350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 12109100
67-70 Mustang Front MuscleBar
1 90001783 Sway Bar (Includes the following)
2 Frame bushing
2 Frame bracket
2 90000114 3” PosiLink spacer
4 90000717 PosiLink T-bushing
2 90000926 10mm 90 degree PosiLink
2 90000924 10mm straight PosiLink
1 90001092 Tube of lithium grease
2 99115003 10mm x 1.5 x 115mm (4 ½”) stud (use Loctite) In PosiLink
Hardware Kit: 99010046
4 99371005 3/8” x 1 ¼” USS bolt Frame bracket
4 99372002 3/8” USS Nylok nut Frame bracket
8 99373003 3/8” SAE flat washer Frame bracket/PosiLink
4 99112002 10mm x 1.5 Nylok nut PosiLink
PDF created with pdfFactory trial version www.pdffactory.com
12109100 Installation Instructions
*****This sway bar is designed to work with our upper StrongArms******
1. Apply lubricant to the poly
bushing, then slide it over the sway
bar.
2. Place the sway bar fame bracket
over the bushing. Bolt the sway bar
to the frame using the 3/8” x 1 ¼”
bolts, Nylok nut and flat washers
supplied.
Note: Do not tighten the frame bolts
until after the PosiLinks are installed.
3. Attach the 90 degree end of the
PosiLink to the rear tab of the upper
control arm using a 10mm Nylok nut
and a 3/8” flat washer on each side
of the tab.
PDF created with pdfFactory trial version www.pdffactory.com
4. Slide a T-bushing over the
straight end of the PosiLink, then
slide it through the sway bar.
Another T-bushing will be installed
on the bottom along with a 10mm
Nylok nut.
5. The frame bolts can now be
tightened.
6. Check sway bar and PosiLink
clearance through full suspension
travel.
7. Ensure that the PosiLinks do not
bind through full suspension travel.
