NEW PRODUCT
SPECIFICATION
A3 COLOUR/MONO LASER PRINTER
PCR38
Nashuatec DSc38
Rex Rotary DSc38
Gestetner DSc38
LAUNCH SCHEDULE
Launch Production
Month Location
September, 2001 Japan
NRG International Limited
Marketing Department
Date Created: January, 2001
Version 6
September, 2001
Contents
Page
• Introduction 2
• Product Ove rview 3
• Selling Points and Benefits 6
• Product Configuration 7
• Product Specifications 9
• Copier Functions 19
PCR38
• Document Server Functions 23
• Scanner Functions 24
• Fax Functions 25
• What Fits What 27
This is a pre-launch document and specifications are
subject to change. If in doubt, or specifications are
required for tenders, etc. please contact NRGI Guernsey
for confirmation of exact product details.
K:\Company\Market\NPS\PCR38.doc
1
PCR38
INTRODUCTION
The PCR38 is a revolutionary product aimed at the general office market, which will give us
the opportunity to satisfy our customers’ varying needs and create a new market segment for
this true mono/colour combination (Hybrid) product.
The PCR38 has been designed as:
• A high performance office network printer that prints at 38ppm in mono and 28ppm
in colour.
• A high quality network printer capable of 1200dpi resolution.
• A versatile and powerful printer with options that include large capacity trays, a
finisher with stapling and punching capabilities, duplex and, early in 2002, optional
copy/scanner/fax units.
The PCR38 can be targeted at either a mono or colour environment and its price positioning
will make it possible to introduce colour into environments where price has caused a
resistance to colour sales in the past.
As a high speed, 38ppm, mono printer with extensive finishing capabilities and a high level
of productivity, we will have a product that will be extremely competitive in this growing
market.
As a high speed, 28ppm, full colour printer, also with extensive finishing capabilities and a
print speed of more than double the accepted speed for the general office, the PCR38 will
astound your customers.
When you combine these qualities into one unit, as has been done with the PCR38, you have
a unique product that will create great demand and generate revenue, as well as assist our
brand in becoming recognized as a printer manufacturer.
Please note :
The PCR38 will be launched as a printer only.
When the optional copy/scanner/fax units are available ± 6 months after launch, the
printer will then be manufactured with the required mounting points and interface
boards. These units will not be attachable to the printers manufactured and in the field
prior to the launch of the optional units.
K:\Company\Market\NPS\PCR38.doc
2
PRODUCT OVERVIEW
PCR38 Mainframe
PCR38 with 2 x 500 sheet Paper Feed Unit
PCR38
K:\Company\Market\NPS\PCR38.doc
3
PCR38 with 4bin Mail Box
PCR38 with Duplex Unit, Face up output tray and 1 x 500 sheet Paper Feed Unit
PCR38
K:\Company\Market\NPS\PCR38.doc
4
PCR38
PCR38 with 2000 sheet Finisher, Duplex Unit and 2000 sheet Large Capacity Tray
PCR38 with Scanner Unit, 2000 sheet Finisher, Duplex Unit and 1 x 500 sheet Paper
Feed Unit
K:\Company\Market\NPS\PCR38.doc
5
PCR38
SELLING POINTS AND BENEFITS
High Performance:
Continuous Print Speed:
Monochrome 38 ppm (A4, LT : LEF)
Colour 28 ppm (A4, LT : LEF)
First Print Speed:
Monochrome Less than 9.0 sec.
Colour Less than 12.0 sec.
Processor:
CPU RM7010 250MHz
High Image Quality:
Resolution True 1200 x 1200dpi / 1bit for General Office Use
Versatile and powerful options:
Input Paper options: 2000 sheets LCT, 500 x 1 tray, 500 x 2 tray
Output Paper options: 2000 sheets Finisher, 4bin Mailbox, Auto Duplex
Controller options: HDD, IEEE1394, Memory
Scanner options: Copier (Scanner) upgradeable, Fax upgradeable (from
October 2001)
High Image Quality:
One objective of the PCR38 is to provide affordable image documents to customers
(1) 1200dpi high resolution
True resolution of 1200dpi.
(2) PCL5c (Standard):
The PCR38 supports PCL5c, which is based on HP ’s Colour LaserJet 5 emulation.
The specifications (except for Colour command) of PCL5c are compatible with those
of the PCL5e.
(3) PostScript level 3 (Standard):
The PCR38 supports Adobe PostScript Level 3 (genuine) Version 3011.103.
(4) RPCS (Standard):
The PCR38 supports the new Ricoh PDL, which is a successor to Ricoh’s IPDL-C.
Target User:
Workgroup users in a Network Environment
K:\Company\Market\NPS\PCR38.doc
6
PCR38
PRODUCT CONFIGURATION
a) Standard Configuration:
Monochrome 38ppm / Colour 28ppm engine with 2 x 500 sheets paper trays,
100 sheets Multi Bypass Tray, 500 sheets output tray (Face Down), 100 sheets
output tray (Face up) & Network Interface Board (Ethernet).
b) Options:
Input Paper Options
(1) 500 sheets x 1 Paper Tray … Alternative with (2) / (3)
(2) 500 sheets x 2 Paper Tray … Alternative with (1) / (3)
(3) 2000 sheets Large Capacity Tray … Alternative with (1) / (2)
Output Paper Options
(4) 2000 sheets Finisher … (7) (9) and (1) or (2) or (3) is required
(5) Punch Kit (3 types) … Option for (4), 1 type can be installed
(6) 4 bin Mailbox … Alternative with (4) / Scanner Options
(7) Duplex Unit …
Controller Options
(8) Memory (4types) … 1 type can be installed
(9) HDD (2types) … 1 type can be installed
(10) IEEE1394 board …
Scanner Options
(11) Copier Unit … Alternative with (6)
(12) ARDF … Option for (11)
(13) Platen Cover … Option for (11), Alternative with (12)
(14) Multi-bin sorter (TBA) … Option for (11), (7) is required,
Alternative with (4)
(15) Fax Unit … Option for (11)
(16) G3 additional Line … Option for (15), Alternative with (17)
(17) G4 Line … Option for (15), Alternative with (16)
(18) JBIG … Option for (15)
(19) Hand Set … Option for (15)
(20) Fax Stamp … Option for (15)
K:\Company\Market\NPS\PCR38.doc
7
PCR38
Versatile and Powerful Options
The PCR38 enables the users to do complete finishing of their jobs thanks to the many input
and output options listed below:
(1) Input Paper Options
There are three types of input paper options, a 2000 sheets LCT, 1 x 500 sheet paper
tray and 2 x 500 sheet paper trays.
Standard input paper capacity is 1,100 sheets (2 trays x 500 sheets and 1 x 100 sheet
multi bypass tray).
If the 2000 LCT is installed, the maximum input capacity is 3,100 sheets.
(2) Output Paper Options
There are two options for handling the paper output, a 4 bin mailbox and a 2000
sheet finisher.
Standard output paper capacity is 600 sheets (1 x 500 sheet f ace down tray and 1 x
100 sheet fac e up tray)
If the 2000 sheet finisher with high capacity mode (2500 sheets) is installed, the
maximum output capacity is 3,100 sheets.
(3) Auto Duplex option
The PCR38 has a continuous duplex speed (100% productivity) that is the fastest
among mid -range network printer s for workgroup s.
(4) Controller options
Standard Memory is 64MB. Maximum memory is 384MB (256MB & 128MB).
There is only one additional slot so standard memory has to be removed when
upgrading to higher than 288MB.
(5) Scanner options
The PCR38 supports a scanner unit, which is capable of Copy/Fax/Scanner functions.
This is due for release in early 2002.
As the PCR38 is designed for an advanced office environment, the Ethernet interface
board is standard. In addition, you can add optional IEEE1394 HDD (standard
IEEE1284) and memory to increase productivity.
K:\Company\Market\NPS\PCR38.doc
8
PCR38
PRODUCT SPECIFICATIONS
Engine:
Configuration: Desktop
Technology: Laser beam scanning, electro-photographic printing and dual-
component toner development
4 tandem drums
Resolution: True 1200 x 1200 dpi
1200 x 600dpi (Default)
600 x 600dpi
PPM:
A4/LT (LEF) Resolution Plain Paper Thick/OHP
Mono
Colour
Duplex Speed: Auto Duplex (Option)
100% productivity
First Print Speed:
Monochrome: 9.0 sec. or less (A4 / LT - LEF, 1st Tray)
Colour: 12.0 sec. or less (A4 / LT - LEF, 1st Tray)
Dimensions
(W x D x H): 575 x 648 x 715mm (22.7” x 25.6 ” x 28.2”)
Weight: Less than 77Kg (170lb)
Input Capacity: Standard: Paper tray: 2 x 500 sheets
(80g/m2) Bypass tray: 1 x 100 sheets
Optional: Paper Tray: 1 x 500 sheets or 2 x 500 sheets
LCT: 2,000 sheets
Max. capacity with options: 3,100 sheets
Output Capacity Standard: Face down: 500 sheets
(80g/m2) Face up: 100 sheets
Optional: 4-bin m ailbox: 4 x 125 sheets
Finisher: 2,000 sheets
(High Capacity Mode: 2,500sheets without shift tray mode)
Max. capacity with options: 3,100 sheets
K:\Company\Market\NPS\PCR38.doc
600dpi x 600dpi 38ppm 10ppm
1200dpi x 600dpi 38ppm 10ppm
1200dpi x 1200dpi 28ppm 10ppm
600dpi x 600dpi 28ppm 10ppm
1200dpi x 600dpi 28ppm 10ppm
1200dpi x 1200dpi 14ppm 10ppm
9
PCR38
Product Specifications continued …
Paper Size Standard: No.1 (upper) tray: A4 / LT (LEF)
No.2 (lower) tray: A3 / DLT, 11”x17” – A5 (SEF)
Envelope* (TB A)
(*Guide fence is required)
Bypass tray: 305 x 458mm – 90 x 148mm
Optional: Paper tray: A3 / DLT, 11”x17” – A5 (SEF)
LCT: A4 / LT (LEF)
Paper Type: Paper tray / LCT: Plain Paper
By-pass Tray: Thick Paper (105g/m2, 28lbs.
more)
Special Paper (OHP)
Paper Weight: Paper Trays (Std./Opt.): 60 - 105 g/m2
Multi Bypass Tray: 60 - 163 g/m2
LCT: 60 - 105 g/m2
Duplex Printing: Auto (Option)
A3 - A5 (LEF)
60 - 105 g/m2
Non-Printable Area: Side: Approx. 4.2mm
Leading & Tailing edge: Approx. 4.2mm
(The printable area may vary depending on paper size, printer language
and printer driver settings.)
Rating Power Specifications: 220 / 230 / 240V, 50/60Hz
Power Consumption: Maximum: 1,300W or less
Energy saver mode: 45W or less
Warm-up Time: Less than 120 sec. (from power on)
Energy Star Mode: 60min.
Selectable: 0.5min. / 15min. / 30min. / 60min.
Safety Standard: EN60950, EN60825-1 (Laser)
EMI: EN55022 Class B
Environmental Standard: Energy Star Tier2 specifications
Sound Power Level: Stand-by: Less than 42dB
Printing: Less than 68dB
Energy Saver: Less than 40dB
(Measured by Ricoh Standard methodology)
K:\Company\Market\NPS\PCR38.doc
10
Controller:
CPU: RM7010 250MHz
Printer Language: PCL5c: CLJ5 class compatible
Adobe PostScript Level 3 (Genuine): Interpreter 3011.103
RPCS: IPDL-C successor
PS: NRGI provides a PPD (PostScript Printer Description) file,
which defines the specific printer features (such as paper
handling options, paper size range, and so on) and the user
interface built into the driver.
Resolution: PCL5c: 300 x 300dpi / 600 x 600dpi
PS: 600 x 600dpi / 1200 x 600dpi / 1200 x 1200dpi
RPCS: 600 x 600dpi / 1200 x 600dpi / 1200 x 1200dpi
RAM: 64MB (Up to 384MB, 1 slot free*)
144 pin (SO_DIMM) 66/100 MHz 64 bit Non-EEC parity
Acs: 6ns
(* When the optional copier unit is installed, there are no free
slots)
Memory Requirements:
PCR38
K:\Company\Market\NPS\PCR38.doc
11
PCR38
HDD: Type 1: 20GB (Printer HDD)
Type 2: 40GB (Copying HDD)
Fonts: PCL5c: 35 intelli fonts,
10 TrueType fonts
1 Bitmap font
(31 fonts can be downloaded by Agfa Font Manager)
PS: 136 Adobe Type 1 fonts
RPCS: N/A
Driver: PCL5c: Win 95 / 98 / Me / NT4.0 / 2000
PS: Win 95 / 98 / Me / NT4.0 / 2000, Mac 7.6.1 or later
RPCS: Win 95 / 98 / Me / NT4.0 / 2000
Auto Tray Select: Yes
From Default Tray - Tray 1 (Upper tray) -Tray 2-Tray 3 (or
LCT)-Tray 4.
Bypass tray not available.
Auto Tray Change: Yes
When the paper runs out in the current tray while printing is in
progress, the printer searches for another tray that contains the
same size, orientation and media type of paper and switches to
that tray automatically.
Paper Runs out: Yes
When the paper runs out in the current tray, while printing
is in progress, the printer automatically searches for another
tray that contains the same size and orientation of paper. If
there is no tray with the specified paper, the “Load (Paper Size)
(Tray No.)” message appears on the LCD of the printer
operation panel. If the specified paper is loaded in the specified
tray, the printer re-starts the printing automatically.
Tray Lock: Yes (Default: Off)
Connectivity: Standard: Parallel: Bi-centronics (IEEE1284 ECP)
NIB: 100/10 Base TX (Standard)
Option: IEEE1394
(Token Ring is not supported)
*USB available: Parallel-USB cable is not included.
Network Protocol: TCP/IP, IPX/SPX, NetBEUI*, AppleTalk
*Only supported by SmartNet Monitor
Utilities: SmartNet Monitor
ScanRouter
Print Utilities for Mac
K:\Company\Market\NPS\PCR38.doc
12
Controller Options
HDD:
Capacity: Approx. 20GB
Specifications: Font download
Electronic sorting
Print Job Spooling (Proof/Secure printing)
Logging Data
Memory:
Type: SO DIMM (SD-RAM),
144 pin, 6ns access time
PC 100 MHz 64bit Non-ECC/Parity
Capacity: 64MB, 128MB, 256MB
IEEE1394:
PCR38
Outline:
IEEE1394 is one of the industry standards, which was authorised as IEEE13941995 by IEEE (Institute of Electrical and Electronics Engineers) in 1995. This
interface is expected to be used for sending large-capacity data, such as
multimedia data, at high speed. Digital Video Camera is one of the popular
products having this interface. Recently, the interface is equipped with many
PCs as standard, and also many “IEEE1394 expansion card” for PCs are
available in the market.
Features:
IEEE1394 provides High Speed data transmission at 100Mbps, 200Mbps and
400Mbps. It offers much faster speed than USB (Universal Serial Bus ), which
has 1.5Mbps and 12Mbps mode.
Connecting Cable & Connector:
The IEEE1394 cable is simple and flexible , like a USB cable. There are 2 types
of IEEE1394 cables in the market. One has “6 wires” with a 6-pin connector,
and the other has “4 wires” with a 4-pin connector.
Picture 1, over the page, shows the cable structure of the “6 wire” cable. The
diameter is 5.5mm.
The “4 wire” cable is used for digital videos and digital cameras etc. The
diameter is 4mm.
K:\Company\Market\NPS\PCR38.doc
13
Electric wires
Twisted pair
100
IEEE1394
IEEE1394
Picture 1: Cable structure of IEEE1394 (6-wires)
(signal wires)
Shield of the Cable
Picture 2: Interface
USB
4-pin connector
Network Style – Topology
There are two ways to configurean IEEE1394 network : “Daisy Chain” and “Node
Branch”.
The Daisy Chain style allows users to connect a maximum of 16 nodes (machines
which have a 1394 port), and the maximum cable length is 4.5m (between each
device).
Node branch style allows users to connect a maximum of 63 nodes (physically
possible node addresses). [See Picture 3] As Hot-plug-in is available , users can
connect & pull out the cables while the machine is working.
Picture3. Network Style of IEEE1394
Workstationn PC HDD
400Mbps
CD-R Camera
PCR38
Signal wire shield
6-pin connector
200Mbps
Printer Scanner
Mbps
K:\Company\Market\NPS\PCR38.doc
200Mbps
100Mbps
100Mbps
14
PCR38
(1)
1394
1394
(2)
1394
1394
(3)
1394
1394
Note 1: Printing feature through IEEE1394 I/F is available only with PCs with
Windows 2000 installed .
Note 2: Recent PCs and IEEE1394 Expansion cards for PCs have a couple of
IEEE1394 ports. The connection types depend on the number of IEEE1394
ports on each device.
Note 3: IEEE1394 Expansion cards for PCs must support Windows 2000.
Note 4: In case of using 6-pin to 4-pin cable, IEEE does not recommend that a device
of 4-pin side connects with other devices.
Hardware Specifications:
Interface IEEE1394 (6pin)
Number of ports 2 ports
Data speed 400Mbps / 200Mbps / 100Mbps
System requirements:
Connectable devices 1. PCs
OS: MS-Windows2000
with IEEE1394 port
2. IEEE1394 Repeaters
Number of Hops 16 hops (Max.)
Length of cable 4.5m between devices (Max.)
K:\Company\Market\NPS\PCR38.doc
15
PCR38
Note: IEEE1394 Interface does not include IEEE1394 cables and customers need to prepare
it. (There are two types of ports in IEEE1394 Standard, 4-pin and 6-pin, the
IEEE1394 option for the PCR38 has “6-pin” ports. Therefore, the cable must have a
“6-pin” connector to connect to the PCR38)
² High Speed data transmission 400/200/100Mbps
² Easy connection Hot PnP
² Easy handling Thin cable (around 5.5mm in diameter)
NV-RAM(64KB):
This is used for storing the “User Code” when you manage your clients by SmartNet
Monitor (successor to Aficio Manager for Admin), such as Usage-restriction or Colour
mode-restriction. This capacity is for up to 400 user codes (std. is 0).
[User Management Tool]
IT Manager (Administrator) can manage / restrict the user (Client)
for Color and B/W printing. (Max. 400 users)
System Requirement
ØSmartNetMonitor for Admin (Standard accessories)
ØUser Account Enhance Unit Type B (Option)
Client 1 Client 2 Client 3
Color & B/W
B/W only
Admin
Client 1 No Yes
Client 2 No Yes
Client 3 Yes Yes
Color B/W
User Account Enhance Unit Type B
K:\Company\Market\NPS\PCR38.doc
16
FC
FC
FC
1 job
Colour Developing
Bk Developing
ACS
FC
FC
FC
1 job
Colour Developing
Auto Colour Sensing (ACS): On/Off (set at operation panel)
On: ACS only works when the first colour page is detected in a print job.
Subsequent Bk pages are printed using the colour PCU.
Off:
Spooling: No
Job Cancel: Yes (from Operation Panel)
Includes printing and processing jobs
Rotate Sort: No
OHP Slip Sheet: Yes (Blank paper only)
Cover Sheet: Yes (with Electronic sorting enabled)
(Front cover / Back cover) Blank or Copied paper can be selected in the Print Driver
Requirements: HDD required
Up to 105g/m2 (28lbs. ) paper weight
RPCS driver only *
Bk Bk
Bk Bk
(*PCL has First page / Other page function only)
Bk Bk
(Colour PCU is used)
Bk Bk
(Colour PCU is used)
PCR38
K:\Company\Market\NPS\PCR38.doc
17
Sample Print (=Proof Print): Yes
Requirements: HDD required
Job Stock Spec.: Max. stock pages: 2,000 pages
Max. stock jobs: 30 jobs (Proof + Secure print)
Overflow job record: latest 20 jobs
Secure Print: Yes
Requirements: HDD required
Job Stock Spec.: Max. stock pages: 2,000 pages
Max. stock jobs: 30 jobs (Sample + Secure print)
Overflow job record: latest 20 jobs
PCR38
K:\Company\Market\NPS\PCR38.doc
18
Copier Functions (Option):
The copier option will be launched in early 2002, approximately.
Please be advised that specifications may change!
Scanner unit and ARDF or Platen cover must be installed together.
Configuration: Rack Type
Originals: Sheet / Book / Object
Original Size: Max. 11” x 17” / A3
Paper Size: Max. 12” x 18 ”
Resolution: 600dpi / 2bit
Gradation: 256 gradations
Copy Size: Max.: 11” x 17” /A3 full bleed on 12”x18”
First Copy Speed
Monochrome TBA (A4 / LT – LEF, 1st Tray)
Colour TBA (A4 / LT – LEF, 1st Tray)
Copy Speed (A4 LEF):
Normal Mode: BW: 38cpm / FC : 28cpm
OHP / Tick Paper Mode: BW : 10cpm / FC : 10cpm
ADF 1 to 1 Speed: BW: 38cpm / FC : 14cpm
Multiple Copying: Up to 100
Reproduction Ratio: 7 reductions, 5 enlargements plus 100%
400, 200, 141, 122, 115, 100, 93, 82, 75, 71, 65, 50, 25%
Zoom: From 25% to 400% in 1% steps
Duplex Copy: Auto (Optional Duplex unit and HDD are required )
Simplex original to Duplex copy
Duplex original to Duplex copy
Simplex Book original to Duplex copy
Duplex Book original to Duplex copy
Memory: TBA
PCR38
K:\Company\Market\NPS\PCR38.doc
19
PCR38
Dimensions (W x D x H):
Standard TBA
+ 1 x 500 sheet tray TBA
+ 2 x 500 sheet tray TBA
Weight: TBA
Power Source:
EU. Model: 220 / 230 / 240V 8A, 50/60Hz
Max. Power Consumption: Less than 1.5KVA
Operation Panel: Monochrome LCD
Colour Selection: Full Colour/Black & White/Single Colour/Twin Colour
Single Colour:
Pre-set colour pallet: 12 colours with 4 levels density selection
Red, Green, Blue, Cyan, Magenta, Yellow, Yellow
Green, Orange, Beige, Pink, Purple and Marine Blue
User Colour Memory: 15 colours (The ratio of Yellow/Magenta/Cyan/Black)
Twin Colour: Black + Pre-set colour + User colour memory
Copy Mode: Auto Text & Photo Separation Mode/Photo Mode/Text
Mode/ Map Mode / 2nd Generation Mode
In Auto Text & Photo Separation Mode and Photo
Mode, the following three photo types can be selected:
6 Press Print Mode
6 Glossy Photo Mode
6 2nd Generation Mode
Reduce / Enlarge:
Auto Paper Selection (APS): Yes
Auto Magnification Selection (AMS): Yes
Zoom: Yes (25-400%, 1% step)
Size Magnification: Yes
Directional Magnification: Yes (% input)
Directional Size Magnification: Yes (mm/inch input)
Poster Mode: No
K:\Company\Market\NPS\PCR38.doc
20
PCR38
Shift / Erase / Book Copy:
Centring: Yes
Cornering: No
Margin Adjustment: Yes
Erase Centre: No
Erase Border: No
Erase Centre / Border: Yes
Combination (N-up):
Simplex 6 types
(Original: Simplex x 2 / Simplex x 4 / Simplex x 8 /
Duplex x 1 / TBA / Duplex x 2 )
Duplex* 6 types
(Original: Simplex x 4 / Simplex x 8 / Simplex x 16 /
Duplex x 2 / Duplex x 4 / Duplex x 8 )
6 For Duplex printing, the Duplex unit is required.
ADS (Auto Density) : Yes
Manual Density Selection: 9 levels
OHP Slip Sheet: Yes (Blank paper)
Cover Sheet : Yes (with Electronic sorting enabled)
(Front cover / Back cover) Blank paper or Copied paper can be selected in the Print
Driver
Requirements: HDD required
Up to 105g/m2 (28lbs.) paper weight
Image Editing :
Area Editing: No
Outline: No
Italic: No
Positive / Negative: No
Under colour: No
Mirroring: No
Shadow: No
Repeat / Double copy: Yes
Erase selected colour: Yes ( 4 colour selectable Black / Yellow / Magenta /
Cyan / Red / Blue / Green)
K:\Company\Market\NPS\PCR38.doc
21
Image Colour Adjustment:
Auto Colour Calibration(ACC): Yes
Colour Balance Adjustment: Yes
Colour Balance Programme: Yes
Colour Separation Adjustment: Yes
Sharp / Soft Adjustment: Yes
Contrast: Yes
Background Density Control: Yes
Pastel Image Adjustment: No
UCR Adjustment: Yes
Auto Text & Photo Separation Adjustment: Yes
Electronic Sort: Yes (with HDD)
Rotation Copy: Yes
Rotation Sort: Yes (with HDD)
1 Scan to Multiple Copies: Yes
Pause / Interrupt: Yes
Energy Saver Mode: Yes
Proof Copy: Yes
Job Recall: No
Reserved Copy: No
PCR38
K:\Company\Market\NPS\PCR38.doc
22
PCR38
1.
Input
Printing
DOCUMENT SERVER FUNCTION S
Storage Output
Copy
2.Printer
3.Fax (Transmission)
4.PC-Fax (Transmission)
5.Scanner
HDD
(1)
(2) re-Fax
(3) re-Distribution
PCR38
Hardware Configurations: Scanner Unit and HDD are required.
Applications: Printer / Copier / Scanner*1 / Fax*2 functions
*1 : excluding TWAIN
*2 : Fax unit is required. Excluding direct transmission
Specifications: 1)Storage on HDD
2)Manage the stored files on HDD
Sorting /Referring
Changing the file name and Deleting the file
3)Combining the stored files ( if required) and then:
Reprinting (Print/Copy/Fax Transmission data)
Refaxing (Fax Transmission data)
Redistributing (Scanner data)
Finishing (Sort / Staple / Punch)
Sample (=Proof) printing
Secure printing
User Interface : By Operation panel or on client’s PC, through a utility called
“Plumeria Lite ”
Limitations: Does not support Duplex printing
Requirements: Storage data: 1200 x 1200dpi
Paper Size: Over A4/LT (e.g. DLT/A3/B4)
K:\Company\Market\NPS\PCR38.doc
23
Document
(Electronic Data)
SCANNER FUNCTIONS (OPTION)
The scanner option will be launched in early 2002, approximately.
Documents
PCR38
PCR38
Scanner unit and Platen cover or ADF must be installed together.
Model type: Platen cover: Desktop flatbed scanner unit (component)
ADF: Sheet pass through type
Driver: Network Twain version 1.7 or later
OS: Win95 / 98 / NT4.0 / 2000
Connectivity: 100/10 Base-TX
Originals: Sheet / Book / Object
Scanning Area: Main Scanning: 298mm
Sub-Scanning: 432mm (ADF: 1260mm)
Resolution: 600dpi
Grey scale: 1 bit or 8 bits/pixel
ADF throughput: 38ppm (A4 / LT SEF, 200dpi, 1 bit)
Scanning time: Less than 6 sec. (A4 / LT SEF, 200dpi, 1bit)
K:\Company\Market\NPS\PCR38.doc
24
PCR38
FAX FUNCTIONS (OPTION)
The Fax option will be available in early 2002, approximately.
Scanner unit, ADF and Fax unit must be installed together.
General Features:
Model Type: Transceiver (G3)
Line Options: Std. G3 x 1 line / Max. 2 lines (G3 orG4)
Circuit: G3 (Standard): PSTN, PBX,
G4 (Optional): ISDN
Resolution: G3: 8 x 3.85 L /mm
8 x 7.7 L /mm
G4: 8 x 15.4 L/mm
6 x 15.4 L/mm
Compression Method: Standard: MH/MR/MMR
Optional: JBIG
Scanning Speed: Approx. 0.7 sec. (A4/LT SEF, 200 x 100dpi)
Modem Speed: G3: 33,600 – 2400 bps Automatic shift-down
G4: Max. 64Kbps
Transmission Speed: G3 (8 x 3.85/mm, 28.8Kbps more): 3 sec. level
(ITU-T No.1 Chart)
G4 (200 x 200dpi, 64Kbps): 3 sec.
SAF memory: Standard: 2MB
Optional: TBA
Page memory: TBA
Memory Backup: 1 hour
Fax Stamp: Option (with ARDF)
Dual Access: Yes
TTI/RTI: Yes
CSI: Yes
Quick Dial: 300 numbers
K:\Company\Market\NPS\PCR38.doc
25
Fax Functions (Option) Continued …
Speed Dial: 200 numbers
Group Dial: 64 groups
User Program: 50 programs (Max 200 programs)
Redial(Automatic/Manual): Yes
AI Short Program Yes (10 calls)
Direct Fax number entry: Yes
Dual Access: Yes
User Code: Yes
Auto document: Standard: 6 documents
Maximum 18 documents
Page count: TBA
Auto Reduction: Yes
Wild Cards: Yes
Summer Time (daylight saving time): Yes
ID code programming: Yes (4 digits)
Programming by OMR: Yes
User Function Keys: Yes (6 keys)
Night Timer: No
Energy Saver: TBA
LCD prompt: Yes
Remaining Memory Indication: TBA
Time Indicator / Clock Adjustment: TBA
User Parameter Setting: TBA
User Data Transfer: TBA
Memory File Transfer: TBA
K:\Company\Market\NPS\PCR38.doc
PCR38
26
PCR38
WHAT FITS WHAT
Machine Nashuatec Rex Rotary Gestetner
PCR38 DSc38 DSc38 DSc38
Peripherals:
AD3800C Duplex Unit
CS3800C 4-bin Mailbox
DHD38A Printer Hard Disk – 20GB
DMEBP128 128MB Memory
DME38 256MB Memory
DFU38A 1 x 500 sheet Paper Supply Unit
DFU38B 2 x 500 sheet Paper Supply Unit
PS470 2000 sheet Large Capacity Tray
SR770 Finisher Unit
DHPU451E4H 4-hole Punch Unit
DHPU451S4H Swedish 4-hole Punch Unit
DIF1045FW IEEE1394 Firewire Board
DMEBP32 32MB Memory
DMEBP64 64MB Memory
DMENV1 NV RAM for user accounting
Language Codes:
PLS38GB Language Kit – English
PLS38F Langauge Kit – French
PLS38D Langauge Kit – German
PLS38I Langauge Kit – Italian
PLS38P Language Kit – Portuguese
PLS38N Language Kit – Norwegian
PLS38H Language Kit – Hungarian
PLS38CZ Language Kit – Czech
PLS38PL Language Kit – Polish
PLS38S Language Kit – Swedish
PLS38SF Langauge Kit - Finnish
Supplies:
DD38BLK Black Developer Yield 100K
DD38COL 3 Colour Developers In One (CMY) Yield 100K
DT38BLK Black Toner Yield 20K @ 5%
DT38CYN Cyan Toner Yield 10K @ 5%
DT38YLW Yellow Toner Yield 10K @ 5%
DT38MGT Magenta Toner Yield 10K @ 5%
DFU1 Fuser Unit Yield 100K
DFO38 Fuser Oil Supply Unit Yield 20K
TDB38 Waste Toner Bottle Yield 50K
PFR38 Paper Feed Roller Yield 150K
K:\Company\Market\NPS\PCR38.doc
27
PCR38
Supplies continued…
DMU38BLK Black Photo Conductor Unit Yield 50K
DMU38COL 3 Colour Photo Conductor Unit (CMY) Yield 50K
CSC760A Staple Cartridge SR760/770 - 1 x 5,000 Yield 5,000
CSC760B Staple Cartridge SR760/770 – 3 x 5,000 Yield 15,000
K:\Company\Market\NPS\PCR38.doc
28
Loading...
