RIGOL RP1100D User Guide

User Guide
RP1000D Series High Voltage
Differential Probe
Apr. 2021
RIGOL TECHNOLOGIES. CO., LTD.
RIGOL
Guaranty and Declaration
Copyright
© 2021 RIGOL TECHNOLOGIES CO., LTD. All Rights Reserved.
Trademark Information
RIGOL® is the trademark of RIGOL TECHNOLOGIES CO., LTD.
Publication Number
UGE18108-1110
Notices
RIGOL products are covered by P.R.C. and foreign patents,
issued and pending.
RIGOL reserves the right to modify or change parts of or all
the specifications and pricing policies at the company’s sole
decision.
Information in this publication replaces all previously released
materials.
Information in this publication is subject to change without
notice.
RIGOL shall not be liable for either incidental or consequential
losses in connection with the furnishing, use, or performance of this manual, as well as any information contained.
Any part of this document is forbidden to be copied,
photocopied, or rearranged without prior written approval of
RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial standards in China as well as the ISO9001:2015 standard and the ISO14001:2015 standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual, please contact RIGOL. E-mail: service@rigol.com
Website: www.rigol.com
RP1000D User Guide I
RIGOL
General Safety Summary
Please review the following safety precautions carefully before putting the instrument into operation so as to avoid any personal injury or damage to the instrument and any product connected to it. To prevent potential hazards, please follow the instructions specified in this manual to use the instrument properly.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To avoid electric shock, connect the earth terminal of the power cord to the Protective Earth terminal before connecting any input or output terminals.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and check your manual for more information about ratings before connecting the instrument.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate with Suspected Failures.
If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially
II RP1000D User Guide
RIGOL
to circuits or accessories must be performed by RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause increasing of temperature or damages to the device. So please keep well ventilated and inspect
the intake and fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the instrument in an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the surfaces of the instrument clean and dry.
Prevent Electrostatic Impact.
Operate the instrument in an electrostatic discharge protective
environment to avoid damage induced by static discharges. Always ground both the internal and external conductors of cables to release static before making connections.
RP1000D User Guide III
RIGOL
death.
product or loss of important data.
It calls attention to an operation, if not correctly
immediately.
It calls attention to an operation, if not correctly
performed, could result in potential injury or hazard.
It calls attention to an operation, if not correctly
other devices connected to the product.
Double
Hazardous
Safety
Protective
Chassis
Test
Safety Terms and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not avoided, will result in serious injury or
CAUTION
Indicates a potentially hazardous situation or practice
which, if not avoided, could result in damage to the
Safety Terms on the Product:
DANGER
performed, could result in injury or hazard
WARNING
CAUTION
performed, could result in damage to the product or
Safety Symbols on the Product:
Insulation
Voltage
Warning
Earth
Terminal
Ground
IV RP1000D User Guide
Ground
RIGOL
Contents
Guaranty and Declaration .................................................. I
General Safety Summary .................................................. II
Safety Terms and Symbols .............................................. IV
RP1000D Overview ........................................................... 1
Basic Operations ............................................................... 5
Cleaning and General Care ................................................ 7
Warranty ........................................................................... 7
Specifications .................................................................... 8
Technical Specifications ..................................................... 8
Operation Environment .................................................... 11
General Specifications ...................................................... 11
Accessories ...................................................................... 12
RP1000D User Guide V
RIGOL
RP1000D Overview
RP1000D series high voltage differential probe can convert high differential input voltage to low voltage and display the waveforms
on the oscilloscope. Its working frequency is up to 25MHz (RP1025D), 50MHz (RP1050D) and 100MHz (RP1100D) and it is rather suitable for large electricity test and R&D.
RP1000D series high voltage differential probe is applicable to general purpose oscilloscope and the labeled attenuation ratios are those when the input impedance of the oscilloscope is 1MΩ. The attenuation ratios will double when the input impedance of the oscilloscope is 50Ω.
RP1000D User Guide 1
RIGOL
Power Adaptor
Attenuation Ratio and
Input Terminal
Overload Indicator
Power Button
Power Indicator
Interface
BNC Interface
Figure 1 RP1025D High Voltage Differential Probe
2 RP1000D User Guide
Power Adaptor
Attenuation Ratio and
RIGOL
Input Terminal
Overload Indicator
Power Indicator
Power Button
Interface
BNC Interface
Figure 2 RP1050D High Voltage Differential Probe
RP1000D User Guide 3
RIGOL
Attenuation Ratio and
Input Terminal
Overload Indicator
Power Indicator
Power Button
Power Adaptor
Interface
BNC Interface
Figure 3 RP1100D High Voltage Differential Probe
4 RP1000D User Guide
RIGOL
Basic Operations
1. Connect the red safety IC clip with one end of the red dual-banana plug silicon cable and the black safety IC clip with one end of the black dual-banana plug silicon cable provided in the accessories. Then, connect the red dual-banana plug silicon cable with the red (+) input terminal of the high voltage probe and the black dual-banana plug silicon cable with the black (-) input terminal of the high voltage probe.
Note: a) The safety IC clip can be replaced by the high voltage
dedicated IC clip, safety alligator clip or safety contact probe prod;
b) The dual-banana plug silicon cable can be replaced by high
voltage dedicated dual-banana plug silicon cable.
2. Connect one end of the dual-BNC coaxial cable to the BNC interface of the high voltage differential probe and the other end to the input terminal of the oscilloscope.
3. Turn on the channel switch on the oscilloscope and adjust the attenuation of the high voltage probe to make it match that of the oscilloscope. If the attenuation ratio of the oscilloscope does not match that of the high voltage probe, the actual vertical scale equals the attenuation ratio of the high voltage probe divided by the attenuation ratio of the oscilloscope and then times the vertical scale of the oscilloscope.
For example, when the attenuation ratio of the oscilloscope is
RP1000D User Guide 5
RIGOL
set to 1X, the attenuation ratio of the high voltage probe is set to X200 and the vertical scale of the oscilloscope is 0.5V/div, the actual vertical scale is 200X0.5V/div=100V/div. When the input impedance of the oscilloscope is 50Ω, the actual vertical scale is 2X200X0.5V/div =200V/div.
Note: When the attenuation ratio of the oscilloscope matches the attenuation ratio of the high voltage probe, the vertical scale displayed on the oscilloscope is the actual scale.
6 RP1000D User Guide
RIGOL
Cleaning and General Care
Cleaning:
This product has no particular requirement for cleaning. To clean the probe, please wipe the probe surface using soft and clean cloth dampened with detergent.
General Care:
Please store this product in anti-humidity case if the product will not be used for more than 60 days.
Warranty
RIGOL TECHNOLOGIES CO., LTD. (hereinafter referred to as RIGOL) warrants that the product will be free from defects in
materials and workmanship within the warranty period. If a product proves defective within the warranty period, RIGOL guarantees free replacement or repair for the defective product.
To get repair service, please contact with your nearest RIGOL sales
or service office.
There is no other warranty, expressed or implied, except such as is expressly set forth herein or other applicable warranty card. There is no implied warranty of merchantability or fitness for a particular purpose. Under no circumstances shall RIGOL be liable for any consequential, indirect, ensuing, or special damages for any breach
of warranty in any case.
RP1000D User Guide 7
RIGOL
Bandwidth
DC - 25MHz (-3dB)
Attenuation Ratio
X20, X50, X200
Accuracy
±2%
Input Voltage
X20 attenuation ratio: ≤ 140Vpp, about
500Vrms or DC
Maximum Input
Maximum differential voltage: 1400V
600Vrms
Input Impedance
Differential: 4MΩ/1.2pF Single-ended and to ground: 2MΩ/2.3pF
Output Voltage
±6.5V
Output Impedance
50Ω
Rise Time
14ns
Common-mode
60Hz: > 50dB
1MHz: > 50dB
Power Supply
RIGOL
Power Consumption
<300 mA
Specifications
Technical Specifications
RP1025D:
Range (DC + AC peak-peak value)
Voltage
Rejection
50Vrms or DC X50 attenuation ratio: ≤ 350Vpp, about 125Vrms or DC X200 attenuation ratio: ≤ 1400Vpp, about
(DC+AC peak-peak value) or 500Vrms Voltage to ground at the input terminal:
100Hz: > 50dB
Specified external 9V DC power supply (must be specified products acknowledged
by
)
8 RP1000D User Guide
RP1050D:
Bandwidth
DC - 50MHz (-3dB)
Attenuation Ratio
X100, X200, X500, X1000
Accuracy
±2%
Input Voltage
X100 attenuation ratio: ≤ 700Vpp, about
2300Vrms or DC
Maximum Input
Maximum differential voltage: 7000V
6500Vrms
Input Impedance
Differential: 16MΩ/1pF Single-ended and to ground: 8MΩ/2pF
Output Voltage
±7.0 V
Output Impedance
50Ω
Rise Time
7ns
Common-mode
60Hz: > 50dB
1MHz: > 50dB
Power Supply
Specified external 9V DC power supply
by RIGOL)
Power Consumption
<300 mA
RIGOL
Range (DC + AC peak-peak value)
Voltage
Rejection
230Vrms or DC X200 attenuation ratio: ≤ 1400Vpp, about 460Vrms or DC X500 attenuation ratio: ≤ 3500Vpp, about 1140Vrms or DC X1000 attenuation ratio: ≤ 7000Vpp,
(DC+AC peak-peak vale) or 2300Vrms
Voltage to ground at the input terminal:
100Hz: > 50dB
(must be specified products acknowledged
RP1000D User Guide 9
RIGOL
Bandwidth
DC - 100MHz (-3dB)
Attenuation Ratio
X100, X200, X500, X1000
Accuracy
±2%
Input Voltage
X100 attenuation ratio: ≤ 700Vpp, about
about 2300Vrms or DC
Maximum Input
Maximum differential voltage: 7000V
6500Vrms
Input Impedance
Differential: 16MΩ/1.2pF Single-ended and to ground: 8MΩ/2.3pF
Output Voltage
±8.0V
Output Impedance
50Ω
Rise Time
3.5ns
Common-mode
60Hz: > 50dB
1MHz: > 50dB
Power Supply
Specified external 9V DC power supply
by RIGOL)
Power Consumption
<300 mA
RP1100D:
Range (DC + AC peak-peak value)
Voltage
Rejection
230Vrms or DC X200 attenuation ratio: ≤ 1400Vpp, about 460Vrms or DC X500 attenuation ratio: ≤ 3500Vpp, about 1140Vrms or DC X1000 attenuation ratio: ≤ 7000Vpp,
(DC+AC peak-peak value) or 2300Vrms
Voltage to ground at the input terminal:
100Hz: > 50dB
(must be specified products acknowledged
10 RP1000D User Guide
Operation Environment
Probe Dimensions
Weight
General Operation Storage
Tem p er at ur e
Humidity 70%RH 10% to
General Specifications
Safety IEC 1010-1, CAT III, pollution degree 2
Electromagnetic Compatibility Maximum Voltage to Ground
Using Environment Indoor environment Insulation Category Double insulation
+20 to +30
RIGOL
0 to +50 -30 to
+70
10% to
85%RH
90%RH
RP1025D: about 214mm x 60mm x 35mm
RP1050D: about 240mm x 85mm x 36mm RP1100D: about 240mm x 85mm x 36mm RP1025D: 280g RP1050D: 280g RP1100D: 280g
Conform to EN50081-1 and 50082-1 standards RP1025D: 600Vrms RP1050D: 6500Vrms RP1100D: 6500Vrms
RP1000D User Guide 11
RIGOL
Accessories
RP1025D:
Accessories Explanation Quantity
1.
User Guide Chinese & English
AC power adaptor
conforming to the
2. standard of the
destination country
3.
Dual-BNC coaxial cable
Dual-banana plug silicon
4. cable
5.
Safety IC clip UL 1000V CAT III Red: 1; Black: 1
6.
Safety alligator clip
-- 1
50Ω impedance
RG58C UL
100cm length
UL 6KV
18AWG
60cm length
UL 1000V CAT II,10A
1
1
Red: 1; Black: 1
Red: 1; Black: 1
12 RP1000D User Guide
RP1050D:
Accessories Explanation Quantity
1. User Guide Chinese & English 1
AC power adaptor
conforming to the
2. standard of the
destination country
3.
Dual-BNC coaxial cable
High voltage dedicated
dual-banana plug silicon
4.
cable
High voltage dedicated IC
5. clip
6. Safety alligator clip
-- 1
50Ω impedance
RG58C UL
100cm length
UL 20KV
16AWG
60cm length
maximum 6500V
(DC+AC p-p)
UL 1000V CAT II,10A
1
Red: 1; Black: 1
Red: 1; Black: 1
Red: 1; Black: 1
RIGOL
RP1000D User Guide 13
RIGOL
RP1100D:
Accessories Explanation Quantity
1. User Guide Chinese & English 1
AC power adaptor
conforming to the
2. standard of the
destination country
3.
Dual-BNC coaxial cable
High voltage dedicated
dual-banana plug silicon
4.
cable
High voltage dedicated IC
5. clip
6. Safety alligator clip
7. Safety contact probe prod
-- 1
50Ω impedance
RG58C UL
100cm length
UL 20KV
16AWG
60cm length
maximum 6500V
(DC+AC p-p)
UL 1000V CAT II,10A
UL 1000VCAT III
1
Red: 1; Black: 1
Red: 1; Black: 1
Red: 1; Black: 1
Red: 1; Black: 1
14 RP1000D User Guide
Loading...
