Ricoh A458 Modification Bulletin F5SRT
MODIFICATION BULLETIN NO. 1 Page 1 of 3 ISSUED ON: June 30, ’92
Model F5 Sorter (NRG S251) Volt/Hz
Modified Article Parts Catalog A458 - 22
Reason for
Parts catalog correction
Modification
Correct your parts catalog as follows:
Page 5
Correct the part number as follows:
Index Incorrect P/N Correct P/N Description
108 12041151 Microswitch
12042278 Microswitch - DD2L-F7AA
Page 7
Correct the part number as follows:
Date of
Modification
Serial Number
Index Incorrect P/N Correct P/N Description
107 03130250B Philips Pan Head Screw - M3 x 25
Page 11
Correct the part number as follows:
Index Incorrect P/N Correct P/N Description
20 A4585630 A4585640 Main Control Board
03130300B Philips Pan Head Screw - M3 x 30
DETAILS OF MODIFICATION
Page 17
1. Correct the part number as follows:
Index Incorrect P/N Correct P/N Description
* A4585630 A4585640 Main Control Board
2. Add the following to the parts list.
Index Part Number Description Q’ty
2 59375604 IC - SI-3242P 1
Page 19
1. Delete the following from the parts list.
MODIFICATION BULLETIN NO. 1 Page 2 of 3 ISSUED ON: June 30, ’92
Index Correct P/N Description
112 11021408 Connector - 1P
2. Correct the part numbers as follows:
Index Incorrect P/N Correct P/N Description
105 11001169 11001639 Fastening Receptacle
116 11021691 11025875 Connector - 3P
