LARGE CAPACITY TRAY B391
PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
1.EXTERIOR (B391)
B391 2 Parts Location and List
1.EXTERIOR (B391)
Index
No.
1 B390 1255 Left Cover 1 2 A193 1759 Stepped Screw 3 3 B384 1120 Upper Left Stay 2 4 B384 1146 Spring Plate 2 5 B391 1116 Stay - Upper Rear 1 6 B384 1117 Bracket - Upper Rear Stay 1 7 B384 1270 Rear Cover 1 8 A860 6140 Bracket - Joint 1 9 AF02 0409 Driven Roller 1 10 AA08 0254 Bushing - M4 2 11 AA06 3382 Pressure Spring 2 12 B391 2565 Guide Plate - Vertical Transport 1 13 A862 2574 Rear Hook - Vertical Transport 1 14 B391 2560 Cover - Vertical Transport 1 15 AA06 0795 Tension Spring 1 16 B391 2571 Lever - Vertical Transport 1 17 A862 2567 Stopper Vertical Transport 1 18 AA14 0709 Unlock Shaft 1 19 A862 2573 Front Hook - Vertical Transport 1 20 AH01 2026 Caster 4 21 A507 1096 Philips Screw - M5x6 16 22 A860 1125 Adjusting Pin 1 23 A232 2995 Front Positioning Guide 1 24 B384 1110 Upper Front Stay 1 25 A860 6220 Left Stand 1 26 A860 6215 Right Stand 1 27 B390 1265 Right Cover 1 28 A860 6230 Screw - M3 2 29 B384 1131 Front Right Bracket 1 30 AA00 0401 Decal - High Temperature 1 31 B391 7350 Tray Heater - 10W 1 32 A861 5370 AC Harness - Heater 1 33 A680 4351 Screw - M4X17 2 34 B384 1132 Front Left Bracket 1 35 AA14 3508 Flat Knob Screw - M4x10 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6 102 0451 3008H Tapping Screw - M3x8 103 0453 3006B Tapping Screw - M3x6 104 1105 0310 Harness Clamp - LWS-1S 105 0950 3006B Sem,s Screw - M3 X 6 106 0720 0030B Retaining Ring - M3 107 0353 0060B Philips Pan Head Screw - M3x6 108 0452 3008B Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B391 3 Parts Location and List
Rev. 11/22/2002
2.PAPER FEED SECTION (B391)
B391 4 Parts Location and List
Q’ty Per
Index
Q’ty Per
Index
Q’ty Per
Index
Q’ty Per
Index
Rev. 11/22/2002
2.PAPER FEED SECTION (B391)
Part No.
No.
No.
1 A862 2753 Arm Pickup Ass'y 1 2 A232 2781 Sensor Bracket 1 3 AW02 0096 Photointerruptor 1 4 B391 2760 Feed Stay 1 5 AA08 2072 Bushing - M6 3 6 A862 2758 Ground Plate Front 1 7 B391 2751 Housing Paper Feed Unit 1 8 AW02 0056 Photointerruptor - EE-SX4235A-P1 2 9 A232 5428 Harness - Paper Feed Unit 1 10 B391 2752 Guide Plate Housing - Paper Feed 1 11 C218 3051 Philips Screw - M3 1 12 AA08 3014 One-way Clutch 1 13 AA14 0655 Shaft - Paper Feed 1 14 A232 2764 Rear Grounding Plate 1 15 AF02 0404 Transport Roller 1 16 A232 2762 Paper End Feeler 1 17 5447 2681 Snap Ring 2 18 AF03 1035 Feed Roller 1 19 AB01 1189 Gear - 18Z 1 20 AF03 0035 Pick-up Roller 1 21 AB01 1188 Gear - 21Z 1 22 A862 2754 Arm Pickup 1 23 AA06 0691 Tension Spring 1 24 AF03 2035 Separation Roller 1 25 A284 2783 Torque Limiter 1 26 A232 2777 Shaft - Paper Separation 1 27 B391 2765 Stay Separate Ass'y 1 28 5206 2686 Snap Ring 2 29 AA06 0692 Tension Spring 1 30 A232 2774 Pressure Lever 1 31 AB01 0106 Gear - 24Z 1 32 AA14 0656 Shaft - Gear 1 33 AB01 0107 Gear - 23Z 1 34 A232 2775 Link Lever 1 35 A232 2776 Release Lever 1
Part No.
Description
Description
Assembly
Assembly
Part No.
No.
No.
36 AA06 0693 Tension Spring 1 37 B391 2769 Rear Feed Mylar 1 38 A862 2756 Guide Plate Swivel 1 39 AA08 2070 Bushing - 8x16x7 2 40 A862 2755 Pickup Arm Guide 1 41 A232 2766 Feed Mylar 1
101 0453 3006B Tapping Screw - M3x6 102 0450 3008B Tapping Screw - M3x8 103 1105 0283 Clamp 104 0451 3008B Tapping Screw - M3x8 105 0805 0089 Retaining Ring - M4 106 0805 3480 Bushing - 6mm 107 0720 0040E Retaining Ring - M4 108 0720 0060E Retaining Ring - M6 109 0451 3006B Tapping Screw - M3x6
Part No.
Description
Description
Assembly
Assembly
B391 5 Parts Location and List
3.TANDEM TRAY 1 (B391)
B391 6 Parts Location and List
3.TANDEM TRAY 1 (B391)
Index
No.
1 B391 2610 Front Cover 1 2 B391 2612 Decal - Size Indication 1 3 B391 2615 Decal - Paper Set Direction 1 4 AA14 3432 Stepped Screw - M3 2 5 B391 1088 Spring Plate 1 6 AA07 0047 Slide Rail 1 7 A862 2725 End Fence - Tandem Tray 1 8 B391 2770 Timing Belt Cover 1 9 A096 6678 Decal - Left Paper Set 1 10 B391 2771 Positioning Sensor Cover 1 11 B391 2737 Bracket - Paper Volume Sensor 1 12 AW02 0115 Photointerruptor 2 13 A862 5350 Paper Volume Sensor Harness 1 14 B391 2736 Rear Side Fence - Tandem Tray 1 15 AA00 2010 Decal - Paper Level 2 16 B391 2665 Rear Side Fence 1 17 B391 2660 Front Side Fence 1 18 B391 2730 Front Side Fence - Tandem Tray 1 19 B391 2757 Decal - Paper Tray 1 20 AA07 0053 Right Slide Rail 1
Part No.
Description
Qty Per
Assembly
Index
No.
101 0450 3010B Tapping Screw - M3x10 102 0453 3006B Tapping Screw - M3x6 103 0450 3008B Tapping Screw - M3x8 104 0452 3008B Tapping Screw - M3x8 105 1105 0283 Clamp 106 0451 3006B Tapping Screw - M3x6
Part No.
Description
Qty Per
Assembly
B391 7 Parts Location and List
4.TANDEM TRAY 2 (B391)
B391 8 Parts Location and List
4.TANDEM TRAY 2 (B391)
Index
No.
1 A862 2692 Oil Damper 1 2 B391 2691 Damper Bracket 1 3 B391 2639 Roller Plate Bracket 2 4 A335 4351 Guide Roller 4 5 AB01 4135 Gear - 18Z 1 6 AB03 0633 Timing Pulley - Tray Bottom Plate 3 7 5053 0223 Bushing - 8mm 2 8 B391 2673 Stay - Timing Belt 1 9 AA04 3524 Timing Belt - S3M417 2 10 B391 2625 Side Plate - Front LCT 1 11 B391 2631 Balancer - Bottom Plate 1 12 A862 2630 Tray Bottom Plate 1 13 A421 2543 Friction Pad 1 14 A096 6677 Decal - Right Paper Set 1 15 A862 2605 Earth Spring Plate - Paper Tray 1 16 A862 2645 End Fence Rear 1 17 B391 2676 End Fence Bracket 1 18 B391 2635 Side Plate - Rear LCT 1 19 B391 2674 Stay - Timing Belt Rear 1 20 A862 2641 Shaft - Tray Bottom Plate Ass'y 1 21 AA06 0796 Tension Spring - End Fence 2 22 A862 2671 DC Solenoid 1 23 A248 6730 Rear Release Lever 1
Part No.
Description
Qty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6 102 0450 3008B Tapping Screw - M3x8 103 0720 0060B Retaining Ring - M6 104 0623 0140E Spring Pin - 3x14mm 105 0453 3006B Tapping Screw - M3x6 106 1105 0267 Harness Clamp - YMC-10-0 107 0313 0040B Philips Pan Head Screw - M3x4 108 0451 4006B Tapping Screw - 4x6 109 0451 3008B Tapping Screw - M3x8
Part No.
Description
Qty Per
Assembly
B391 9 Parts Location and List
5.TANDEM TRAY 3 (B391)
B391 10 Parts Location and List
5.TANDEM TRAY 3 (B391)
Index
No.
1 AX04 0126 DC Motor - 19.2W 1 2 AB01 3798 Gear - Z18 1 3 5053 0447 Bushing - 6mm 2 4 B391 2741 DC Motor Bracket 1 5 AB01 9475 Gear - 48T 1 6 B391 2745 Timing Belt Bracket 1 7 AB03 3085 Timing Pulley - 15T 1 8 AA04 3525 Timing Belt - S3M600 1 9 B391 2721 Stopper - Timing Belt Slider 1 10 A862 2720 End Fence Slider 1 11 AA14 0711 Timing Pulley Shaft 1 12 B391 2728 Timing Pulley Bracket 1 13 AB03 3084 Timing Pulley - 15T 1 14 AW02 0086 Photointerruptor 2 15 AW02 0112 Photointerruptor 1 16 B391 2722 Bracket - Photointerruptor 1 17 A862 5320 Tray Harness 1 18 A862 2600 Paper Tray 1
Part No.
Description
Qty Per
Assembly
Index
No.
101 0450 3008B Tapping Screw - M3x8 102 0720 0040B Retaining Ring - M4 103 1105 0283 Clamp 104 1105 0310 Harness Clamp - LWS-1S 105 0450 3010B Tapping Screw - M3x10
Part No.
Description
Qty Per
Assembly
B391 11 Parts Location and List
6.DRIVE/ELECTRICAL SECTION (B391)
B391 12 Parts Location and List
6.DRIVE/ELECTRICAL SECTION (B391)
Index
No.
1 A862 5110 Interface Board 1 2 A862 5330 Interface Harness 1 3 A862 5310 Main Harness 1 4 AA14 3510 Drawer Screw 2 5 AA06 3600 Compression Spring 2 6 B391 1131 Drawer Bracket 1 7 AA14 3312 Stepped Screw - M3x10 2 8 G697 1082 Tray Holder 1 9 A862 2650 Moter - Dc18w 1 10 G584 5760 DC Motor - 11.3w 1 11 B391 2808 DC Motor Drive Ass'y 1 12 AB01 4134 Gear - 28Z 1 13 AB01 4133 Gear 60/28z 1 14 B391 2826 Stopper - Magnetic Clutch 1 15 AA08 2047 Bushing - 8x16x7 2 16 AX20 0138 Electrical Clutch - Mice-13 1 17 AB03 0564 Pulley - M17 1 18 B391 2830 Belt Tensioner 1 19 AA06 0797 Spring Belt - Tensioner 1 20 AB03 0575 Timing Pulley - 20T 1 21 AA14 0712 Connecting Shaft 1 22 AB03 0566 Timing Pulley - 20T 1 23 AB01 4136 Gear - 31Z 1 24 AB01 4037 Gear - 24Z 1 25 5053 0447 Bushing - 6mm 1 26 AX20 0153 Electrical Clutch 1 27 AB01 4038 Gear - 22Z 1 28 AA04 3526 Timing Belt - B60S3M312 1 29 AB03 0565 Timing Pulley - 20T 1 30 B391 1126 Bracket - Micro Switch 1 31 AW02 0086 Photointerruptor 6 32 B391 2677 Bracket Detector 1 33 AW50 0022 Push Switch 1 34 AA14 3518 Flat Screw 1 35 B391 2810 Bracket DC DC Motor Drive 1
Part No.
Description
Qty Per
Assembly
Index
No.
101 0451 3006B Tapping Screw - M3x6 102 0451 3008B Tapping Screw - M3x8 103 0353 0060B Philips Pan Head Screw - M3x6 104 0451 3014B Tapping Screw - M3-14 105 1105 0310 Harness Clamp - LWS-1S 106 1105 0192 Locking Support 107 0594 0080Z Bolt - M4x8 108 1105 0348 Clamp 109 1105 0267 Harness Clamp - YMC-10-0 110 1105 0413 Harness Clamp 111 0720 0060E Retaining Ring - M6 112 1204 2356 Microswitch - AM51612A531
Part No.
Description
Qty Per
Assembly
B391 13 Parts Location and List
7.DECALS AND DOCUMENTS (B391)
B391 14 Parts Location and List
7.DECALS AND DOCUMENTS (B391)
Index
No.
1 A096 6677 Decal - Right Paper Set 1 2 A096 6678 Decal - Left Paper Set 1 3 B391 2612 Decal - Size Indication 1 4 B391 2615 Decal - Paper Set Direction 1 5 AA00 0401 Decal - High Temperature 1 6 AA00 2010 Decal - Paper Level 1 7 B391 2757 Decal - Paper Tray 1
Part No.
Description
Qty Per
Assembly
Index
No.
Part No.
Description
Qty Per
Assembly
B391 15 Parts Location and List
LARGE CAPACITY TRAY B391
PARTS INDEX
This section instructs you as to the numbers and names of parts on this machine.

PM Parts Index

Section Name
PAPER FEED SECTION (B391) AF03 1035 Feed Roller Feed Roller 1 5- 10 AF03 0035 Pick-up Roller Pick-up Roller 1 5- 20 AF03 2035 Separation Roller Separation Roller 1 5- 24
Part No.
Description in Service Manu al
Description in Parts Catalog
Q’ty Per
Assembly
Page and
Index No.
B391 2 Parts Index

Parts Index

Part No.
B391 1088 Spring Plate 7- 5 B391 1116 Stay - Upper Rear 3- 5 B391 1126 Bracket - Micro Switch 13- 30 B391 1131 Drawer Bracket 13- 6 B391 2560 Cover - Vertical Transport 3- 14 B391 2565 Guide Plate - Vertical Transport 3- 12 B391 2571 Lever - Vertical Transport 3- 16 B391 2610 Front Cover 7- 1 B391 2612 Decal - Size Indication 15- 3 B391 2612 Decal - Size Indication 7- 2 B391 2615 Decal - Paper Set Direction 7- 3 B391 2615 Decal - Paper Set Direction 15- 4 B391 2625 Side Plate - Front LCT 9- 10 B391 2631 Balancer - Bottom Plate 9- 11 B391 2635 Side Plate - Rear LCT 9- 18 B391 2639 Roller Plate Bracket 9- 3 B391 2660 Front Side Fence 7- 17 B391 2665 Rear Side Fence 7- 16 B391 2673 Stay - Timing Belt 9- 8 B391 2674 Stay - Timing Belt Rear 9- 19 B391 2676 End Fence Bracket 9- 17 B391 2677 Bracket Detector 13- 32 B391 2691 Damper Bracket 9- 2 B391 2721 Stopper - Timing Belt Slider 11- 9 B391 2722 Bracket - Photointerruptor 11- 16 B391 2728 Timing Pulley Bracket 11- 12 B391 2730 Front Side Fence - Tandem Tray 7- 18 B391 2736 Rear Side Fence - Tandem Tray 7- 14 B391 2737 Bracket - Paper Volume Sensor 7- 11 B391 2741 DC Motor Bracket 11- 4 B391 2745 Timing Belt Bracket 11- 6 B391 2751 Housing Paper Feed Unit 5- 7 B391 2752 Guide Plate Housing - Paper Feed 5- 10 B391 2757 Decal - Paper Tray 15- 7 B391 2757 Decal - Paper Tray 7- 19
Page and Index No.
Part No.Description
B391 2760 Feed Stay 5- 4 B391 2765 Stay Separate Ass'y 5- 27 B391 2769 Rear Feed Mylar 5- 37 B391 2770 Timing Belt Cover 7- 8 B391 2771 Positioning Sensor Cover 7- 10 B391 2808 DC Motor Drive Ass'y 13- 11 B391 2810 Bracket DC DC Motor Drive 13- 35 B391 2826 Stopper - Magnetic Clutch 13- 14 B391 2830 Belt Tensioner 13- 18 B391 7350 Tray Heater - 10W 3- 31
Description
Page and Index No.
B391 3 Parts Index
Part No.
AA00 0401 Decal - High Temperature 15- 5 AA00 0401 Decal - High Temperature 3- 30 AA00 2010 Decal - Paper Level 15- 6 AA00 2010 Decal - Paper Level 7- 15 AA04 3524 Timing Belt - S3M417 9- 9 AA04 3525 Timing Belt - S3M600 11- 8 AA04 3526 Timing Belt - B60S3M312 13- 28 AA06 0691 Tension Spring 5- 23 AA06 0692 Tension Spring 5- 29 AA06 0693 Tension Spring 5- 36 AA06 0795 Tension Spring 3- 15 AA06 0796 Tension Spring - End Fence 9- 21 AA06 0797 Spring Belt - Tensioner 13- 19 AA06 3382 Pressure Spring 3- 11 AA06 3600 Compression Spring 13- 5 AA07 0047 Slide Rail 7- 6 AA07 0053 Right Slide Rail 7- 20 AA08 0254 Bushing - M4 3- 10 AA08 2047 Bushing - 8x16x7 13- 15 AA08 2070 Bushing - 8x16x7 5- 39 AA08 2072 Bushing - M6 5- 5 AA08 3014 One-way Clutch 5- 12 AA14 0655 Shaft - Paper Feed 5- 13 AA14 0656 Shaft - Gear 5- 32 AA14 0709 Unlock Shaft 3- 18 AA14 0711 Timing Pulley Shaft 11- 11 AA14 0712 Connecting Shaft 13- 21 AA14 3312 Stepped Screw - M3x10 13- 7 AA14 3432 Stepped Screw - M3 7- 4 AA14 3508 Flat Knob Screw - M4x10 3- 35 AA14 3510 Drawer Screw 13- 4 AA14 3518 Flat Screw 13- 34 AB01 0106 Gear - 24Z 5- 31 AB01 0107 Gear - 23Z 5- 33 AB01 1188 Gear - 21Z 5- 21
Page and Index No.
Part No.Description
AB01 1189 Gear - 18Z 5- 19 AB01 3798 Gear - Z18 11- 2 AB01 4037 Gear - 24Z 13- 24 AB01 4038 Gear - 22Z 13- 27 AB01 4133 Gear 60/28z 13- 13 AB01 4134 Gear - 28Z 13- 12 AB01 4135 Gear - 18Z 9- 5 AB01 4136 Gear - 31Z 13- 23 AB01 9475 Gear - 48T 11- 5 AB03 0564 Pulley - M17 13- 17 AB03 0565 Timing Pulley - 20T 13- 29 AB03 0566 Timing Pulley - 20T 13- 22 AB03 0575 Timing Pulley - 20T 13- 20 AB03 0633 Timing Pulley - Tray Bottom Plate 9- 6 AB03 3084 Timing Pulley - 15T 11- 13 AB03 3085 Timing Pulley - 15T 11- 7 AF02 0404 Transport Roller 5- 15 AF02 0409 Driven Roller 3- 9 AF03 0035 Pick-up Roller 5- 20 AF03 1035 Feed Roller 5- 18 AF03 2035 Separation Roller 5- 24 AH01 2026 Caster 3- 20 AW02 0056 Photointerruptor - EE-SX4235A-P1 5- 8 AW02 0086 Photointerruptor 13- 31 AW02 0086 Photointerruptor 11- 14 AW02 0096 Photointerruptor 5- 3 AW02 0112 Photointerruptor 11- 15 AW02 0115 Photointerruptor 7- 12 AW50 0022 Push Switch 13- 33 AX04 0126 DC Motor - 19.2W 11- 1 AX20 0138 Electrical Clutch - Mice-13 13- 16 AX20 0153 Electrical Clutch 13- 26 B384 1110 Upper Front Stay 3- 24 B384 1117 Bracket - Upper Rear Stay 3- 6 B384 1120 Upper Left Stay 3- 3
Description
Page and Index No.
B391 4 Parts Index
Page and
Part No. Description
Part No.
B384 1131 Front Right Bracket 3- 29 B384 1132 Front Left Bracket 3- 34 B384 1146 Spring Plate 3- 4 B384 1270 Rear Cover 3- 7 B390 1255 Left Cover 3- 1 B390 1265 Right Cover 3- 27 C218 3051 Philips Screw - M3 5- 11 G584 5760 DC Motor - 11.3w 13- 10 G697 1082 Tray Holder 13- 8
Page and Index No.
Index No.
Part No.Description
Part No.Description
A096 6677 Decal - Right Paper Set 15- 1 A096 6677 Decal - Right Paper Set 9- 14 A096 6678 Decal - Left Paper Set 15- 2 A096 6678 Decal - Left Paper Set 7- 9 A193 1759 Stepped Screw 3- 2 A232 2762 Paper End Feeler 5- 16 A232 2764 Rear Grounding Plate 5- 14 A232 2774 Pressure Lever 5- 30 A232 2775 Link Lever 5- 34 A232 2776 Release Lever 5- 35 A232 2777 Shaft - Paper Separation 5- 26 A232 2781 Sensor Bracket 5- 2 A232 2995 Front Positioning Guide 3- 23 A232 5428 Harness - Paper Feed Unit 5- 9 A248 6730 Rear Release Lever 9- 23 A284 2783 Torque Limiter 5- 25 A335 4351 Guide Roller 9- 4 A421 2543 Friction Pad 9- 13 A507 1096 Philips Screw - M5x6 3- 21 A680 4351 Screw - M4X17 3- 33 A860 1125 Adjusting Pin 3- 22 A860 6140 Bracket - Joint 3- 8 A860 6215 Right Stand 3- 26 A860 6220 Left Stand 3- 25 A860 6230 Screw - M3 3- 28 A861 5370 AC Harness - Heater 3- 32 A862 2567 Stopper Vertical Transport 3- 17 A862 2573 Front Hook - Vertical Transport 3- 19 A862 2574 Rear Hook - Vertical Transport 3- 13 A862 2600 Paper Tray 11- 18 A862 2605 Earth Spring Plate - Paper Tray 9- 15 A862 2630 Tray Bottom Plate 9- 12 A862 2641 Shaft - Tray Bottom Plate Ass'y 9- 20 A862 2645 End Fence Rear 9- 16 A862 2650 Moter - Dc18w 13- 9
Description
Page and
Page and Index No.
Index No.
B391 5 Parts Index
Part No.
A862 2671 DC Solenoid 9- 22 A862 2692 Oil Damper 9- 1 A862 2720 End Fence Slider 11- 10 A862 2725 End Fence - Tandem Tray 7- 7 A862 2753 Arm Pickup Ass'y 5- 1 A862 2754 Arm Pickup 5- 22 A862 2755 Pickup Arm Guide 5- 40 A862 2756 Guide Plate Swivel 5- 38 A862 2758 Ground Plate Front 5- 6 A862 5110 Interface Board 13- 1 A862 5310 Main Harness 13- 3 A862 5320 Tray Harness 11- 17 A862 5330 Interface Harness 13- 2 A862 5350 Paper Volume Sensor Harness 7- 13
Page and Index No.
Part No.Description
5053 0223 Bushing - 8mm 9- 7 5053 0447 Bushing - 6mm 11- 3 5053 0447 Bushing - 6mm 13- 25 5206 2686 Snap Ring 5- 28 5447 2681 Snap Ring 5- 17
Description
Page and Index No.
B391 6 Parts Index
Part No.
0313 0040B Philips Pan Head Screw - M3x4 9-107 0353 0060B Philips Pan Head Screw - M3x6 13-103 0353 0060B Philips Pan Head Screw - M3x6 3-107 0450 3008B Tapping Screw - M3x8 11-101 0450 3008B Tapping Screw - M3x8 9-102 0450 3008B Tapping Screw - M3x8 5-102 0450 3008B Tapping Screw - M3x8 7-103 0450 3010B Tapping Screw - M3x10 11-105 0450 3010B Tapping Screw - M3x10 7-101 0451 3006B Tapping Screw - M3x6 5-109 0451 3006B Tapping Screw - M3x6 13-101 0451 3006B Tapping Screw - M3x6 9-101 0451 3006B Tapping Screw - M3x6 7-106 0451 3006B Tapping Screw - M3x6 3-101 0451 3008B Tapping Screw - M3x8 5-104 0451 3008B Tapping Screw - M3x8 13-102 0451 3008B Tapping Screw - M3x8 9-109 0451 3008H Tapping Screw - M3x8 3-102 0451 3014B Tapping Screw - M3-14 13-104 0451 4006B Tapping Screw - 4x6 9-108 0452 3008B Tapping Screw - M3x8 7-104 0452 3008B Tapping Screw - M3x8 3-108 0453 3006B Tapping Screw - M3x6 7-102 0453 3006B Tapping Screw - M3x6 3-103 0453 3006B Tapping Screw - M3x6 5-101 0453 3006B Tapping Screw - M3x6 9-105 0594 0080Z Bolt - M4x8 13-107 0623 0140E Spring Pin - 3x14mm 9-104 0720 0030B Retaining Ring - M3 3-106 0720 0040B Retaining Ring - M4 11-102 0720 0040E Retaining Ring - M4 5-107 0720 0060B Retaining Ring - M6 9-103 0720 0060E Retaining Ring - M6 13-111 0720 0060E Retaining Ring - M6 5-108 0805 0089 Retaining Ring - M4 5-105
Page and Index No.
Part No.Description
0805 3480 Bushing - 6mm 5-106 0950 3006B Sem,s Screw - M3 X 6 3-105 1105 0192 Locking Support 13-106 1105 0267 Harness Clamp - YMC-10-0 13-109 1105 0267 Harness Clamp - YMC-10-0 9-106 1105 0283 Clamp 7-105 1105 0283 Clamp 5-103 1105 0283 Clamp 11-103 1105 0310 Harness Clamp - LWS-1S 13-105 1105 0310 Harness Clamp - LWS-1S 3-104 1105 0310 Harness Clamp - LWS-1S 11-104 1105 0348 Clamp 13-108 1105 0413 Harness Clamp 13-110 1204 2356 Microswitch - AM51612A531 13-112
Description
Page and Index No.
B391 7 Parts Index

TECHNICAL SERVICE BULLETINS

TECHNICAL SERVICE BULLETIN
BULLETIN NUMBER: B391 – 001 11/21/2002
APPLICABLE MODEL: GESTETNER – PS500 for 2212/2712 RICOH – PS500 for AFICIO 1022/1027 SAVIN – PS500 for 2522/2527
Note: This copy is intended as a master original
for reproduction of additional bulletins.
SUBJECT: FEED MYLAR
GENERAL:
The Feed Mylar for the Paper Feed Section was omitted from the B391 Parts Catalog. The following part correction is being issued for all B391 Parts Catalogs. Also, please correct the illustration on page 4 of the B391 Parts Catalog by adding item number 41 to the Feed Mylar as shown in the illustration below.
PARTS
REFERENCE
PART NUMBER DESCRIPTION QTY PAGE ITEM
A2322766 Feed Mylar 1 5 41 *
DENOTES NEW ITEM NUMBER
*
Copyright
 2002 RICOH Corporation. All rights reserved.
