Rigol RSA3030E-TG, RSA3015E, RSA3030E, RSA3015E-TG Programming Guide

Programming Guide

RSA3000E Series Real-time

Spectrum Analyzer

Aug. 2019

RIGOL (SUZHOU) TECHNOLOGIES INC.

RIGOL

Guaranty and Declaration

Copyright

© 2019 RIGOL (SUZHOU) TECHNOLOGIES INC. All Rights Reserved.

Trademark Information

RIGOL is a registered trademark of RIGOL (SUZHOU) TECHNOLOGIES INC.

Publication Number

PGD24100-1110

Software Version

00.01.00
Software upgrade might change or add product features. Please acquire the latest version of the manual
from RIGOL website or contact RIGOL to upgrade the software.

Notices

 RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
 RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at

the company’s sole decision.

 Information in this publication replaces all previously relea sed materials.
 Information in this publication is subject to change without notice.
 RIGOL shall not be liable for either incidental or consequential losses in connection with the furnishing,

use, or performance of this manual, as well as any information contained.

 Any part of this document is forbidden to be copied, photocopied, or rearranged without prior written

approval of RIGOL.

Product Certification

RIGOL guarantees that this product conforms to the national and industrial standards in China as well as
the ISO9001:2015 standard a nd the ISO14001:2015 standard. Other international standard conformance
certifications are in progress.

Contact Us

If you have any problem or requirement when using our products or this manual, please contact RIGOL.
E-mail: [e-mail]
Website: www.rigol.com

RSA3000E Programming Guide I

RIGOL

Tip

For the latest version of this manual, download it from the official website of RIGOL (www.rigol.com).

Document Overview

This manual introduces how to program and control RIGOL RSA3000E series spectrum analyzer by using
SCPI commands through USB and LAN interface.

Main Topics in this Manual:

Chapter 1 Programming Overview

This chapter introduces how to set up remote communication between the spectrum analyzer and the PC,
the remote control methods, the syntax, symbols, parameters, and abbreviation rules of the SCPI
commands.

Chapter 2 Command Systems for GPSA and RTSA Modes

This chapter introduces the syntax, function, parameters, and usage of each command of RSA3000E series
in GPSA and RTSA modes.

Chapter 3 Command System for EMI Mode

This chapter introduces the commands of R SA3000E series in EMI mode.

Chapter 4 Command System for VSA Mode
This chapter introduces the commands of RSA3000E series in VSA mode.

Chapter 5 Programming Examples

This chapter illustrates how to control the RSA3000E series by programming in the development
environments such as Visual C++, Visual Basic, and LabVIEW.

Format Conventions in this Manual:

1. Keys:

The keys on the front panel are usually denoted by the format of "Key Name (Bold) + Text Box". For
example, FREQ denotes the FREQ key.

2. Menu keys:

The menu softkeys are usually denoted by the format of "Menu Word (Bold) + Character Shading". For
example, Center Freq denotes the center frequency menu item under the FREQ function key.

3. Connectors:

The connectors on the fron t or rear panel are usual ly denoted by the f ormat of "Connector Name (Bo ld)
+ Square Brackets (Bold)". For example, [Gen Output 50Ω].

4. Operation Procedures:

"" indicates the next step of operation. For example, FREQ  Center Freq indicates pressing
FREQ on the front panel and then pressing the menu softkey Cent er Freq.

Content Conventions in this Manual:

The RSA3000E series spectrum analyzer includes the following models. Unless otherwise specified, this
manual takes RSA3030E-TG as an example to illustrate the usage of each command of RSA3000E series
spectrum analyzer.

II RSA3000E Programming Guide

RIGOL

Model

Frequency Range

Tracking Generator

RSA3030E

9 kHz to 3 GHz

None

RSA3015E

9 kHz to 1.5 GHz

None

RSA3030E-TG

9 kHz to 3 GHz

3 GHz

RSA3015E-TG

9 kHz to 1.5 GHz

1.5 GHz

RSA3000E Programming Guide III

RIGOL Contents

Contents

Guaranty and Declaration .......................................................................................................... I

Document Overview ................................................................................................................. II

Chapter 1 Programming Overview ..................................................................................... 1-1

Build Remote Communication .................................................................................................... 1-2

Remote Control Method ............................................................................................................. 1-3

SCPI Command Overview .......................................................................................................... 1-4

Syntax ............................................................................................................................... 1-4

Symbol D escription ............................................................................................................. 1-4

Parameter Type .................................................................................................................. 1-5

Command Abbreviation ....................................................................................................... 1-5

Chapter 2 Command Systems for GPSA and RTSA Modes ................................................. 2-1

:CALCulate Commands .............................................................................................................. 2-2

:CALCulate:BANDwidth|BWIDth:NDB ................................................................................... 2-4

:CALCulate:BANDwidth|BWIDth:RESult? .............................................................................. 2-4

:CALCulate:BANDwidth|BWIDth:RLEFt? ............................................................................... 2-5

:CALCulate:BANDwidth|BWIDth:RRIGht? ............................................................................. 2-5

:CALCulate:BANDwidth|BWIDth [:STATe] ............................................................................. 2-5

:CALCulate:LLINe:ALL:DELete ............................................................................................. 2-6

:CALCulate:LLINe:TEST ...................................................................................................... 2-6

:CALCulate:LLINe<n>:AMPLitude:CMODe:RELative .............................................................. 2-7

:CALCulate:LLINe<n>:BUILd .............................................................................................. 2-7

:CALCulate:LLINe<n>:COPY ............................................................................................... 2-8

:CALCulate:LLINe<n>:DATA................................................................................................ 2-8

:CALCulate:LLINe<n>:DELete ............................................................................................. 2-9

:CALCulate:LLINe<n>:DISPlay ............................................................................................ 2-9

:CALCulate:LLINe<n>:FAIL? ............................................................................................. 2-10

:CALCulate:LLINe<n>:FREQuency:CMODe:RELative ........................................................... 2-10

:CALCulate:LLINe<n>:MARGin .......................................................................................... 2-11

:CALCulate:LLINe<n>:MARGin:STATe ................................................................................ 2-11

:CALCulate:LLINe<n>:TRACe ............................................................................................ 2-12

:CALCulate:LLINe<n>:TYPE .............................................................................................. 2-12

:CALCulate:MARKer:AOFF ................................................................................................. 2-13

:CALCulate:MARKer:COUPle[:STATe] .................................................................................. 2-13

:CALCulate:MARKer:PEAK:EXCursion.................................................................................. 2-13

:CALCulate:MARKer:PEAK:EXCursion:STATe........................................................................ 2-14

:CALCulate:MARKer:PEAK:SEARch:MODE ........................................................................... 2-14

:CALCulate:MARKer:PEAK:SORT ........................................................................................ 2-15

:TRACe:MATH:PEAK:SORT ................................................................................................ 2-15

:CALCulate:MARKer:PEAK:TABLe:READout ......................................................................... 2-16

:TRACe:MATH:PEAK:THReshold ......................................................................................... 2-16

:CALCulate:MARKer:PEAK:TABLe[:STATe] ........................................................................... 2-16

:TRACe:MATH:PEAK:TABLe:STATe ..................................................................................... 2-16

:CALCulate:MARKer:PEAK:THReshold ................................................................................. 2-17

:CALCulate:MARKer:PEAK:THReshold:STATe ....................................................................... 2-17

:CALCulate:MARKer:TABLe[:STATe] ................................................................................... 2-18

:CALCulate:MARKer:TRCKing[:STATe] ................................................................................ 2-18

:CALCulate:MARKer<n>:CPSearch[:STATe] ........................................................................ 2-19

:CALCulate:MARKer<n>:FCOunt:GATetime ........................................................................ 2-20

:CALCulate:MARKer<n>:FCOunt:GATetime:AUTO ............................................................... 2-20

:CALCulate:MARKer<n>:FCOunt[:STATe] ........................................................................... 2-21

:CALCulate:MARKer<n>:FCOunt:X? ................................................................................... 2-21

:CALCulate:MARKer<n>:FUNCtion ..................................................................................... 2-22

:CALCulate:MARKer<n>:FUNCtion:BAND:LEFT ................................................................... 2-22

IV RSA3000E Programming Guide

Contents RIGOL

:CALCulate:MARKer<n>:FUNCtion:BAND:RIGHt ................................................................. 2-23

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN .................................................................. 2-24

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN:AUTO ........................................................ 2-24

:CALCulate:MARKer<n>:LINes[:STATe] ............................................................................. 2-25

:CALCulate:MARKer<n>:MAXimum:LEFT ........................................................................... 2-25

:CALCulate:MARKer<n>:MAXimum[:MAX] ......................................................................... 2-26

:CALCulate:MARKer<n>:MAXimum:NEXT .......................................................................... 2-26

:CALCulate:MARKer<n>:MAXimum:RIGHt ......................................................................... 2-27

:CALCulate:MARKer<n>:MINimum .................................................................................... 2-27

:CALCulate:MARKer<n>:MODE ......................................................................................... 2-28

:CALCulate:MARKer<n>:PTPeak ....................................................................................... 2-28

:CALCulate:MARKer<n>:REFerence................................................................................... 2-29

:CALCulate:MARKer<n>[:SET]:CENTer .............................................................................. 2-29

:CALCulate:MARKer<n>[:SET]:DELTa:CENTer .................................................................... 2-30

:CALCulate:MARKer<n>[:SET]:DELTa:SPAN ....................................................................... 2-30

:CALCulate:MARKer<n>[:SET]:RLEVel ............................................................................... 2-31

:CALCulate:MARKer<n>[:SET]:STARt ................................................................................ 2-31

:CALCulate:MARKer<n>[:SET]:STEP ................................................................................. 2-32

:CALCulate:MARKer<n>[:SET]:STOP ................................................................................. 2-32

:CALCulate:MARKer<n>:STATe ......................................................................................... 2-33

:CALCulate:MARKer<n>:TRACe ........................................................................................ 2-33

:CALCulate:MARKer<n>:TRACe:AUTO ............................................................................... 2-34

:CALCulate:MARKer<n>:X ................................................................................................ 2-35

:CALCulate:MARKer<n>:X:READout .................................................................................. 2-35

:CALCulate:MARKer<n>:X:READout:AUTO ........................................................................ 2-36

:CALCulate:MARKer<n>:Y ................................................................................................ 2-37

:CALCulate:MARKer<n>:Z:POSition ................................................................................... 2-37

:CALCulate:MATH ............................................................................................................. 2-38

:CALCulate:NTData[:STATe] .............................................................................................. 2-39

:CALibration Commands .......................................................................................................... 2-40

:CALibration:[ALL] ............................................................................................................ 2-40

:CALibration:AUTO ........................................................................................................... 2-40

:CONFigure Commands ........................................................................................................... 2-41

:CONFigure? .................................................................................................................... 2-41

:CONFigure:ACPower ....................................................................................................... 2-42

:CONFigure:CNRatio ......................................................................................................... 2-42

:CONFigure:DENSity ......................................................................................................... 2-42

:CONFigure:DSPEctrogram ............................................................................................... 2-43

:CONFigure:EBWidth ........................................................................................................ 2-43

:CONFigure:HDISt ............................................................................................................ 2-43

:CONFigure:LPSTep .......................................................................................................... 2-43

:CONFigure:MCHPower ..................................................................................................... 2-44

:CONFigure:NORMal ......................................................................................................... 2-44

:CONFigure:OBWidth ........................................................................................................ 2-44

:CONFigure:PSGRam ........................................................................................................ 2-45

:CONFigure:PSPectrum ..................................................................................................... 2-45

:CONFigure:PVT ............................................................................................................... 2-45

:CONFigure:SANalyzer ...................................................................................................... 2-45

:CONFigure:SPECtrogram ................................................................................................. 2-46

:CONFigure:TOI ............................................................................................................... 2-46

:CONFigure:TPOWer ........................................................................................................ 2-46

:COUPle Commands ................................................................................................................ 2-47

:COUPle .......................................................................................................................... 2-47

:DISPlay Commands ............................................................................................................... 2-48

:DISPlay:BACKlight ........................................................................................................... 2-49

:DISPlay:ENABle .............................................................................................................. 2-49

:DISPlay:GRATicule[:STATe] .............................................................................................. 2-50

:DISPlay:HDMI[:STATe] .................................................................................................... 2-50

RSA3000E Programming Guide V

RIGOL Contents

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:COUPle ......................................................... 2-51

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:PDIVision ...................................................... 2-51

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RLEVel .......................................................... 2-52

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RPOSition ..................................................... 2-52

:DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:PDIVision ...................................................... 2-53

:DISPlay:PVTime : WIN Do w: TR ACe :Y[ : SCA Le] :RLE Vel <real > .............................................. 2-53

:DISPlay:VIEW:DENSity:AADJust ....................................................................................... 2-54

:DISPlay:VIEW:DENSity:CNONlinear .................................................................................. 2-54

:DISPlay:VIEW:DENSity:CPALettes ..................................................................................... 2-55

:DISPlay:VIEW:DENSity:HDHue ......................................................................................... 2-55

:DISPlay:VIEW:DENSity:LDHue ......................................................................................... 2-56

:DISPlay:VIEW:DENSity:PERSistence ................................................................................. 2-56

:DISPlay:VIEW:DENSity:PERSistence:INFinite ..................................................................... 2-57

:DISPlay:VIEW[:SELect] .................................................................................................... 2-57

:DISPlay:VIEW:SPECtrogram:AADJust ................................................................................ 2-58

:DISPlay:VIEW:SPECtrogram:BOTTom ............................................................................... 2-58

:DISPlay:VIEW:SPECtrogram:HUE ..................................................................................... 2-59

:DISPlay:VIEW:SPECtrogram:POSition ............................................................................... 2-59

:DISPlay:VIEW:SPECtrogram:REFerence ............................................................................ 2-60

:DISPlay:VIEW:SPECtrogram:TRACe:COUPle ...................................................................... 2-60

:DISPlay:VIEW:SPECtrogram:TRACe:SELection ................................................................... 2-61

:DISPlay:WINDow:SELect ................................................................................................. 2-62

:DISPlay:WINDow:TRACe:Y:DLINe .................................................................................... 2-62

:DISPlay:WINDow:TRACe:Y:DLINe:STATe .......................................................................... 2-63

:DISPlay:WINDow:TRACe:Y[:SCALe]:NRLevel .................................................................... 2-63

:DISPlay:WINDow:TRACe:Y[:SCALe]:NRPosition ................................................................ 2-64

:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision .................................................................. 2-64

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel ...................................................................... 2-65

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet .......................................................... 2-65

:DISPlay:WINDow:TRACe:Y[:SCALe]:SPACing .................................................................... 2-66

:FETCh Commands .................................................................................................................. 2-67

:FETCh:ACPower? ............................................................................................................. 2-68

:FETCh:ACPower:LOWer? .................................................................................................. 2-68

:FETCh:ACPower:MAIN? ................................................................................................... 2-69

:FETCh:ACPower:UPPer? ................................................................................................... 2-69

:FETCh:CNRatio? .............................................................................................................. 2-70

:FETCh:CNRatio:CARRier? ................................................................................................. 2-70

:FETCh:CNRatio:CNRatio? ................................................................................................. 2-71

:FETCh:CNRatio:NOISe? ................................................................................................... 2-71

:FETCh:EBWidth? ............................................................................................................. 2-72

:FETCh:HARMonics:AMPLitude:ALL? .................................................................................. 2-72

:FETCh:HARMonics :AMP L it ude ? <n > ................................................................................. 2-73

:FETCh:HARMonics[:DISTortion]? ...................................................................................... 2-73

:FETCh:HARMonics:FREQuency:ALL? ................................................................................. 2-74

:FETCh:HARMonics :FRE Q ue ncy ? <n > ................................................................................ 2-74

:FETCh:HARMonics:FUNDamental? .................................................................................... 2-75

:FETCh:OBWidth? ............................................................................................................. 2-75

:FETCh:OBWidth:OBWidth? ............................................................................................... 2-76

:FETCh:OBWidth:OBWidth:FERRor? ................................................................................... 2-76

:FETCh:SANalyzer<n>? .................................................................................................... 2-77

:FETCh:TOIntercept? ........................................................................................................ 2-77

:FETCh:TOIntercept:IP3? .................................................................................................. 2-78

:FETCh:TPOWer? .............................................................................................................. 2-78

:FORMat Commands ............................................................................................................... 2-79

:FORMat:BORDer ............................................................................................................. 2-79

:FORMat[:TRACe][:DATA] ................................................................................................. 2-80

IEEE 488.2 Common Commands .............................................................................................. 2-81

*CLS ................................................................................................................................ 2-82

VI RSA3000E Programming Guide

Contents RIGOL

*ESE ............................................................................................................................... 2-82

*ESR? ............................................................................................................................. 2-83

*IDN? ............................................................................................................................. 2-83

*OPC ............................................................................................................................... 2-84

*RCL ............................................................................................................................... 2-84

*RST ............................................................................................................................... 2-84

*SAV ............................................................................................................................... 2-85

*SRE ............................................................................................................................... 2-85

*STB? ............................................................................................................................. 2-86

*TRG .............................................................................................................................. 2-86

*TST? ............................................................................................................................. 2-86

*WAI ............................................................................................................................... 2-86

:INITiate Commands ............................................................................................................... 2-87

:INITiate:CONTinuous ...................................................................................................... 2-87

:INITiate[:IMMediate] ...................................................................................................... 2-87

:INSTrument Commands ......................................................................................................... 2-88

:INSTrument:COUPle:FREQuency:CENTer .......................................................................... 2-88

:INSTrument:DEFault ....................................................................................................... 2-88

:INSTrument:NSELect ....................................................................................................... 2-89

:INSTrument[:SELect] ...................................................................................................... 2-89

:MMEMory Commands ............................................................................................................ 2-90

:MMEMory:DELete ............................................................................................................ 2-90

:MMEMory:LOAD:CORRection ........................................................................................... 2-91

:MMEMory:LOAD:FMT ...................................................................................................... 2-91

:MMEMory:LOAD:LIMit ..................................................................................................... 2-91

:MMEMory:LOAD:STATe .................................................................................................... 2-92

:MMEMory:LOAD:TRACe ................................................................................................... 2-92

:MMEMory:LOAD:TRACe:DATA .......................................................................................... 2-93

:MMEMory:MOVE ............................................................................................................. 2-93

:MMEMory:STORe:CORRection .......................................................................................... 2-93

:MMEMory:STORe:LIMit .................................................................................................... 2-94

:MMEMory:STORe:MTABle ................................................................................................ 2-94

:MMEMory:STORe:PTABle ................................................................................................. 2-95

:MMEMory:STORe:RESults ................................................................................................ 2-95

:MMEMory:STORe:SCReen ................................................................................................ 2-96

:MMEMory:STORe:STATe .................................................................................................. 2-96

:MMEMory:STORe:TRACe ................................................................................................. 2-97

:MMEMory:STORe:TRACe:DATA ........................................................................................ 2-97

:OUTPut Command ................................................................................................................. 2-98

:OUTPut[:EXTernal][:STATe] ............................................................................................. 2-98

:READ Commands .................................................................................................................. 2-99

:READ:ACPower? ........................................................................................................... 2-100

:READ:ACPower:LOWer? ................................................................................................ 2-100

:READ:ACPower:MAIN? .................................................................................................. 2-100

:READ:ACPower:UPPer?.................................................................................................. 2-101

:READ:CNRatio? ............................................................................................................. 2-101

:READ:CNRatio:CARRier? ................................................................................................ 2-101

:READ:CNRatio:CNRatio? ................................................................................................ 2-102

:READ:CNRatio:NOISe? .................................................................................................. 2-102

:READ:EBWidth? ............................................................................................................ 2-102

:READ:HARMonics:AMPLitude:ALL? ................................................................................. 2-103

:READ:HARMonics:AMPLitude? <n> ................................................................................ 2-103

:READ:HARMonics[:DISTortion]? ..................................................................................... 2-104

:READ:HARMonics:FREQuency:ALL? ................................................................................ 2-104

:READ:HARMonics:FREQuency ? <n> .............................................................................. 2-104

:READ:HARMonics:FUNDamental? ................................................................................... 2-105

:READ:OBWidth?............................................................................................................ 2-105

:READ:OBWidth:OBWidth? ............................................................................................. 2-106

RSA3000E Programming Guide VII

RIGOL Contents

:READ:OBWidth:OBWidth:FERRor? .................................................................................. 2-106

:READ:SANalyzer<n>?.................................................................................................... 2-107

:READ:TOIntercept? ....................................................................................................... 2-107

:READ:TOIntercept:IP3? ................................................................................................. 2-108

:READ:TPOWer? ............................................................................................................. 2-108

[:SENSe] Commands ............................................................................................................. 2-109

[:SENSe]:ACPower:AVERage:COUNt ................................................................................ 2-113

[:SENSe]:ACPower:AVERage[:STATe] ............................................................................... 2-113

[:SENSe]:ACPower:AVERage:TCONtrol ............................................................................. 2-114

[:SENSe]:ACPower:BANDwidth:ACHannel ........................................................................ 2-114

[:SENSe]:ACPower:BANDwidth:INTegration...................................................................... 2-115

[:SENSe]:ACPower:CSPacing ........................................................................................... 2-115

[:SENSe]:ACQuisition:TIME ............................................................................................. 2-116

[:SENSe]:ACQuisition:TIME:AUTO ................................................................................... 2-116

[:SENSe]:ACQuisition:TIME:PVTime ................................................................................. 2-117

[:SENSe]:ACQuisition:TIME:PVTime:AUTO ....................................................................... 2-117

[:SENSe]:AVERage:COUNt .............................................................................................. 2-118

:TRACe:AVERage:COUNt ................................................................................................. 2-118

[:SENSe]:AVERage:COUNt:CURRent? ............................................................................... 2-119

:TRACe:AVERage:COUNt:CURRent? ................................................................................. 2-119

[:SENSe]:AVERage:TYPE ................................................................................................. 2-119

:TRACe<n>:AVERage:TYPE ............................................................................................ 2-119

[:SENSe]:AVERage:TYPE:AUTO ....................................................................................... 2-120

[:SENSe]:BANDwidth|BWIDth:EMIFilter:STATe ................................................................. 2-120

[:SENSe]:BANDwidth|BWIDth[:RESolution] ...................................................................... 2-121

[:SENSe]:BANDwidth|BWIDth[:RESolution]:AUTO ............................................................ 2-121

[:SENSe]:BANDwidth|BWIDth[:RESolution]:SELect ........................................................... 2-122

[:SENSe]:BANDwidth|BWIDth[:RESolution]:SELect:AUTO[:STATe] ..................................... 2-122

[:SENSe]:BANDwidth|BWIDth:SHAPe............................................................................... 2-123

[:SENSe]:BANDwidth|BWIDth:VIDeo ............................................................................... 2-124

[:SENSe]:BANDwidth|BWIDth:VIDeo:AUTO ..................................................................... 2-124

[:SENSe]:BANDwidth|BWIDth:VIDeo:RATio ..................................................................... 2-125

[:SENSe]:BANDwidth|BWIDth:VIDeo:RATio:AUTO ............................................................ 2-125

[:SENSe]:CNRatio:AVERage:COUNt ................................................................................. 2-126

[:SENSe]:CNRatio:AVERage[:STATe] ................................................................................ 2-126

[:SENSe]:CNRatio:AVERage:TCONtrol .............................................................................. 2-127

[:SENSe]:CNRatio:BANDwidth:INTegration ....................................................................... 2-128

[:SENSe]:CNRatio:BANDwidth:NOISe............................................................................... 2-128

[:SENSe]:CNRatio:OFFSet ............................................................................................... 2-129

[:SENSe]:CORRection:CSET:ALL:DELete ........................................................................... 2-129

[:SENSe]:CORRection:CSET:ALL[:STATe] .......................................................................... 2-129

[:SENSe]:CORRection:CSET<n>:DATA ............................................................................. 2-130

[:SENSe]:CORRection:CSET<n>:DATA:MERGe ................................................................. 2-131

[:SENSe]:CORRection:CSET<n>:DELete .......................................................................... 2-131

[:SENSe]:CORRection:CSET<n>[:STATe] ......................................................................... 2-132

[:SENSe]:CORRection:CSET<n>:X:SPACing ..................................................................... 2-132

:INPut:IMPedance .......................................................................................................... 2-133

[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] .................................................... 2-133

[:SENSe]:CORRection:SA[:RF]:GAIN ................................................................................ 2-133

[:SENSe]:DEMod ............................................................................................................ 2-134

[:SENSe]:DEMod:GAIN:AUTO .......................................................................................... 2-134

[:SENSe]:DEMod:GAIN:INCRement ................................................................................. 2-135

[:SENSe]:DEMod:STATe .................................................................................................. 2-136

[:SENSe]:DETector:TRACe:PVTime .................................................................................. 2-136

[:SENSe]:DETector[:FUNCtion] ........................................................................................ 2-137

[:SENSe]:DETector:TRACe<n> ........................................................................................ 2-137

[:SENSe]:DETector:TRACe<n>:AUTO .............................................................................. 2-138

[:SENSe]:EBWidth:AVERage:COUNt ................................................................................. 2-138

VIII RSA3000E Programming Guide

Contents RIGOL

[:SENSe]:EBWidth:AVERage[:STATe] ............................................................................... 2-139

[:SENSe]:EBWidth:AVERage:TCONtrol ............................................................................. 2-139

[:SENSe]:EBWidth:FREQuency:SPAN ............................................................................... 2-140

[:SENSe]:EBWidth:MAXHold:STATe ................................................................................. 2-140

[:SENSe]:EBWidth:XDB .................................................................................................. 2-141

[:SENSe]:FCAPture:BLOCk .............................................................................................. 2-141

[:SENSe]:FCAPture:LENGth ............................................................................................ 2-142

[:SENSe]:FCAPture:POINter ............................................................................................ 2-143

[:SENSe]:FCAPture:WLENgth? ........................................................................................ 2-143

[:SENSe]:FETCh:FCAPture? ............................................................................................ 2-143

[:SENSe]:INITiate:FCAPture ........................................................................................... 2-144

[:SENSe]:FREQuency:CENTer.......................................................................................... 2-144

[:SENSe]:FREQuency:CENTer:STEP:AUTO ....................................................................... 2-145

[:SENSe]:FREQuency:CENTer:STEP[:INCRement] ............................................................ 2-145

[:SENSe]:FREQuency:OFFSet .......................................................................................... 2-146

[:SENSe]:FREQuency:SPAN ............................................................................................ 2-146

[:SENSe]:FREQuency:SPAN:BANDwidth[:RESolution]:RATio .............................................. 2-147

[:SENSe]:FREQuency:SPAN:BANDwidth[:RESolution]:RATio:AUTO .................................... 2-147

[:SENSe]:FREQuency:SPAN:FULL .................................................................................... 2-148

[:SENSe]:FREQuency:SPAN:PREVious ............................................................................. 2-148

[:SENSe]:FREQuency:SPAN:ZERO ................................................................................... 2-148

[:SENSe]:FREQuency:STARt ........................................................................................... 2-148

[:SENSe]:FREQuency:STOP ............................................................................................ 2-149

[:SENSe]:FREQuency:TUNE:IMMediate ........................................................................... 2-149

[:SENSe]:HDISt:AVERage:COUNt .................................................................................... 2-150

[:SENSe]:HDISt:AVERage[:STATe] .................................................................................. 2-150

[:SENSe]:HDISt:AVERage:TCONtrol................................................................................. 2-151

[:SENSe]:HDISt:NUMBers ............................................................................................... 2-151

[:SENSe]:HDISt:TIME ..................................................................................................... 2-152

[:SENSe]:MCHPower:AVERage:COUNt ............................................................................. 2-153

[:SENSe]:MCHPower:AVERage[:STATe] ........................................................................... 2-153

[:SENSe]:MCHPower:AVERage:TCONtrol ......................................................................... 2-154

[:SENSe]:MCHPower:FREQuency:CENTer......................................................................... 2-154

[:SENSe]:MCHPower:CHAnnel:ADD ................................................................................. 2-155

[:SENSe]:MCHPower:CHAnnel:DELete ............................................................................. 2-155

[:SENSe]:MCHPower:CHAnnel:DELete:ALL ...................................................................... 2-155

[:SENSe]:MCHPower:FREQuency:SPAN ........................................................................... 2-156

[:SENSe]:MCHPower:SHEet ............................................................................................ 2-156

[:SENSe]:OBWidth:AVERage:COUNt ................................................................................ 2-157

[:SENSe]:OBWidth:AVERage[:STATe] .............................................................................. 2-157

[:SENSe]:OBWidth:AVERage:TCONtrol ............................................................................ 2-158

[:SENSe]:OBWidth:FREQuency:SPAN .............................................................................. 2-158

[:SENSe]:OBWidth:MAXHold:STATe ................................................................................. 2-159

[:SENSe]:OBWidth:PERCent ........................................................................................... 2-159

[:SENSe]:POWer[:RF]:ATTenuation ................................................................................. 2-160

[:SENSe]:POWer[:RF]:ATTenuation:AUTO ........................................................................ 2-160

[:SENSe]:POWer[:RF]:GAIN[:STATe] ............................................................................... 2-161

[:SENSe]:POWer[:RF]:MIXer:RANGe[:UPPer] ................................................................... 2-161

[:SENSe]:SIGCapture:2FSK:AMPDown ............................................................................. 2-162

[:SENSe]:SIGCapture:2FSK:AMPUp ................................................................................. 2-162

[:SENSe]:SIGCapture:2FSK:MARK1:FREQ ........................................................................ 2-163

[:SENSe]:SIGCapture:2FSK:MARK1:SWitch[:STATe] ......................................................... 2-163

[:SENSe]:SIGCapture:2FSK:MARK2:FREQ ........................................................................ 2-164

[:SENSe]:SIGCapture:2FSK:MARK2:SWitch[:STATe] ......................................................... 2-164

[:SENSe]:SIGCapture:2FSK:MAXHold[:STATe] .................................................................. 2-165

[:SENSe]:SIGCapture:2FSK:PEAKAmp? ............................................................................ 2-165

[:SENSe]:SIGCapture:2FSK:PEAKFreq? ............................................................................ 2-166

[:SENSe]:SIGCapture:2FSK:PF? ...................................................................................... 2-166

RSA3000E Programming Guide IX

RIGOL Contents

[:SENSe]:SIGCapture:2FSK:PFSWitch[:STATe] .................................................................. 2-167

[:SENSe]:SIGCapture:2FSK:RESet ................................................................................... 2-167

[:SENSe]:SIGCapture:2FSK:SIGNal .................................................................................. 2-168

[:SENSe]:SWEep:POINts ................................................................................................. 2-168

[:SENSe]:SWEep:TIME ................................................................................................... 2-169

[:SENSe]:SWEep:TIME:AUTO .......................................................................................... 2-169

[:SENSe]:SWEep:TIME:AUTO:RULes ............................................................................... 2-170

[:SENSe]:TOI:AVERage:COUNt ........................................................................................ 2-170

[:SENSe]:TOI:AVERage[:STATe] ...................................................................................... 2-171

[:SENSe]:TOI:AVERage:TCONtrol .................................................................................... 2-171

[:SENSe]:TOI:FREQuency:SPAN ...................................................................................... 2-172

[:SENSe]:TPOWer:AVERage:COUNt ................................................................................. 2-173

[:SENSe]:TPOWer:AVERage[:STATe] ................................................................................ 2-173

[:SENSe]:TPOWer:AVERage:TCONtrol .............................................................................. 2-174

[:SENSe]:TPOWer:LLIMit ................................................................................................ 2-174

[:SENSe]:TPOWer:MODE ................................................................................................ 2-175

[:SENSe]:TPOWer:RLIMit ................................................................................................ 2-175

[:SENSe]:VSWR:FREFlect ................................................................................................ 2-176

[:SENSe]:VSWR:NREFlect ............................................................................................... 2-176

[:SENSe]:VSWR:RESet .................................................................................................... 2-176

[:SENSe]:VSWR:STATe .................................................................................................... 2-177

:SOURce Commands ............................................................................................................. 2-178

:SOURce:CORRection:OFFSet .......................................................................................... 2-178

:SOURce[:EXTernal]:POWer[:LEVel][:IMMediate][:AMPLitude]........................................... 2-178

:SOURce:TRACe:REFerence:STATe................................................................................... 2-179

:SOURce:TRACe:STORref ................................................................................................ 2-179

:STATus Commands ............................................................................................................... 2-180

:STATus:OPERation:CONDition? ....................................................................................... 2-181

:STATus:OPERation:ENABle ............................................................................................. 2-181

:STATus:OPERation[:EVENt]? .......................................................................................... 2-182

:STATus:PRESet .............................................................................................................. 2-182

:STATus:QUEStionable:CONDition? .................................................................................. 2-182

:STATus:QUEStionable:ENABle......................................................................................... 2-182

:STATus:QUEStionable[:EVENt]? ...................................................................................... 2-183

:SYSTem Commands ............................................................................................................. 2-184

:SYSTem:BEEPer:STATe .................................................................................................. 2-185

:SYSTem:COMMunicate:LAN[:SELF]:APPLy ....................................................................... 2-185

:SYSTem:COMMunicate:LAN[:SELF]:AUToip:STATe ............................................................ 2-185

:SYSTem:COMMunicate:LAN[:SELF]:DHCP:STATe ............................................................. 2-186

:SYSTem:COMMunicate:LAN[:SELF]:IP:ADDRess .............................................................. 2-186

:SYSTem:COMMunicate:LAN[:SELF]:IP:DNS:AUTO[:STATe] ............................................... 2-187

:SYSTem:COMMunicate:LAN[:SELF]:IP:DNSBack .............................................................. 2-188

:SYSTem:COMMunicate:LAN[:SELF]:IP:DNSPreferred ........................................................ 2-188

:SYSTem:COMMunicate:LAN[:SELF]:IP:DNSServer ............................................................ 2-188

:SYSTem:COMMunicate:LAN[:SELF]:IP:GATeway .............................................................. 2-189

:SYSTem:COMMunicate:LAN[:SELF]:IP:SUBMask .............................................................. 2-189

:SYSTem:COMMunicate:LAN[:SELF]:MANuip:STATe .......................................................... 2-190

:SYSTem:COMMunicate:LAN[:SELF]:MDNS:STATe ............................................................. 2-191

:SYSTem:COMMunicate:LAN[:SELF]:RESet ....................................................................... 2-191

:SYSTem:CONFigure:INFormation? .................................................................................. 2-191

:SYSTem:DATE ............................................................................................................... 2-192

:SYSTem:FSWitch[:STATe] .............................................................................................. 2-192

:SYSTem:LANGuage ........................................................................................................ 2-193

:SYSTem:LKEY ............................................................................................................... 2-193

:SYSTem:OPTion:STATe? ................................................................................................. 2-194

:SYSTem:PON:TYPE ........................................................................................................ 2-194

:SYSTem:PRESet ............................................................................................................ 2-195

:SYSTem:PRESet:SAVE .................................................................................................... 2-195

X RSA3000E Programming Guide

Contents RIGOL

:SYSTem:PRESet:TYPE ................................................................................................... 2-195

:SYSTem:PRESet:USER:SAVE .......................................................................................... 2-196

:SYSTem:SCPI:DISPlay ................................................................................................... 2-196

:SYSTem:SECurity:CLEar ................................................................................................ 2-196

:SYSTem:SHOW ............................................................................................................. 2-197

:SYSTem:TIME ............................................................................................................... 2-197

:TRACe Commands ............................................................................................................... 2-198

:TRACe:CLEar:ALL ......................................................................................................... 2-198

:TRACe[:DATA] .............................................................................................................. 2-198

:TRACe:MATH:A ............................................................................................................. 2-200

:TRACe:MATH:B ............................................................................................................. 2-200

:TRACe:MATH:CONSt ..................................................................................................... 2-201

:TRACe:MATH:PEAK[:DATA]? ......................................................................................... 2-201

:TRACe:MATH:PEAK:POINts? .......................................................................................... 2-201

:TRACe:MATH:REFerence ............................................................................................... 2-202

:TRACe:MATH:STATe ...................................................................................................... 2-202

:TRACe:MATH:TYPE ....................................................................................................... 2-203

:TRACe:PRESet:ALL ....................................................................................................... 2-203

:TRACe<n>:DISPlay:STATe ............................................................................................ 2-204

:TRACe<n>:MODE ......................................................................................................... 2-204

:TRACe<n>:TYPE .......................................................................................................... 2-204

:TRACe<n>:UPDate:STATe ............................................................................................. 2-205

:TRIGger Commands ............................................................................................................ 2-206

:TRIGger[:SEQuence]:ATRigger ...................................................................................... 2-207

:TRIGger[:SEQuence]:ATRigger:STATe ............................................................................ 2-207

:TRIGger[:SEQuence]:EXTernal<n>:DELay...................................................................... 2-208

:TRIGger[:SEQuence]:EXTernal<n>:DELay:STATe ............................................................ 2-208

:TRIGger[:SEQuence]:EXTernal<n>:SLOPe ..................................................................... 2-209

:TRIGger[:SEQuence]:FMT:APTRigger ............................................................................. 2-209

:TRIGger[:SEQuence]:FMT:CRITeria ................................................................................ 2-210

:TRIGger[:SEQuence]:FMT:DELay ................................................................................... 2-211

:TRIGger[:SEQuence]:FMT:DELay:STATe ......................................................................... 2-211

:TRIGger[:SEQuence]:FMT:MASK .................................................................................... 2-212

:TRIGger[:SEQuence]:FMT:MASK:EDIT ........................................................................... 2-212

:TRIGger[:SEQuence]:FMT:MASK:RELative:AMPLitude ..................................................... 2-213

:TRIGger[:SEQuence]:FMT:MASK:RELative:FREQuency .................................................... 2-213

:TRIGger[:SEQuence]:FMT:MASK<n>:BUILd ................................................................... 2-214

:TRIGger[:SEQuence]:FMT:MASK<n>:DATA .................................................................... 2-214

:TRIGger[:SEQuence]:FMT:MASK<n>:DELete.................................................................. 2-215

:TRIGger[:SEQuence]:FMT:MASK<n>:NEW ..................................................................... 2-215

:TRIGger[:SEQuence]:HOLDoff ....................................................................................... 2-216

:TRIGger[:SEQuence]:HOLDoff:STATe ............................................................................. 2-216

:TRIGger[:SEQuence]:SOURce ........................................................................................ 2-217

:TRIGger[:SEQuence]:VIDeo:DELay ................................................................................ 2-217

:TRIGger[:SEQuence]:VIDeo:DELay:STATe ...................................................................... 2-218

:TRIGger[:SEQuence]:VIDeo:LEVel ................................................................................. 2-218

:TRIGger[:SEQuence]:VIDeo:SLOPe ................................................................................ 2-219

:TRIGger2:MODE ........................................................................................................... 2-220

:UNIT Command................................................................................................................... 2-221

:UNIT:POWer ................................................................................................................. 2-221

Chapter 3 Command System for EMI Mode ........................................................................ 3-1

:CALCulate Commands .............................................................................................................. 3-2

:CALCulate:EMI:SLISt:DELete ............................................................................................. 3-4

:CALCulate:FSCan:MAMarker[:SET]:SLISt ............................................................................ 3-4

:CALCulate:FSCan:MARKer:AOFF ........................................................................................ 3-4

:CALCulate:FSCan:MARKer:COUPle[:STATe] ......................................................................... 3-4

:CALCulate:FSCan:MARKer:PEAK:EXCursion ......................................................................... 3-5

RSA3000E Programming Guide XI

RIGOL Contents

:CALCulate:FSCan:MARKer:PEAK:EXCursion:STATe ............................................................... 3-5

:CALCulate:FSCan:MARKer:PEAK:SEARch:MODE .................................................................. 3-6

:CALCulate:FSCan:MARKer:PEAK:SEARch:THReshold ............................................................ 3-7

:CALCulate:FSCan:MARKer:PEAK:SEARch:THReshold:STATe .................................................. 3-7

:CALCulate:FSCan:MARker<n>:FUNCtion:MAMarker? ........................................................... 3-8

:CALCulate:FSCan:MARKer<n>:MAXimum ........................................................................... 3-8

:CALCulate:FSCan:MARKer<n>:MAXimum:LEFT ................................................................... 3-8

:CALCulate:FSCan:MARKer<n>:MAXimum:NEXT .................................................................. 3-9

:CALCulate:FSCan:MARKer<n>:MAXimum:RIGHt ................................................................. 3-9

:CALCulate:FSCan:MARKer<n>:MINimum .......................................................................... 3-10

:CALCulate:FSCan:MARKer<n>:MODE ............................................................................... 3-10

:CALCulate:FSCan:MARKer<n>:REFerence ......................................................................... 3-11

:CALCulate:FSCan:MARKer<n>[:SET]:SLISt ....................................................................... 3-11

:CALCulate:FSCan:MARKer<n>[:SET]:METer ...................................................................... 3-11

:CALCulate:FSCan:MARKer<n>:TO:METer .......................................................................... 3-12

:CALCulate:FSCan:MARKer<n>:TRACe .............................................................................. 3-12

:CALCulate:FSCan:SLISt:APPend:METer ............................................................................. 3-13

:CALCulate:FSCan:SLISt:DELete:SIGNal ............................................................................. 3-13

:CALCulate:FSCan:SLISt:MARK:ALL ................................................................................... 3-13

:CALCulate:FSCan:SLISt:MARK:CLEar:ALL .......................................................................... 3-13

:CALCulate:FSCan:SLISt:MARK:CLEar:SIGNal ..................................................................... 3-13

:CALCulate:FSCan:SLISt:MARK:SIGNal ............................................................................... 3-14

:CALCulate:FSCan:SLISt:REPLace:METer ............................................................................ 3-14

:CALCulate:FSCan:SLISt:SET:METer .................................................................................. 3-14

:CALCulate:FSCan:SLISt:SORT:AUTO ................................................................................. 3-15

:CALCulate:FSCan:SLISt:SORT:DAMPlitude ........................................................................ 3-15

:CALCulate:FSCan:SLISt:SORT:DLDelta ............................................................................. 3-16

:CALCulate:FSCan:SLISt:SORT:ORDer ............................................................................... 3-16

:CALCulate:FSCan:SLISt:SORT:TYPE ................................................................................. 3-17

:CALCulate:FSCan:SLISt:ZOOM ......................................................................................... 3-17

:CALCulate:FSCan:SLISt:ZOOM:OUT .................................................................................. 3-18

:CALCulate:LLINe:ALL:DELete ........................................................................................... 3-18

:CALCulate:LLINe:TEST .................................................................................................... 3-18

:CALCulate:LLINe<n>:AMPLitude:CMODe:RELative ............................................................ 3-18

:CALCulate:LLINe<n>:BUILd ............................................................................................ 3-19

:CALCulate:LLINe<n>:CONTrol:INTerpolate:TYPE .............................................................. 3-19

:CALCulate:LLINe<n>:COPY ............................................................................................. 3-20

:CALCulate:LLINe<n>:DATA.............................................................................................. 3-20

:CALCulate:LLINe<n>:DELete ........................................................................................... 3-21

:CALCulate:LLINe<n>:DISPlay .......................................................................................... 3-21

:CALCulate:LLINe<n>:FAIL? ............................................................................................. 3-22

:CALCulate:LLINe<n>:FREQuency:CMODe:RELative ........................................................... 3-22

:CALCulate:LLINe<n>:MARGin .......................................................................................... 3-23

:CALCulate:LLINe<n>:MARGin:STATe ................................................................................ 3-23

:CALCulate:LLINe<n>:OFFSet:X ........................................................................................ 3-24

:CALCulate:LLINe<n>:OFFSet:Y ........................................................................................ 3-24

:CALCulate:LLINe<n>:TRACe ............................................................................................ 3-25

:CALCulate:MARker:PEAK:SEARch:THReshold:LINe ............................................................ 3-25

:CALCulate:MARKer<n>:LINes[:STATe].............................................................................. 3-26

:CALCulate:MARKer<n>:STATe ......................................................................................... 3-26

:CALCulate:MARKer<n>:X ................................................................................................ 3-27

:CALCulate:MARKer<n>:Y? ............................................................................................... 3-27

:CALCulate:METer:LIMit:ALL:FAIL? .................................................................................... 3-28

:CALCulate:METer:POWer[:CURRent]? ............................................................................... 3-28

:CALCulate:METer:POWer:PEAK? ....................................................................................... 3-28

:CALCulate:METer<n>:LIMit[:DATA] ................................................................................. 3-29

:CALCulate:METer<n>:LIMit:FAIL? .................................................................................... 3-29

:CALCulate:METer<n>:LIMit:STATe .................................................................................. 3-30

XII RSA3000E Programming Guide

Contents RIGOL

:CALibration Commands .......................................................................................................... 3-31

:CALibration:[ALL] ............................................................................................................ 3-31

:CALibration:AUTO ........................................................................................................... 3-31

:COUPle Command ................................................................................................................. 3-32

:COUPle .......................................................................................................................... 3-32

:CONFigure Command ............................................................................................................ 3-33

:CONFigure? .................................................................................................................... 3-33

:CONFigure:FSCan ........................................................................................................... 3-33

:DISPlay Commands ............................................................................................................... 3-34

:DISPlay:BACKlight ........................................................................................................... 3-35

:DISPlay:ENABle .............................................................................................................. 3-35

:DISPlay:FSCan:VIEW:METer:FLINe .................................................................................. 3-36

:DISPlay:FSCan:VIEW:METer[:STATe] ............................................................................... 3-36

:DISPlay:FSCan:VIEW:WINDow:TRACe:Y[:SCALe]:PDIVision .............................................. 3-37

:DISPlay:FSCan:VIEW:WINDow:TRACe:Y[:SCALe]:RLEVel .................................................. 3-37

:DISPlay:FSCan:VIEW:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet ...................................... 3-38

:DISPlay:FSCan:WINDow:MAMarker[:STATe] .................................................................... 3-38

:DISPlay:GRATicule[:STATe] .............................................................................................. 3-39

:DISPlay:HDMI[:STATe] .................................................................................................... 3-39

:DISPlay:METer<n>[:STATe]............................................................................................ 3-40

:DISPlay:VIEW:WINDow:TRACe:X:SPACing ....................................................................... 3-40

:DISPlay:WINDow:TRACe:Y:DLINe .................................................................................... 3-41

:DISPlay:WINDow:TRACe:Y:DLINe:STATe .......................................................................... 3-41

:DISPlay[:WINDow]:TRACe<n>:MODE ............................................................................. 3-42

:FETCh Command ................................................................................................................... 3-43

:FETCh:FSCan? ................................................................................................................ 3-43

:FORMat Commands ............................................................................................................... 3-44

:FORMat:BORDer ............................................................................................................. 3-44

:FORMat[:TRACe][:DATA] ................................................................................................. 3-45

IEEE 488.2 Common Commands.............................................................................................. 3-46

:INITiate Commands ............................................................................................................... 3-47

:INITiate:FSCan:CLEar:IMMediate ..................................................................................... 3-47

:INITiate:PAUSe ............................................................................................................... 3-47

:INITiate:RESume ............................................................................................................ 3-47

:INITiate1:CONTinuous .................................................................................................... 3-47

:INITiate2:CONTinuous .................................................................................................... 3-48

:INITiate2:IMMediate ....................................................................................................... 3-48

:INITiate2:RESTart ........................................................................................................... 3-48

:INSTrument Commands ......................................................................................................... 3-49

:INSTrument:COUPle:FREQuency:CENTer .......................................................................... 3-49

:INSTrument:DEFault ....................................................................................................... 3-49

:INSTrument:NSELect ....................................................................................................... 3-50

:INSTrument[:SELect] ...................................................................................................... 3-50

:MMEMory Commands ............................................................................................................ 3-51

:MMEMory:DELete ............................................................................................................ 3-52

:MMEMory:LOAD:CORRection ........................................................................................... 3-52

:MMEMory:LOAD:LIMit ..................................................................................................... 3-52

:MMEMory:LOAD:SCAN .................................................................................................... 3-53

:MMEMory:LOAD:SLISt ..................................................................................................... 3-53

:MMEMory:LOAD:STATe .................................................................................................... 3-54

:MMEMory:LOAD:TRACe ................................................................................................... 3-54

:MMEMory:LOAD:TRACe:DATA .......................................................................................... 3-54

:MMEMory:MOVE ............................................................................................................. 3-55

:MMEMory:STORe:CORRection .......................................................................................... 3-55

:MMEMory:STORe:LIMit .................................................................................................... 3-56

:MMEMory:STORe:SCAN ................................................................................................... 3-56

:MMEMory:STORe:SCReen ................................................................................................ 3-56

:MMEMory:STORe:SLISt ................................................................................................... 3-57

RSA3000E Programming Guide XIII

RIGOL Contents

:MMEMory:STORe:STATe ................................................................................................... 3-57

:MMEMory:STORe:TRACe .................................................................................................. 3-58

:MMEMory:STORe:TRACe:DATA ......................................................................................... 3-58

[:SENSe] Commands ............................................................................................................... 3-59

[:SENSe]:AVERage:COUNt ................................................................................................ 3-61

[:SENSe]:AVERage:TYPE ................................................................................................... 3-61

[:SENSe]:AVERage:TYPE:AUTO ......................................................................................... 3-62

[:SENSe]:BANDwidth|BWIDth:EMIFilter:STATe ................................................................... 3-62

[:SENSe]:BANDwidth|BWIDth[:RESolution] ........................................................................ 3-63

[:SENSe]:BANDwidth|BWIDth[:RESolution]:AUTO .............................................................. 3-63

[:SENSe]:CORRection:CSET:ALL:DELete ............................................................................. 3-64

[:SENSe]:CORRection:CSET:ALL[:STATe] ............................................................................ 3-64

[:SENSe]:CORRection:CSET<n>:DATA ............................................................................... 3-65

[:SENSe]:CORRection:CSET<n>:DATA:MERGe ................................................................... 3-65

[:SENSe]:CORRection:CSET<n>:DELete ............................................................................ 3-66

[:SENSe]:CORRection:CSET<n>[:STATe] ........................................................................... 3-66

[:SENSe]:CORRection:CSET<n>:X:SPACing ....................................................................... 3-67

:INPut:IMPedance ............................................................................................................ 3-67

[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] ...................................................... 3-67

[:SENSe]:CORRection:SA[:RF]:GAIN .................................................................................. 3-68

[:SENSe]:DETector:TRACe<n>:AUTO ................................................................................ 3-68

[:SENSe]:EMC:STANdard[:SELect] ..................................................................................... 3-69

[:SENSe]:FREQuency:CENTer ............................................................................................ 3-69

[:SENSe]:FREQuency:MIDSpan ......................................................................................... 3-70

[:SENSe]:FREQuency:SPAN ............................................................................................... 3-70

[:SENSe]:FREQuency:STARt .............................................................................................. 3-71

[:SENSe]:FREQuency:STARt:AUTO .................................................................................... 3-71

[:SENSe]:FREQuency:STOP ............................................................................................... 3-72

[:SENSe]:FREQuency:STOP:AUTO ..................................................................................... 3-72

[:SENSe]:FSCan:DETector:TRACe<n> ............................................................................... 3-73

[:SENSe]:FSCan:FINal:DETector<n> ................................................................................. 3-73

[:SENSe]:FSCan:FINal:DETector<n>:DWELl ...................................................................... 3-74

[:SENSe]:FSCan:FINal:DETector<n>:LDELta...................................................................... 3-75

[:SENSe]:FSCan:MARKer:COUPle:METer ............................................................................ 3-75

[:SENSe]:FSCan:SCAN:ABORT ........................................................................................... 3-76

[:SENSe]:FSCan:SCAN<n>:BANDwidth|BWIDth:EMIFilter:STATe ......................................... 3-76

[:SENSe]:FSCan:SCAN<n>:BANDwidth[:RESolution] .......................................................... 3-76

[:SENSe]:FSCan:SCAN<n>:BANDwidth[:RESolution]:AUTO ................................................. 3-77

[:SENSe]:FSCan:SCAN<n>:INPut:ATTenuation ................................................................... 3-78

[:SENSe]:FSCan:SCAN<n>:INPut:ATTenuation:AUTO ......................................................... 3-78

[:SENSe]:FSCan:SCAN<n>:POINT ..................................................................................... 3-79

[:SENSe]:FSCan:SCAN<n>:POWer:GAIN[:STATe] ............................................................... 3-79

[:SENSe]:FSCan:SCAN<n>:STARt ..................................................................................... 3-80

[:SENSe]:FSCan:SCAN<n>:STATe ..................................................................................... 3-80

[:SENSe]:FSCan:SCAN<n>:STOP ...................................................................................... 3-81

[:SENSe]:FSCan:SCAN<n>:TIME....................................................................................... 3-81

[:SENSe]:FSCan:SCAN<n>:TIME:AUTO ............................................................................. 3-82

[:SENSe]:FSCan:SEARch:MODE ......................................................................................... 3-82

[:SENSe]:FSCan:SEARch:PEAK:COUNt ............................................................................... 3-83

[:SENSe]:FSCan:SEARch:PEAK:COUNt:STATe .................................................................... 3-83

[:SENSe]:FSCan:SEARch:SUBRange:COUNt ....................................................................... 3-84

[:SENSe]:FSCan:SEQuence ............................................................................................... 3-84

[:SENSe]:FSCan:SEQuence:REMeasure .............................................................................. 3-85

[:SENSe]:FSCan:SLISt:COUPle:METer ................................................................................ 3-85

[:SENSe]:FSCan:TRACe:TYPE ............................................................................................ 3-86

[:SENSe]:METer:DETector:DWELl ...................................................................................... 3-86

[:SENSe]:METer:PHOLd:ADJustable ................................................................................... 3-87

[:SENSe]:METer:PHOLd:RESet .......................................................................................... 3-87

XIV RSA3000E Programming Guide

Contents RIGOL

[:SENSe]:METer:PHOLd:TYPE ........................................................................................... 3-87

[:SENSe]:METer<n>:DETector ......................................................................................... 3-88

[:SENSe]:POWer[:RF]:ATTenuation ................................................................................... 3-88

[:SENSe]:POWer[:RF]:GAIN[:STATe] ................................................................................. 3-89

:STATus Commands ................................................................................................................ 3-90

:SYSTem Commands ............................................................................................................... 3-91

:TRACe Commands ................................................................................................................. 3-92

:TRACe[:DATA] ................................................................................................................ 3-92

:TRACe<n>:DISPlay[:STATe] ............................................................................................ 3-93

:TRACe<n>:UPDate:STATe ............................................................................................... 3-93

:TRIGger Commands .............................................................................................................. 3-94

:TRIGger[:SEQuence]:ATRigger ........................................................................................ 3-94

:TRIGger[:SEQuence]:ATRigger:STATe .............................................................................. 3-95

:TRIGger[:SEQuence]:EXTernal<n>:DELay........................................................................ 3-95

:TRIGger[:SEQuence]:EXTernal<n>:DELay:STATe .............................................................. 3-96

:TRIGger[:SEQuence]:EXTernal<n>:SLOPe ....................................................................... 3-96

:TRIGger[:SEQuence]:HOLDoff ......................................................................................... 3-97

:TRIGger[:SEQuence]:HOLDoff:STATe ............................................................................... 3-97

:TRIGger[:SEQuence]:SOURce .......................................................................................... 3-98

:TRIGger2:MODE ............................................................................................................. 3-98

:UNIT Command................................................................................................................... 3-100

:UNIT:POWer ................................................................................................................. 3-100

Chapter 4 Command System for VSA Mode ........................................................................ 4-1

:CALCulate Commands .............................................................................................................. 4-2

:CALCulate:DDEMod:MARKer:AOFF ..................................................................................... 4-3

:CALCulate:DDEMod:MARKer:COUPle[:STATe] ..................................................................... 4-3

:CALCulate:DDEMod:MARKer:TABLe[:STATe] ....................................................................... 4-3

:CALCulate:DDEMod:MARKer<n>:CPSearch[:STATe] ............................................................ 4-4

:CALCulate:DDEMod:MARKer<n>:FUNCtion ........................................................................ 4-4

:CALCulate:DDEMod:MARKer<n>:FUNCtion:BAND:LEFT ...................................................... 4-5

:CALCulate:DDEMod:MARKer<n>:FUNCtion:BAND:RIGHt ..................................................... 4-5

:CALCulate:DDEMod:MARKer<n>:FUNCtion:BAND:SPAN ...................................................... 4-6

:CALCulate:DDEMod:MARKer<n>:MAXimum ....................................................................... 4-7

:CALCulate:DDEMod:MARKer<n>:MAXimum:LEFT ............................................................... 4-7

:CALCulate:DDEMod:MARKer<n>:MAXimum:NEXT .............................................................. 4-7

:CALCulate:DDEMod:MARKer<n>:MAXimum:PREVious ......................................................... 4-8

:CALCulate:DDEMod:MARKer<n>:MAXimum:RIGHt ............................................................. 4-8

:CALCulate:DDEMod:MARKer<n>:MINimum ........................................................................ 4-9

:CALCulate:DDEMod:MARKer<n>:MODE ............................................................................. 4-9

:CALCulate:DDEMod:MARKer<n>:REFerence ..................................................................... 4-10

:CALCulate:DDEMod:MARKer<n>:TRACe .......................................................................... 4-10

:CALCulate:DDEMod:MARKer<n>:X .................................................................................. 4-11

:CALCulate:DDEMod:MARKer<n>:Y:IMAGinary .................................................................. 4-11

:CALCulate:DDEMod:MARKer<n>:Y[:REAL] ....................................................................... 4-12

:CALCulate:MARKer<n>[:SET]:CENTer .............................................................................. 4-13

:CALCulate:MARKer<n>[:SET]:DELTa:CENTer .................................................................... 4-13

:CALCulate:MARKer<n>[:SET]:RLEVel ............................................................................... 4-13

:CALCulate:MARKer<n>[:SET]:STARt ................................................................................ 4-14

:CALCulate:MARKer<n>[:SET]:STEP ................................................................................. 4-14

:CALCulate:MARKer<n>[:SET]:STOP ................................................................................. 4-15

:CALibration Commands .......................................................................................................... 4-16

:CALibration:[ALL] ............................................................................................................ 4-16

:CALibration:AUTO ........................................................................................................... 4-16

:CONFigure Commands ........................................................................................................... 4-17

:CONFIgure:BERate ......................................................................................................... 4-17

:CONFigure:DDEMod ........................................................................................................ 4-17

:DISPlay Commands ............................................................................................................... 4-18

RSA3000E Programming Guide XV

RIGOL Contents

:DISPlay:BACKlight ........................................................................................................... 4-19

:DISPlay:DDEMod:TRACe<n>:DDEMod:EYE:COUNt ........................................................... 4-19

:DISPlay:DDEMod:TRACe<n>:DDEMod:SYMBol:FORMat .................................................... 4-20

:DISPlay:DDEMod:TRACe<n>:FEED .................................................................................. 4-20

:DISPlay:DDEMod:TRACe<n>:FORMat .............................................................................. 4-21

:DISPlay:DDEMod:TRACe<n>:X[:SCALe]:COUPle ............................................................... 4-21

:DISPlay:DDEMod:TRACe<n>:X[:SCALe]:RLEVel ................................................................ 4-22

:DISPlay:DDEMod:TRACe<n>:X[:SCALe]:RPOSition ........................................................... 4-23

:DISPlay:DDEMod:TRACe<n>:X[:SCALe]:SPAN .................................................................. 4-23

:DISPlay:DDEMod:TRACe<n>:Y[:SCALe]:AUTO:ONCE ........................................................ 4-24

:DISPlay:DDEMod:TRACe<n>:Y[:SCALe]:PDIVision ............................................................ 4-24

:DISPlay:DDEMod:TRACe<n>:Y[:SCALe]:RLEVel ................................................................ 4-25

:DISPlay:DDEMod:TRACe<n>:Y:UNIT:PREFerence ............................................................. 4-25

:DISPlay:DDEMod:WINDow:FORMat .................................................................................. 4-26

:DISPlay:ENABle ............................................................................................................... 4-26

:DISPlay:GRATicule[:STATe] .............................................................................................. 4-27

:DISPlay:HDMI[:STATe] .................................................................................................... 4-27

:FETCh Commands .................................................................................................................. 4-28

:FETCh:BER? .................................................................................................................... 4-28

:FETCh:DDEMod? ............................................................................................................. 4-28

:FORMat Commands ............................................................................................................... 4-29

:FORMat:BORDer ............................................................................................................. 4-29

:FORMat[:TRACe][:DATA] ................................................................................................. 4-29

IEEE 488.2 Common Commands .............................................................................................. 4-31

:INITiate Command................................................................................................................. 4-32

:INITiate:BER:RESTart ...................................................................................................... 4-32

:INITiate:CONTinuous ...................................................................................................... 4-32

:INSTrument Commands.......................................................................................................... 4-33

:INSTrument:COUPle:FREQuency:CENTer .......................................................................... 4-33

:INSTrument:DEFault ........................................................................................................ 4-33

:INSTrument:NSELect ....................................................................................................... 4-34

:INSTrument[:SELect] ....................................................................................................... 4-34

:MMEMory Commands ............................................................................................................. 4-35

:MMEMory:DELete ............................................................................................................ 4-35

:MMEMory:LOAD:FMT ....................................................................................................... 4-35

:MMEMory:LOAD:STATe .................................................................................................... 4-36

:MMEMory:LOAD:TRACe:DATA .......................................................................................... 4-36

:MMEMory:MOVE .............................................................................................................. 4-37

:MMEMory:STORe:FMT ..................................................................................................... 4-37

:MMEMory:STORe:SCReen ................................................................................................ 4-37

:MMEMory:STORe:STATe ................................................................................................... 4-38

:MMEMory:STORe:TRACe:DATA ......................................................................................... 4-38

[:SENSe] Commands ............................................................................................................... 4-40

[:SENSe]:ACQuisition:TIME ............................................................................................... 4-41

:INPut:IMPedance ............................................................................................................ 4-41

[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] ...................................................... 4-41

[:SENSe]:CORRection:SA[:RF]:GAIN .................................................................................. 4-42

[:SENSe]:DDEMod:ALPHa ................................................................................................. 4-42

[:SENSe]:DDEMod:FFT:WINDow[:TYPE] ............................................................................ 4-43

[:SENSe]:DDEMod:FILTer:MEASurement ............................................................................ 4-43

[:SENSe]:DDEMod:FILTer:MEASurement:USER<n>[:DATA]................................................. 4-44

[:SENSe]:DDEMod:FILTer:REFerence ................................................................................. 4-44

[:SENSe]:DDEMod:FILTer:REFerence:USER<n>[:DATA] ...................................................... 4-45

[:SENSe]:DDEMod:FSK:DEViation:REFerence ..................................................................... 4-45

[:SENSe]:DDEMod:FSK:DEViation:REFerence:AUTO ........................................................... 4-46

[:SENSe]:DDEMod:LOAD:KNOWndata ............................................................................... 4-46

[:SENSe]:DDEMod:MODulation .......................................................................................... 4-47

[:SENSe]:DDEMod:PPSYmbol ............................................................................................ 4-47

XVI RSA3000E Programming Guide

Contents RIGOL

[:SENSe]:DDEMod:RTTrace:DETector ............................................................................... 4-48

[:SENSe]:DDEMod:SRATe ................................................................................................. 4-48

[:SENSe]:DDEMod:STANdard:PRESet ................................................................................ 4-49

[:SENSe]:DDEMod:SWEep:POINts .................................................................................... 4-49

[:SENSe]:DDEMod:SYNC:ALENgth ..................................................................................... 4-50

[:SENSe]:DDEMod:SYNC:BURSt:RUNIn ............................................................................. 4-50

[:SENSe]:DDEMod:SYNC:BURSt:STATe .............................................................................. 4-51

[:SENSe]:DDEMod:SYNC:SLENgth ..................................................................................... 4-51

[:SENSe]:DDEMod:SYNC:SWORd:OFFSet .......................................................................... 4-52

[:SENSe]:DDEMod:SYNC:SWORd:PATTern ......................................................................... 4-52

[:SENSe]:DDEMod:SYNC:SWORd:STATe ............................................................................ 4-53

[:SENSe]:FREQuency:CENTer............................................................................................ 4-53

[:SENSe]:FREQuency:CENTer:STEP:AUTO ......................................................................... 4-54

[:SENSe]:FREQuency:CENTer:STEP[:INCRement] .............................................................. 4-54

[:SENSe]:FREQuency:SPAN? ............................................................................................. 4-55

[:SENSe]:FREQuency:STARt ............................................................................................. 4-55

[:SENSe]:FREQuency:STOP .............................................................................................. 4-56

[:SENSe]:POWer[:RF]:RANGe ........................................................................................... 4-56

:STATus Commands ................................................................................................................ 4-57

:SYSTem Commands ............................................................................................................... 4-58

:TRACe Command .................................................................................................................. 4-59

:TRACe<n>[:DATA]? ....................................................................................................... 4-59

:TRIGger Commands .............................................................................................................. 4-60

:TRIGger[:SEQuence]:ATRigger ........................................................................................ 4-60

:TRIGger[:SEQuence]:ATRigger:STATe .............................................................................. 4-61

:TRIGger[:SEQuence]:EXTernal<n>:DELay........................................................................ 4-61

:TRIGger[:SEQuence]:EXTernal<n>:DELay:STATe .............................................................. 4-62

:TRIGger[:SEQuence]:EXTernal<n>:SLOPe ....................................................................... 4-62

:TRIGger[:SEQuence]:FMT:CRITeria .................................................................................. 4-63

:TRIGger[:SEQuence]:FMT:DELay ..................................................................................... 4-64

:TRIGger[:SEQuence]:FMT:DELay:STATe ........................................................................... 4-64

:TRIGger[:SEQuence]:FMT:MASK ...................................................................................... 4-65

:TRIGger[:SEQuence]:FMT:MASK:EDIT ............................................................................. 4-65

:TRIGger[:SEQuence]:FMT:MASK:RELative:AMPLitude ....................................................... 4-66

:TRIGger[:SEQuence]:FMT:MASK:RELative:FREQuency ...................................................... 4-66

:TRIGger[:SEQuence]:FMT:MASK<n>:BUILd ..................................................................... 4-67

:TRIGger[:SEQuence]:FMT:MASK<n>:DATA ...................................................................... 4-67

:TRIGger[:SEQuence]:FMT:MASK<n>:DELete.................................................................... 4-68

:TRIGger[:SEQuence]:FMT:MASK<n>:NAME ..................................................................... 4-68

:TRIGger[:SEQuence]:FMT:MASK<n>:NEW ....................................................................... 4-69

:TRIGger[:SEQuence]:HOLDoff ......................................................................................... 4-69

:TRIGger[:SEQuence]:HOLDoff:STATe ............................................................................... 4-70

:TRIGger[:SEQuence]:LEVel ............................................................................................. 4-70

:TRIGger[:SEQuence]:SOURce .......................................................................................... 4-71

:TRIGger2:MODE ............................................................................................................. 4-71

Chapter 5 Programming Examples ..................................................................................... 5-1

Programming Instructions ......................................................................................................... 5-2

Programming Preparations ........................................................................................................ 5-2

Visual C++ 6.0 Programming Example ....................................................................................... 5-3

Visual Basic 6.0 Programming Example .................................................................................... 5-11

LabVIEW 2010 Programming Example ..................................................................................... 5-15

Linux Programming Example ................................................................................................... 5-19

Programming Preparations ................................................................................................ 5-19

Linux Programming Procedures ......................................................................................... 5-22

Chapter 6 Appendix ............................................................................................................ 6-1

Appendix A: Default Settings ..................................................................................................... 6-1

Appendix B: Warranty ............................................................................................................. 6-11

RSA3000E Programming Guide XVII

Chapter 1 Programming Overview RIGOL

Chapter 1 Programming Overview

This chapter introduces how to set up remote communication between the spectrum analyzer and the PC,
the remote control methods, the syntax, symbols, parameters, and abbreviation rules of the SCPI
commands.

Contents in this chapter:

 Build Remote Communication
 Remote Control Method
 SCPI Command Overview

RSA3000E Programming Guide 1-1

RIGOL Chapter 1 Programming Overview

Build Remote Communicatio n

RSA3000E supports communication with PC via USB and LAN interface for remote control. This chapter
introduces in detai ls how to use Ultra Sigma to send comm ands through the USB interface to control the
analyzer.

Operation Procedures:

1. Install Ultra Sigma (PC) software.

You can download Ultra Sigma from the official website of RIGOL (www.rigol.com) and install the
software according to the installation wizard.

2. Connect the analyzer to the PC and configure the interface parameters for the instrument

RSA3000E supports three communication inte rfaces: USB and LAN.

USB DEVICE
LAN

Figure 1-1 RSA3000E Communication Interface

(1) Remote communication via USB:

Use the USB cable to connect the USB DEVICE interface on the rear panel of RSA3000E to the USB
HOST interface of the PC.

(2) Remote communication via LAN:

 Make sure that your PC has been accessed to the local area network.
 Check whether the local area network where your PC resides supports DHCP or auto IP mode.

If not, you need to obtain the available network interface parameters, including the IP
address, subnet mask, default gateway, and DNS.

 Connect RSA3000E to the local area network by using a network cable.
 Press System  Interface  LAN to configure the IP address, subnet mask, default

gateway, and DNS for the instrument.

3. Check whether the connection is successful.

Run Ultra Sigma, and then search for the resources and right-click the resource name. Select "SCPI
Panel Control" to open the SCPI command control panel. In the SCPI command control panel, input a
correct command. After that, click Send Command first and then click Read Response. Or you can
also directly click Send & Read to verify whether the connection works properly . The following figure
takes USB interface as an example to illustrate it.

1-2 RSA3000E Programming Guide

Chapter 1 Programming Overview RIGOL

Remote Control Method

1. User-defined programming

You can refer to the SCPI (Standard Commands for Programmable Instruments) commands listed in
Chapter 2 in this manual to control RSA3000E by programming in LabVIEW, Visual C++, and other
development environments. For details, refer to descriptions in Chapter 4 in this manual.

2. Send SCPI commands via the PC software

Yo u can use the PC so ftw are to sen d comman ds to c ontrol RSA3000E remotely. RIGOL Ultra Sigma is
recommended. You can download the software from RIGOL official website (www.rigol.com).

RSA3000E Programming Guide 1-3

RIGOL Chapter 1 Programming Overview

SCPI Command Overview

SCPI (Standard Commands for Programmable Instruments) is a standardiz ed instrument programming
language that is built upon the existing standard IEEE 488.1 and IEEE 488.2 and conforms to various
standards, such as the floating point operation rule in IEEE 754 standard, ISO 646 7-bit coded character set
for information interchange (equivalent to ASCII programming). This chapter introduces the syntax,
symbols, parameters, and abbreviation rules of the SCPI commands.

Syntax

The SCPI commands provide a hierarchical tree structure, and consist of multiple subsystems. Each
command subsystem consis ts of one root keyword and one or more sub-keywords. The command line
usually starts with ":"; the keywords are separated by ":" and are followed by the parameter settings
available; "?" i s add ed at the en d of the comman d line to in dic ate a qu ery; the comman ds an d p ar ameters
are separated by spaces.

For example,
:CALCulate:BANDwidth:NDB <rel_ampl>
:CALCulate:BANDwidth:NDB?

CALCulate is the root keyword of the command. BANDwidth is the second-level keyword, and NDB is the
third-level keyword. The command line starts with ":", and a colon is also used to separate the
multiple-level keywords. <rel_ampl > r epres ents th e par ameter s a vailable fo r setting. "?" represent s qu ery.
The command :CALCulate:BANDwidth:NDB and the parameter <rel_ampl> are separated by a space.

In some commands with multiple parameters , "," is often us ed to separate these parameters. F or exampl e,
:SYSTem:DATE <yea r>,<month >, <da y >.

Symbol Description

The following four symbols are not part of the SCPI command, and they are not sent with the commands,
but taken as delimiters to better describe the parameters in the command.

1. Braces { }
The parameters enclosed in the b races are op tional. You do not hav e to set it, also you c an set for one
or more times.

2. Vertical Bar |
The vertical bar is used to separate multiple parameters. When using the command, you must select
one of the parameters. For example, in the command :CALCulate:MARKer<n>:LINes[:STATe]
OFF|ON|0|1, you can select any of the four available parameters: OFF, ON, 0, or 1.

3. Square Brackets [ ]

The content (command keyword) in the square brack ets can be omit ted. If a keyword is omitted, it will
be set to the default. F or example, for the [:SENSe]:POWer[:RF]:ATTenuation? command, sending any
of the four commands below can generate the same effect:
:POWer:ATTenuation?
:POWer:RF:ATTenuation?
:SENSe:POWer:ATTenuation?
:SENSe:POWer:RF:ATTenuation?

4. Angle Brackets < >
The parameter enclosed in the angle brackets must be replaced by an effective value. For example,
send the :SENSe:FREQuency:CENTer 1000 command in [:SENSe]:FREQuency:CENTer <freq>format.

1-4 RSA3000E Programming Guide

Chapter 1 Programming Overview RIGOL

Parameter Type

The command parameters introduced in this manual include 6 types: Bool, Keyword, Integer, Consecutive
Real Number, Discrete, and ASCII String.

1. Bool
The parameter can be set to OFF (0) or ON (1).

2. Keyword
The parameter can be any of the values listed.

3. Integer
Unless otherwise specified, the parameter can be any integer within the effective value range. Note:
Do not set the parameter to a decimal, otherwise, errors will occur.

4. Consecutive Real Number
Unless otherwise specified, the parameter could be any value within the effective value range
according to the accuracy requirement (by default, there are 9 digits after the decimal point).

5. Discrete
The parameter could only be one of the specified values and these values are discontin uous.

6. ASCII String
The parameter can be the combinations of ASCII characters.

Command Abb r eviation

All the commands are case-insensitive. T hey can all be written in upper case or in lower case. For
abbreviations, you only need to input all the upper-case letters in the command. For example,
:CALCulate:BANDwidth:NDB? can be abbreviated as :CALC:BAND:NDB? or :calc:band:ndb?

RSA3000E Programming Guide 1-5

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Chapter 2 Command Systems for GPSA and RTSA

Modes

This chapter introduces the commands of the RSA3000E series spectrum analyzer.

Contents in this chapter:

 :CALCulate Commands
 :CALibration Commands
 :CONFigure Commands
 :COUPle Commands
 :DISPlay Commands
 :FETCh Commands
 :FORMat Commands
 IEEE 488.2 Common Commands
 :INITiate Commands
 :INSTrument Commands
 :MMEMory Commands
 :OUTPut Command
 :READ Commands
 [:SENSe] Commands
 :SOURce Commands
 :STATus Commands
 :SYSTem Commands
 :TRACe Commands
 :TRIGger Commands
 :UNIT Command

Remarks:

1. The commands concerning the advanced measurement are only available for the RSA3000E model

2. The commands related to the tracking generator are only available for RSA3030E-TG/RSA3015E-TG.

3. For the command set, unless otherwise specified, the query command returns "N/A" (without

4. This manual takes RSA3030E as an example to illustrate the range of the parameters in each

installed with relevant options. For details, refer to remarks for each command subsystem.
They are only available for GPSA mode.
quotations in its return format) if no specified option is installed. If the queried function is disabled or

improper type match is found, the query command will return "Error" (without quotations in its return
format).

command.

RSA3000E Programming Guide 2-1

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:CALCulate Commands

Command List:

 :CALCulate:BANDwidth|BWIDth:NDB
 :CALCulate:BANDwidth|BWIDth:RESult?
 :CALCulate:BANDwidth|BWIDth:RLEFt?
 :CALCulate:BANDwidth|BWIDth:RRIGht?
 :CALCulate:BANDwidth|BWIDth [:STATe]
 :CALCulate:LLINe:ALL:DELete
 :CALCulate:LLINe:TEST
 :CALCulate:LLINe<n>:AMPLitude:CMODe:RELative
 :CALCulate:LLINe<n>:BUILd
 :CALCulate:LLINe<n>:COPY
 :CALCulate:LLINe<n>:DATA
 :CALCulate:LLINe<n>:DELete
 :CALCulate:LLINe<n>:DISPlay
 :CALCulate:LLINe<n>:FAIL?
 :CALCulate:LLINe<n>:FREQuency:CMODe:RELative
 :CALCulate:LLINe<n>:MARGin
 :CALCulate:LLINe<n>:MARGin:STATe
 :CALCulate:LLINe<n>:TRACe
 :CALCulate:LLINe<n>:TYPE
 :CALCulate:MARKer:AOFF
 :CALCulate:MARKer:COUPle[:STATe]
 :CALCulate:MARKer:PEAK:EXCursion
 :CALCulate:MARKer:PEAK:EXCursion:STATe
 :CALCulate:MARKer:PEAK:SEARch:MODE
 :CALCulate:MARKer:PEAK:SORT
 :TRACe:MATH:PEAK:SORT
 :CALCulate:MARKer:PEAK:TABLe:READout
 :CALCulate:MARKer:PEAK:TABLe[:STATe]
 :CALCulate:MARKer:PEAK:THReshold
 :CALCulate:MARKer:PEAK:THReshold:STATe
 :CALCulate:MARKer:TABLe[:STATe]
 :CALCulate:MARKer:TRCKing[:STATe]
 :CALCulate:MARKer<n>:CPSearch[:STATe]
 :CALCulate:MARKer<n>:FCOunt:GATetime
 :CALCulate:MARKer<n>:FCOunt:GATetime:AUTO
 :CALCulate:MARKer<n>:FCOunt[:STATe]

2-2 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

 :CALCulate:MARKer<n>:FCOunt:X?
 :CALCulate:MARKer<n>:FUNCtion
 :CALCulate:MARKer<n>:FUNCtion:BAND:LEFT
 :CALCulate:MARKer<n>:FUNCtion:BAND:RIGHt
 :CALCulate:MARKer<n>:FUNCtion:BAND:SPAN
 :CALCulate:MARKer<n>:FUNCtion:BAND:SPAN:AUTO
 :CALCulate:MARKer<n>:LINes[:STATe]
 :CALCulate:MARKer<n>:MAXimum:LEFT
 :CALCulate:MARKer<n>:MAXimum[:MAX]
 :CALCulate:MARKer<n>:MAXimum:NEXT
 :CALCulate:MARKer<n>:MAXimum:RIGHt
 :CALCulate:MARKer<n>:MINimum
 :CALCulate:MARKer<n>:MODE
 :CALCulate:MARKer<n>:PTPeak
 :CALCulate:MARKer<n>:REFerence
 :CALCulate:MARKer<n>[:SET]:CENTer
 :CALCulate:MARKer<n>[:SET]:DELTa:CENTer
 :CALCulate:MARKer<n>[:SET]:DELTa:SPAN
 :CALCulate:MARKer<n>[:SET]:RLEVel
 :CALCulate:MARKer<n>[:SET]:STARt
 :CALCulate:MARKer<n>[:SET]:STEP
 :CALCulate:MARKer<n>[:SET]:STOP
 :CALCulate:MARKer<n>:STATe
 :CALCulate:MARKer<n>:TRACe
 :CALCulate:MARKer<n>:TRACe:AUTO
 :CALCulate:MARKer<n>:X
 :CALCulate:MARKer<n>:X:READout
 :CALCulate:MARKer<n>:X:READout:AUTO
 :CALCulate:MARKer<n>:Y
 :CALCulate:MARKer<n>:Z:POSition
 :CALCulate:MATH
 :CALCulate:NTData[:STATe]

RSA3000E Programming Guide 2-3

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<rel_ampl>

Consecutive Real Number

-140 dB to -0.01 dB

-3.01 dB

:CALCulate:BANDwidth|BWIDth:NDB

Syntax

:CALCulate:BANDwidth|BWIDth:NDB <rel_ampl>
:CALCulate:BANDwidth|BWIDth:NDB?

Description

Sets the N value in N dB BW measurement.
Queries the N value in N dB BW measurement.

Parameter

Remarks

This command is invalid for the PvT measurement mode in RTSA.

Return Format

The query returns the N value in scientific notation.

Example

The following command sets N to -4.
:CALCulate:BANDwidth:NDB -4
:CALCulate:BWIDth:NDB -4

The following query returns -4.000000e+00.
:CALCulate:BANDwidth:NDB?
:CALCulate:BWIDth:NDB?

:CALCulate:BANDwidth|BWIDth:RESult?

Syntax

:CALCulate:BANDwidth|BWIDth:RESult?

Description
Queries the measurement results of the N dB band, and its unit is Hz.

Remarks

This command is invalid for the PvT measurement mode in RTSA.
Return Format

The query returns the bandwidth value in scientific notation (with Hz as the unit).
If the two points which are located at both sides of the current marker with N dB fall or rise in its peak
amplitude are not found, the query returns -1.000000000e+02.

2-4 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:BANDwidth|BWIDth:RLEFt?

Syntax

:CALCulate:BANDwidth|BWIDth:RLEFt?

Description
Queries the frequency value of the frequency point that is located at the left side of the current marker with
N dB fall or rise in its peak amplitude.

Remarks

This command is invalid for the PvT measurement mode in RTSA.

Return Format
The query returns the frequency value in scientific notation (with Hz as the unit).
If the frequency point that is located at the left side of the current marker with N dB fall or rise in its peak
amplitude is not found, the query returns -1.000000000e+02.

:CALCulate:BANDwidth|BWIDth:RRIGht?

Syntax

:CALCulate:BANDwidth|BWIDth:RRIGht?

Description
Queries the frequency value of the frequency point that is located at the right side of the current marker
with N dB fall or rise in its peak amplitude.

Remarks

This command is invalid for the PvT measurement mode in RTSA.

Return Format
The query returns the frequency value in scientific notation (with Hz as the unit).
If the frequency point that is located at the right side of the current marker with N dB fall or rise in its peak
amplitude is not found, the query returns -1.000000000e+02.

:CALCulate:BANDwidth|BWIDth [:STATe]

Syntax

:CALCulate:BANDwidth|BWIDth[:STATe] OFF|ON|0|1
:CALCulate:BANDwidth|BWIDth[:STATe]?

Description

Enables or disables the N dB bandwidth measurement function.
Queries the status of the N dB bandwidth measurement function.

Parameter

Remarks

This command is invalid for the PvT measurement mode in RTSA.

RSA3000E Programming Guide 2-5

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

Return Format

The query returns 0 or 1.

Example

The following command enables the N dB BW measurement function.
:CALCulate:BANDwidth:STATe ON or :CALCulate:BANDwidth:STATe 1
:CALCulate:BWIDth:STATe ON or :CALCulate:BWIDth:STATe 1

The following query returns 1.
:CALCulate:BANDwidth:STATe?
:CALCulate:BWIDth:STATe?

:CALCulate:LLINe:ALL:DELete

Syntax

:CALCulate:LLINe:ALL:DELete

Description

Deletes all the limit line data.

:CALCulate:LLINe:TEST

Syntax

:CALCulate:LLINe:TEST OFF|ON|0|1
:CALCulate:LLINe:TEST?

Description

Enables or disables the limit line test function.
Queries the status of the limit line test function.

Parameter

Return Format

The query returns 0 or 1.
Example

The following command disables the limit line test function.
:CALCulate:LLINe:TEST OFF or :CALCulate:LLINe:TEST 0

The following query returns 0。
:CALCulate:LLINe:TEST?

2-6 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Keyword

TRACE1|TRACE2|TRACE3|TRACE4|TRACE5|TRACE6

——

:CALCulate:LLINe<n>:AMPLitude:CMODe:RELative

Syntax

:CALCulate:LLINe<n>:AMPLitude:CMODe:RELative OFF|ON|0|1
:CALCulate:LLINe<n>:AMPLitude:CMODe:RELative?

Description

Enables or disables the coupling functions between the selected limit line data points and the reference
level.
Queries the status of the coupling functions between the selected limit line data points and the reference
level.

Parameter

——

Remarks

OFF|0: disables the coupling function. That is, "Fixed" is selected under Y to Ref, and the amplitude of the
current limit line editing point is not affected by the reference level.
ON|1: enables the coupling function. That is, "Relative" is selected under Y to Ref, and the amplitude of
the current limit line editing point is the difference between the current point with the current reference
level. At this time, if th e ref eren c e level changes, the positio n of th e current editing point will move up and
down with it.

Return Format
The query returns 0 or 1.

Example
The following command disables the coupling functions between the selected limit line data points and the
reference level.
:CALCulate:LLINe2:AMPLitude:CMODe:RELative OFF or :CALCulate:LLINe2:AMPLitude:CMODe:RELative 0

The following query returns 0.
:CALCulate:LLINe2:AMPLitude:CMODe:RELative?

:CALCulate:LLINe<n>:BUILd

Syntax

:CALCulate:LLINe<n>:BUILd TRACE1|TRACE2|TRACE3|TRACE4|TRACE5|TRACE6

Description

Builds the limit line from the selected trace.

Parameter

Example

The following command builds Limit Line 2 from Trace2.
:CALCulate:LLINe2:BUILd TRACE2

RSA3000E Programming Guide 2-7

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Keyword

LLINE1|LLINE2|LLINE3|LLINE4|LLINE5|LLINE6

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

1

<x>

Consecutive Real Number

0 Hz to 3 GHz

——

<ampl>

Consecutive Real Number

-1,000 dBm to 1,000 dBm

——

<connect>

Discrete

0|1

0

:CALCulate:LLINe<n>:COPY

Syntax

:CALCulate:LLINe<n>:COPY LLINE1|LLINE2|LLINE3|LLINE4|LLINE5|LLINE6

Description

Copies the selected limit line to the current limit line.

Parameter

Remarks

If the limit line to be copied that you select is the same as the current limit line, no operation should be
performed.

Example

The following command copies Limit Line 1 to Lim it Line 2.
:CALCulate:LLINe2:COPY LLINE1

:CALCulate:LLINe<n>:DATA

Syntax

:CALCulate:LL INe<n>:DATA <x>,<ampl>,<connect>{,<x>,<ampl>,<connect>}
:CALCulate:LLINe<n>:DATA?

Description

Edits one limit line, and marks it with n.
Queries the limit line data that you are editing currently.

Parameter

Remarks

<x>: indicates frequency.
<apml>: indicates the amplitude. By default, its unit is dBm. The same X value can be configured with at
most two amplitude values.
<connect>: can be configured with 0 or 1. When it is con fi gured with 1, it indicates that the current point
connects with the previous point to determine the limit line; when configured with 0, it indicates that the
current point is disconnected from the previous point. The <connect> value of the firs t point can be
configured with 0.

Return Format
Queries the returned limit line data that you are editing currently.

Example

The following command edits a limit line that contains three points, and marks it Limit Line 2.
:CALCulate:LLINe 2: DATA 50,100,0,100,150,1, 20 0, 20 0, 1

2-8 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

1

——

Bool

OFF|ON|0|1

OFF|0

The following query returns 50,100,0,100,150,1,200,200,1.
:CALCulate:LLINe2:DATA?

:CALCulate:LLINe<n>:DELete

Syntax

:CALCulate:LLINe<n>:DELete

Description

Deletes the selected limit line.

Parameter

Example

The following command deletes Limit Line 2.
:CALCulate:LLINe2:DELete

:CALCulate:LLINe<n>:DISPlay

Syntax

:CALCulate:LLINe<n>:DISPlay OFF|ON|0|1
:CALCulate:LLINe<n>:DISPlay?

Description

Turns on or off the selected limit line.
Queries the status of the selected limit line.

Parameter

Return Format

The query returns 0 or 1.
Example

The following command turns on Limit Line 2.
:CALCulate:LLINe2:DISPlay ON or :CALCulate:LLINe2:DISPlay 1

The following query returns 1.
:CALCulate:LLINe2:DISPlay?

RSA3000E Programming Guide 2-9

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:LLINe<n>:FAIL?

Syntax

:CALCulate:LLINe<n>:FAIL?
Description

Queries the measurement results of the selected limit line and its associated trace.

Parameter

Remarks

If you enable the test for the displayed trace and its corresponding limit line, and each displayed trace has
its corresponding limit line enabled , then you can run the comm and to query whether the trace t est passes.

Return Format
The query returns 0 (pass) or 1 (fail).

:CALCulate:LLINe<n>:FREQuency:CMODe:RELative

Syntax

:CALCulate:LLINe<n>:FREQuency:CMODe:RELative OFF|ON|0|1
:CALCulate:LLINe<n>:FREQuency:CMODe:RELative?

Description

Enables or disables the coupling functions between the selected limit line data points and the center
frequency.
Queries the status of the coupling functions between the selected limit line data points and the center
frequency.

Parameter

Remarks

OFF|0: disables the coupling function. That is, "Fixed" is selected under X to CF, and the frequency of the
current limit line editing point is not affected by the center frequency.
ON|1: enables the coupling function. That is, "Relative" is selected under X to CF, and the amplitude of the
current limit line editing point is the difference between th e current point with th e current center f requency.
At this time, if the center frequency changes, the position of the current editing point will move left and
right with it.

Return Format
The query returns 0 or 1.

Example
The following command disables the coupling functions between data points of Limit Line 2 and the center
frequency.
:CALCulate:LLINe2:FREQuency:C MODe:RELative OFF or :CALCulate:LLINe2:FREQuency:CMODe:RELative
0

The following query returns 0.
:CALCulate:LLINe2:FREQuency:CMODe:RELative?

2-10 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

<rel_ampl>

Consecutive Real Number

-40 dB to 0 dB

0 dB

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:LLINe<n>:MARGin

Syntax

:CALCulate:LL INe<n>:MARGin <r el _am p l>
:CALCulate:LLINe<n>:MARGin?

Description

Sets the margin for the selected limit line.
Queries the margin for the selected limit line.

Parameter

Return Format

The query returns the margin for the limit line in scientific notation.

Example

The following command sets the margin for Limit Line 2 to 1 dB.
:CALCulate:LLINe2:MARGin 1 dB

The following query returns 1.000000e+00.
:CALCulate:LLINe2:MARGin?

:CALCulate:LLINe<n>:MARGin:STATe

Syntax

:CALCulate:LL INe<n>:MAR G in:STATe OFF|ON|0|1
:CALCulate:LLINe<n>:MARGin:STATe?

Description

Enables or disables the margin for the selected limit line.
Queries the status of the margin for the selected limit line.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command turns on the margin for Limit Line 2.
:CALCulate:LLINe2:MARGin:STATe ON or :CALCulate:LLINe2:MARGin:S TATe 1

The following query returns 1.
:CALCulate:LLINe2:MARGin:STATe?

RSA3000E Programming Guide 2-11

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Discrete

1|2|3|4|5|6

Refer to "Remarks"

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6

——

——

Keyword

UPPer|LOWer

Refer to "Remarks"

:CALCulate:LLINe<n>:TRACe

Syntax

:CALCulate:LLINe<n>:TRACe 1|2|3|4|5|6
:CALCulate:LLINe<n>:TRACe?

Description

Sets the trace to be tested against the current limit line.
Queries the trace to be tested against the current limit line.

Parameter

Remarks

Limit Line 1 and 2: The default is Trace 1.
Limit Line 3 and 4: The default is Trace 2.
Limit Line 5 and 6: The default is Trace 3.

Return Format
The query returns 1, 2, 3, 4, 5, or 6.

Example

The following command sets that Trace 2 is tested against Limit Line 3.
:CALCulate:LLINe 3: TR AC e 2

The following query returns 2.
:CALCulate:LLINe3:TRACe?

:CALCulate:LLINe<n>:TYPE

Syntax

:CALCulate:LL INe<n>:TYPE UPPer|LOWer
:CALCulate:LLINe<n>:TYPE?

Description

Sets the type of the specified limit line.
Queries the type of the specified limit line.

Parameter

Remarks

Limit Line 1, Limit Line 3, and Limit Line 5 belong to the upper type; Limit Line 2, Limit Line 4, and Limit Line
6 belong to the lower type.

Return Format
The query returns UPP or LOW.

Example

The following command sets Limit Line 2 to the upper type.

2-12 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:LLINe2:TYPE UPPer
The following query returns UPP.

:CALCulate:LLINe2:TYPE?

:CALCulate:MARKer:AOFF

Syntax

:CALCulate:MARKer:AOFF

Description

Turns off all the enabled markers.

:CALCulate:MARKer:COUPle[:STATe]

Syntax

:CALCulate:MARKer:COUPle[:STATe] OFF|ON|0|1
:CALCulate:MARKer:COUPle[:STATe]?

Description

Enables or disables the couple marker function.
Queries the state of the couple marker function.

Parameter

Remarks

When you enable the couple marker function, moving any marker will make other markers (that are not
fixed or off) move along with it.

Return Format

The query returns 0 or 1.

Example

The following command disables the couple marker function.
:CALCulate:MARKer:COUPle:STATe OFF or :CALCulate:MARKer:COUPle:STATe 0

The following query returns 0.
:CALCulate:MARKer:COUPle:STATe?

:CALCulate:MARKer:PEAK:EXCursion

Syntax

:CALCulate:MARKer:PEAK:EXCursion <rel_ampl>
:CALCulate:MARKer:PEAK:EXCursion?

Description

Sets the peak offset. Its unit is dB.
Queries the peak offset.

RSA3000E Programming Guide 2-13

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<rel_ampl>

Consecutive Real Number

0 dB to 100 dB

6 dB

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

Name

Type

Range

Default

——

Keyword

PARameter|MAXimum

MAXimum

Parameter

Return Format

The query returns the peak offset in scientific notation.

Example

The following command sets the peak offset to 12 dB.
:CALCulate:MARKer:PEAK:EXCursion 12

The following query returns 1.200000e+01.
:CALCulate:MARKer:PEAK:EXCursion?

:CALCulate:MARKer:PEAK:EXCursion:STATe

Syntax

:CALCulate:MARKer:PEAK:EXCursion:STATe OFF|ON|0|1
:CALCulate:MARKer:PEAK:EXCursion:STATe?

Description

Enables or disables the peak offset function.
Queries the status of the peak offset function.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables the peak offset function.
:CALCulate:MARKer:PEAK:EXCursion:STATe ON or :CALCulate:MARKer:PEAK:EXCursion:STATe 1

The following query returns 1.
:CALCulate:MARKer:PEAK:EXCursion:STATe?

:CALCulate:MARKer:PEAK:SEARch:MODE

Syntax

:CALCulate:MARKer:PEAK:SEARch:MODE PARameter|MAXimum
:CALCulate:MARKer:PEAK:SEARch:MODE?

Description

Sets the peak search mode.
Queries the peak search mode.

Parameter

2-14 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Keyword

FREQuency|AMPLitude

AMPLitude

Remarks

 PARameter: ind icates parameter. If "parameter" is selected un der search mode, the system will search

for the peak of the specified parameter on the trace.

 MAXimum: indicates maximum. If "maximum" is selected under search mode, the system will search

for the maximum value on the trace.

The command is only v alid for the peak s earch executed b y sending the
command. Other items under the peak search menu such as Next Peak, Next Peak Right, Next Peak Left,
and Minimum Peak are all searched based on "parameter".

Return Format
The query returns PAR or MAX.

Example

The following command sets the peak search mode to "parameter".
:CALCulate:MARKer:PEAK:SEARch:MODE PARameter

The following query returns PAR.
:CALCulate:MARKer:PEAK:SEARch:MODE?

:CALCulate:MARKer<n>:MAXimum

:CALCulate:MARKer:PEAK:SORT
:TRACe:MATH:PEAK:SORT

Syntax

:CALCulate:MARKer:PEAK:SORT FREQuency|AMPLitude
:CALCulate:MARKer:PEAK:SORT?
:TRACe:MATH:PEAK:SORT FREQuency| AMPLitude
:TRACe:MATH:PEAK:SORT?

Description

Sets the sorting order of the data displayed in the peak table.
Queries the sorting order of the data displayed in the peak table.

Parameter

Remarks

FREQuency: lists the peaks in order of ascending frequency.
AMPLitude: lists the peaks in order of desce nding am p litude.

Return Format

The query returns FREQ or AMPL.

Example

The following command sets the data in the peak table to be sorted in descending amplitude.
:CALCulate:MARKer:PEAK:SORT AMPLitude
:TRACe:MATH:PEAK:SORT AMPLitude

The following query returns AMPL.
:CALCulate:MARKer:PEAK:SORT?
:TRACe:MATH:PEAK:SORT?

RSA3000E Programming Guide 2-15

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

ALL|GTDLine|LTDLine

NORMal|DLMore|DLLess

:CALCulate:MARKer:PEAK:TABLe:READout
:TRACe:MATH:PEAK:THReshold

Syntax

:CALCulate:MARKer:PEAK:TABLe:READout ALL|GTDLine|LTDLine
:CALCulate:MARKer:PEAK:TABLe:READout?
:TRACe:MATH:PEAK:THReshold NORMal|DLMore|DLLess
:TRACe:MATH:PEAK:THReshold?

Description

Sets the peak criteria that the displayed peak must meet.
Queries the peak criteria that the displayed peak must meet.

Parameter

—— Keyword

Remarks

ALL|NORMal: lists all the peaks defined by the peak criteria, and displays data based on the current sorting
order in the peak table.
GTDLine|DLMore: lists the peaks that are greater than the defined display line and that meet the peak
criteria.
LTDLine|DLLess: lists the peaks that are smaller than the defined display line and that meet the peak
criteria.

Return Format

The query returns ALL (NORM), GTDL (DLM), or LTDL (DLL).

Example

The following command lists all the peaks that are greater than the defined display line and that meet the
peak criteria.
:CALCulate:MARKer:PEAK:TABLe:READout GTDLine
:TRACe:MATH:PEAK:THReshold DLMore

The following query returns GTDL.
:CALCulate:MARKer:PEAK:TABLe:READout?
The following query returns DLM.
:TRACe:MATH:PEAK:THReshold?

ALL

:CALCulate:MARKer:PEAK:TABLe[:STATe]
:TRACe:MATH:PEAK:TABLe:STATe

Syntax

:CALCulate:MARKer:PEAK:TABLe[:STATe] OFF|ON|0|1
:CALCulate:MARKer:PEAK:TABLe[:STATe]?
:TRACe:MATH:PEAK:TABLe:STATe OFF|ON|0|1
:TRACe:MATH:PEAK:TABLe:STATe?

Description

Enables or disables the peak table.
Queries the status of the peak table.

2-16 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

<ampl>

Consecutive Real Number

-200 dBm to 0 dBm

-90 dBm

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables the peak table.
:CALCulate:MARKer:PEAK:TABLe:STATe ON or :CALCulate:MARKer:PEAK:TABLe:STATe 1
:TRACe:MATH:PEAK:TABLe:STATe ON or :TRACe:MATH:PEAK:TABLe:STATe 1

The following query returns 1.
:CALCulate:MARKer:PEAK:TABLe:STATe?
:TRACe:MATH:PEAK:TABLe:STATe?

:CALCulate:MARKer:PEAK:THReshold

Syntax

:CALCulate:MARKer:PEAK:THReshold <ampl>
:CALCulate:MARKer:PEAK:THReshold?

Description

Sets the peak threshold, and its default unit is dBm.
Queries the peak threshold.

Parameter

Return Format

The query returns the peak threshold i n scientific notation.

Example

The following command sets the peak threshold to -100 dB.
:CALCulate:MARKer:PEAK:THReshold -100

The following query returns -1.000000e+02.
:CALCulate:MARKer:PEAK:THReshold?

:CALCulate:MARKer:PEAK:THReshold:STATe

Syntax

:CALCulate:MARKer:PEAK:THReshold:STATe OFF|ON|0|1
:CALCulate:MARKer:PEAK:THReshold:STATe?

Description

Enables or disables the peak threshold function .
Queries the status of the peak threshold function.

RSA3000E Programming Guide 2-17

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables the peak threshold function.
:CALCulate:MARKer:PEAK:THReshold:STATe ON or :CALCulate:MARKer:PEAK:THReshold:STATe 1

The following query returns 1.
:CALCulate:MARKer:PEAK:THReshold:STATe?

:CALCulate:MARKer:TABLe[:STATe]

Syntax

:CALCulate:MARKer:TABLe[:STATe] OFF|ON|0|1
:CALCulate:MARKer:TABLe[:STATe]?

Description

Enables or disables the marker table.
Queries the status of the marker table.

Parameter

Return Format

The query returns 0 or 1.

Example

The fol lowing command disables the marker table.
:CALCulate:MARKer:TABLe:STATe OFF or :CALCulate:MARKer:TABLe:STATe 0

The following query returns 0.
:CALCulate:MARKer:TABLe:STATe?

:CALCulate:MARKer:TRCKing[:STATe]

Syntax

:CALCulate:MARKer:TRCKing[:STATe] OFF|ON|0|1
:CALCulate:MARKer:TRCKing[:STATe]?

Description

Enables or disables the signal track.
Queries the status of the signal track.

Parameter

2-18 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Bool

OFF|ON|0|1

OFF|0

Remarks

When the signal track is enabled, the instrument will execute a peak search after each sweep, and set the
frequency value at the current peak to the center frequency to keep the signal always displayed at the
center of the screen.
This command is only available for GPSA mode.

Return Format

The query returns 0 or 1.

Example

The following command enables the signal track.
:CALCulate:MARKer:TRCKing:STATe ON or :CALCulate:MARKer:TRCKing:STA Te 1

The following query returns 1.
:CALCulate:MARKer:TRCKing:STATe?

:CALCulate:MARKer<n>:CPSearch[:STATe]

Syntax

:CALCulate:MARKer<n>:CPSearch[:STATe] OFF|ON|0|1
:CALCulate:MARKer<n>:CPSearch[:STATe]?

Description

Enables or disables continuous peak search function, and ma r ks the peak value with n.
Queries the status of continuous peak search function.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command performs the cont inuous peak search function, and marks with Marker 1.
:CALCulate:MARKer1:CPSeatch:STATe ON or :CALCulate:MARKer1:CPSeatch:STATe 1

The following query returns 1.
:CALCulate:MARKer1:CPSeatch:STATe?

RSA3000E Programming Guide 2-19

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

<time>

Consecutive Real Number

1 μs to 500 ms

100 ms

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:MARKer<n>:FCOunt:GATetime

Syntax

:CALCulate:MARKer<n>:FCOunt:GATetime <time>
:CALCulate:MARKer<n>:FCOunt:GATetime?

Description

Sets the gate time for Marker n. The unit is s.
Queries the gate time for Marker n.

Parameter

Remarks

This command is only available for GPSA mode.

Return Format

The query returns the gate time for Marker n in scientific notation.

Example

The following command sets the gate time for Marker 2 to 10 ms.
:CALCulate:MARKer2:FCOunt:GATetime 0.01

The following query returns 1.000000e-02.
:CALCulate:MARKer2:FCOunt:GATetime?

:CALCulate:MARKer<n>:FCOunt:GATetime:AUTO

Syntax

:CALCulate:MARKer<n>:FCOunt:GATetime:AUTO OFF|ON|0|1
:CALCulate:MARKer<n>:FCOunt:GATetime:AUTO?

Description

Turns on or off the auto gate time for Marker n.
Queries the status of the auto gate time for Marker n.

Parameter

Remarks

This command is only available for GPSA mode.

Return Format

The query returns 1 or 0.

Example

The following command enables the auto gate time for Marker 2.
:CALCulate:MARKer2:FCOunt:GATetime:AUTO ON or :CALCulate:MARKer2:FCOunt:GATetime:AUTO 1
The following query returns 1.
:CALCulate:MARKer2:FCOunt:GATetime:AUTO?

2-20 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>:FCOunt[:STATe]

Syntax

:CALCulate:MARKer<n>:FCOunt[:STATe] OFF|ON|0|1
:CALCulate:MARKer<n>:FCOunt[:STATe]?

Description

Enables or disables the frequency counter function of the specified marker.
Queries the status of the frequency counter function of the specified marker.

Parameter

Remarks

This command is only available for GPSA mode.

Return Format

The query returns 0 or 1.

Example

The following command enables the frequency counter function of Marker 2.
:CALCulate:MARKer2:FCOunt:STATe ON or :CALCulate:MARKer2:FCOunt:STATe 1

The following query returns 1.
:CALCulate:MARKer2:FCOunt:STATe?

:CALCulate:MARKer<n>:FCOunt:X?

Syntax

:CALCulate:MARKer<n>:FCOunt:X?

Description

Queries the readout of the frequency counter of the specified marker.

Parameter

Remarks

This command is only available for GPSA mode.

Return Format

The query returns the readout in integer. Its unit is Hz.
When the frequency counter function is disa bled, the command returns NAN.

RSA3000E Programming Guide 2-21

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Keyword

NOISe|BPOWer|BDENsity|OFF

OFF

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

--

center frequency-bandwidth/2

sweep time/2-bandwidth/2 (zero span)

:CALCulate:MARKer<n>:FUNCtion

Syntax

:CALCulate:MARKer<n>:FUNCtion NOISe|BPOWer|BDENsity|OFF
:CALCulate:MARKer<n>:FUNCtion?

Description

Selects the special measurement type for the specified marker.
Queries the special measurement type of the specified marker.

Parameter

Remarks

NOISe: indicates the noise measurement.
BPOWer: indicates the bandwidth power.
BDENsity: indicates the bandwidth density.
OFF: disables the measurements.

Return Format

The query returns NOIS, BPOW, BDEN, or OFF.

Example

The following command sets the measurement type of Marker 1 to noise measurement.
:CALCulate:MARKer1:FUNCtion NOISe

The following query returns NOIS.
:CALCulate:MARKer1:FUNCtion?

:CALCulate:MARKer<n>:FUNCtion:BAND:LEFT

Syntax

:CALCulate:MAR Ker<n >: F U NCt io n :BAND:LEFT <fre q >
:CALCulate:MARKer<n>:FUNCtion:BAND:LEFT?

Description

Sets the left edge frequency or time of the signal involved in the calculation for the band function.
Queries the left edge frequency or time of the signal involved in the calculati on for the band function.

Parameter

<freq> Consecutive Real Number 0 to band right

Remarks

This command is only valid when the corresponding bandwidth function is enabled.
This command is used to set the lef t edge time when th e zero span is enabl ed in GPSA mod e or when in the
PvT view in RTSA mode.

Return Format

The query returns the left edge frequency or time of the signal in scientific notation.

2-22 RSA3000E Programming Guide

capture time/2-bandwidth/2 (PvT)

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

--

center frequency+bandwidth/2

sweep time/2+bandwidth/2 (zero span)

Example

The following comman d sets the lef t edge f requenc y of th e sign al in vol ved in the calc ulatio n fo r the Mar ker
1 band function to 2 M H z.
:CALCulate:MARKer1: FUNCtion:BAND:LE F T 20 00 00 0

The following query returns 2.000000000e+06.
:CALCulate:MARKer1:FUNCtion:BAND:LEFT?

:CALCulate:MARKer<n>:FUNCtion:BAND:RIGHt

Syntax

:CALCulate:MAR Ker<n >: F U NCt io n :BAND:RIGHt <fre q>
:CALCulate:MARKer<n>:FUNCtion:BAND:RIGHt?

Description

Sets the right edge frequency or time of the signal involved in the calculation for the band function.
Queries the right edge frequency or time of the signal involved in the calculation for the band function.

Parameter

<freq> Consecutive Real Number band left to +∞

Remarks

This command is only valid when the corresponding bandwidt h function is enabled.
This command is used to set the right edge time when the zero span is enabled in GPSA mode or when in
the PvT view in RTSA mode.

Return Format

The query returns the right edge frequency or time of the signal in scientific notation.

capture time/2+bandwidth/2 (PvT)

Example

The following command sets the right edge frequency of the signal involved in the calculation for the
Marker 1 band function to 4 GHz.
:CALCulate:MARKer1: F UNCtion:BAND:RIGHt 400000 0000

The following query returns 4.000000000e+09.
:CALCulate:MARKer1:FUNCtion:BAND:RIGHt?

RSA3000E Programming Guide 2-23

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

--

span/2

sweep time/20 (zero span)

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

--

--

Bool

OFF|ON|0|1

ON|1

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN

Syntax

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN <freq>
:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN?

Description

Sets the bandwidth or the time span of the signal involved in the calculation for the band function.
Queries the bandwidth or the time span of the signal involved in the cal culation for the band function.

Parameter

<freq> Consecutive Real Number 0 to +∞

Remarks

This command is only valid when the corresponding bandwidth function is enabled.
This command is used to set the signal time when the zero span is enabl ed in GPSA mode or when in the
PvT view in RTSA mode.

Return Format

The query returns the bandwidth of the signal involved in the calculation for the band function in scientific
notation.

capture time/20 (PvT)

Example

The following command sets the bandwidth of the signal involved in the calculation for the Marker 1 band
function to 500 MHz.
:CALCulate:MARKer1: F UNCtion:BAND:SPAN 500000000

The following query returns 5.000000000e+08.
:CALCulate:MARKer1:FUNCtion:BAND:SPAN?

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN:AUTO

Syntax

:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN:AUTO OFF|ON|0|1
:CALCulate:MARKer<n>:FUNCtion:BAND:SPAN:AUTO?

Description

Enables or disables the band span auto function.
Queries the status of band span auto function.

Parameter

Remarks

This command is only valid when the corresponding bandwidth function is enabled.

2-24 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF

Return Format

The query returns 1 or 0.

Example

The following command enables the band span auto function of Marker 1.
:CALCulate:MARKer1:FUNCtion:BAND:SPAN:AUTO ON
or :CALCulate:MARKer1:FUNCtion:BAND:SPAN:AUTO 1

The following query returns 1.
:CALCulate:MARKer1:FUNCtion:BAND:SPAN:AUTO?

:CALCulate:MARKer<n>:LINes[:STATe]

Syntax

:CALCulate:MARKer<n>:LINes[:STATe] OFF|ON|0|1
:CALCulate:MARKer<n>:LINes[:STATe]?

Description

Enables or disables the marker line of the specified marker.
Queries the status for the marker line of the specified marker.

Parameter

<n> Discrete 1|2|3|4|5|6|7|8 ——

Remarks

If the marker is not visible in the selec ted area, enable the mark er line function to extend th e marker line to
the display area for better observation.
The PvT only supports setting the marker on Trace 1.

Return Format

The query returns 0 or 1.

Example

The following command enables the marker line of Marker 1.
:CALCulate:MARKer1: LINes:STATe ON or :CALCulate:MARKer1:LINes:STATe 1

The following query returns 1.
:CALCulate:MARKer1:LINes:STATe?

:CALCulate:MARKer<n>:MAXimum:LEFT

Syntax

:CALCulate:MARKer<n>:MAXimum:LEFT

Description

Searches for and marks the nearest peak which is loc ated at the left side of the current peak and meets the
peak search condition.

RSA3000E Programming Guide 2-25

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Parameter

Remarks

When no peak is found, a prompt message "No peak found" is displayed on the screen.
Example

The following command performs one left peak search, and marks with Marker 2.
:CALCulate:MARKer2:MAXimum:LEFT

:CALCulate:MARKer<n>:MAXimum[:MAX]

Syntax

:CALCulate:MARKer<n>:MAXimum[:MAX]

Description

Performs one peak search based on the search mode set by the :CALCulate:MARKer:PEAK:SEARch:MODE
command and marks it with the specified marker.

Parameter

Remarks

When no peak is found, a prompt message "No peak found" is displayed on the screen.
Example

The following command performs one peak search, and marks with Marker 2.
:CALCulate:MARKer2:MAXimum:MAX

:CALCulate:MARKer<n>:MAXimum:NEXT

Syntax

:CALCulate:MARKer<n>:MAXimum:NEXT

Description

Searches for and marks the peak whose amplitude on the trace is next to that of the current peak and
which meets the peak search condition.

Parameter

Remarks

When no peak is found, a prompt message "No peak found" is displayed on the screen.
Example

The following command performs one next peak search, and marks with Marker 2.
:CALCulate:MARKer2:MAXimum:NEXT

2-26 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>:MAXimum:RIGHt

Syntax

:CALCulate:MARKer<n>:MAXimum:RIGHt

Description

Searches for and marks the nearest peak which is located at the right side of the current peak and meets
the peak search condition.

Parameter

Remarks

When no peak is found, a prompt message "No peak found" is displayed on the screen.
Example

The following command performs one right peak search, and marks with Marker 2.
:CALCulate:MARKer2:MAXimum:RIGHt

:CALCulate:MARKer<n>:MINimum

Syntax

:CALCulate:MARKer<n>:MINimum

Description

Searches for and marks the peak wit h the minimum amplitude on the trace.

Parameter

Remarks

When no peak is found, a prompt message "No peak found" is displayed on the screen.
Example

The following command performs one minimum search, and marks it with Marker 2.
:CALCulate:MARKer2:MINimum

RSA3000E Programming Guide 2-27

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Keyword

POSition|DELTa|FIXed|OFF

OFF

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>:MODE

Syntax

:CALCulate:MARKer<n>:MODE POSition|DELTa|FIXed|OFF
:CALCulate:MARKer<n>:MODE?

Description

Sets the type of the specified marker.
Queries the type of the specified marker.

Parameter

Remarks

POSition: indicates the normal marker.
DELTa: indicates difference between two data points.
FIXed: indicates that the marker is fixed.
OFF: turns off the se lected marker.
The PvT only supports setting the marker on Trace 1.

Return Format

The query returns POS, DELT, FIX, or OFF.

Example

The following command sets the type o f Marker 1 to Position.
:CALCulate:MARKer1:MODE POSition

The following query returns POS.
:CALCulate:MARKer1:MODE?

:CALCulate:MARKer<n>:PTPeak

Syntax

:CALCulate:MARKer<n>:PTPeak

Description

Performs the peak-peak search and marks it with a specified marker.

Parameter

Remarks

After the command is executed, the marker mode of the specified mark er selects "Delta" automatic ally . The
peak search results will be marked b y the reference marker (by default, the next marker), and the minimum
search will be marked by the Delta marker.

Example

The following command performs the peak-peak search, and marks the peak-peak position with the
reference marker (Marker 2) and the Delta marker (Marker 1), respectively.
:CALCulate:MARKer1:PTPeak

2-28 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

By default, the marker

reference marker.

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>:REFerence

Syntax

:CALCulate:MARKer<n>:REFerence <integer>
:CALCulate:MARKer<n>:REFerence?

Description

Sets the reference marker for the specified marker.
Queries the reference marker for the specified marker.

Parameter

<integer> Integer 1 to 8

Remarks

Each marker can have another marker to be its reference marker.
It the current marker is a Delta marker, the measurement result of the marker will be determined by the
reference marker.
Any marker cannot have itself to be the reference marker.
The PvT only supports setting the marker on Trace 1.

Example

The following command sets the reference marker for Marker 1 to 2.
:CALCulate:MARKer1:REFerence 2

The following query returns 2.
:CALCulate:MARKer1:REFerence?

following the specifi ed marker

is considered to be the

:CALCulate:MARKer<n>[:SET]:CENTer

Syntax

:CALCulate:MARKer<n>[:SET]:CENTer

Description

Sets the frequency of the specified marker to the center frequency of the analyzer.

Parameter

Remarks

If the marker mode of the specified marker is Position or Fixed, the center frequency will be set to the
frequency of the marker.
If the specified mark er mode is Del ta, the cent er freque ncy wil l be set to the f requen cy of the D elta marker.
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example

The following command sets the frequency at Marker 1 (Position) to the center frequency.
:CALCulate:MARKer1:SET:CENTer

RSA3000E Programming Guide 2-29

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>[:SET]:DELTa:CENTer

Syntax

:CALCulate:MARKer<n>[:SET]:DELTa:CENTer

Description

Sets the frequency difference of the specified Delta marker to the center frequency of the analyzer.

Parameter

Remarks

It is only valid when the current marker mode is "Delta".
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example
The following command sets th e f requ ency difference of the Delta Marker 1 to the center fr equ ency of the
analyzer.
:CALCulate:MARKer1:SET:DELTa:CENTer

:CALCulate:MARKer<n>[:SET]:DELTa:SPAN

Syntax

:CALCulate:MARKer<n>[:SET]:DELTa:SPAN

Description

Sets the frequency difference of the specified Delta marker to the span of the analyzer.

Parameter

Remarks

It is only valid when the current marker mode is "Delta".
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example
The following command sets the frequency difference of the Delta Marker 1 to the span of the analyzer.
:CALCulate:MARKer1:SET:DELTa:SPAN

2-30 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>[:SET]:RLEVel

Syntax

:CALCulate:MARKer<n>[:SET]:RLEVel

Description

Sets the amplitude of the specified marker to the reference level of the analyzer.

Parameter

Remarks

If the marker mode of the specified marker is Position or Fixed, the reference level will be set to the
amplitude of the marker.
If the specified marker mode is Delta and the current marker is the reference marker, then the reference
level is set to the amplitude of the reference marker; if the current marker is the Delta marker, then the
reference level is set to the amplitude of the Delta marker.

Example
The following command sets the amplitude of Marker 2 (Position) to the reference level of the analyzer.
:CALCulate:MARKer2:SET:RLEVel

:CALCulate:MARKer<n>[:SET]:STARt

Syntax

:CALCulate:MARKer<n>[:SET]:STARt

Description

Sets the frequency of the specified marker to the start frequency of the analyzer.

Parameter

Remarks

If the marker mode of the specified marker is Position or Fixed, the start frequency will be set to the
frequency of the marker.
If the specified marker mode is Delta, the start frequency will be set to the frequency of the Delta marker.
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example

The following command sets the frequency of Marker 3 (Position) to the start frequency of the analyzer.
:CALCulate:MARKer3:SET:STARt

RSA3000E Programming Guide 2-31

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>[:SET]:STEP

Syntax

:CALCulate:MARKer<n>[:SET]:STEP

Description

Sets the frequency of the specified marker to the center frequency step of the analyzer.

Parameter

Remarks

If the marker mode of the speci fied mark er is P o sition or Fi xed , the center frequ ency step will be set to th e
frequency of the marker.
If the specified marker mode is Delta, the center frequency step will be set to the frequency difference
between the Delta marker and the reference marker.
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example

The following command sets the frequency of Marker 4 (Position) to the center frequency step of the
analyzer.
:CALCulate:MARKer4:SET:STEP

:CALCulate:MARKer<n>[:SET]:STOP

Syntax

:CALCulate:MARKer<n>[:SET]:STOP

Description

Sets the frequency of the specified marker to the stop frequency of the analyzer.

Parameter

Remarks

If the marker mode of the specified marker is Position or Fixed, the stop frequency will be set to the
frequency of the marker.
If the specified marker mode is Delta, the stop frequency will be set to the frequency of the Delta marker.
This function is invalid in zero span.
This command is invalid for the PvT measurement mode in RTSA.

Example

The following command sets the frequency of Marker 2 (Position) to the stop frequency of the analyzer.
:CALCulate:MARKer2:SET:STOP

2-32 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

:CALCulate:MARKer<n>:STATe

Syntax

:CALCulate:MARKer<n>:STATe OFF|ON|0|1
:CALCulate:MARKer<n>:STATe?

Description

Enables or disables the specified marker.
Queries the status for the specified marker.

Parameter

Remarks

If the specified marker is disabled currently, by default, the marker mode is "Position" when you send the
command to enable the marker.
The PvT only supports setting the marker on Trace 1.

Return Format

The query returns 0 or 1.

Example

The following command enables Marker 1.
:CALCulate:MARKer1:STATe ON or :CALCulate:MARKer1:STATe 1

The following query returns 1.
:CALCulate:MARKer1:STATe?

:CALCulate:MARKer<n>:TRACe

Syntax

:CALCulate:MARKer<n>:TRACe <integer>
:CALCulate:MARKer<n>:TRACe?

Description

Sets the marker trace for the specified marker.
Queries the marker trace for the specified marker.

Parameter

<integer> Discrete

Remarks

<integer> indicates the marker tr ac e, and i ts r ange is from Trace 1 to Trace 6. The selected trace must be
enabled.
You can also run the
specified marker to "Auto".
The PvT does not support this command.

RSA3000E Programming Guide 2-33

:CALCulate:MARKer<n>:TRACe:AUTO command to set the marker trace of the

1|2|3|4|5|6

1

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

——

Bool

OFF|ON|0|1

ON|1

Return Format

The query returns a ny integer from 1 to 6.
If the marker trace is set to "Auto", the query command returns a trace number on which the marker is
placed.

Example

The following command sets the marker trace of Marker 1 to Trace 2.
:CALCulate:MARKer1:TRACe 2

The following query returns 2.
:CALCulate:MARKer1:TRACe?

:CALCulate:MARKer<n>:TRACe:AUTO

Syntax

:CALCulate:MARKer<n>:TRACe:AUTO OFF|ON|0|1
:CALCulate:MARKer<n>:TRACe:AUTO?

Description

Enables or disables the auto trace marking of the specified marker.
Queries the status of the auto trace marking of the specified marker.

Parameter

Remarks

When you disable the auto marking of the trace, the currently enabled marker will stay on the
corresponding trace.
The PvT does not support this command.

Return Format

The query returns 0 or 1.

Example

The following command sets the marker trace of Marker 1 to Auto.
:CALCulate:MARKer1:TRACe:AUTO ON or :CALCulate:MARKer1:TRACe:AUTO 1

The following query returns 1.
:CALCulate:MARKer1:TRACe:AUTO?

2-34 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

<param>

Consecutive Real Number

Refer to "Remarks"

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

Remarks

:CALCulate:MARKer<n>:X

Syntax

:CALCulate:MAR Ker<n >: X <pa ra m>
:CALCulate:MARKer<n>:X?

Description

Sets the X-axis value of the specified marker. Its default unit is Hz.
Queries the X-axis value of the specified marker.

Parameter

Remarks

If the readout mode is frequency, it cannot exceed the frequency range of the sweep and th e units available
are Hz (default), kHz, MHz, and GHz.
If the readout mode is time, it cannot exceed the time range of the sweep and the units available are s
(default), μs, ms, and ks.
<param> can be any value within the available range of the current X axis.
If the marker mode of the specified marker is Position or Fixed, this command sets the X value of the
marker.
If the specified marker mode is Delta, this command sets the X value of the delta marker relative to the
reference marker.
The PvT only supports setting the marker on Trace 1.

Return Format

The query returns the X-axis value of the marker in scientific notation.

Example

The following command sets the X-axis value of Marker 1 to 150 MHz (the readout mode is frequency).
:CALCulate:MARKer1: X 150000000

The following query returns 1.500000000e+08.
:CALCulate:MARKer1:X?

:CALCulate:MARKer<n>:X:READout

Syntax

:CALCulate:MARKer<n>:X:READout FREQuency|TIME|ITIMe|PERiod
:CALCulate:MARKer<n>:X:READout?

Description

Sets the readout mode of the X axis of the specified marker.
Queries the readout mode of the X axis of the specified marker.

Parameter

—— Keyword FREQuency|TIME|ITIMe|PERiod Refer to "

RSA3000E Programming Guide 2-35

"

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

Remarks

FREQuency: indicates frequency. It is the default readout mode in non-zero span mode.
TIME: indicates time. It is the default readout mode in zero span mode.
ITIMe: indicates the reciprocal of time. It is available only in zero span mode and a Delta marker is selected.
PERiod: indicates period. It is not available in zero span mode.
The PvT does not support this command.

Return Format

The query returns FREQ, TIME, ITIM, or PER.

Example

The following command sets the readout mode of the X axis of Marker 1 to "Time".
:CALCulate:MARKer1:X:READout TIME

The following query returns TIME.
:CALCulate:MARKer1:X:READout?

:CALCulate:MARKer<n>:X:READout:AUTO

Syntax

:CALCulate:MARKer<n>:X:READout:AUTO OFF|ON|0|1
:CALCulate:MARKer<n>:X:READout:AUTO?

Description

Enables or disables the auto readout mode of the specified marker.
Queries the auto readout mode of the specified marker.

Parameter

<n> Discrete 1|2|3|4|5|6|7|8 ——

Remarks

When the auto readout mode is enabled, if the marker trace changes, the readout mode will be
re-determined based on the destination trace.
The PvT does not support this command.

Return Format

The query returns 0 or 1.

Example

The following command enables the auto readout mode of Marker 1 in the X-axis.
:CALCulate:MARKer1:X:READout:AUTO ON or :CALCulate:MARKer1:X:READout:AUTO 1

The following query r eturns 1.
:CALCulate:MARKer1:X:READout:AUTO?

2-36 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

——

<amp>

Consecutive Real Number

-170 dBm to 30 dBm

——

Name

Type

Range

Default

<n>

Discrete

1|2|3|4|5|6|7|8

<integer>

Integer

1 to 8192

1

:CALCulate:MARKer<n>:Y

Syntax

:CALCulate:MARKer<n>:Y <amp>
:CALCulate:MARKer<n>:Y?

Description

Sets the Y-axis value of the specified fixed marker.
Queries the Y-axis value of the specified marker, and its default unit is dBm.

Parameter

Remarks

This setting command is only available when there is only one marker and it is a fixed marker.
If the marker mode of t he s pec if ied mark er is Pos itio n or Fix ed, th e qu ery co mmand qu eri es th e Y v alu e o f

the marker
If the marker mode of the specified marker is Delta, the query command queries the Y-axis difference
between the reference marker and the Delta marker.
The PvT only supports setting the marker on Trace 1.

Return Format

The query returns the Y-axis value in scientific notation .

Example

The following command sets the Y-axis value of Marker 1 is -59.6 dBm.
:CALCulate:MARKer1:Y -59.6

The following query returns -5.960000000e+01.
:CALCulate:MARKer1:Y?

.

:CALCulate:MARKer<n>:Z:POSition

Syntax

:CALCulate:MARKer<n>:Z:POSition <integer>
:CALCulate:MARKer<n>:Z:POSition?

Description

Sets the trace number of the trace where the marker stays in the Spectrogram view.
Queries the trace number of the trace where the marker stays in the Spectrogram view.

Parameter

Remarks

Only when you sel ect t he Spec tro gr am view of the Spectrogram, Density Spectrogram or PvT Spectrogram
in RTSA mode, can this command be effective.

Return Format

The query returns the trace number in integer.

RSA3000E Programming Guide 2-37

——

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

TRACE1|TRACE2|TRACE3|TRACE4|TRACE

5|TRACE6

PDIFference|PSUM|LOFFset|LMOFFset|LD

IFference|OFF

TRACE1|TRACE2|TRACE3|TRACE4|TRACE

5|TRACE6

TRACE1|TRACE2|TRACE3|TRACE4|TRACE

5|TRACE6

Consecutive Real

Number

Consecutive Real

Number

Example

The following command sets the trace number of the trace where the marker1 stays in to 100.
:CALCulate:MARKer1:Z:POSition 100

The following query returns 100.
:CALCulate:MARKer1:Z:POSition?

:CALCulate:MATH

Syntax

:CALCulate:MATH
<trace_destination>,<function_math>,<trace1_operation>,<trace2_operation>,<rel_offset>,<rel_refer
ence>
:CALCulate:MATH? TRACE1|TRACE2|TRACE3|TRACE4|TRACE5|TRACE6

Description
Sets mathematical operations between traces and, in some cases, user-defined offsets.
Queries the math operation function of the specified trace.

Parameter

<trace_destination> Keyword

<function_math> Keyword

<trace1_operation> Keyword

<trace2_operation> Keyword

<rel_offset>

<rel_reference>

Remarks

PDIFference: indicates the power difference between Operand 1 and Operand 2.
PSUM: indicates the power sum between Operand 1 and Operand 2.
LOFFset: indicates the sum between Operand 1 and the offset parameter <rel_offset>.
LMOFFset: indicates the difference between Operand 1 and the offset parameter <rel_offset>.
LDIFference: indicates that Operand 1 (Op1) minus Operand 2 (Op2), and t hen plus the reference
parameter value <rel_reference>.
OFF: disables the operation function.
<rel_offset> indicates the log offset, and its unit is dB; <rel_reference> indicates the log reference, and its
unit is dBm.
For certain oper ation, if some par ameters are irr elev ant in the oper ation, y ou can replace these par ameters
with ",," in the command. The returned parameters are s epar ated b y commas. The retur ned results of the
irrelevant parameters are undefined. The empty fields are replaced by ",,".

Return Format

The query returns the operation function of the specified trace, namely , PDIF, PSUM, LOFF, LMOFF, LDIF, or
OFF.

Example

The following command sets Trace 1 to the power difference math operation, an d sets Operand Trace 1 to
Trace 4 and Operand Trace 2 to Trace 5.

-100 dB to 100 dB 0 dB

-170 dBm to 30 dBm 0 dBm

——

OFF

TRACE5

TRACE6

2-38 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

:CALCulate:MATH TRACE1,PDIFference,TRACE4,TRACE5,,
The following query returns PDIFference.

:CALCulate:MATH? TRACE1

:CALCulate:NTData[:STATe]

Syntax

:CALCulate:NTData[:STATe] OFF|ON|0|1
:CALCulate:NTData[:STATe]?

Description

Enables or disables the normalize function.
Queries the status of normalization.

Parameter

Remarks

This command is only available for RSA3030E-TG/RSA3015E-TG working in GPSA mode.
This command is only valid when the tracking generator function is enabled.

Return Format

The query returns 0 or 1.

Example

The following command enables normalization.
:CALCulate:NTData:STATe ON or :CALCulate:NTDa ta:STATe 1

The following query returns 1.
:CALCulate:NTData:STATe?

RSA3000E Programming Guide 2-39

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

:CALibration Commands

Command List:

 :CALibration:[ALL]
 :CALibration:AUTO

:CALibration:[ALL]

Syntax

:CALibration:[ALL]

Description

Executes self-calibration immediately.

Remarks

If the self-calibration succeeded, the co mmand :CALibration:[ALL]? ret urns 0; if failed, the
command :CALibration:[ALL]? returns 1.

Example

The following command executes the self-calibration immediately.
:CALibration:ALL

:CALibration:AUTO

Syntax

:CALibration:AUTO OFF|ON|0|1
:CALibration:AUTO?

Description

Enables or disables auto calibration.
Query the setting status of auto calibration.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables auto calibration.
:CALibration:AUTO ON or :CALibration:AUTO 1

The following query returns 1.
:CALibration:AUTO?

2-40 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:CONFigure Commands

Command List:

 :CONFigure
 :CONFigure:ACPower*
 :CONFigure:CNRatio*
 :CONFigure:DENSity
 :CONFigure:DSPEctrogram

?

 :CONFigure:EBWidth
 :CONFigure:HDISt*
 :CONFigure:LPSTep
 :CONFigure:MCHPower
 :CONFigure:NORMal
 :CONFigure:OBWidth
 :CONFigure:PSGRam
 :CONFigure:PSPectrum
 :CONFigure:PVT
 :CONFigure:SANalyzer
 :CONFigure:SPECtrogram
 :CONFigure:TOI
 :CONFigure:TPOWer*

Remarks:

The commands with * are only available for the RSA3000E series that has been installed with advanced
measurement kit option.

*

*

*

*

:CONFigure?

Syntax

:CONFigure?

Description

Queries the current measurement function.

Return Format

The query returns SAN, TPOW, ACP, MCHP, OBW, EBW, CNR, HARM, TOI, NORM, DENS, SPEC, DSPE, P VT,
PSP, or PSGR. The explanations for the return results are as follows: SAN (swept SA), TPOW (time-domain
power), ACP (adjacent power), MCHP (multi-channel power), OBW (occupied bandwidth), EBW (emission
bandwidth), CNR (carrier/noise ratio), HARM (harmonics distortion), TO I (third-order intercept), NORM
(Normal), DENS (Density), SPEC (Spectrogram), DSPE (Density Spectrogram), PVT (power versus time),
PSP (PvT Spectrum), PSGR (PvT Spectrogram).

RSA3000E Programming Guide 2-41

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:CONFigure:ACPower

Syntax

:CONFigure:ACPower

Description

Sets the analyzer to be in the ACP measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:CNRatio

Syntax

:CONFigure:CNRatio

Description

Sets the analyzer to be in the CNR measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:DENSity

Syntax

:CONFigure:DENSity
Description

Sets the analyzer to be in the Density measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.

2-42 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:CONFigure:DSPEctrogram

Syntax

:CONFigure:DSPEctrogram
Description

Sets the analyzer to be in the Density Spectr ogram measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.

:CONFigure:EBWidth

Syntax

:CONFigure:EBWidth

Description

Sets the analyzer to be in the EBW measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:HDISt

Syntax

:CONFigure:HDISt

Description

Sets the analyzer to be in the harmonic distortion measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:LPSTep

Syntax

:CONFigure:LPSTep

Description

Resets all the parameters in the current measurement mode.

RSA3000E Programming Guide 2-43

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:CONFigure:MCHPower

Syntax

:CONFigure:MCHPower

Description

Sets the analyzer to be in the MCHP measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.
After changing any measurement s etup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:NORMal

Syntax

:CONFigure:NORMal
Description

Sets the analyzer to be in the Normal measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.

:CONFigure:OBWidth

Syntax

:CONFigure:OBWidth

Description

Sets the analyzer to be in the OBW measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

2-44 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:CONFigure:PSGRam

Syntax

:CONFigure:PSGRam
Description

Sets the analyzer to be in the PvT Spectrogram measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.

:CONFigure:PSPectrum

Syntax

:CONFigure:PSPectrum
Description

Sets the analyzer to be in the PvT Spectrum measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discon tinue the current measurement and resto re the specified measurement of
the instrument to the default factory state.

:CONFigure:PVT

Syntax

:CONFigure:PVT
Description

Sets the analyzer to be in the PvT measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.

:CONFigure:SANalyzer

Syntax

:CONFigure:SANalyzer

Description

This command is only available for GPSA mode.
This command will disable the currently ac tivated measurement function , and set the analyzer to the swept
SA mode.

RSA3000E Programming Guide 2-45

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:CONFigure:SPECtrogram

Syntax

:CONFigure:SPECtrogram
Description

Sets the analyzer to be in the Spectrogram measurement state.

Remarks

This command is only available for RTSA mode.
Running this command will discontinu e the current measurement and restore th e specified measurement of
the instrument to the default factory state.

:CONFigure:TOI

Syntax

:CONFigure:TOI

Description

Sets the analyzer to be in the TOI measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

:CONFigure:TPOWer

Syntax

:CONFigure:TPOWer

Description

Sets the analyzer to be in the time-domain power measurement state.

Remarks

This command is only available for GPSA mode.
Running this command will discontinue the current measurement and restore the specified measurement of
the instrument to the default factory state.
After changing any measurement setup, running the
you do not have to set the measurement to the default.

:READ Commands will initialize the measurement, and

2-46 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:COUPle Commands

Command List:

 :COUPle

:COUPle

Syntax

:COUPle ALL

Description

Sets all the manual/auto settings in the current measurement mode to "Auto".

RSA3000E Programming Guide 2-47

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:DISPlay Commands

Command List:

 :DISPlay:BACKlight
 :DISPlay:ENABle
 :DISPlay:GRATicule[:STATe]
 :DISPlay:HDMI[:STATe]
 :DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:COUPle
 :DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:PDIVision
 :DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RLEVel
 :DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RPOSition
 :DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:PDIVision
 :DISPlay:PVTime:WINDow: TR AC e:Y [: SCA Le] :RLE Vel <rea l>
 :DISPlay:VIEW:DENSity:AADJust
 :DISPlay:VIEW:DENSity:CNONlinear
 :DISPlay:VIEW:DENSity:CPALettes
 :DISPlay:VIEW:DENSity:HDHue
 :DISPlay:VIEW:DENSity:LDHue
 :DISPlay:VIEW:DENSity:PERSistence
 :DISPlay:VIEW:DENSity:PERSistence:INFinite
 :DISPlay:VIEW[:SELect]
 :DISPlay:VIEW:SPECtrogram:AADJust
 :DISPlay:VIEW:SPECtrogram:BOTTom
 :DISPlay:VIEW:SPECtrogram:HUE
 :DISPlay:VIEW:SPECtrogram:POSition
 :DISPlay:VIEW:SPECtrogram:REFerence
 :DISPlay:VIEW:SPECtrogram:TRACe:COUPle
 :DISPlay:VIEW:SPECtrogram:TRACe:SELection
 :DISPlay:WINDow:SELect
 :DISPlay:WINDow:TRACe:Y:DLINe
 :DISPlay:WINDow:TRACe:Y:DLINe:STATe
 :DISPlay:WINDow:TRACe:Y[:SCALe]:NRLevel

*

 :DISPlay:WINDow:TRACe:Y[:SCALe]:NRPosition*
 :DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision
 :DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel
 :DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet
 :DISPlay:WINDow:TRACe:Y[:SCALe]:SPACing

Remarks:

The commands with * are only available for RSA3030E-TG/RSA3015E-TG.

2-48 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<integer>

Integer

1 to 100

100

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

:DISPlay:BACKlight

Syntax

:DISPlay:BACKlight <integer>
:DISPlay:BACKlight?

Description

Sets the brightnes s of the backlight of LCD.
Queries the brightness of the backlight of LCD.

Parameter

Return Format

The query returns the brightness of the LCD backlight i n i nteger.

Example

The following command sets the brightness of the LCD backlight to 50.
:DISPlay:BACKlight 50

The following query returns 50.
:DISPlay:BACKlight?

:DISPlay:ENABle

Syntax

:DISPlay:ENABle OFF|ON|0|1
:DISPlay:ENABle?

Description

Turns on or off the LCD.
Queries the status of the LCD.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables the LCD.
:DISPlay:ENABle ON or :DISPlay:ENABle 1

The following query returns 1.
:DISPlay:ENABle?

RSA3000E Programming Guide 2-49

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

ON|1

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

:DISPlay:GRATicule[:STATe]

Syntax

:DISPlay:GRATicule[:STATe] OFF|ON|0|1
:DISPlay:GRATicule[:STATe]?

Description

Enables or disables the display of the graticule.
Queries the display of the graticule.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables display of the graticule.
:DISPlay:GRATicule:STATe ON or :DISPlay:GRATicule:STATe 1

The following query returns 1.
:DISPlay:GRATicule:STATe?

:DISPlay:HDMI[:STATe]

Syntax

:DISPlay:HDMI[:STATe] OFF|ON|0|1
:DISPlay:HDMI[:STATe]?

Description

Enables or disables HDMI.
Queries the status of HDMI.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables HDMI.
:DISPlay:HDMI:STATe ON or :DISPlay:HDMI:STATe 1

The following query returns 1.
:DISPlay:HDMI:STATe?

2-50 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

--

Bool

OFF|ON|0|1

ON|1

Name

Type

Range

Default

acquisition

time/10

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:COUPle

Syntax

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:COUPle OFF|ON|0|1
:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:COUPle?

Description

Enables or disables the auto scale function for the horizontal axis in the PvT view.
Queries the status of the auto scale function for the horizonta l axis in the PvT view.

Parameter

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

Return Format

The query returns 1 or 0.

Example

The following command enables the auto scale function for the horizontal axis in the PvT view.
:DISPlay:PVTime:WINDow:TRA Ce:X:SCALe:COUPle ON
or :DISPlay:PVTime:WINDow:TRACe:X:SCALe:COUPle 1

The following query returns 1.
:DISPlay:PVTime:WINDow:TRACe:X:SCALe:COUPle?

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:PDIVision

Syntax

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:PDIVision <time>
:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:PDIVision?

Description

Sets the unit per division in the horizontal axis of the PvT view.
Queries the unit per division in the horizontal axis of t he PvT view.

Parameter

<time> Consecutive Real Number 20 μs to 4 s

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

Return Format

The query returns the X-axis scale value in scientific notation.

Example

The following command sets the horizontal scale in the PvT view to 40 μs.
:DISPlay:PVTime : WIN Do w: TR AC e:X :SCALe:PDIVision 0. 000 04

RSA3000E Programming Guide 2-51

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<real>

Consecutive Real Number

-1 s to 40 s

0 μs

Name

Type

Range

Default

--

Keyword

LEFT|CENTer|RIGHt

LEFT

The following query returns 4.000000000e-07.
:DISPlay:PVTime:WINDow:TRACe:X:SCALe:PDIVision?

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RLEVel

Syntax

:DISPlay:PVTime:WINDow:TRA Ce:X[:SCALe]:RLEVel <real>
:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RLEVel?

Description

Sets the reference time for the horizontal axis in the PvT view.
Queries the reference time for the horizontal axis in the PvT vi ew.

Parameter

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

Return Format

The query returns the reference time for the horizonta l axis in scientific notation.

Example

The following command sets the reference time for the horizontal axis in the PvT view to 2 s.
:DISPlay:PVTime:WINDow:TRA Ce:X:SCALe:RLEVel 2

The following query returns 2.000000000e+00.
:DISPlay:PVTime:WINDow:TRACe:X:SCALe:RLEVel?

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RPOSition

Syntax

:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RPOSition LEFT|CENTer|RIGHt
:DISPlay:PVTime:WINDow:TRACe:X[:SCALe]:RPOSition?

Description

Sets the position of the reference time in the horizontal axis of the PvT view.
Queries the position of the reference time in the horizontal axis of the PvT view.

Parameter

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

Return Format

The query returns LEFT, CENT, or RIGH.

Example

The following command sets the position of the reference time in the horizontal axis of the PvT view to

2-52 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<time>

Consecutive Real Number

0.1 dB to 20 dB

10 dB

Name

Type

Range

Default

<n>

Discrete

1|2|3

1

<real>

Consecutive Real Number

-250 dBm to 250 dB m

0 dBm

"Left".
:DISPlay:PVTime : WIN Do w: TR AC e:X :SCALe:RPOSitio n LE F T

The following query returns LEFT.
:DISPlay:PVTime:WINDow:TRACe:X:SCALe:RPOSition?

:DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:PDIVision

Syntax

:DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:PDIVision <rel_ampl>
:DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:PDIVision?

Description

Sets the unit per division in the vertical axis of the PvT view.
Queries the unit per division in the vertical axis of the PvT vie w.

Parameter

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

Return Format

The query returns the Y-axis scale value in scientific notation.

Example

The following command sets the vertical scale in the PvT view to 15 dB.
:DISPlay:PVTime : WIN Do w: TR AC e:Y:SCALe:PDIVision 15

The following query returns 1.500000000e+01.
:DISPlay:PVTime:WINDow:TRACe:Y:SCALe:PDIVision?

:DISPlay:PVTime:WINDow :TRACe:Y[:SCALe]:RLEVel <real>

Syntax

:DISPlay:PVTime : WIN Do w: TR AC e:Y [: SCA Le] :RLE Vel <rea l>
:DISPlay:PVTime:WINDow:TRACe:Y[:SCALe]:RLEVel?

Description

Sets the reference level for the vertical axis in the PvT view.
Queries the reference level for the vertical axis in the PvT view.

Parameter

Remarks

This command is only valid when the PvT view in RTSA mode is selected.

RSA3000E Programming Guide 2-53

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<real>

Consecutive Real Number

-100 to 100

75

Return Format

The query returns the reference level for the vertical axis in scienti fic notation.

Example

The following command sets the reference level for the vertical axis in the PvT view to 100 dBm.
:DISPlay:PVTime:WINDow:TRA Ce:Y:SCALe:RLEVel 100

The following query returns 1.000000000e+02.
:DISPlay:PVTime:WINDow2:TRACe:Y:SCALe:RLEVel?

:DISPlay:VIEW:DENSity:AADJust

Syntax

:DISPlay:VIEW:DENSity:AADJust

Description

Sets the highest density hue to the highes t density value found in the current bitmap; sets the lowest
density hue to the lowest non-zero density value found in the current bitmap.

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

:DISPlay:VIEW:DENSity:CNONlinear

Syntax

:DISPlay:VIEW:DENSity:CNONlinear <real>
:DISPlay:VIEW:DENSity:CNONlinear?

Description

Sets the curve nonlinearity.
Queries the curve nonlinearity.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.
Within the range between the highest density hue and lowest density hue, setting the curve nonlinearity
can change the gradient among different density hues, making the displayed results move towards either
the higher or lower end of the gradient. Increasing the curve nonlinearity value will compress the colors
towards the higher end of the color bar, and decreasing the nonlinearity value will compress the colors
towards the lower end of the color bar.

Return Format

The query returns the curve nonlinearity value in scientific no tation.

Example

The following command sets the curve nonlinearity value to 50.
:DISPlay:VIEW:DENSity:CNONlinear 50

The following query returns 5.000000e+01.
:DISPlay:VIEW:DENSity:CNONlinear?

2-54 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Keyword

COOL|WARM|RADar|FIRE|FROSt

WARM

Name

Type

Range

Default

<real>

Consecutive Real Number

0.1 to 100

100

:DISPlay:VIEW:DENSity:CPALettes

Syntax

:DISPlay:VIEW:DENSity:CPALettes COOL|WARM|RADar|FIRE|FROSt
:DISPlay:VIEW:DENSity:CPALettes?

Description

Sets the color palette of Density.
Queries the color palette of Density.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

Return Format

The query returns COOL, WARM, RAD, FIRE, or FROS.

Example

The following command sets the color palette of Density to Cool.
:DISPlay:VIEW:DENSity:CPALettes COOL

The following query returns COOL.
:DISPlay:VIEW:DENSity:CPALettes?

:DISPlay:VIEW:DENSity:HDHue

Syntax

:DISPlay:VIEW:DENSity:HDHue <real>
:DISPlay:VIEW:DENSity:HDHue?

Description

Sets the highest density hue.
Queries the highest density hue.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

Return Format

The query returns the highest density hue in scientific nota ti on.

Example

The following command sets the highest density hue to 60.
:DISPlay:VIEW:DENSity:HDHue 60

The following query returns 6.000000e+01.
:DISPlay:VIEW:DENSity:HDHue?

RSA3000E Programming Guide 2-55

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<real>

Consecutive Real Number

0 to 99.9

0

Name

Type

Range

Default

<time>

Consecutive Real Number

0 s to 10 s

300 ms

:DISPlay:VIEW:DENSity:LDHue

Syntax

:DISPlay:VIEW:DENSity:LDHue <real>
:DISPlay:VIEW:DENSity:LDHue?

Description

Sets the lowest density hue.
Queries the lowest density hue.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

Return Format

The query returns the lowest density hue in scientific notation.

Example

The following command sets the lowest density hue to 30.
:DISPlay:VIEW:DENSity:LDHue 30

The following query returns 3.000000e+01.
:DISPlay:VIEW:DENSity:LDHue?

:DISPlay:VIEW:DENSity:PERSistence

Syntax

:DISPlay:VIEW:DENSity:PERSistence <tim e >
:DISPlay:VIEW:DENSity:PERSistence?

Description

Sets the persistence time.
Queries the persistence time.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

Return Format

The query returns the persistence time in scientific notation.

Example

The following command sets the persistence time to 5 s.
:DISPlay:VIEW:DENSity:PERSistence 5

The following query returns 5.000000e+00.
:DISPlay:VIEW:DENSity:PERSistence?

2-56 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

NORMal|SPECtrogram|DENSity|DSPectrogram|PVT|

PVTSpectrum|PSPectrogram

:DISPlay:VIEW:DENSity:PERSistence:INFinite

Syntax

:DISPlay:VIEW:DENSity:PERSistence:INFinite OFF|ON|0|1
:DISPlay:VIEW:DENSity:PERSistence:INFinite?

Description

Enables or disables the infinite mode of the persistence time.
Queries the status of the infinite mode of the persistence time.

Parameter

Remarks

This command is only available for Density and Density Spectrogram in RTSA mode.

Return Format

The query returns 0 or 1.

Example

The following command enables the infinite mode of the persistence time.
:DISPlay:VIEW:DENSity:PERSistence:INFinite ON or :DISPlay:VIEW:DENSity:PERSistence:INFinite 1

The following query returns 1.
:DISPlay:VIEW:DENSity:PERSistence:INFinite?

:DISPlay:VIEW[:SELect]

Syntax

:DISPlay:VIEW[:SELect] NORMal|SPECtrogram|DENSity|DSPectrogram|PVT|PVTSpectrum|PSPectrogram
:DISPlay:VIEW[:SELect]?

Description

Sets the current display view.
Queries the current display view.

Parameter

—— Keyword

Remarks

NORMal: indicates the normal view.
SPECtrogram: indicates Spectrogram.
DENSity: indica tes Density.
DSPectrogram: indicates Density and Density Spectrogram.
PVT: indicates Power versus Time spectrum.
PVTSpectrum: indicates PvT Spectrum.
PSPectrogram: indicates PvT Spectrogram.
This command is only available for RTSA mode.

Return Format

The query returns NORM, SPEC, DENS, DSP, PVT, PVTS, or PSP.

RSA3000E Programming Guide 2-57

NORMal

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<integer>

Integer

0 to min (90%, with th e referen ce positio n valu e -10%)

0

Example

The following commands sets the current view to Spectrogram .
:DISPlay:VIEW:SELect SPECtrogram

The following query returns SPEC.
:DISPlay:VIEW:SELect?

:DISPlay:VIEW:SPECtrogram:AADJust

Syntax

:DISPlay:VIEW:SPECtrogram:AADJust

Description

Auto adjusts the reference hue position and bottom hue position based on the highest amplitude value and
the lowest amplitude value found in the spectrogram, respectively.

Remarks

The reference hue position is set to the highest amplitude value, and the bottom hue position to the lowest
amplitude value.
This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

:DISPlay:VIEW:SPECtrogram:BOTTom

Syntax

:DISPlay:VIEW:SPECtrog ram:B OTTom <integer>
:DISPlay:VIEW:SPECtrogram:BOTTom?

Description

Sets the bottom hue position displayed in the graticule.
Queries the bottom hue position displayed in the graticule.

Parameter

Remarks

Any amplitudes lower than the bottom hue position ar e displayed as black.
This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

Return Format

Queries the bottom hue position displayed in the graticule in int eger.

Example

The following command sets the bottom hue position displayed in the graticule to 40.
:DISPlay:VIEW:SPECtrog ram:B OTTom 40

The following query returns 40.
:DISPlay:VIEW:SPECtrogram:BOTTom?

2-58 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<real>

Consecutive Real Number

0 to 359.9

0

Name

Type

Range

Default

<integer>

Integer

1 to 8,192 (RTSA)

1

:DISPlay:VIEW:SPECtrogram:HUE

Syntax

:DISPlay:VIEW:SPECtrogram:HUE <real>
:DISPlay:VIEW:SPECtrogram:HUE?

Description

Sets the reference hue.
Queries the reference hue.

Parameter

Remarks

The reference hue indicates the hue value at the top of the color bar in the spectrogram.
This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

Return Format

The query returns the reference hue value in scientific notation.

Example

The following command sets the reference hue value to 120.
:DISPlay:VIEW:SPECtrog ram:H UE 12 0

The following query returns 1.200000e+02.
:DISPlay:VIEW:SPECtrogram:HUE?

:DISPlay:VIEW:SPECtrogram:POSition

Syntax

:DISPlay:VIEW:SPECtrogram:POSition <integer>
:DISPlay:VIEW:SPECtrogram:POSition?

Description

Sets the trace to be displayed in the spectrogram.
Queries the trace to be displayed in the spectrogram.

Parameter

Remarks

This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.
In the trace window displayed in the spectrogram mode, you can determine the trace either by the trace
number or the trace time. Trace 1 indicates the latest trace. If you select the trac e by tr ac e time, the trac e
that is closest to the set time will be selected.

Return Format

The query returns the displayed trace number in integer.

Example

The following command sets the displayed trace number to 146.
:DISPlay:VIEW:SPECtrogram:POSition 146

RSA3000E Programming Guide 2-59

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<integer>

Integer

Max (10%, bottom hue value +10%) to 100

100

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

The following query returns 146.
:DISPlay:VIEW:SPECtrogram:POSition?

:DISPlay:VIEW:SPECtrogram:REFerence

Syntax

:DISPlay:VIEW:SPECtrogram:REFerence <integer>
:DISPlay:VIEW:SPECtrogram:REFerence?

Description

Sets the position of the reference hue displayed in the graticule.
Queries the position of the reference hue displayed in the graticule.

Parameter

Remarks

This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

Return Format

Queries the reference hue position displayed in the graticule in integer.

Example

The following command sets the reference hue position displayed in the graticule to 60.
:DISPlay:VIEW:SPECtrogram:REFerence 60

The following query returns 60.
:DISPlay:VIEW:SPECtrogram:REFerence?

:DISPlay:VIEW:SPECtrogram:TRACe:COUPle

Syntax

:DISPlay:VIEW:SPECtrogram:TRACe:COUPle ON|OFF|1|0
:DISPlay:VIEW:SPECtrogram:TRACe:COUPle?

Description

Enables or disables coupling the marker to the trace.
Queries whether the marker is coupled to the trace.

Parameter

Remarks

When you select "Off", the command allows you to fix the current marker to the displayed trace that is
active when the marker is turned on.
When you select "On", the marker will stay on the selected trace and change with the trace.
This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

Return Format

The query returns 0 or 1.

2-60 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Keyword

TIME|TNUMber

TNUMber

Example

The following command enables coupling the marker to the trace.
:DISPlay:VIEW:SPECtrogram:TRACe:COUPle ON or :DISPlay:VIEW:SPECtrogram:TRACe:COUPle 1

The following query returns 1.
:DISPlay:VIEW:SPECtrogram:TRACe:COUPle?

:DISPlay:VIEW:SPECtrogram:TRACe:SELection

Syntax

:DISPlay:VIEW:SPECtrog ram:TR AC e: SE Lec tion TIME|TNUMber
:DISPlay:VIEW:SPECtrogram:TRACe:SELection?

Description

Sets the selection method for the displayed trace.
Queries the selection method for the displayed trace.

Parameter

Remarks

TIME: indicates the trace time.
TNUMber: indicates the trace number.
Each trace is associated with a time value that represents the acquisition time. Th e formula is as follows:
Trace Time = Trace Number x Acquisition Time.
This command is only available for Spectrogram in RTSA mode or the view that contains the spectrogram.

Return Format

The query returns TIME or TNUM.

Example

The following command sets the selection method for the displayed trace to Time.
:DISPlay:VIEW:SPECtrog ram:TR AC e: SE Lec tion TIME

The following query returns TIME.
:DISPlay:VIEW:SPECtrogram:TRACe:SELection?

RSA3000E Programming Guide 2-61

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Keyword

SPECtrum|PVT

——

Name

Type

Range

Default

<ampl>

Consecutive Real Number

Current amplitude range

-25 dBm

:DISPlay:WINDow:SELect

Syntax

:DISPlay:WINDow:SELect SPECtrum|PVT
:DISPlay:WINDow:SELect?

Description

Selects a window in the current view.
Queries the currently selected window type.

Parameter

Remarks

This command is only available for Density Spectrogram, PvT Spectrum, or PvT Spectrogram in RT SA mode.
Return Format

The query returns SPEC or PVT.

Example

The following command selects the PvT w indow in the PvT Spe ctr um view.
:DISPlay:WINDow:SELect PVT

The following query re turns PVT.
:DISPlay:WINDow:SELect?

:DISPlay:WINDow:TRACe:Y:DLINe

Syntax

:DISPlay:WINDow:TRACe:Y:DLINe <ampl>
:DISPlay:WINDow:TRACe:Y:DLINe?

Description

Sets the position of the display line. Its default unit is dBm.
Queries the position of the display line.

Parameter

Remarks

By default, the display line is disabled. When the display line is enabled for the first time, its position is -25
dBm.

Return Format

The query returns the position of the display line in scientific notation.

Example

The following command sets the position of the display line to -10 dBm.
:DISPlay:WINDow:TRACe:Y:DLINe -10

The following query returns -1.000000e+01.
:DISPlay:WINDow:TRACe:Y:DLINe?

2-62 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

——

Bool

OFF|ON|0|1

OFF|0

Name

Type

Range

Default

<rel_ampl>

Consecutive Real Number

-200 dB to 200 dB

10 dB

:DISPlay:WINDow:TRACe:Y:DLINe:STATe

Syntax

:DISPlay:WINDow:TRACe:Y:DLINe:STATe OFF|ON|0|1
:DISPlay:WINDow:TRACe:Y:DLINe:STATe?

Description

Turns on or off the display line.
Queries the status of the display line.

Parameter

Return Format

The query returns 0 or 1.

Example

The following command enables the display line.
:DISPlay:WINdow:TRACe:Y:DLINe:STATe ON or :DISPlay:WINdow:TRACe: Y:DLINe:STATe 1

The following query returns 1.
:DISPlay:WINdow:TRACe:Y:DLINe:STATe?

:DISPlay:WINDow:TRACe:Y[:SCALe]:NRLevel

Syntax

:DISPlay:WINDow:TRACe:Y[:SCA Le]:NRLevel <rel_am pl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:NRLevel?

Description

Sets the reference level of normalization.
Queries the reference level of normalization.

Parameter

Remarks

This command is only available for RSA3030E-TG/RSA3015E-TG working in GPSA mode.
This command is only valid when the tracking generator function is enabled.

Return Format

The query returns the reference level of normalization in scientific notation.

Example

The following command sets the reference level of normalization to -20 dB.
:DISPlay:WINDow:TRACe:Y:SCALe:NRLevel -20

The following query returns -2.000000e+01.
:DISPlay:WINDow:TRACe:Y:SCALe:NRLevel?

RSA3000E Programming Guide 2-63

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<integer>

Integer

0% to 100%

100%

Name

Type

Range

Default

<rel_ampl>

Consecutive Real Number

0.1 dB to 20 dB

10 dB

:DISPlay:WINDow:TRACe:Y[:SCALe]:NRPosition

Syntax

:DISPlay:WINDow:TRACe:Y[:SCA Le]:NRPosition <integ e r>
:DISPlay:WINDow:TRACe:Y[:SCALe]:NRPosition?

Description

Sets the reference position of normalization.
Queries the reference position of normalization.

Parameter

Remarks

This command is only available for RSA3030E-TG/RSA3015E-TG working in GPSA mode.
This command is only valid when the tracking generator function is enabled.

Return Format

The query returns the reference position of normalization in integer.

Example

The following command sets the reference position of normalization to 50%.
:DISPlay:WINDow:TRACe:Y:SCALe:NRPosition 50

The following query returns 50.
:DISPlay:WINDow:TRACe:Y:SCALe:NRPosition?

:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision

Syntax

:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision <rel_ampl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision?

Description

Sets the Y-axis scale type.
Queries the Y-axis scale type.

Parameter

Return Format

The query returns the Y-axis scale value in scientific notation.

Example

The following command sets the Y-axis scale value to 15 dB.
:DISPlay:WINDow:TRACe:Y:SCALe:PDIVision 15

The following query returns 1.500000e+01.
:DISPlay:WINDow:TRACe:Y:SCALe:PDIVision?

2-64 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<ampl>

Consecutive Real Number

-170 dBm to 30 dBm

0 dBm

Name

Type

Range

Default

<rel_ampl>

Consecutive Real Number

-300 dB to 300 dB

0 dB

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel

Syntax

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel <ampl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel?

Description

Sets the reference level.
Queries the reference level.

Parameter

Return Format

The query returns the reference level in scientific notation.

Example

The following command sets the reference level to -10 dB.
:DISPlay:WINDow:TRACe:Y:SCALe:RLEVel -10

The following query returns -1.000000e+01.
:DISPlay:WINDow:TRACe:Y:SCALe:RLEVel?

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet

Syntax

:DISPlay:WINDow:TRACe:Y[:SCA Le]:RLEVel:OFFSet <rel_am pl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet?

Description

Sets the reference level offset.
Queries the reference level offset.

Parameter

Remarks

The offset of the reference level only mo difies the reference level and amplitude readout of the marker, but
does not change t he position of the curve.

Return Format

The query returns the offset of the reference level in scientific notation.

Example

The following command sets the reference level offset to 10 dB.
:DISPlay:WINDow:TRACe:Y:SCALe:RLEVel:OFFSet 10

The following query returns 1.000000e+01.
:DISPlay:WINDow:TRACe:Y:SCALe:RLEVel:OFFSet?

RSA3000E Programming Guide 2-65

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

——

Keyword

LINear|LOGarithmic

LOGarithmic

:DISPlay:WINDow:TRACe:Y[:SCALe]:SPACing

Syntax

:DISPlay:WINDow:TRACe:Y[:SCALe]:SPACing LINear| LOGarithmic
:DISPlay:WINDow:TRACe:Y[:SCALe]:SPACing?

Description

Sets the Y-axis scale type.
Queries the Y-axis scale type.

Parameter

Remarks

LINear: indicates linear.
LOGarithmic: indicates log.

Return Format

The query returns LIN or LOG.
Example

The following command sets the Y-axis scale type to LOG.
:DISPlay:WINDow :TRAC e: Y:SCALe:SPACing LOGarithmic

The following query returns LOG.
:DISPlay:WINDow:TRACe:Y:SCALe:SPACing?

2-66 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:FETCh Commands

Command List:

 :FETCh:ACPower?
 :FETCh:ACPower:LOWer?
 :FETCh:ACPower:MAIN?
 :FETCh:ACPower:UPPer?
 :FETCh:CNRatio?
 :FETCh:CNRatio:CARRier?
 :FETCh:CNRatio:CNRatio?
 :FETCh:CNRatio:NOISe?
 :FETCh:EBWidth?
 :FETCh:HARMonics:AMPLitude:ALL?
 :FETCh:HARMonics:AMPLi tud e? <n >
 :FETCh:HARMonics[:DISTortion]?
 :FETCh:HARMonics:FREQuency:ALL?
 :FETCh:HARMonics:FREQuency? <n>
 :FETCh:HARMonics:FUNDamental?
 :FETCh:OBWidth?
 :FETCh:OBWidth:OBWidth?
 :FETCh:OBWidth:OBWidth:FERRor?
 :FETCh:SANalyzer<n>?
 :FETCh:TOIntercept?
 :FETCh:TOIntercept:IP3?
 :FETCh:TPOWer?

Remarks:

The :FETCh commands are only available for the RSA3000E serie s that has been installed with advanced
measurement kit (AMK) option.

RSA3000E Programming Guide 2-67

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:FETCh:ACPower?

Syntax

:FETCh:ACPower?

Description

Queries the results of adjacent channel power measurement.

Remarks

This command is only valid when the adjacent channel power measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns 5 values (main ch annel po wer, u pp er chan n el power, the power dif f erence b etween the
upper channel and the main c h annel (i n dBc), t he l ower ch ann el power, the po wer di ff erenc e between th e
lower channel and the main channel (in dBc)) in scientific notation, and the values are se parated by
commas.

Example

The following query returns

-5.150423000e+01,-5.173441000e+01,-2.301865000e-01,-5.142665000e+01,7.757568000e-02.
:FETCh:ACPower?

:FETCh:ACPower:LOWer?

Syntax

:FETCh:ACPower:LOWer?

Description

Queries the lower channel power of the adjacent channel power measurement.

Remarks

This command is only valid when the adja cent channel power measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the lower channel power in scientific notation.

Example

The following query returns -5.142665000e+01.
:FETCh:ACPower:LOWer?

2-68 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:FETCh:ACPower:MAIN?

Syntax

:FETCh:ACPower:MAIN?

Description

Queries the main channel power of the adjacent channel power measurement.

Remarks

This command is only valid when the adjacent channel power measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the main channel power in scientific notation.

Example

The following query returns -5.150423000e+01.
:FETCh:ACPower:MAIN?

:FETCh:ACPower:UPPer?

Syntax

:FETCh:ACPower:UPPer?

Description

Queries the upper channel power of the adjacent channel power measurement.

Remarks

This command is only valid when the adjacent channel power measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the upper channel power in scientific notation.

Example

The following query returns -5.173441000e+01.
:FETCh:ACPower:UPPer?

RSA3000E Programming Guide 2-69

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:FETCh:CNRatio?

Syntax

:FETCh:CNRatio?

Description

Queries the results of C/N ratio measurement.

Remarks

This command is only valid when the C/N ratio measurement in GPSA mode is enable d .
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the carrier power, noise power, and C/N ratio (in dB) in scientific notation. They are
separated by commas.

Example

The following query returns -6.048788000e+01,-6.186192000e+01,1.374039000e+00.
:FETCh:CNRatio?

:FETCh:CNRatio:CARRier?

Syntax

:FETCh:CNRatio:CARRier?

Description

Queries the carrier power.

Remarks

This command is only valid when the C/N ratio measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the carrier power in scientific notation.

Example

The following query returns -1.484203000e+01.
:FETCh:CNRatio:CARRier?

2-70 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

:FETCh:CNRatio:CNRatio?

Syntax

:FETCh:CNRatio:CNRatio?

Description

Queries the results of C/N ratio measurement.

Remarks

This command is only valid when the C/N ratio measurement in GPSA mode is enabled.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the C/N ratio in scientific notation.

Example

The following query returns 8.956909000e-02.
:FETCh:CNRatio:CNRatio?

:FETCh:CNRatio:NOISe?

Syntax

:FETCh:CNRatio:NOISe?

Description

Queries the noise power.

Remarks

This command is only valid when the C/N ratio measurement in GPSA mode is enabled.
The power unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the noise power in scientific not ation.

Example

The following query returns -1.442294000e+01.
:FETCh:CNRatio:NOISe?

RSA3000E Programming Guide 2-71

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

:FETCh:EBWidth?

Syntax

:FETCh:EBWidth?

Description

Queries the result of the emission bandwidth measurement.

Remarks

This command is only valid when the emission bandwidth measurement in GPSA mode is enabled.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the emission bandwidth in integer, and its unit is Hz.

Example

The following query returns 5.000000000e+04.
:FETCh:EBWidth?

:FETCh:HARMonics:AMPLitude:ALL?

Syntax

:FETCh:HARMonics:AMPLitude:ALL?

Description

Queries the amplitudes of the first 10 harmonics. The first harmonic is the fundamental waveform.

Remarks

This command is only valid when the harmonic distortion measurement in GPSA mode is enabled.
The amplitude unit of the return value is consistent with the current Y-axis unit.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the amplitudes of the first 10 harmonics in scientific notation (separated by commas).
If the number of harmonics under measurement is less than 10, the harmonics that are not measured do
not have return values.

Example

The following query returns

-1.692102000e+01,-6.458423000e+01,-7.509421000e+01,-7.924328000e+01,-7.847027000e+01,-7.885
457000e+01,-7.882358000e+01,-7.921457000e+01,-7.923057000e+01,-7.915358000e+01.
:FETCh:HARMonics:AMPLitude:ALL?

2-72 RSA3000E Programming Guide

Chapter 2 Command Systems for GPSA and RTSA Modes RIGOL

Name

Type

Range

Default

<n>

Integer

1 to 10

——

:FETCh:HARMonics:AMPLitude? <n>

Syntax

:FETCh:HARMonics :A MP Lit ud e? <n >

Description

Queries the amplitude of the specified harmonic.

Parameter

Remarks

This command is only valid when the harmonic distortion measurement in GPSA mode is enabled.
The amplitude unit of the return value is consistent with the current Y-axis unit.
The query returns --- when the harmonic read does not have data.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the amplitude of the specified harmonic in scientific no tation.

Example

The following query returns -1.692102000e+01.
:FETCh:HARMonics:AMPLitude? 1

:FETCh:HARMonics[:DISTortion]?

Syntax

:FETCh:HARMonics[:DISTortion]?

Description

Queries the percentage of the total harmonic distortion.

Remarks

This command is only valid when the harmonic distortion measurement in GPSA mode is enabled.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the percentage of the total harmonic distortion in scientific notation.

Example

The following query returns 1.510000000e-02.
:FETCh:HARMonics:DISTortion?

RSA3000E Programming Guide 2-73

RIGOL Chapter 2 Command Systems for GPSA and RTSA Modes

Name

Type

Range

Default

<n>

Integer

1 to 10

——

:FETCh:HARMonics:FREQuency:ALL?

Syntax

:FETCh:HARMonics:FREQuency:ALL?

Description

Queries the frequencies of the first 10 harmonics. The first harmonic is the fundamental waveform.

Remarks

This command is only valid when the harmonic distortion measurement in GPSA mode is enabled.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the frequencies of the first 10 harmonics in scientific notation (separated by commas).
The unit is Hz.
If the number of harmonics under measurement is less than 10, the harmonics that are not measured do
not have return values.

Example

The following query returns

4.550000000e+07,9.100000000e+07,1.365000000e+08,1.820000000e+08,2.275000000e+08,2.7300000

00e+08,3.185000000e+08,3.640000000e+08,4.095000000e+08,4.550000000e+08.

:FETCh:HARMonics:FREQuency:ALL?

:FETCh:HARMonics:FREQuency? <n>

Syntax

:FETCh:HARMonics:FREQuency? <n>

Description

Queries the frequency of the specified harmonic.

Parameter

Remarks

This command is only valid when the harmonic distortion measurement in GPSA mode is enabled.
The query returns --- when the harmonic read does not have data.
This command will select data from the latest measurement results, and then transmit the data to the
output buffer.

Return Format

The query returns the frequency of the specified harm onic in scientific notation. The unit is Hz.

Example

The following query returns 4.550000000e+07.
:FETCh:HARMonics:FREQuency? 1

2-74 RSA3000E Programming Guide
