Ricoh AP3800C User Manual

Operating Instructions

Maintenance Guide

For safety, please read this manual carefully before you use this product and keep it handy for future reference.

Introduction

This manual describes detailed instructions on the operation and notes about the use of this machine. To get maximum versatility from this machine all operators are requested to read this manual carefully and follow the instructions. Please keep this manual in a handy place near the machine.

Trademarks

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other countries.

Other product names used herein are for identification purposes only and might be trademarks of their respective companies. We disclaim any and all rights in those marks.

Notes:

Some illustrations in this manual might be slightly different from the machine.

Certain options might not be available in some countries. For details, please contact your local dealer.

Note

The proper names of the Windows operating systems are as follows:

•Microsoft

Windows® 95 operating system

Windows® 98 operating system

Windows® Millennium Edition (Windows Me)

Windows ® 2000 Professional

Windows ® 2000 Server

Windows® XP Professional

Windows® XP Home Edition

Windows NT® Server operating system Version 4.0

Windows NT® Workstation operating system Version 4.0

Safety Information

When using your printer, the following safety precautions should always be followed.

Safety During Operation

In this manual, the following important symbols are used:

WARNING:

CAUTION:

Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.

Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.

R WARNING:

•

Disconnect the power plug (by pulling the plug, not the cable) if the power cable or plug becomes frayed or otherwise damaged.

• To avoid hazardous electric shock or laser radiation exposure, do not remove any covers or screws other than those specified in this manual.

• Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if any of the following conditions exists:

• You spill something into the equipment.

•

You suspect that your equipment needs service or repair.

• Your equipment's cover has been damaged.

•

Do not incinerate spilled toner or used toner. Toner dust might ignite when exposed to an open flame.

• Disposal can take place at our authorized dealer or at appropriate collection sites.

• Dispose of the used toner cartridge in accordance with the local regulation.

R CAUTION:

• Protect the machine from dampness or wet weather, such as rain and snow.

• Unplug the power cord from the wall outlet before you move the machine.

While moving the machine, you should take care that the power cord will not be damaged under the machine.

• When you disconnect the power plug from the wall outlet, always pull the plug (not the cable).

• Do not allow paper clips, staples, or other small metallic objects to fall inside the machine.

• Keep toner (used or unused) and toner cartridge out of the reach of children.

• For environmental reasons, do not dispose of the machine or expended

supply waste at household waste collection points. Disposal can take place at an authorized dealer.

• The inside of the machine could be very hot. Do not touch the parts with a label indicating the “hot surface”. Otherwise an injury might occur.

iii

ENERGY STAR Program

As an ENERGY STAR Partner, we have determined that this machine model meets the ENERGY STAR Guidelines for energy efficiency.

The ENERGY STAR Guidelines intend to establish an international energy-saving system for developing and introducing energy-efficient office equipment to deal with environmental issues, such as global warming.

When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall place the ENERGY STAR logo onto the machine model.

This product was designed to reduce the environmental impact associated with office equipment by means of energy-saving features, such as Low-power mode.

❖❖❖❖ Low-power Mode (Energy Saver mode)

This printer automatically lowers its power consumption 60 minutes after the last operation has been completed. To exit Low-power (Energy Saver) mode, press any key on the control panel. For details about how to configure Energy Saver mode, see “Making Printer Settings with the Control Panel” in Administrator Reference 2 as a PDF file on the CD-ROM.

❖❖❖❖ Specifications

Energy Saver mode Power Consumption 45 W or less

Default Time 60 minutes

Recovery Time 120 seconds or less

How to Read This Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.

CAUTION:

This symbol indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before operating.

Note

This symbol indicates precautions for operation, or actions to take after misoperation.

Limitation

This symbol indicates numerical limits, functions that cannot be used together, or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's panel display.

Keys and buttons that appear on the computer's display.

{}

Keys built into the machine's control panel.

Keys on the computer's keyboard.

1.Replacing Consumables and Maintenance Kit

Detaching the SR770 (2 Tray Finisher)..................................................... 1

Opening and Closing the Duplex Reversal Unit ...................................... 2

Replacing the Toner Cartridge .................................................................. 3

Replacing the Fuser Oil Unit ..................................................................... 6

Replacing the Photoconductor Unit ....................................................... 10

Replacing the Development Unit ............................................................ 15

Replacing the Fusing Unit ....................................................................... 19

Replacing the Dustproof Filter................................................................ 24

Replacing the Waste Toner Bottle .......................................................... 26

Replacing the Paper Feed Rollers .......................................................... 28

2.Cleaning and Adjusting the Printer

Cautions to Take When Cleaning............................................................ 31

Cleaning the Registration Roller............................................................. 32

Cleaning the DustProof Glass ................................................................. 33

Adjusting the Color Registration ............................................................ 34

Auto Adjust................................................................................................... 34

Fuser Adjust................................................................................................. 35

Manual Adjust .............................................................................................. 39

Test Sheet Samples..................................................................................... 41

Adjusting the Image Density................................................................... 43

Adjusting the Registration of the Trays ................................................. 44

3.Paper and Other Media

Paper and Other Media Supported by This Printer............................... 47

Paper Sizes.................................................................................................. 47

Paper Recommendations ........................................................................ 53

Loading Paper.............................................................................................. 53

Storing Paper ............................................................................................... 53

Types of Paper and Other Media ................................................................. 54

Printable Area ........................................................................................... 57

Loading Paper........................................................................................... 58

Loading Paper in Tray 1............................................................................... 58

Loading Paper in Tray 2 and the Optional Paper Feed Unit ........................ 59

Loading paper in Paper Bank PS470 (2000-sheet Large Capacity Tray) .... 60

If you load a paper size that is not selected automatically ........................... 61

Changing the paper type.............................................................................. 63

Load Paper in the Bypass Tray.................................................................... 64

4.Troubleshooting

Error & Status Messages on the Control Panel..................................... 69

Printer Does Not Print .............................................................................. 81

Other Printing Problems .......................................................................... 84

Removing Misfed Paper ........................................................................... 88

Detaching the 2 Tray Finisher...................................................................... 88

Opening and Closing the Duplex Reversal Unit........................................... 89

Removing Misfed Paper in the Duplex Feed Unit ........................................ 89

When "Remove Misfeed A:Internal Path" Appears ...................................... 92

When "Remove Misfeed B: Fusing Unit" Appears ....................................... 92

When "Remove Misfeed W: Mailbox" Appears ............................................ 94

When "Remove Misfeed R: Finisher" Appears ............................................ 94

When "Remove Misfeed Y: Paper Tray" Appears........................................ 96

When "Remove Misfeed :Duplex Unit " Appears ......................................... 96

Removing Jammed Staples ..................................................................... 98

Adding Staples ....................................................................................... 100

Removing Punch-hole Chips................................................................. 102

When the message appears even after removing the Punch-hole chips... 102

5.Appendix

When the Front Cover Does Not Close ................................................ 103

Moving and Transporting the Printer ................................................... 105

Moving the Printer ...................................................................................... 105

Consumables .......................................................................................... 107

INDEX....................................................................................................... 109

vii

viii

1. Replacing Consumables and Maintenance Kit

Detaching the SR770 (2 Tray Finisher)

There are times when you might have to detach the 2 Tray Finisher from the printer to remove misfed paper. This section describes how to detach the 2 Tray Finisher.

Hold the handle at the top of the 2

AAAA

Tray Finisher firmly with one hand, pull the 2 Tray Finisher straight out, and let go when it stops.

ZDJP201J

The 2 Tray Finisher is detached from the printer.

Use both hands to push it straight

BBBB

back in, and let go when it clicks into place.

Important

❒ Be sure to attach the 2 Tray Fin-

isher to the printer after closing the Duplex Reversal Unit. See p.2 “Opening and Closing the Duplex Reversal Unit”.

ZDJP202J

The 2 Tray Finisher is reattached to the printer.

Replacing Consumables and Maintenance Kit

Opening and Closing the Duplex Reversal Unit

There are times when you might have to detach the Duplex Reversal Unit to remove misfed paper. This section describes how to detach the Duplex Reversal Unit.

Push up the lock release button

AAAA

and keep it in place.

ZDJP203J

Lower the Duplex Reversal Unit

BBBB

slowly until it stops.

Note

❒ You do not have to remove the

External Tray even if the 2 Tray Finisher is attached.

The Duplex Reversal Unit is opened.

Raise the Duplex Reversal Unit

CCCC

slowly with both hands, and push it in until it clicks into place.

The Duplex Reversal Unit is closed.

Important

❒ Attach the Duplex Reversal

Unit after closing the upper left cover of the printer.

ZDJP205J

ZDJP204J

Important

❒ Open the Duplex Reversal Unit

after detaching the 2 Tray Finisher from the printer. See p.1 “Detaching the SR770 (2 Tray Finisher)”.

Replacing the Toner Cartridge

WARNING:

• Do not incinerate spilled toner or used toner. Toner dust is flammable and might ignite when exposed to an open flame. Disposal should take place at an authorized dealer or an appropriate collection site. If you dispose of the used toner cartridges yourself, dispose of them according to local regulations.

CAUTION:

• Keep toner (used or unused) and the toner cartridge out of reach of children.

Note

❒ The actual number of printed pag-

es will differ depending on the paper type, size, contents and settings. For more information, see p.107 “Toner cartridge”.

If "Add Toner" appears on the panel display, replace the toner cartridge.

Note

❒ A combination of one to four

colors, yellow, magenta, cyan, black, is displayed in "XXX".

❒ If cyan or magenta or yellow toner

runs out, you can print in black and white mode using the black toner. Change the color mode setting to "Black and White" from the printer driver .

❒ If black toner runs out, printing is

not possible until the black toner cartridge is replaced.

While pushing the lock button on

AAAA

the upper right cover of the printer (AAAA), open the upper right cover (BBBB).

Add Toner XXX

Add Toner XXX/XXX

ZDJT006J

From the end, the toner cartridges are installed in the order of magenta (M), cyan (C), yellow (Y), and black (K).

Replacing Consumables and Maintenance Kit

Remove the toner cartridge for

BBBB

the color you want to replace.

Take out a new toner cartridge

CCCC

from the box.

A Unhook the green hook on the

toner cartridge with one hand.

ZDJT202J

ZDJT999J

B Holding the toner cartridge

with the other hand, pull out the cartridge up slowly.

Note

❒ The black toner cartridge con-

tains more than the other toner cartridges.

Shake the toner cartridge back

DDDD

and forth 5-6 times.

ZDJT201J

Important

ZDJT203J

❒ Do not shake the removed

toner cartridge. The remaining toner might scatter.

Note

❒ Depending on the setting up

environment, toner might be left in a toner cartridge. In such case, reinstall the toner cartridge.

Replacing the Toner Cartridge

Holding the toner cartridge with

EEEE

the metal contact area in front, attach in the direction of the arrow.

Important

❒ Do not touch the metal contact

point with your fingers.

Insert the toner cartridge slowly

FFFF

until the green hook snaps on the metal contact area.

ZDJT004J

Close the upper right cover.

GGGG

The following message appears on the panel display. Please wait a while.

Loading Toner...

Important

❒ Do not turn off the power

switch during "Loading Toner..." appears on the panel display to avoid a printer malfunction.

ZDJH042J

ZDJT005J

Important

❒ Do not install and remove the

toner cartridges over and over. This could result in a toner leak.

Replacing Consumables and Maintenance Kit

Replacing the Fuser Oil Unit

CAUTION:

• The Fusing Unit becomes very hot. When installing the new Fuser Oil Unit, turn off the printer and wait about an hour. After that, install the new Fusing Unit. Not waiting for the unit to cool down can result in a burn.

If "Replace Fuser Oil Unit (TypeG)" appears on the panel display, replace the Fuser Oil Unit.

Replace Fuser Oil Unit (TypeG)

Turn off the power switch and

AAAA

unplug the power cable.

Important

❒ Be sure to wait about an hour to

prevent a burn.

If 2 Tray Finisher is installed, de-

BBBB

tach it from the printer.

Reference

See p.1 “Detaching the SR770 (2 Tray Finisher)”

If the Duplex Unit is installed,

CCCC

open the Duplex Reversal Unit.

If the External Tray is attached to

DDDD

the printer, raise it in the direction of the arrow (AAAA), and remove it (BBBB).

Pull out the left cover of the print-

EEEE

er slowly.

Open the upper left cover.

FFFF

ZDJP038J

ZDJH047J

Reference

See p.2 “Opening and Closing the Duplex Reversal Unit”

ZDJH048J

Replacing the Fuser Oil Unit

Holding the green handle, pull

GGGG

up the Fusing Unit slowly in the direction of the arrow.

Important

❒ Do not touch any areas other

than the handle.

Put the removed Fusing Unit in a

HHHH

stable and level place.

Lift the Fuser Oil Unit in the di-

IIII

rection of the arrow to remove it, and put it in a stable and level place.

ZDJH208J

ZDJH052E

Take out the Fuser Oil Unit from

JJJJ

the bag, and remove seal (AAAA), and then remove seal (BBBB) as shown in the illustration.

Note

❒ Be sure to remove seal (A), and

then pull it out in a level manner.

Important

❒ Be sure to remove the seals to

avoid printer malfunction.

❒ Be sure to remove seal (A) first,

and then remove seal (B) to avoid oil leak.

❒ Be sure to put the Fuser Oil Unit

in a stable and level place to avoid oil leak.

❒ There is oil on the removed

seals and fuser oil roller. Be careful not to let them come in contact with your clothes.

ZDJH053J

Important

❒ Do not touch inside of the Fus-

ing Unit.

❒ Be careful no to touch the area

other than the shown in the illustration.

Replacing Consumables and Maintenance Kit

Match (UUUU) on the front of the Fus-

KKKK

er Oil Unit and the arrow on the Fusing Unit as shown in the illustration.

ZDJH055J

Important

❒ Be careful not to get oil on the

metal point of the left side of the Fuser Oil Unit.

Insert the left and right protru-

LLLL

sions of the Fuser Oil Unit into the white holders of the Fusing Unit (AAAA), and then move the Fuser Oil Unit in the direction shown by the arrow (BBBB) to attach the Fuser Oil Unit to the Fusing Unit.

Holding the green handle with

MMMM

one hand, use your other hand to push the front area of the handle to create a slight slant, and push the Fusing Unit slowly to the back.

Note

❒ Confirm that the Fuser Oil Unit

is facing the inside of the printer.

At this point, make sure the Fusing Unit is on the stand properly.

Close the upper left cover (AAAA) and

NNNN

push the handle slowly (BBBB) to the back until it clicks into place.

ZDJH050E

ZDJH054J

Place the old Fuser Oil Unit into

OOOO

the bag which contained the new Fuser Oil Unit, and seal the bag.

ZDJH051J

If you removed the External Tray

PPPP

in step Insert the hooks of the External Tray into the printer slits, and lower it toward you.

If the Duplex Unit is installed,

QQQQ

close the Duplex Reversal Unit.

If the 2 Tray Finisher was in-

RRRR

stalled, reattach the 2 Tray Finisher to the printer.

, reattach it to the printer.

DDDD

Reference

See p.2 “Opening and Closing the Duplex Reversal Unit”

Replacing the Fuser Oil Unit

ZDJH010J

Reference

See p.1 “Detaching the SR770 (2 Tray Finisher)”

Plug in the power cable and turn

SSSS

on the power switch.

Note

❒ If you dispose of the used toner

cartridges by yourself, dispose of them according to local regulations.

Replacing Consumables and Maintenance Kit

Replacing the Photoconductor Unit

If "Replace Black PCU (Type F)" ap-

pears on the panel display, replace the black Photoconductor Unit.

Take out the green screwdriver.

CCCC

Use this screwdriver for all attachment and detachment of screws.

Replace Black PCU (Type F)

If "Replace Color PCU (Type A)" appears on the panel display, replace the three color Photoconductor Units.

Replace Color PCU (Type A)

ZDJH013J

Turn off the power switch and

AAAA

unplug the power cable.

Open the front cover slowly by

BBBB

pulling down from the two areas on the left and right.

Turn the light brown lever coun-

DDDD

terclockwise.

ZDJH014E

ZDJH007J

Loosen two screws that are fasten-

EEEE

ing the inner cover using provided screwdriver.

You cannot remove these two screws.

ZDJH015J

Replacing the Photoconductor Unit

Lift the inner cover until it clicks

FFFF

into place and holds.

The Photoconductor Units are installed as shown in the illustration. The black Photoconductor Unit is at the upper left period. The other three are color Photoconductor Units.

ZDJH016J

Remove the Photoconductor Unit

GGGG

you want to replace.

For black, remove the upper left one, and for color, remove the three on the right.

A Move the green hook slowly to

the right as shown in the illustration. The green hook is located on the upper right of the Photoconductor Unit.

B Grip the green areas at the top

and bottom of the Photoconductor Unit, and pull slowly until you can see all of the green handle.

ZDJX701J

ZDJH045J

ZDJH211J

Important

❒ Pulling out the Photoconduc-

tor Unit quickly might cause it to drop.

Replacing Consumables and Maintenance Kit

C Lift and hold the green handle

at the top (AAAA), and pull out the unit slowly (BBBB).

B Place the Photoconductor Unit,

and remove the adhesive tape at the tip of the unit.

ZDJH222J

ZDJH223J

Install a new Photoconductor

HHHH

Unit.

For black, install one, and for color, install three.

A Take the unit out from the bag.

ZDJH210J

C Match the green arrow at the

tip of the Photoconductor Unit to the rail inside the printer.

ZDJH221J

Important

❒ Do not remove the cover that

is attached to the bottom of the Photoconductor Unit at this time.

Important

❒ Make sure the green arrow

fits securely on the rail before proceeding to the next step.

D Push the front of the Photocon-

ductor Unit slowly, slide the unit on the cover, and push in until it stops.

ZDJH224J

Replacing the Photoconductor Unit

Important

❒ If you do not attach the green

arrow of the Photoconductor Unit securely to the rail, you might damage the Photoconductor Unit.

❒ Do not touch the light-sensi-

tive area of the Photoconductor Unit.

E Remove the cover and push in

the Photoconductor Unit until it stops.

Lower the inner cover slowly.

IIII

ZDJX702E

Tighten two screws using provid-

JJJJ

ed screwdriver.

Note

❒ Be sure to return the provided

screwdriver to its original position on the back of the front cover.

Turn the light brown lever clock-

KKKK

wise.

ZDJH019J

ZDJH018J

Close the front cover slowly by

LLLL

pushing the two areas on the left and right.

ZDJH020E

ZDJH041J

Replacing Consumables and Maintenance Kit

Plug in the power cable and turn

MMMM

on the power switch.

The following message appears on

the panel display. The printer starts calibration. Please wait until it stops.

Calibrating...

Important

❒ Do not turn off the power

switch during calibration to avoid a printer malfunction.

Replacing the Development Unit

If "Replace Black Dev. Unit(TypeD)" appears on the panel display, replace the black Development Unit.

Replace Black Dev. Unit(TypeD)

If "Replace Color Dev. Unit(TypeB)" appears on the panel display, replace the three color (CMY) Development Units.

Replace Color Dev. Unit(TypeB)

Note

❒ A dustproof filter is attached to the

black Development Unit. When replacing the black Development Unit, also replace the dustproof filter. See p.24 “Replacing the Dustproof Filter”.

❒ When replacing the black Devel-

opment Unit, clean the registration roller. See p.32 “Cleaning the Registration Roller”.

Turn off the power switch and

AAAA

unplug the power cable.

Open the front cover slowly by

BBBB

pulling down from the two areas on the left and right.

Take out the green screwdriver.

CCCC

Use this screwdriver for all attachment and detachment of screws.

Turn the light brown lever coun-

DDDD

terclockwise.

Loosen two screws that are fasten-

EEEE

ing the inner cover using provided screwdriver.

ZDJH013J

ZDJH014E

ZDJH007J

ZDJH015J

You cannot remove these two screws.

Replacing Consumables and Maintenance Kit

Lift the inner cover until it clicks

FFFF

into place and holds.

Important

❒ Pulling out the Development

Unit quickly might cause it to drop.

B Hold the right side of the De-

velopment Unit with your right hand, and pull out the unit slowly.

ZDJH016J

The Development Unit is installed shown in the illustration. Starting from the upper left, the units are attached in the order of black (K), yellow (Y), cyan (C), and magenta (M).

Important

ZDJH993J

❒ Be careful not to touch the

right side of the Photoconductor Unit.

❒ Be careful not to let it get in

contact with your hands or clothes.

Remove the Development Unit.

GGGG

The procedure for removing the unit is the same for all four colors.

A Hook your finger on the green

tab in front of the Development Unit you want to replace, and pull it out halfway.

ZDJH046J

ZDJH225J

Install a new Development Unit.

HHHH

The procedure for attaching the Development Unit is the same for all four colors.

A Take the unit out from the bag.

ZDJH226J

Replacing the Development Unit

B Insert the Development Unit

along the rail, and push in slowly until it stops.

ZDJH227E

C Holding the Development

Unit, pull out the tape slowly in a level manner.

ZDJH039J

Important

❒ Be sure to pull out the tape to

avoid printer malfunction during operation.

❒ The removed tape is dirty. Be

careful not to let it get in contact with your hands or clothes.

Lower the inner cover slowly.

IIII

Tighten two screws using provid-

JJJJ

ed screwdriver.

Note

❒ Be sure to return the provided

screwdriver to its original position on the inside of the front cover.

Turn the light brown lever clock-

KKKK

wise.

ZDJH018J

ZDJH019J

ZDJH020E

Replacing Consumables and Maintenance Kit

Close the front cover slowly by

LLLL

pushing the two areas on the left and right.

ZDJH041J

Plug in the power cable and turn

MMMM

on the power switch.

"Please Wait " appears on the panel display, and initial adjustments begin. Please wait until it stops.

Please Wait

Important

❒ Do not turn off the power

switch during adjustments to avoid a printer malfunction.

Replacing the Fusing Unit

CAUTION:

• The Fusing Unit becomes very hot. When installing the new Fusing Unit, turn off the printer and wait about an hour. After that, install the new Fusing Unit. Not waiting for the unit to cool down can result in a burn.

If "Replace Fusing Unit (Type C)" appears on the panel display, replace the Fusing Unit.

Replace Fusing Unit (Type C)

Turn off the power switch and

AAAA

unplug the power cable.

Important

❒ Be sure to wait about an hour to

prevent a burn.

If the 2 Tray Finisher is installed,

BBBB

detach it from the printer.

Reference

See p.1 “Detaching the SR770 (2 Tray Finisher)”

If the Duplex Unit is installed,

CCCC

open the Duplex Reversal Unit.

If the External Tray is attached to

DDDD

the printer, raise it in the direction of the arrow (AAAA), and remove it (BBBB).

Pull out the left cover of the print-

EEEE

er.

Open the upper left cover.

FFFF

ZDJP038J

ZDJH047J

Reference

See p.2 “Opening and Closing the Duplex Reversal Unit”

ZDJH048J

Important

❒ Do not touch any areas other

than the handle.

Replacing Consumables and Maintenance Kit

Holding the green handle, pull

GGGG

up the Fusing Unit slowly in the direction of the arrow, and then put it in a stable and level place.

Match (UUUU) on the front of the Fus-

JJJJ

er Oil Unit and the arrow on the Fusing Unit as shown in the illustration.

ZDJH055J

Take out the new Fusing Unit

HHHH

from the bag and put it in a stable and level place.

Important

❒ The A3 paper which comes with

the new Fusing Unit will be used in a later step ful not to lose it.

❒ Do not turn the blue dial at the

side of the new fusing unit when replacing it or before turning on the power switch.

, so be care-

ZDJH208J

Important

❒ Be careful not to get oil on the

metal point of the left side of the Fuser Oil Unit.

Insert the left and right protru-

KKKK

Remove the Fuser Oil Unit in the

IIII

direction of the arrow.

Important

❒ Do not touch inside of the Fus-

ing Unit.

❒ Be careful not to touch the oil.

ZDJH052E

Put the removed Fuser Oil Unit in

LLLL

the bag that enclosed the new Fusing Unit, and then seal it.

ZDJH054J

+ 94 hidden pages

Ricoh AP3800C User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Trademarks

Safety Information

Safety During Operation

ENERGY STAR Program

How to Read This Manual

TABLE OF CONTENTS

Detaching the SR770 (2 Tray Finisher)

Opening and Closing the Duplex Reversal Unit

Replacing the Toner Cartridge

Replacing the Fuser Oil Unit

Replacing the Photoconductor Unit

Replacing the Development Unit

Replacing the Fusing Unit
