DSA800E
DSA800E Series Spectrum Analyzer
General Inspection
1. Inspect the shipping container for damage
If your shipping container appears to be damaged, keep
the shipping container or cushioning material until you
have inspected the contents of the shipment for
completeness and have checked the instrument
electrically and mechanically. If your instrument has been
damaged during shipping, please contact your shipper and
carrier for compensation. RIGOL will provide no free
repair or replacement.
2. Inspect the instrument
If there is any mechanical damage or defect, or if the
instrument does not pass electrical and mechanical tests,
please contact your RIGOL sales representative.
3. Check the accessories
Please check the accessories according to the packing lists.
If the accessories are incomplete or damaged, please
contact your RIGOL sales representative.
-6-
General Safety Summary
1. Use power cords designed for the instrument and
authorized by local country.
2. Make sure the instrument is grounded properly.
3. Do not operate without covers.
4. Use proper fuse.
5. Avoid circuit or wire exposure.
6. Do not operate with suspected failures.
7. Keep proper ventilation.
8. Do not operate in wet conditions.
9. Do not operate in flammable and explosive environment.
10. Keep product surface clean and dry.
11. Protect the instrument from static electricity.
12. Pay attention to handling saf ety.
-7-
Preset LCD Menu Softkeys/Menu Control Keys Function Keys Knob
Print
Direction
Numeric
Product Overview
Featuring light weight, compact structure, low cost, and high
performance, DSA800E series spectrum analyzers are portable
spectrum analyzers designed for starters. It includes DSA832E
one model. Configured with easy-to-operate keyboard,
high-resolution color LCD display and various remote
communication interfaces, they can be widely used in various
fields, such as education, company research and development
as well as industrial manufacture.
Keys
Help
Keyboard
Power Switch USB Host Earphone Jack TG Output RF Input
USB Device
LAN
TRIGGER IN
10MHz OUT
10MHz IN
AC Connector Fuse Seat Handle Security Lock Hole
-8-
CAUTION
grounded to avoid electric shock.
Unfold the Supporting Legs
To Adjust the Supporting Legs
Users can unfold the supporting legs to use them as stands to
tilt the instrument upwards for easier operation and observation.
Users can also fold the supporting legs when the instrument is
not in use for easier storage or shipment.
Fold the Supporting Legs
To Connect Power
Connect the spectrum analyzer to AC power source using the
power cord supplied with the accessories. DSA800E supports
100 V - 240 V, 45 Hz - 440 Hz AC power source and 5 mm×20
mm, 250V AC, T2A fuse.
Make sure that the instrument is properly
Start-up and Self-calibration
After connecting the instrument to power source correctly, press
at the front panel to start the spectrum analyzer. You can
obtain information about the start-up initialization process
through the start-up progress indications. Following the start-up
screen, the sweep curve is displayed. Press System
Calibrate Cal Now and the instrument will perform
self-calibration using the internal calibration source (for more
information, refer to the
DSA800E Series User’s Guide
-9-
).
CAUTION
reverse DC voltage cannot exceed 50 V.
CAUTION
respectively.
Using Notices
1. To use the tracking generator output terminal:
To avoid damage to the tracking
2. To use the RF input terminal:
generator, the reverse power cannot
exceed +10 dBm when the frequency
less than 10 MHz; the reverse power
cannot exceed +20 dBm when the
frequency more than 10 MHz. The
To avoid damage to the instrument,
for the signal input from the RF input
terminal, the DC voltage component
and the maximum continuous power
of the AC (RF) signal component
cannot exceed 50 V and +20 dBm
Remote Control Overview
DSA800E supports communication with PC via USB, LAN or GPIB
(option) interfa ce for remote control. The remote control is
realized on the basis of SCPI (Standard Commands for
Programmable Instruments) command set through two ways:
user-defined programming and PC software (such as RIGOL
Ultra Sigma). When the instrument is in remote mode, the
icon is displayed in the user interface and the front
panel keys (except Esc) are locked. At this point, you can press
Esc to exit remote mode.
-10-
For More Product Information
You can ob tain t he ins tr ument inform a ti on including model,
serial number as well as har d war e an d so f twar e ver sio n
numbers through System Information System Info.
You can also view the list of installed options through System
License. For more information of this product, please refer
to the following manuals (you can download them from the
RIGOL network):
DSA800E Series User’s Guide
of the functions of this product;
DSA800E Series Programming Guide
introductions of the SCPI commands and progra mm ing of this
product;
DSA800E Series Datasheet
and specifications of this product;
DSA800E Series Accessories and Options
introductions of the accessories and options of this product.
: provide detailed introductions
: provide detailed
: provide the main characteristics
: provide detailed
