Ricoh A724 Modification Bulletin XJ170R
MODIFICATION BULLETIN NO. 1 PAGE 1 OF 4
ISSUED ON: November 30, ’95
Model Fiery XJ Series (XJ170R) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts Catalog Correction
Modification
Please correct your parts catalog as follows.
1. The following parts are newly registered as service part s.
New P/N Description Q’ty Used
A724 5061 Power Switch 1 21 3
A724 5062 XJ Chassis Cover 1 23 3
A724 5063 Top/Base Cover 1 24 3
A724 5064 XJ Stand 1 25 3
A724 5065 Front Bezel 1 26 3
Parts Catalog
Index No. Page
Date of
Modification
Serial Number
A724 5066 XJ 170 Jewel 1 28 3
A724 5067 Fiery Jewel 1 27 3
A724 5076 PAPST Multifan 4312M 1 22 3
A724 5083 Media Pack - English 1 29 3
A724 5089 User Manual - English 1 30 3
A724 5102 User Manual - French 1 30 3
A724 5108 User Manual - German 1 30 3
A724 5090 Networking Guide - English 1 31 3
A724 5103 Networking Guide - French 1 31 3
ISSUED ON: November 30, ’95
MODIFICATION BULLETIN NO. 1 PAGE 2 OF 4
New P/N Description Q’ty Used
A724 5109 Networking Guide - German 1 31 3
A724 5091 Color Printing Guide - English 1 32 3
A724 5104 Color Printing Guide - French 1 32 3
A724 5110 Color Printing Guide - German 1 32 3
A724 5143 Mother Board Fuse (2pcs/set) 1 33 3
A724 5081 Disk Pack User S/W & Adobe Driver (Mac/Win) 1 34 3
A724 5099 Disk Pack User S/W & Adobe Driver (Mac/Win) - French 1 34 3
A724 5105 Disk Pack User S/W & Adobe Driver (Mac/Win) - German 1 34 3
2. Please correct the description of the following parts.
Incorrect Correct
P/N Description Index No. P/N Description Index No.
Parts Catalog
Index No. Page
A583 6010 Power Supply Cord - UK 12 A583 6010 Power Supply Cord - International 12
A583 6011 Power Supply Cord - International 12 A583 6011 Power Supply Cord - UK 12
ISSUED ON: November 30, ’95
MODIFICATION BULLETIN NO. 1 PAGE 3 OF 4
3. The following parts have become RMA pa rts.
Incorrect Correct
P/N Description Index No. P/N Description Index No.
A724 5093 1GB SCSI HDD W/O S/W 6 A724 5093 1GB SCSI HDD W/O S/W #6
A724 5094 2GB SCSI HDD W/O S/W 6 A724 5094 2GB SCSI HDD W/O S/W #6
A724 5078 Video Interface Harness 14 A724 5078 Video Interface Harness #14
M. Iwasa, Manager
Technical Support Department
ISSUED ON: November 30, ’95
MODIFICATION BULLETIN NO. 1 PAGE 4 OF 4
MOdel Name V/Hz Destination Code Serial Number
Fiery XJ170R 115V/60Hz USA A724-05 B
Fiery XJ170R 230V/50Hz Europe, etc. A724-06 B
Fiery XJ300R 115V/60Hz USA A724-08 B
Fiery XJ300R 230V/50Hz Europe, etc. A724-09 B
XJR1 Conversion Kit 115V/230V USA/Europe,etc. A724-12 –
MODIFICATION BULLETIN NO. 2 PAGE 1 OF 2
ISSUED ON: November 30, ’95
Model Fiery XJ Sereis (XJ170R) Volt/Hz
Modified Article Motherboard
Reason for
To accomodate a new feature in the future
Modification
Date of
Modification
To accomodate a new feature expected with the future system software release, the mot he rbo ard has been changed.
Inter-
Old P/N New P/N Description Q’ty Used
A724 5068 A724 5142 Motherboard W/O SIMMS 1® 1O/O 1 3
change-
ability
Parts Catalog
Index No. Page
Serial Number
M. Iwasa, Manager
Technical Support Department
