350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11314099
91-96 Impala Rear CoolRide Kit
Components:
2 90009000 Tapered sleeve air spring
2 90000059 Upper cup bracket
2 90000072 Lower cup bracket
2 90000224 Upper washer (4” diameter - may not be needed)
Hardware:
2 99435003 7/16” x 2” stud Cup bracket to frame
2 99433002 7/16” flat washer Cup bracket to frame
2 99432001 7/16” Nylok nut Cup bracket to frame
6 99371001 3/8” x 3/4" USS bolt Air spring mounting
6 99373003 3/8” SAE washer Air spring mounting
6 99373005 3/8” lock washer Air spring mounting
1. Jack up rear of vehicle and support with jackstand under the frame.
2. Remove lower shock absorber bolts. Doing this one side at a time prevents chasing the axle
around under the car.
3. By pushing rearend down slightly, you should be able to remove the coilsprings.
4. Assemble the upper bracket and lower brackets onto the airspring. The upper bracket will have a
slot for airline access. When installing the fitting, be sure it is pointed towards this slot.
5. The supplied center stud should be inserted into the nut that is welded to the inside of the upper
bracket. This will attach the upper bracket to the upper coilspring cup. It may be trimmed to correct
length.
6. Insert the stud through the existing hole in the coilspring pocket. Tighten the nut on the center stud
to 15 -20 ft/lb. The lower bracket will sit on the old coilspring mount with no other attachment.
7. Re-attach the shock absorbers and route the airlines.
If you have any questions concerning the air ride system, please don’t hesitate to call us. We want to
insure that your installation is done as safely as possible, and that it will be reliable for years to come.
AIR RIDE TECHNOLOGIES 812.482.2932
Upper
Washer
Airline
Frame
Airspring
Airspring
Plate
Axle Tube
Lower
Washer
