R3200x SERIES
RESET TIMER IC FOR MOBILE EQUIPMENTS
NO.EA-280-120328
OUTLINE
The R3200x Series are reset timer ICs with two input signals for mobile equipments which require long interval for reset sequence. The long interval prevents unexpected resets caused by accidental key operations. Internally, each of these ICs consist of a delay generator circuit and output driver transistors.
The R3200x Series have two active-low input pins (SR0 and SR1) which generate reset signals after output delay time when both input pins are activated at the same time.
R3200x Series has two versions that are different in output delay time settings and output release method.
-R3200x001x : Output delay time selectable (7.5s or 11.25s) by connecting DSR pin to either GND or VDD.
The reset signal will be canceled if either of the input pin becomes “H”. Until either input pin becomes “H”, the reset signal will be continually outputted.
-R3200x002x : Output delay time is fixed at 7.5s. After the reset signal is being output 0.234s, it will be
released automatically or if either of the input pin becomes “H”, the reset signal will be canceled.
While the reset signals are remaining active or being sent out, the ICs provide ultra-low supply current. The R3200x Series are available in DFN(PLP)2020-8B and DFN1216-8 packages.
FEATURES
• Supply Current 1 (at standby) ............................................... |
Typ. 0.28μA (VDD=5.5V) |
|
• Supply Current 2 (at active before reset signal output) ........ |
Typ. 3μA (VDD=5.5V) * |
|
• Supply Current 3 (at active after reset signal output) ........... |
Typ. 0.45μA (VDD=5.5V) |
|
• |
Operating Voltage Range...................................................... |
1.65V to 5.5V |
• |
Operating Temperature Range ............................................. |
−40 to 85 °C |
• |
Output Delay Time (R3200x001x) ........................................ |
Typ. 7.5s or 11.25s Selectable |
|
(R3200x002x)......................................... |
Typ. 7.5s |
• Output Delay Time Accuracy................................................. |
±20% |
|
• |
Output Release Time (R3200x002x) .................................... |
Typ. 0.234s |
• Output Release Time Accuracy (R3200x002x)..................... |
±20% (Min. 0.187s, Max. 0.282s) |
|
• |
Output Types......................................................................... |
Nch Open Drain and CMOS |
• |
Packages .............................................................................. |
DFN(PLP)2020-8B, |
|
|
DFN1216-8 |
) Guaranteed by design engineering.
APPLICATIONS
•Mobile phone, Smartphone
•E-book, Tablet devices
•Portable Games
•Personal Navigation Devices
1
R3200x
BLOCK DIAGRAMS
R3200xxxxA |
R3200xxxxB |
SR0 Reset
Logic
SR1
Delay
Logic
|
|
|
|
|
|
|
|
|
DSR |
|
|
|
Delay Time |
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
OSC |
|||
|
|
|
Selector |
|
|
|||
|
|
|
|
|
|
|
|
|
VDD |
SR0 |
Reset |
|
|
|
|
Logic |
|
|
|
SR1 |
|
Delay |
|
RST |
|
|
||
|
|
Logic |
||
|
|
|
||
GND |
DSR |
Delay Time |
OSC |
|
Selector |
||||
|
|
|||
|
|
|
VDD
RST2
RST |
GND
) The red block part exists only in R3200x001x.
SELECTION GUIDE
The combination of output delay time settings and output release method, the package type and the output type for the ICs can be selected at the users’ request.
Product Name |
Package |
Quantity per Reel |
Pb Free |
Halogen Free |
R3200Kxxx -TR |
DFN(PLP)2020-8B |
5,000 pcs |
Yes |
Yes |
R3200Lxxx -E2 |
DFN1216-8 |
5,000 pcs |
Yes |
Yes |
xxx: The combination of output delay time settings and output release method can be designated by serial numbers. (from 001)
(001) The output delay time of the reset signals selectable from 7.5s or 11.25s.
The reset signal will be canceled if either of the input pin becomes “H”. Until either input pin becomes “H”, the reset signal will be continually outputted.
(002) The output delay time of the reset signals is fixed at 7.5s. After reset signal is being output 0.234s, it will be released automatically or if either of the input pin becomes “H”, the reset signal will be canceled.
: Designation of Output Type
(A)Nch Open Drain
(B)Nch Open Drain and CMOS
2
R3200x
PIN CONFIGURATIONS
• DFN(PLP)2020-8B |
• DFN1216-8 |
Top View
8 7 6 5
1 2 3 4
Bottom View
5 |
6 |
7 |
8 |
|
1 |
|
|
4 |
3 |
2 |
1 |
Top View
8 7 6 5
1 2 3 4
Bottom View
5 |
6 |
7 |
8 |
1 |
|
|
|
4 |
3 |
2 |
1 |
) Tab is GND level. (They are connected to the reverse side of this IC.)
The tab is better to be connected to the GND, but leaving it open is also acceptable
PIN DESCRIPTIONS
• DFN(PLP)2020-8B, DFN1216-8
Pin No. |
Symbol |
|
Description |
||||
|
|||||||
1 |
|
|
NC |
|
No Connection (Only for A version) |
||
|
|
|
|
|
|
|
|
RST2 |
|
CMOS Output Pin, "H" Active (Only for B version) |
|||||
|
|
||||||
|
|
|
|
|
|
|
|
2 |
GND |
|
Ground Pin |
||||
|
|
|
|
|
|
|
2nd Reset Input Pin, ("L" Active) *1 |
3 |
|
|
|
|
|||
|
SR1 |
|
|||||
|
|
|
|
|
|
|
Nch Open Drain Output Pin, ("L" Active) *2 |
4 |
|
|
|
||||
|
RST |
|
|
||||
|
|
|
|
|
|
|
|
5 |
|
DSR |
|
Output Delay Time Selection Pin (R3200x001x) (GND: 7.5s, VDD: 11.25s) *3 |
|||
|
|
|
|
|
|
|
|
TEST2 |
|
Test Pin *4 (R3200x002x) |
|||||
|
|
||||||
|
|
|
|
|
|
|
|
6 |
TEST |
|
Test Pin *4 |
||||
|
|
|
|
|
|
|
|
7 |
|
|
|
|
1st Reset Input Pin, ("L" Active) *1 |
||
|
|
SR0 |
|
|
|||
|
|
|
|
|
|
|
|
8 |
|
|
VDD |
|
Power Supply Input Pin |
||
|
|
|
|
|
|
|
|
1) In the case of using one "L" active input signal pin, either SR0 or SR1 must be connected to GND.2) In the case of using B version without RST, RST must be connected to GND or left open.
3) DSR pin must be connected to either GND or VDD.4) TEST must be connected to GND.
3
R3200x
ABSOLUTE MAXIMUM RATINGS
Symbol |
Item |
Rating |
Unit |
|
VDD |
Supply Voltage |
GND-0.3 to 6 |
V |
|
|
|
|
|
|
VSR0 |
Input Voltage (1st Reset input pin) |
GND-0.3 to 6 |
V |
|
|
|
|
|
|
VSR1 |
Input Voltage (2nd Reset input pin) |
GND-0.3 to 6 |
V |
|
|
|
|
|
|
VRST |
Output Voltage (1st Reset output pin) |
GND-0.3 to 6 |
V |
|
|
|
|
|
|
VRST2 |
Output Voltage (2nd Reset output pin) |
GND-0.3 to VDD+0.3 |
V |
|
|
|
|
|
|
VDSR |
Input Voltage (Output Delay Time Selection Pin) (only R3200x001x) |
GND-0.3 to 6 |
V |
|
|
|
|
|
|
IOUT |
Output Current |
20 |
mA |
|
|
|
|
|
|
PD |
Power Dissipation (DFN(PLP)2020-8B) |
880 |
mW |
|
Power Dissipation (DFN1216-8) |
625 |
|||
|
|
|||
Topt |
Operating Temperature Range |
−40 to 85 |
°C |
|
|
|
|
|
|
Tstg |
Storage Temperature Range |
−55 to 125 |
°C |
|
|
|
|
|
) For Power Dissipation, please refer to PACKAGE INFORMATION.
ABSOLUTE MAXIMUM RATINGS
Electronic and mechanical stress momentarily exceeded absolute maximum ratings may cause the permanent damages and may degrade the life time and safety for both device and system using the device in the field. The functional operation at or over these absolute maximum ratings is not assured.
4
R3200x
ELECTRICAL CHARACTERISTICS
•R3200x001x
The specification in is checked and guaranteed by design engineering at −40°C ≤ Topt ≤ 85°C.
Topt=25°C
Symbol |
|
|
|
|
|
Item |
Conditions |
|
Min. |
Typ. |
|
Max. |
Unit |
|||||||
VDD |
Operating Voltage |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
1.65 |
|
|
|
5.5 |
V |
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
ISS1 |
Supply Current1 |
VDD=5.5V, at standby |
|
|
|
|
|
0.28 |
|
|
|
|
|
μA |
||||||
|
|
|
|
|
|
1.35 |
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VDD=5.5V, |
|
|
|
|
|
|
|
|
|
|
|
|
|
ISS2 |
Supply Current2 |
|
|
|
|
|
|
3.0 |
|
|
6.5 |
|
μA |
|||||||
at active before reset signal output |
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
VDD=5.5V, |
|
|
|
|
|
|
|
|
|
|
|
|
|
ISS3 |
Supply Current3 |
|
|
|
|
|
|
0.45 |
|
|
1.7 |
|
μA |
|||||||
at active after reset signal output |
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
VDD ≥ 4.5V |
IOL=8mA |
|
|
|
|
|
|
|
|
|
|
|
|
VOL |
"L" Output Voltage |
|
|
|
|
|
|
|
|
|
|
|
|
V |
||||||
VDD ≥ 3.3V |
IOL=5mA |
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
0.3 |
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VDD ≥ 1.65V |
IOL=3mA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VDD ≥ 4.5V |
IOH=5mA |
|
|
|
|
|
|
|
|
|
|
|
|
|
"H" Output Voltage |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
VOH |
VDD ≥ 3.3V |
|
|
|
|
|
|
|
|
|
|
|
|
V |
||||||
IOH=2.5mA |
VDD x 0.85 |
|
|
|
|
|
|
|||||||||||||
(Only for B version) |
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
VDD ≥ 1.65V |
IOH=0.8mA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ILEAKI |
|
|
|
|
VDD = 5.5V |
|
|
|
|
|
|
|
|
|
|
|
|
μA |
||
|
SR0 |
, |
|
SR1 |
Input Leakage Current |
|
|
|
|
|
|
|
|
0.1 |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
ILEAKO |
Output Leakage Current |
VDD = 5.5V |
|
|
|
|
|
|
|
|
|
|
|
|
μA |
|||||
|
|
|
|
|
|
|
|
0.1 |
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
DSR=GND |
|
|
|
|
|
7.5 |
|
|
|
|
s |
||
tDELAY |
Output Delay Time |
|
6 |
|
|
|
9 |
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
DSR=VDD |
|
|
|
|
|
|
11.25 |
|
|
|
|
|
s |
|||||||
|
|
|
|
|
|
|
|
|
9 |
|
|
|
13.5 |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
VIL |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
V |
|
SR0 |
, |
|
SR1 |
"L" Input Voltaget |
|
|
|
|
|
|
|
|
|
0.3 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
VIH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
V |
|
SR0 |
, |
|
SR1 |
"H" Input Voltaget |
|
|
0.85 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
All of units are tested and specified under load conditions such that Tj≈Topt=25°C except for Supply Current2.
RECOMMENDED OPERATING CONDITIONS (ELECTRICAL CHARACTERISTICS)
All of electronic equipment should be designed that the mounted semiconductor devices operate within the recommended operating conditions. The semiconductor devices cannot operate normally over the recommended operating conditions, even if when they are used over such conditions by momentary electronic noise or surge. And the semiconductor devices may receive serious damage when they continue to operate over the recommended operating conditions.
5
