RIGOL RSA3000-EMI, RSA5000-EMI User manual

RIGOL

User’s Guide

EMI Measurement Application

Applicable to RSA5000-EMI/RSA3000-EMI

Feb. 2019

RIGOL (SUZHOU) TECHNOLOGIES INC.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

Guaranty and Declaration

Copyright

© 2018 RIGOL (SUZHOU) TECHNOLOGIES INC. All Rights Reserved.

Trademark Information

RIGOL is a registered trademark of RIGOL (SUZHOU) TECHNOLOGIES INC.

Publication Number

UGD23101-1110

Software Version

00.02.00

 RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
 RIGOL reserves the right to modify or change parts of or all the specifications

and pricing policies at the company’s sole decision.

 Information in this publication replaces all previously released materials.
 Information in this publication is subject to change without notice.
 RIGOL shall not be liable for either incidental or consequential losses in

connection with the furnishing, use, or performance of this manual, as well as
any information contained.

 Any part of this document is forbidden to be copied, photocopied, or rearranged

without prior written approval of RIGOL.

EMI User's Guide I

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

Safety Requirement

General Safety Summary

Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please
follow the instructions specified in this manual to use the instrument properly.

Use Proper Power Cord.

Only the exclusive power cord designed for the instrument and authorized for use
within the local country could be used.

Ground the Instrument.

The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, connect the earth terminal of the power cord to the Protective
Earth terminal before connecting any input or output terminals.

Connect the Probe Correctly.

If a probe is used, the probe ground lead must be connected to earth ground. Do not
connect the ground lead to high voltage. Improper way of connection could result in
dangerous voltages being present on the connectors, controls or other surfaces of
the oscilloscope and probes, which will cause potential hazards for operators.

Observe All Terminal Ratings.

To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.

Use Proper Overvoltage Protection.

Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the
product. Otherwise, the operator might be exposed to the danger of an electric
shock.

Do Not Operate Without Covers.

Do not operate the instrument with covers or panels removed.

Do Not Insert Objects Into the Air Outlet.

Do not insert objects into the air outlet, as doing so may cause damage to the
instrument.

Use Proper Fuse.

Please use the specified fuses.

II EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

Avoid Circuit or Wire Exposure.

Do not touch exposed junctions and components when the unit is powered.

Do Not Operate With Suspected Failures.

If you suspect that any damage may occur to the instrument, have it inspected by
RIGOL authorized personnel before further operations. Any maintenance,
adjustment or replacement especially to circuits or accessories must be performed
by RIGOL authorized personnel.

Provide Adequate Ventilation.

Inadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.

Do Not Operate in Wet Conditions.

To avoid short circuit inside the instrument or electric shock, never operate the
instrument in a humid environment.

Do Not Operate in an Explosive Atmosphere.

To avoid personal injuries or damage to the instrument, never operate the
instrument in an explosive atmosphere.

Keep Product Surfaces Clean and Dry.

To avoid dust or moisture from affecting the performance of the instrument, keep the
surfaces of the instrument clean and dry.

Prevent Electrostatic Impact.

Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.

Use the Battery Properly.

Do not expose the battery (if available) to high temperature or fire. Keep it out of the
reach of children. Improper change of a battery (lithium battery) may cause an
explosion. Use the RIGOL specified battery only.

Handle with Caution.

Please handle with care during transportation to avoid damage to keys, knobs,
interfaces, and other parts on the panels.

EMI User's Guide III

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

WARNING

avoided, will result in serious injury or death.

CAUTION

avoided, could result in damage to the product or loss of important data.

DANGER

It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.

WARNING

It calls attention to an operation, if not correctly performed, could
result in potential injury or hazard.

CAUTION

It calls attention to an operation, if not correctly performed, could

product.

Hazardous

Voltage

Safety Warning

Protective Earth

Terminal

Chassis Ground

Test Ground

Safety Notices and Symbols

Safety Notices in this Manual:

Indicates a potentially hazardous situation or practice which, if not

Indicates a potentially hazardous situation or practice which, if not

Safety Terms on the Product:

result in damage to the product or other devices connected to the

Safety Symbols on the Product:

IV EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

CAUTION

WARNING

supply.

Care and Cleaning

Care

Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.

Cleaning

Clean the instrument regularly according to its operating conditions.

1. Disconnect the instrument from all power sources.

2. Clean the external surfaces of the instrument with a soft cloth dampened with

mild detergent or water. Avoid having any water or other objects into the chassis
via the heat dissipation hole. When cleaning the LCD, take care to avoid
scarifying it.

To avoid damage to the instrument, do not expose it to caustic liquids.

To avoid short-circuit resulting from moisture or personal injuries, ensure
that the instrument is completely dry before connecting it to the power

Environmental Considerations

The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.

Product End-of-Life Handling

The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.

EMI User's Guide V

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

RSA Series Spectrum Analyzer Overview

RSA series is a new generation of cost-efficient real-time spectrum analyzer with high
performance. With superb performance specifications, clear user interface, the RSA
series allows you to operate it through various ways, such as pressing keys on the
front panel, using the touch screen, connecting the mouse and the keyboard.
Remote communication interfaces are also available. The instrument can be widely
used in education science, corporate R&D, industrial production, and other fields.

Document Overview

This document mainly introduces the front panel functions of the EMI mode.

Topics in this Manual:
Chapter 1 Quick Start

This chapter introduces the user interface of the spectrum analyzer in EMI mode and
its mode settings.

Chapter 2 Front Panel Function Keys

This chapter gives detailed function descriptions of the EMI's front panel keys and
the associated menu keys.

Chapter 3 Appendix

This chapter lists the options and accessories that can be ordered along with your
analyzer as well as the service and support information.

Format Conventions in this Manual:

1. Keys:

The keys on the front panel are usually denoted by the format of "Key Name
(Bold) + Text Box". For example, FREQ denotes the FREQ key.

2. Menu keys:

The menu softkeys are usually denoted by the format of "Menu Word (Bold) +
Character Shading". For example, Midspan Freq denotes the midspan menu
item under the FREQ function key.

3. Connectors:

The connectors on the front or rear panel are usually denoted by the format of
"Connector Name (Bold) + Square Brackets (Bold)". For example, [Gen Output

50Ω].

4. Operation Procedures:

 indicates the next step of operation. For example, FREQ  Midspan Freq

VI EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL

Model

Frequency Range

TG

RSA5065

9 kHz to 6.5 GHz

None

RSA5032

9 kHz to 3.2 GHz

None

RSA5065-TG

9 kHz to 6.5 GHz

6.5 GHz

RSA5032-TG

9 kHz to 3.2 GHz

3.2 GHz

RSA3045

9 kHz to 4.5 GHz

None

RSA3030

9 kHz to 3 GHz

None

RSA3045-TG

9 kHz to 4.5 GHz

4.5 GHz

indicates pressing FREQ on the front panel and then pressing the menu softkey

Midspan Freq.

Content Conventions in this Manual:

The RSA series spectrum analyzer includes the following models. This manual takes
RSA5065-TG as an example.

RSA3030-TG 9 kHz to 3 GHz 3 GHz

User Manuals of this Product:
Quick Guide, User’s Guide, Programming Guide, Data sheet, etc. For the desired
manual󱶡

EMI User's Guide VII

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Contents

Contents

Guaranty and Declaration ......................................................................... I

Safety Requirement ................................................................................. II

General Safety Summary........................................................................... II

Safety Notices and Symbols ..................................................................... IV

Care and Cleaning .................................................................................... V

Environmental Considerations .................................................................... V

RSA Series Spectrum Analyzer Overview ................................................ VI

Document Overview ............................................................................... VI

Chapter 1 Quick Start ........................................................................ 1-1

User Interface ........................................................................................ 1-2

Mode Setting ......................................................................................... 1-5

Mode .............................................................................................. 1-5

Mode Setup .................................................................................... 1-6

Install the Option ................................................................................... 1-8

Chapter 2 Front Panel Function Keys ................................................. 2-1

Basic Settings ........................................................................................ 2-2

FREQ .............................................................................................. 2-2

SPAN .............................................................................................. 2-5

AMPT ............................................................................................. 2-6

Sweep and Function Settings................................................................... 2-9

BW ................................................................................................. 2-9

Sweep .......................................................................................... 2-11

Trig ger ......................................................................................... 2-13

Trac e ............................................................................................ 2-16

Measurement Settings .......................................................................... 2-19

Meas ............................................................................................ 2-19

Meas Setup ................................................................................... 2-19

Marker Measurement ............................................................................ 2-30

Marker .......................................................................................... 2-30

er-> ...................................................................................... 2-34

Mark

Marker Func .................................................................................. 2-35

Peak ............................................................................................. 2-37

Input/Output ....................................................................................... 2-40

Input Impedance ........................................................................... 2-40

Ext Gain ....................................................................................... 2-40

Ext Trigger2 .................................................................................. 2-40

Corrections ................................................................................... 2-41

Shortcut Key ........................................................................................ 2-43

Auto Tune ..................................................................................... 2-43

Preset........................................................................................... 2-43

VIII EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Contents RIGOL

User ............................................................................................. 2-46

Quick Save .................................................................................... 2-46

Cont ............................................................................................. 2-46

Single ........................................................................................... 2-46

System Function ................................................................................... 2-47

System ......................................................................................... 2-47

File ............................................................................................... 2-56

Recall ........................................................................................... 2-60

Save ............................................................................................. 2-63

Chapter 3 Appendix ............................................................................ 3-1

Appendix A: RSA5000 Accessories and Option List .................................... 3-1

Appendix B: RSA3000 Accessories and Option List .................................... 3-2

Appendix C: Warranty ............................................................................ 3-3

Index ....................................................................................................... 1

EMI User's Guide IX

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1 Quick Start RIGOL

Chapter 1 Quick Start

This chapter gives you a quick review about the user interface, mode settings, and
option installation in the EMI mode of the RSA series spectrum analyzer. For its
appearance and dimensions, its front and rear panel, and precautions during first use
of the analyzer, refer to relevant chapters in

User's Guide

Contents in this chapter:

 User Interface
 Mode Setting
 Install the Option

.

RSA5000 User's Guide

and

RSA3000

EMI User's Guide 1-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 1 Quick Start

No.

Name

Description

1

Marker

Displays the current measurement results for the

Span).

2

RIGOL

Company logo.

3

System status

Rmt: indicates remote operation.

CISPR: indicates that the EMC standard.

4

Trace indicator

[1]

Displays information about the trace and the
detector.

5

Information setting

: indicates messages, such as the prompt

: indicates the speaker. You can tune it up and

2 3 4 5 6 7 8 9 10 11 12

1
17 16 15 14 13

User Interface

The user interface of EMI mode is shown in the following figure.

Figure 1-1 User Interface (EMI Mode)

Tab l e 1-1 User Interface Icons

measurement
result

marker (when no marker exists, the measurement
results display Frequency(Meter), Midspan Freq, and

Ext: indicates the external reference.
Uncal: indicates that the measurement has not be
calibrated.
PA on: indicates that the preamp has been enabled.

messages, alarm messages, and error messages.

1-2 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1 Quick Start RIGOL

down to increase and decrease the speaker volume,

inserted.

6

Measurement bar

Displays measurement settings.

7

Measurement
function

Displays the currently selected measurement
function.

8

Working mode

Displays the currently selected working mode.

9

Function keypad
icon

Clicks/Touches the icon to display the function
keypad interface.

10

Time

Displays the system time.

11

Menu title

Displays the currently selected menu name.

12

Menu item

Displays the menu item of the current function.

13

Menu page
number

Displays the current page and the total number of
pages.

14

Meter

mode

: indicates continue; : indicates single.

15

Meter display area

Displays the histogram of the meter and its
parameter information.

16

Trac e display area

Displays the scanned spectral trace and the setting
information after the pre-scan is performed.

17

Signal table display
area

Displays the searched signal, which correspond to
the marks in the trace.

Trace Number

Trace Typ e

Detector Type

or set it to mute .

: indicates the network settings. You can

configure network parameters.

: unlocks the front panel keys; : locks the

front panel keys.

: unlocks the touch screen; : locks the touch

screen.

: indicates that no USB storage device is inserted;

: indicates that a USB storage device has been

measurement

[1]:

Note

The display of the trace indicator is shown in the following figure:

 The first line displays the trace number. The color of the number is the same as that of

the trace. EMI mode only supports 3 traces.

 The second line displays the trace type, including W (Clear/Write), A (Trace Average),

M (Maximum Hold), and m (Minimum Hold). The letters with different colors and in
different forms show different meanings:

— The letter in blue indicates that the trace is updating.
— The letter in gray indicates that the trace is not updated.
— The letter with strikethrough and in gray color indicates that the trace will neither

be updated nor displayed.

— The letter with strikethrough and in blue color indicates that the trace is updating

but not displayed. It is useful in trace math operation.

EMI User's Guide 1-3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 1 Quick Start

 The third line displays the detector type of each trace, including P (Positive Peak), p

(Negative Peak), C (CISPR Average), R (RMS Average), Q (Quasi Peak), and V (Voltage
Average). The letter in blue in the third line (detector type) indicates that the detector
is in auto state; the letter in white indicates that it is in manual state.

1-4 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1 Quick Start RIGOL

Mode Setting

Mode

RSA provides four working modes: GPSA, RTSA, VSA (option), and EMI (option).
Press Mode to select the working mode.

Note: In different working modes, the functions of the keys on the front panel may
be different. Press Help to display the help information of the current working mode.
If you need help information for other modes, please exit the help interface first.
Then select the desired working mode and obtain the corresponding help
information.

1. GPSA

GPSA adopts two analysis methods: swept SA and FFT. It can not only carry out
frequency domain analysis, but also time domain (zero span) analysis.

Select GPSA. In this working mode, you can press Meas to select multiple
measurements. For details, refer to relevant chapters in Chapter 2 of

or

User's Guide

2. RTSA

RTSA provides the analysis function for the real-time signal, which can capture
the complex signal seamlessly.

Select RTSA. In this working mode, you can also press Meas to select multiple
measurements. For details, refer to relevant chapters in Chapter 3 of

User's Guide

3. VSA

VSA mode provides the standard vector signal analysis function. If you need this
function, please purchase this option (order No. RSA5000-VSA), and install it
according to instructions in "Install the Option".

4. EMI

EMI mode provides the EMI precompatibility measurement function. If you need
this function, please purchase this option (order No.
RSA5000-EMI/RSA3000-EMI), and install it according to instructions in "Install

the Option".

Note: when you purchase the RSA3000-EMI option, there is no need to

repeatedly purchase EMC filter and quasi-peak detector kit RSA3000-EMC. The
RSA3000-EMI option contains all the functions of RSA3000-EMC.

RSA3000 User's Guide

or

RSA3000 User's Guide

.

.

RSA5000

RSA5000

EMI User's Guide 1-5

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 1 Quick Start

Mode Setup

The Mode Setup menu is used to set parameters related to the working mode.

Open the global parameter setting menu for the selected working mode under

Mode.

Global CF Mode

Turns on or off the global center frequency. In any working mode, if you enable the
global center frequency mode, then the global center frequency will be set to the
center frequency of the current mode. When a different working mode is selected,
the global center frequency will be set to the center frequency of the previous
working mode, that is, the one that is before switching the working mode. If you
change the center frequency in any working mode, then the global center frequency
will change with it.

Global CF

Sets the global center frequency. It is only available when you turn on the global
center frequency.

Mode Preset

Resets the parameters of the current mode to be the factory default settings.

EMC Standard

Sets the EMC standard to "None" or "CISPR".
 When "None" is selected, the filter type is set to Gauss. At this point, the filter

bandwidth is -3 dB. The instrument will switch to "CISPR" standard
automatically when "Quasi Peak", "CISPR Average" or "RMS Average" detector is
selected. The filter type is set to EMI. At this point, the filter bandwidth is -6 dB.

 When "CISPR" is selected, for Meter 1, the detector is, by default, positive peak;

for Meter 2, the detector is, by default, quasi peak; for Meter 3, the detector is,
by default, CISPR average.

1-6 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1 Quick Start RIGOL

Meters Control

Sets the parameters of the meter.

1. Meters

1) Select Meter

Specifies the currently selected meter to "Meter1", "Meter2", or "Meter3".

2) Meter

Enables or disables the selected meter.
 When enabled, the histogram of the selected meter is displayed in the

meter display area of the user interface, and the corresponding
detector type is selected to perform the measurement.

 When disabled, the selected meter is not displayed and the system will

not perform the measurement.

3) Detector

Sets the detector of the selected meter, including "Pos Peak", "Quasi Peak",
"CISPR Average", "RMS Average", "Average(Vol)", and "Neg Peak".
Note: "Quasi Peak", "CISPR Average", "RMS Average", and "Average(Vol)"
are mutually exclusive. You can at most select two among the three items
("Quasi Peak", "CISPR Average", and "RMS Average").

4) Limit

Sets the limits of the selected meter.

5) Limit State

Enables or disables the limit line of the selected meter.

2. Dwell Time

Sets the dwell time of the meter detector.

3. Peak Hold Time

1) Peak Hold Type

Sets the max hold time type of the meter to "Adjust" or "Infinite".
 When "Infinite" is selected, the peak hold line of the selected meter will

not be reset. The Adjust Time menu is grayed out and disabled.

 When "Adjust" is selected, the peak hold line of the selected meter will

be reset to the current signal value after the set peak hold time. At this
time, you can use the Adjust Time menu to set the peak hold time.

2) Adjust Time

Sets the peak hold time of the meter.

4. Reset Peak Hold

Resets the peak hold lines of all the currently enabled meters to the current

EMI User's Guide 1-7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 1 Quick Start

signal value.

5. Couple to Signal

Enables or disables the coupling function of the meter and the signal table.
When enabled, the instrument will search for the signal frequency that is closest
to that of the current meter from the signal table automatically and modify the
meter frequency to the frequency of the signal.

6. Couple to Marker

Enables or disables the coupling function of the meter and the marker. When
enabled, the instrument will set the meter frequency to the current frequency at
the marker.

Install the Option

RSA provides various options (for option information, refer to "Accessories and
Option List") to expand the function of the spectrum analyzer. If you need to

purchase the option, please contact RIGOL sales representative. After you have
purchased the option successfully, you will get the corresponding key. Then perform
the following operations to install the option.

1. Acquire the License of the Option

 Log in to the RIGOL official website (www.rigol.com), click License

Activation to enter the "Registered product license code" interface.

 Input the correct key, serial number (press System  About System 

System Info to acquire the serial number of the instrument), and

verification code. Click Generate to acquire the option license. In the
license generation interface, click Download to download and save the
license file to the PC.

2. Install the Option

You can install the option via the following 2 methods.

1) Install the option by reading the license file from the USB storage device

 Copy the saved option license file to the root directory of the USB

storage device.

 Power on the instrument and insert the USB storage device. Press File

to enter the file operation menu interface.

 Press File Explorer, and then the file manager interface is displayed.

In the interface, find the directory of the USB storage device. Then
select the desired option license file (suffixed with ".lic"). Press Import
License to import the activation code and complete the reading of the
option installation file.

2) Install the option by sending SCPI Commands

1-8 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 1 Quick Start RIGOL

 Use the USB cable to connect the rear-panel USB DEVICE interface of

RSA to the USB HOST interface of the PC.

 Run Ultra Sigma. Search the resource and right-click the resource

name. In the displayed menu, select "SCPI Panel Control". Input the
following option installation command in the displayed SCPI control
panel: :SYSTem:LKEY <option info>@<license info>

<option info>

indicates the option order No., and <license info>

. Wherein,

indicates the option license code.

For example, the following command is used to install the option
RSA5000-PA.
:SYSTem:LKEY
RSA5000-PA@8AD12B8EBC5DF492D1D4289B7CBA5B6150BF6F5D752
D645C36D74530B05F39B49C461B23A50D6C94A34E06782AC4380070
B0D1A86BA84E02768391FFD70C2103

EMI User's Guide 1-9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Chapter 2 Front Panel Function Keys

This chapter describes in detail the front-panel function keys of RSA and their
associated menu functions in EMI mode.

Contents in this chapter:

 Basic Settings
 Sweep and Function Settings
 Measurement Settings
 Marker Measurement
 Input/Output
 Shortcut Key
 System Function

EMI User's Guide 2-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

start

f

stop

f

center

f

span

f

2)(

startstopcenter

fff +=

startstopspan

fff −=

Parameter

Remarks

Default

515 MHz

Range

0 Hz to Fmax

[1]

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step
Up/Down Arrow Key Step

step = RBW (meter)*10

Basic Settings

FREQ

Sets the frequency parameters of the analyzer.

The frequency range of the current channel can be expressed by either of two

/

groups of parameters: Start Frequency/Stop Frequency (

); or Span

Center Frequency/Span (

/

). If any of the four parameters is changed, the

other three parameters will make adjustment automatically to ensure the coupling
relationship among them:

(2-1)

(2-2)

Frequency(Meter)

It is used to set the frequency of the meter in frequency scan. You can use the
numeric keys, the knob, or arrow keys to modify this parameter; you can also use the
touch screen to modify the parameter.

Note: In the trace display area of the user interface, a purple vertical line is used to
mark the frequency of the meter. Press System  Display  Meters Freq Line,
you can turn on or off a purple vertical line.

Tab l e 2-1 Frequency (Meter)

step = RBW (meter)/2

[1]

Note

RSA5065, Fmax is 6.5 GHz; for RSA5032, Fmax is 3.2 GHz. For RSA3045, Fmax is 4.5 GHz; for
RSA3030, Fmax is 3 GHz.

: The maximum measurement frequency Fmax is determined by the instrument model. For

2-2 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

515 MHz

Range

5 Hz to (Fmax - 5 Hz)

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step
Up/Down Arrow Key Step

step = RBW (meter)*10

Parameter

Remarks

Default

midspan frequency - span/2

Range

0 Hz to (Fmax – 10 Hz)

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step
Up/Down Arrow Key Step

step = RBW (meter)*10

Midspan Freq

Sets the center frequency of the current channel.

Remarks:

 When you modify the midspan frequency, the start and stop frequency will be

modified automatically if the span remains to be unchanged.

 Modifying the midspan frequency indicates that the frequency is changed along

the current channel horizontally, and the adjustable range should be within the
frequency range specified in the technical specifications of the analyzer.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-2 Midspan Freq

step = RBW (meter)/2

Start Freq

Sets the start frequency of the current frequency channel.

Remarks:

 When you modify the start frequency, the span and midspan frequency will be

changed.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-3 Start Frequency

step = RBW (meter)/2

EMI User's Guide 2-3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

midspan frequency + span/2

Range

10 Hz to Fmax

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step
Up/Down Arrow Key Step

step = RBW (meter)*10

Start Freq Mode

Sets the coupling mode of the start frequency to "Manual" or "Auto". When "Auto" is
selected, the start frequency will automatically couple to the start frequency of the
first range among the currently enabled ranges in the scan table.

Stop Freq

Sets the stop frequency of the current frequency channel.

Remarks:

 When you modify the stop frequency, the span and midspan frequency will be

changed.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-4 Stop Frequency

step = RBW (meter)/2

Stop Freq Mode

Sets the coupling mode of the stop frequency to "Manual" or "Auto". When "Auto" is
selected, the stop frequency will automatically couple to the stop frequency of the
first range among the currently enabled ranges in the scan table.

Scale Type

Sets the scale type of X-axis to Lin or Log.

Remarks:

 The X-axis scale type is only related to data display, and will not affect scan and

trace data.

 Modifying the X-axis scale type will neither restart the scan nor affect the

number of scan points.

2-4 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

970 MHz

Range

10 Hz to Fmax

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-2-5 step

SPAN

Sets the span of the analyzer. Changing this parameter will change the frequency
parameters.

Span

Sets the frequency range of the current channel.

Remarks:

 When you modify the span, the start and stop frequency will be modified

automatically if the midspan frequency remains to be unchanged.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-5 Span

step = span/200, Min = 2 Hz

EMI User's Guide 2-5

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

106.99 dBuV

Range

-63.01 dBuV ~ 136.99 dBuV

Unit

dBm, dBmV, dBuV, V, W

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

step = scale

AMPT

Sets the amplitude parameters of the analyzer. You can modify these parameters to
make the signals under test be displayed with minimal errors in the current window,
easy for you to observe.

Ref Level

Sets the maximum power or voltage that can be displayed in the current window.

Remarks:

 The RF link is limited by the maximum mixer level, so when you reduce the

attenuation, the instrument may reduce the reference level to meet the mixer
level limit. When you increase the attenuation, the reference level remains
unchanged.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-6 Ref Level

step = scale/10

Att(Meter)

Sets the meter attenuator.

Remarks:

 In the frequency scan measurement, this value only affects the attenuation of

the meter.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

2-6 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

0 dB

Range

0 dB to 50 dB

Unit

dB

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

5 dB





















×=

0.001W

1

R

2

Volts

10lgdBm















=

V1

Volts

20lgVdB

µ

µ















=

1mV

Volts

20lgdBmV

R

2

Volts

Watts =

R

Tab l e 2-7 Att(Meter)

preamp off, step = 1 dB

RF Preamp(Meter)

Sets the meter preamplifier to be on or off. When the signal under test is a low-level
signal, turning on the preamplifier can reduce the displayed average noise level, so
that you can distinguish low-level signals from the noise. By default, the preamp gain
is 20 dB.

Y Axis Unit

Sets the unit of the Y-axis to dBm, dBmV, dBμV, Volts, or Watts. Wherein, dBm, dBmV,
and dBμV are for Log scale; Volts and Watts are for Linear scale. The default unit is
dBuV.

Remarks:

The conversion relations between units are as follows:

(2-3)

(2-4)

(2-5)

(2-6)

Wherein,

denotes the reference resistance.

EMI User's Guide 2-7

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

10 dB

Range

0.1 dB to 20 dB

Unit

dB

Knob Step

scale ≥ 1, step = 1 dB
scale < 1, step = 0.1 dB

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-2-5 step

Parameter

Remarks

Default

0 dB

Range

-300 dB to 300 dB

Unit

dB

Knob Step

level offset ≥ 1 or level offset ≤ -1: step = 1 dB;

-1 < level offset < 1, step = 0.1 dB

Left/Right Arrow Key Step

Up/Down Arrow Key Step

5 dB

Scale/Div

Sets the unit per division in the vertical axis.

Remarks:

 The amplitude range to be displayed can be adjusted by setting the scale.
 The range of the signal amplitude that can be displayed is as follows:

Minimum: reference level – 10 × current scale value
Maximum: reference level

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-8 Scale/Div

Ref Offset

Adds an offset value to the reference level to compensate for gains or losses
generated between the DUT and the analyzer input.

Remarks:

 The offset value does not affect the trace position, but will modify the reference

level readout and the marker amplitude readout.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-9 Reference Level Offset

2-8 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

120 kHz

Range

100 Hz to 10 MHz

[1]

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-3-10 step

Frequency (Meter) Fmet

RBW

Fmet < 150 kHz

200 Hz

150 kHz ≤ Fmet < 30 MHz

9 kHz

30 MHz ≤ Fmet < 1 GHz

120 kHz

Fmet ≥ 1 GHz

1 MHz

Sweep and Function Settings

BW

RBW(Meter)

Sets the resolution bandwidth (RBW) of the meter. You can use the numeric keys, the
knob, or arrow keys to modify this parameter; you can also use the touch screen to
modify the parameter.

Tab l e 2-10 RBW

at 1-3-10 step

[1]

Note

range is as above. When "EMI" filter is selected, resolution bandwidth can only be 200 Hz, 9 kHz,
120 kHz, or 1 MHz.

RBW Mode(Meter)

Sets the RBW mode of the meter to "Manual" or "Auto".

Remarks:

 When you select "Manual", use the RBW(Meter) menu to set the RBW value.
 When you select "Auto", use the RBW to automatically couple to the frequency

 When the EMC measurement standard is "None", the RBW Mode(Meter)

: When the EMC measurement standard is "None" and "Gauss" filter is selected, the RBW

of the meter.
menu is grayed out and disabled. You can manually set the RBW. When the EMC

measurement standard is "CISPR", select the Auto RBW mode.

EMI User's Guide 2-9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Filter Type(Meter)

Sets the RBW filter type.

Remarks:

 The RSA series supports two kinds of RBW filters: Gauss and EMI.
 When the EMC measurement standard is "CISPR", the Filter Type(Meter)

menu is grayed out and disabled. By default, EMI filter is selected. When "EMI"
is selected, resolution bandwidth can only be 200 Hz, 9 kHz, 120 kHz, or 1 MHz.

 When the EMC measurement standard is "None", the default filter is "Gauss".

2-10 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Sweep

Sets the sweep-related parameters.

Frequency Scan

Sets the current frequency scan mode to "Single" or "Cont".

Start/Stop

Selects "Start" to start pre-scan, peak search, or the final measurement according to
the selected frequency scan mode.
Selects "Stop" to stop the current scan, search, or measurement.

Pause/Resume

Selects "Pause" to pause the current pre-scan, peak search, or final measurement
operation. Note, the pause operation can be executed only within the two scan
ranges.
Selects "Resume" to resume scan, search, or measurement and start the operation
from the scan point where you pause.

Clear List and Start

After you press or tap this menu, all the signals in the signal table will be cleared.
Then, the selected scan sequence will be launched. If the selected scan sequence is
being scanned and is in the Cont scan mode, you need to select "Stop" under the
Start/Stop menu to stop scan. In other conditions, when the measurement is
completed, the scan sequence is stopped automatically.

Continue(Meter)

Sets the measurement mode of the meter to Continuous. Only when you set the
current setting to Single scan mode or restart to launch the scan sequence, can the
measurement be stopped.

EMI User's Guide 2-11

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Single(Meter)

Sets the measurement mode of the meter to Single. The meter performs a single
measurement with the meter and then stops. You can launch the meter by switching
the mode to Continuous.

2-12 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

1 μs

Range

0 μs to 500 ms

Unit

s, ms, μs, ns, ps

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-1.5-2-3-5-7.5 step

Trigger

Selects the trigger source and sets trigger-related parameters.

Trigger Source

Sets "Free Run", "External 1", or "External 2" to be the trigger source.

Free Run

The trigger conditions are met at any time, that is, the analyzer generates trigger
signals continuously.

External 1

In this mode, an external signal is input via the [TRIGGER IN] connector on the
rear panel. When the signal meets the set trigger conditions, trigger signals are
generated.

1. Slope

Sets the trigger polarity for External Trigger 1 to "POS" or "NEG".

2. Delay State

Enables or disables the trigger delay function. After the trigger delay function is
enabled, you can set the trigger delay time.

3. Delay Time

Sets the time interval during which the instrument waits to start the sweep
operation after the trigger signal that meets the trigger conditions is generated.
You can use the numeric keys, the knob, or arrow keys to modify this parameter;
you can also use the touch screen to modify the parameter.

Tab l e 2-11 Trigger Delay Time

trigger delay/100, Min = 1 μs

EMI User's Guide 2-13

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

1 μs

Range

0 μs to 500 ms

Unit

s, ms, μs, ns, ps

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-1.5-2-3-5-7.5 step

External 2

Press Input/Output  Ext Trigger2 to select "In". Then, an external signal is
input via the [TRIGGER IN/OUT] connector on the rear panel. When the signal
meets the set trigger conditions, trigger signals are generated.

Note: The input signal frequency on the external trigger interface should not be
greater than 1 MHz.

1. Slope

Sets the trigger polarity for External Trigger 2 to "POS" or "NEG".

2. Delay State

Enables or disables the trigger delay function. After the trigger delay function is
enabled, you can set the trigger delay time.

3. Delay Time

Sets the time interval during which the instrument waits to start the sweep
operation after the trigger signal that meets the trigger conditions is generated.
You can use the numeric keys, the knob, or arrow keys to modify this parameter;
you can also use the touch screen to modify the parameter.

Tab l e 2-12 Trigger Delay Time

trigger delay/100, Min = 1 μs

Hold-off State

Turns on or off the trigger hold-off function.

Hold-off Time

Sets the hold-off time between trigger signals. You can use the numeric keys, the
knob, and the arrow keys on the front panel to modify this parameter; also you can
modify it on the touchscreen.

When the trigger conditions are met, the trigger occurs. Then, the delay begins, and

2-14 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

100 ms

Range

100 μs to 500 ms

Unit

s, ms, μs, ns, ps

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-1.5-2-3-5-7.5 step

Parameter

Remarks

Default

100 ms

Range

1 ms to 100 s

Unit

s, ms, μs, ns, ps

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

at 1-1.5-2-3-5-7.5 step

the hold-off time begins. During the hold-off time, new trigger signals will be ignored.
For a free-running trigger, the hold-off value is the minimum time between two
trigger signals.

Tab l e 2-13 Trigger Hold-off Time

trigger holdoff time/100, Min = 1 μs

Auto Trig State

Enables or disables the auto trigger function.

Auto Trig

Sets the time that the instrument will wait for the trigger conditions to be met. When
the set waiting time times out, the instrument will not wait and start to initiate the
sweep measurement.

Tab l e 2-14 Auto Trigger Time

auto trigger time/100, Min = 1 μs

EMI User's Guide 2-15

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Trace

Displays the trace-related parameters.

Selected Trace

RSA series can display at most 3 traces synchronously in EMI mode. Select the
corresponding trace to set the relevant parameters for the specified trace. By default,
Trace1 is selected and enabled, and the trace type is "Clear Write".

Note: The trace currently displayed on the screen can be saved to the internal or
external memory. If needed, you can recall it at any time. Press Save to save it
according to descriptions in "Save".

Trace Type

Sets the type of the currently selected trace. The system calculates the scanned data
by a specific operation method according to the selected trace type. The results will
not be displayed unless you set "Trace Update" and "Trace Display" to "On". Trace
types include Clear Write, Average, Max Hold, and Min Hold.

1. Clear Write

Sets the trace data to a minimum value, and displays the real-time scanned data
of each point on the trace.

2. Average

Displays an average trace, which is represented by averaging the data of each
point on the trace. The type of the trace is displayed to be smooth.

3. Max Hold

Maintains and displays a max hold trace, which represents the maximum data
value on a point-by-point basis. When a new maximum value is generated, data
will be updated, and the newly updated maximum value prevails.

4. Min Hold

Maintains and displays a min hold trace, which represents the minimum data
value on a point-by-point basis. When a new minimum value is generated, data
will be updated, and the newly updated minimum value prevails.

Trace Det

Sets the detector for the current measurement. The selected detector can be applied
to the current trace. The available trace detectors include Pos Peak, Quasi Peak,

2-16 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

∑

=

×=

N

iAV

v

N

V

1i

1

AV

V

i

v

CISPR Average, RMS Average, Average(Vol), and Neg Peak.

1. Pos Peak

For each trace point, Positive Peak detector displays the maximum value of data
sampled within the corresponding time interval.

2. Quasi-Peak

The quasi-peak detector is implemented according to CISPR standard.

3. CISPR Average

The average detector is implemented according to CISPR standard.

4. RMS Average

The RMS average detector is implemented according to CISPR standard.

5. Average

For each data point, average (see equation (2-7)) all the sampled data within
the corresponding time interval and display the result.

(2-7)

Wherein,

values for each point displayed;

is the average of voltage in V; N is the number of sampled

is the envelope of the sampled value in V.

6. Neg Peak

For each trace point, Negative Peak detector displays the minimum value of data
sampled within the corresponding time interval.

Detector Auto

Enables or disables the Detector Auto function. By default, Detector Auto is enabled.
If you set the detector type manually, the Detector Auto function is disabled
automatically.

Trace Update

Enables or disables trace update.

EMI User's Guide 2-17

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Trace Display

Enables or disables the trace display.

Remarks:

 The trace state and the parameter settings for the corresponding state are as

follows:

 Active: Trace Update and Trace Display are "On".
 View: Trace Update is "Off", and Trace Display is "On".
 Clear: Trace Update and Trace Display are "Off".
 Back-end: Trace Update is "On", and Trace Display is "Off".

 In most cases, the inactive trace data keep unchanged. However, the data may

be changed in the following conditions:

 Load the stored data to trace.
 Trace data are cleared by the trace clear function.

2-18 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Parameter

Remarks

Default

1

Range

1 to 10,000

Unit

None

Knob Step

1

Left/Right Arrow Key Step

1

Up/Down Arrow Key Step

1

k

NewdataOldAvg1)(k

NewAvg

+×−

=

Measurement Settings

Meas

Provides the frequency scan measurement function.

Meas Setup

Avg Setting

1. Avg Number

Specifies the number of counts (N) for Average, Max Hold, and Min Hold. For
Average, the greater the value of N, the smoother the trace is displayed.
In Average, Max Hold, and Min Hold modes, the instrument will not stop
sweeping until the sweep count has reached N only when the scan sequence is
"Scan Only" and the instrument performs the single sweep. Except "Scan Only",
when other scan sequences are started, if the selected trace type is "Average",
"Max Hold", or "Min Hold", the measurement will stop after a specified number
of times of measurement is executed.

Tab l e 2-15 Average Count

2. Avg Type

Selects the average type to "Log", "RMS", or "Scalar".
 Log: In this mode, all filtering and averaging processes select the log unit

(dB). This average type is the most effective one for finding the low-level
signal that is close to the noise amplitude. The formula is shown as follow:

In the above formula, the parameter unit is dB.

 RMS: In this mode, all filtering and averaging processes work on the power

(the square of the amplitude) of the signal. This average type is best for
measuring the true time average power of complex signals. As the voltage
result is in proportion to the square root of the average of the square of the
voltage, it is also called the root mean square. The formula is shown as
follows:

EMI User's Guide 2-19

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

(2-8)

RIGOL Chapter 2 Front Panel Function Keys

）

k

10101)(k

10log

（

NewAvg

10

Newdata

10

OldAvg

+×−

=

）（

k

10101)(k

20logNewAvg

20

Newdata

20

OldAvg

+×−

=

(2-9)

In the above formula, the parameter unit is dB.

 Scalar: In this mode, all filtering and averaging processes work on the

voltage envelope of the signal. This average type is the most appropriate
one for observing the great envelope fluctuations of AM or pulse-modulated
signals such as radar and TDMA transmitters. The formula is shown as
follows:

(2-10)

In the above formula, the parameter unit is dB.

3. Avg Auto

Sets the status of auto average. When the auto average function is enabled, the
instrument will select the best average type based on the current settings. When
you select one of the average types manually, the instrument will apply the
selected type, and the auto average status is set to Manual.

Limit

Sets the parameters of limit lines. After you press Preset, the limit line
measurement function is disabled, but the data of the limit lines will be reserved. The
limit line data will only be deleted when the loading mode is
the measurement mode, the limit line data will not be deleted.

1. Test Limits

Selects whether the displayed traces are tested against the displayed limit lines.
For each displayed trace, the corresponding limit line is turned on, and a
message will be displayed at the upper-left corner of the trace to indicate
whether the test passes or fails.

2. Select Limit

Selects the current limit line. By default, it is Limit1.

3. Limit State

Enables or disables the display of the limit line. When the limit line is on, the
measurement interface displays the limit line, and the corresponding traces are
tested against the current limit lines. Each limit line is displayed in a different
color.

4. Edit Limit

When "Display State" of the limit line is set to "On", this menu is valid. When you

Default. When you exit

2-20 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

press this key to enter the editing menu, open the limit editing window.
 X to CF: When "Fixed" is selected, the frequency of the current editing

point will not be affected by the midspan frequency. When "Relative" is
selected, the frequency of the current editing point is the difference
between the frequency of the point and the current midspan fr eque ncy. A t
this time, if the midspan frequency changes, then the position of the
current editing point changes along with the midspan freq uency.

 Y to Ref: When "Fixed" is selected, the amplitude of the current editing

point will not be affected by the reference level. When "Relative" is selected,
the amplitude of the current editing point is the difference between the
amplitude of the point and that of the current reference level. At this time, if
the reference level changes, then the position of the current editing point
changes along with the reference level.

 Margin State: Enables or disables the display of the margin. When you

enable the display of the margin, the measurement interface displays the
margin lines; when you disable the display of the margin, the margin is
invalid.

 Margin: Sets the margin for the current limit line.
 Freq Interpolation: Sets the interpolation mode between two frequency

points in the limit line table to "Linear" or "Log".

 Navigation: Selects the first line of the limit line table.
 Frequency: Edits the frequency of the current point. When Rel Freq is

selected, edit the frequency difference between the frequency of the
current point and the center frequency.

 Amplitude: Edits the amplitude of the current point. If the Rel Ampt is

enabled, edit the amplitude difference between the amplitude of the
current point and the reference level.

 Append Point: Inserts an edit point.
 Delete Point: Deletes the point that you are editing.
 Build From: Sets a trace for building the limit line. The range is from

Trace1 to Trace3.

 Build: Builds the limit line from the selected trace.
 Copy From: Copies the selected limit line into the current limit line. The

range is from Limit1 to Limit6.

 Copy: Performs the limit line copy operation.
 X Offset: Sets the frequency offset of the current limit line.
 Y Offset: Sets the amplitude offset of the current limit line.
 Apply Offset: Adds the X and Y offsets to each point of the current limit

line, then resets the X and Y offset values to 0.

Tip: You can touch any point in the trace display window on the screen to
edit the current point to be the limit line data point. You can also drag the
point to adjust the position of the current edit point, that is, to change the
frequency/amplitude of the current point.

EMI User's Guide 2-21

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Description

NO.

indicates signal sequence number.

Checkbox

"√" indicates that the signal is marked.

Trc

indicates the measured trace.

Freq

indicates the frequency of the searched frequency point that
meets the peak condition.

Peak Amp

indicates positive peak detector amplitude.

performed. If there is no measurement data, "--" is displayed.

QP Amp

indicates quasi peak detector amplitude

performed. If there is no measurement data, "--" is displayed.

5. Test Trace

Sets the trace for the current limit line test.

6. Delete Limit

Deletes the current limit line. The data of the current limit line will be cleared
and they will be restored to factory defaults.

7. Delete All Limits

Deletes all limit lines. After you press the menu, the data of all the limit lines will
be cleared and they will be restored to factory defaults.

Signal Table

Sets the parameters for the signal table.

The signal table is displayed below the user interface, as shown in the figure below.

Displays the corresponding amplitude when the current trace
detector is pos peak after the search operationis executed.
Displays the corresponding detection amplitude of the final
measurement detector 1 type after the final measurement is

Displays the corresponding amplitude when the current trace
detector is quasi-peak after the search operationis executed.
Displays the corresponding detection amplitude of the final
measurement detector 2 type after the final measurement is

2-22 EMI User's Guide

Figure 2-1 Signal Table

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

CAvg Amp

indicates CISPR average detector amplitude

"--" is displayed.

Peak Lim1△

Difference between positive peak detector amplitude and

no measurement data, "--" is displayed.

QP Lim1△

Difference between quasi-peak detector amplitude and limit1.

no measurement data, "--" is displayed.

CAvg Lim1△

Difference between CISPR average detector amplitude and

no measurement data, "--" is displayed.

Displays the corresponding amplitude when the current trace
detector is CISPR average after the search operationis
executed. Displays the corresponding detection amplitude of
the final measurement detector 3 type after the final
measurement is performed. If there is no measurement data,

limit1.
Only when the corresponding limit line is enabled and the final
measurement is performed, the difference between the
detector amplitude of the currently selected measurement
detector1 type and the limit line (1 to 6) is displayed. If there is

Only when the corresponding limit line is enabled and the final
measurement is performed, the difference between the
detector amplitude of the currently selected measurement
detector2 type and the limit line (1 to 6) is displayed. If there is

limit1.
Only when the corresponding limit line is enabled and the final
measurement is performed, the difference between the
detector amplitude of the currently selected measurement
detector3 type and the limit line (1 to 6) is displayed. If there is

Note: The signal table currently displayed on the screen can be saved to the internal
or external memory. If needed, you can recall it at any time. Press Save to save it
according to descriptions in "Save".

1. Select Signal

Selects signal n in the signal table.

2. Page Up

If the current signal table has several pages of data, press this key to go to the
previous page to view the data.

3. Page Down

If the current signal table has several pages of data, press this key to go to the
next page to view the data.

4. Signal->Meters

Modifies the frequency of the meter to the frequency of the selected signal.

Find Quality Products Online at: [e-mail]

EMI User's Guide 2-23

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

5. Mark Signal

Performs the signal marking operation. Marks the checkbox next to the marked
signal.

6. Mark All

Marks all the signals in the signal table.

7. Clear Mark

Unmarks all the signals in the signal table.

8. Delete

Deletes the signal of the selected type.

 Selected: deletes the selected signal from the signal table.
 All: marks and deletes all the signals in the signal table.
 Marked: deletes all the marked signals from the signal table.
 Unmarked: deletes all the unmarked signals from the signal table.

9. Signal Zoom

Zooms the coordinate display of the currently selected signal to 10% of the
current span by taking the midspan frequency as the reference.

10. Zoom Out

Returns the coordinate display of the currently selected signal to its previous
display set before the Signal Zoom.

11. Sort Signals

Sorts the signal in the signal table according to "frequency", "detector
amplitude", or "limit delta detector amplitude".
Wherein, detector amplitude includes "Det 1 Amp", "Det 2 Amp", and "Det 3
Amp"; limit delta detector amplitude includes "△Det 1 Amp", "△Det 2 Amp",
and "△Det 3 Amp".

12. Sort Order

Selects the signal to be sorted in ascending or descending order.

13. Auto Sort

Enables or disables the auto sort function. When enabled, the measurement will
sort the signal according to the previously set sort order and sort type.
Otherwise, the signal will be added to the signal table in the descending order of
the trace amplitude.

14. Search Criteria

Sets the search criteria. When the peak that meets the conditions is searched,
the signal will be added to the signal table.
 Peak Criteria: performs the search and finds the peak that meets the peak

criteria.

2-24 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

 Pk Crit & LIM: performs the search and finds the peak that meets the peak

criteria and limit line criteria.

 SubRng & LIM: performs the search and finds the peak that meets the peak

criteria for each subrange and limit line criteria. After this mode is selected,
the whole span is divided into n subranges. Wherein, n is set by the

Subrange Num menu.

15. Peak Num State

Enables or disables the setting of the number of peaks.

16. Peak Num

When the search criteria is "Peak Criteria" or "Pk Crit & LIM", set the maximum
number of peaks searched.

17. Subrange Num

Sets the number of subranges for the signal search.

Scan Table

Sets the parameters for 10 ranges in the scan table.

Note: The scan table currently displayed on the screen can be saved to the internal
or external memory. If needed, you can recall it at any time. Press Save to save it
according to descriptions in "Save". If a scan sequence is currently executed, then
the Scan Table menu is grayed out and disabled.

1. Select Range

Specifies the selected range. 10 ranges are available for you to choose.

2. Range

Enables or disables the selected scan range. When enabled, the selected range
will be chosen as a part of the measurement. Besides, you can tap the checkbox
at the left side of the selected range in the pre-scan setting table. If the
checkbox is highlighted and with a tick "√" being displayed, it indicates that the
selected range is enabled.

3. Start Freq

Sets the start frequency of the selected scan range.

4. Stop Freq

Sets the stop frequency of the selected scan range.

5. Points

Sets the number of scan points for the selected scan range.

EMI User's Guide 2-25

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

6. Scan Time

Sets the time to scan the selected scan range for one time.

7. Auto Scan Time

Enables or disables the auto scan time function of the selected scan range.
When enabled, the instrument is configured with a scan time automatically.
When disabled, you can press Scan Time to manually set the scan time of the
selected range.

Besides, you can also tap the checkbox at the left side of scan time of the
selected range in the pre-scan setting list. If the checkbox is checked with a tick
"√" and highlighted, it indicates that auto scan time within the selected range is
enabled.

8. RBW

Sets the RBW of the selected scan range. Reducing RBW can gain a higher
frequency resolution, but will also prolong the sweep time.

9. Auto RBW

Enables or disables the auto RBW function. When enabled, the instrument is
configured with a RBW automatically. When disabled, you can press RBW to
manually set the RBW of the selected range.

Besides, you can also tap the checkbox at the left side of RBW of the selected
range in the pre-scan setting list. If the checkbox is checked with a tick "√" and
highlighted, it indicates that auto RBW within the selected range is enabled.

10. Filter Type

Sets the RBW filter type in the selected range to "Gauss" or "EMI".
When the EMC measurement standard is "CISPR", the Filter Type menu is
grayed out and disabled. By default, EMI filter is selected. When "EMI" is
currently selected, resolution bandwidth can only be 200 Hz, 9 kHz, 120 kHz, or
1 MHz. When the EMC measurement standard is "None", the default filter is
"Gauss".

11. Attenuation

Sets the attenuation value of the selected scan range.

12. Auto Att

Enables or disables the auto attenuation function of the selected scan range.
When enabled, the instrument is configured with an attenuation value
automatically. When disabled, you can press Attenuation to manually set the
attenuation value of the selected range.

Besides, you can also tap the checkbox at the left side of attenuation of the
selected range in the pre-scan setting list. If the checkbox is checked with a tick

2-26 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

"√" and highlighted, it indicates that auto attenuation within the selected range
is enabled.

13. RF Preamp

Enables or disables the preamplifier of the selected scan range.

14. Scan Table

Enables or disables the scan table display. When enabled, the scan table will be
displayed in the user interface.

Scan Sequence

Selects the measurement sequence.

Remarks:

 You need to select "Start" under Sweep  Start/Stop menu to start the

selected measurement sequence.

 If a scan sequence is currently executed, then the Scan Sequence menu is

grayed out and disabled.

1. Scan Only

Only performs the pre-scan operation.

2. Search Only

Only performs the peak search operation.

3. Scan-Srch-Ms

Performs the pre-scan, peak search, and final measurement.

4. Scan-Search

Performs the pre-scan and peak search.

5. Search-Meas

Performs the peak search and final measurement.

6. (Re)measure

Performs the final measurement.

EMI User's Guide 2-27

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

(Re)measure

Sets the type of the final measurement to "Curr Signal", "All Signals", or "Marked
Sigs".

Remarks:

 If you select the type of the marked signal, but the marked signal is not found in

the signal table, then re-measurement cannot be executed.

 If a scan sequence is currently executed, then the Re(measure) menu is

grayed out and disabled.

Detectors

Sets the detector parameters related to the final measurement. If a scan sequence is
currently executed, then the Detectors menu is grayed out and disabled.
Note: when these detector parameters are set, the detector parameters under the

Marker Func key will also be changed accordingly.

1. Select Detector

Select the detector to be "Detector 1", "Detector 2", or "Detector 3".

2. Dwell Time

Sets the dwell time of the selected detector.

3. Detector

Sets the type of the selected detector. The available detector types include Pos
Peak, Quasi Peak, CISPR Average, RMS Average, Average, and Neg Peak. You
can also turn off the detector.

4. Limit for Delta

Sets the limit line of the current detector measurement, so as to obtain the limit
delta data in the signal table. The available limits include "Limit 1" through "Limit
6".

Auto Couple

When you enable "Auto Couple" function, all the manual/auto settings in the current
measurement mode will be set to "Auto". This operation does not affect other
measurement modes.
In auto state, the auto coupled parameters are changed with their coupled
parameters. The auto coupling operation will ensure the optimal performance of the
instrument. After the operation, all the auto coupled parameters will immediately be
automatically reset based on the coupled parameters.

2-28 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Meas Preset

Restores the parameters associated with the current measurement to their factory
default values.

EMI User's Guide 2-29

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys





Marker

Marker Readout

Marker Measurement

Marker

Marker is a triangle sign (as shown in the following figure), which is used for marking
the point on the trace. You can read the amplitude and frequency of each point on
the trace via marker.

Figure 2-2 Marker

Remarks:

RSA offers 8 markers, and only a single marker or one pair of markers can be

turned on each time.

In the Marker menu, you can use the numeric keys, the knob, or the arrow keys

to modify frequency or time; to view the readout of different points on the trace.
You can also use the touch screen to do the above things.

2-30 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL











Selected Marker

RSA series provides 8 markers. By default, Marker1 is selected under "Selected
Marker". After you select a marker, you can set parameters such as the marker mode
and the marker trace. The currently enabled marker will be marked on the trace
selected under Marker Trace. The readout of the currently activated marker at the
marker point will be displayed in the measurement result bar at the upper-left corner
of the screen.

Marker Mode

Sets the type of the marker. The available marker modes include Position, Delta, and
Off.

1. Position

It is used to measure the X (Frequency) and Y (Amplitude) values of a certain
point on the trace. When "Position" is selected, a marker whose name is Marker
plus a marker number (such as "Marker1") appears on the trace.

Remarks:

If no active marker exists currently, a marker will be enabled at the midspan

fr equ ency. If the current marker is found in the range where no trace is

2. Delta

displayed, a marker will be enabled at the midspan frequency, and it will be
displayed at the bottom of the trace display area .

The readout resolution of the X-axis is related to the span. To obtain a

higher readout resolution, reduce the span.

It is used to measure the difference between "reference point" and "certain
point on the trace": X (frequency) and Y (amplitude) value.

Remarks:

If an active marker exists currently, then activate a reference marker at the

current marker; otherwise activate both the reference marker and Delta
marker at the same time at the midspan frequency.

When you change the position of the Delta marker, the position of the

reference marker remains unchanged, but the frequency difference
between the two markers will change along with it.

The frequency difference between the two markers and the amplitude

difference between them are displayed in the measurement result bar at
the upper-left corner of the screen.

EMI User's Guide 2-31

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Application of the "Delta" Marker

amplitude displayed in the measurement results is S/N ratio.

Parameter

Remarks

Default

515 MHz

Range

0 Hz to 6.5 GHz

Unit

GHz, MHz, kHz, Hz

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

step = span/(sweep points – 1)*100

It is used to measure the S/N ratio of the single spectrum signal.
Move the reference marker to the location where the signal resides, and
move the Delta marker to the location where the noise resides. The

3. Off

Turns off the marker currently selected. Then, the marker information displayed
on the screen and the functions concerning the marker will also be disabled.

Reference Marker

Sets the reference marker for the current marker. By default, the reference marker is
the marker next to it.

Remarks:

 Each marker can have another marker to be its reference marker.
 If the current marker is a Delta marker, the measurement result of the marker

will be determined by the reference marker.

 Any marker cannot take itself to be the reference marker.

Marker Trace

Selects the trace that the current marker marks. It can be Trace 1, Tra ce 2, and Trace

3. One marker can only mark one trace. The selected trace determines the position
of the marker and the final readout results.

Marker Frequency

Sets the frequency of the marker to change the position of the marker on the trace.
Press this key to modify the value to change the position of the marker.

Tab l e 2-16 Marker Frequency

step = span/(sweep points – 1)

2-32 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Line State

Enables or disables the marker line.

Remarks:

 When you enable the marker line, a cross line is displayed at the amplitude point

where the marker resides. The width of the horizontal line and the height of the
vertical line are consistent with the length and height of the graticule in the
waveform display area.

 If the marker is not visible in the selected area, extend the marker line to the

display area for better observation. This function is useful for the marker outside
the display area. The marker extension line can better display the amplitude of
the marker, making it easy for you to observe and compare.

Couple Markers

Enables or disables the couple marker function. When this function is enabled,
moving any marker will enable other markers (except the Off marker) to move with
it.

All Markers Off

Turns off all the enabled markers and their related functions.

EMI User's Guide 2-33

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys











Marker->

Adds the new measurement results to the existing signal table.

Mkr->List

Adds the frequency at the current marker to the signal table.

Remarks:

The newly added signal frequency information is sorted according to the current

ordering rule.

If the trace detector matches the detector in the signal table, then the

corresponding amplitude and limit delta values will be updated.

Meas at Mkr->List

Adds the current measurement results (including frequency, marker amplitude, and
limit delta) to the signal table.

Remarks:

If the invalid marker measurement is executed, then errors may occur and you

cannot add the measurement results to the signal table.

The newly added signal measurement result information is sorted according to

the current ordering rule.

If the trace detector matches the detector in the signal table, then the

corresponding amplitude and limit delta values will be updated.

Meter->Mkr Freq

Sets the frequency of the meter to the frequency at the currently selected marker.

Mkr->Meter Freq

Sets the frequency at the currently selected marker to the frequency of the meter.

Meter->Signal

Replaces the frequency of the currently selected signal with the currently set
frequency of the meter.

2-34 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Meter->List

Adds the currently set meter frequency to the signal table.

Marker Func

Selected Marker

Selects a marker for measurement. The available markers include Marker 1 through
Marker 8.

Detectors

1. Select Detector

Sets the detector for marker measurement. The available detectors include
Detector 1, Detector 2, and Detector 3.

2. Dwell Time

Sets the dwell time of the selected detector.

3. Detector

Sets the type of the detector for marker measurement. The available detector
types include Pos Peak, Quasi Peak, CISPR Average, RMS Average, Average, and
Neg Peak. You can also turn off the detector.

4. Limit for Delta

Sets the limit line of the current detector measurement to obtain the limit delta
in the marker measurement list. The available limits include Limit 1 through
Limit 6.

Meas at Mkr Win

Enables or disables the marker measurement window display. When this function is
enabled, the marker measurement window is displayed in the upper left corner of the
user interface. The final measurement results of the current marker will be displayed
in the window.

EMI User's Guide 2-35

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Measure at Marker

Press this key to perform the marker measurement. At this time, the final
measurement is performed according to the detector settings at the current marker
frequency, and the measurement results are displayed in the window.

If multiple traces are turned on, you can place a marker on any trace in the scan
display and make measurements at the marker.

2-36 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Peak

The peak search function enables the marker to move to the specific signal peak
point, and then in combination with the function of Delta marker, it can provide a
powerful analysis capability.

Peak Search

Performs the peak search function.

Remarks:

 If "Max" is selected under Search Mode, the system will search for the

maximum value on the trace and mark it with a marker.

 If "Para" is selected under Search Mode, the system will search for the peak of

the specified parameter on the trace and mark the peak with a marker.

 The peak search for the Next Peak, Next Peak Right, and Next Peak Left must

meet the specified peak search condition.

 When no peak meets the specified peak search condition, "No peak found" is

displayed.

Next Peak

Searches for and marks the peak whose amplitude on the trace is next to that of the
current peak and which meets the peak search condition.

Next Peak Right

Searches for and marks the nearest peak which is located at the right side of the
current peak and meets the peak search condition.

Next Peak Left

Searches for and marks the nearest peak which is located at the left side of the
current peak and meets the peak search condition.

Minimum Search

Searches for and marks the peak with the minimum amplitude on the trace.

EMI User's Guide 2-37

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

16.99 dBuV

Range

-93.01 dBuV ~ 106.99 dBuV

Unit

dBm, dBmV, dBuV, V, W

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

5 dBuV

Parameter

Remarks

Default

6 dB

Range

0 dB to 100 dB

Unit

dB

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

5 dB

Peak Config

1. Peak Threshold

Specifies the minimum value of the peak amplitude. Only when the peak is
greater than the peak threshold, can it be judged as a peak.

Tab l e 2-17 Peak Threshold

1 dBuV

2. Threshold State

Enables or disables the peak threshold function.

Remarks:

 When the peak threshold function is enabled, press Peak Threshold to set

it.

 When the peak threshold function is disabled, the Peak Threshold menu

is grayed out and disabled.

3. Peak Excursion

Sets the excursion of the peak amplitude. It defines the minimum amplitude
variation required for a signal to be identified as peak.

Tab l e 2-18 Peak Amplitude

1 dB

4. Excursion State

Enables or disables the peak excursion function.

Remarks:

 When the peak excursion function is enabled, press Peak Excursion to set

it.

 When the peak excursion function is disabled, the Peak Excursion menu

is grayed out and disabled.

2-38 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

5. Threshold Line

Sets whether to display the peak threshold line or not. By default, it is off.

Remarks:

 When the threshold line is on, the threshold line displays the amplitude it

represents.

 If the excursion state is on, then the peak excursion line will be displayed at

the top of the peak threshold, and the peak area will be displayed at the left
section.

Figure 2-3 Threshold Line

6. Search Mode

Sets the peak search condition: maximum value on the trace or the parameter
that meets the search criteria.
 If "Max" is selected, the system searches for the maximum value on the

trace. This setting applies only to the peak search executed by pressing

Peak. Other searches such as Next Peak, Next Peak Right, and Next Peak

Left are all searched based on "Para".

 If "Para" is selected, the system searches for the peak that meets the

search criteria on the trace.

EMI User's Guide 2-39

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

0 dB

Range

-120 dB to 120 dB

Unit

dB

Knob Step

1 dB

Left/Right Arrow Key Step

1 dB

Up/Down Arrow Key Step

5 dB

Input/Output

Sets the input/output interface of the instrument.

Input Impedance

Sets the input impedance for voltage-to-power conversions (refer to equation (2-3).
The default input impedance is 50 Ω. If the output impedance of the system under
measurement is 75 Ω, you should use a 75 Ω to 50 Ω adapter (option) supplied by
RIGOL to connect the analyzer with the system under test, and then set the input
impedance to 75 Ω.

Ext Gain

Compensates for gain or loss in the measurement system outside the instrument.

Remarks:

 The value does not affect the trace position, but will modify the parameters such

as reference level readout and the marker amplitude readout.

 You can use the numeric keys, the knob, or arrow keys to modify this parameter;

you can also use the touch screen to modify the parameter.

Tab l e 2-19 External Gain

Ext Trigger2

Sets the external trigger 2 [TRIGGER IN/OUT] to be the "input" or "output"
interface.

2-40 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Corrections

Sets the parameters related to the amplitude correction to compensate for the gain
or loss from external devices such as Antenna and Cable. When using this function,
you can view the correction data table and save or load the current correction data.

Select

Selects a correction factor from Antenna, Cable, Other, or User. By default, all the
correction factors are disabled. After selecting a correction factor, press Correction
to enable the correction factor. RSA allows users to enable multiple correction factors
at the same time.

Correction

Sets the on/off status of the amplitude correction. By default, it is off. If enabled, the
currently selected correction factor data will be used for amplitude correction. If
multiple correction factors are enabled, all the corresponding data will be used for
amplitude correction.

Freq Interp

Sets the interpolation type of the points between two points in the correction table
during amplitude correction.
 In Lin mode, linear interpolation is adopted for the frequency, and log

interpolation is adopted for the amplitude.

 In Log mode, for both of frequency and amplitude, we interpolate on a log scale.

Edit

Press this key to enter the correction data editing interface. You can edit the
frequency of the correction factor and the correction data of the corresponding
amplitude.

1. Navigation: Selects the first line of the correction data table.

2. Frequency: Edits the frequency of the currently selected point.

3. Amplitude: Edits the amplitude correction value of the currently selected point.

4. Append Point: Inserts an edit point and adds a line to the correction table.

5. Delete Point: Deletes the currently selected point and deletes a line from the

correction table.

Note: The edited correction data can be saved to the internal or external memory of

EMI User's Guide 2-41

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

the analyzer. If needed, you can recall it at any time. After completing the correction
data editing, press Save to save it according to descriptions in "Save

".

Delete Correction

Deletes the correction data that you are editing.

Delete All Corr

Deletes all the edited correction data.

2-42 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL



Parameter Name

EMI Parameter Value
FREQ

Frequency(Meter)

515 MHz

Midspan Freq

515 MHz

Start Freq

Auto, 30 MHz

Stop Freq

Auto, 1 GHz

Sc al e Ty pe

Log

SPAN

Span

970 MHz

AMPT

Ref Level

106.99 dBuV

Att(Meter)

10 dB

RF Preamp(Meter)

Off

Y Axis Unit

dBuV

Scale/Div

10 dB

Ref Offset

0 dB

BW

RBW(Meter)

Auto, 120 kHz

Filter Type(Meter)

EMI

Trigger

Source

Free Run

Hold-off

OFF, 100 ms

Auto Trig

OFF, 100 ms

Slope

POS

Delay

OFF, 1 μs

Shortcut Key

Auto Tune

In EMI mode, the Auto Tune function is disabled.

Preset

Recalls the preset setting and restores the system settings of the analyzer to a
specified status.

Remarks:

 To set the preset type, press System

types include "Factory" or any one of items from "User1" to "User6".

 Press Preset to recall the factory settings listed in the following table (except

items specified in Note [1]) or user-defined settings.

Reset  Preset Type. The available

EMI User's Guide 2-43

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Trace

Selected Trace

Trac e1

Tra ce Typ e

Clear Write

Trace Det

Pos Peak

Detector Auto

On

Trace Update

On

Trace Display

On

Mode Setup

Global CF

Off, 515 MHz

EMC Standard

CISPR

Select Meter

Meter 1

Meter

On

Detector

Pos Peak

Limit

Off, 80 dBuV

Dwell Time

10 ms

Peak Hold Type

Infinite

Adjust Time

2 s

Couple to Signal

Off

Couple to Marker

Off

Meas Setup

Frequency Scan

Avg Number

1

Avg Typ e

Scalar

Avg Auto

Auto

Tes t Limits

Off

Select Limit

Limit1

Limit State

Off

Tes t Tr ac e

Trac e1

X to CF

Fixed

Y to Ref

Fixed

Margin

Off, 0 dB

Freq Interpolation

Lin

Frequency

0 Hz

Amplitude

106.99 dBuV

Build From

Trac e1

Copy From

Limit1

X Offset

0 Hz

Y Offset

0 dB

Select Signal

1

Delete

Selected

Sort Signals

Freq

Sort Order

ASC

Auto Sort

On

Search Criteria

Peak Criteria

2-44 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Peak Number

On, 25

Subrange Num

25

Select Range

Range 5

Range

On

Start Freq

600 MHz

Stop Freq

1 GHz

Point

6667

Scan Time

On, 544.117 ms

Auto RBW

On, 120 kHz

Filter Type

EMI

Attenuation

On, 10 dB

RF Preamp

Off

Scan Table

Off

Scan Sequence

Scan Only

(Re)measure

Curr Signal

Select Detector

Detector 1

Dwell Time

200 ms

Detector

Pos Peak

Limit for Delta

Limit 1

Marker

Selected Marker

Marker 1

Marker Mode

Position

Reference Marker

Marker 2

Marker Trace

Trac e 1

Marker Frequency

515 MHz

Line State

Off

Couple Markers

Off

Peak

Peak Threshold

On, 16.99 dBuV

Peak Excursion

On, 6 dB

Threshold Line

Off

Search Mode

Max

Marker Func

Selected Marker

Marker 1

Select Detector

Detector 1

Dwell Time

200 ms

Detector

Pos Peak

Limit for Delta

Limit 1

Meas at Mkr Win

Off

System

[1]

Power On

Preset

Preset Type

Default

Align Auto

On

LAN Setting Mode

DHCP

EMI User's Guide 2-45

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Display Line

Off, 81.99 dBuV

Graticule

On

HDMI

On

HDMI Resolution

1280*720 60Hz

LCD

On

LCD Backlight

100%

Meters Display

On

Meters Freq Line

On

Next Range Display

Off

Power Switch

Default

Beep Switch

Off

Volume

50

SCPI Display

On

User Key

Off

Language

English

[1]

Note

: Not affected by Preset settings.

User

User-defined shortcut key. For some hard-to-find but commonly used function menu,
you can define it as shortcut key (for the defining method, refer to the introduction in

"User Key

quickly open and set the desired menu or function.

Note: You can use the User key to define all the keys on the front panel and the
sub-menus of these keys (except Save).

"). After that, press the shortcut key under any operation interface to

Quick Save

Repeats the most recent save that was performed from the Save menu. Its save
location is the currently defined "Quick Save Path". The register storage does not
support Quick Save.

Cont

Press this key to perform the continuous sweep operation.

Single

Press this key to perform the single sweep operation.

2-46 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

System Function

System

Sets the system parameters.

Preset

Functions include: select the instrument settings to be recalled after the analyzer is
powered on ("Last" or "Preset"); set the preset type ("Default" or one of the items
from "User1" to "User6"); save system configuration.

1. Power On

Sets the power on setting to "Last" or "Preset".
 When "Last" is selected, the last system settings before power-off would be

recalled automatically at power-on.

 When "Preset" is selected, settings defined in Preset Type would be

recalled automatically at power-on.

2. Preset Type

Sets the preset type to "Default" (by default) or any one of the items from
"User1" to "User6".
 When Power On is set to "Preset", the specified preset type will be recalled

at power-on.

 After the instrument starts, press Preset on the front panel in any

operation interface will recall the specified preset type.

3. Save User Preset

Saves the current system setting as user-defined settings to the internal
non-volatile memory. You can store up to 6 system states (correspond to
"User1" to "User6" in the preset type) and name each state file.

When one of the items from "User1" to "User6" is selected under Preset Type,
press Save User Preset, and the instrument automatically completes the
saving operation.

Alignment

1. Align Now

Press this key and the analyzer will use the internal calibration source to perform
a self-calibration immediately.

2. Align Auto

Enables or disables auto self-calibration. If auto self-calibration is enabled, the

EMI User's Guide 2-47

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

analyzer will perform one self-calibration after being started.

Interface

The analyzer supports the LAN or USB communication interface.

1. Network Interface

Sets the LAN parameters. Use the touch screen or the externally connected

mouse to tap or click the setting information icon at the top of the user
interface. Then tap or click the network setting information icon

parameter setting interface is displayed, as shown in the following figure.

. The LAN

Figure 2-4 LAN Parameter Setting

The following items can be set through the front panel keys, shortcut keys on
the keyboard, externally connected mouse, touch screen, or remote interface.

1) Mode

Sets the mode of obtaining the IP address.
 DHCP: When DHCP is selected, the DHCP server assigns network

parameters (such as the IP address, subnet mask, and gateway) to the
analyzer based on the current network configuration.

 Auto: When "Auto" is selected, the instrument will acquire the IP

address ranging from "169.254.0.1" to "169.254.255.254" and the
subnet mask (255.255.0.0) automatically based on the current
network configuration.

 Manual: When "Manual" is selected, you can self-define a desired IP

address for the analyzer.

Note: The analyzer attempts to acquire the IP address configuration

2-48 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

according to the sequence of DHCP, Auto IP, and Manual IP. These three
methods cannot be disabled at the same time.

2) IP

Press IP and use the numeric keys to input the desired IP address.
The format of the IP address is "nnn.nnn.nnn.nnn". The range for the first
segment (nnn) of the address is from 1 to 223 (except 127); and the range
for the other three segments is from 0 to 255. You are recommended to ask
your network administrator for an IP address available.

3) Subnet mask

Press Subnet mask and use the numeric keys to input the desired subnet
mask.
The format of the subnet mask is nnn.nnn.nnn.nnn; wherein, the range of
"nnn" is from 0 to 255. You are recommended to ask your network
administrator for a subnet mask available.

4) Gateway

Press Gateway and use the numeric keys to input the desired gate
address.
The format of the default gateway is "nnn.nnn.nnn.nnn". The range for the
first segment (nnn) is from 1 to 223 (except 127); and the range for the
other three segments is from 0 to 255. You are recommended to ask your
network administrator for a gate address available.

5) DNS

 mDNS: enables or disables the sending of the network information

(including IP address, host name, etc.).

 DNS Mode: sets the mode of obtaining the DNS address to "Manual" or

"Auto".

 Preferred DNS: sets the preferred address for the DNS.
 Backup DNS: sets the backup address for the DNS.

The format of the DNS address is "nnn.nnn.nnn.nnn". The range for the
first segment (nnn) of the address is from 1 to 223 (except 127); and the
range for the other three segments is from 0 to 255. You are recommended
to ask your network administrator for an address available.

6) Apply

After the LAN interface configuration is finished, press this key to apply the
current configuration to the instrument.

7) Reset

Turns on DHCP and Auto-IP; turns Manual-IP off. Clears the set network
password and restores it to the factory defaults.

EMI User's Guide 2-49

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Parameter

Remarks

Default

81.99 dBuV

Range

Current amplitude range

Unit

dBm, dBmV, dBuV, V, W

Knob Step

Left/Right Arrow Key Step

Up/Down Arrow Key Step

step = scale

2. USB

RSA provides a USB DEVICE interface on the rear panel. The analyzer may serve
as a "slave" device to be connected to the PC via this interface.

Display

Controls the screen display. You can set the current mode, the current measurement
interface or window, and other display-related parameters.

1. Display Line State

Turns on or off the display line.

2. Display Line

Sets the display line level to change its display location. This line can be used as
the reference for the readout.

Remarks:

 This line is a reference horizontal line whose amplitude is equal to the set

value, and the corresponding amplitude unit is the same as the Y-axis unit.

 You can use the numeric keys, the knob, and the arrow keys on the front

panel to modify the display line level; also you can modify it on the
touchscreen.

 The settings of the display line only take effect in the spectral line display

area.

 If the display line is out of the visible range, then the display level value will

be marked at the top or bottom of the graticule.

Tab l e 2-20 Display Line Level

step = scale/10

3. Graticule

Enables or disables the display of the graticule.

4. HDMI

Enables or disables HDMI.

5. HDMI Resolution

The resolution supported by the HDMI interface is "1280*720 60Hz", "640*480

2-50 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

60Hz", or "720*480 60Hz".

6. LCD

Enables or disables LCD.

Remarks:

 If you are not updating data, turning off LCD can improve the measurement

speed.

 To reduce the electromagnetic radiation of some circuit component, turn off

the LCD.

 To avoid misoperation, turn off the LCD.

7. LCD Backlight

Sets the brightness of the LCD backlight.
The brightness is expressed in percentage. When it is 100, it indicates that the
backlight is the brightest; when it is 1, the backlight is the darkest.

8. Meters Display

Enables or disables the display of the meter window. When enabled, the meter
window is displayed at the upper-right section of the user interface. When
disabled, the meter window is not displayed in the user interface, and only the
spectral line window and the signal table window are displayed in the user
interface.

9. Meters Freq Line

Enables or disables the display of the meter frequency line. When enabled, a
purple vertical line that indicates the current frequency of the meter is displayed
in the spectral line display window. When disabled, the meter frequency display
line is hidden.

10. Next Range Display

Enables or disables the display of the next scan range. When enabled, the
currently selected scan range is marked by a green box. By default, it is Range 1.
When you press Next Range, you can switch to the next scan range. When
disabled, the scan range is not marked, and you cannot switch to the next
range.

11. Next Range

Press or tap this menu, and then you can switch the current scan range to the
next range.

EMI User's Guide 2-51

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

About System

Displays the system information or the option information.

1. System Info

 Model
 Serial Number
 Hardware Version Number
 Firmware Version Number
 Software Version

2. Option Info

Displays the option information.
RSA provides many kinds of options to meet your various measurement
requirements.

3. Self Test

 Screen

Tests whether the screen has a dot defect by using six colors: blue, red,
green, gray, white, and black. Press any key to switch the screen color and
exit the test.

 Multi-point Touch

Enters the multi-point touch test interface. Use multiple fingers to make
pinch or stretch gestures on the screen, and observe the size of the
characters. If they do not change along with your gestures, it indicates that
problems occurred to the multi-point touch function. To exit the test, press
Esc for three consecutive times.

 Single-point Touch

Enters the single-point touch test interface. Touch or use the mouse to
make stretch or strike gestures on the screen. If the corresponding traces
are displayed, then it indicates that the point on the touchscreen is valid. To
exit the test, press Esc for three consecutive times.

 Keyboard

Enters the keyboard test interface. Press the function keys on the front
panel one by one and observe whether the corresponding key is illuminated.
If not, an error may have occurred to that key. To exit the test, press Esc
for three consecutive times.

Note: For the transparent keys on the front panel, they will be also
illuminated during the test.

4. License Info

Displays the license registration information about the components such as
Linux and QT.

2-52 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL





5. Online Update

Connects the analyzer to the external network by using the network cable. If
you do not have the right to access the Internet, please ask the administrators
to grant your right to access the external Internet first. Then, press this key to
update the software.

Date/Time

Sets the system date and time.

1. Set Time

Sets the displayed system time of the analyzer. Press the Hour, Minute, and
Second softkeys respectively to set the time.

2. Set Date

Sets the displayed system date of the analyzer. Press the Year, Month, and
Day softkeys respectively to set the date. You can also press Date Format to

select whether the date is displayed in "YMD" or "MDY" form.

Security Clear

Press this key to perform the security clear function.

following operations:

Deletes all the files that users have saved, including the state files (state), trace

state files (trace state), screen files (screen), measdata files (measdata), and
limit files (limit), amplitude correction files (correction), signal table (signaltable),
and scan table (scantable) saved by users in all modes.

Executes the factory resetting operation.

Language

RSA supports multi-language menu, Chinese and English built-in help and pop-up
messages.
Press this key to select the desired display language.

This function includes the

EMI User's Guide 2-53

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys






Settings

1. Power Switch

Sets whether the power switch on the front panel is effective or not.
 Default: When the analyzer is powered on, press the power switch on the

front panel to start up the analyzer.

 Always: When the analyzer is powered on, it starts automatically.

2. Beep Switch

Turns on or off the beeper.

3. Volume

After you turn on the beeper, you can press this key to adjust the volume of the
beeper.

4. User Key

Defines an associated function for the User key on the front panel. The
definition method is as described below. After that, pressing User in any
operation interface can quickly enable the defined function.

Press User Key to select "On";
Open the function menu that needs to be defined. For example, press

5. SCPI Display

System  Display  Display Line;

Press User and the definition is finished. At this time, User Key turns off

automatically.

When you use the SCPI commands to control the instrument remotely, turning
on the SCPI Display will go to the specified menu of the corresponding
command; turning off the SCPI Display will not go to the specified menu.

System Message

Press this key, and then a prompt message dialog box will be displayed. You can
press the corresponding front-panel softkey to select to view all the messages, the
messages that have been read or not read. You can also use the touch screen or the
externally connected mouse to tap or click the specified icon in the prompt message
dialog box.

1. Select All

Selects all the displayed messages.

2. Select Read

Only selects the messages that have been read.

2-54 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

3. Select Unread

Only selects the messages that have not been read.

4. Delete

Deletes the selected messages.

5. Query All

Views all the displayed messages.

6. Query Read

Only views the messages that have been read.

7. Query Unread

Only views the messages that have not been read.

EMI User's Guide 2-55

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

File

RSA allows you to save various types of files to the internal or external memory, and
recall them when necessary.

Press File on the front panel to enter the file operation menu interface.

File Explorer

Press the key to enter the file manager interface. You can touch the screen or use the
mouse to tap or click on the screen to select the corresponding file or folder. All the
files with the specified file types are displayed. When you select a file, you can press
the Copy, Paste, or Delete softkeys to copy, paste, or delete the specified file.

Figure 2-5 File Manager

The available file types include: State, Trace+State, Measurement Data, Limit,
Screen Image, License, Amplitude Correction, Signal Ta b le , and Scan Table. The
descriptions for various file types are shown in the following table.

2-56 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

File Type

Format

Suffix Name

State

BIN

.sta

Trace+State

BIN

.trs

Measurement Data

CSV

.csv

Limit

CSV

.csv

Amplitude Correction

CSV

.csv

Screen Image


.jpg/bmp/png

Signal Tab l e

CSV

.csv

Scan Tab l e

CSV

.csv

Tab l e 2-21 Descriptions of File Type

Note: RSA can only recognize files whose filenames consist of Chinese characters,
English letters, or numbers. If the filename or folder name contains other characters,
the file or the folder might not be displayed normally in the file manager interface.

Copy

Copies the currently selected file or folder.

Paste

Pastes the file or folder.

When the current path has contained a file or folder whose name is the same as the
one that you want to paste, after you perform the paste operation, the original file or
folder will be overwritten.

Rename

Renames a file that has been stored. After you select a file, press this key to input a
new filename.

Delete

Deletes the selected file.

EMI User's Guide 2-57

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

New Folder

Creates a folder. Press this key to create a new empty folder under the current
directory, and the file is named with a default filename. To modify this filename,
press Rename to rename the file.

Quick Print

If the printer has been successfully installed, press this key to quickly print the
currently displayed screen image.

Print

Prints the current screen according to print parameter settings when the printer has
been successfully installed and is in idle state.

Printer Setup

1. Printer Parameters

1) Page Size

Sets the page size for printing. When "Default" is selected, the page size
depends on the printer currently connected.

2) Quality

Sets the print quality.

3) Color

Sets the print color to Color, Mono, Inverse, or Inverse-Mono.

4) Orientation

Sets the print orientation to "Landscape" or "Portrait".

5) Adjust

Sets the print border to Adaptive, Non-Adpt, and Hold Min.

6) Counts

Sets the print copies and the default is 1. The range available is from 1 to

99.

7) Border

Turns on or off the border.

2-58 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

In addition, you can preview the print page, and set to print the image or the
text in All page, 1/2, 1/4, or 1/9 page.

2. Add Device

Queries and adds a printer. Inputs the IP address of the printer, the
manufacturer of the printer, the printer model, and printer drive. Then, the
printer is added.

3. Select Device

Selects the desired printer.

Import License

In the file manager interface, select a file to be imported and then press Import
License to import the file.

System Update

Press this key to update the analyzer software after selecting the update file in the
USB storage device.

EMI User's Guide 2-59

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Recall

RSA allows you to recall various types of files saved to the internal or external
storage memory.

Press Recall on the front panel to enter the file recalling menu. The available file
types include: State, Trace+State, Measurement Data, Limit, Amplitude Correction,
Signal Tab l e, and Scan Table.

State

Press State to enter the state recalling menu. The state can be recalled from the
register or the file.

1. Recall

Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.

2. Register 1 through Register 16

When any one of the items from Register 1 to Register 16 is selected, the state
of the specified register will be recalled.

Trace+State

Press Trace+State to enter the trace+state recalling menu. The state of the
instrument and the selected trace can be recalled from the register or the file.

1. Recall

Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.

2. To Trace

Selects the trace+state file or the trace data of the register to recall them to the
selected trace.

3. Register 1 through Register 16

When any one of the items from Register 1 to Register 16 is selected, the state
of the specified register will be recalled.

2-60 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Measurement Data

Press Meas Data to enter the measurement data recalling menu.

1. Recall

Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.

2. To Trace

Selects the measurement data file and recalls it to the selected trace.

Limit

Press Limit to enter the limit recalling menu.

1. Recall

Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.

2. To Limit

Selects the limit line file and recalls it to the selected limit line.

3. Limit Directory

Sets the limit directory to be recalled to "User" or "Preloaded". If you select
"Preloaded", you can load the built-in limit line from the Preloadedlimit folder. If
you select "User", you can load the user-defined limit line from the Limit folder.

Amplitude Correction

Press Correction to enter the amplitude correction data recalling menu.

1. Recall

Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.

2. To Correction

Selects the amplitude correction file and recalls it to the selected type of the
amplitude correction.

EMI User's Guide 2-61

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Signal Table

Press Signal Table to enter the signal table recalling menu.

Press File Explorer to enter the file manager interface. Select a file and then press

Recall to import the file.

Scan Table

Press Scan Table to enter the scan table recalling menu.

Press File Explorer to enter the file manager interface. Select a file and then press
Recall to import the file.

2-62 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Save

RSA allows you to save various types of files to the internal or external memory.

Press Save on the front panel to enter the file saving menu. The available file types
include: State, Trace+State, Measurement Data, Limit, Screen Image, Amplitude
Correction, Signal Tab le , and Scan Table.

State

Press State to enter the state saving menu. The state can be saved to the register or
the file.

1. Save

Press this key to save the current state in the default filename or user-defined
filename.

The default state filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is state<n>.sta. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1. For
example, if 3 files (state1.sta, state2.sta, state5.sta) exist in the current
directory, then the new filename for the file that you want to save should be
state6.sta by default.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.sta". After that, press the Save key again, another file is
saved automatically with the filename "abc1.sta".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding state file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

3. Register 1 through Register 16

When any one of the items from Register 1 to Register 16 is selected, the
current state of the instrument will be saved to the corresponding register. The
register supports quick save and recalling instrument state. The register menu
displays the time for saving the instrument state.

EMI User's Guide 2-63

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Trace+State

Press Trace+State to enter the trace+state saving menu. The state of the
instrument and the selected trace can be saved to the register or the file.

1. Save

Press this key to save the current trace+state file in the default filename or
user-defined filename.

The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is tracestate<n>.trs. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.trs". After that, press the Save key again, another file is
saved automatically with the filename "abc1.trs".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding trace+state file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

3. Save From Trace

Selects the trace to be saved. You can select any single trace from Trace1 to
Trac e3.

4. Register 1 through Register 16

When any one of the items from Register 1 to Register 16 is selected, the
current state of the instrument will be saved to the corresponding register. The
register supports quick save and loading instrument state. The register menu
displays the time for saving the instrument state.

Measurement Data

Press Meas Data to enter the measurement data saving menu. The selected
measurement data type (e.g. trace, measurement results) can be saved to the
specified file. The data will be saved in .csv format. They are separated with a
comma, and this is convenient for you to use the Excel to analyze the data.

1. Save

Press this key to save the currently selected type of measurement data in the

2-64 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Menu Name

Function Description

Tem pe ra tur e

Enables or disables the display of the temperature.

Humidity

Enables or disables the display of the humidity.

Testing Place

Enables or disables the display of the testing place.

Testing Distance

Enables or disables the display of the testing
distance.

Polar Direction

Enables or disables the display of the polar
direction.

Other Explanation

Enables or disables the display of the other
explanation.

default filename or user-defined filename.
The default filename is determined by the following methods:

 If you haven't input a filename by pressing the Save As key, its default

filename is measdata<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.csv". After that, press the Save key again, another file is
saved automatically with the filename "abc1.csv".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding Measurement Data file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

3. Save From Trace

If the data to be saved are traces, select the trace to be saved. You can select
any single trace from Trace1 to Trace3.

4. Data Type

Selects the measurement data type to be saved. The data types supported by
the instrument include trace and EMI measurement results.

5. Meas Results

After selecting the type of the EMI measurement results, click this menu, and
then the measurement results interface is displayed. You can enable the touch
screen or use its sub-menu to set the EMI measurement report.

1) Environment

After selecting the corresponding menu, you can edit the information using
the pop-up soft keyboard in the text box on the right side of the
corresponding parameters in the Meas Result Content interface.

EMI User's Guide 2-65

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Menu Name

Function Description

Client

Enables or disables the display of the client information.

Operator

Enables or disables the display of the operator
information.

Product Desc

Enables or disables the display of the product
description.

2) Header

press this menu to enter the trace file header information menu.

After selecting the corresponding menu, you can edit the information using
the pop-up soft keyboard in the text box on the right side of the
corresponding parameters in the Meas Result Content interface.

3) Ampt Corr

Selects the displayed amplitude correction data to "Full Data". You can also
select "Off" to turn off the display of the correction data.

4) Limits

Selects the displayed limit line data to "Full Data". You can also select "Off"
to turn off the display of the limit line data.

5) Screen

Sets the screen image of the report to "Inverted" or "Normal". You can also
select "Off" to turn off the display of the screen image.

6) Ta bl e &List
 Scan Table: enables or disables the display of the scan table

information of the report.

 Signal Tab l e: enables or disables the display of the signal table

information of the report.

7) Output Format
Sets the output format of the report to "HTML" or "PDF". When you select
"HTML", save the report with the name suffixed with ".html". When you
select "PDF", save the report suffixed with ".pdf".

Limit

Press Limit to enter the limit line saving menu. The selected limit line is saved to the
file.

1. Save

Press this key to save the currently selected limit line in the default filename or
user-defined filename.
The default filename is determined by the following methods:

2-66 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

 If you haven't input a filename by pressing the Save As key, its default

filename is limit<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.csv". After that, press the Save key again, another file is
saved automatically with the filename "abc1.csv".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding Limit file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

3. Select Limit

Selects the limit line to be saved. You can select any single limit line from Limit1
to Limit6.

Screen Image

Press Screen Image to enter the screen saving menu.

1. Save

Press this key to save the current screen image in the default filename or
user-defined filename.

The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is screen<n>.jpg. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.jpg". After that, press the Save key again, another file is
saved automatically with the filename "abc1.jpg".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding Screen Image file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

EMI User's Guide 2-67

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

3. Screenshot Info

1) Format
Press this key to select the file format of the current screen image to "JPEG",
"BMP", or "PNG".

2) Color Type
Press this key to select the color of the current screen image to "Normal" or
"Inverted".

Amplitude Correction

Press Correction to enter the amplitude correction data saving menu. The selected
amplitude correction data is saved to the file.

1. Save

Press this key to save the current amplitude correction data in the default
filename or user-defined filename.

The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is correction<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.csv". After that, press the Save key again, another file is
saved automatically with the filename "abc1.csv".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding amplitude correction file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

3. Select Corr

Selects the amplitude correction type to be saved. You can select "Antenna",
"Cable", "Other", or "User". "

2-68 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 2 Front Panel Function Keys RIGOL

Signal Table

1. Save

Press this key to save the selected signal table in the default filename or
user-defined filename.

The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is signaltable<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.csv". After that, press the Save key again, another file is
saved automatically with the filename "abc1.csv".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding signal table file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

Scan Table

1. Save

Press this key to save the selected scan table in the default filename or
user-defined filename.

The default filename is determined by the following methods:
 If you haven't input a filename by pressing the Save As key, its default

filename is scantable<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.

 If you have pressed the Save As key to input the filename abc, then the file

is saved to be "abc.csv". After that, press the Save key again, another file is
saved automatically with the filename "abc1.csv".

2. Save As

Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding scan table file.

You can also touch the screen or use the mouse to tap or click the Save As
menu, and then input the filename with the keypad.

EMI User's Guide 2-69

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 2 Front Panel Function Keys

Quick Save Path

1. Set Path

Press the Set Path softkey to open the file explorer interface. Select the
corresponding path, and then press OK to set the current path to be the quick
save path.

2. View Path

Press the View Path softkey to display the current quick save path information
in the center of the user interface.

2-70 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Chapter 3 Appendix RIGOL

Remarks

Order No.

Real-time Spectrum Analyzer, 9 kHz to 3.2 GHz

RSA5032

Real-time Spectrum Analyzer, 9 kHz to 6.5 GHz

RSA5065

Real-time Spectrum Analyzer, 9 kHz to 3.2 GHz (with
tracking generator, factory installed)

Real-time Spectrum Analyzer, 9 kHz to 6.5 GHz (with
tracking generator, factory installed)

Standard
Accessories

Quick Guide (hard copy)

-

Power Cord

-

Preamplifier (PA)

RSA5000-PA

Highly Stable Clock

OCXO-C08

Real-time Analysis Bandwidth 40 MHz

RSA5000-B40

Advanced Measurement Kit

RSA5000-AMK

EMI Measurement Application

RSA5000-EMI

Vector Signal Analysis Measurement Application

RSA5000-VSA

Spectrum Analyzer PC Software

Ultra Spectrum

S1210 EMI

Software

Include: N-SMA cable, BNC-BNC cable, N-BNC

(2pcs)

Include: N(F)-N(F) adaptor (1pcs), N(M)-N(M)

Ω BNC impedance adaptor (1pcs)

Include: 50 Ω to 75 Ω adaptor (2pcs)

RF CATV Kit

Include: 6 dB attenuator (1pcs), 10 dB attenuator
(2pcs)

30 dB high-power attenuator, with the max power of
100 W

N Male-N Male RF Cable

CB-NM-NM-75-L-12G

N Male-SMA Male RF Cable

CB-NM-SMAM-75-L-12G

VSWR Bridge, 1 MHz to 3.2 GHz

VB1032

VSWR Bridge, 2 GHz to 8 GHz

VB1080

Near-field Probe

NFP-3

Rack Mount Kit

RM6041

USB Cable

CB-USBA-USBB-FF-150

Chapter 3 Appendix

Appendix A: RSA5000 Accessories and Option List

Model

Option

Optional
Accessories

EMI Pre-compliance Test Software

adaptor, N-SMA adaptor, 75 Ω-50 Ω adaptor, 900
MHz/1.8 GHz antenna (2pcs), 2.4 GHz antenna

adaptor (1pcs), N(M)-SMA(F) adaptor (2pcs),
N(M)-BNC(F) adaptor (2pcs), SMA(F)-SMA(F)
adaptor (1pcs), SMA(M)-SMA(M) adaptor (1pcs),
BNC T type adaptor (1pcs), 50 Ω SMA load (1pcs), 50

RSA5032-TG

RSA5065-TG

Pre-compliance

DSA Utility Kit

RF Adaptor Kit

RF Attenuator Kit

ATT03301H

EMI User's Guide 3-1

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

RIGOL Chapter 3 Appendix

Description

Order No.

Real-time Spectrum Analyzer, 9 kHz to 3 GHz

RSA3030

Real-time Spectrum Analyzer, 9 kHz to 4.5 GHz

RSA3045

Real-time Spectrum Analyzer, 9 kHz to 3 GHz (with TG
installed when leaving the factory)

Real-time Spectrum Analyzer, 9 kHz to 4.5 GHz(with TG
installed when leaving the factory)

Standard
Quick Guide (hard copy)

-

Power Cord

-

High Stability Clock

OCXO-C08

RBW 1 Hz to 10 MHz

RSA3000-BW1

Real-time Analysis Bandwidth 25 MHz

RSA3000-B25

Real-time Analysis Bandwidth 40 MHz

RSA3000-B40

Advanced Measurement Kit

RSA3000-AMK

EMI Measurement Application (includes RSA3000-EMC)

RSA3000-EMI

EMC Filter and Quasi-Peak Detector Kit

RSA3000-EMC

Spectrum Analyzer PC Software

Ultra Spectrum

S1210 EMI

Software

Include: N-SMA cable, BNC-BNC cable, N-BNC adaptor,

antenna (2pcs), 2.4 GHz antenna (2pcs)

Include: N(F)-N(F) adaptor (1pcs), N(M)-N(M) adaptor

(1pcs), 50 Ω BNC impedance adaptor (1pcs)

Include: 50 Ω to 75 Ω adaptor (2pcs)

RF CATV Kit

Include: 6 dB attenuator (1pcs), 10 dB attenuator (2pcs)

RF Attenuator Kit

30 dB high-power attenuator, with the max power of 100 W

ATT03301H

CB-NM-NM-75-L­12G

CB-NM-SMAM-7
5-L-12G

VSWR Bridge, 1 MHz to 3.2 GHz

VB1032

VSWR Bridge, 2 GHz to 8 GHz

VB1080

Near-field Probe

NFP-3

Rack Mount Kit

RM6041

Appendix B: RSA3000 Accessories and Option List

Model

Accessories

Option

RSA3030-TG

RSA3045-TG

Preamplifier (PA) RSA3000-PA

EMI Pre-compliance Test Software

N-SMA adaptor, 75 Ω-50 Ω adaptor, 900 MHz/1.8 GHz

(1pcs), N(M)-SMA(F) adaptor (2pcs), N(M)-BNC(F) adaptor
(2pcs), SMA(F)-SMA(F) adaptor (1pcs), SMA(M)-SMA(M)
adaptor (1pcs), BNC T type adaptor (1pcs), 50 Ω SMA load

Pre-compliance

DSA Utility Kit

RF Adaptor Kit

Optional
Accessories

N(M)-N(M) RF Cable

N(M)-SMA(M) RF Cable

USB Cable

3-2 EMI User's Guide

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

CB-USBA-USBB­FF-150

Chapter 3 Appendix RIGOL

Appendix C: Warranty

RIGOL (SUZHOU) TECHNOLOGIES INC. (hereinafter referred to as RIGOL)
warrants that the product will be free from defects in materials and workmanship
within the warranty period. If a product proves defective within the warranty period,
RIGOL guarantees free replacement or repair for the defective product.

The

re is no other warranty, expressed or implied, except such as is expressly set
forth herein or other applicable warranty card. There is no implied warranty of
merchantability or fitness for a particular purpose. Under no circumstances shall
RIGOL be liable for any consequential, indirect, ensuing, or special damages for any
breach of warranty in any case.

EMI User's Guide 3-3

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Index RIGOL

Index

(Re)measure ............................ 2-28

Att(Meter) .................................. 2-6

Auto IP .................................... 2-47

Average (RMS) ......................... 2-17

Brightness ................................ 2-49

CISPR Average ......................... 2-17

Clear Write ............................... 2-16

Corrections ............................... 2-40

Default Gateway ....................... 2-48

DHCP....................................... 2-47

Display line .............................. 2-49

Ext Gain ................................... 2-39

Free Run .................................. 2-13
