PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
1.Exterior 1 (D355)
2
101
2
2
3
1
101
101
3
4
101
102
101
101
17 18 20
101
5
6
101
102
26
102102 103 104 22
101
19
23
21
7
101
8
101
16
15 14
24
25
13
101
11
101
27
D355 2 Parts Location and List
101
10
12
101
101
9
10
1.Exterior 1 (D355)
Index
No.
1 D355 1361 Cover: Upper Front: Printer 1
2 B065 1343 NCU Cap 3
3 D532 1327 Cover: Rear Left 2
4 D355 1379 Bracket: Support: Cover: Upper Rear: Left 1
5 D355 1364 Cover: Upper Rear 1
6 D355 1378 Bracket: Fix: Cover: Rear Right 1
7 D355 1326 Cover: Rear Middle 1
8 B065 1341 Connector Cap 1
9 D532 1341 Cover: Right Upper: Ass'y 1
10 B070 1312 Cap: Joint: Large Capacity Tray 5
11 B234 1313 Cover - Large Capacity Tray 1
12 B065 1299 Cap: MM22 1
13 D532 1343 Cover: Right Lower: Ass'y 1
14 B070 1307 Decal: Paper Set Direction 2
15 D355 4575 Decal: Paper Tray: LCT 1
16 G178 2958 Decal: Size I ndication: Multi-Language 1
17 B832 1101 Positioning Pin - Lower 2
18 B832 1100 Positioning Pin - Upper 2
19 D355 1371 Cover: Upper: Extension 1
20 D355 1365 Cover: Upper Left: Rear 1
21 B132 1226 Holder: Stand 4
22 B706 1859 Screw: Slider: Lock 3
23 B832 1371 Spacer Cushion 1
24 D516 2783 End Fence: Tab: Ass'y 1
25 D516 1322 Decal: End Fence: Tab 1
26 D016 1372 Bracket: Cover: Extension 2
27 D532 1345 Cover: Front Right: Lower 1
Part No.
Description
Q’ty Per
Assembly
Rev. 02/14/2012
Index
No.
101 0451 4008N Tapping Scre w: 4x8
102 0450 4008N Tapping Screw - M4x8
103 0451 4020N Tapping Screw - M4x20
104 0954 4008N Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
D355 3 Parts Location and List
2.Exterior 2 (D355)
101
102
101
101
21
3
1
22
2
101
102
101
5 6
4
4
101
101
7
101
101
18 17
102 102
101
16
101 101
8
101
101
14
9
10
10
13
101
11
23
101
3
12
102
4
101
101
20
101
19
101
4
101
15
102
102
102
D355 4 Parts Location and List
2.Exterior 2 (D355)
Index
No.
1 D355 1331 Cover: Front Left: Open And Close: Ass'y 1
2 D355 1350 Decal: Misfeed Removal: Left 1
3 5447 2681 Snap Ring 2
4 D355 3846 Knob: Misfeed Removal 5
5 D355 1317 Inner Cover: Left Upper: Ass'y 1
6 D355 1308 Decal: Knob: Left Upper 1
7 D355 1303 Inner Cover: Middle Upper 1
8 B511 1378 Cover: Cover: Upper 1
9 D355 1356 Cover: Upper Left: Ass'y 1
10 B024 1365 Cap - 38x77 4
11 D355 1363 Cover: Upper Right 1
12 D355 1358 Cover: Front Right: Open and Close: Ass'y 1
13 D355 1352 Decal: Misfeed Removal: Horizontal: Transport 1
14 D355 1319 Inner Cover: Paper Feed: Lower: Ass'y 1
15 D355 1315 Decal: Knob: Paper Feed Unit: Lower 1
16 D355 1318 Inner Cover: Paper Feed: Upper: Ass'y 1
17 D355 1314 Decal: Knob: Transport: Middle Upper 1
18 D355 1313 Decal: Knob: Paper Feed Unit: Upper 1
19 D355 3090 Transport Unit: Horizontal: Exterior: Ass'y 1
20 D355 1305 Inner Cover: Left Lower 1
21 D355 1316 Inner Cover: Left Middle: Ass'y 1
22 D355 1307 Decal: Knob: Left Middle 1
23 D355 1185 Bracket: Fix: Cover: Right Front 1
Part No.
Description
Q’ty Per
Assembly
Rev. 02/14/2012
Index
No.
101 0451 4008N Tapping Scre w: 4x8
102 0450 4008N Tapping Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
D355 5 Parts Location and List
3.Paper Tray 1 (D355)
106
101
107
18
105
105
102
105
16
104
104
1
2
15
17
101
13
101
103
101
11
3
101
10
4
5
6
7
105
8
101
102
101
101
105
10
102
101
8
11
104
7
14
101
101
19
104
101
19
9
22
104
101
105
1
101
12
13
21
103
105
20
102
107
105
106
D355 6 Parts Location and List
3.Paper Tray 1 (D355)
Index
No.
1 B834 3386 Link Handle 2
2 B834 3400 Stopper Guide - Left 1
3 B834 3391 Plate: Left: No. 2 [TSB#005] 1
4 B834 3283 Stay: Main 1
5 B834 3476 Bracket: Main 1
6 B834 3438 Link Shaft 1
7 B834 3384 Contact Point Shaft 2
8 H516 3666 Spring - 19.6mm 2
9 B834 3378 Stay 1
10 B834 3390 Contact Point Stay 2
11 B834 3389 Stopper Shaft 2
12 D355 1384 Grip: Paper Tray: Ass'y 1
13 B834 3312 Collar 2
14 D532 4892 Plate: Side: Registration: Left 2
15 B834 3379 Arm: Swivel: Left: Peen 1
16 D453 1310 Decal: Paper: Supply 1
17 D453 1310 Decal: Paper: Supply 1
18 D355 1387 Cover: Paper Tray: Ass'y 1
19 D532 4891 Plate: Side: Registration: Right 2
20 B834 3425 Stopper Guide - Right 1
21 B834 3385 Arm - Right 1
22 B834 3392 Plate: Right: No. 2 [TSB#005] 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Scre w: 4x8
102 0720 0060E Retaining Ring - M6
103 D516 1537 Plain Shaft Bearing: DIA 8 [TSB#005]
104 0454 4008Q Tapping Screw - M4x8
105 0720 0040E Retaining Ring - M4
106 0720 0050E Retaining Ring - M5
107 D516 3506 Plain Shaft Bearing: Dia6
Part No.
Description
Rev. 05/02/2013
Q’ty Per
Assembly
D355 7 Parts Location and List
4.Paper Tray 2 (D355)
102
13
101
12
15
14
106
22
108
23
18
106
106
103
6
104
103
105
4
10
108
103
108
5
103
7
108
8
108
101
4
4
9
6
3
107
11
16
107
109
106
1
17
106
106
106
106
19
106
20
21
106
4
106
105
106
107
2
109
Tray Front Side
107
D355 8 Parts Location and List
4.Paper Tray 2 (D355)
Index
No.
1 D355 3462 Cover: Blower: Harness 1
2 D355 3459 Guard: Blower: Front 1
3 D350 4516 Guard: Tray: Side Fence 1
4 B834 3350 Bushing - 6x10x6.5 4
5 B834 3312 Collar 1
6 B834 3368 Slide Shaft - Upper 2
7 B834 3323 Holder - Upper Front 1
8 B834 3321 Side Fence Bracket - Upper Front 1
9 D350 3339 Rack: Upper Front: Peen 1
10 D355 3334 Guide: LM-6: Upper Front: Peen 1
11 B834 3337 Cover - Upper Front 1
12 D516 2879 Knob Screw: Tray: Guide: Green 2
13 D355 1394 Decal: Side Fence: Scale: Front 1
14 D355 3365 Duct: Upper Front: Blower: Ass'y 1
15 AA06 0858 DC Solenoid Spring 1
16 D355 3372 Duct: Lower: Blower 1
17 D355 5515 Blower: Fan: DC24V 18.24W 1
18 D355 4657 Side Fence: Front 1
19 D516 4153 Side Fence Grip 1
20 D355 4630 Tray Bottom Plate - Support 1
21 D355 4608 Spacer: Side Fence: Push Rivet [TSB#002] 2
22 D355 4652 Supporting Plate: Side Fence: Front 1
23 D355 4654 Cover: Side Fence 1
Part No.
Description
Q’ty Per
Assembly
Rev. 4/3/2013
Index
No.
101 0453 3006N Tapping Screw - M3x6
102 0453 4006N Binding Self Tapping Screw: 4x6
103 0720 0040E Retaining Ring - M4
104 0720 0030E Retaining Ring - M3
105 0720 0080E Retaining Ring - M8
106 0451 4008N Tapping Screw: 4x8
107 0454 4006Q Tapping Screw: 4x6
108 0454 4008Q Tapping Screw - M4x8
109 1105 0511 Harness Clamp - LWS-0306ZC
Part No.
Description
Q’ty Per
Assembly
D355 9 Parts Location and List
5.Paper Tray 3 (D355)
5
6
102
102
102
102
24
102
8
10
7
102
106
18
4
109
101
30
3
102
102
109
26
25
102
107
20
9
104
108
13
106
14
16
104
106
103
104
13
13
104
23
106
11
29
12
12
13
108
15
17
17
17
19
101
105
109
28
1
109
27
102
2
106
21
106
101
109
22
101
Tray Back Side
D355 10 Parts Location and List
5.Paper Tray 3 (D355)
Index
No.
1 D355 4666 Side Fence: Rear 1
2 D355 4662 Supporting Plate: Side Fence: Rear 1
3 D355 5515 Blower: Fan: DC24V 18.24W 1
4 D355 3375 Duct: Upper Rear: Blower: Ass'y 1
5 D355 3372 Duct: Lower: Blower 1
6 AA06 0858 DC Solenoid Spring 1
7 D355 3461 Guard: Blower: Rear 1
8 D516 2877 Knob Screw: Tray: Guide: Green 1
9 D355 1395 Decal: Side Fence: Scale: Rear 1
10 B834 3338 Cover - Upper Rear 1
11 B834 4743 Feeler - Paper Size Sensor No.2 1
12 B834 3368 Slide Shaft - Upper 2
13 B834 3350 Bushing - 6x10x6.5 4
14 B834 3334 Guide - Upper Rear 1
15 B834 4742 Feeler - Paper Size Sensor No.1 1
16 B834 3349 Rack - Upper Rear 1
17 AW02 0204 Paper Feed Sensor 3
18 B834 3316 Gear - 13Z 1
19 B834 4741 Paper Size Sensor Bracket 1
20 B834 3312 Collar 3
21 B834 3329 Holder - Upper Rear 1
22 B834 3322 Side Fence Bracket - Upper Rear 1
23 AA08 2101 Bushing - 6x10x6 1
24 D516 4163 Side Fence Grip - Rear 1
25 D453 2777 Plate: Auxiliary: Small: Adhesion 2
26 D355 2674 Decal - Paper Volume 1
27 D355 4630 Tray Bottom Plate – Support [TSB#002] 1
28 D355 4608 Spacer: Side Fence: Push Rivet [TSB#002] 2
29 C236 3237 Collar 6x11.2x1.5 1
30 D355 4654 Cover: Side Fence 1
Part No.
Description
Q’ty Per
Assembly
Rev. 02/14/2012
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0451 4008N Tapping Screw: 4x8
103 0453 4006N Binding Self Tapping Screw: 4x6
104 0453 3006N Tapping Screw - M3x6
105 1105 0522 Edge Saddle - LES0510
106 0720 0040E Retaining Ring - M4
107 0720 0030E Retaining Ring - M3
108 0720 0080E Retaining Ring - M8
109 1105 0511 Harness Clamp - LWS-0306ZC
Part No.
Description
Q’ty Per
Assembly
D355 11 Parts Location and List
6.Paper Tray 4 (D355)
Rev. 06/28/2011
12
11
13
104
101
2
14
102
4
3
1
101
2
10
101
3
14
102
4
103
103
7
6
5
103
6
8
101
103
7
104
101
101
9
10
101
102
3
4
101
2
14
1
5
101
D355 12 Parts Location and List
6.Paper Tray 4 (D355)
Index
No.
1 D355 4568 Feeler: Paper Volume Sensor 1
2 C563 3116 Belt Joint 4
3 D355 3232 Bracket: Timing Belt: Rear 4
4 A335 4351 Guide Roller 4
5 B234 6141 Positioning Sleeve - Inner Back 1
6 B834 4032 Cushion: Tray: No.1 4
7 B834 2715 Tray Cushion Holder 4
8 D355 4640 Tray Bottom Plate: Adhesion 1
9 5201 2858 Friction Pad 1
10 D355 4579 Guide: End Fence: Left 1
11 D355 4578 Guide: End Fence: Right 1
12 B834 3490 Spacer - Side Fence 2
13 D516 4591 Grip: End Fence 1
14 B834 3231 Timing Belt Holder - Rear 4
15 D355 4633 Stay: Center: Paper Tray [TSB#004R] 1
Part No.
Description
Q’ty Per
Assembly
Rev. 12/13/2011
Index
No.
101 0451 4008N Tapping Screw: 4x8
102 0720 0060E Retaining Ring - M6
103 0454 4008Q Tapping Screw - M4x8
104 0453 4006N Binding Self Tapping Screw: 4x6
Part No.
Description
Q’ty Per
Assembly
D355 13 Parts Location and List
7.Paper Tray 5 (D355)
101
11
17
16
101
3
7
106
7
106
101
7
4
8
106
9
104
13
102
2
104
103
13
105
107
5
6
104
12
103
104
1
2
3
2
107
105
15
10
105
2
2
103
108
104
104
2
14
101
D355 14 Parts Location and List
7.Paper Tray 5 (D355)
Index
No.
1 AA08 2101 Bushing - 6x10x6 1
2 B834 3350 Bushing - 6x10x6.5 6
3 B834 3318 Plate:Lower 2
4 B834 3315 Gear - 13Z 1
5 A376 1295 Spacer - M6x10x5 1
6 B834 3316 Gear - 13Z 1
7 B834 3312 Collar 4
8 B834 3314 Shaft Holder - Lower 1
9 B834 3313 Rack - Front:Lower 1
10 B834 4696 Rack - Rear Lower 1
11 B834 3346 Coupling Shaft - Rear 1
12 D355 4866 Ball Bearing:Slide:DIA6 1
13 B834 3111 Side Fence Shaft - Lower 2
14 B834 3309 Side Fence Bracket - Lower Rear 1
15 D355 3306 Bracket:Side Fence:Lower Front 1
16 D355 4572 Decal:Paper Tray:Warning 1
17 D355 4574 Decal:Paper Tray:Caution 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 0453 3006N Tapping Screw - M3x6
103 0453 4006N Binding Self Tapping Screw:4x6
104 0720 0040E Retaining Ring - M4
105 0720 0080E Retaining Ring - M8
106 0720 0030E Retaining Ring - M3
107 0725 0120E Retaining Ring C - M12
108 1105 0522 Edge Saddle - LES0510
Part No.
Description
Q’ty Per
Assembly
D355 15 Parts Location and List
8.Paper Tray 6 (D355)
2
102
9
8
10
104
11
102
101
1
102
103
102
102
104
102
12
1
101
104
5
102
6
103
103
104
15
16
103
103
103
104
102
13
11
14
4
3
103
7
D355 16 Parts Location and List
8.Paper Tray 6 (D355)
Index
No.
1 D355 4593 Rack: Base: End Fence 2
2 D516 3065 Slide Rail - End Fence 1
3 B834 4595 Contact Point Shaft - Long 1
4 B834 4593 Paper Size Sensor Bracket - Long 1
5 G052 1518 Spring - Lo ck Lever 1
6 AW02 0204 Paper Feed Sensor 1
7 D355 2719 Separation Plate: Drive Unit 1
8 B834 4594 Shielding Plate - Long 1
9 B834 3169 Paper Size Sensor Plate 1
10 A294 4156 Gear - 23Z 1
11 H085 1109 Bushing - M6x5 2
12 D355 4597 Shaft: End Fence: Coupling 1
13 D355 4587 Bracket: End Fence 1
14 A228 3613 Gear - 20Z 1
15 D355 4589 Bracket: Paper Size Sensor 1
16 D355 4598 Roller: Slider 1
Part No.
Description
Q’ty Per
Assembly
Rev. 4/3/2013
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0451 4008N Tapping Screw: 4x8
103 0453 4006N Binding Self Tapping Screw: 4x6
104 0720 0040E Retaining Ring - M4
Part No.
Description
Q’ty Per
Assembly
D355 17 Parts Location and List
9.Paper Tray 7 (D355)
1
101
101
102
2
4
102
3
2
7
103
102
102
103
4
8
101
103
9
102
10
102
105
103
4
104
12
102
104
11
101
101
102
2
102
5
102
103
103
6
103
102
13
2
101
D355 18 Parts Location and List
9.Paper Tray 7 (D355)
Index
No.
1 B834 4563 Plate 2
2 B834 4557 Timing Pulley:Drive:No.2:Ass'y 4
3 B834 4572 Timing Belt - B100S5M2000 2
4 B834 4559 Tensioner 4
5 AA06 0840 Pressure Spring - 29N 1
6 B834 3245 Tension Bracket No.2 - Front 1
7 B834 3237 Bracket - Front 1
8 B834 4564 Holder - Front 1
9 B834 3493 Oil Damper:0.2N 1
10 D355 4140 Gear - 24Z 1
11 D355 4564 Bracket:Drive:Front Lower 1
12 B834 4565 Timing Pulley - 20T 1
13 B834 4568 Stud 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 0720 0060E Retaining Ring - M6
103 0454 4008Q Tapping Screw - M4x8
104 0742 3808 Ball Bearing - 8x16x5
105 0633 0140G Parallel Pin - 3x14
Part No.
Description
Q’ty Per
Assembly
D355 19 Parts Location and List
10.Paper Tray 8 (D355)
Rev. 03/20/2009
16
104
12
15
103
4
103
14
2
102
4
102
4
102
13
103
102
8
9
107
1
101
2
102
3
105
2
102
108
5
101
106
101
101
107
103
10
103
103
103
6
11
103
D355 20 Parts Location and List
103
102
2
7
102
102
107
109
10.Paper Tray 8 (D355)
Index
No.
1 B834 4563 Plate 1
2 B834 4557 Timing Pulley: Drive: No.2: Ass'y 4
3 B834 4572 Timing Belt - B100S5M2000 1
4 B834 4559 Tensioner 4
5 AA06 0840 Pressure Spring - 29N 1
6 B834 4566 Tension Bracket No.2 - Rear 1
7 B834 4568 Stud 1
8 D355 4556 Bracket: Paper Volume Sensor 1
9 AW02 0204 Paper Feed Sensor 4
10 B834 3248 Bracket - Rear 1
11 D355 4563 Drive Bracket - Rear Lower 1
12 D355 4531 Shaft: Main: Drive 1
13 D355 4534 Holder: Driven: Rear 1
14 D355 5315 Harness: Connecting: Tray 1
15 B834 4881 Drawer Connector Bracket 1
16 D355 5316 Harness: Fan 1
Part No.
Description
Q’ty Per
Assembly
Rev. 6/11/2013
Index
No.
101 0451 4008N Tapping Screw: 4x8
102 0720 0060E Retaining Ring - M6
103 0454 4008Q Tapping Screw - M4x8
104 0743 3808 Radial Ball Bearing - 8x16x5
105 1105 0518 Edge Saddle - LES-1010
106 1105 0487 Harness Clamp
107 1105 0511 Harness Clamp - LWS-0306ZC
108 1105 0522 Edge Saddle - LES0510
109 1105 0008 Nylon Clamp – 2N [TSB#001R2]
Part No.
Description
Q’ty Per
Assembly
D355 21 Parts Location and List
11.Paper Feed Section 1 (D355)
22
101
21
20
106
106
101
102
1
2
102
101
104
101
101
7
10
101
10
101
18
101
3
11
12
6
19
105
107
105
101
107
104
102
14
9
16
13
17
105
15
105
107
8
23
101
103
5
3
4
D355 22 Parts Location and List
11.Paper Feed Section 1 (D355)
Index
No.
* D355 2501 Paper Feed Unit: Ass'y 2
1 AB01 1478 Gear - 18Z 2
2 B834 2631 Stay 1
3 AA10 0014 Retaining Ring C - Separate 2
4 AF03 0071 Pick-up Roller 1
5 5447 2706 Gear - 15T 1
6 AF03 1041 Feed Roller - Bypass Feed 1
7 D355 2577 Bracket: Sensor: Paper Feed 1
8 B832 2574 Pickup Arm 1
9 AA06 6677 Tension Spring 1
10 AW01 0122 Paper Feed Sensor 2
11 AF02 1410 Transport Roller 1
12 AA14 3812 Screw - Scale 1
13 AA06 3204 Compression Spring 1
14 AA08 3015 Roller Clutch 1
15 B832 2585 Feed Roller Shaft 1
16 AB01 7724 Gear - 23Z/28Z 1
17 B132 4119 Spacer: Gear: Idler 1
18 B832 2578 DC Solenoid 24V 1
19 B832 2579 Stay: Feed: Peen 1
20 AW02 0160 Paper Feed Sensor 1
21 B511 2677 Sensor Bracket 1
22 D350 5311 Harness: Paper Feed Unit 1
23 D355 2571 Paper Feed Roller: Guard 1
Part No.
Description
Q’ty Per
Assembly
Rev. 03/07/2013
Index
No.
101 0451 4008N Tapping Screw: 4x8
102 0720 0060E Retaining Ring - M6
103 0720 0040E Retaining Ring - M4
104 0742 3808 Ball Bearing - 8x16x5
105 0805 0088 Retaining Ring - M6
106 1105 0511 Harness Clamp - LWS-0306ZC
107 0741 3708 Ball Bearing - 8x12x3.5mm
Part No.
Description
Q’ty Per
Assembly
D355 23 Parts Location and List
12.Paper Feed Section 2 (D355)
23
102
101
22
103
20
19
18
104
19
18
105
104
12
21
105
104
15
106
16
14
13
104
17
104
107
104
107
101
5
6
10
11
101
101
101
4
3
2
1
7
8
9
D355 24 Parts Location and List
12.Paper Feed Section 2 (D355)
Index
No.
1 AA10 0014 Retaining Ring C - Separate 1
2 AF03 2041 Separation Roller - Bypass Feed 1
3 B234 6301 Torque Limiter:75mN m 1
4 B234 6223 Driven Reverse Shaft 1
5 B832 2541 Stay 1
6 D355 2551 Bracket:Reverse:Release 1
7 B303 2559 Lever:Pressure Release:Reverse 1
8 D355 2559 Tension Spring:Reverse 1
9 D355 2554 Hook:Reverse:Pressure 1
10 D355 2563 Compression Spring:Reverse:
Pressure:Auxiliary 1
11 D355 2556 Lever:Reverse:Pressure:Swivel 1
12 B303 2556 Reverse Pressure Lever 1
13 B833 2567 Tension Spring 1
14 AB01 1591 Gear:Reverse 1
15 AB01 1392 Drive Reverse Gear - 24Z 1
16 B234 6222 Reverse Drive Shaft 1
17 BB01 3008 Gear - 31Z 1
18 B833 2565 Compression Spring 2
19 AA08 4059 Ball Bearing Holder 2
20 B834 2568 Transport Roller - Driven 1
21 A229 2692 Damping Insulation 1
22 B832 2535 Reverse Guide Plate 1
23 B834 2520 Feed Guide Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 1105 0511 Harness Clamp - LWS-0306ZC
103 1105 0522 Edge Saddle - LES0510
104 0720 0040E Retaining Ring - M4
105 0741 3506 Ball Bearing - 6x12x4 mm
106 0573 0030E Hexagon Headless Set Screw - M3x3
107 0741 3706 Ball Bearing - 6x10x3
Part No.
Description
Q’ty Per
Assembly
D355 25 Parts Location and List
13.Transfer Section 1 (D355)
1
Rev. 2/16/2012
101
107
2
6
14
5
9
8
1013
9
12
105
8
103
101
1
101
102
3
101
19
4
103
104
101
106
101
105
101
7
101
104
11
103
103
103
18
101
17
16
102
15
10
*
D355 26 Parts Location and List
13.Transfer Section 1 (D355)
Index
No.
* D355 3500 Transport Sub-Unit: Vertical Transport: Left: Ass’y 1
1 D355 3870 Bracket: Tension: Manual Feed Unit: Sub-ass'y 1
2 AA14 3810 Development Cover Screw 1
3 B234 6508 Tension Spring 1
4 B234 6506 Timing Pulley - 30T 1
5 D355 3861 Guide Plate: Left: Manual Feed: Peen 1
6 D355 3864 Guide Plate: Manual Feed: Right 1
7 D355 3806 Drive Roller: Transport: CW 1
8 AA06 6675 Compression Spring 2
9 AA08 4059 Ball Bearing Holder 2
10 D355 3803 Transport Roller: Driven 1
11 D355 3817 Gear: Drive: Grip: Z22 1
12 D355 3998 Bracket: Sensor: Transport 1
13 AW01 0122 Paper Feed Sensor 1
14 D355 5311 Harness: Sensor: Transport: Ass'y 1
15 B835 2826 Timing Belt - B60S2M110 1
16 B835 2825 Gear - 29Z/36T 1
17 D355 3829 Bracket: Stepper Motor: Peen 1
18 AX06 0333 Stepper Motor DC2.4V 13W 1
19 B132 3350 Gear: Idler: Transport Screw: Small 1
Part No.
Description
Q’ty Per
Assembly
Rev. 2/16/2012
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0720 0040E Retaining Ring - M4
103 0720 0060E Retaining Ring - M6
104 0742 3808 Ball Bearing - 8x16x5
105 0454 4006Q Tapping Screw: 4x6
106 1105 0511 Harness Clamp - LWS-0306ZC
107 0453 3006N Tapping Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
D355 27 Parts Location and List
14.Transfer Section 2 (D355)
7
4
Rev. 06/17/2009
101
5
103
101
1
2
8
4
3
9
10
9
8
6
1
02
13
101
16
11
1102
15
102
13
14
D355 28 Parts Location and List
104
17
10
14.Transfer Section 2 (D355)
Index
No.
1 D355 3897 Screw: M4: 3M 2
2 D355 3809 Cushion: Stay 2
3 D355 3828 Holder: Stay: Guide Plate 2
4 D355 3857 Tension Spring: Guide Plate: 12N 1
5 D355 3832 Guide Plate: Upper: Open And Close: Peen 1
6 D355 3859 Guide Plate: Horizontal Transport: Lower 1
7 D355 3873 Guide Plate: Horizontal Transport: Upper 1
8 AA06 6675 Compression Spring 4
9 AA08 4059 Ball Bearing Holder 4
10 D355 3803 Transport Roller: Driven 2
11 D355 3567 Handle: Ass'y [TSB#003R] 2
12 [TSB#003]
13 AA08 2070 Bushing - 8x16x7 1
14 D355 3894 Lever: Misfeed Removal: Ass'y 1
15 D355 3892 Decal: U3: Lever: Operate: Display 1
16 D355 3893 Lever: Misfeed Removal: Ass'y 1
17 D355 3891 Decal: U1: Lever: Operate: Display
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0720 0060E Retaining Ring - M6
103 1105 0511 Harness Clamp - LWS-0306ZC
104 0954 4010N Screw: Polished Round/Spring: M4x10
Part No.
Description
Rev. 02/07/2012
Q’ty Per
Assembly
D355 29 Parts Location and List
15.Transfer Section 3 (D355)
107
1
102
4
105 107
103
6
103
104
101
103
5
6
7
103
104
2
101
3
107
102
101
101
12
12
4
106
105
9
101
11
10
14
10
11
101
13
104
103
101
8
104
101
101
103
D355 30 Parts Location and List
15.Transfer Section 3 (D355)
Index
No.
1 AX04 0158 Stepper Motor DC2.64V 6.3W 1
2 A232 4666 Cushion - Stepper Motor 1
3 D355 3821 Bracket:Stepper Motor 1
4 D355 3874 Timing Belt:60S2M210 3
5 A017 2988 Ring 1
6 B234 6506 Timing Pulley - 30T 3
7 B234 6507 Timing Pulley - 25T 1
8 B832 3909 Bracket Cushion 1
9 D355 3841 Guide Plate:Upper Paper Feed:Lower:Peen 1
10 AW01 0122 Paper Feed Sensor 2
11 D355 3998 Bracket:Sensor:Transport 2
12 D355 3806 Drive Roller:Transport:CW 2
13 D355 3845 Guide Plate:Upper Paper Feed:Upper:Peen 1
14 D355 5312 Harness:Sensor:F1:Vertical Transport:Ass'y 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0360 3006N Screw - M3x6
103 0720 0060E Retaining Ring - M6
104 0742 3808 Ball Bearing - 8x16x5
105 1105 0551 Clamp:LES-0505
106 1105 0534 Clamp
107 1105 0511 Harness Clamp - LWS-0306ZC
Part No.
Description
Q’ty Per
Assembly
D355 31 Parts Location and List
16.Transfer Section 4 (D355)
106
101
104
21
101
20
104
105
101
101
101
16
17
18
3
2
1
11
15
101
102
103
14
101
8
9
13
12
4
5
6
7
10
8
9
106
101
19
101
20
105
104
D355 32 Parts Location and List
16.Transfer Section 4 (D355)
Index
No.
1 D355 3882 Roller:Pressure Release 1
2 D355 3886 Shaft:Arm:On-Off 1
3 D355 3889 Arm:On-Off 1
4 D355 3883 Bracket:Arm 1
5 B234 4842 Shaft:Arm:On-Off 1
6 D355 3872 Guide Plate:Middle Lower 1
7 D355 3851 Guide Plate:Middle Upper 1
8 B234 4818 Compression Spring 2
9 AA08 4059 Ball Bearing Holder 2
10 D355 3804 Transport Roller:Release:Driven 1
11 D355 3853 Shaft:Cam:Pickup Roller:Ass'y 1
12 D355 3830 Guide Plate:Middle Upper:Exit:Peen 1
13 D355 3836 Bracket:Pressure Release:
Photo Refiection Sensor 1
14 AW01 0122 Paper Feed Sensor 1
15 D355 5314 Harness:Sensor:Exit:Ass'y 1
16 D355 3837
17 AW02 0145 Photointerruptor:Flat 1
18 D355 3877 Guide Plate:Middle Lower:Open And Close 1
19 D355 3823 Guide Plate:Middle Lower:Exit 1
20 D355 3897 Screw:M4:3M 2
21 B835 2790 Gear - 14Z 1
Part No.
Bracket:Pressure Release:Photointerruptor:Flat 1
Description
Q’ty Per
Assembly
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0720 0030E Retaining Ring - M3
103 0720 0020E Retaining Ring - M2
104 0720 0040E Retaining Ring - M4
105 0741 3906 Bushing - M6
106 0451 4008N Tapping Screw:4x8
Part No.
Description
Q’ty Per
Assembly
D355 33 Parts Location and List
17.Transfer Section 5 (D355)
Rev. 12/10/2009
26
103
1
2
101
1
102
4
2
101
103
5
103
104
5
6
103
101
102
102
10
104
3
3
105
105
101
7
101
20
19
105
27
11
102
4
17
106
25
16
18
105
23
22
106
19
20
24
25
105
28
101
9
22
101
104
103
23
103
21
104
103
103
104
103
101
12
13
105
8
14
13
12
101
15
101 7
107
9
101
D355 34 Parts Location and List
17.Transfer Section 5 (D355)
Index
No.
1 AX04 0158 Stepper Motor DC2.64V 6.3W 2
2 A232 4666 Cushion - Stepper Motor 2
3 D355 3874 Timing Belt: 60S2M210 2
4 D355 3821 Bracket: Stepper Motor 2
5 B234 6506 Timing Pulley - 30T 2
6 B234 6507 Timing Pulley - 25T 1
7 D355 3897 Screw: M4: 3M 2
8 B832 3909 Bracket Cushion 1
9 D355 3805 Drive Roller: Transport: Exit 1
10 D355 3840 Bracket: Detent: Ass'y 1
11 D355 3858 Torsion Spring: Guide Plate: 16N 2
12 AA06 6675 Compression Spring 4
13 AA08 4059 Ball Bearing Holder 4
14 D355 3803 Transport Roller: Driven 2
15 D355 3828 Holder: Stay: Guide Plate 2
16 D355 3850
17 D355 3842 Guide Plate: Lower Right: Paper Tray:
No.2: Peen 1
18 D355 3810 Bracket: Detent: Right: Ass'y 1
19 D355 1196 Roller: Detent 2
20 G363 1105 Detent Roller Shaft 2
21 D355 3817 Gear: Drive: Grip: Z22 1
22 AW01 0122 Paper Feed Sensor 2
23 D355 3998 Bracket: Sensor: Transport 2
24 D355 5313 Harness: Sensor: F2: Vertical Transport: Ass'y 1
25 D355 3807 Drive Roller: Transport: CCW 2
26 D355 3875 Timing Belt: 60S2M224 1
27 D355 3809 Cushion: Stay 1
28 D355 5311 Harness: Sensor: Transport: Ass'y 1
29 D355 3885 Stopper: Frame [TSB#003] 1
Part No.
Guide Plate: Lower Left: Open And Close: Peen 1
Description
Q’ty Per
Assembly
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0360 3006N Screw - M3x6
103 0720 0060E Retaining Ring - M6
104 0742 3808 Ball Bearing - 8x16x5
105 0720 0030E Retaining Ring - M3
106 1105 0511 Harness Clamp - LWS-0306ZC
107 0451 4008N Tapping Screw: 4x8
Part No.
Description
Rev. 12/10/2009
Q’ty Per
Assembly
D355 35 Parts Location and List
18.Drive Section 1 (D355)
22
104
23
24
1
102
104
105
101
101
13
21
20
14
101
101
19
16
104
18
17
15
14
13
104
104
105
101
104
3
105
12
8
6
101
103
7
11
9
10
5
5
4
8
103
7
6
25
101
101
102
1
102
101
101
2
101
101
1
101
2
101
D355 36 Parts Location and List
18.Drive Section 1 (D355)
Index
No.
1 AX04 0157 Stepper Motor DC1.68V 6.7W 3
2 B802 1622 Stepper Motor Damper 1
3 AA16 1122 Motor Cushion 2
4 B834 1725 Paper Feed Unit Drive Bracket 1
5 AA04 2550 Timing Belt - S2M138 2
6 B832 1750 Tension Bracket 2
7 AA14 3562 Screw:M4:DIA6x1.2 2
8 B234 6508 Tension Spring 2
9 B834 1730 Grip Drive Shaft 1
10 B834 1740 Shaft 1
11 B834 1718 Bracket 1
12 AB01 3654 Gear - 30Z 1
13 B125 3230 Spacer - 0.3 2
14 D355 1167 Compression Spring:Joint:Drive 2
15 D355 1168 Joint:Horizontal Transport:Drive:Shaft:Ass'y 1
16 D355 1159 Bracket:Horizontal Transport:Drive:
Rear:Peen 1
17 B834 3885 Gear/pulley - 31Z/31T 1
18 AA13 2205 Spacer - Timing Belt 1
19 D355 1157 Bracket:Horizontal Transport:Drive:Front 1
20 D355 1137 Joint:Transport Unit 1
21 D355 1136 Shaft:Horizontal Transport:Drive:Ass'y 1
22 B234 6506 Timing Pulley - 30T 2
23 D355 1197 Timing Belt:60S2M286 1
24 B835 2977 Timing Belt - B40S2M150 1
25 D355 1328 Bracket:Cover:Rear Left 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 0314 0080N Philips Pan Head Screw - M4x8
103 0454 4006Q Tapping Screw:4x6
104 0720 0060E Retaining Ring - M6
105 0742 3808 Ball Bearing - 8x16x5
Part No.
Description
Q’ty Per
Assembly
D355 37 Parts Location and List
19.Drive Section 2 (D355)
101
1
101
103
102
103
102
101
101
105
7
6
104
102
103
5
11
102
10
106
9
102
8
102
103
102
2
13
3
101 101
12
105
107
101
108
14
101
101
109
15
16
17
101
D355 38 Parts Location and List
19.Drive Section 2 (D355)
Index
No.
1 D355 4934 Plate: Drive: Rear 2
2 D532 3203 Gear: No. 2: Drive 2
3 D532 4547 Gear: No. 4: Middle 2
4 D355 4931 Plate: Drive: Middle 2
5 D355 4548 Shaft: Main: Drive 2
6 B834 4388 Compression Spring 2
7 D532 1185 Joint: Motor: Rise 2
8 D355 4549 Shaft: Gear: Drive 2
9 D532 3214 Gear: Small: No. 1 2
10 D532 3217 Gear: No. 2: Drive: Middle 2
11 D355 4933 Plate: Drive: Front 2
12 AX04 0229 DC Motor 24V 21.6W 2
13 D355 3214 Gear - 30Z 2
14 D355 1096 Bracket: Cover: Rear 2
15 D355 4915 Spring Plate: Earth: Tray 2
16 GX64 0024 Fan Motor - DC 3.12W 1
17 D355 1172 Bracket: Cooling Unit 1
Part No.
Description
Q’ty Per
Assembly
Rev. 12/30/2011
Index
No.
101 0451 4008N Tapping Screw: 4x8
102 0720 0060E Retaining Ring - M6
103 0742 3808 Ball Bearing - 8x16x5
104 0708 0080N Washer-DIA8
105 0727 0080E Retaining Ring - M8
106 0633 0140G Parallel Pin - 3x14
107 0451 3006N Tapping Screw - 3x6
108 1105 0487 Harness Clamp
109 0451 4030N Tapping Screw: M4x30
Part No.
Description
Q’ty Per
Assembly
D355 39 Parts Location and List
20.Electrical Section (D355)
101
101
9
104
10
101
105
16
6
1
5
106
3
2
8
2
1
102
7
103
4
101
16
107
15
11
12
104
101
101
106
3
2
1
102
13
108
101
14
D355 40 Parts Location and List
20.Electrical Section (D355)
Index
No.
1 D355 4784 Screw:Drawer:Connector 6
2 D355 4875 Compression Spring 6
3 B834 4883 Drawer:Connector Bracket - Rear 2
4 D355 1152 Bracket:Drawer:Connector 1
5 D355 5331 Harness:Power Source:Connecting:
Large Capacity Tray 1
6 D355 1143 Bracket:Plug:Coupling 1
7 D355 5020 PCB:Ass'y 1
8 D355 1174 Bracket:PCB 1
9 D355 5301 Harness:Main:Drawer:Ass'y 1
10 D355 5303 Harness:Main:Motor:Ass'y 1
11 D355 5302 Harness:Main:Paper Feed:Ass'y 1
12 D355 5304 Harness:Safety Switch:Ass'y 1
13 D355 5318 Harness:Interface:ALE:Ass'y 1
14 D355 5300 Harness:Interface:Main:Ass'y 1
15 D355 1132 Bracket:Power Supply Cord 1
16 D355 1181 Bracket:Harness Clamp:Peen 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 1102 9781 Connector:51405-3919
103 1102 9430 Connector:Drawer:1612257-7
104 0451 3006N Tapping Screw - 3x6
105 1105 0194 PCB Stud
106 1105 0488 Harness Clamp
107 1105 0511 Harness Clamp - LWS-0306ZC
108 1105 0022 Cord Stopper - AWG 18/16 UL
Part No.
Description
Q’ty Per
Assembly
D355 41 Parts Location and List
21.Frame Section 1 (D355)
101
105
101
19
105
17
16
102
22
2
1
101
104
5
4
3
101
103
102
7
101
101
20
12
6
101
102
101
101
101
101
8
10
11
13
23
18
105
14
101
15
101
24
101
21
101
9
101 102 101 101
10
11
D355 42 Parts Location and List
21.Frame Section 1 (D355)
Index
No.
1 D355 5309 Harness:Sensor:Horizontal Transport:
Exit:Ass'y 1
2 D355 3998 Bracket:Sensor:Transport 1
3 AW01 0122 Paper Feed Sensor 1
4 J502 3127 Bushing:Stepper Motor 2
5 D355 3993 Guide Plate:Joint Unit:Upper:Peen 1
6 D355 3995 Transport Roller:Joint Unit:Ass'y 1
7 AB01 1478 Gear - 18Z 1
8 D355 3990 Guide Plate:Joint Unit:Lower:Peen 1
9 D355 3803 Transport Roller:Driven 1
10 AA08 4059 Ball Bearing Holder 2
11 AA06 6675 Compression Spring 2
12 D355 1366 Bracket:Fix:Cover:Upper Front 1
13 D355 1341 Hinge:Cover:Front Right:Upper:Peen 1
14 D355 1372 Bracket:Fix:Cover:Extension:Front 1
15 D355 1102 Bracket:Detent:Peen 1
16 D355 1195 Torsion Spring:Detent:8N 1
17 D355 1198 Bracket:Detent 1
18 D355 1196 Roller:Detent 1
19 G363 1105 Detent Roller Shaft 1
20 D355 1334 Hinge:Cover:Front Left:Upper:Peen 1
21 D355 1043 Bracket:Fix:Transport Unit 2
22 D355 1367 Bracket:Fix:Cover:Upper Left 2
23 D355 1059 Bracket:Channel:Rear 1
24 D355 1373 Bracket:Fix:Cover:Extension:Rear 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 4008N Tapping Screw:4x8
102 0720 0060E Retaining Ring - M6
103 0742 3808 Ball Bearing - 8x16x5
104 1105 0511 Harness Clamp - LWS-0306ZC
105 0720 0030E Retaining Ring - M3
Part No.
Description
Q’ty Per
Assembly
D355 43 Parts Location and List
22.Frame Section 2 (D355)
101
101
C
105
101
9
6
11
101
101
101
21
D
105
17
10
101
8
101
22
101
12
101
103
15
13
101
3
102 18
101
19
16
101
5
14
E
101
E
101
D
C
B
A
D
C
4
B
A
18
20
101
101
101
7
B
A
6
104
1st
101
102
2
3
101
101
1
D355 44 Parts Location and List
22.Frame Section 2 (D355)
Index
No.
1 B234 7559 Connector Bracket 1
2 D355 1122 Bracket: Slide Rail: Right: Peen 1
3 D355 3958 Slide Rail: Transport Unit 2
4 D355 1342 Hinge: Cover: Front Right: Lower: Peen 1
5 D355 1336 Hinge: Cover: Front Left: Lower: Peen 1
6 D355 1173 Bracket: Slide Rail 4
7 D355 1015 Bracket: Holder: Stopper: Right: Ass'y 2
8 D516 1195 Slide Rail: Right: Ass'y 2
9 D355 1016 Bracket: Holder: Stopper: Left: Ass'y 2
10 D516 1185 Slide Rail: Left: Ass'y 2
11 B512 1078 Positioning Pin: Guide: Rear 1
12 G570 1540 Rubbe r Foot H=10 2
13 B600 1082 Holder: Paper Tray 1
14 B512 1079 Positioning Pin: Guide: Front 1
15 D355 1164 Bracket: Horizontal Transport Unit:
Receive Plate: Rear 1
16 B234 6141 Positioning Sleeve - Inner Back 2
17 D355 1121 Bracket: Slide Rail: Left: Peen 1
18 D355 1058 Bracket: Frame: Base 2
19 D355 1163 Bracket: Joint Unit: Receive Plate: Rear 1
20 AA14 0912 Screw - 8x14 x2.8 2
21 D355 1902 Bracket: Tray: Stopper 2
22 D355 1162 Damper: Tray: Lock: Right 2
Part No.
Description
Q’ty Per
Assembly
Rev. 6/11/2013
Index
No.
101 0451 4008N Tapping Screw: 4x8
102 0453 3008N Binding Self Tapping Screw: 3x8
103 0451 3008N Tapping Screw - M3x8
104 1105 0487 Harness Clamp
105 0453 4008N Binding Self Tapping Screw: 4x8
Part No.
Description
Q’ty Per
Assembly
D355 45 Parts Location and List
23.Frame Section 3 (D355)
1
101
102
102
101
102
101
1
5
103
4
1
1
101
6
8
102
105
7
102
2
3
103
4
4
104
102
18
102
7
102
102
12
105
6
106
102
13
9
14
102
106
10
19
16
103
14
104
107
15
109
17
11
108
D355 46 Parts Location and List
23.Frame Section 3 (D355)
Index
No.
1 B303 1116 Grounding Plate 4
2 D355 1114 Slider: Lock 1
3 AA06 6671 Lock Spring 1
4 AA14 0912 Screw - 8x14 x2.8 4
5 GH01 0007 Rubber Foot - FF-006(P4070)N 2
6 AG07 1012 Magnet Catch: Ass'y 2
7 D355 1325 Cover: Push Switch 2
8 D355 1349 Bracket: Safety Switch: Right 1
9 D355 1347 Bracket: Safety Switch: Left 1
10 D355 1183 Ground Plate: Lower 1
11 AH01 2040 Caster: 1470N: Dia60 6
12 D355 1144 Cover: Dehumidifier: Heater 1
13 D352 1147 Decal: H-High Temp Warning 1
14 AX40 0012 Heater - 230V/18W 2
15 D355 5340 Harness: Connecting: Heater: Ass'y 1
16 AA14 3798 Hexagonal Bolt: M12x35 4
17 D355 5317 Harness: Earth: Ass'y 1
18 D355 5304 Harness: Safety Switch: Ass'y 1
19 D355 5305 Harness: Safety Switch: Connecting: Exit 1
Part No.
Description
Q’ty Per
Assembly
Rev. 12/31/2012
Index
No.
101 0454 4008Q Tapping Screw - M4x8
102 0451 4008N Tapping Screw: 4x8
103 1105 0522 Edge Saddle - LES0510
104 1105 0600 Clamp: LWSM-0306-2M
105 1204 2382 Interlock Switch - Fail-CA22
106 0314 0060N Screw - M4x6
107 1105 0487 Harness Clamp
108 0951 6012N Screw - M6x12
109 0954 4008N Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
D355 47 Parts Location and List
24.Decals And Documents (D355)
Rev. 12/09/2010
1
2, 3
4
1
1
4
2 3
5
1
6
2
2
3
4
2
5 6
D355 48 Parts Location and List
7
1
>PS<
24.Decals And Documents (D355)
8
9
12
13
10
14
11
D355 49 Parts Location and List
24.Decals And Documents (D355)
15
17 18
16
19 20
21
D355 50 Parts Location and List
24.Decals And Documents (D355)
Index
No.
1 B070 1307 Decal: Paper Set Direction 1
2 D453 1310 Decal: Paper: Supply 1
3 D453 1310 Decal: Paper: Supply 1
4 D516 1322 Decal: End Fence: Tab 1
5 D355 1307 Decal: Knob: Left Middle 1
6 D355 1308 Decal: Knob: Left Upper 1
7 D355 1313 Decal: Knob: Paper Feed Unit: Upper 1
8 D355 1314 Decal: Knob: Transport: Middle Upper 1
9 D355 1315 Decal: Knob: Paper Feed Unit: Lower 1
10 D355 1350 Decal: Misfeed Removal: Left 1
11 D355 1352 Decal: Misfeed Removal: Horizontal: Transport 1
12 D355 1394 Decal: Side Fence: Scale: Front 1
13 D355 1395 Decal: Side Fence: Scale: Rear 1
14 D355 2674 Decal - Paper Volume 1
15 D355 3891 Decal: U1: Lever: Operate: Display 1
16 D355 3892 Decal: U3: Lever: Operate: Display 1
17 D355 4572 Decal: Paper Tray: Warning 1
18 D355 4574 Decal: Paper Tray: Caution 1
19 D355 4575 Decal: Paper Tray: LCT 1
20 G178 2958 Decal: Size Indication: Multi-Language 1
21 D352 1147 Decal: H-High Temp Warning 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
Part No.
Description
Rev. 8/1/2011
Q’ty Per
Assembly
D355 51 Parts Location and List
LCIT RT5020
D355
PARTS INDEX
This section instructs you as to the numbers and names of parts on this machine.
Parts Index
Part No.
D355 1015 Bracket:Holder:Stopper:Right:Ass'y 45 - 7
D355 1016 Bracket:Holder:Stopper:Left:Ass'y 45 - 9
D355 1043 Bracket:Fix:Transport Unit 43 - 21
D355 1058 Bracket:Frame:Base 45 - 18
D355 1059 Bracket:Channel:Rear 43 - 23
D355 1096 Bracket:Cover:Rear 39 - 14
D355 1102 Bracket:Detent:Peen 43 - 15
D355 1114 Slider:Lock 47 - 2
D355 1121 Bracket:Slide Rail:Left:Peen 45 - 17
D355 1122 Bracket:Slide Rail:Right:Peen 45 - 2
D355 1132 Bracket:Power Supply Cord 41 - 15
D355 1136 Shaft:Horizontal Transport:Drive:Ass'y 37 - 21
D355 1137 Joint:Transport Unit 37 - 20
D355 1143 Bracket:Plug:Coupling 41 - 6
D355 1144 Cover:Dehumidifier:Heater 47 - 12
D355 1152 Bracket:Drawer:Connector 41 - 4
D355 1157 Bracket:Horizontal Transport:Drive:Front 37 - 19
D355 1159 Bracket:Horizontal Transport:Drive: 37 - 16
D355 1162 Damper:Tray:Lock:Right 45 - 22
D355 1163 Bracket:Joint Unit:Receive Plate:Rear 45 - 19
D355 1164
D355 1167 Compression Spring:Joint:Drive 37 - 14
D355 1168 Joint:Horizontal Transport:Drive:Shaft:Ass'y 37 - 15
D355 1172 Bracket:Cooling Unit 39 - 17
D355 1173 Bracket:Slide Rail 45 - 6
D355 1174 Bracket:PCB 41 - 8
D355 1181 Bracket:Harness Clamp:Peen 41 - 16
D355 1183 Ground Plate:Lower 47 - 10
D355 1185 Bracket:Fix:Cover:Right Front 5 - 23
D355 1195 Torsion Spring:Detent:8N 43 - 16
D355 1196 Roller:Detent 35 - 19
D355 1196 Roller:Detent 43 - 18
D355 1197 Timing Belt:60S2M286 37 - 23
D355 1198 Bracket:Detent 43 - 17
D355 1303 Inner Cover:Middle Upper 5 - 7
Bracket:Horizontal Transport Unit:Receive Plate:Rear 45 - 15
Page and
Index No.
Part No. Description
D355 1305 Inner Cover:Left Lower 5 - 20
D355 1307 Decal:Knob:Left Middle 5 - 22
D355 1307 Decal:Knob:Left Middle 51 - 5
D355 1308 Decal:Knob:Left Upper 51 - 6
D355 1308 Decal:Knob:Left Upper 5 - 6
D355 1313 Decal:Knob:Paper Feed Unit:Upper 5 - 18
D355 1313 Decal:Knob:Paper Feed Unit:Upper 51 - 7
D355 1314 Decal:Knob:Transport:Middle Upper 5 - 17
D355 1314 Decal:Knob:Transport:Middle Upper 51 - 8
D355 1315 Decal:Knob:Paper Feed Unit:Lower 5 - 15
D355 1315 Decal:Knob:Paper Feed Unit:Lower 51 - 9
D355 1316 Inner Cover:Left Middle:Ass'y 5 - 21
D355 1317 Inner Cover:Left Upper:Ass'y 5 - 5
D355 1318 Inner Cover:Paper Feed:Upper:Ass'y 5 - 16
D355 1319 Inner Cover:Paper Feed:Lower:Ass'y 5 - 14
D355 1321 Cover:Right Upper:Ass'y 3 - 9
D355 1323 Cover:Right Lower:Ass'y 3 - 13
D355 1325 Cover:Push Switch 47 - 7
D355 1326 Cover:Rear Middle 3 - 7
D355 1327 Cover:Rear Left 3 - 3
D355 1328 Bracket:Cover:Rear Left 37 - 25
D355 1331 Cover:Front Left:Open And Close:Ass'y 5 - 1
D355 1334 Hinge:Cover:Front Left:Upper:Peen 43 - 20
D355 1336 Hinge:Cover:Front Left:Lower:Peen 45 - 5
D355 1338 Cover:Front Right:Open And Close:Ass'y 5 - 12
D355 1341 Hinge:Cover:Front Right:Upper:Peen 43 - 13
D355 1342 Hinge:Cover:Front Right:Lower:Peen 45 - 4
D355 1345 Cover:Front Right:Lower 3 - 27
D355 1347 Bracket:Safety Switch:Left 47 - 9
D355 1349 Bracket:Safety Switch:Right 47 - 8
D355 1350 Decal:Misfeed Removal:Left 51 - 10
D355 1350 Decal:Misfeed Removal:Left 5 - 2
D355 1352 Decal:Misfeed Removal:Horizontal:Transport 5 - 13
D355 1352 Decal:Misfeed Removal:Horizontal:Transport 51 - 11
D355 1356 Cover:Upper Left:Ass'y 5 - 9
Description
Page and
Index No.
D355 2 Parts Index
Part No.
Page and
Index No.
D355 1361 Cover:Upper Front:Printer 3 - 1
D355 1363 Cover:Upper Right 5 - 11
D355 1364 Cover:Upper Rear 3 - 5
D355 1365 Cover:Upper Left:Rear 3 - 20
D355 1366 Bracket:Fix:Cover:Upper Front 43 - 12
D355 1367 Bracket:Fix:Cover:Upper Left 43 - 22
D355 1371 Cover:Upper:Extension 3 - 19
D355 1372 Bracket:Fix:Cover:Extension:Front 43 - 14
D355 1373 Bracket:Fix:Cover:Extension:Rear 43 - 24
D355 1378 Bracket:Fix:Cover:Rear Right 3 - 6
D355 1379 Bracket:Support:Cover:Upper Rear:Left 3 - 4
D355 1384 Grip:Paper Tray:Ass'y 7 - 12
D355 1387 Cover:Paper Tray:Ass'y 7 - 18
D355 1394 Decal:Side Fence:Scale:Front 9 - 13
D355 1394 Decal:Side Fence:Scale:Front 51 - 12
D355 1395 Decal:Side Fence:Scale:Rear 51 - 13
D355 1395 Decal:Side Fence:Scale:Rear 11 - 9
D355 1902 Bracket:Tray:Stopper 45 - 21
D355 2501 Paper Feed Unit:Ass'y 23 - *
D355 2551 Bracket:Reverse:Release 25 - 6
D355 2554 Hook:Reverse:Pressure 25 - 9
D355 2556 Lever:Reverse:Pressure:Swivel 25 - 11
D355 2559 Tension Spring:Reverse 25 - 8
D355 2563 Compression Spring:Reverse: 25 - 10
D355 2571 Paper Feed Roller:Guard 23 - 23
D355 2577 Bracket:Sensor:Paper Feed 23 - 7
D355 2674 Decal - Paper Volume 51 - 14
D355 2674 Decal - Paper Volume 11 - 26
D355 2719 Separation Plate:Drive Unit 17 - 7
D355 2777 Plate:Auxiliary:Small:Adhesion 11 - 25
D355 2784 End Fence:Tab:Ass'y 3 - 24
D355 3090 Transport Unit:Horizontal:Exterior:Ass'y 5 - 19
D355 3214 Gear - 30Z 39 - 13
D355 3232 Bracket:Timing Belt:Rear 13 - 3
D355 3306 Bracket:Side Fence:Lower Front 15 - 15
Part No. Description
Description
Page and
Index No.
D355 3365 Duct:Upper Front:Blower:Ass'y 9 - 14
D355 3372 Duct:Lower:Blower 9 - 16
D355 3372 Duct:Lower:Blower 11 - 5
D355 3375 Duct:Upper Rear:Blower:Ass'y 11 - 4
D355 3459 Guard:Blower:Front 9 - 2
D355 3461 Guard:Blower:Rear 11 - 7
D355 3462 Cover:Blower:Harness 9 - 1
D355 3566 Handle:Ass'y 29 - 11
D355 3803 Transport Roller:Driven 29 - 10
D355 3803 Transport Roller:Driven 43 - 9
D355 3803 Transport Roller:Driven 27 - 10
D355 3803 Transport Roller:Driven 35 - 14
D355 3804 Transport Roller:Release:Driven 33 - 10
D355 3805 Drive Roller:Transport:Exit 35 - 9
D355 3806 Drive Roller:Transport:CW 31 - 12
D355 3806 Drive Roller:Transport:CW 27 - 7
D355 3807 Drive Roller:Transport:CCW 35 - 25
D355 3809 Cushion:Stay 29 - 2
D355 3809 Cushion:Stay 35 - 27
D355 3810 Bracket:Detent:Right:Ass'y 35 - 18
D355 3817 Gear:Drive:Grip:Z22 35 - 21
D355 3817 Gear:Drive:Grip:Z22 27 - 11
D355 3821 Bracket:Stepper Motor 35 - 4
D355 3821 Bracket:Stepper Motor 31 - 3
D355 3823 Guide Plate:Middle Lower:Exit 33 - 19
D355 3828 Holder:Stay:Guide Plate 35 - 15
D355 3828 Holder:Stay:Guide Plate 29 - 3
D355 3829 Bracket:Stepper Motor:Peen 27 - 17
D355 3830 Guide Plate:Middle Upper:Exit:Peen 33 - 12
D355 3832 Guide Plate:Upper:Open And Close:Peen 29 - 5
D355 3836
Bracket:Pressure Release:Photo Refiection Sensor 33 - 13
D355 3837 Bracket:Pressure Release:Photointerruptor:Flat 33 - 16
D355 3840 Bracket:Detent:Ass'y 35 - 10
D355 3841 Guide Plate:Upper Paper Feed:Lower:Peen 31 - 9
D355 3842 Guide Plate:Lower Right:Paper Tray: 35 - 17
D355 3 Parts Index
Part No.
Page and
Index No.
D355 3845 Guide Plate:Upper Paper Feed:Upper:Peen 31 - 13
D355 3846 Knob:Misfeed Removal 5 - 4
D355 3850 Guide Plate:Lower Left:Open And Close:Peen 35 - 16
D355 3851 Guide Plate:Middle Upper 33 - 7
D355 3853 Shaft:Cam:Pickup Roller:Ass'y 33 - 11
D355 3857 Tension Spring:Guide Plate:12N 29 - 4
D355 3858 Torsion Spring:Guide Plate:16N 35 - 11
D355 3859 Guide Plate:Horizontal Transport:Lower 29 - 6
D355 3861 Guide Plate:Left:Manual Feed:Peen 27 - 5
D355 3864 Guide Plate:Manual Feed:Right 27 - 6
D355 3870 Bracket:Tension:Manual Feed Unit: 27 - 1
D355 3872 Guide Plate:Middle Lower 33 - 6
D355 3873 Guide Plate:Horizontal Transport:Upper 29 - 7
D355 3874 Timing Belt:60S2M210 31 - 4
D355 3874 Timing Belt:60S2M210 35 - 3
D355 3875 Timing Belt:60S2M224 35 - 26
D355 3877 Guide Plate:Middle Lower:Open And Close 33 - 18
D355 3882 Roller:Pressure Release 33 - 1
D355 3883 Bracket:Arm 33 - 4
D355 3886 Shaft:Arm:On-Off 33 - 2
D355 3889 Arm:On-Off 33 - 3
D355 3891 Decal:U1:Lever:Operate:Display 51 - 15
D355 3891 Decal:U1:Lever:Operate:Display 29 - 17
D355 3892 Decal:U3:Lever:Operate:Display 51 - 16
D355 3892 Decal:U3:Lever:Operate:Display 29 - 15
D355 3893 Lever:Misfeed Removal:Ass'y 29 - 16
D355 3894 Lever:Misfeed Removal:Ass'y 29 - 14
D355 3897 Screw:M4:3M 29 - 1
D355 3897 Screw:M4:3M 35 - 7
D355 3897 Screw:M4:3M 33 - 20
D355 3958 Slide Rail:Transport Unit 45 - 3
D355 3990 Guide Plate:Joint Unit:Lower:Peen 43 - 8
D355 3993 Guide Plate:Joint Unit:Upper:Peen 43 - 5
D355 3995 Transport Roller:Joint Unit:Ass'y 43 - 6
D355 3998 Bracket:Sensor:Transport 27 - 12
Part No. Description
Description
Page and
Index No.
D355 3998 Bracket:Sensor:Transport 35 - 23
D355 3998 Bracket:Sensor:Transport 31 - 11
D355 3998 Bracket:Sensor:Transport 43 - 2
D355 4140 Gear - 24Z 19 - 10
D355 4531 Shaft:Main:Drive 21 - 12
D355 4534 Holder:Driven:Rear 21 - 13
D355 4548 Shaft:Main:Drive 39 - 5
D355 4549 Shaft:Gear:Drive 39 - 8
D355 4563 Drive Bracket - Rear Lower 21 - 11
D355 4564 Bracket:Drive:Front Lower 19 - 11
D355 4568 Feeler:Paper Volume Sensor 13 - 1
D355 4572 Decal:Paper Tray:Warning 51 - 17
D355 4572 Decal:Paper Tray:Warning 15 - 16
D355 4574 Decal:Paper Tray:Caution 51 - 18
D355 4574 Decal:Paper Tray:Caution 15 - 17
D355 4575 Decal:Paper Tray:LCT 3 - 15
D355 4575 Decal:Paper Tray:LCT 51 - 19
D355 4578 Guide:End Fence:Right 13 - 11
D355 4579 Guide:End Fence:Left 13 - 10
D355 4587 Bracket:End Fence 17 - 13
D355 4589 Bracket:Paper Size Sensor 17 - 15
D355 4591 Grip:End Fence 13 - 13
D355 4593 Rack:Base:End Fence 17 - 1
D355 4596 Bracket:Paper Volume Sensor 21 - 8
D355 4597 Shaft:End Fence:Coupling 17 - 12
D355 4598 Roller:Slider 17 - 16
D355 4620 Tray Bottom Plate:Adhesion 13 - 8
D355 4621 Tray Bottom Plate - Support 11 - 27
D355 4630 Tray Bottom Plate - Support 9 - 20
D355 4652 Supporting Plate:Side Fence:Front 9 - 22
D355 4654 Cover:Side Fence 9 - 23
D355 4654 Cover:Side Fence 11 - 30
D355 4656 Side Fence:Front 9 - 18
D355 4662 Supporting Plate:Side Fence:Rear 11 - 2
D355 4664 Side Fence:Rear 11 - 1
D355 4 Parts Index
Part No.
Page and
Index No.
D355 4784 Screw:Drawer:Connector 41 - 1
D355 4866 Ball Bearing:Slide:DIA6 15 - 12
D355 4875 Compression Spring 41 - 2
D355 4915 Spring Plate:Earth:Tray 39 - 15
D355 4931 Plate:Drive:Middle 39 - 4
D355 4933 Plate:Drive:Front 39 - 11
D355 4934 Plate:Drive:Rear 39 - 1
D355 5020 PCB:Ass'y 41 - 7
D355 5300 Harness:Interface:Main:Ass'y 41 - 14
D355 5301 Harness:Main:Drawer:Ass'y 41 - 9
D355 5302 Harness:Main:Paper Feed:Ass'y 41 - 11
D355 5303 Harness:Main:Motor:Ass'y 41 - 10
D355 5304 Harness:Safety Switch:Ass'y 41 - 12
D355 5304 Harness:Safety Switch:Ass'y 47 - 18
D355 5305 Harness:Safety Switch:Connecting:Exit 47 - 19
D355 5309 Harness:Sensor:Horizontal Transport: 43 - 1
D355 5311 Harness:Sensor:Transport:Ass'y 35 - 28
D355 5311 Harness:Sensor:Transport:Ass'y 27 - 14
D355 5312 Harness:Sensor:F1:Vertical Transport:Ass'y 31 - 14
D355 5313 Harness:Sensor:F2:Vertical Transport:Ass'y 35 - 24
D355 5314 Harness:Sensor:Exit:Ass'y 33 - 15
D355 5315 Harness:Connecting:Tray 21 - 14
D355 5316 Harness:Fan 21 - 16
D355 5317 Harness:Earth:Ass'y 47 - 17
D355 5318 Harness:Interface:ALE:Ass'y 41 - 13
D355 5331 Harness:Power Source:Connecting:
Large Capacity Tray 41 - 5
D355 5340 Harness:Connecting:Heater:Ass'y 47 - 15
D355 5515 Blower:Fan:DC24V 18.24W 11 - 3
D355 5515 Blower:Fan:DC24V 18.24W 9 - 17
Part No. Description
Description
Page and
Index No.
A017 2988 Ring 31 - 5
A228 3613 Gear - 20Z 17 - 14
A229 2692 Damping Insulation 25 - 21
A232 4666 Cushion - Stepper Motor 31 - 2
A232 4666 Cushion - Stepper Motor 35 - 2
A294 4156 Gear - 23Z 17 - 10
A335 4351 Guide Roller 13 - 4
A376 1295 Spacer - M6x10x5 15 - 5
B024 1365 Cap - 38x77 5 - 10
B065 1299 Cap:MM22 3 - 12
B065 1341 Connector Cap 3 - 8
B065 1343 NCU Cap 3 - 2
B070 1307 Decal:Paper Set Direction 3 - 14
B070 1307 Decal:Paper Set Direction 51 - 1
B070 1312 Cap:Joint:Large Capacity Tray 3 - 10
B125 3230 Spacer - 0.3 37 - 13
B132 1226 Holder:Stand 3 - 21
B132 3350 Gear:Idler:Transport Screw:Small 27 - 19
B132 4119 Spacer:Gear:Idler 23 - 17
B234 1313 Cover - Large Capacity Tray 3 - 11
B234 4818 Compression Spring 33 - 8
B234 4842 Shaft:Arm:On-Off 33 - 5
B234 6141 Positioning Sleeve - Inner Back 45 - 16
B234 6141 Positioning Sleeve - Inner Back 13 - 5
B234 6222 Reverse Drive Shaft 25 - 16
B234 6223 Driven Reverse Shaft 25 - 4
B234 6301 Torque Limiter:75mN m 25 - 3
B234 6506 Timing Pulley - 30T 37 - 22
B234 6506 Timing Pulley - 30T 35 - 5
B234 6506 Timing Pulley - 30T 27 - 4
B234 6506 Timing Pulley - 30T 31 - 6
B234 6507 Timing Pulley - 25T 35 - 6
B234 6507 Timing Pulley - 25T 31 - 7
B234 6508 Tension Spring 27 - 3
B234 6508 Tension Spring 37 - 8
D355 5 Parts Index
Part No.
Page and
Index No.
B234 7559 Connector Bracket 45 - 1
B303 1116 Grounding Plate 47 - 1
B303 1185 Metal Joint 39 - 7
B303 2556 Reverse Pressure Lever 25 - 12
B303 2559 Lever:Pressure Release:Reverse 25 - 7
B511 1378 Cover:Cover:Upper 5 - 8
B511 2677 Sensor Bracket 23 - 21
B512 1078 Positioning Pin:Guide:Rear 45 - 11
B512 1079 Positioning Pin:Guide:Front 45 - 14
B600 1082 Holder:Paper Tray 45 - 13
B706 1859 Screw:Slider:Lock 3 - 22
B802 1622 Stepper Motor Damper 37 - 2
B832 1100 Positioning Pin - Upper 3 - 18
B832 1101 Positioning Pin - Lower 3 - 17
B832 1371 Spacer Cushion 3 - 23
B832 1750 Tension Bracket 37 - 6
B832 2535 Reverse Guide Plate 25 - 22
B832 2541 Stay 25 - 5
B832 2569 Stay:Feed:Peen 23 - 19
B832 2574 Pickup Arm 23 - 8
B832 2578 DC Solenoid 24V 23 - 18
B832 2585 Feed Roller Shaft 23 - 15
B832 2877 Knob Screw:Tray:Guide:Green 9 - 12
B832 2877 Knob Screw:Tray:Guide:Green 11 - 8
B832 3909 Bracket Cushion 35 - 8
B832 3909 Bracket Cushion 31 - 8
B833 2565 Compression Spring 25 - 18
B833 2567 Tension Spring 25 - 13
B834 1145 Slide Rail - Left Middle 45 - 10
B834 1155 Slide Rail - Right Middle 45 - 8
B834 1718 Bracket 37 - 11
B834 1725 Paper Feed Unit Drive Bracket 37 - 4
B834 1730 Grip Drive Shaft 37 - 9
B834 1740 Shaft 37 - 10
B834 2520 Feed Guide Plate 25 - 23
Part No. Description
Description
Page and
Index No.
B834 2568 Transport Roller - Driven 25 - 20
B834 2631 Stay 23 - 2
B834 2715 Tray Cushion Holder 13 - 7
B834 3065 Slide Rail - End Fence 17 - 2
B834 3111 Side Fence Shaft - Lower 15 - 13
B834 3169 Paper Size Sensor Plate 17 - 9
B834 3203 Gear - 48Z 39 - 2
B834 3214 Gear - 30Z 39 - 9
B834 3217 Gear - 60Z 39 - 10
B834 3231 Timing Belt Holder - Rear 13 - 14
B834 3237 Bracket - Front 19 - 7
B834 3245 Tension Bracket No.2 - Front 19 - 6
B834 3248 Bracket - Rear 21 - 10
B834 3283 Stay:Main 7 - 4
B834 3309 Side Fence Bracket - Lower Rear 15 - 14
B834 3312 Collar 9 - 5
B834 3312 Collar 7 - 13
B834 3312 Collar 15 - 7
B834 3312 Collar 11 - 20
B834 3313 Rack - Front:Lower 15 - 9
B834 3314 Shaft Holder - Lower 15 - 8
B834 3315 Gear - 13Z 15 - 4
B834 3316 Gear - 13Z 11 - 18
B834 3316 Gear - 13Z 15 - 6
B834 3318 Plate:Lower 15 - 3
B834 3321 Side Fence Bracket - Upper Front 9 - 8
B834 3322 Side Fence Bracket - Upper Rear 11 - 22
B834 3323 Holder - :Upper Front 9 - 7
B834 3329 Holder - Upper Rear 11 - 21
B834 3332 Guide - Upper Front 9 - 10
B834 3334 Guide - Upper Rear 11 - 14
B834 3337 Cover - Upper Front 9 - 11
B834 3338 Cover - Upper Rear 11 - 10
B834 3346 Coupling Shaft - Rear 15 - 11
B834 3349 Rack - Upper Rear 11 - 16
D355 6 Parts Index
Part No.
Page and
Index No.
B834 3350 Bushing - 6x10x6.5 11 - 13
B834 3350 Bushing - 6x10x6.5 15 - 2
B834 3350 Bushing - 6x10x6.5 9 - 4
B834 3368 Slide Shaft - Upper 11 - 12
B834 3368 Slide Shaft - Upper 9 - 6
B834 3378 Stay 7 - 9
B834 3379 Arm:Swivel:Left:Peen 7 - 15
B834 3384 Contact Point Shaft 7 - 7
B834 3385 Arm - Right 7 - 21
B834 3386 Link Handle 7 - 1
B834 3389 Stopper Shaft 7 - 11
B834 3390 Contact Point Stay 7 - 10
B834 3395 Plate - Left 7 - 3
B834 3396 Plate - Right 7 - 22
B834 3400 Stopper Guide - Left 7 - 2
B834 3425 Stopper Guide - Right 7 - 20
B834 3438 Link Shaft 7 - 6
B834 3475 Bracket 7 - 5
B834 3490 Spacer - Side Fence 9 - 21
B834 3490 Spacer - Side Fence 13 - 12
B834 3490 Spacer - Side Fence 11 - 28
B834 3493 Oil Damper:0.2N 19 - 9
B834 3885 Gear/pulley - 31Z/31T 37 - 17
B834 4032 Cushion:Tray:No.1 13 - 6
B834 4153 Side Fence Grip 9 - 19
B834 4163 Side Fence Grip - Rear 11 - 24
B834 4388 Compression Spring 39 - 6
B834 4547 Gear - 36Z/60Z 39 - 3
B834 4557 Timing Pulley:Drive:No.2:Ass'y 19 - 2
B834 4557 Timing Pulley:Drive:No.2:Ass'y 21 - 2
B834 4559 Tensioner 21 - 4
B834 4559 Tensioner 19 - 4
B834 4563 Plate 19 - 1
B834 4563 Plate 21 - 1
B834 4564 Holder - Front 19 - 8
Part No. Description
Description
Page and
Index No.
B834 4565 Timing Pulley - 20T 19 - 12
B834 4566 Tension Bracket No.2 - Rear 21 - 6
B834 4568 Stud 19 - 13
B834 4568 Stud 21 - 7
B834 4572 Timing Belt - B100S5M2000 21 - 3
B834 4572 Timing Belt - B100S5M2000 19 - 3
B834 4593 Paper Size Sensor Bracket - Long 17 - 4
B834 4594 Shielding Plate - Long 17 - 8
B834 4595 Contact Point Shaft - Long 17 - 3
B834 4696 Rack - Rear Lower 15 - 10
B834 4741 Paper Size Sensor Bracket 11 - 19
B834 4742 Feeler - Paper Size Sensor No.1 11 - 15
B834 4743 Feeler - Paper Size Sensor No.2 11 - 11
B834 4881 Drawer Connector Bracket 21 - 15
B834 4883 Drawer:Connector Bracket - Rear 41 - 3
B834 4891 Registration Side Plate - Right 7 - 19
B834 4892 Registration Side Plate - Left 7 - 14
B835 2790 Gear - 14Z 33 - 21
B835 2825 Gear - 29Z/36T 27 - 16
B835 2826 Timing Belt - B60S2M110 27 - 15
B835 2977 Timing Belt - B40S2M150 37 - 24
C236 3237 Collar 6x11.2x1.5 11 - 29
C563 3116 Belt Joint 13 - 2
D016 1372 Bracket:Cover:Extension 3 - 26
D350 1312 Decal:Paper:Supply:Right 51 - 2
D350 1312 Decal:Paper:Supply:Right 7 - 17
D350 1313 Decal:Paper:Supply:Left 7 - 16
D350 1313 Decal:Paper:Supply:Left 51 - 3
D350 1322 Decal:End Fence:Tab 3 - 25
D350 1322 Decal:End Fence:Tab 51 - 4
D350 3339 Rack:Upper Front:Peen 9 - 9
D350 4516 Guard:Tray:Side Fence 9 - 3
D350 5311 Harness:Paper Feed Unit 23 - 22
G052 1518 Spring - Lock Lever 17 - 5
G178 2958 Decal:Size Indication:Multi-Language 51 - 20
D355 7 Parts Index
Part No.
Page and
Index No.
G178 2958 Decal:Size Indication:Multi-Language 3 - 16
G363 1105 Detent Roller Shaft 43 - 19
G363 1105 Detent Roller Shaft 35 - 20
G570 1540 Rubber Foot H=10 45 - 12
H085 1109 Bushing - M6x5 17 - 11
H516 3666 Spring - 19.6mm 7 - 8
J502 3127 Bushing:Stepper Motor 43 - 4
Part No. Description
Description
Page and
Index No.
AA04 2550 Timing Belt - S2M138 37 - 5
AA06 0840 Pressure Spring - 29N 19 - 5
AA06 0840 Pressure Spring - 29N 21 - 5
AA06 0858 DC Solenoid Spring 11 - 6
AA06 0858 DC Solenoid Spring 9 - 15
AA06 3204 Compression Spring 23 - 13
AA06 6671 Lock Spring 47 - 3
AA06 6675 Compression Spring 43 - 11
AA06 6675 Compression Spring 35 - 12
AA06 6675 Compression Spring 27 - 8
AA06 6675 Compression Spring 29 - 8
AA06 6677 Tension Spring 23 - 9
AA08 2070 Bushing - 8x16x7 29 - 13
AA08 2101 Bushing - 6x10x6 15 - 1
AA08 2101 Bushing - 6x10x6 11 - 23
AA08 3015 Roller Clutch 23 - 14
AA08 4059 Ball Bearing Holder 43 - 10
AA08 4059 Ball Bearing Holder 25 - 19
AA08 4059 Ball Bearing Holder 29 - 9
AA08 4059 Ball Bearing Holder 27 - 9
AA08 4059 Ball Bearing Holder 33 - 9
AA08 4059 Ball Bearing Holder 35 - 13
AA10 0014 Retaining Ring C - Separate 25 - 1
AA10 0014 Retaining Ring C - Separate 23 - 3
AA13 2205 Spacer - Timing Belt 37 - 18
AA14 0912 Screw - 8x14x2.8 45 - 20
AA14 0912 Screw - 8x14x2.8 47 - 4
AA14 3562 Screw:M4:DIA6x1.2 37 - 7
AA14 3798 Hexagonal Bolt:M12x35 47 - 16
AA14 3810 Development Cover Screw 27 - 2
AA14 3812 Screw - Scale 23 - 12
AA16 1122 Motor Cushion 37 - 3
AB01 1392 Drive Reverse Gear - 24Z 25 - 15
AB01 1478 Gear - 18Z 23 - 1
AB01 1478 Gear - 18Z 43 - 7
D355 8 Parts Index
Part No.
Page and
Index No.
AB01 1591 Gear:Reverse 25 - 14
AB01 3654 Gear - 30Z 37 - 12
AB01 7724 Gear - 23Z/28Z 23 - 16
AF02 1410 Transport Roller 23 - 11
AF03 0071 Pick-up Roller 23 - 4
AF03 1041 Feed Roller - Bypass Feed 23 - 6
AF03 2041 Separation Roller - Bypass Feed 25 - 2
AG07 1012 Magnet Catch:Ass'y 47 - 6
AH01 2031 Caster:1470N 47 - 11
AW01 0122 Paper Feed Sensor 43 - 3
AW01 0122 Paper Feed Sensor 33 - 14
AW01 0122 Paper Feed Sensor 35 - 22
AW01 0122 Paper Feed Sensor 23 - 10
AW01 0122 Paper Feed Sensor 27 - 13
AW01 0122 Paper Feed Sensor 31 - 10
AW02 0145 Photointerruptor:Flat 33 - 17
AW02 0160 Paper Feed Sensor 21 - 9
AW02 0160 Paper Feed Sensor 17 - 6
AW02 0160 Paper Feed Sensor 23 - 20
AW02 0160 Paper Feed Sensor 11 - 17
AX04 0157 Stepper Motor DC1.68V 6.7W 37 - 1
AX04 0158 Stepper Motor DC2.64V 6.3W 31 - 1
AX04 0158 Stepper Motor DC2.64V 6.3W 35 - 1
AX04 0229 DC Motor 24V 21.6W 39 - 12
AX06 0333 Stepper Motor DC2.4V 13W 27 - 18
AX40 0012 Heater - 230V/18W 47 - 14
BB01 3008 Gear - 31Z 25 - 17
GA00 0036 Decal - (High Temperature) Left 47 - 13
GA00 0036 Decal - (High Temperature) Left 51 - 21
GH01 0007 Rubber Foot - FF-006(P4070)N 47 - 5
GX64 0024 Fan Motor - DC 3.12W 39 - 16
Part No. Description
Description
Page and
Index No.
0314 0060N Screw - M4x6 47 - 106
0314 0080N Philips Pan Head Screw - M4x8 37 - 102
0360 3006N Screw - M3x6 31 - 102
0360 3006N Screw - M3x6 35 - 102
0450 4008N Tapping Screw - M4x8 3 - 102
0450 4008N Tapping Screw - M4x8 5 - 102
0451 3006N Tapping Screw - 3x6 41 - 104
0451 3006N Tapping Screw - 3x6 39 - 107
0451 3008N Tapping Screw - M3x8 45 - 103
0451 4008N Tapping Screw:4x8 15 - 101
0451 4008N Tapping Screw:4x8 11 - 102
0451 4008N Tapping Screw:4x8 39 - 101
0451 4008N Tapping Screw:4x8 13 - 101
0451 4008N Tapping Screw:4x8 37 - 101
0451 4008N Tapping Screw:4x8 33 - 106
0451 4008N Tapping Screw:4x8 35 - 107
0451 4008N Tapping Screw:4x8 17 - 102
0451 4008N Tapping Screw:4x8 19 - 101
0451 4008N Tapping Screw:4x8 21 - 101
0451 4008N Tapping Screw:4x8 3 - 101
0451 4008N Tapping Screw:4x8 25 - 101
0451 4008N Tapping Screw:4x8 23 - 101
0451 4008N Tapping Screw:4x8 41 - 101
0451 4008N Tapping Screw:4x8 5 - 101
0451 4008N Tapping Screw:4x8 7 - 101
0451 4008N Tapping Screw:4x8 47 - 102
0451 4008N Tapping Screw:4x8 9 - 106
0451 4008N Tapping Screw:4x8 43 - 101
0451 4008N Tapping Screw:4x8 45 - 101
0451 4020N Tapping Screw - M4x20 3 - 103
0451 4030N Tapping Screw:M4x30 39 - 109
0453 3006N Tapping Screw - M3x6 15 - 102
0453 3006N Tapping Screw - M3x6 11 - 104
0453 3006N Tapping Screw - M3x6 27 - 107
0453 3006N Tapping Screw - M3x6 9 - 101
D355 9 Parts Index
Part No.
Page and
Index No.
0453 3008N Binding Self Tapping Screw:3x8 45 - 102
0453 4006N Binding Self Tapping Screw:4x6 15 - 103
0453 4006N Binding Self Tapping Screw:4x6 13 - 104
0453 4006N Binding Self Tapping Screw:4x6 11 - 103
0453 4006N Binding Self Tapping Screw:4x6 17 - 103
0453 4006N Binding Self Tapping Screw:4x6 9 - 102
0453 4008N Binding Self Tapping Screw:4x8 45 - 105
0454 4006Q Tapping Screw:4x6 27 - 105
0454 4006Q Tapping Screw:4x6 37 - 103
0454 4006Q Tapping Screw:4x6 9 - 107
0454 4008Q Tapping Screw - M4x8 29 - 101
0454 4008Q Tapping Screw - M4x8 11 - 101
0454 4008Q Tapping Screw - M4x8 27 - 101
0454 4008Q Tapping Screw - M4x8 21 - 103
0454 4008Q Tapping Screw - M4x8 9 - 108
0454 4008Q Tapping Screw - M4x8 47 - 101
0454 4008Q Tapping Screw - M4x8 19 - 103
0454 4008Q Tapping Screw - M4x8 31 - 101
0454 4008Q Tapping Screw - M4x8 7 - 104
0454 4008Q Tapping Screw - M4x8 17 - 101
0454 4008Q Tapping Screw - M4x8 33 - 101
0454 4008Q Tapping Screw - M4x8 35 - 101
0454 4008Q Tapping Screw - M4x8 13 - 103
0573 0030E Hexagon Headless Set Screw - M3x3 25 - 106
0633 0140G Parallel Pin - 3x14 39 - 106
0633 0140G Parallel Pin - 3x14 19 - 105
0708 0080N Washer-DIA8 39 - 104
0720 0020E Retaining Ring - M2 33 - 103
0720 0030E Retaining Ring - M3 11 - 107
0720 0030E Retaining Ring - M3 35 - 105
0720 0030E Retaining Ring - M3 15 - 106
0720 0030E Retaining Ring - M3 33 - 102
0720 0030E Retaining Ring - M3 9 - 104
0720 0030E Retaining Ring - M3 43 - 105
0720 0040E Retaining Ring - M4 27 - 102
Part No. Description
Description
Page and
Index No.
0720 0040E Retaining Ring - M4 15 - 104
0720 0040E Retaining Ring - M4 11 - 106
0720 0040E Retaining Ring - M4 33 - 104
0720 0040E Retaining Ring - M4 9 - 103
0720 0040E Retaining Ring - M4 17 - 104
0720 0040E Retaining Ring - M4 7 - 105
0720 0040E Retaining Ring - M4 23 - 103
0720 0040E Retaining Ring - M4 25 - 104
0720 0050E Retaining Ring - M5 7 - 106
0720 0060E Retaining Ring - M6 13 - 102
0720 0060E Retaining Ring - M6 43 - 102
0720 0060E Retaining Ring - M6 35 - 103
0720 0060E Retaining Ring - M6 31 - 103
0720 0060E Retaining Ring - M6 19 - 102
0720 0060E Retaining Ring - M6 7 - 102
0720 0060E Retaining Ring - M6 29 - 102
0720 0060E Retaining Ring - M6 23 - 102
0720 0060E Retaining Ring - M6 37 - 104
0720 0060E Retaining Ring - M6 21 - 102
0720 0060E Retaining Ring - M6 39 - 102
0720 0060E Retaining Ring - M6 27 - 103
0720 0080E Retaining Ring - M8 11 - 108
0720 0080E Retaining Ring - M8 9 - 105
0720 0080E Retaining Ring - M8 15 - 105
0725 0120E Retaining Ring C - M12 15 - 107
0727 0080E Retaining Ring - M8 39 - 105
0740 3506 Ball Bearing - 6x12x4 mm 7 - 107
0741 3506 Ball Bearing - 6x12x4 mm 25 - 105
0741 3706 Ball Bearing - 6x10x3 25 - 107
0741 3708 Ball Bearing - 8x12x3.5mm 23 - 107
0741 3808 Ball Bearing - 8x16x5mm 7 - 103
0741 3906 Bushing - M6 33 - 105
0742 3808 Ball Bearing - 8x16x5 21 - 104
0742 3808 Ball Bearing - 8x16x5 39 - 103
0742 3808 Ball Bearing - 8x16x5 27 - 104
D355 10 Parts Index
Part No.
Page and
Index No.
0742 3808 Ball Bearing - 8x16x5 37 - 105
0742 3808 Ball Bearing - 8x16x5 31 - 104
0742 3808 Ball Bearing - 8x16x5 19 - 104
0742 3808 Ball Bearing - 8x16x5 23 - 104
0742 3808 Ball Bearing - 8x16x5 35 - 104
0742 3808 Ball Bearing - 8x16x5 43 - 103
0805 0088 Retaining Ring - M6 23 - 105
0951 6012N Screw - M6x12 47 - 108
0954 4008N Screw - M4x8 3 - 104
0954 4008N Screw - M4x8 47 - 109
0954 4010N Screw:Polished Round/Spring:M4x10 29 - 104
1102 9430 Connector:Drawer:1612257-7 41 - 103
1102 9781 Connector:51405-3919 41 - 102
1105 0022 Cord Stopper - AWG 18/16 UL 41 - 108
1105 0194 PCB Stud 41 - 105
1105 0487 Harness Clamp 39 - 108
1105 0487 Harness Clamp 47 - 107
1105 0487 Harness Clamp 21 - 106
1105 0487 Harness Clamp 45 - 104
1105 0488 Harness Clamp 41 - 106
1105 0511 Harness Clamp - LWS-0306ZC 21 - 107
1105 0511 Harness Clamp - LWS-0306ZC 23 - 106
1105 0511 Harness Clamp - LWS-0306ZC 25 - 102
1105 0511 Harness Clamp - LWS-0306ZC 27 - 106
1105 0511 Harness Clamp - LWS-0306ZC 29 - 103
1105 0511 Harness Clamp - LWS-0306ZC 11 - 109
1105 0511 Harness Clamp - LWS-0306ZC 43 - 104
1105 0511 Harness Clamp - LWS-0306ZC 31 - 107
1105 0511 Harness Clamp - LWS-0306ZC 41 - 107
1105 0511 Harness Clamp - LWS-0306ZC 9 - 109
1105 0511 Harness Clamp - LWS-0306ZC 35 - 106
1105 0518 Edge Saddle - LES-1010 21 - 105
1105 0522 Edge Saddle - LES0510 25 - 103
1105 0522 Edge Saddle - LES0510 15 - 108
1105 0522 Edge Saddle - LES0510 47 - 103
Part No. Description
Description
Page and
Index No.
1105 0522 Edge Saddle - LES0510 11 - 105
1105 0522 Edge Saddle - LES0510 21 - 108
1105 0534 Clamp 31 - 106
1105 0551 Clamp:LES-0 505 31 - 105
1105 0600 Clamp:LWSM-0306-2M 47 - 104
1204 2382 Interlock Switch - Fail-CA22 47 - 105
D355 11 Parts Index
Part No.
Page and
Index No.
5201 2858 Friction Pad 13 - 9
5215 2621 Snap Ring - M6 29 - 12
5447 2681 Snap Ring 5 - 3
5447 2706 Gear - 15T 23 - 5
Part No. Description
Description
Page and
Index No.
D355 12 Parts Index
Loading...
