RIGE TECHNOLOGY CO., LIMITED
- 1 -
DMX 300W BEAM MOVING HEAD
User manual
RG
RGRG
RG----M10
M10M10
M10
RIGE TECHNOLOGY CO., LIMITED
- 2 -
Congratulations on purchasing this 300W BEAM moving head.
Thank you for extending your trust in our technology!
For reasons of safety and approval (CE) the personal reconstruction and/or modification of this product is
prohibited. Please observe that damage caused by modifications performed manually to this device is not
covered by the warranty.
This product leaves our works in a perfect condition. Please observe all notes in these operating
instructions to warrant this condition and the safe operation of the product!
Any damage caused as a result of the non-compliance with these operating instructions leads to the
expiration of any warranty claim. The manufacturer does not accept liability for any damage to property or
for personal injury resulting from the improper handling of the product, or non-observance of the operating
instructions.
Store these operating instructions in a safe place for later reference and pass them to any new holder when
selling or lending or leaving this device in the hands of any other party.
Application According to Purpose
This product is a lighting effect which creates special light effects with one lamp. To generate these effects,
the product must be connected to mains and a DMX-512 compatible controller.
This product is designed for 220V, 50Hz A/C operation and exclusively for indoor use.
If used for any purpose other than described in these operating instructions, the device may suffer damage
and the warranty expires. Also, any other use is linked with risks such as short circuits, fire, electrical shock,
etc.
The manufacturer's serial number must never be removed as otherwise the warranty expires.
1. Before Operation
ATTENTION:
DANGER OF LIFE! RISK OF FIRE!
RISK OF SHORT CIRCUIT!
Prior to the initial operation of this product, please do the followings
- Read these operating instructions with great care;
- Study and observe all instructions carefully;
- Ensure that everybody and anybody involved in the installation, operation, transport and storage of this
product is suitably qualified;
- Verify whether any visible damage was caused during transport. If the power cord, housing or the light
are damaged, do not operate the device; contact your specialized dealer immediately.
RIGE TECHNOLOGY CO., LIMITED
- 3 -
2. Suppl
y Voltage, Mains Cord and Connection to Mains
ATTENTION:
DANGER OF LIFE!
RISK OF FIRE! RISK OF SHORT CIRCUIT!
The handling of supply voltage, mains cords and connections to mains calls for particular care considering
the risk from a life-threatening electric shock, the risk of fire and the risk of short circuits! Please observe the
following notes in particular:
Products operating on supply voltage should be kept out of the reach of children. Therefore ensure the
permanent supervision if children are in the immediate vicinity of the product!
For commercial facilities the regulations on the prevention of accidents of the respective trade association
must be observed. The operation of this equipment at schools, training facilities, and hobby or self-help
workshops must be supervised responsibly by trained personnel.
Check the product regularly for any damage to the mains cord! Should you discover any damage to the
mains cord, do not operate or disconnect this product! Secure the product against accidental operation and
contact your specialized dealer!
Always separate the product from mains by holding the mains plug by the handling surface. Never
disconnect by holding the line cord! Be sure to connect the product exclusively to 230 V, 60 Hz A/C!
Always ensure during installation, operation, transport and when storing the product that the mains cord is
not exposed to possible mechanical damage, or damage caused by humidity, fluids, heat or cold!
The product's cable entry must not be exposed to stress from pull! Create the mains connection once the
product has been installed only. Always connect the mains plug last!
The product must only be connected to a proper outlet of the public supply grid. Connect the mains cord to
suitable outlets only! Use extensions cords in compliance with specifications only! Do not allow the mains
cord to come into contact with other cords!
Ensure during installation, operation, transport and storage that none of the cables are freely exposed!
Never touch the mains cord, mains plug and outlets with wet or damp hands!
When not using the product, and prior to cleaning always disconnect the product from mains! To do so, hold
the mains plug by the handling surface and never pull the mains cord!
Never connect the device to dimmer packs!
3. Housing
ATTENTION:
DANGER OF LIFE! RISK OF BURNS!
RISK OF FIRE! RISK OF SHORT CIRCUIT!
Always ensure during installation, operation, transport and when storing the product that no shocks or other
forces impact the housing!
The housing must not touch onto any other devices or objects during operation!
RIGE TECHNOLOGY CO., LIMITED
- 4 -
Easily flammable materials, e.g. decoration material and other surfaces and objects, must maintain a
minimum distance of 3m to the housing! Walls must maintain a minimum distance of 50cm to the housing!
The device must be installed on a fireproof surface only (no carpet)! Always ensure a proper circulation of
air.
Do not touch the housing during operation - it will heat up. The housing is safe to touch approx. 5 minutes
following the end of operation!
The device must never be carried via the projector arms. Use the carrying handles only!
Fluids must not enter the housing as this could reduce the protective insulation and may trigger short
circuits which may lead to fatal electric shocks! If fluids have entered, disconnect the mains plug
immediately and secure the product against unintentional operation and contact your specialized dealer!
Damage caused as a result of fluids entering the housing is exempt from warranty.
No metal parts or other items must enter the housing as this may reduce the protective insulation or trigger
short circuits which may lead to fatal electric shocks! If metal parts or other items have entered, disconnect
the mains plug immediately, secure the product against unintentional operation and contact your
specialized dealer! Damage caused by metal parts or other items in the housing is exempt from warranty.
4. Operating Environment
ATTENTION:
DANGER OF LIFE! RISK OF BURNS!
RISK OF FIRE! RISK OF SHORT CIRCUIT!
The product must be operated and stored in a dry environment only! Splash water, rain, humidity, fog may
reduce the protective insulation which may lead to fatal electric shocks! The limit value for relative humidity
is 50% at 45°C. A minimum distance of 1.5m to a fog machine must be observed; fog saturation in the room
must not reduce the visibility to below 10m.
The product must be operated at a temperature range of between -5 °C and 45 °C only. Protect the product
against direct exposure to sunlight or other heat, such as from radiators! If the product is taken from a cold
environment into a warm environment it must only be taken into operation once it has reached ambient
temperature, since the condensation created by the difference in temperature may destroy the device!
Protect the product against dust! Dust may reduce the protective insulation, which may cause fatal electric
shocks!
The product must be operated at altitudes ranging between 20m below and 3000m above sea level only!
The product must not be operated during thunder storms; risk of destruction from surge voltages!
The product must be operated at a minimum distance of 1.5 m to lit objects only!
5. Installation
ATTENTION:
DANGER OF LIFE!
RIGE TECHNOLOGY CO., LIMITED
- 5 -
This product can be operated suspended or as a stand-alone system.
Should your lighting effect show any signs of damage, do not install the device! In this case, have your
lighting effect repaired by your specialized dealer. It does not accept responsibility or liability for damage to
property or personal injury resulting from an improperly installation!
As a stand-alone system the device must be installed vertically on an absolute planar, firm, fireproof, shock-
and vibration-free surface. The installation of this lighting effect must be carried out by trained and
professional staff! The installation of this lighting must only be carried out with the appropriate materials!
The suspended installation of this lighting effect necessitates a suitable suspension system! The lighting
effect must never be fixed swinging freely in the room. No individuals should linger underneath the lighting
effect during suspended installation!
It is a must to install this device with a second independent fixture. Such second fixture must guarantee in
the event of failure of the main fixture that no assembly parts will fall down. Use the fixture on the
undersurface only.
The light effect unit must be attached via two certified hooks and omega bracket to a tie-bar system. Use
the screw threads on the undersurface only.
It must be ensured that an expert inspects the mechanical and safety-relevant installation prior to the initial
operation and following major modifications, prior to the renewed operation. It must be ensured that an
expert inspects the mechanical and safety-relevant installation at least once a year. It must be ensured that
an expert inspects the mechanical installation and the installation of relevance to safety within the
framework of an acceptance test at least every four years.
The installation fixture must be as such that it can withstand for a period of 60 minutes 10 times the load
capacity without harmful deformation.
It is prohibited for any individual to unnecessarily stay or pass beneath the installation during any type of
assembly work.
The light effect unit must be secured by a safety arrester cable if fly-mounted. The cable must withstand 12
times the weight of the light effect unit. Use arrester cables equipped with quick closing links. The dropping
distance must not exceed 20 cm. Defect arrester cables or arrester cables that have already been exposed
to stress must not be used.
6. Operation
ATTENTION:
RISK OF HEALTH!
6
.1 Controls
Link all DMX devices with a DMX-512 controller by using a standard, 3-pin DMX cable. Connect the output
of the first device with the input of the second device and the output of the second device with the input of
the third device and so on.
Connect the mains plug to an outlet.
Operating the product for the first time may generate smoke and odor; this is not a defect. Avoid
RIGE TECHNOLOGY CO., LIMITED
- 6 -
dis/connecting the product repeatedly and quickly from/with mains! Always wait 15 minutes prior to the next
dis/connection!
The device starts until a self-testing and starting time. If the moving head is ready to start, push and roll the
function wheel. The LCD display shows the options, as follows:
Menu settings:
8 8 8 8
8 8 8 88 8 8 8
8 8 8 8
ESC UP DOWN ENTER
DMX512 [address set]
This feature allows the user to change device address value
1. Press the ESC key until shows "A001". Now click "UP" or "DOWN" will be the key to browse other menu.
2. Press "ENTER", the letter "A" extinguished. Use "UP" or "DOWN" button to select address value
"001-512", press "ENTER" confirmation exit or press the "ESC button" abandon exit.
DMX preset
This feature allows the user to select different control method.
1. According to "UP" or "DOWN" browse other menu.
2. Press "ENTER" , then click "UP" or "DOWN" choose "Nod. 1" or "Nod. 2", click "ENTER" sure to save exit
or press the "ESC" non-preservation exit.
Nod. 1: (mode1) the normal channel model number control
Nod. 2: (mode 2) less channel number control
To accept host synchronous (i.e. from machine model), DMX preset for "nod. 1".
Test（（（（Test Program)
This feature allows users without external controller under the state implements internal demo programs. This set
will be saved, as you do not test program start out every time will be automatically entered into test programs.
Press the "UP" or "DOWN" button will choose other mode, click "ENTER" ENTER.
1 Nod. 1 (test mode 1)
Press the "UP" or "DOWN" button will choose other mode, click "ENTER" ENTER, shows "RUN"
RIGE TECHNOLOGY CO., LIMITED
- 7 -
Test running. If need to exit, press "ESC" exit
2. Ast (mainframe controls)
This feature allows you to run the test when need be host DMX synchronized signal sent out to vice
machine use. Press the "UP" or "DOWN" choose other mode, click "ENTER" , show "ON" as host send
signals, DMX signal indicator emit light. Display "OFF" not to send out signals, DMX signal lights out, press
"ENTER" sure to save exit, press "ESC" non-preservation exit. Set to "ON" later, the user must interrupt
DMX controller connection and external cannot have two above same Settings for the host in the same way.
AUDI (sound control stimulate)
This feature allow users to use sound stimulate test programs.
1. According to "UP" or "DOWN" browse other menu.
2. Press "ENTER", then click "UP" or "DOWN" choose "ON" or "OFF" expressing test runtime whether to
use voice inspired. "ON" shows sound control, "OFF" shows no sound control mode, the automatic control.
Set the "ON", run the test program with music ADUIO signal light will shine.
R. Pan (level reversion
)
Press the "ENTER", then click "UP" or "DOWN", if need reversion, select the "ON", otherwise choose "OFF",
click "ENTER" save exit or press the "ESC" non-preservation exit.
R.til (vertical reversion
Press the "ENTER", use "UP" or "DOWN" button, if have to reversion, select the "ON", if not required, then
choose "OFF", click "ENTER" save exit or press the "ESC" non-preservation exit.
Rset (device reset
This feature allow users to reopen the device to recover for the original standard orientation. Press the
"ENTER" confirmation.
300W beam moving head Skill Specifications
Item
Technical Parameter
Power supply AC220V/50Hz
power consumption
450W
Fuse 6A
Lamp NSK 300W
DMX512 DMX512, 12 Channels
Color wheel 8 single color+ running water effect
Gobo wheel 6 rotating gobos+ white light+ Rainbow effect
Strobe
0-10 times/second，adjustable
X Pan 540o
Y Tilt 270o
LED Display ON/OFF
Protect Intelligent thermal overheating protection
RIGE TECHNOLOGY CO., LIMITED
- 8 -
Size 400*380*650mm
DMX Channels
1
X (Pan 540°)
0-255 0-540o
2
Y (Tilt 270°)
0-255 0-270o
3 Pan/Tilt Speed 0-255 X,Y spead adjustable
4 On/Off, strobe
0-255 Dimming
5 On/Off, strobe
0-255 Slow to fast, strobe
0-23 White
24-47 Red
48-71 Yellow
72-95 Blue
96-119 Green
120-143 Purple
144-167 Orange
168-191 Pink
192-225 Heating slice
6 Color
225-255 running water effect, fast to slow
0-7 White
7-13 Gobo2
13-20 Gobo3
20-26 Gobo4
26-32 Gobo5
32-36 Gobo6
36-42 Gobo7
42-156 1-7 gobo repeat shake
7 Gobo
156-255 Gobo rotation
8 (Gobo rotation) 0
0-127
128-255
Stop do not turn
Forward rotation from fast to slow
Reverse rotation from slow to fast
9 Atomizing 0-255 Atomizing effect
10
X tiny adjust (3.6°)
0-255 X tiny adjustable
11
Y tiny adjust ( 3.6°)
0-255 Y tiny adjustable
12
Reset
255
reset
RIGE TECHNOLOGY CO., LIMITED
- 9 -
7. Lamps
ATTENTION:
DANGER OF LIFE! RISK OF BURNS!
RISK OF FIRE!
During operation, the lamps will reach temperatures of up to 200°C. Touching the lamps may cause serious
burns! Objects coming into contact with the lamps during and shortly after operation may catch fire!
Disconnect the product from mains prior to installing or before changing a lamp! Allow a lamp to cool for
approx. 15 minutes before exchanging it!
Never touch a lamp with bare hands! If damaged or deformed, a lamp must be exchanged!
When exchanging the lamp be sure to use suitable lamps only. Lamps with greater performance generate
excessive heat for the product; risk of fire! Damage resulting from the use of an unsuitable lamp is exempt
from warranty!
Replace a lamp by unscrewing the fixing screws A, B and C. Then you open the housing. Remove the lamp
by unscrew the two ends of the bulb. Install a lamp by putting it into the socket and then properly fasten the
screws at its two ends. Do not use any force - this could cause serious damage to the socket as well as the
lamp! Close the compartment and tighten the screws. Adjust the lamp position by turning screws X, Y and
Z.
8. Fuse
ATTENTION:
DANGER OF LIFE!
Disconnect the product from the mains prior before changing a fuse.
Only replace the fuse by a fuse of same type and rating! An incorrect fuse could damage or destruct the
lighting effect.
Replace a fuse by levering the fuse holder cover with an appropriate screwdriver. Remove the old fuse and
place the fuse inside the holder. Replace the fuse holder and insert it.
9. Cle
aning
ATTENTION:
DANGER OF LIFE! RISK OF FIRE!
RISK OF SHORT CIRCUIT!
The product must be freed regularly from dust, other deposits and contamination as this may reduce the
protective insulation, which may lead to a fatal electric shock!
Before cleaning, always disconnect the product from mains!
This product should be cleaned with a moist cloth only; never use aggressive cleaning agents, solvents or
benzene for cleaning.
RIGE TECHNOLOGY CO., LIMITED
- 10 -
Ensure that the product is completely dry before operating it again after cleaning!
10. Transport
CAUTION:
FRAGILE!
To avoid damage caused during transport, wrap the product in its original packaging only and handle it with
great care during transport!
Please note: All information is subject to change without prior notice.
Loading...
