Ricoh AP505 User Manual

OPERATING INSTRUCTIONS

Printer Reference

Read this manual carefully before you use this product and keep it handy for future reference. For safety, please follow the instructions in this manual.

RICOH COMPANY, LTD.

15-5, 1 chome, Minami-Aoyama, Minato-ku, Tokyo Telephone: Tokyo 3479-3111

RICOH COLOR LASER AP505 OPERATING INSTRUCTIONS

Overseas Affiliates

U.S.A.

RICOH CORPORATION 5 Dedrick Place West Caldwell, New Jersey 07006 Phone: +1-973-882-2000

The Netherlands

RICOH EUROPE B.V. Groenelaan 3, 1186 AA, Amstelveen Phone: +31-(0)20-5474111

United Kingdom

RICOH UK LTD. Ricoh House, 1 Plane Tree Crescent, Feltham, Middlesex, TW13 7HG Phone: +44-(0)181-261-4000

Germany

RICOH DEUTSCHLAND GmbH Mergenthalerallee 38-40, 65760 Eschborn Phone: +49-(0)6196-9060

France

RICOH FRANCE S.A. 383, Avenue du Général de Gaulle BP 307-92143 Clamart Cedex Phone: +33-(0)1-40-94-38-38

Spain

RICOH ESPAÑA S.A. Avda. Litoral Mar, 12-14, 08005 Barcelona Phone: +34-(0)93-295-7600

Italy

RICOH ITALIA SpA Via della Metallurgia 12, 37139 Verona Phone: +39-(0)45-8181500

Hong Kong

RICOH HONG KONG LTD. 23/F., China Overseas Building, 139, Hennessy Road, Wan Chai, Hong Kong Phone: +852-2862-2888

Singapore

RICOH ASIA PACIFIC PTE.LTD. 260 Orchard Road, #15-01/02 The Heeren, Singapore 238855 Phone: +65-830-5888

Model number: G024–17 Printed in Japan UE USA G024-8637

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get maximum versatil ity from this ma chine all opera tors sho uld careful ly read an d follow the ins tructi ons in this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Power Source

120 V, 60 Hz, 10 A or more Please be sure to connect the power cord to a power source as above.

Operator Safety:

This machine is considered a CDRH clas s I lase r devi ce, safe for office/ EDP use. Th e ma chine con tains 10-milliwatt, 760 - 800 nanometer wavelength, GaAIAs laser diode. Direct (or indirect reflected) eye contact with the laser beam might cause serious eye damage. Safety precautions and interlock mechanisms have been designed to prevent any possible laser beam exposure to the operator.

Laser Safety:

The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical unit in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and laser subsystems to the fac tory or se rvice d epot when replace ment or the op tical subsyste m is required.

Important

Parts of this manual are subject to change without prior notice. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages as a result of handling or operating the machine.

Caution:

Use of controls or adjustment or performance of procedures other than those specified in this manual might result in hazardous radiation exposure.

Do not attempt any mainte nance or troub leshooti ng other th an that ment ioned in this manual. Th is machine contains a laser beam generator and direct exposure to laser beams can cause permanent eye damage.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version. Ricoh shall not be resp onsib le for any damag e or exp ense that m ight res ult fr om the u se of part s other

than genuine Ricoh parts in your Ricoh office product. For good copy quality, Ricoh recommends that you use genuine Ricoh toner.

Note to users in the United States of America

Notice:

This equipment has been tes t ed and found to comply with the limits fo r a Cl ass B digital device, pursuant to Part 15 of the FCC Ru le s . Th ese limits are designe d to pr ovi de reasonable protect i on against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and us ed in accord ance with the instru ctions, may cau se harmful int erference to rad io communications.

However, there is no guar antee that inter ference will not occur in a particular i nstallation. If this eq uipment does cause harmful interference to radio or telev ision reception, which can be de termined by turning the equipment off and on, the use r is encou raged to try to correct the int erfere nce by o ne mor e of the f ollowi ng measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected. Consult the dealer or an experienced radio/TV tech nician f or he lp.

Warning

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operat e the equipment.

Caution (in case of 100BaseTX environment):

Properly shielded and grounded cables (STP) and connectors must be used for connections to host computer (and/or periph eral) in order to meet FC C emission limits.

Declaration of Conformity

Product Name: Printer Model Number: G0 24– 17 Responsible part y: R ic oh Corporation Address: 5 Dedrick Place, West Caldwell, NJ 07006 Telephone number : 973- 882-2000 This device complies with part 15 of FCC Rules. Operation is subject t o the fo l lo win g t w o co ndi t i ons :

1. This device may not cause harmful interf er ence, and

2. this device must accept any interference received, including interfer ence that may cause un desired operation.

Properly shielded cables m ust be u sed for co nnections to host com puter (a nd/or peri pheral) in order to meet FCC emission limits .

Network interface cable with ferrite core mus t be used for RF interfer ence suppression.

Note to users in Canada

Note:

This Class B digital apparatus complies with Canadian ICES-003.

Remarque concernant les utilisateurs au Canada

Avertissement:

Cet appareil numéri q ue de la classe B est conforme à l a nor m e N M B- 003 du Canada.

In accordance wi th IEC 60417, this machine uses the following sym bols for the main powe r switch:

a

means POWER ON.

b

means POWER OFF.

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get maximum versatil ity from this ma chine all opera tors sho uld careful ly read an d follow the ins tructi ons in this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Power Source

120 V, 60 Hz, 10 A or more Please be sure to connect the power cord to a power source as above.

Operator Safety:

This machine is considered a CDRH clas s I lase r devi ce, safe for office/ EDP use. Th e ma chine con tains 10-milliwatt, 760 - 800 nanometer wavelength, GaAIAs laser diode. Direct (or indirect reflected) eye contact with the laser beam might cause serious eye damage. Safety precautions and interlock mechanisms have been designed to prevent any possible laser beam exposure to the operator.

Laser Safety:

The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical unit in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and laser subsystems to the fac tory or se rvice d epot when replace ment or the op tical subsyste m is required.

Important

Parts of this manual are subject to change without prior notice. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages as a result of handling or operating the machine.

Caution:

Use of controls or adjustment or performance of procedures other than those specified in this manual might result in hazardous radiation exposure.

Do not attempt any mainte nance or troub leshooti ng other th an that ment ioned in this manual. Th is machine contains a laser beam generator and direct exposure to laser beams can cause permanent eye damage.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version. Savin shall not be responsi ble for any damage or expens e that mi ght resul t from the us e of parts ot her

than genuine Savin parts in your Savin office product. For good copy quality, Savin recommends that you use genuine Savin toner.

Note to users in the United States of America

Notice:

This equipment has been tes t ed and found to comply with the limits fo r a Cl ass B digital device, pursuant to Part 15 of the FCC Ru le s . Th ese limits are designe d to pr ovi de reasonable protect i on against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and us ed in accord ance with the instru ctions, may cau se harmful int erference to rad io communications.

However, there is no guar antee that inter ference will not occur in a particular i nstallation. If this eq uipment does cause harmful interference to radio or telev ision reception, which can be de termined by turning the equipment off and on, the use r is encou raged to try to correct the int erfere nce by o ne mor e of the f ollowi ng measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected. Consult the dealer or an experienced radio/TV tech nician f or he lp.

Warning

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operat e the equipment.

Caution (in case of 100BaseTX environment):

Properly shielded and grounded cables (STP) and connectors must be used for connections to host computer (and/or periph eral) in order to meet FC C emission limits.

Declaration of Conformity

Product Name: Printer Model Number: G0 24– 17 Responsible part y: R ic oh Corporation Address: 5 Dedrick Place, West Caldwell, NJ 07006 Telephone number : 973- 882-2000 This device complies with part 15 of FCC Rules. Operation is subject t o the fo l lo win g t w o co ndi t i ons :

1. This device may not cause harmful interf er ence, and

2. this device must accept any interference received, including interfer ence that may cause un desired operation.

Properly shielded cables m ust be u sed for co nnections to host com puter (a nd/or peri pheral) in order to meet FCC emission limits .

Network interface cable with ferrite core mus t be used for RF interfer ence suppression.

Note to users in Canada

Note:

This Class B digital apparatus complies with Canadian ICES-003.

Remarque concernant les utilisateurs au Canada

Avertissement:

Cet appareil numéri q ue de la classe B est conforme à l a nor m e N M B- 003 du Canada.

In accordance wi th IEC 60417, this machine uses the following sym bols for the main powe r switch:

a

means POWER ON.

b

means POWER OFF.

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get maximum versatil ity from this ma chine all opera tors sho uld careful ly read an d follow the ins tructi ons in this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Power Source

120 V, 60 Hz, 10 A or more Please be sure to connect the power cord to a power source as above.

Operator Safety:

This machine is considered a CDRH clas s I lase r devi ce, safe for office/ EDP use. Th e ma chine con tains 10-milliwatt, 760 - 800 nanometer wavelength, GaAIAs laser diode. Direct (or indirect reflected) eye contact with the laser beam might cause serious eye damage. Safety precautions and interlock mechanisms have been designed to prevent any possible laser beam exposure to the operator.

Laser Safety:

The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical unit in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and laser subsystems to the fac tory or se rvice d epot when replace ment or the op tical subsyste m is required.

Important

Parts of this manual are subject to change without prior notice. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages as a result of handling or operating the machine.

Caution:

Use of controls or adjustment or performance of procedures other than those specified in this manual might result in hazardous radiation exposure.

Do not attempt any mainte nance or troub leshooti ng other th an that ment ioned in this manual. Th is machine contains a laser beam generator and direct exposure to laser beams can cause permanent eye damage.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version. Gestetner shall not be responsible for any damage or expense that might result from the use of parts

other than genuine Gestetner parts in your Gestetner office product. For good copy quality, Gestetner recommends that you use genuine Gestetner toner.

Note to users in the United States of America

Notice:

This equipment has been tes t ed and found to comply with the limits fo r a Cl ass B digital device, pursuant to Part 15 of the FCC Ru le s . Th ese limits are designe d to pr ovi de reasonable protect i on against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and us ed in accord ance with the instru ctions, may cau se harmful int erference to rad io communications.

However, there is no guar antee that inter ference will not occur in a particular i nstallation. If this eq uipment does cause harmful interference to radio or telev ision reception, which can be de termined by turning the equipment off and on, the use r is encou raged to try to correct the int erfere nce by o ne mor e of the f ollowi ng measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected. Consult the dealer or an experienced radio/TV tech nician f or he lp.

Warning

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operat e the equipment.

Caution (in case of 100BaseTX environment):

Properly shielded and grounded cables (STP) and connectors must be used for connections to host computer (and/or periph eral) in order to meet FC C emission limits.

Declaration of Conformity

Product Name: Printer Model Number: G0 24– 17 Responsible part y: R ic oh Corporation Address: 5 Dedrick Place, West Caldwell, NJ 07006 Telephone number : 973- 882-2000 This device complies with part 15 of FCC Rules. Operation is subject t o the fo l lo win g t w o co ndi t i ons :

1. This device may not cause harmful interf er ence, and

2. this device must accept any interference received, including interfer ence that may cause un desired operation.

Properly shielded cables m ust be u sed for co nnections to host com puter (a nd/or peri pheral) in order to meet FCC emission limits .

Network interface cable with ferrite core mus t be used for RF interfer ence suppression.

Note to users in Canada

Note:

This Class B digital apparatus complies with Canadian ICES-003.

Remarque concernant les utilisateurs au Canada

Avertissement:

Cet appareil numéri q ue de la classe B est conforme à l a nor m e N M B- 003 du Canada.

In accordance wi th IEC 60417, this machine uses the following sym bols for the main powe r switch:

a

means POWER ON.

b

means POWER OFF.

Trademarks

Windows®, and Windows NT® are registered trademarks of Microsoft Corporation in the United States and/or other countries.

PostScript

®

is a registered trademark of Adobe Systems. Incorporated. AppleTalk is registered trademarks of Apple Computer, Incorporated. Other product names used herein are for identification purposes only and might

be trademarks of their respective companies. We disclaim any and all rights in those marks.

Notes:

Some illustrations might be slightly different from your machine. Certain options might not be available in some countries. For details, please con-

tact your local dealer.

Notes:

The proper names of the Windows operating systems are as follows:

• Microsoft

®

Windows® 95 operating system

®

Windows® 98 operating system

®

Windows NT® Server network operating system Version 4.0

®

Windows NT® Workstation operating system Version 4.0

i

Safety Information

R

When using your equipment, the following safety precautions should always be followed.

Safety During Operation

In this manual, the following important symbols are used:

R

WARNING:

CAUTION:

Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.

Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.

ii

R

WARNING:

Connect the power cord directly into a wall outlet and never use an ex-

•

tension cord.

•

Disconnect the power plu g (by pulling the plug, not the cable ) if the power cable or plug becom es frayed or otherwise damag ed .

•

To avoid hazardous electric shock or laser radiation exposure, do not remove any covers or screws other than those specified in this manual.

•

Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if any of the following conditions exists:

•

You spill something into the equipment.

•

You suspect that your equipment needs service or repair.

•

Your equipment's cover has been damaged.

•

Do not incinerat e spi lled ton er or us ed tone r. To ner du st might ignit e when exposed to an open flame.

•

Disposal can take place at our authorized dealer or at appropriate collection sites.

•

If you dispose of the used toner containers yourself, dispose of them according to your lo cal regulations.

iii

R

CAUTION:

Protect the equipment from dampness or wet weather, such as rain, snow,

•

and so on. Unplug the power cord from the wall socket before you move the equip-

•

ment. While moving the equipment, you should take care that the power cord will not be damaged under the equipment.

When you disconnect the power plug from the wall socket, always pull the

•

plug (not the cable). Do not allow paper clips, staples, or other small metallic objects to fall in-

•

side the equipment. Do not eat or swallow toner.

•

Keep toner (used or unused) and toner cartridge out of reach of children.

•

For environmental reasons, do not dispose of the equipment or expended

•

supply's wastes at a household waste a collection point. Disposal can take place at our authorized dealer or at an appropriate collection site.

Our products are engineered to meet the highest standards of quality and

•

functionality. When purchasing expendable supplies, we recommend using only those specified by an authorized dealer.

The inside of the machine could be very hot. Do not touch the parts with a

•

label indicating the “hot surface”. Otherwise, it could cause a personal burn. If you use this printer in a cold area, leave the printer on. Otherwise, severe

•

cold might damage sensitive components inside the printer.

iv

Energy Star Program

As an ENERGY STAR Partner, we have determined that this machine model meets the ENERGY STAR Guidelines for energy efficiency.

The ENERGY STAR Guidelines intend to establish an international energy-saving system for developing and introducing energy-efficient office equipment to deal with environmental issues, such as global warming.

When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall place the ENERGY STAR logo onto the machine model.

This product was designed to reduce the environmental impact associated with office equipment by means of energy-saving features, such as Low-power mode.

❖

Low-power mode (Energy Save mode)

This printer automatically lowers its power consumption 60 minutes after the last operation has been completed when the Energy Save mode is set to level

1. To exit Low-power (Energy Save) mode, press any key on the operation panel. To change the setting of the Energy Save mode, see the “Getting Started”.

❖

Specifications

Lower-power mode (Energy Save mode)

Recycled Paper

-

Power Consumption 45W or less Default Time 60 minutes

Please contact your sales or service representative for recommended recycled paper types that may be used in this machine.

v

Manuals for Your Printer

There are four manuals that describe the procedures separately for the installation of your printer and for the operation and maintenance of your printer and its optional equipment.

To enhance safe and efficient operation of your printer, all users should read and follow the instructions contained in the following manuals.

❖

Quick Installation Guide

Describes the procedures for installing your printer.

❖

Getting Started

Describes how to install software to enable users to print. Specifically, it describes installation of PostScript printer drivers, printer description files, and other software provided on the CD-ROM that comes with the printer. It also explains how to connect each user to the network.

❖

User's Guide

Provides an introduction to desktop color printing, how to print from various computers and workstations, what you need to know about using the printer in a networked environment, and how to use the software provided.

❖

Printer Reference (this manual)

Describes the procedures and necessary information on setting up and using your printer and its optional equipment.

vi

How to Read this Manual

R

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.

CAUTION:

This symbol indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before operating.

Note

This symbol indicates precautions for operation, or actions to take after misoperation.

Limitation

This symbol indicates numerical limits, functions that cannot be used together, or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's panel display. Keys and buttons that appear on the computer's display.

{}

Keys built into the machine's operation panel. Keys on the computer's keyboard.

vii

1. Getting Acquainted

Guide to the Printer

Exterior-Fron t View

12 3 4 5 6 7

8

9

1. Power Switch

Use this switch to turn printer power on and off.

2. Fuser Oil Bottle Cover

Open this cover when replacing the fuser oil bottle.

3. Output Tray

Printed pages are stacked here.

4. Output Tray Extender

Pull out this extender when printing on long paper.

5. Operation Panel

Contains keys for printer operation and a panel display that shows the printer status.

10 11

TFWX020E

8. Left Cover

Open this cover when replacing the toner cartridge.

9. Inset Grips

Hold the printer at the location indicated in the illustration when transporting it. Note that there are four grips, two on the left side and two on the right side of the printer.

6. Front Cover Release Button

Use this button to open the front cover.

7. Front Cover

Open this cover when accessing the inside of the printer.

TFWX030E

1

Getting Acquainted

10. Bypass tray

Use to print on to thick paper, OHP transparencies and adhesive labels in addition to plain paper.

1

11. Paper Tray

Load paper into this tray for printing.

2

Exterior-Rear View

3 4

5

Guide to the Printer

12

1

68

1. Paper Exit Cover

Open this cover when removing misfed paper at the fusing unit.

2. Ozone Filter

This filter reduces the amount of ozone that is discharged into the air.

3. Ventilator

This hole allow air to circulate, preventing components inside the printer from overheating.

Important

❒

Do not leave the ventilator obstructed or blocked. Doing so creates the danger of malfunction due to overheating.

4. Back Plate

Remove to install some options.

5. Parallel Interface Connector

Plug the interface cable that connects the printer to your computer into this connector.

Important

❒

Rating voltage of the parallel interface connector for the computer; Max. DC 5V.

6. Network Interface Connector for

10BASE-T/100BASE-TX

79

Plug the network interface cable for 10BASE-T/100BASE-TX that connects the printer to the network into this connector.

Important

❒

Rating voltage of the network in-

TFWX040E

terface connector for 10BASE-T/ 100BASE-TX; Max. DC5V.

7. Network Interface Connector for

10BASE5

Plug the network interface cable for 10BASE5 that connects the printer to the network into this connector.

Important

❒

Rating voltage of the network interface connector for 10BASE5; Max. DC12V.

8. Ventilator

This hole allow air to circulate, preventing components inside the printer from overheating.

Important

❒

Do not leave the ventilator obstructed or blocked. Doing so creates the danger of malfunction due to overheating.

9. Power Connector

Connect the power cord to this connector.

3

Getting Acquainted

Interior

1

12 3456

1. Toner Cartridge

2. Fuser Oil Bottle

This bottle holds oil used for fusing toner to the paper.

3. Ozone Filters

These filters reduce the amount of ozone that is discharged into the air.

Do not rotate the gear on the right side

❒

of the printer. Otherwise, the inside b e l t g e t s d a m a g e d .

TFWX051E

4. Charger

5. Waste Toner Bottle

This bottle is a receptacle for waste toner generated during the printing process.

6. Photoconductor Unit

This contains a photoconductor unit that is used to compose the image being printed.

Note

Screws are used to hold the photocon-

❒

ductor unit in place. Be sure to remove the screws before attempting to remove the unit.

The condition of the photoconductor

❒

unit belt directly affects output appearance and quality. Always be careful to prevent the green film in this unit from becoming dirty or damaged. And do not touch the black belt.

4

TFWX060E

Guide to the Printer

Operation Panel

Important

❒

Never press any operation panel keys while the Data In indicator is flashing on the operation panel.

3 41

2

On Line

1

Power Error Data In

8

9

1. Panel Display

The display shows the current status of the printer and error messages. ⇒ P.29

“Error & Status Messages on the Operation Panel”

2. On Line indicator

Tells you whether the printer is on-line or off-line.

Stays on while the printer is on-line (a state in which the printer can receive data from the computer).

Stays off when the printer is off-line (a state in which printer cannot receive data).

key

}

key

}

keys

3.

On Line

{

Press this key to switch the printer between on-line and off-line conditions.

4.

{W}{U}{V}{T }

Use these keys to select values on the panel display when making settings.

5.

Menu

{

Press this key to make and check the printer settings.

Cancel

{

Enter

{

7

Enter

}

key

}

TFWS010E

key

Cancel

Menu

6

5

10

6.

Pressing this key cancels the ongoing print job.

7.

Press this key to execute menu items selected on the panel display.

8. Power indicator

Stays on while the printer power is on. Stays off when the power is turned off or while the printer is in the Energy Save mode.

Blinks while the printer is warming up.

9. Error indicator

Lights up whenever any printer error occurs. A message describing the cause of the error also appears on the panel display. ⇒ P.29

the Operation Panel”

“Error & Status Messages on

10. Data In indicator

Blinks while the printer is communicating via the network with the network utility of client computers.

5

Getting Acquainted

Turning the Printer On and Off

1

Turning On the Printer

A Make sure that the power cord is

securely plugged into the wall socket and the printer.

B Set the printer's power switch to

the On position.

TFWX130E

After turning on the printer, it takes about eight minutes to warm up before being able to print.

When the printer is turned on, the Power indicator will blink repeatedly. Once it stops blinking and remains on, you will be able to send data from the computer to the printer. When the following message appears on the operation panel, the printer will be able to begin printing.

Turning Off the Pri nter

A Confirm that the Data In and the

Error indicators are off.

Note

❒

The Data In indicator blinks while receiving and printing data from the computer and remains lit when printing. Do not turn off the printer while it is blinking.

❒

When the Error indicator lights up, a printer error has occurred. Use the message that appears on the operation panel to troubleshoot the problem.

B Set the printer's power switch to

the Off position.

TFWX110E

The Power indicator turns off.

READY

6

Note

❒

After printing, wait for about two minutes before turning off the printer. The printer uses this time to maintain itself. Turning off the printer immediately after printing may, over time, reduce the print quality.

2. Installing Options

R

CAUTION:

Make sure to turn off the printer and wait for about 30 minutes before in-

•

stalling options. Not waiting for the printer to cool down can result in a burn. It is recommended that at least two persons are used to lift the machine.

•

Otherwise, the machine might fall and cause personal injury. When lifting the machine, use the inset grips on both sides of the machine.

•

Otherwise, the machine might fall and cause personal injury. When you move the machine, unplug the power cord from the wall socket

•

to avoid a fire or an electric shock.

7

2

Installing Options

Available Options

The following options can be installed to your printer.

Reference

For more information on the options, see P.59 other than those specified in this manual.

1

2

“Options”

. Do not use options

3

TFWX180E

1. Memory Unit Type505 ⇒ P.9

• Memory Unit Type505 (32MB) (DIMM)

• Memory Unit Type505 (64MB) (DIMM)

2. Printer Hard Disk Type505 ⇒ P.11

3. Paper Feed Unit Type305 ⇒ P.13

Note

It is impossible to install more than two paper feed units to your printer at a time.

❒

8

Installing the Memory Unit Type505 (DIMM)

R

Installing the Memory Unit Type505 (DIMM)

CAUTION:

Make sure to turn off the printer

•

and wait for about 30 minutes before installing options. Not waiting for the printer to cool down can result in a burn.

C Open the white tabs, which hold

the memory, to their widest position (A). Insert the memory unit horizontally into the slot (B). Push it in and then close the white tabs (C).

2

Important

❒

The memory unit can be damaged by small amounts of static electricity. Before touching it, touch something metal to discharge static electricity from you.

A Turn off the printer's power

switch and remove all cables and cords from the printer.

B Remove screws and remove the

back plate.

TFWX185E

Note

❒

There are two notches on the side with the connector of the memory unit. They are located on the left and in the center. Be sure to align the notches over the guides correctly, as shown in the illustration.

TFWX190E

D Attach the back plate to its origi-

nal position, and fasten it with screws that were removed in step B.

Note

❒

A coin can be used to remove the screws.

Note

❒

A coin can be used to fasten the screws.

TFWX195E

9

2

Installing Options

E Plug the printer's power cord

back into the printer and the wall socket. Turn on the printer's power switch.

F Print a configuration page to con-

firm that the memory unit is properly installed.

Reference

For more information on the configuration page, see the “Getting Started”.

Note

❒

If the memory unit is not properly installed, repeat steps A to F again. If you fail again, contact your sales or service representative.

10

Installing the Printer Hard Disk Type505

R

Installing the Printer Hard Disk Type505

CAUTION:

Make sure to turn off the printer

•

and wait for about 30 minutes before installing options. Not waiting for the printer to cool down can result in a burn.

Note

❒

For this printer, use only Printer Hard Disk Type505.

A Check the contents of the box for

the following items.

• Printer Hard Disk Type505

• Installation Guide

• Screws (3 pcs)

B Turn off the printer's power

switch and remove all cables and cords from the printer.

C Remove screws and remove the

back plate.

D Make sure that the projection of

the connector of the hard disk is on the top. Attach the connector to the slot while holding the hard disk.

E Set the hard disk in the lower left

corner at the rear of the printer, as shown in the illustration. Make sure that the screw holes of the hard disk align with the screw holes of the printer. And fasten it with the screws that are enclosed in the box using the screw driver.

2

TFWX600E

Note

❒

A coin can be used to remove the screws.

TFWX186E

TFWX610E

11

Installing Options

2

F Attach the back plate to its origi-

nal position, and fasten it with screws that were removed in step C.

TFWX196E

Note

❒

A coin can be used to fasten the screws.

G Plug the printer's power cord

back into the printer and the wall socket. Turn on the printer's power switch.

H After installing the hard disk, ini-

tialize it using the operation panel.

The following message appears on the panel display.

J When initialization finishes, the

following message appears on the panel display.

READY

K Print a configuration page to con-

firm that the hard disk is properly installed.

Reference

For more information on the configuration page, see the “Getting Started”.

Note

❒

If the hard disk is not properly installed, repeat steps B to K again. If you fail again, contact your sales or service representative.

Important

❒

To make the printer recognize the installed option properly, you must set up the option with the printer driver. See the “User's Guide” for further details.

12

PRESS ENTER TO INITIALIZE DISK

I Press

The printer starts initializing the hard disk. The following message appears on the panel display.

Enter

{

.

}

INITIALIZING

Installing the Paper Feed Unit Type305

R

Installing the Paper Feed Unit Type305

CAUTION:

It is recommended that at least

•

two persons are used to lift the machine. Otherwise, the machine might fall and cause personal injury.

When lifting the machine, use

•

the inset grips on both sides of the machine. Otherwise, the machine might fall and cause personal injury.

When moving the printer, be

•

sure to keep it level to avoid spilling the fuser oil. If oil is spilt, wipe it with alkaline cleaner. Otherwise, the oily surfaces can create the danger of slipping and personal injury.

Important

❒

If your printer is equipped with the optional tray, do not pull out more than one tray with paper at a time. If you do, the printer might tilt forward.

C Move the printer to make install-

ing space.

Important

❒

Be careful to lift the printer as the right front side of the printer is significantly heavier than the left front side.

D Remove the paper feed unit from

the box, and remove the styrofoam packing and the bag from the side covers.

2

TFWH100E

Note

❒

It is impossible to install more than two paper feed units to your printer at a time.

A Check the contents of the box for

the following items.

• Paper Feed Unit Type305

• Installation Guide

B Turn off the printer's power

switch and remove all cables and cords from the printer.

TFWP050E

13

Installing Options

2

E Remove both pieces of adhesive

tape.

TFWP060E

F Pull out the paper tray, and re-

move the padding.

I Place the printer on the paper

feed unit.

Align the printer onto the 4 upright pins on the paper feed unit and then lower it gently.

TFWP100E

J Connect all of cables that were re-

moved in step B.

K Plug the printer's power cord

back into the printer and the wall socket. Turn on the printer's power switch.

G Remove the ring attached to the

red tag.

H If installing two paper feed units,

place one paper feed unit on the other paper feed unit at first. If installing only one paper feed unit, go to step I.

Align the paper feed unit onto the 4 upright pins on the other paper feed unit.

14

TFWP070E

TFWP061E

L Print a configuration page to con-

firm that the paper feed unit is properly installed.

Reference

For more information on the configuration page, see the “Getting Started”.

Note

❒

If the paper feed unit doesn't work, follow the above instructions to reinstall it. If it still doesn't work, contact your sales or service representative.

Important

❒

To make the printer recognize the installed option properly, you must set up the option with the printer driver. See the “User's Guide” for further details.

❒

After installing the paper feed unit properly, set up the paper size. ⇒ P.25

“Loading Paper”

3. Paper and Other Media

Paper and Other Media Supported by this Printer

Paper Types and Sizes

This section provides the type, size, feed direction, and maximum capacity of paper that can be loaded into each paper tray in this printer.

Note

❒

The ”K” symbol means short-edge feed direction.

❒

The ”L” symbol means long-edge feed direction.

❒

The paper feed direction depends on the paper size.

❒

This printer can automatically switch to 81/ is no A4 size paper available, and vice-versa. For example, if the printer has no A4 size paper when you want to print on A4, the printer searches for 8 (Letter) size paper and prints on that instead.

”×11” (Letter) size paper if there

2

1

/

”×11”

2

15

Paper and Other Media

❖

Paper Sizes (Metric version)

3

13" × 18" 12" × 18" A3 B4 JIS

A4

B5 JIS

A5

B6 JIS A6 Double Letter

(DLT, 11" × 17")

Legal (LG, 8

1

/2" × 14")

Feed direction

K

L

K

L

K

L

K

Size (mm)

330 × 457 305 × 457 297 × 420 257 × 364

210 × 297 297 × 210

182 × 257 257 × 182 148 × 210 210 × 148 128 × 182 105 × 148 279 × 432

216 × 356

Bypass Tray

✩❍ ✩★

Standard Tray (Tray 1)

Paper Feed Unit

Type305 (Tray 2/3)

× ×

✩❍❍ ✩

★

*1

★

×××

*1

✩

❍❍

×××

✩★★

×××

✩❍ ❍ ✩

×× ××

×

✩★❍

16

Letter (LT, 8

1

/2" × 11")

K

L

Half Letter (HLT, 5

1

/2" × 81/2")

Executive (Exec., 7

Folio (8

Foolscap (F4, 8

1

/4" × 101/2")

1

/4" × 13")

1

/2" × 13")

F/GL (8" × 13")

*1

:Default setting for “p” on the dial.⇒ P.26

K

L

K

L

K

panel”

216 × 279 279 × 216 216 × 140 140 × 216 184 × 276 276 × 184 210 × 330

216 × 330

203 × 330

×××

✩❍❍

×××

✩★

×××

✩★❍ ✩★★

✩❍ ✩★★

“Specifying paper size using the operation

★

×

*1

Paper and Other Media Supported by this Printer

•✩ means that the size is supported and needs to specify the paper size using

the operation panel. (Regarding the bypass tray, there is no dial on the tray.) ⇒ P.27

“Loading Paper in the Bypass Tray”

•❍ means that the size is supported and indicated on the tray dial. Be sure to

set the paper size dial to match the actual paper size loaded in the tray.

•★ means that the size is supported but not indicated on the paper size dial.

You should set the paper size dial to “p”, and specify the paper size using the operation panel. The default setting is Foolscap (8.5“×13”). ⇒ P.26

“Spec-

ifying paper size using the operation panel”

• × means that the size is not supported.

2

The paper tray can support paper 64 – 105 g/m The bypass tray can support paper 64 – 157 g/m The optional paper tray can support paper 64 – 105 g/m

(17 – 28 lb).

2

(17 – 42 lb).

2

(17 – 28 lb).

3

17

Paper and Other Media

❖

Paper Sizes (Inch version)

3

13" × 18" 12" × 18" Double Letter

(DLT) Legal (LG)

Letter (LT)

Half Letter (HLT)

Executive (Exec.)

A3 B4 JIS A4

Feed direction

K

L

K

L

K

L

K

Size (inch)

13" × 18" 12" × 18" 11" × 17"

1

8

1

8

11" × 8

1

5

1

8

1

7

10

11.26” × 16.54”

10.12” × 14.33”

8.26” × 5.83”

/2" × 14"

/2" × 11"

1

/2"

/2" × 81/2"

/2" × 51/2"

/4" × 101/2"

1

/2" × 71/4"

Bypass Tray

✩★ ✩❍

Standard Tray (Tray 1)

Paper Feed Unit

Type305 (Tray 2/3)

× ×

✩❍❍

×××

*1

✩

❍❍

×××

✩★

×

×××

✩❍❍ ✩★❍

✩

×

★

×××

18

L

B5 JIS

K

L

A5

K

L

B6 JIS A6 Folio

Foolscap (F4)

F/GL

*1

: Default setting for “p” on the dial.⇒ P.26

panel”

K

5.83” × 8.26”

7.17” × 10.12”

10.12” × 7.17”

5.83” × 8.26”

8.26” × 5.83”

5.04” × 7.17”

4.13" × 5.83"

1

8

/4" × 13"

1

8

/2" × 13"

8" × 13"

✩❍❍

×××

✩

×××

✩

×××

✩ ✩★★

✩

★

✩★★

“Specifying paper size using the operation

×

★

××

*1

★

*1

Paper and Other Media Supported by this Printer

•✩ means that the size is supported and needs to specify the paper size using

the operation panel. (Regarding the bypass tray, there is no dial on the tray.) ⇒ P.27

“Loading Paper in the Bypass Tray”

•❍ means that the size is supported and indicated on the tray dial. Be sure to

set the paper size dial to match the actual paper size loaded in the tray.

•★ means that the size is supported but not indicated on the paper size dial.

You should set the paper size dial to “p”, and specify the paper size using the operation panel. The default setting is Foolscap (8.5“×13”). ⇒ P.26

“Spec-

ifying paper size using the operation panel”

• × means that the size is not supported.

2

The paper tray can support paper 64 – 105 g/m The bypass tray can support paper 64 – 157 g/m The optional paper tray can support paper 64 – 105 g/m

(17 – 28 lb).

2

(17 – 42 lb).

2

(17 – 28 lb).

3

19

3

Paper and Other Media

Precautions for Pape r

Note the following precautions when handling or selecting paper to be used with this printer.

Cautions in loading paper

Important

❒

Do not use paper that is meant for an inkjet printer. Otherwise, it may stick to the fusing unit and cause a paper misfeed.

❒

When printing on an OHP transparency that has a print side, load it with the print side down onto the bypass tray. Otherwise, it may stick to the fusing unit and cause a misfeed.

• Use only the recommended paper types. Print quality cannot be guaranteed

if other paper types are used. ⇒ P.23

• Do not use paper that is already printed on.

“Paper not supported by this printer”

Cautions in storing paper

Paper should always be stored properly. Improperly stored paper might result in poor print quality, paper misfeeds, or printer damage.

Follow the precautions below.

• Avoid storing paper in humid areas.

• Avoid exposing paper to direct sunlight.

• Store on a flat surface.

• Keep open reams of paper in the package in which the paper came.

Paper types and cautions

❖

Plain paper

• The standard tray can hold up to 250 sheets.

• The bypass tray can hold up to 50 sheets.

• The Paper Feed Unit Type305 (option) can hold up to 500 sheets.

*1

: Based on paper that is 80 g/m2 (metric version), 20 lb (inch version) in weight.

*1

• If paper is curled or bent, correct it before loading.

Note

❒

To get the best print quality, we recommend you use paper exclusively designed for color copier.

20

❖

Thick Paper

Paper and Other Media Supported by this Printer

• If you print on paper heavier than 105 g/m2 (28 lb), use the bypass tray. The bypass tray can hold paper up to 157 g/m

2

(42 lb) in weight. The print

quality on paper that is thicker cannot be guaranteed.

• The bypass tray can hold up to 25 sheets.

Note

❒

The number of sheets to be set may vary depending on the paper thickness and paper type.

• When printing on thick paper, you should select the thick paper mode with the printer driver.

❖

Adhesive labels

• When printing on adhesive labels, use the bypass tray.

3

TFWY060E

• Load adhesive labels into the tray with the print side down.

• Remove any unused adhesive labels from the tray after you are finished printing. Leaving them in the tray can cause them to curl.

• When printing on adhesive labels, you should select the plain paper mode with the printer driver.

• The bypass tray can hold up to 40 adhesive labels.

Note

❒

The number of sheets to be set may vary depending on the paper thickness and paper type.

21

Paper and Other Media

❖

OHP transparencies

• When printing on OHP transparency, use the bypass tray.

3

TFWY060E

• Load OHP transparencies into the tray with the print side down. Otherwise, it may stick to the fusing unit and cause a misfeed.

• Remove any unused OHP transparencies from the tray after you are finished printing. Leaving them in the tray can cause them to curl.

• When printing on OHP transparencies, you should select the OHP transparency mode with the printer driver.

• The bypass tray can hold up to 50 OHP transparency sheets.

Note

❒

The number of sheets to be set may vary depending on the paper thickness and paper type.

• When the “OHP SLIP SHEET” setting is set to “NO”, be sure to remove each OHP transparency immediately after it is printed. For more information, see the “Getting Started”.

Note

❒

This printer uses paper in tray 1 for OHP slip sheet even if the direction and size of paper loaded in tray 1 is different from the direction and size of the OHP transparency. Check the direction and size of paper loaded in tray 1 before using “OHP SLIP SHEET” setting.

22

❒

When there is no paper in tray 1, “OHP SLIP SHEET” will not work even if “OHP SLIP SHEET” setting is set to “YES”. Be sure to remove each OHP transparency immediately after it is printed.

Paper and Other Media Supported by this Printer

Paper not supported by this printer

Avoid using the following types of paper that are not supported by this printer:

• Paper whose weight is heavier or lighter than the limitation.

• Bent, folded, or creased paper

• Curled or twisted paper

•Torn paper

• Wrinkled paper

• Damp paper

• Paper stuck together

• Paper that is dry enough to emit static electricity

• Paper that has already been printed on (with the exception of preprinted letterhead)

Note

❒

The ink for the format printing by a copier, or an inkjet printer and so on might do harm to the fusing unit of this printer due to a difference in fusing temperatures.

3

• Coated paper (except the recommended one)

• Special paper like thermal paper, aluminum foil, carbon paper and conductive paper

• Heavily textured paper

•Glued paper

• Label paper on which glue or base paper is exposed

• Paper with clips or stapled

• Paper with tape or ribbons attached

• Paper is meant for an inkjet printer.

• Envelopes

23

Paper and Other Media

Printable Area

The following shows the printable area for this printer. Be sure to set the print margins correctly.

3

4.3mm(1/6")

printable area

4.3mm(1/6")

Note

❒

The printable area may vary depending on paper size, printer language and printer driver settings.

24

Loading Paper

Loading Paper in the Paper Tray

Use the following procedure to load paper in the paper tray and optional tray. See P.27

pass Tray”

tray.

Important

❒

After you load paper, you must set the paper size dial to match the actual paper size loaded in the tray. Otherwise, the printer might be damaged.

Reference

See P.15

Supported by this Printer”

on supported paper types and sizes.

“Loading Paper in the By-

for details on the bypass

“Paper and Other Media

for details

A Carefully pull the paper tray out

of the printer and place it on a flat surface.

B Slide the paper guides to posi-

tions that match the size of paper you want to load.

Adjust the paper guides until they click into position.

TFWY100E

Important

❒

Do not touch the friction pad (A). Otherwise, paper misfeeds or paper multi-feeds might occur .

C Load paper into the tray with the

print side up.

3

TFWY090E

Important

❒

Make sure that the stack of paper is no higher than the limit mark (

❒

Make sure the paper fits under the back paper guide.

) inside the tray.

T

TFWY110E

25

Paper and Other Media

3

D Adjust the paper size dial to

match the size of the paper in the paper tray.

TFWY120E

Note

❒

For more information about the position of the paper size dial, see P.16

sion)” version)”

“Paper Sizes (Metric ver-

or P.18

“Paper Sizes (Inch

.

E Slide the paper tray completely

into the printer.

B Use

{U}{T}

ER SETUP”.

to display “PRINT-

PRINTER SETUP

C Press

appears.

{

until “SET [*] SIZE”

Enter

}

SET [*] SIZE NO

D Use

{U}{T}

then press “TRAY1 [*] SIZE”.

The currently selected paper size in paper tray appears on the panel display.

to select “YES”, and

Enter

{

to display

}

TRAY1 [*] SIZE

8.5x13 *

Important

❒

Be sure to insert the paper tray completely. Otherwise, paper misfeeds might occur.

Specifying paper size using the operation panel

Use the following procedure to specify the paper size from the printer's operation panel after loading paper with mark “p” in the table mentioned above into tray 1, tray 2 and tray 3.

A Press

Menu

{

.

}

On Line

Cancel

Menu

Power Error Data In

Enter

E Use

{U} {T}

size you have specified for the paper tray, and then press

to select the paper

Enter

{

TRAY1 [*] SIZE 8x13

F Press

The setting becomes effective.

G Press

The normal display screen appears.

Menu

{

Menu

{

.

}

.

}

READY

.

}

26

TFWS020E

Loading Paper

Loading Paper in the Bypass Tray

Note

❒

Do not open the front cover when loading paper into the bypass tray.

Reference

⇒ P.15 ⇒ P.20

“Paper Types and Sizes”

“Precautions for Paper”

Loading paper

A Open the bypass tray.

Note

❒

Slide out the bypass tray extender.

TFWY150E

C Load paper until it stops with the

print side down.

3

B Slide the side guides.

TFWY130E

TFWY140E

Important

❒

Make sure the paper fits under the side guides.

❒

The side guides should be set to the correct paper size to avoid paper feed problems.

❒

Do not load paper when printing.

TFWY160E

27

Paper and Other Media

3

Specifying paper size using the operation panel

Use the following procedure to specify the paper size from the printer's operation panel after loading paper into the bypass tray.

A Press

B Use

{U}{T}

ER SETUP”.

Menu

{

.

}

On Line

Cancel

Menu

Power Error Data In

to display “PRINT-

Enter

TFWS020E

PRINTER SETUP

Sliding out the Output Tray Extender

If you load paper of A4L or 81/ 11"L or larger, slide out the output tray extender.

Important

❒

Do not place the rear end of the printer near a wall or touch it with barehands. This area can become extremely hot.

" ×

2

TFWX440E

C Press

TRAY SIZE” appears.

Enter

{

until “BYPASS

}

BYPASS TRAY SIZE

8.5x11 *

D Use

{U} {T}

size you have specified for the paper tray, and then press

to select the paper

Enter

{

BYPASS TRAY SIZE 8x13

E Press

The setting becomes effective.

F Press

The normal display screen appears.

Menu

{

Menu

{

.

}

.

}

READY

Note

❒

After printing, return the output tray extender to its original position.

.

}

28

4. Troubleshooting

Error & Status Messages on the Operation Panel

Message Description Comments

ADD FUSER OIL The fuser oil bottle is empty. Replace the fuser oil bottle.

P.50

⇒

Oil Bottle and Ozone Filter”

“Replacing the Fuser

CALL SERVICE SC:nn

CHECK CHARGER The charger is not set cor-

CHECK FUSING UNIT

CHECK PCU The photoconductor unit is

CHECK TONER CARTRIDGE

CHECK WASTE TONER BOTTLE

CHECK (tray name) The paper tray is not in-

There is a malfunction in the printer.

rectly or the charger cleaner is not in the correct position.

The fusing unit is not installed in the printer.

not installed in the printer.

The toner cartridge is not installed correctly.

The waste toner bottle is not installed.

stalled correctly.

Turn the printer off and on. If this doesn't clear the prob-

lem, contact your sales or service representative.

Set the charger correctly.

P.53

⇒

Toner Bottle and Charger”

Contact your sales or service representative.

Install the photoconductor unit. ⇒ P.48

Photoconductor Unit”

Install the cartridge correctly. ⇒ P.45

Toner Cartridge”

Install the waste toner bottle. ⇒ P.53

Waste Toner Bottle and Charger”

Install the paper tray correctly.

“Replacing the Waste

“Replacing the

CLOSE FRONT COVER

CLOSE LEFT COVER

CLOSE PAPER EXIT COVER

The tray on the paper feeding path was not set correctly when the printer received the print job.

The front cover is open. Close the front cover.

The left cover is open. Close the left cover. (⇒ P.1)

The paper exit cover is open. Close the paper exit cover.

Install the paper tray correctly. The printer will restart printing automatically.

(⇒ P.1)

(⇒ P.3)

29

Troubleshooting

Message Description Comments

4

ERROR POWER OFF AND ON

FUSER OIL LOW Fuser oil is low. You can

LOAD PAPER IN (tray name)

LOAD BYPASS (media type) (paper size)

LOAD (tray name) (paper size)

OPEN FRONT COVER REMOVE MISFEED

PAPER SIZE ERROR CHECK GUIDES

↓↑

OPEN AND CLOSE COVER TO CLEAR

There is a malfunction in the printer.

print about 200 or /more pages after this message appears.

There is no paper in the indicated tray.

There is no indicated media type and paper size in the bypass tray.

There is no indicated paper size in the paper tray.

There is a paper misfeed in the printer.

There is a difference between the position of the paper guides in the bypass tray and the specified paper size set with the operation panel.

Turn the printer off and on. If this doesn't clear the prob-

lem, contact your sales or service representative.

Replace the fuser oil bottle.

P.50

⇒

Oil Bottle and Ozone Filter”

Load paper into the indicated tray.

Load the indicated media or paper into the bypass tray.

Load the indicated paper into the paper tray.

Remove the misfed paper.

⇒

per”

After confirming that the paper guides are set to the correct positions, open and close the front cover. ⇒ P.27

“Loading Paper in the Bypass Tray”

“Replacing the Fuser

P.38

“Removing Misfed Pa-

30

PAPER SIZE ERROR (paper size)

↓↑

OPEN AND CLOSE COVER TO CLEAR

REMOVE MISFEED FROM OUTPUT TRAY

REMOVE MISFEED FROM INPUT TRAY

REPLACE FUSING UNIT

There is a difference between the paper size in the paper tray and the specified paper size set with the operation panel or the paper size dial.

There is a paper misfeed in the printer.

The fusing unit is nearly at the end of its service life.

After confirming that the size and feed derection of paper in the paper tray is set correctly, open and close the front cover. ⇒ P.25

Paper in the Paper Tray”

Remove the misfed paper.

P.38

⇒

per”

Remove the misfed paper.

⇒

per”

Contact your sales or service representative.

“Removing Misfed Pa-

P.38

“Removing Misfed Pa-

“Loading

Error & Status Messages on the Operation Panel

Message Description Comments

REPLACE PCU The photoconductor unit is

nearly at the end of its life.

TONER LOW xxx

WARMING UP The printer is preparing for

WASTE TONER ALMOST FULL

WASTE TONER FULL

Indicated toner is low or runs out.

printing. The printer adjusts itself

regularly to maintain print quality. (This message might appear while printing.)

The waste toner bottle is nearly full.

The waste toner bottle is full.

If printed side gets dirty, replace the photoconductor unit. ⇒ P.48

Photoconductor Unit”

Replace the indicated toner cartridge. ⇒ P.45

the Toner Cartridge”

Wait until the printer is warmed up.

It is not an error message. The printer is working prop-

erly. Just wait a while.

Replace the waste toner bottle. ⇒ P.53

Waste Toner Bottle and Charger”

Replace the waste toner bottle. ⇒ P.53

Waste Toner Bottle and Charger”

“Replacing the

“Replacing

“Replacing the

4

Note

❒

If you cannot solve the problem by taking above actions, turn the printer power off and then back on again. If this doesn't clear the error message, write down the error number and the message, and contact your sales or service representative.

31

Troubleshooting

Printer Doesn't Print

Possible Cause Solutions

Is the power on? Make sure that the power cord is securely plugged into the

wall socket and the printer's power socket. Turn on the printer's power switch. ⇒ P.6

Printer On and Off”

“Turning the

4

Is the interface cable properly connecting the printer to your computer connected securely?

Are you using a correct interface cable?

Does the cator stay on?

Is the paper set? Load paper into the paper tray or on the bypass tray. ⇒ P.25

Does the stay red?

On Line

Error

indi-

indicator

Connect the interface cable properly. If there are any connectors or screws, make sure they are fastened securely.

See the "Quick Installation Guide" for details about the settings.

The type of interface cable you should use depends on your computer. Be sure to use the correct one.

If the cable is damaged or worn, replace it with a new one. See the “Quick Installation Guide” for details about the set-

tings. Press

“Loading Paper”

Check the error message on the panel display and do the required action. ⇒ P.29

tion Panel”

On Line

{

to light it up.

}

“Error & Status Messages on the Opera-

32

Possible Cause Solutions

Printer Doesn't Print

Is the

Data In

blinking after starting the print job?

indicator

If not, the data is not being sent to the printer. Or the printer may be resetting the print job because there was a long delay in receiving the data from the computer.

❖

If your printer is connected to the computer using the interface cable

Confirm that the parallel port setting is set to on. For more information on the printer port settings, see the “Getting Started”.

❖

If the printer is using the I/O timeout setting

Increase the value of the I/O timeout setting. For more information on the the I/O timeout setting, see the “Getting Started”.

❖

Network Connection

Contact your network administrator.

If the

Data In

Take the following steps to correct the situation.

• Wait until the printer finishes receiving data from the computer.

• Cancel the job if the data sent from the computer is too large or complex.

indicator is blinking.

4

Can you print a test page (configuration page)?

If you cannot print a test page, it probably indicates a printer malfunction. You should contact your sales or service representative.

If you can print a test page but cannot get the printer to print when you issue a print command from your computer, it probably means there is a problem with your computer.

Also keep in mind that large, complex data might take long time for the printer process. For more information, see the “Getting Started”.

If you cannot solve the problem by taking the above actions, contact your sales or service representative.

33

Troubleshooting

Note

• Windows 95/98

4

Click

A

Select the icon of the printer by clicking it. Next, on the

B

Properties

[

Click

C

Check the

D

, point to

Start

[

]

.

]

Details

[

tab.

]

Print to the following port

[

Settings

[

, and then click

]

box to make sure the correct port is

]

selected.

• Windows NT4.0 Click

A

Select the icon of the printer by clicking it. Next, on the

B

Properties

[

Click

C

Check the

D

, point to

Start

[

]

.

]

tab.

Port

[

]

Print to the following port

[

Settings

[

, and then click

]

box to make sure the correct port is

]

selected.

Printers

[

Printers

[

]

.

[

.

[

File

menu, click

]

menu, click

]

34

Removing Misfed Paper

When a paper misfeed occurs, an error message appears on the panel display. The procedure you should follow to remove the misfed paper depends on its location which is indicated on the panel display.

CAUTION:

When removing misfed pa-

•

per, do not touch the fusing section because it could be very hot.

When accessing the inside of

•

the machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or inju ry.

❒

Make sure the size of the paper loaded in tray 1 is same as the size of the OHP transparency.

If misfeeds persist, contact your sales or service representative.

Do not touch the photoconductor unit when removing misfed paper. If you do, the photoconductor unit might be damaged.

Exposing the photoconductor unit to light for too long can reduce its performance. Close the cover as quickly as possible.

After removing the misfed paper, the back sides of the next printout might get dirty. Print a few pages to absorb the toner.

Important

❒

If your printer is equipped with the optional tray, do not pull out more than one tray with paper at a time. If you do, the printer might tilt forward.

❒

Check the following points if paper continues to misfeed.

• Make sure paper is properly loaded in the paper tray.

• Make sure the number of sheets do not exceed the maximum capacity of the tray.

• Make sure you are using only the appropriate type of paper.

• Make sure misfed paper is still not inside the printer when you resume printing.

• Check the paper type settings. The type of paper set with the printer driver might be different from the actual paper or media type. Make the correct paper or media type setting.

38

Removing Misfed Paper

R

When the Message "REMOVE MISFEED FROM INPUT TRAY" Appears

Standard Tray (Tray 1) or Paper Feed Unit (Tray 2/3)

A Pull out the paper tray gently, be-

ing careful not to tear the misfed paper, and remove the misfed paper.

Make sure that you do not leave any misfed paper in the printer.

Bypass tray

A Carefully pull the misfed paper.

Make sure that you do not leave any misfed paper in the printer.

TFWY180E

B When paper is left in the bypass

tray, remove the paper.

C Close the bypass tray, open the

front cover, and then close it to reset the misfeed condition.

4

TFWY170E

Note

❒

If your printer has an optional paper feed unit installed, check all paper trays for misfeeds.

B Slide the paper tray completely

into the printer.

Important

❒

Be sure to insert the paper tray completely. Otherwise, misfeeds might occur, or the front cover might touch the paper tray.

C Open the front cover, and then

close it to reset the misfeed condition.

D Reload paper into the bypass tray.

When the Message "OPEN FRONT COVER REMOVE MISFEED" Appears

CAUTION:

When removing misfed paper,

•

do not touch the fusing section because it could be very hot.

39

Troubleshooting

R

A Open the front cover by pushing

the front cover release button.

TFWX220E

4

TFWX080E

B If the paper is in the front side of

the photoconductor unit, carefully pull it out.

Note

❒

When removing misfed paper, be careful not to touch the fusing section because it could be very hot.

TFWX210E

D Close the front cover.

When the Message "REMOVE MISFEED FROM OUTPUT TRAY" Appears

CAUTION:

When removing misfed paper,

•

do not touch the fusing section because it could be very hot.

A Open the paper exit cover.

Note

❒

When opening the paper exit cover, be careful as it may be hot.

C When the misfed paper is in the

main section of the photoconductor unit, turn the dial downward then remove the misfed paper in the printer.

Make sure that you do not leave any misfed paper in the printer.

Note

❒

If it is difficult to turn the dial, turn it slightly upward in the opposite direction, and then try again.

40

TFWX230E

B Open the front cover by pushing

the front cover release button.

Removing Misfed Paper

TFWX220E

TFWX080E

C Turn the dial downward, then re-

move the misfed paper in the printer.

Note

❒

When removing misfed paper, be careful not to touch the fusing section because it could be very hot.

When you can see the misfed paper inside the printer.

Note

❒

If it is difficult to turn the dial, turn it slightly upward in the opposite direction, and then try again.

A Remove the misfed paper from

inside of the printer.

When you cannot see the misfed paper inside the printer.

A Remove the misfed paper from

the output tray.

While turning the dial, remove the misfed paper as shown in the illustration. Be careful not to leave any misfed paper in the printer.

Note

❒

When removing misfed paper, be careful not to touch the fusing section because it could be very hot.

4

While turning the dial, remove the misfed paper as shown in the illustration. Be careful not to leave any misfed paper in the printer.

Note

❒

When removing misfed paper, be careful not to touch the fusing section because it could be very hot.

TEWX240E

D Close the paper exit cover. E Close the front cover.

41

Troubleshooting

R

Cleaning the Printer

4

Cleaning the Friction Pad

If the friction pad becomes dirty, misfeeds or multi-feeds of paper might occur. In this case, clean the pad as follows:

A Slide the paper tray out until it

stops. After that, lift it slightly, then pull it out of the printer. Then remove the paper from the paper tray.

B Clean the friction pad with a soft

damp cloth. After wiping it with a damp cloth, wipe it with a dry cloth to remove the water.

Important

❒

Do not use chemical cleaners or organic solvents such as thinner or benzene.

Cleaning the Charger

The charger requires cleaning when your printouts appear dirty.

CAUTION:

When accessing the inside of the

•

machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or injury.

A Open the front cover by pushing

the front cover release button.

C Load paper with the print side up

into the paper tray. While lifting the front side of the tray, insert the paper tray into the printer. Then push in until it stops.

42

TFWY230E

TFWX080E

Important

❒

Exposing the photoconductor unit to light for too long can reduce its performance. Clean the charger as quickly as possible.

B Hold the inset grips (green part)

of the photoconductor unit, and pull the top side of the photoconductor unit forward.

TFWX250E

Cleaning the Printer

R

C Move the charger cleaner (light

blue part) left and right 2 or 3 times, and return it to the left side. Set the arrow of the charger cleaner to the arrow of the photoconductor unit.

TFWX260E

Important

❒

If the charger cleaner is not on the left side, an error message or print problem might occur.

D Hold the inset grips (green part)

of the photoconductor unit, and push the photoconductor unit to its original position.

A Open the front cover by pushing

the front cover release button.

TFWX080E

Important

❒

Exposing the photoconductor unit to light for too long can reduce its performance. Clean the dust-proofing glass as quickly as possible.

B Hold the inset grips (green part)

of the photoconductor unit, and pull the top side of the photoconductor unit forward.

4

E Close the front cover.

Cleaning the Dust-proo fi ng glass

The dust-proofing glass may require cleaning if black or white lines appear on the print side of the document.

CAUTION:

When accessing the inside of the

•

machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or injury.

TFWX250E

C Remove the cleaning brush from

back of the front cover.

TFWX270E

43

4

Troubleshooting

D Insert the cleaning brush into the

back of the guide (light blue) until it stops, and then move it left and right 4 or 5 times.

TFWX280E

E Return the cleaning brush to its

original position.

F Hold the inset grips (green part)

of the photoconductor unit, and push the photoconductor unit to its original position.

G Close the front cover.

44

Replacing Consumables

R

Replacing Consumables

Replacing the Toner Cartrid ge

You should replace toner cartridges whenever the message “TONER LOW XXX” appears on the panel display.

TONER LOW xxx

WARNING:

•

Do not incinerate spilled toner or used toner. Toner dust might ignite when exposed to an open flame.

•

Disposal can take place at our authorized dealer or at appropriate collection sites.

•

If you dispose of the used toner containers yourself, dispose of them according to your local regulations.

A Open the left cover.

TFWX140E

4

B Slide the lock lever up.

TFWX150E

Note

❒

Before removing a toner cartridge from the printer, spread paper or some other material around the area you are working to keep toner from making floor dirty.

❒

When several toner colors run out at the same time, a message appears on the operation panel. Replace them in the following order:

Black

A

Yellow

B

Cyan

C

Magenta

D

❒

When there is no all color toner cartridges that you want to replace, you can specify the replacing toner cartridges. ⇒ P.47

“Specifying the replacing toner cartridge”

C Carefully pull out the toner car-

tridge. A Hold the grip of the toner car-

tridge, and slide it out until you can see the green tape.

B With your hand under the

green tape, remove the toner cartridge carefully as shown in the illustration.

TFWX480E

45

Troubleshooting

4

D Remove the protective sheet from

the new toner cartridge.

TFWX490E

E Hold the new toner cartridge and

shake it with a horizontal motion, about 10 times, as shown in the illustration.

G Return the lock lever to its origi-

nal position.

TFWX170E

H Pull the tape out as shown in the

illustration.

TFWX500E

Important

❒

If the toner cartridge is not shaken enough, toner might not be evenly distributed in the cartridge. In this case, the print quality might be reduced.

F Slide the new toner cartridge into

the printer.

TFWX160E

Important

❒

Be sure to pull the tape horizontally. Pulling it upward or downward causes toner scattering.

❒

After pulling the tape out of the cartridge, toner scatters easily. Do not shake or give a shock to the cartridge.

I Close the left cover.

The “TONER LOW XXX” message clears from the panel display and the printer starts warming up. It takes a few minutes.

TFWX510E

46

Replacing Consumables

Specifying the replacing toner cartridge

When several toner colors run out at the same time, you can replace only the specific toner cartridges. If you do not have all indicated toners, you should do this before following P.45

Cancel

.

Enter

TFWS020E

En-

{

“Replacing the Toner Cartridge”

The following procedure describes how to replace the magenta toner cartridge. You can use the same procedure to replace the toner cartridges for the other toner colors as well.

A Press

B Use

TENANCE", and then press

ter

{

{U}{T}

.

}

Menu

.

}

On Line

Menu

Power Error Data In

to display "MAIN-

D Press

GENTA TONER”.

The following message appears on the panel display.

Enter

{

to display "MA-

}

MAGENTA TONER NO *

E Use

{U}{T}

then press

The following message appears on the panel display.

to select “YES”, and

.

Enter

{

}

MAGENTA TONER PLEASE WAIT

The machine prepares itself for a new toner cartridge. Prepare the new toner cartridge for installation.

When the machine is ready, the following message is displayed.

REPLACE TONER MAGENTA

4

MAINTENANCE

The following message appears on the panel display.

SELECT TONER NO *

C Use

{U}{T}

then press

The following message appears on the panel display.

to select “YES”, and

Enter

{

.

}

CYAN TONER NO *

F Replace the toner cartridge. ⇒

“Replacing the Toner Car-

P.45

tridge”

47

Troubleshooting

R

Replacing the Photoconductor

performance. Replace the unit as quickly as possible.

4

Unit

The message shown below indicates that the photoconductor unit is approaching the end of its life.

REPLACE PCU

You can still continue to use the current photoconductor unit if you are satisfied with the quality of the output being produced by the printer.

When the printed image starts looking soiled (horizontal lines along the edges of the page, for example), replace the photoconductor unit as soon as possible.

WARNING:

•

Do not incinerate the photoconductor unit. Toner dust might ignite when exposed to an open flame.

Note

❒

Before removing the photoconductor unit from the printer, spread paper or some other material around the area you are working to keep toner from making floor dirty.

❒

The “REPLACE PCU” message is based on a printed page counter kept internally by the printer. It is meant as a general guide to photoconductor unit life only. Actual photoconductor unit life depends on the printing conditions.

A Remove the new photoconductor

unit from the box.

B Remove the protective sheet by

pulling the red tab from the new photoconductor unit.

•

Disposal can take place at our authorized dealer or at appropriate collection sites.

•

If you dispose the used photoconductor unit yoursel f, dispose of it according to your local regulations.

CAUTION:

When accessing the inside of the

•

machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or injury.

Important

❒

Exposing the photoconductor unit to light for too long can reduce its

TFWX471E

C Turn off the printer's power

switch.

48

Replacing Consumables

TFWX520E

D Open the front cover by pushing

the front cover release button.

TFWX080E

E Loosen the screws that hold the

photoconductor unit in the printer with the screw driver in the new photoconductor unit's box.

The screws cannot be completely removed from the photoconductor unit.

G Hold the inset grips (green part)

of the photoconductor unit, remove the photoconductor unit from the printer, and place it carefully inside the new photoconductor unit's box.

TYWX290E

Important

❒

To prevent accidental spilling of toner, do not shake, rotate, drop or hold the toner cartridge upside down.

4

TFWX400E

F Hold the inset grips (green part)

of the photoconductor unit, and pull the top side of the photoconductor unit forward.

TFWX250E

49

Troubleshooting

R

4

Note

❒

Do not close the front cover removing the photoconductor unit. Otherwise, you cannot replace the photoconductor unit because the photoconductor unit holder will be closed. If you do this by mistake, return the photoconductor unit holder to its original position before replacing the photoconductor unit.

TFWX300E

H Hold the inset grips (green part)

of the new photoconductor unit, and insert the photoconductor unit into the photoconductor unit holder.

When inserting the photoconductor unit, be careful not to damage the surface of it.

I Hold the inset grips (green part)

of the new photoconductor unit, and push the photoconductor unit to its original position.

J Fix the photoconductor unit with

fastening the screws using the screw driver.

K Close the front cover.

Make sure that the front cover close properly.

L Turn on the printer’s power

switch.

Replacing the Fuser Oil Bot tle and Ozone Filter

Replace the oil bottle and ozone filter whenever the message shown below appears on the panel display.

FUSER OIL LOW

ADD FUSER OIL

50

Note

❒

The white powder on the photoconductor unit is to protect it after installation into the printer. This white powder doesn't have any adverse effect on the interior of the printer.

TFWX305E

There is the fuser oil bottle and the ozone filter in the Fuser Oil Type305.

WARNING:

•

Do not incinerate the oil bottle. This action could cause a fire or getting burned.

•

Spilt oil is very slippery. If oil is spilt, wipe it with alkaline cleaner. Otherwise, the oily surfaces can create the danger of slipping and personal injury.

Replacing Consumables

R

CAUTION:

When accessing the inside of the

•

machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or injury.

Important

❒

There are three ozone filters in this printer. Two of them are set inside in the front, one of them is set in the rear. Be careful when replacing the ozone filters as the front side filter is a different shape from the rear side filter.

❒

Disposal can take place at our authorized dealer or at appropriate collection sites.

❒

Dispose of used ozone filters as general burnable refuse.

B Open the fuser oil bottle cover

of the printer.

TFWX090E

C Remove the used oil bottle

from the printer carefully.

D Insert the new oil bottle into

the oil bottle case.

4

A Turn off the printer's power

switch.

B Replace the oil bottle.

A Remove the green cap from the

new oil bottle.

Important

❒

Hold the clear cap while turning the green cap. Do not remove the clear cap.

TFWX031E

TFWX100E

E Close the fuser oil bottle cover.

Important

❒

The fuser oil bottle cover should be kept closed.

C Replace the ozone filter on the

back side of the printer. A Remove the ventilator hole

cover.

TFWX960E

51

Troubleshooting

4

B Remove the ozone filter from

inside the ventilator hole cover.

TFWX070E

C Install a new ozone filter on

the ventilator hole cover.

D Replace the ventilator hole

cover onto the printer.

D Replace the ozone filters inside

the printer. (There are two filters.) A Open the front cover by push-

ing the front cover release button.

C Insert a new ozone filter into

the printer.

Slide the filter into the stopper. Two small thin plastic tabs of the top of the filter should pop into place.

TFWX320E

D Close the front cover.

Make sure that the front cover close properly.

E Turn on the printer’s power

switch.

TFWX080E

B Grasping the ozone filter by its

tab, remove it from the printer.

TFWX310E

Note

❒

After replace the fuser oil bottle, it takes a few minutes until the message clears.

52

Replacing Consumables

R

Replacing the Waste Toner Bottle and Charger

You should replace waste toner bottle and charger whenever the following messages appear on the panel display.

WASTE TONER ALMOST FULL

WASTE TONER FULL

WARNING:

•

Do not incinerate spilled toner or used toner. Toner dust might ignite when exposed to an open flame.

•

Disposal can take place at our authorized dealer or at appropriate collection sites.

A Turn on the printer’s power

switch.

B Open the front cover by pushing

the front cover release button.

TFWX080E

C Hold the inset grips (green part)

of the photoconductor unit, and pull the top side of the photoconductor unit forward.

4

•

If you dispose of the used toner containers yourself, dispose of them according to your local regulations.

CAUTION:

When accessing the inside of the

•

machine, do not touch any sections other than those specified in this manual. If you do, it might result in receiving a burn or injury.

Note

❒

Before removing the waste toner bottle from the printer, spread paper or some other material around the area you are working to keep toner from making floor dirty.

TFWX250E

D Replace the waste toner bottle .

A Grasping the waste toner bot-

tle by its green tabs, remove it from the printer.

TFWX330E

53

4

Troubleshooting

B Insert a new waste toner bottle

at the rear of the photoconductor unit.

Insert a new waste toner bottle completely. Otherwise, print problem may occur.

E Replace the charger.

A Push the right and left lock le-

vers of the charger.

The locks release, and the charger is lifted slightly.

TFWX340E

TFWX460E

Note

❒

Return the charger cleaner to the left side. Otherwise, print problem may occur.

F Hold the inset grips (green part)

of the new photoconductor unit, and push the photoconductor unit to its original position.

G Close the front cover.

Make sure that the front cover close properly.

TFWX450E

B Remove the charger. C Install a new charger into the

printer.

Insert the new charger into the printer with the arrow of the charger cleaner's lever facing toward you. The charger locks automatically.

H Turn on the printer’s power

switch.

54

5. Appendix

R

Moving and Transporting the Printer

CAUTION:

It is recommended that at least two persons are used to lift the machine.

•

Otherwise, the machine might fall and cause personal injury. When lifting the machine, use the inset grips on both sides of the machine.

•

Otherwise, the machine might fall and cause personal injury. When you move the machine, unplug the power cord from the wall socket

•

to avoid a fire or an electric shock. When you pull out the plug from the socket, grip the plug to avoid damaging

•

the cord and causing a fire or an electric shock. When moving the printer, be sure to keep it level to avoid spilling the fuser

•

oil. If oil is spilt, wipe it with alkaline cleaner. Otherwise, the oily surfaces can create the danger of slipping and personal injury.

Important

❒

Be sure to disconnect all cables from the printer before transporting it.

❒

The printer is a precision piece of machinery. Take care to avoid damage during shipment.

55

5

Appendix

Specifications

Mainframe

❖

Configuration:

Desktop

❖

Print Process:

Laser beam and dry toner electrical photographic system

❖

Printing Speed:

Monochrome: 17 pages per minute (A4, 81/ Color: 5 pages per minute (A4, 8

❖

Resolution:

600 dpi

❖

Parallel Interface:

Conforms to the standard centronics

Interface

A standard 36-pin printer cable and a parallel port on the host computer

Mode

Compatible, Nibble, ECP

Connector

IEEE P1284-B

1

/

"×11")

2

"×11")

2

56

• Do not use a cable more than 2.5 meters (8.2 feet) long.

❖

Printer Language:

Adobe PostScript Level3, PCL5c/5e

❖

Paper Size:

⇒ P.15

❖

Paper Weight:

⇒ P.15

❖

Power Source:

⇒ Inside of the front cover of this manual

❖

Power Consumption:

“Paper and Other Media Supported by this Printer”

Standby (Maximum) 150 W or less Printing (Maximum) 1,200 W or less

Printing (Average) 750 W or less

Energy Save (Maximum) 45 W or less

❖

Noise Emission (Sound Power Level):

Printing Less than 64 db(A)

Stand-by Less than 43 db(A)

Note

❒

The above measurements are made in accordance with ISO7779.

❖

Dimensions:

Width Depth Height

Printer only 660 mm (26") 625 mm (24.7") 475 mm (18.8")

Specifications

With one optional

paper feed unit

With two optional

paper feed units

660 mm (26") 625 mm (24.7") 601 mm (23.7")

660 mm (26") 625 mm (24.7") 727 mm (28.7")

Measurement conditions: With paper tray, bypass tray and output tray extender closed.

❖

Weight:

Approximately 62 kg (136.7 lb) (including consumables)

❖

Warm-up Time:

Less than 450 seconds (23°C)

❖

Paper Capacity:

Standard paper tray

Bypass tray

Optional paper feed unit

*1

Paper weight: 80 g/m2, 20 lb

❖

Paper Output Capacity:

250 sheets

50 sheets

500 or 1,000 sheets

*1

A4: 250 sheets (80 g/m2, 20 lb) A3: 100 sheets (80 g/m

2

, 20 lb)

5

❖

CPU:

R4700-133MHz

❖

Memory:

Standard 32MB, Up to 160MB (with optional memory unit)

❖

Network:

Topology: Ethernet (10BASE-T/100BASE-TX, 10BASE5), TokenRing (Option) Protocol: TCP/IP, IPX/SPX, AppleTalk, SMB

57

5

Appendix

❖

Optional Equipment:

• Paper Feed Unit Type305

• Memory Unit Type505 (32MB/64MB) (DIMM)

• Printer Hard Disk Type505

58

Options

Paper Feed Unit Type305

❖

Paper Size:

⇒ P.15

❖

Paper Weight:

⇒ P.15

Memory Unit Type505 (32MB) and Memory Unit Type505 (64MB)

❖

Model Type:

DIMM (Dual In-Line Memory Module)

❖

Memory Type:

PC100 SDRAM (precisely described as PC100 Rev1.0 compatible)

“Paper Types and Sizes”

Specifications

5

❖

Number of Pins:

168 pins

❖

Access Time (Frequency):

100MHz

❖

CAS Latency:

2

Printer Hard Disk Type505

❖

Type:

2.5 inch slim type (8.45mm height)

❖

Storage Capacity (Formatted):

1.62GB

❖

DIsk Rotational Speed:

4,200rpm

❖

Seek Time (Average):

13ms

❖

Host Interface:

EIDE (UDMA mode supported)

59

Appendix

R

Consumables

CAUTION:

Our products are engineered to meet the highest standards of quality and

•

functionality. When purchasing expendable supplies, we recommend using only those specified by an authorized dealer.

❖

Toner Cartridge

5

Average printable number of pages per cartridge

COLOR TONER Type305 Cyan 15,000 pages COLOR TONER Type305 Ma-

genta COLOR TONER Type305 Yellow 15,000 pages TONER Type305 Black 15,000 pages

*1

A4 5% test chart

Note

❒

The actual number of printed pages you get from a particular toner car-

15,000 pages

tridge depends on the type and size of paper you are using, the contents of your print images, and printing environment conditions. The life of a toner cartridge also shortens as the cartridge becomes older. All this means that a toner cartridge might require replacement sooner than the normal life described above.

❒

Toner cartridges that come with the printer are for setup purposes, and will not provide the number of pages described above. The average number of printable pages that can be expected from the toner cartridges included in the printer are as follows:

• Black toner cartridge : about 6,000 pages

• Cyan, magenta and yellow toner cartridges : about 3,000 pages for each

*1

60

❖

Other Consumables

Note

❒

Actual life of consumables depends on the type and size of paper you are using, the contents of your print images, and printing environment conditions. The life of consumables also shortens as the consumables become older. All that means that consumables might require replacement sooner than the life indicated.

Consumables

Service Life

Waste Toner Bottle Type305

*4

20,000 pages

5,000 pages

Photo Conductor Unit Type305

60,000 pages

15,000 pages

Fuser Oil Type305 20,000 pages

*1

A4 5% test chart

*2

For monochrome printing

*3

For full color printing

*4

Waste Toner Bottle Type305 includes a charger.

*1

*2

*3

*2

*3

5

61

INDEX

A

Adhesive labels

,

21

B

Back Plate Bypass Tray

,

3

, 2,

27

C

,

5

Cancel

{

Charger

key

}

, 4, 42,

53

D

Data In indicator Dust-proofing glass

,

5

,

43

E

,

5

key

Enter

{

}

,

Error indicator Error & Status Messages on the Operation

,

Panel

29

5

F

O

,

5

,

1

, 3, 4,

,

1

22

5

, 1,

50

OHP transparency On Line indicator

On Line

{

Operation Panel Options Output Tray Output Tray Extender Ozone Filter

}

,

key

7

P

Panel Display

, 15,

Paper Paper Exit Cover Paper Feed Unit Type305 Paper Tray Parallel Interface Connector Photoconductor Unit Plain paper Power Connector Power indicator Power Switch Printable Area Printer Hard Disk Type505

,

25

, 2,

,

20

,

5

25

,

1

,

24

3

, 4,

3

5

28

, 8,

,

48

, 8,

13

3

11

Friction Pad Front Cover Front Cover Release Button Fuser Oil Bottle Fuser Oil Bottle Cover

, ,

42

1

, 4,

50

,

1

I

Inset Grips

,

1

L

Left Cover

,

1

M

Memory Unit Type505

,

5

key

Menu

{

}

Misfed Paper

,

38

, 8,

9

N

Network Interface Connector for 10BASE5 Network Interface Connector for

,

10BASE-T/100BASE-TX

3

,

T

Thick Paper Toner Cartridge

,

21

, 4,

45

V

Ventilator

,

3

W

Waste Toner Bottle

3

, 4,

53

62 UE USA G024

Ricoh AP505 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Note to users in the United States of America

Safety Information

Energy Star Program

Manuals for Your Printer

How to Read this Manual

Symbols

TABLE OF CONTENTS

1. Getting Acquainted

Guide to the Printer

Exterior-Fron t View

Exterior-Rear View

Interior

Operation Panel

Turning the Printer On and Off

Turning On the Printer

Turning Off the Pri nter

2. Installing Options

Available Options

Installing the Memory Unit Type505 (DIMM)

Installing the Printer Hard Disk Type505

Installing the Paper Feed Unit Type305

3. Paper and Other Media

Paper and Other Media Supported by this Printer

Paper Types and Sizes

Paper Sizes (Metric version)

Paper Sizes (Inch version)

Precautions for Pape r

Cautions in loading paper

Cautions in storing paper

Paper types and cautions

Paper not supported by this printer

Printable Area

Loading Paper

Loading Paper in the Paper Tray

Specifying paper size using the operation panel

Loading Paper

Loading Paper in the Bypass Tray

Specifying paper size using the operation panel

Sliding out the Output Tray Extender

4. Troubleshooting

Error & Status Messages on the Operation Panel

Printer Doesn't Print

Other Printing Problems

Removing Misfed Paper

When the Message "REMOVE MISFEED FROM INPUT TRAY" Appears

Standard Tray (Tray 1) or Paper Feed Unit (Tray 2/3)

Bypass tray

When the Message "OPEN FRONT COVER REMOVE MISFEED" Appears

When the Message "REMOVE MISFEED FROM OUTPUT TRAY" Appears

When you can see the misfed paper inside the printer.

When you cannot see the misfed paper inside the printer.

Cleaning the Printer

Cleaning the Friction Pad

Cleaning the Charger

Cleaning the Dust-proo fi ng glass

Replacing Consumables

Replacing the Toner Cartrid ge

Specifying the replacing toner cartridge

Replacing the Fuser Oil Bot tle and Ozone Filter

Replacing the Waste Toner Bottle and Charger

5. Appendix

Moving and Transporting the Printer

Specifications

Mainframe

Options

Paper Feed Unit Type305

Memory Unit Type505 (32MB) and Memory Unit Type505 (64MB)

Printer Hard Disk Type505

Consumables

INDEX
