BYPASS TRAY B415
PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
1.Bypass Tray 1 (B415)
B415 2 Parts Location and List
1.Bypass Tray 1 (B415)
Index
No.
1 B415 6054 Manual Feed Table 1
2 B415 6100 Cover - Manual Feed Table 1
3 AA06 3653 Spring - 3.1N 2
4 A899 6108 Ground Plate 1
5 G020 2784 Lever - By-pass Feed Table 1
6 G020 2786 Shaft - By-pass Release Lever 1
7 5447 2681 Snap Ring 1
8 A899 6106 Stay Base 1
9 B415 6103 Base Manual Feed 1
10 B415 6101 Guide - Manual Feed Table 1
11 B415 6109 Decal - Paper Set Direction 1
12 G012 3050 Side Fence Gear 1
13 A899 6107 Rotary Switch 1
14 5215 2713 Bottom Plate Pad 1
15 B415 6104 Side Fence - Front 1
16 B415 6105 Side Fence - Rear 1
17 B415 6110 Decal - Side Fence 1
18 A896 1050 Holder 1
19 B414 1320 Cover - Holder Rear 1
20 B414 1310 Cover - Holder Front 1
21 A896 1120 Allen Key 2.5 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3008H Tapping Screw - M3x8
102 0804 6115 Hexagonal Set Screw - M4x12.5
103 0451 3006B Tapping Screw - M3x6
104 0720 0030E Retaining Ring - M3
105 0804 6113 Hexagonal Set Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B415 3 Parts Location and List
2.Bypass Tray 2 (B415)
B415 4 Parts Location and List
2.Bypass Tray 2 (B415)
Index
No.
1 A899 6063 Holder Manual Feed Table 2
2 A899 6060 Side Plate Front 1
3 B415 6091 Cover - Front 1
4 AF03 1058 Paper Feed Roller 1
5 AA14 1084 Feed Shaft 1
6 A899 6076 Guide - Paper End 1
7 A899 6070 Stay Feed Roller 1
8 AF04 0559 Driven Roller - M9 3
9 B415 6090 Cover - Feed 1
10 G020 2772 By-pass Paper End Sensor 1
11 A899 5255 Paper End Harness 1
12 A899 6061 Side Plate Rear 1
13 A899 6080 Bracket Input 1
14 AB01 1202 Gear - Z39/Z31 1
15 AA06 0831 Spring - 3.5n 1
16 B415 6092 Cover - Rear 1
17 AX20 0168 Magnetic Clutch - 0.25n M Z49 1
18 A899 6082 Bracket Drive 1
19 A899 5250 Manual Feed Harness 1
20 A190 2715 Friction Pad Holder 1
21 G020 2713 Pressure Spring 1
22 G030 2670 Friction Pad 1
23 A899 6086 Holder Guide 1
24 A899 6064 Separate Stay 1
26 A899 6087 Spring Washer 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6
102 0805 0089 Retaining Ring - M4
103 0805 3480 Bushing - 6mm
104 0451 3008H Tapping Screw - M3x8
105 1105 0283 Clamp
106 1105 0328 Harness Clamp - ES-0505
107 1105 0487 Harness Clamp
Part No.
Description
Q’ty Per
Assembly
B415 5 Parts Location and List
BYPASS TRAY B415
PARTS INDEX
This section instructs you as to the numbers and names of parts on this machine.
Parts Index
Part No.
B415 6054 Manual Feed Table 2- 1
B415 6090 Cover - Feed 5- 9
B415 6091 Cover - Front 5- 3
B415 6092 Cover - Rear 5- 16
B415 6100 Cover - Manual Feed Table 2- 2
B415 6101 Guide - Manual Feed Table 2- 10
B415 6103 Base Manual Feed 2- 9
B415 6104 Side Fence - Front 2- 15
B415 6105 Side Fence - Rear 2- 16
B415 6109 Decal - Paper Set Direction 2- 11
B415 6110 Decal - Side Fence 2- 17
Page and
Index No.
Part No.Description
AA06 0831 Spring - 3.5n 5- 15
AA06 3653 Spring - 3.1N 2- 3
AA14 1084 Feed Shaft 5- 5
AB01 1202 Gear - Z39/Z31 5- 14
AF03 1058 Paper Feed Roller 5- 4
AF04 0559 Driven Roller - M9 5- 8
AX20 0168 Magnetic Clutch - 0.25n M Z49 5- 17
B414 1310 Cover - Holder Front 2- 20
B414 1320 Cover - Holder Rear 2- 19
G012 3050 Side Fence Gear 2- 12
G020 2713 Pressure Spring 5- 21
G020 2772 By-pass Paper End Sensor 5- 10
G020 2784 Lever - By-pass Feed Table 2- 5
G020 2786 Shaft - By-pass Release Lever 2- 6
G030 2670 Friction Pad 5- 22
Description
Page and
Index No.
B415 2 Parts Index
Part No.
A190 2715 Friction Pad Holder 5- 20
A896 1050 Holder 2- 18
A896 1120 Allen Key 2.5 2- 21
A899 5250 Manual Feed Harness 5- 19
A899 5255 Paper End Harness 5- 11
A899 6060 Side Plate Front 5- 2
A899 6061 Side Plate Rear 5- 12
A899 6063 Holder Manual Feed Table 5- 1
A899 6064 Separate Stay 5- 24
A899 6070 Stay Feed Roller 5- 7
A899 6076 Guide - Paper End 5- 6
A899 6080 Bracket Input 5- 13
A899 6082 Bracket Drive 5- 18
A899 6086 Holder Guide 5- 23
A899 6087 Spring Washer 5- 26
A899 6106 Stay Base 2- 8
A899 6107 Rotary Switch 2- 13
A899 6108 Ground Plate 2- 4
Page and
Index No.
Part No.Description
5215 2713 Bottom Plate Pad 2- 14
5447 2681 Snap Ring 2- 7
Description
Page and
Index No.
B415 3 Parts Index
Part No.
0451 3006B Tapping Screw - M3x6 5-101
0451 3006B Tapping Screw - M3x6 2-103
0451 3008H Tapping Screw - M3x8 5-104
0451 3008H Tapping Screw - M3x8 2-101
0720 0030E Retaining Ring - M3 2-104
0804 6113 Hexagonal Set Screw - M3x8 2-105
0804 6115 Hexagonal Set Screw - M4x12.5 2-102
0805 0089 Retaining Ring - M4 5-102
0805 3480 Bushing - 6mm 5-103
1105 0283 Clamp 5-105
1105 0328 Harness Clamp - ES-0505 5-106
1105 0487 Harness Clamp 5-107
Page and
Index No.
Part No.Description
Description
Page and
Index No.
B415 4 Parts Index
