Performance Verification Guide
MSO5000-E Series Digital Oscilloscope
Sept. 2019
RIGOL (SUZHOU) TECHNOLOGIES INC.
RIGOL
Guaranty and Declaration
Copyright
© 2019 RIGOL (SUZHOU) TECHNOLOGIES INC. All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL (SUZHOU) TECHNOLOGIES INC.
Publication Number
PVA28101-1110
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications and pricing
policies at the company’s sole decision.
Information in this publication replaces all previously released materials.
Information in this publication is subject to change without notice.
RIGOL shall not be liable for either incidental or consequential losses in connection with the
furnishing, use, or performance of this manual, as well as any information contained.
Any part of this document is forbidden to be copied, photocopied, or rearranged without prior
written approval of RIGOL.
Product Certification
RIGOL guarantees that t his product conf orms to the nat ional and industrial standards in China as well
as the ISO9001:2015 standard and the ISO14001:2015 standard. Other international standard
conforman ce ce rt i fications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual, please contact
RIGOL.
E-mail: service@rigol.com
Website: www.rigol.com
MSO5000-E Performance Verification Guide I
RIGOL
General Safety Summary
Please review the following safety precautions carefully before putting the instrument into operation
so as to avoid any personal injury or damage to the instrument and any product connected to it. To
prevent potential hazards, please follow the instructio ns specified in this manual to use the instrument
properly.
Use Proper Power Cord.
Only the exclusive power cord designed for the instrument and authorized for use within the local
country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To avoid electric
shock, connect the earth terminal of the power cord to the Protective Ea rth terminal before connecting
any input or output terminals.
Connect the Probe Correctly.
If a probe is used, the probe ground lead must be connected to earth ground. Do not connect the
ground lead to high voltage. Improper way of connection could result in dangerous voltages being
present on t he c onne ct ors , con t rols or oth e r sur f ace s o f the oscilloscope a nd p robes, whi ch will cause
potential hazards for operators.
Observe All Terminal Ratings.
To avoid f ire or shock hazard, observe all ratings and markers on the instrument and check your
manual for more information about ratings before connecting the instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the product.
Otherwise, the operator might be exposed to the danger of an electric shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Objects Into the Air Outlet.
Do not insert anything into the holes of the fan to avoid damaging the instrument.
Use Proper Fuse.
Please use the specified fuses.
Avoid Circu i t or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate With Suspected Failures.
If you suspect that any damage may occur to t he i nstrument, ha ve it i nspe cted by RIGOL authorized
personnel before further operations. Any maintenance, adjustment or replacement especially to
circuits or accessories must be performed by RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause an increase of temperature in the instrument, which would cause
damage to the instrument . So please k eep the instrument w ell ventilated an d inspect the air outlet and
the fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric sho ck, never operate the instrument in a humid
environment.
II MSO5000-E Performance Verification Guide
RIGOL
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the instrument in an explosive
atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the surfaces of the
instrument clean and dry.
Prevent Ele c tr o static Imp act.
Operate the instrument in an ele ctrostatic discha rge protective en vi ronment to a void dama ge indu ced
by static discharges. Always ground both the internal and external conductors of cables to release
static before making connections.
Use the Battery Properly.
Do not expose the bat tery (if av ailable) t o high tem perature or fire. Keep it out of the rea ch of children .
Improper change o f a battery (lithium battery) may cause an explosion. Use the RIGOL specified
battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs, interfaces, and other
parts on the panels.
MSO5000-E Performance Verification Guide III
RIGOL
WARNING
Indicates a potentially hazardous situation or practice which, if not avoided, will result in
serious injury or death.
CAUTION
damage to the product or loss of important data.
DANGER
It calls attention to an operation, if not correctly performed, could result in injury or
hazard immediately.
WARNING
It calls attention to an ope r ati on , if not correctly performed, could result in potential
injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could result in damage
to the product or other devices connected to the product.
Hazardous
Voltage
Safety Warning
Protective Earth
Terminal
Chassis Ground
Test Ground
Safety Notices and Symbols
Safety Notic e s in this Manua l:
Indicates a potentially hazardous situation or p ractice which, if n ot avoided, c ould result in
Safety Terms on the Product:
Safety Symbols on the Product:
IV MSO5000-E Performance Verification Guide
RIGOL
Max. Analog
Bandwidth
No. of Analog
Channels
No. of Channels of
Function/AWG
16 (required to pu rchase
the probe)
Document Overview
This manual is designed to guide you to properly test the performance specifications of RIGOL
MSO5000-E series digital oscilloscope. For the operation methods mentioned in the test procedures,
refer to User Guide of this product.
Main Topics in this Manual:
Chapter 1 Overview
This chapter introduces th e pre parations befo re perf orming the perfo rmance v erification tests and the
notices.
Chapter 2 Performance Verification Test
This chapter introduces the limit, test devices required as well as the test m ethod and procedures of
each performance specification.
Appendix Test Record Form
The appendix provides a test record form for users to record the test results and judge whether each
performance specification can meet the requirement.
Format Conventions in this Manual:
1. Key
The key on the front panel is denoted by the format of "Key Name (Bold) + Text Box" in the
manual. For example, Utility d enotes the "Utility" key.
2. Menu
The menu items are denoted by the format of "Menu Word (Bo ld) + Character Shading". For
example, System denotes the "System" menu item under Utility.
3. Operation Procedures:
denotes the next step of operation. For example, Utility System d enotes that first press
Utility, and then press the System softkey.
Content Conventions in this Manual:
MSO5000-E series includes the following models. Unless otherwise specified, this manual takes
MSO5152-E as an example to illustrate the test methods for the performance verification of the
MSO5000-E series.
Model
MSO5152-E 150 MHz 2 1 (option)
MSO5000-E Performance Verification Guide V
No. of Digital Channels
RIGOL Contents
Contents
Guaranty and Declaration ................................................................................................. I
General Safe ty Summary ................................................................................................ II
Safety Notic e s an d Symbols ........................................................................................... IV
Document Overview ........................................................................................................ V
Chapter 1 Overview ................................................................................................... 1-1
Test Preparations ........................................................................................................... 1-1
Self-test .................................................................................................................. 1-1
Self-calibration ........................................................................................................ 1-1
Test Result Reco r d ......................................................................................................... 1-1
Specifications ................................................................................................................ 1-1
Chapter 2 Performance Verification Test ................................................................... 2-1
Impedance Test ............................................................................................................. 2-2
Specification ........................................................................................................... 2-2
Test Connection Diagram .......................................................................................... 2-2
Test Proc edures ....................................................................................................... 2-2
Test Record Form .................................................................................................... 2-2
DC Gain Accuracy Test .................................................................................................... 2-3
Specification ........................................................................................................... 2-3
Test Connection Diagram .......................................................................................... 2-3
Test Procedures ....................................................................................................... 2-3
Te s t Record Form .................................................................................................... 2-4
Bandwidth Test .............................................................................................................. 2-5
Specification ........................................................................................................... 2-5
Test Connection Diagram .......................................................................................... 2-5
Test Proc edures ....................................................................................................... 2-5
Te s t Record Form .................................................................................................... 2-6
Bandwidth Limit Test ...................................................................................................... 2-7
Specification ........................................................................................................... 2-7
Test Connection Diagram .......................................................................................... 2-7
Test Proc edures ....................................................................................................... 2-7
Te s t Record Form .................................................................................................... 2-8
Timebase Accuracy Test .................................................................................................. 2-9
Specification ........................................................................................................... 2-9
Test Connection Diagram .......................................................................................... 2-9
Test Proc edures ....................................................................................................... 2-9
Te s t Record Form .................................................................................................. 2-10
Appendix Test Record Form ............................................................................................. 1
VI MSO5000-E Performance V erification Guide
Chapter 1 Overview RIGOL
Tip:
results in the copy so that the form can be used repeatedly.
Tip:
minutes.
Chapter 1 Overview
Test Preparations
Before performing the test, make the following preparations.
1. Self-test
2. Warm-up (make sure that the instrument has been running for at least 30 minutes)
3. Self-calibration
Self-test
When the oscilloscope is connected to power, press the Power key at the lower-left corner of the front
panel to start the oscilloscope. (You can also pre ss Utility System Power status, and select
"Switch On". After the instrument is connected to power source, it will start directly.) During the
start-up process, the oscilloscope performs a series of self-tests. After the self-test, the welcome
screen is displayed.
If the oscilloscope cannot s tart no rmally, refer to "Troubleshooting" section in
to locate the problem and resolve it. Do not perform self-calibration or performance tests until the
instrument passes the self-test.
Self-calibration
Make sure that the oscilloscope has been warmed up or operating for more than 30 minutes before
performing self-calibration.
1. Disconnect all the input channels.
2. Press Utility System SelfCal, and the press Start to execute self-calibration. The
self-calibration lasts for about 45 minutes.
3. Restart the oscilloscope, and then press Acquire Acquisition to select "Average", and then
press Averages to se t it to 16.
4. Set the vertical scale of each channel to 2 mV/div and view the offset of the waveform of each
channel. If the offset is greater than 0.5 div, check whether there are interference signals around
you and whether the power source is well grounded. If yes, perform self-calibration again.
MSO5000-E Use r Gui de
Test Result Record
Record and keep the test result of each test. In the Appendix of this manual, a test result record form
which lists all the test it ems and their correspondin g performance limits as we ll as spaces for users t o
record the test results, is provided.
It is recommended that users photocop y the test record form before each test and record the test
Specifications
The specif ication of each test item is provided in Chapt er 2. For other technical parameters, refer to
MSO5000-E DataSheet
All the specifications are only valid when the oscilloscope has been warmed up for more than 30
MSO5000-E Performance Verification Guide 1-1
(available to download them from RIGOL website: http://www.rigol.com)
Chapter 2 Performance Verification Test Overview RIGOL
2-1
Recommended
Model
DC output voltage range:
Fast edge signal rise time: ≤ 150 ps
Chapter 2 Performance Verification Test
This chapter takes MSO5152-E as an example to illustrate the performance verification test methods
and procedures o f MSO5000-E series digital oscilloscope. Fluke 9500B is used in this manual for the
tests. You can also use other devices that fulfill the "Specification" in Table 2-1.
Table 2-1 Test Devices Required
Device Specification
Oscilloscope
Calibrator
Note:
1. Make sure that the oscilloscope passes the self-test and self-calibration before executing the
performance verification tests.
2. Make sure that the oscilloscope has bee n warmed u p for at lea st 30 minutes before exe cuting an y
of the following tests.
3. Please reset the instrument to the factory setting before or after executing any of the following
tests.
1 MΩ: 1 mV to 200 V
50 Ω: 1 mV to 5 V
Fluke 9500B
MSO5000-E Performance Verification Guide
RIGOL Chapter 2 Performance Verification Test Overview
Input Impedance
Channel
Vertical Scale
Test Result
Limit
Pass/Fail
100 mV/div
500 mV/div
100 mV/div
500 mV/div
Fluke 9500B
MSO5000-E
Impedance Test
Specification
Analog Channel 1 MΩ: 0.99 MΩ to 1.01 MΩ
Test Connection Di ag ram
Figure 2-1 Impedance Test Connection Diagram
Test Procedures
1. Connect the active he ad of Fluke 9500B to CH1 of th e oscilloscope, as sh own in the figure above.
2. Configure the oscilloscope:
1) Press 1 in the vertical control area (Vertical) on the front panel to enable CH1.
2) Press 1 Impedance to set the input impedance of CH1 to 1 MΩ.
3) Set the vertical scale of CH1 to 100 mV/div.
3. Turn on Fluke 9500B; set its impedance to 1 MΩ and select the resistance measurement function.
Read and record the resistance measured.
4. Adjust the vertical scale of CH1 of the oscillosco pe to 500 mV/di v; rea d and rec ord the resist ance
measured.
5. Turn off CH1. Measure the resistance of CH2 using the method above and record the
measurement results.
Test Record Form
CH1
CH2
2-2 MSO5000-E Performance Verification Guide
0.99 MΩ to 1.01 MΩ
Chapter 2 Performance Verification Test Overview RIGOL
DC Gain Accuracy
Specification
±3% of Full Scale
[1]
Fluke 9500B
MSO5000-E
DC Gain Accuracy Test
Specification
[1]
Note
setting. For vertical accuracy calcula tions, use full sc ale of 32 mV for 500 uV/div1, 1 mV/div, and 2 mV/div vertical
sensitivity setting.
Test Connection Di ag ram
Test Procedures
1. Connect the active he ad of Fluke 9500B to CH1 of th e oscilloscope, as sh own in the figure above.
2. Set the impedance of Fluke 9500B to 1 MΩ.
3. Output a DC signal with +3 mV
4. Configure the oscilloscope:
5. Press Measure Add Category to select "Vertical". Then, select "Vavg" measurement
6. Adjust Fluke 9500B to make it output a DC signal with -3 mV
7. Enable the average measurement function. Read and record Vavg2.
8. Calculate the relative error of this vertical scale: |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full
9. Keep the other settings of the oscilloscope unchanged.
: Full scale = 8 × Current Vertical Scale. 500 uV/div1, 1 mV/div, and 2 mV/div are a magnification of 4 mV/div
Figure 2-2 DC Gain Accuracy Test Connection Diagram
voltage (Vout1) via Fluke 9500B.
DC
1) Press 1 in the vertical control area (Vertical) on the front panel to enable CH1.
2) Press 1 Attenuation to set the probe attenuation ratio to "1X".
3) Press 1 Impedance to set the input impedance of CH1 to 1 MΩ.
4) Set the vertical scale to 1 mV/div.
5) Set the horizontal timebase to 1 μs/div.
6) Set the vertical offset to 0.
7) Press Acquire Acquisition to select "Average", a nd then press Averages to set it to 32.
8) Adjust the trigger level to avoid that the signals are being triggered by mistake.
parameter to enable the average measurement function. Read and record Vavg1.
voltage (Vout2).
DC
Scale × 100%.
1) Set the vertic al scale to 500 uV/div, 2 mV/div, 5 mV/div, 10 mV/div, 20 mV/div, 50 mV/div,
100 mV/div, 200 mV/div, 500 mV/div, 1 V/div, 2 V/div, 5 V/div, and 10 V/div respectiv e l y.
2) Adjust the output voltage of Fluke 9500B to 3 × the current vertical scale and -3 × the
MSO5000-E Performance Verification Guide 2-3
RIGOL Chapter 2 Performance Verification Test Overview
Test Result
Calculation
Result
500 uV/div
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
500 uV/div
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
current vertical scale respectively.
3) Repeat Step 3-7 and record the test results.
4) Calculate the relative error of each vertical scale: |(Vavg1 - Vavg2) - (Vout1 -
Vout2)|/Full Scale × 100%.
10. Turn off CH1. Test the relative error of ea ch scale of CH2 using the method above and record the
test results.
Test Record Form
Channel
CH1
Vertical
Scale
Vavg1 Vavg2
[1]
Limit Pass/Fail
≤3%
CH2
[1]
Note
are 3 × the current vertical scale and -3 × the current vertical scale respectively.
: The calculation formula is |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full Scale × 100%; wherein, Vout1 and Vout2
2-4 MSO5000-E Performance Verification Guide
Chapter 2 Performance Verification Test Overview RIGOL
Bandwidth
Amplitude Loss
[1]
150 MHz
-3 dB, all-channel mode
Model
Full Bandwidth
Horizontal Timebase
MSO5152-E
150 MHz
5 ns/div
Fluke 9500B
MSO5000-E
Bandwidth Test
The bandwidth test verifies the bandwidth performance of the oscilloscope by testing the amplitude
loss of the oscilloscope under test at full bandwidth.
Specification
[1]
Note
effective value at 1 MHz and Vrms2 is the measurement result of amplitude effective value at full bandwidth.
Test Connection Di ag ram
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrm s1); wherein, Vrms1 is th e measurement result of amplitude
Figure 2-3 Bandwidth Test Connection Diagram
Test Procedures
1. Connect the active he ad of Fluke 9500B to CH1 of th e oscilloscope, as sh own in the figure above.
2. Turn on Fluke 9500B; set its impedanc e t o 1 MΩ.
3. Configure the oscilloscope:
1) Press 1 in the vertical control area (Ver tical) on the front panel to enable CH1.
2) Press 1 Attenuation to set the probe attenuation ratio to "1X".
3) Press 1 Impedance to set the input impedance of CH1 to 1 MΩ.
4) Set the horizontal timebase to 500 ns/div.
5) Set the vertical scale to 100 mV/div.
6) Set the horizontal position and vertical offset to 0.
7) Set the trigger level to 0 V.
4. Output a Sine with 1 MHz frequency and 600 mVpp amplitude via Fluke 9500B.
5. Press Measure Add Category to select "Vertical". Then, select "VRMS" measurement
parameter to enable the effective value measurement function. Read and record Vrms1.
6. Output a Sine with 150 MHz frequency (the setting value is different for different models of the
oscilloscope under test; please refer to Table 2-2) and 600 mVpp amplitude via Fluke 9500B.
Table 2-2 Setting Value of the Oscilloscope under Test
7. Set the horizontal timebase to 5 ns/div (the setting value is different for different models of the
oscilloscope under test; please refer to Table 2-2).
MSO5000-E Performance Verification Guide 2-5
RIGOL Chapter 2 Performance Verification Test Overview
Test Result
Amplitude
Loss
100 mV/div
500 mV/div
100 mV/div
500 mV/div
8. Enable the effective value measurement function. Read and record Vrms2.
9. Calculate the amplitude loss: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
10. Keep the other settings of the oscilloscope in Step 3 unchanged and set the vertical scale to 500
mV/div.
11. Output a Sine with 1 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
12. Repeat Step 5.
13. Output a Sine with 150 MHz frequency (the setting value is different for different models of the
oscilloscope under test; please refer to Table 2-2) and 3 Vpp amplitude via Fluke 9500B.
14. Repeat Step 7-9.
15. Turn off CH1. Test CH2 using the method above respectively and record the test results.
Test Record Form
Channel
CH1
CH2
[1]
Note
Vertical
Scale
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
Vrms1 Vrms2
[1]
Limit Pass/Fail
-3 dB to 3 dB
2-6 MSO5000-E Performance Verification Guide
Chapter 2 Performance Verification Test Overview RIGOL
Input Impedance of the Oscilloscope
Available Bandwidth Limit
1 MΩ
20 MHz
Bandwidth Limit
Amplitude Loss
[1]
-3 dB, all-channel mode
Fluke 9500B
MSO5000-E
Bandwidth Limit Test
The bandwidth limit test v erifies the 20 MHz bandwidth limit functi on of the oscilloscope by t esting the
amplitude losses of the oscilloscope under test at the bandwidth limits.
Table 2-3 Bandwidth Limit
Specification
[1]
Note
effective value at 1 MHz and Vrms2 is the measurement result of amplitude effective value at the bandwidth limit.
Test Connection Di ag ram
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrm s1); wherein, Vrms1 is th e measurement result of amplitude
Figure 2-4 Bandwidth Limit Test Connection Diagram
Test Procedures
1. Connect the active he ad of Fluke 9500B to CH1 of the oscilloscope, as sh own in the figure above.
2. Turn on Fluke 9500B; set its impedance to 1 MΩ.
3. Configure the oscilloscope:
1) Press 1 in the vertical control area (Vertical) on the front panel to enable CH1.
2) Press 1 Attenuation to set the probe attenuation ratio to "1X".
3) Press 1 Impedance to set the input impedance to 1 MΩ.
4) Set the vertical scale to 100 mV/div.
5) Set the horizontal timebase to 500 ns/div.
6) Set the horizontal position and vertical offset to 0.
7) Set the trigger level to 0 V.
4. Output a Sine with 1 MHz frequency and 600 mVpp amplitude via Fluke 9500B.
5. Press Measure Add Category to select "Vertical". Then, select "VRMS" measurement
parameter to enable the effective value measurement function. Read and record Vrms1.
6. Press 1 BW Limit to set the bandwidth limit to "20 M".
7. Output a Sine with 20 MHz frequency and 600 mVpp amplitude via Fluke 9500B.
8. Set the horizontal timebase to 20 ns/div.
9. Enable the effective value measurement function. Read and record Vrms2.
MSO5000-E Performance Verification Guide 2-7
RIGOL Chapter 2 Performance Verification Test Overview
Test Result
Amplitude
Loss
100 mV/div
500 mV/div
100 mV/div
500 mV/div
10. Calculate the amplitude l oss: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1), and co mpa re
the result with the specification. At this point, the amplitude loss should be within the
specification range.
11. Keep the other settings of the oscilloscope in Step 3 unchanged and set the vertical scale to 500
mV/div.
12. Output a Sine with 1 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
13. Repeat Step 5.
14. Output a Sine with 20 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
15. Repeat Step 8-10.
16. Turn off CH1. Test CH2 using the method above respectively.
Test Record Form
20 MHz bandw idth limit tes t
Channel
CH1
CH2
[1]
Note
Vertical
Scale
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
Vrms1 Vrms2
[1]
Limit Pass/Fail
-3 dB to 3 dB
2-8 MSO5000-E Performance Verification Guide
Chapter 2 Performance Verification Test Overview RIGOL
Timebase Accuracy
[1]
Specification
≤ ±(10 ppm + Clock Drift
[2]
× Number of years that the instrument has been
used
Fluke 9500B
MSO5000-E
Timebase Accuracy Test
Specification
[3]
[1]
Note
Note
Note
verification certificate provided when the instrument leaves factory.
: Typical.
[2]
: Clock drift≤ ±10 ppm/year.
[3]
: For the number of years that t he instrument h as been use d, please calc ulate acc ording to the dat e in the
Test Connection Di ag ram
）
Figure 2-5 Timebase Accuracy Test Connection Diagram
Test Procedures
1. Connect the active he ad of Fluke 9500B to CH1 of th e oscilloscope, as sh own in the figure above.
2. Turn on Fluke 9500B; set its impedanc e t o 1 MΩ.
3. Output a Sine with 10 MHz frequency and 1 Vpp amplitude via Fluke 9500B.
4. Configure the oscilloscope:
1) Press 1 in the vertical control area (V e rtical) on the front panel to enable CH1.
2) Press 1 Attenuation to set the probe attenuation ratio to "1X".
3) Press 1 Impedance to set the input impedance to 1 MΩ.
4) Set the vertical scale to 50 mV/div.
5) Set the vertical offset to 0.
6) Set the horizontal timebase to 1 ns/div.
7) Set the horizontal position to 1 ms.
5. Observe the screen of the oscilloscope. Press Cursor Mode, then select "Manual" to enable
the manual mode of cursor measurement. Measure the offset (ΔT) of the middle point of the
signal (namely the crossing point of the rising edge of the current signal and the tri gger level line )
relative to the screen center using manual cursor measurement and record the measurement
result.
6. Calculate the timebase accuracy; namely the ratio of ΔT to the horizontal position of the
oscilloscope. For example, if the offset measured is 1 ns, then the timebase accuracy is 1 ns/1
ms=1 ppm.
7. Calculate the time base accur acy limit b y using the formula ± (10 ppm + 10 ppm/year × Number of
years that the instrument has been used).
MSO5000-E Performance Verification Guide 2-9
RIGOL Chapter 2 Performance Verification Test Overview
Test Result
ΔT
Calculation
Result
±(10 ppm + 10 ppm/year × Number of
used
)
Test Record Form
Channel
CH1
[1]
Note
Note
verification certificate provided when the instrument leaves factory.
: Calculation Result = T est Result ΔT/1 ms.
[2]
: For the number of years that t he instrument h as been use d, please calc ulate acc ording to the dat e in the
[1]
years that the instrument has been
Limit Pass/Fail
[2]
2-10 MSO5000-E Performance Verification Guide
Appendix Test Record Form RIGOL
1
Model:
Tested by:
Test D a te:
Channel
Vertical Scale
Test Result
Limit
Pass/Fail
100 mV/div
500 mV/div
100 mV/div
500 mV/div
Test Result
Calculation
Result
500 uV/div
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
500 uV/div
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
2 V/div
5 V/div
10 V/div
Appendix Test Record Form
RIGOL MSO5000-E Series Digital Oscilloscope Performance Verification Test Record Form
Impedance Test
CH1
0.99 MΩ to 1.01 MΩ
CH2
DC Gain Accuracy Test
Channel
CH1
CH2
Vertical
Scale
Vavg1 Vavg2
[1]
Limit Pass/Fail
≤3%
[1]
Note
are 3 × the current vertical scale and -3 × the current vertical scale respectively .
MSO5000-E Performance Verification Guide
: The calculation formula is |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full Scale × 100%; wherein, Vout1 and Vout2
RIGOL Appendix Test Record Form
Test Result
Amplitude
Loss
100 mV/div
500 mV/div
100 mV/div
500 mV/div
Test Result
Amplitude
Loss
100 mV/div
500 mV/div
100 mV/div
500 mV/div
Calculation
Result
±(10 ppm + 10 ppm/year × Number of years
that the instrument has been used
)
Bandwidth Test
Channel
CH1
CH2
[1]
Note
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
Vertical
Scale
Vrms1 Vrms2
Bandwidth Limit Test
20 MHz bandw idth limit tes t
Channel
Vertical
Scale
Vrms1 Vrms2
CH1
CH2
[1]
Note
: Amplitude Loss (dB) = 20 × lg (Vrms2/Vrms1).
Timebase Accuracy Test
[1]
[1]
Limit Pass/Fail
-3 dB to 3 dB
Limit Pass/Fail
-3 dB to 3 dB
Channel Test Result ΔT
CH1
[1]
Note
Note
verification certificate provided when the instrument leaves factory.
: Calculation Result = T est Result ΔT/1 ms.
[2]
: For the number of years that t he instrument h as been use d, please calc ulate acc ording to the dat e in the
[1]
Limit Pass/Fail
[2]
2 MSO5000-E Performance Verification Guide
