Ricoh PJ X2240, PJ WX2240, PJ S2240 Product Sheet

Business Projection Systems

RICOH
PJ S2240/PJ X2240/
PJ WX2240

Projection

brightness up to

WXGA: 3,100lm

XGA/SVGA:

3,000lm

Ready 3D

Connectivity

HDMI

Showcase your best ideas wherever you go

The old adage is true: Some things have to be seen to be believed. Choose the RICOH® PJ S2240/PJ X 2240/

PJ WX2240 to share information on the big screen with more people in more places in stunning clarity.

Take the lightweight business projection system with you and conduct presentations, show videos, movies

and more in vivid color and sharp resolutions at projection sizes ranging from 30 inches to 300 inches wide

—making it perfect whether you’re in the conference room or the classroom. Backed by world-class service

and support, these projectors are ideally designed for today’s mobile workplace.

Customize presentations for every audience

You tailored content to suit your audience. Shouldn’t you do the same
with how it looks? With the Ricoh PJ S2240/PJ X2240/PJ WX2240, you
can present high-quality images at impressive resolutions to accommodate
your message, environment and audience. Choose from SVGA or XGA
resolution to showcase images, presentations and more. Need even higher
detail? With WXGA resolution, more information can be displayed in
widescreen format with crisp lines and stunning clarity when connected to
digital and video cameras and DVD players.

Carry your best ideas with you

Academic staff and corporate professionals alike rely on personal mobile
devices to perform everyday tasks. Now you can have this same freedom
of movement with your business projector. With the portable and
lightweight Ricoh PJ S2240/PJ X2240/PJ WX2240, you can move from
one presentation location to the next with ease to put your ideas in
front of your audience — wherever they are.

Rely on Ricoh's proven technology and support

Impress your audience with brighter,
sharper images

You’re presenting your ideas for a reason — you want them to be
noticed. What better way than through sharp lines, vivid colors and
bright images. You can even present in 3D to add a new dimension
to your CAD drawings or educational videos. Take advantage of
Digital Light Processing (DLP) projection technology for a higher
contrast ratio of 10,000:1 to make images stand out on screen and
with less lag, which improves video quality and consistency. With
its impressive brightness rating of up to 3,100 lumens (WXGA) and
3,000 lumens (XGA/SVGA), you can use the Ricoh PJ S2240/PJ X2240/
PJ WX2240 to produce vibrant presentations in almost any location,
including rooms with dim lighting.

Keep the focus on your message

Would you rather have your audience notice your presentation, or the
projector sitting on the table? Input terminals are located on the side
of the Ricoh PJ S2240/PJ X2240/PJ WX2240, so cords don’t take up
as much valuable table space or distract your audience. It can present
clear audio at high volumes, but still runs quietly with a noise level
below 34 dB. You can fine-tune images with a focus lever conveniently
placed on the top of the projection system. Use the convenient remote
control to make other adjustments at any time, from anywhere in the
room. With the Eco Mode option, you can even run it using less power
to save lamp life and reduce noise levels even more.

Receive support when you need it most

You’ve worried enough about your presentation. You shouldn’t
have to worry about putting it in front of your audience, too. Gain
confidence with Ricoh’s legacy of fast, responsive service and support.
Take advantage of our three-year warranty to ensure you have the
parts you need. But we doubt you’ll need to use it. With a 6,000-hour
lamp life in Eco Mode, you can present hour after hour, year after
year with clarity while saving on maintenance costs. Add the Ricoh
PJ S2240/PJ X2240/PJ WX2240 to your fleet of Ricoh printers and
MFPs for exceptional single-source support from a proven, experienced
industry leader.

Ricoh PJ S2240/PJ X2240/PJ WX2240

SPECIFICATIONS

Specifications

Projector
PJ S2240 Part # 431175
PJ X2240 Part # 431172
PJ WX2240 Part # 431169
Replacement Lamp* Part # 512758
3D Glasses Type 2** Part # 512511
Projection System Single Chip DLP
Resolution PJ S2240: SVGA – 800 x 600 dpi

PJ X2240: XGA – 1024 x 768 dpi
PJ WX2240: WXGA – 1280 x 800 dpi
Liquid Crystal Panel Size PJ S2240/PJ X2240: 0.55"
PJ WX2240: 0.65"
Aspect Ratio PJ S2240/PJ X2240: 4:3
PJ WX2240: 16:10

White Light Output PJ S2240/PJ X2240: 3,000 lm
(Brightness) PJ WX2240: 3,100 lm
Contrast Ratio WXGA: 2,000:1

Screen Size/ 30" – 300"/39.37" – 393.7"
Projection Distance
Lamp Type High pressure mercury (190W)
Lamp Life Standard Mode: 4,500 hours

Economy Mode: 6,000 hours

XGA/SVGA: 2,200:1

®

system

Projection Lens Zoom Ratio: 1.1
Zoom/Focus: Manual/Manual

Projector Features Keystone (Direction: Vertical - Manual);

Built-in Speaker 2W Mono for PJ X2240 and

Dimensions (WxDxH) 12.4" x 8.8" x 4" (314 x 224 x 102 mm)
Weight 5.75 lbs. (2.6 kg)
Power Consumption While Operating:

Eco Mode: 195W
Standby: 0.5W

Storage & Transportation Storage Temperature: -20° to 60°C
Environment Transportation Temperature: 5°F to 40°F;
Humidity: 80%
Fan Noise Standard Mode: 34 dB or less

Eco Mode: 31 dB or less
Power Supply 100/240V; 50 – 60Hz

AV Mute; Freeze; Re-size (Magnify);
Wall Color Mode; Security Bar;
Kensington Lock; Eco Mode;
3D Projection Ready; Front/Rear Tilt
Foot Adjuster; High Altitude Mode

PJ WX2240 only

Standard Mode: 230W

Interface Terminal

Ricoh PJ S2240 Ricoh PJ X2240/PJ WX2240

Computer In 1 Mini D-SUB15pin x 1 Mini D-SUB15pin x 1

Computer In 2 N/A Mini D-SUB15pin x 1

Monitor Out N/A Mini D-SUB15pin x 1

S Video Mini DIN 4pin x 1 Mini DIN 4pin x 1

Video In RCA 1pin x 1 RCA 1pin x 1

PC Control D-SUB 9pin x 1 (RS-232C) D-SUB 9pin x 1 (RS-232C)

Audio In 1 N/A Mini Jack x 1

Audio In 2 N/A Mini Jack x 1

Audio Out N/A Mini Jack x 1

Service USB-TYPE-minB x 1 USB-TYPE-minB x 1

HDMI HDMI(1.4) x 1 HDMI(1.4) x 1

Accessories Packaged Cables: Single RGB Cable, Power Cord,
with Projector CD ROM: Operating Instructions;

Carrying Case: Included for PJ X2240

Remote Control: Remote Control

* Lamps are consumable products and therefore are not covered by the

projector’s warranty.

** Native support for Frame Sequential 3D format. Other sources may require

a converter that is not provided from Ricoh.

For maximum performance and yield, we recommend using genuine
Ricoh parts and supplies.

Quick Start Guide; Warranty Sheet and
Registration (US only)

and PJ WX2240 only

(CR2025 x 1 Battery included)

Warranty

The Ricoh PJ S2240/PJ X2240/PJ WX2240 is under warranty
against defects for a period of three years from the date of purchase.
Consumables are under warranty for a period of 90 days from the
date of purchase or until depleted, whichever comes first. Please refer
to warranty documents shipped with the product for more details.

Remote Control

Remote Control

Power

Enter

Menu

Freeze

Eco

Input

AV Mute

Auto Set

Zoom Out/In
