO., LTD.
Publication Number
UGD20102-1110
Software Version
00.01.00
Software upgrade might change or add product features. Please acquire the latest
version of the manual from RIGOL website or contact RIGOL to upgrade the
software.
Notices
⚫ RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
⚫ RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at the company’s sole decision.
⚫ Information in this publication replaces all previously released materials.
⚫ Information in this publication is subject to change without notice.
⚫ RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or performance of this manual, as well as
any information contained.
⚫ Any part of this document is forbidden to be copied, photocopied, or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial
standards in China as well as the ISO9001:2015 standard and the ISO14001:2015
standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: service@rigol.com
Website: www.rigol.com
RIGOL
II RSA5000 User Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please
follow the instructions specified in this manual to use the instrument properly.
Use Proper Power Cord.
Only the exclusive power cord designed for the instrument and authorized for use
within the local country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, connect the earth terminal of the power cord to the Protective
Earth terminal before connecting any input or output terminals.
Connect the Probe Correctly.
If a probe is used, the probe ground lead must be connected to earth ground. Do not
connect the ground lead to high voltage. Improper way of connection could result in
dangerous voltages being present on the connectors, controls or other surfaces of
the oscilloscope and probes, which will cause potential hazards for operators.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the
product. Otherwise, the operator might be exposed to the danger of an electric
shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Objects into the Air Outlet.
Do not insert objects into the air outlet, as doing so may cause damage to the
instrument.
Use Proper Fuse.
Please use the specified fuses.
RIGOL
RSA5000 User Guide III
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate with Suspected Failures.
If you suspect that any damage may occur to the instrument, have it inspected by
RIGOL authorized personnel before further operations. Any maintenance,
adjustment or replacement especially to circuits or accessories must be performed
by RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the
instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the
instrument in an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the
surfaces of the instrument clean and dry.
Prevent Electrostatic Impact.
Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.
Use the Battery Properly.
Do not expose the battery (if available) to high temperature or fire. Keep it out of the
reach of children. Improper change of a battery (lithium battery) may cause an
explosion. Use the RIGOL specified battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs,
interfaces, and other parts on the panels.
RIGOL
IV RSA5000 User Guide
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could
result in potential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety Warning
Protective Earth
Terminal
Chassis Ground
Test Ground
RIGOL
RSA5000 User Guide V
Care and Cleaning
Care
Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with
mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries, ensure
that the instrument is completely dry before connecting it to the power
supply.
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.
RIGOL
VI RSA5000 User Guide
RSA5000 Series Overview
RSA5000 series is a new generation of cost-efficient real-time spectrum analyzer with
high performance. With superb performance specifications and the clear user
interface, the RSA5000 series allows you to operate it through various ways, such as
pressing keys on the front panel, using the touch screen, connecting the mouse and
the keyboard. Remote communication interfaces are also available. The instrument
can be widely used in education science, corporate R&D, industrial production, and
other fields.
Main Features:
⚫ Ultra-Real technology
⚫ Frequency: up to 6.5 GHz
⚫ Displayed average noise level (DANL): <-165 dBm (typical)
⚫ Phase noise: <-108 dBc/Hz (typical)
⚫ Level measurement uncertainty: <0.8 dB
⚫ 6.5 GHz tracking generator
⚫ Min. RBW 1 Hz
⚫ EMC filter and quasi-peak detector
⚫ Various measurement functions
⚫ Multiple measurement modes
⚫ Up to 40 MHz real-time analysis bandwidth
⚫ Multiple trigger modes and trigger masks
⚫ Density, Spectrogram, and other display modes
⚫ PC software options
⚫ 10.1'' capacitive multi-touch screen, supporting touch gestures
⚫ USB, LAN, HDMI and other communication and display interfaces
RIGOL
RSA5000 User Guide VII
Document Overview
Topics in this manual:
Chapter 1 Quick Start
This chapter introduces the front/rear panel and user interface as well as
announcements during first use of the analyzer.
Chapter 2 Functions of the Front Panel of GPSA
This chapter gives detailed function descriptions of the GPSA's front panel keys and
the associated menu keys.
Chapter 3 Functions of the Front Panel of RTSA
This chapter gives detailed function descriptions of the RTSA's front panel keys.
Chapter 4 Input/Output
This chapter introduces the parameter settings for the input/output interface.
Chapter 5 Shortcut Key
This chapter introduces the functions of the shortcut keys on the front panel.
Chapter 6 System Function
This chapter introduces the system function settings.
Chapter 7 Remote Control
This chapter shows how to control the analyzer in remote mode.
Chapter 8 Troubleshooting
This chapter lists the troubleshooting information and messages that may appear
during the use of the analyzer.
Chapter 9 Appendix
This chapter lists the options and accessories that can be ordered along with your
analyzer as well as the service and support information.
RIGOL
VIII RSA5000 User Guide
Format Conventions in this Manual:
1. Keys:
The keys on the front panel are usually denoted by the format of "Key Name
(Bold) + Text Box". For example, FREQ denotes the FREQ key.
2. Menu Keys:
The menu softkeys are usually denoted by the format of "Menu Word (Bold) +
Character Shading". For example, Center Freq denotes the center frequency
menu item under the FREQ function key.
3. Connectors:
The connectors on the front or rear panel are usually denoted by the format of
"Connector Name (Bold) + Square Brackets (Bold)". For example, [Gen Output
50Ω].
4. Operation Procedures:
"→" represents the next step of operation. For example, FREQ → Center Freq
indicates pressing FREQ on the front panel and then pressing the menu softkey
Center Freq.
Content Conventions in this Manual:
The RSA5000 series spectrum analyzer includes the following models. This manual
takes RSA5065-TG as an example.
Model
Frequency Range
Tracking Generator
RSA5065
9 kHz to 6.5 GHz
None
RSA5032
9 kHz to 3.2 GHz
None
RSA5065-TG
9 kHz to 6.5 GHz
6.5 GHz
RSA5032-TG
9 kHz to 3.2 GHz
3.2 GHz
RSA5065N
9 kHz to 6.5 GHz
6.5 GHz
RSA5032N
9 kHz to 3.2 GHz
3.2 GHz
User Manuals of this Product:
Quick Guide, User Guide, Programming Guide, Data sheet, etc. For the desired
manual, please download it from www.rigol.com.
Contents RIGOL
RSA5000 User Guide IX
Contents
Guaranty and Declaration ......................................................................... I
Safety Requirement ................................................................................ II
General Safety Summary ........................................................................... II
Safety Notices and Symbols ...................................................................... IV
Care and Cleaning .................................................................................... V
Environmental Considerations .................................................................... V
RSA5000 Series Overview ...................................................................... VI
Document Overview .............................................................................. VII
Chapter 1 Quick Start ......................................................................... 1-1
General Inspection ................................................................................ 1-2
Appearance and Dimensions ................................................................... 1-3
To Prepare for Use ................................................................................. 1-4
To Adjust the Supporting Legs .......................................................... 1-4
To Connect to AC Power .................................................................. 1-5
Turn-on Checkout ........................................................................... 1-5
Self-calibration ................................................................................ 1-5
To Set the System Language ............................................................ 1-6
Front Panel ........................................................................................... 1-7
Function Keys on the Front Panel ..................................................... 1-8
Utility Function Keys on the Front Panel ........................................... 1-10
Front Panel Key Backlight ............................................................... 1-11
Front Panel Connector .................................................................... 1-12
To Use the Numeric Keypad ............................................................ 1-14
Rear Panel ........................................................................................... 1-16
User Interface ...................................................................................... 1-18
Mouse/Keyboard/Touch Screen Operation Rule ........................................ 1-20
Mouse Operation Rule .................................................................... 1-20
Keyboard Operation Rule ................................................................ 1-21
Touch Screen Operation Rule .......................................................... 1-22
Menu Operation ................................................................................... 1-23
Parameter Setting................................................................................. 1-25
To Use the Built-in Help System ............................................................. 1-27
Fuse Replacement ................................................................................ 1-28
Mode Setting ....................................................................................... 1-29
Mode ............................................................................................ 1-29
Mode Setup ................................................................................... 1-30
Chapter 2 Functions of the Front Panel of GPSA ................................. 2-1
Basic Settings ....................................................................................... 2-2
FREQ ............................................................................................. 2-2
SPAN ............................................................................................. 2-8
RIGOL Contents
X RSA5000 User Guide
AMPT ............................................................................................. 2-9
Sweep and Function Settings................................................................. 2-14
BW ............................................................................................... 2-14
Sweep .......................................................................................... 2-18
Trigger ......................................................................................... 2-22
Trace ............................................................................................ 2-26
Tracking Generator (Option) ........................................................... 2-32
Measurement Settings .......................................................................... 2-35
Meas ............................................................................................ 2-35
Meas Setup ................................................................................... 2-38
Marker Measurement ............................................................................ 2-66
Marker .......................................................................................... 2-66
Marker To ..................................................................................... 2-73
Marker Function ............................................................................ 2-75
Peak ............................................................................................. 2-79
Chapter 3 Functions of the Front Panel of RTSA ................................. 3-1
Basic Settings ........................................................................................ 3-2
FREQ .............................................................................................. 3-2
SPAN .............................................................................................. 3-2
AMPT ............................................................................................. 3-5
Sweep and Function Settings................................................................... 3-6
BW ................................................................................................. 3-6
Sweep ............................................................................................ 3-8
Trigger ......................................................................................... 3-10
Trace ............................................................................................ 3-15
Measurement Settings .......................................................................... 3-17
Meas ............................................................................................ 3-17
Meas Setup ................................................................................... 3-25
Marker Setup ....................................................................................... 3-32
Marker .......................................................................................... 3-32
Marker To ..................................................................................... 3-32
Marker Function ............................................................................ 3-32
Peak ............................................................................................. 3-32
Chapter 4 Input/Output ..................................................................... 4-1
Chapter 5 Shortcut Key ...................................................................... 5-1
Auto Tune ....................................................................................... 5-1
Preset............................................................................................. 5-3
User ............................................................................................... 5-9
Quick Save ...................................................................................... 5-9
Cont ............................................................................................... 5-9
Single ............................................................................................. 5-9
Chapter 6 System Function ................................................................ 6-1
System ........................................................................................... 6-1
File................................................................................................. 6-9
Contents RIGOL
RSA5000 User Guide XI
Recall ........................................................................................... 6-13
Save ............................................................................................. 6-15
Chapter 7 Remote Control .................................................................. 7-1
Remote Control Overview ....................................................................... 7-2
Remote Control via USB ......................................................................... 7-3
Remote Control via LAN ......................................................................... 7-4
Chapter 8 Troubleshooting ................................................................. 8-1
Chapter 9 Appendix ............................................................................ 9-1
Appendix A: RSA5000 Accessories and Option List .................................... 9-1
Appendix B: Warranty ............................................................................ 9-3
Index ....................................................................................................... 1
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-1
Chapter 1 Quick Start
This chapter gives you a quick review about the appearance and dimensions of the
RSA5000 series, its front and rear panel, user interface, as well as announcements
during first use of the analyzer.
Contents in this chapter:
◼ General Inspection
◼ Appearance and Dimensions
◼ To Prepare for Use
◼ Front Panel
◼ Rear Panel
◼ User Interface
◼ Mouse/Keyboard/Touch Screen Operation Rule
◼ Menu Operation
◼ Parameter Setting
◼ To Use the Built-in Help System
◼ Fuse Replacement
◼ Mode Setting
RIGOL Chapter 1 Quick Start
1-2 RSA5000 User Guide
General Inspection
1． Inspect the packaging
If the packaging has been damaged, do not dispose the damaged packaging or
cushioning materials until the shipment has been checked for completeness and
has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrument
resulting from shipment. RIGOL would not be responsible for free
maintenance/rework or replacement of the instrument.
2． Inspect the instrument
In case of any mechanical damage, missing parts, or failure in passing the
electrical and mechanical tests, contact your RIGOL sales representative.
3． Check the accessories
Please check the accessories according to the packing lists. If the accessories
are damaged or incomplete, please contact your RIGOL sales representative.
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-3
Appearance and Dimensions
Figure 1-1 Front View Unit: mm
Figure 1-2 Vertical View Unit: mm
RIGOL Chapter 1 Quick Start
1-4 RSA5000 User Guide
To Prepare for Use
To Adjust the Supporting Legs
You can unfold the supporting legs to use them as stands to tilt the instrument
upwards for easier operation and observation. You can also fold the supporting legs
for easier storage or shipment when the instrument is not in use.
Figure 1-3 To Adjust the Supporting Legs
To unfold the
supporting legs
To fold the
supporting legs
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-5
To Connect to AC Power
Please use the power cord provided in the accessories to connect the spectrum
analyzer to the AC power source. The AC power supply specification of this spectrum
analyzer is 100-240 V, 45-440 Hz. The power consumption of the instrument cannot
exceed 95 W. When the spectrum analyzer is connected to the AC power source via
the power cord, the instrument automatically adapts to the voltage range, and you
do not need to select the voltage range manually.
CAUTION
To avoid electric shock, ensure that the instrument is correctly grounded.
Turn-on Checkout
After connecting the instrument to the power source properly, press the Power key
on the front panel to start the spectrum analyzer. Then, you will see an initial
splash screen. Following the start-up screen which shows the start-up initialization
process information, the sweep curve is displayed.
Self-calibration
After the instrument starts, execute self-calibration.
Press System → Alignment → Align Now, and then the instrument will perform
self-calibration with the internal calibration source.
RIGOL Chapter 1 Quick Start
1-6 RSA5000 User Guide
To Set the System Language
RSA5000 series spectrum analyzer supports multiple system languages. You can
press System → Language to switch the system language.
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-7
Front Panel
The front panel of RSA5000 is shown in the following figure.
Figure 1-4 Front Panel
Table 1-1 Front Panel Description
No.
Description
No.
Description
1
LCD
9
Numeric keypad
2
Menu softkeys
10
Tracking generator output
[1]
3
Back to previous menu item
11
Utility function key area
4
Function key area
12
Page up/down key
5
Help key
13
Speaker
6
Knob
14
Earphone jack
7
Arrow keys
15
USB HOST
8
RF input
16
Power key
Note
[1]
: This function is only available for RSA5065-TG/RSA5032-TG.
1 2 3
16 15 14 13 12 11 10 9 8
5
6
7
4
RIGOL Chapter 1 Quick Start
1-8 RSA5000 User Guide
Function Keys on the Front Panel
Figure 1-5 Function Keys
Table 1-2 Descriptions of Function Keys on the Front Panel
Function Key
Description
Sets the parameters such as center frequency, start frequency,
and stop frequency; enables the signal tracking function.
Sets the frequency span of the sweep.
Sets the parameters such as reference level, RF attenuator,
scale, and Y-axis unit. Enables preamp.
Sets the parameters such as resolution bandwidth (RBW) and
video bandwidth (VBW).
Sets the parameters such as input impedance, external gain,
and External Trigger 2. Selects the RF calibration signal.
Reads the amplitude and frequency of a certain point on the
trace via marker.
Opens the peak search menu and searches for peaks
immediately.
Sets the parameters related to trace.
Sets the parameters related to the tracking generator
[1]
.
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-9
Sets other system parameters based on the current marker
value.
Indicates the special functions of the marker, such as noise
marker, N dB bandwidth measurement, and frequency counter.
Sets the sweep parameters.
Sets the sweep/measurement mode to be continuous.
Sets the sweep/measurement mode to be single.
Sets the trigger source and its related parameters.
Selects the working mode of the spectrum analyzer.
Sets the parameters for the selected working mode.
Selects and controls the measurement function
[2]
.
Sets the parameters
[2]
for the selected measurement function.
Searches for signals automatically within full frequency range.
Restores the system to factory settings or user-defined state.
Sets the system parameters.
Recalls the files.
Manages the files.
Saves the files.
User-defined shortcut key.
Provides quick save function.
Note
[1]
: This function is only available for RSA5065-TG/RSA5032-TG.
Note
[2]
: This function is only available for the instrument installed with RSA5000-AMK.
RIGOL Chapter 1 Quick Start
1-10 RSA5000 User Guide
Tip:
Click the function keypad icon at the right corner of the LCD or finger-touch it,
and then the function keypad that corresponds to the specified keys on the front
panel appears. At this time, you can operate the instrument with the function
keypad.
Utility Function Keys on the Front Panel
Table 1-3 Descriptions of Utility Function Keys on the Front Panel
Locks all the keys (except the Power key) on the front panel.
Locks the touch screen of the instrument.
In the multi-window display mode, press this key to select the
specified window to zoom it in or out.
In the multi-window display mode, press this key to switch the
window.
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-11
Front Panel Key Backlight
The on/off state and the color of the backlights of some keys on the front panel
indicate the working state of the spectrum analyzer. The states are listed below.
1. Power Key
⚫ Flash on and off alternatively, in breathing state: indicates that the unit is in
stand-by state.
⚫ Constant on: indicates that the instrument is in normal operating state.
2. Auto Tune
When you press the Auto Tune key, it is illuminated. The instrument starts
sweeping within the full frequency range, searches for the signal with the
maximum amplitude and moves it to the center of the screen. After the sweep is
completed, the backlight turns off.
3. Tracking Generator (Option)
When the tracking generator function is enabled, the TG key is illuminated;
when disabled, the backlight of the TG key is off.
4. Single
When the Single key is illuminated, it indicates that the sweep/measurement
mode is single.
5. Keypad Locking Key
When the backlight is on, it indicates that all the keys (except the Power key) on
the front panel is locked. Press the key again to unlock the front panel keys, and
then the backlight of the key is off.
6. Touch Screen Locking Key
When the backlight is on, it indicates that the touch screen of the instrument is
locked. Press the key again to unlock the touch screen, and then the backlight is
off.
RIGOL Chapter 1 Quick Start
1-12 RSA5000 User Guide
Front Panel Connector
Figure 1-6 Front Panel Connector
1. USB HOST
The analyzer can serve as a "master" device to connect to the external USB
device. The USB storage device, mouse, and keyboard can be connected to the
instrument via the interface.
⚫ USB Storage Device
Reads the state file, trace+state file, measurement data file, limit line file,
and FMT file (in RTSA mode) from the USB storage device; or stores the
current instrument state, trace, measurement data, limit line, or FMT to the
USB storage device; or stores the contents currently displayed on the
screen to the USB storage device in ".jpg", ".bmp", or ".png" format.
⚫ Mouse
After the mouse is properly connected to the instrument, you can use it to
click on the screen to perform parameter setting and function configuration.
For details, refer to descriptions in "Mouse/Keyboard/Touch Screen
Operation Rule".
⚫ Keyboard
After the keyboard is properly connected to the instrument, you can use the
shortcut keys on the keypad to perform the same function as what you do
with the front panel keys. For details, refer to descriptions in
"Mouse/Keyboard/Touch Screen Operation Rule".
USB HOST
Earphone Jack
TG Output
RF Input
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-13
2. Earphone Jack
Insert the earphone to the jack to acquire the audio output of the demodulated
signal.
CAUTION
To avoid damaging your hearing, please turn the volume down
to zero first and then gradually turn the volume up after
putting on the earphone.
3. Gen Output 50Ω
The output of the tracking generator can be connected to a receiver through a
cable with an N male connector. This function is only available for
RSA5065-TG/RSA5032-TG.
CAUTION
To avoid damage to the tracking generator, the reverse power
cannot exceed +10 dBm when the frequency is lower than 10
MHz; the reverse power cannot exceed +20 dBm when the
frequency is greater than 10 MHz. The reverse DC voltage
should not exceed 50 V.
4. RF Input 50Ω
The input terminal of the signal under test. [RF Input 50Ω] can be connected
to the device under test (DUT) via a cable with an N male connector.
CAUTION
For the signal input to the RF input terminal, ensure that the
DC voltage component and the maximum continuous power of
the AC (RF) signal component do not exceed 50 V and +30
dBm to avoid damaging the instrument.
RIGOL Chapter 1 Quick Start
1-14 RSA5000 User Guide
To Use the Numeric Keypad
The numeric keypad is available on the front panel of RSA5000, as shown in the
figure below. The numeric keypad supports the Chinese characters, English
uppercase/lowercase letters, numbers, and common symbols (including decimal
point, space, and +/- signs), which are mainly used to edit the file/folder name and
set parameters (refer to "Parameter Setting").
Figure 1-7 Numeric Keypad
The numeric keypad consists of the following parts:
1. Number/Letter
⚫ Multiplexing keys for numbers and letters. They are used to directly input
the desired number or letter.
⚫ : press this key to input 1 in number input; to switch between
uppercase and lowercase letter in English input. This key is invalid in
Chinese input.
⚫ is the multiplexing key for 0 and space. Press this key to input 0 in
number input and space in Chinese or English input.
2.
⚫ Press this key to input a decimal point at the current cursor position in
number input.
⚫ This key is invalid in Chinese or English input.
Chapter 1 Quick Start RIGOL
RSA5000 User Guide 1-15
3.
⚫ The number input mode is, by default, selected for parameter setting. Press
this key to input the symbol ("+" or "-"). When you press the key for the
first time, the parameter symbol "-" is displayed, and when you press it
again, "+" is displayed.
⚫ When you input a file or folder name, press this key repeatedly to switch
among the Chinese input, English input, and number input.
4.
⚫ When editing the parameter, press this key to exit parameter input.
⚫ When you edit the filename with the on-screen keyboard, press this key to
hide the on-screen keyboard.
⚫ In multi-touch test, single-touch test, and keyboard test state, press this
key to exit the current test state.
⚫ When the instrument is in remote mode, press this key to return to the local
mode.
5.
⚫ When editing the parameter, press this key to delete the character to the
left of the cursor.
⚫ When editing the file name, press this key to delete the character to the left
of the cursor.
6.
During parameter editing, pressing this key will complete the input and insert a
default unit for the parameter.
RIGOL Chapter 1 Quick Start
1-16 RSA5000 User Guide
Rear Panel
The rear panel of RSA5000 is shown in the following figure.
Figure 1-8 Rear Panel
1. AC Power Cord Connector
The AC power supply specification of RSA5000 is: 100-240 V; 45-440 Hz.
2. Fuse Holder
You can replace the fuse. The fuse rating supported by the instrument is AC 250
V, T3.15 A.
3. OCXO (Option)
OCXO (Oven Controlled Crystal Oscillator) can provide a highly stable frequency
reference over temperature variations. For order information of the option, refer
to the datasheet manual. Note: A 40-minute warm-up is required for OCXO to
reach its nominal frequency.
4. Handle
You can rotate the handle upright and make the portable instrument easy to
carry.
5. 10MHz IN
RSA5000 can use the internal or external reference source.
⚫ When a 10 MHz external clock signal is received at the [10 MHz IN]
connector, this signal is used as the external reference source. At this time,
the status bar of the user interface displays "Ext". When the external
13
12
11
10
9
8
7
6
5
1 2 3 4
Loading...
