Showcase messages with laser focus precision
What good is having an audience if you don’t have its attention? Use the RICOH® PJ WXL6280 and
PJ WUL6280 (PJ 6280 Series) Laser Projectors to project brilliant high-definition images and videos in
larger conference rooms, auditoriums, churches and other venues and captivate every audience, every time.
Because it combines laser technology with the brilliance of digital light processing (DLP) projection, you
can share your ideas with brighter colors and sharper lines for more lifelike representations. Run the
projector longer with less heat, less maintenance and less noise, to keep everybody’s focus on your
message. Plus, you can take advantage of multiple PC and HDMI terminals as well as optional lenses
to give your presentation with speed, ease and convenience to make it even more memorable.
Be ready to share your biggest ideas
You have big, important news to share. Why not showcase it in the best
light on the big screen? Use innovative laser projection to display videos,
images, spreadsheets and other presentations using 6,000 lumens, so
your message can be seen clearly in almost any size room regardless of
the ambient lighting conditions. Choose between two easily mounted
projection systems to showcase ideas to large audiences without
any training or IT support. With the PJ WXL6280, you can display
widescreen WXGA images with 1280 x 800 dpi resolution in more than
1.07 billion colors with a 16:10 aspect ratio with high luminosity and
3D projection. Use the PJ WUL6280 and take advantage of more than
2 million pixels and 1920 x 1200 dpi resolution for even more lifelike
reproductions without downscaling for high-definition widescreen TV
signals, DVDs and Blu-ray
TM
images.
16:10
Make the most of any space
Where your audience sits shouldn’t compromise how they view your
presentation. Simply choose between five interchangeable lenses to
accommodate your room, audience and presentation. From diagonal
screen sizes as small as 50 inches up to 300 inches (25 feet) projections,
use the PJ 6280 Series laser projectors so every person in your audience
— from the first row just a few feet from the screen to the last row
yards away — sees every image with incredible color and clarity. Add
your choice of media source, including computers, TVs, DVDs and
more and use 360-degree tilting to showcase images on floors,
ceilings, angled walls and more, making the projector perfect for
unique applications.

Project higher-quality laser images with ease
Turn your message into the star attraction
You’re ready, and so is your audience. Make certain you’re not
leaving them in the dark. Once the PJ 6280 Series projection systems
are mounted, you’re assured of about 20,000 hours of nearly
maintenance-free operation. Laser technology replaces lamps that
can burn out before or during presentations. In addition, there’s
minimal heat emitted with laser technology. You also make less noise.
Simply turn it on and images are projected in brilliant colors almost
instantly. Powering down is just as easy — the image cuts to black
in a moment without the drone of a device cooling down that can
distract audiences from hearing your message.
Put your ideas into focus
You worked hard to craft the perfect message. Hopefully, your audience
sees it the same way. The PJ 6280 Series offer more brightness and
contrast to images, so there’s more of a separation between dark and
light colors. There’s also minimal lag when watching action-packed
motion on the big screen. With the convenient wireless remote control,
you control the motorized lens horizontal and vertical shift, zoom
and focus functions so you can fine-tune presentations in seconds.
Sometimes, clarity is out of your hands entirely. With Keystone
Correction Image Adjustment, images are balanced to resolve distortion
issues before your audience even notices them. You can also use the
Eco Mode option to adjust brightness on darker levels and use less
energy without compromising image quality.
Showcase big images on a small budget
Let your audience see your presentation the way you see it, without
awkward delays for buffering video. Scrambling to find and run up
to 100 meters of HDMI video cables is a strain on your IT resources,
as well as your budget. Take advantage of HDBaseT connectivity
to show densely packed, uncompressed video in high-definition
format over existing network cabling without degrading the signal
or compromising image quality. When you need to control or
reconfigure settings for one or multiple projectors, optional AV
management software is available to make adjustments quickly
from your computer or laptop.
To view detailed features of our projection products
online go to www.ricoh-usa.com/products

RICOH PJ WXL6280/PJ WUL6280
SPECIFICATIONS
Projector Mainframe Only (excluding lens)
PJ WXL6280 Part # 432078
PJ WUL6280 Part # 432075
Projection System Digital Light Processing (DLP) Technology
Panel Size PJ WXL6280: 0.65"
PJ WUL6280: 0.67"
Aspect Ratio 16:10
Resolution PJ WXL6280: WXGA – 1280 x 800 dpi
PJ WUL6280: WUXGA – 1920 x 1200 dpi
Size of Projected Image Up to 50" to 300" diagonal screen
White Light Output 6,000 lumens
Brightness
Light Source Type Laser diodes
Laser Life Approximately 20,000 hours
Lens 5 optional bayoneted lenses available.
Lens Shift Motorized Vertical (Up to ±50%) and
Zoom/Focus Motorized
Zoom Ratios See chart below
Keystone +/- 20 degrees
(Vertical/Horizontal)
Contrast Ratio (dynamic) PJ WXL6280: 1100:1 (100000:1)
PJ WUL6280: 1200:1 (100000:1)
See chart below.
Horizontal (Up to ±15%)
PJ WXL6280 and PJ WUL6280
Standard
Lens Features
Replacement Lens
Type A3 –
Part # 512916
Color Reproducibility 1.07 billion colors
Projection Modes Standard, Rear, Ceiling, Rear Ceiling
Video Input Signals HDTV 720p (50/60 Hz), 1080i/p (50/60 Hz),
Supported Resolutions Up to WUXGA@60 Hz (Reduced Blanking)
Scan Rate Horizontal: 15-91.1 KHz; Vertical: 24-85 Hz
Connection Terminals HDBaseT x 1
HDMI x 1
Computer In x 1
Monitor Out x 1
DVI-D x 1
USB Type A x 1*
YPBPR x 1
PC Control (D-sub 9 pin) x 1
Wired In/Out (3.5 mm phone jack) x 1*
LAN (RJ45) x 1
Service x 1*
*For service only
Supported Utilities PJ Link™, Crestron® and AMX®** AV
**Compatible later in 2016
Replacement Lens
(Short Throw) –
Part # 512914
1080p (24/25/30/50/60 Hz) SDTV 480i/p,
576i/p
& UXGA@60 Hz
management software
Type A1
Replacement Lens
Type A2
(Wide Zoom) –
Part # 512915
Primary Projection 360º Free Tilt Free, Picture-in-Picture,
Features Picture-by-Picture, Pincushion, Portrait Mode,
Dimensions (WxDxH) 19" x 20" x 7.3" (484 x 509 x 185 mm)
Weight 39.6 lbs. (18 kg) (not including lens)
Power Supply 100 – 240 V; 50/60 Hz
Power Consumption Standard Mode: 540 W; Eco Mode: 260 W
Fan Noise Standard Mode: 35 dB; Eco Mode: 33 dB
What’s In the Box CD-ROM with user manual, RGB cable,
For maximum performance and yield, we recommend using genuine
Ricoh parts and supplies.
Warranty
The RICOH PJ WXL6280 and PJ WUL6280 is under warranty against
defects for a period of three years from the date of purchase.
Consumables are under warranty for a period of 90 days from the
date of purchase or until depleted, whichever comes first. Please refer
to warranty documents shipped with the product for more details.
Replacement Lens
Type A4
(Long Zoom) –
Part # 512917
Security Bar, Kensington Lock, 3D Projection
(Frame sequential XGA/720p only), Eco
Mode, Firmware Update
or less
Power cord, Warranty sheet and registration
(US only), Remote control and batteries, lens
mount cover
Replacement Lens
Type A5
(Ultra-Long Zoom) –
Part # 512918
Focal Length 18.07 – 22.59 11.11 – 14.06 14.03 – 17.96 22.56 – 42.87 42.60 – 80.90
F Number 2.00 – 2.32 2.30 – 2.53 2.30 – 2.57 2.30 – 3.39 2.30 – 2.74
Focus Spec (MTF) 47 lp/mm 67 lp/mm 67 lp/mm 67 lp/mm 67 lp/mm
Zoom Range (Ratio) 1.25X 1.26X 1.28X 1.9X 1.9X
Zoom and Focus Adjustment Motorized
Throw Ratio for PJ WXL6280 1.28 – 1.61 0.79 – 1.00 1.00 – 1.28 1.60 – 3.07 3.04 – 5.78
Throw Distance for PJ WXL6280 54" – 409" (1.38 – 10.4 m) 33" – 254" (0.83 – 6.45 m) 43" – 326" (1.08 – 8.27 m) 68" – 781" (1.72 – 19.84 m) 129" – 1,470" (3.27 – 37.35 m)
Throw Ratio for PJ WUL6280 1.22 – 1.53 0.75 – 0.95 0.95 – 1.22 1.52 – 2.92 2.90 – 5.50
Throw Distance for PJ WUL6280 52" – 389" (1.31 – 9.89 m) 32" – 241" (0.81 – 6.13 m) 40" – 310" (1.02 – 7.88 m) 65" – 743" (1.64 – 18.87 m) 123" – 1,399" (3.12 – 35.54 m)
Projection Image Size (Diagonal) 50 – 300 inch
