BRIDGE UNIT B417
PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
1.Bridge Unit 1 (B417)
B417 2 Parts Location and List
1.Bridge Unit 1 (B417)
Index
No.
1 A897 6259 Joint Stay - Base Unit 1
2 AA12 0094 Antistatic Brush 1
3 B417 6266 Cover - Transport-left 1
4 G020 1327 Knob Screw - M3 1
5 B417 6268 Cover - Rear 1
6 B417 6267 Cover - Left Upper Rear 1
7 AF04 0558 Driven Roller 4
8 A897 6292 Spring Plate Pressure 8
9 B417 6261 Cover - Transport 1
10 B417 6351 Cover - Exit Upper 1
11 AA02 1030 Magnet Catch 2
12 AA12 0089 Antistatic Brush 1
13 A897 6318 Pin Side Plate 1
14 AA14 0708 Driven Shaft - Exit Roller 1
15 AF04 0565 Driven Exit R oller 2
16 AA06 3596 Compression Spring - Exit Roller 2
17 B417 6356 Cover - Exit Left 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0450 3008B Tapping Screw - M3x8
102 0451 3008H Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B417 3 Parts Location and List
2.Bridge Unit 2 (B417)
B417 4 Parts Location and List
2.Bridge Unit 2 (B417)
Index
No.
1 A897 6341 DC Solenoid 1
2 A897 5275 Exit Harness - Joint Unit 1
3 AB01 7500 Gear - 28Z/35Z 1
4 AB01 7498 Gear - 31Z/40Z 1
5 AA04 3518 Timing Belt - S2M210 1
6 5447 2681 Snap Ring 2
7 AB03 0631 Upperpulley - Exit Roller 1
8 A897 6311 Side Plate Rear 1
9 A897 6325 Guide Plate Exit 1
10 AF02 0468 Exit Roller 1
11 A897 6331 Gate Pawl 1
12 AA06 6583 Spring - Gate Pawl - Joint Unit 1
13 AW02 0098 Photosensor 1
14 A897 6323 Guide Plate Upper 1
15 AF02 0469 Right Transport Roller 1
16 A897 6321 Guuide Plate Lower 1
17 A897 6316 Side Plate Front 1
18 A897 6318 Pin Side Plate 1
19 A897 6344 Lever Solenoid 1
20 A897 6342 Bracket DC Solenoid 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 0720 0040E Retaining Ring - M4
103 0805 3385 Bushing - 6mm
104 0805 3480 Bushing - 6mm
105 0802 5276 Tapping Screw With Washer - M3x6
106 1105 0328 Harness Clamp - ES-0505
107 1105 0283 Clamp
108 0313 0040B Philips Pan Head Screw - M3x4
Part No.
Description
Q’ty Per
Assembly
B417 5 Parts Location and List
3.Bridge Unit 3 (B417)
B417 6 Parts Location and List
3.Bridge Unit 3 (B417)
Index
No.
1 A897 6253 Sheet Base 1
2 A688 3913 Support Plate 1
3 B417 5255 Harness - Connector 1
4 B417 6286 Bracket - Connector 1
5 A897 6283 Bracket Motor 1
6 AB01 1401 Motor Gear 2 1
7 AB01 7501 Motor Gear 1 1
8 B417 5254 Relay Harness 1
9 B417 6282 DC Motor - 24W 1
10 AA04 3519 Timing Belt - S2M 250 2
11 AA04 3518 Timing Belt - S2M210 1
12 AB01 7499 Exit Roller Pulley 1
13 AB03 0632 Transport Roller Pulley 2
14 AF02 0471 Lower Exit R ol ler 1
15 AF02 0470 Middle Transport Roller 2
16 AF04 0558 Driven Roller 4
17 A897 6291 Spring Plate Pressure Right 8
18 AA02 1030 Magnet Catch 1
19 G020 5626 Push Switch 2
20 B417 6251 Base - Joint Unit 1
21 A897 6256 Bracket Fan 1
22 AX64 0085 Fan Motor - DC 1.68W 1
23 G020 4472 Paper Feed Sensor 1
24 B417 5144 Ckb2 Board 1
25 B417 5252 Detector Harness - Joint Unit 1
26 B417 5253 Main Harness 1
27 A897 6288 Cover Tkb Board 1
28 A897 6252 Sheet Guide Exit Lower 2
29 AA02 1031 Magnetic Catch 1
101 0450 3008B Tapping Screw - M3x8
102 0720 0040E Retaining Ring - M4
103 0451 3006B Tapping Screw - M3x6
104 0451 3008H Tapping Screw - M3x8
105 1102 8502 Connector - 54679-1615
106 1105 0334 Edge - 17
Part No.
Description
Q’ty Per
Assembly
Index
No.
107 1105 0310 Harness Clamp - LWS-1S
108 0314 0080B Philips Pan Head Screw - M4x8
109 0805 3480 Bushing - 6mm
110 0313 0220B Philips Pan Head Screw - M3x22
Part No.
Description
Q’ty Per
Assembly
B417 7 Parts Location and List
BRIDGE UNIT B417
PARTS INDEX
This section instructs you as to the numbers and names of parts on this machine.
Parts Index
Part No.
B417 5144 Ckb2 Board 7- 24
B417 5252 Detector Harness - Joint Unit 7- 25
B417 5253 Main Harness 7- 26
B417 5254 Relay Harness 7- 8
B417 5255 Harness - Connector 7- 3
B417 6251 Base - Joint Unit 7- 20
B417 6261 Cover - Transport 3- 9
B417 6266 Cover - Transport-left 3- 3
B417 6267 Cover - Left Upper Rear 3- 6
B417 6268 Cover - Rear 3- 5
B417 6282 DC Motor - 24W 7- 9
B417 6286 Bracket - Connector 7- 4
B417 6351 Cover - Exit Upper 3- 10
B417 6356 Cover - Exit Left 3- 17
Page and
Index No.
Part No.Description
AA02 1030 Magnet Catch 7- 18
AA02 1030 Magnet Catch 3- 11
AA02 1031 Magnetic Catch 7- 29
AA04 3518 Timing Belt - S2M210 7- 11
AA04 3518 Timing Belt - S2M210 5- 5
AA04 3519 Timing Belt - S2M 250 7- 10
AA06 3596 Compression Spring - Exit Roller 3- 16
AA06 6583 Spring - Gate Pawl - Joint Unit 5- 12
AA12 0089 Antistatic Brush 3- 12
AA12 0094 Antistatic Brush 3- 2
AA14 0708 Driven Shaft - Exit Roller 3- 14
AB01 1401 Motor Gear 2 7- 6
AB01 7498 Gear - 31Z/40Z 5- 4
AB01 7499 Exit Roller Pulley 7- 12
AB01 7500 Gear - 28Z/35Z 5- 3
AB01 7501 Motor Gear 1 7- 7
AB03 0631 Upperpulley - Exit Roller 5- 7
AB03 0632 Transport Roller Pulley 7- 13
AF02 0468 Exit Roller 5- 10
AF02 0469 Right Transport Roller 5- 15
AF02 0470 Middle Transport Roller 7- 15
AF02 0471 Lower Exit Roller 7- 14
AF04 0558 Driven Roller 7- 16
AF04 0558 Driven Roller 3- 7
AF04 0565 Driven Exit Roller 3- 15
AW02 0098 Photosensor 5- 13
AX64 0085 Fan Motor - DC 1.68W 7- 22
G020 1327 Knob Screw - M3 3- 4
G020 4472 Paper Feed Sensor 7- 23
G020 5626 Push Switch 7- 19
Description
Page and
Index No.
B417 2 Parts Index
Part No.
A688 3913 Support Plate 7- 2
A897 5275 Exit Harness - Joint Unit 5- 2
A897 6252 Sheet Guide Exit Lower 7- 28
A897 6253 Sheet Base 7- 1
A897 6256 Bracket Fan 7- 21
A897 6259 Joint Stay - Base Unit 3- 1
A897 6283 Bracket Motor 7- 5
A897 6288 Cover Tkb Board 7- 27
A897 6291 Spring Plate Pressure Right 7- 17
A897 6292 Spring Plate Pressure 3- 8
A897 6311 Side Plate Rear 5- 8
A897 6316 Side Plate Front 5- 17
A897 6318 Pin Side Plate 5- 18
A897 6318 Pin Side Plate 3- 13
A897 6321 Guuide Plate Lower 5- 16
A897 6323 Guide Plate Upper 5- 14
A897 6325 Guide Plate Exit 5- 9
A897 6331 Gate Pawl 5- 11
A897 6341 DC Solenoid 5- 1
A897 6342 Bracket DC Solenoid 5- 20
A897 6344 Lever Solenoid 5- 19
Page and
Index No.
Part No.Description
5447 2681 Snap Ring 5- 6
Description
Page and
Index No.
B417 3 Parts Index
Part No.
0313 0040B Philips Pan Head Screw - M3x4 5-108
0313 0220B Philips Pan Head Screw - M3x22 7-110
0314 0080B Philips Pan Head Screw - M4x8 7-108
0450 3008B Tapping Screw - M3x8 7-101
0450 3008B Tapping Screw - M3x8 3-101
0451 3006B Tapping Screw - M3x6 7-103
0451 3006B Tapping Screw - M3x6 5-101
0451 3008H Tapping Screw - M3x8 3-102
0451 3008H Tapping Screw - M3x8 7-104
0720 0040E Retaining Ring - M4 7-102
0720 0040E Retaining Ring - M4 5-102
0802 5276 Tapping Screw With Washer - M3x6 5-105
0805 3385 Bushing - 6mm 5-103
0805 3480 Bushing - 6mm 5-104
0805 3480 Bushing - 6mm 7-109
1102 8502 Connector - 54679-1615 7-105
1105 0283 Clamp 5-107
1105 0310 Harness Clamp - LWS-1S 7-107
1105 0328 Harness Clamp - ES-0505 5-106
1105 0334 Edge - 17 7-106
Page and
Index No.
Part No.Description
Description
Page and
Index No.
B417 4 Parts Index
