Page 1
MODIFICATION BULLETIN NO. 2 Page 1 of 2 ISSUED ON: March 15, ’92
Model Paper Bank for NC11 Volt/Hz
Modified Article See below
Reason for
Due to parts standardization with other model
Modification
Date of
Modification
Due to parts standardization with other model, the following parts have been modified.
Old P/N New P/N Description Q’ty Interchangeability
Index No. Page
A4644271 A3424271 Rear Cover 1 → 1 O/O 9 1 - 3 Ricoh version
A4644277 A3424277 Rear Cover 1 → 1 O/O 9 1 - 3 HCS version
A4644241 A3424241 Right Cover 1 → 1 O/O 10 1 - 3 Ricoh version
A4644247 A3424247 Right Cover 1 → 1 O/O 10 1 - 3 HCS version
54472676 AB042004 Output Hub 1 → 1 O/O 47 1 - 5 All
A0302711 A0722611 Paper Feed Stay 1 → 1 O/O 61 1 - 5 All
Parts Catalog
Serial Number
Destination
A4642925 A4642929 Rear Cassette Holder 1 → 1 O/O 14 1 - 7 Ricoh version
A4642921 A4642924 Front Cassette Holder 1 → 1 O/O 15 1 - 7 Ricoh version
T. Ito, Manager
Copier Technical Support
Page 2
MODIFICATION BULLETIN NO. 2 Page 2 of 2 ISSUED ON: March 15, ’92
MODEL NAME
PS 130 115/60 USA, CANADA A464-01
PS130 220, 240/50 EUROPE, etc. A464-02
EUC 240 220, 240/50 EUROPE, etc. A464-05
EUC 240 115/60 USA, CANADA A464-06
CT 1 220, 240/50 EUROPE A464-07
V/Hz DESTINATION CODE SERIAL NUMBER
Page 3
MODIFICATION BULLETIN NO. 3 Page 1 of 2 ISSUED ON: September 15, ’92
Model Paper Bank for NC11 Volt/Hz
Modified Article Bushing
Reason for
Due to parts standardization with other model
Modification
Due to parts standardization with other model, paper feed roller bushing has been modified.
Old P/N New P/N Description Q’ty Interchangeability
Index No. Page
AA083004 52052865 One - way Clutch - Feed
1 → 1
O/O 36 1 - 5
Parts Catalog
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
Page 4
MODIFICATION BULLETIN NO. 3 Page 2 of 2 ISSUED ON: September 15, ’92
MODEL NAME
PS 130 115/60 USA, CANADA A464-01
PS130 220, 240/50 EUROPE, etc. A464-02
EUC 240 220, 240/50 EUROPE, etc. A464-05
EUC 240 115/60 USA, CANADA A464-06
CT 1 220, 240/50 EUROPE A464-07
V/Hz DESTINATION CODE SERIAL NUMBER
Page 5
MODIFICATION BULLETIN NO. 4 PAGE 1 OF 2
ISSUED ON:January 15, ’94
Model Paper Bank for NC11 Volt/Hz
Modified Article Door Hinges
Reason for
Parts standardization
Modification
Due to parts standardization with other mo del, th e followin g parts have been modif ied .
Inter-
Old P/N New P/N Description Q’ty Used
A4644173 A4644168 Right Lower Hinge
A4644171 A4644165 Left Lower Hinge
1 → 1
1 → 1
change-
ability
O/O 26 3
O/O 28 3
Date of
Modification
Parts Catalog
Index No. Page
Serial Number
S. Hamano, Assistant General Manager
Technical Support Department
Page 6
MODIFICATION BULLETIN NO. 4 PAGE 2 OF 2
ISSUED ON: January 15, ’94
MODEL NAME
PS 130 115/60 USA, CANADA A464-01
PS130 220, 240/50 EUROPE, etc. A464-02
EUC 240 220, 240/50 EUROPE, etc. A464-05
EUC 240 115/60 USA, CANADA A464-06
CT 1 220, 240/50 EURIPE A464-07
V/Hz DESTINATION CODE SERIAL NUMBER
