PARTS CATALOG
INTRODUCTION
This chapter instructs you the numbers and names of parts on this machine.
INDEX to PARTS CATALOG
LOCATION OF UNIT............................................................... 2
1.EXTERIOR (B302)............................................................... 6
2.STAPLE TRAY 1 (B302)...................................................... 8
3.STAPLE TRAY 2 (B302)...................................................... 10
4.STAPLE TRAY 3 (B302)...................................................... 12
5.STAPLE TRAY 4 (B302)...................................................... 14
6.STAPLER UNIT (B302)....................................................... 16
7.STAPLE TRANSPORT 1 (B302)......................................... 18
8.STAPLE TRANSPORT 2 (B302)......................................... 20
9.STAPLE TRANSPORT 3 (B302)......................................... 22
10.STAPLE TRANSPORT 4 (B302)........................................ 24
11.TRANSPORT SECTION 1 (B302)...................................... 26
12.TRANSPORT SECTION 2 (B302)...................................... 28
13.PAPER EXIT SECTION 1 (B302)....................................... 30
14.PAPER EXIT SECTION 2 (B302)....................................... 32
15.PAPER EXIT SECTION 3 (B302)....................................... 34
16.DRIVE SECTION (B302).................................................... 36
17.ELECTRICAL SECTION (B302)......................................... 38
18.FRAME SECTION 1 (B302) ............................................... 40
19.FRAME SECTION 2 (B302) ............................................... 42
20.DECAL AND DOCUMENT (B302)..................................... 44
PARTS INDEX ........................................................................ 49
December, 1 ’99
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg4.png)
LOCATION OF UNIT
7.STAPLE TRANSPORT 1 (B302)
See Page 19
10.STAPLE TRANSPORT 4 (B302)
8.STAPLE TRANSPORT 2 (B302)
See Page 21
11.TRANSPORT SECTION 1 (B302)
9.STAPLE TRANSPORT 3 (B302)
See Page 23
12.TRANSPORT SECTION 2 (B302)
See Page 25
See Page 27
3
See Page 29
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg5.png)
LOCATION OF UNIT
13.PAPER EXIT SECTION 1 (B302)
See Page 31
16.DRIVE SECTION (B302)
14.PAPER EXIT SECTION 2 (B302)
See Page 33
17.ELECTRICAL SECTION (B302)
15.PAPER EXIT SECTION 3 (B302)
See Page 35
18.FRAME SECTION 1 (B302)
See Page 37
See Page 39
4
See Page 41
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg6.png)
LOCATION OF UNIT
19.FRAME SECTION 2 (B302)
See Page 43
20.DECAL AND DOCUMENT (B302)
See Page 47
99.PARTS INDEX
See Page 49
5
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg8.png)
1.EXTERIOR (B302)
Index
No.
1 B302 6211 Rear Cover 1
2 B302 6131 Upper Tray 1
3 B302 6115 Tray Stopper 1
4 B302 6141 Slide Tray 1
5 B302 6451 Table 1
6 B302 6251 Upper Tray Lever 1
7 B302 6261 Upper Cover 1
8 A697 6111 Rear Cover - Shift Tray 1
9 A666 2421 Sub - Shift Tray 1
10 A697 3031 Shift Tray 1
11 B302 6311 Left Lower Cover 1
12 A697 6101 Front Cover - Shift Tray 1
13 B302 6351 Left Inner Cover 1
14 B302 6611 Inner Cover 1
15 B302 7020 Front Door 1
16 B302 7722 Decal - Misfeed Staple Removal 1
17 B302 7721 Decal - Misfeed Paper Removal 1
18 A606 1595 Small Door Cover 1
19 B302 6161 Magnet Catch Plate 1
20 B302 6155 Upper Hinge - Front Door 1
21 A077 4162 Shoulder Screw - M3 3
22 A697 1153 Front Joint Bracket 1
23 A697 1144 Rear Joint Bracket 1
24 B302 7531 Cushion -10x15x585 1
25 B302 6116 Cover Cushion 1
26 B302 6135 Spring - 23x44mm 1
27 B302 6121 Upper Cover 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3008B Tapping Screw - M3x8
102 0451 3008H Tapping Screw - M3x8
103 0452 4008B Binding Self Tapping Screw - M4x8
104 0451 3006B Tapping Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
7
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bga.png)
2.STAPLE TRAY 1 (B302)
Index
No.
1 B302 6651 Inner Cover - Staple Tray 1
2 B302 4273 Stapler Unit Knob 1
3 B302 4155 Timing Belt - 153P3M6 1
4 B302 7008 Cover - Stapler Unit Drive 1
5 B302 7709 Decal - R9 1
6 B302 7708 Decal - R8 1
7 B302 7007 Staple Tray Grip 1
8 B302 7707 Decal - R7 1
9 B302 4151 Stack Plate Shaft 2
10 B302 4911 Right Stay 1
11 AX04 0120 Stepped Motor - DC 9.0W 1
12 B302 4121 Bracket - Stack Plate Motor 1
13 AW02 0086 Photointerruptor 1
14 B302 4131 Stack Plate Cover 1
15 B302 4155 Timing Belt - 153P3M6 1
16 B302 4141 Stack Plate Wheel 1
17 B302 4142 Stack Plate Guide 1
18 B302 4113 Bushing - 6x9mm 1
19 B302 4112 Bushing - 6mm 1
20 B302 4153 Spring - 3x29mm 2
21 B302 4115 Stack Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3008B Tapping Screw - M3x8
102 0451 3006B Tapping Screw - M3x6
103 0720 0040B Retaining Ring - M4
104 1105 0199 Clamp
105 0451 3010B Tapping Screw - M3x10
Part No.
Description
Q’ty Per
Assembly
9
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bgc.png)
3.STAPLE TRAY 2 (B302)
Index
No.
1 AX05 0148 Stepped Motor - DC 8.0W 1
2 B302 4751 Jogger Motor Bracket 1
3 A300 3634 Spring Plate - Timing Belt 2
4 B302 4756 Timing Belt - 753P3M6 1
5 AB03 0278 Idler - 20z 1
6 A697 1125 Stepped Screw - Lever 1
7 5442 4121 Spring - Oil Blade 1
8 B302 4766 Tightener 1
9 B302 4746 Middle Stay - Staple Unit 1
10 A666 3220 Tightener - Timing Belt 1
11 5201 2722 Bushing - M6x5 2
12 B302 4611 Front Jogger Fence 1
13 B302 4629 Guide Mylar 2
14 B302 4711 Paper Feed Guide 1
15 B302 4721 Paper Guide - Positioning Roller 1
16 B302 4617 Jogger Fence Slider 2
17 B302 4619 Jogger Fence Shaft 2
18 AW01 0076 Photosensor - PS-117D1 1
19 B302 4621 Rear Jogger Fence 1
20 B302 4736 Upper Stay - Staple Unit 1
21 AW02 0086 Photointerruptor 1
22 B302 5370 Sensor Harness - Staple Tray 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 0313 0040B Philips Pan Head Screw - M3x4
103 1105 0229 Clamp
104 0450 3008B Tapping Screw - M3x8
105 0720 0060B Retaining Ring - M6
106 0720 0040B Retaining Ring - M4
107 0451 3010B Tapping Screw - M3x10
108 1105 0199 Clamp
Part No.
Description
Q’ty Per
Assembly
11
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bge.png)
4.STAPLE TRAY 3 (B302)
Index
No.
1 B302 4515 Front Slide Holder 2
2 A300 3759 Spring 3
3 B302 4538 Bushing - 6x12x5 3
4 B302 4511 Front Positiong Fence 1
5 B302 4521 Middle Positioning Fence 1
6 B302 4517 Mylar Guide 2
7 B302 4239 Guide Roller 1
8 B302 4531 Rear Positioning Fence 1
9 B302 4742 Bracket - Slide Holder Shaft 1
10 B302 4541 Front Shaft - Slide Holder 1
11 B302 4741 Lower Stay - Staple Unit 1
12 B302 4772 Timing Belt - 898P2M14 1
13 A666 3180 Timing Pulley - Z32 2
14 B302 4726 Bracket - Feed-out Belt Sensor 1
15 AW02 0049 Photointerruptor - OS - 580213-703 1
16 B302 5370 Sensor Harness - Staple Tray 1
17 A353 2763 Washer - M5 1
18 B302 4771 Paper Exit Pawl 1
19 B302 4731 Lower Exit Shaft 1
20 B302 4716 Upper Exit Shaft 1
21 B302 4542 Rear Shaft - Slide Holder 1
22 AX05 0110 Stepping Motor - 2.4V 7.2W 1
23 B302 4423 Timing Pulley - 15Z 1
24 B302 4535 Rear Slide Holder 1
25 A232 3562 Ball Bearing - 6x12x4mm 1
26 A697 2260 Pulley - 17T 1
27 B302 4421 Timing Belt - 293P3M6 1
28 B302 5380 Stapler Harness 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 0720 0040B Retaining Ring - M4
103 0451 3008B Tapping Screw - M3x8
104 0451 3010B Tapping Screw - M3x10
105 0451 4006B Tapping Screw - 4x6
106 1105 0199 Clamp
107 1105 0328 Harness Clamp - ES-0505
108 0633 0100G Parallel Pin - 3x10
109 0805 3385 Bushing - 6mm
110 0710 0020W Hexagonal Nut - M2
111 0242 0035B Pan Head Screw - M2x3.5
113 0450 3008B Tapping Screw - M3x8
114 0574 0050E Hexagon Headless Set Screw - M4x5
115 1105 0946 Stepping Motor Cushion
Part No.
Description
Q’ty Per
Assembly
13
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg10.png)
5.STAPLE TRAY 4 (B302)
Index
No.
1 B302 4811 Stay - Upper Slide Rail 2
2 B302 4255 Guide Rod 1
3 B302 4251 Stapler Motor Bracket 1
4 B302 4411 Rear Side Plate - Staple Tray 1
5 B302 4259 Timing Belt - 195PM6 1
6 B302 4256 Timing Pulley - 20Z/40Z 1
7 B302 4756 Timing Belt - 753P3M6 1
8 A300 3812 Spacer - 6x22x1.5 1
9 B302 4292 Belt Holder 1
10 B302 4912 Right Stay Arm 1
11 B302 4291 Belt Holder Bracket 1
12 AX05 0149 Stepped Motor - DC 6.9W 1
13 AX05 0148 Stepped Motor - DC 8.0W 1
14 5442 4121 Spring - Oil Blade 1
15 AB03 0278 Idler - 20Z 1
16 B302 4766 Tightener 1
17 A697 1125 Stepped Screw - Lever 1
18 B302 4311 Front Side Plate - Staple Tray 1
19 A232 3562 Ball Bearing - 6x12x4mm 1
20 B302 4274 Worm Gear Shaft 1
21 B302 4291 Belt Holder Bracket 1
22 AW02 0086 Photointerruptor 3
23 B302 4261 Stapler Unit Slider 1
24 B302 4272 Worm Gear - Z1 1
25 B302 4269 Spring - 12x64mm 1
26 B302 4268 Return Arm - Stapler Unit 1
27 AA08 0072 Bushing - 6x10x3 2
28 B302 4299 Bracket - Return Support Sensor 1
29 B302 4266 Guide Rail - Stapler Unit 1
30 B302 4281 Bracket - Return Support Solenoid 1
31 AX12 0046 DC Solenoid - 24V 1
32 B302 4286 Spring - 4.4x24mm 1
33 B302 4285 Return Support Lever 1
34 B302 4287 Spring - 5.5x17mm 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 0720 0060B Retaining Ring - M6
103 0451 4010B Tapping Screw - 4x10
104 0720 0040B Retaining Ring - M4
105 0313 0040B Philips Pan Head Screw - M3x4
106 1105 0328 Harness Clamp - ES-0505
107 0740 3506 Ball Bearimg - 6x12x4 Mm
108 1105 0310 Harness Clamp - LWS-1S
109 0633 0100G Parallel Pin - 3x10
110 1105 0199 Clamp
Part No.
Description
Q’ty Per
Assembly
15
![](/html/64/6405/6405db8ed21367ab7e31c1f40bbbea487163f51c457d3e16ce16b935e94ca2ab/bg12.png)
6.STAPLER UNIT (B302)
Index
No.
1 B302 4239 Guide Roller 4
2 B302 4229 Sensor Actuator 1
3 B302 4231 1st Holder - Stapler Unit 1
4 B302 4238 Slide Guide 4
5 A697 4150 Stepped Screw - M5 4
6 B302 4221 2nd Holder - Stapler Unit 1
7 B302 4237 Slider Hook 1
8 A377 4741 Roller - M14 2
9 B302 4213 Stapler Bracket 1
10 B302 4217 Rear Stapler Cover 1
11 B302 4219 Entrance Stapler Guide Mylar 1
12 AJ01 1014 Stapler - EH-1100R 1
13 B302 4215 Front Stapler Cover 1
14 B302 4216 Stapler Harness Cover 1
15 B302 4267 Spring - 10x59mm 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0720 0040B Retaining Ring - M4
102 0720 0060B Retaining Ring - M6
103 0451 3006B Tapping Screw - M3x6
104 0451 4008B Philips Tapping Screw - M4x8
105 1105 0229 Clamp
106 0805 3368 Ball Bearing - 8x16x5mm
107 1105 0328 Harness Clamp - ES-0505
Part No.
Description
Q’ty Per
Assembly
17
