MODIFICATION BULLETIN NO. 5 Page 1 of 2 ISSUED ON: Oct. 31, ’90
Model ARDF for COSMOS - 1 Volt/Hz
Modified Article Original Stopper Bracket
Reason for
Parts standardization
Modification
To standardization the 115/220, 240V version machines with 100V version machine, the original stoppe r bracket
shown in the figure has been cahnged.
Old P/N New P/N Description Q’ty Interchangeability Index No. Page
A4371198 A4371170 Original Stopper Bracket 1 ---- 1 X/O 17 3
A4371171 Decal - Original Stopper 0 ---- 1 *57 3
Modification
* New Index
Date of
Serial Number
17
*59
T.Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 5 Page 2 of 2 ISSUED ON: Oct. 31, ’90
MODEL NAME
RICOH ARDF53 115/60 USA, CANADA A437 - 17 226010XXXX
INFOTEC ARDF5020 220,240/50 EUROPE A437 - 26 373100XXXX
RICOH ARDF53 220,240/50 EUROPE etc. A437 - 27 2260100001
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 6 Page 1 of 2 ISSUED ON: April 15 , ’91
Model ARDF for COSMOS-1 Volt/Hz
Modified Article Side Roller
Reason for
Parts standardization with other model
Modification
Due to parts standardization with other model, the side roller has been changed. The
interchangeability is O/O.
Old P/N New P/N Description Q’ty Index Page
A4221090 A3181090 Side Roller 2 46 5
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 6 Page 2 of 2 ISSUED ON: April 15 , ’91
MODEL NAME
Ricoh ARDF52 115/60 USA, Canada A437-17 236104XXXX
INFOTEC ARDF5020 220,240/50 Europe A437-26 373041XXXX
Ricoh DF52 220,240/50 Europe, etc. A437-27 226104XXXX
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 7 Page 1 of 3 ISSUED ON: September 30, ’91
Model ADRF for COSMOS1 Volt/Hz
Modified Article Friction Belt and Friction Roller
Reason for
To ensure separation
Modification
Draw
No.
Old Parts
No.
A4221354 A4971170 Firiction belt 1 → 1 X/O 69 5
A4221069 Friction Roller 1 → 0 72 5
New Parts
No.
Description
Modification
A.B.C.
Rank Part No. Description
Q’ty Used
Old → New
Inter-
change-
ability
Part needed for replacement by new part Parts Catalog
Date of
Serial Number
Index
No.
Page
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for replacement by new part" to
install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether the new part can be used
in the old machine. x = Not interchangeable o = Interchangeable
MODIFICATION BULLETIN NO. 7 Page 2 of 3 ISSUED ON: September 30, ’91
DETAILS OF MODIFICATION
To ensure the original separation, we found that it is more effective to increase the angle ( θ) as shown.
These are the modifications on production machines to change the angle from θ1 to θ2 :
1. The friction roller has been removed.
2. The mylar on the friction belt has been removed.
3. The dimension of the friction belt has been changed.
Friction Roller
60
Friction Belt
Old
θ2 > θ
θ
1
Mylar
58.5
Friction Belt
θ
2
New
1
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 7 Page 3 of 3 ISSUED ON: September 30, ’91
MODEL NAME
Ricoh ARDF52 115/60 USA, Canada A437-17 236108XXXX
INFOTEC ARDF5020 220,240/50 Europe A437-26 373041XXXX
Ricoh ARDF52 220,240/50 Europe, etc. A437-27 226108XXXX
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 8 Page 1 of 2 ISSUED ON: April 15, ’91
Model ARDF for COSMOS 1 Volt/Hz
Modified Article Harness - Pulse Generator
Reason for
Part standardization with other ARDF
Modification
Due to part standardization with other ARDF, the Harness - Pulse Generator has been changed. The
new Harness - Pulse Generator is an assembly of a relay harness and a grounding wire. The
interchangeability is X/O.
Old P/N New P/N Description Q’ty Used Interchangeability Index No. Page
A4225202 A4975202 Harness Pulse Generator
A4225212 ------
1 → 1
X/O
1 → 0
Modification
10 5
88 5
Date of
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 8 Page 2 of 2 ISSUED ON: April 15, ’91
MODEL NAME
Ricoh ARDF53 115/60 USA, Canada A437-17 2261090001
INFOTEC ARDF5020 220,240/50 Europe A437-26 373042XXXX
Ricoh DF53 220,240/50 Europe, etc. A437-27 226204XXXX
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 9 Page 1 of 2 ISSUED ON: September 15, ’92
Model ARDF for Cosmos - 1 Volt/Hz
Modified Article Mounting Bracket
Reason for
Parts standardization
Modification
For the purpose of parts standardization, Mounting Bracket has been changed.
Old P/N New P/N Description Q’ty Used Interchangeability
A4371183 A3381183 Mounting Bracket
1 → 1
O/O 12 3
Parts catalog
Index No. Page
Date of
Modification
Serial Number
T. Ito, Manager
Copier Technical Support
MODIFICATION BULLETIN NO. 9 Page 2 of 2 ISSUED ON: September 15, ’92
MODEL NAME
Ricoh ARDF52 115/60 USA, Canada A437-17
INFOTEC ARDF5020 220,240/50 Europe A437-26
Ricoh DF52 220,240/50 Europe, etc. A437-27
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 10 PAGE 1 OF 2
ISSUED ON: December 31, ’93
Model ARDF for Cosmos - 1 Volt/Hz
Modified Article Original Table
Reason for
To improve durability of the original table
Modification
Old P/N New P/N Description Q’ty Used Interchangeability
A4371321 A4371603 Original Table 1 → 1O/O 4 3
Date of
Modification
Parts Catalog
Index No. Page
Serial Number
S. Hamano, Assistant General Manager
Technical Support Department
MODIFICATION BULLETIN NO. 10 PAGE 2 OF 2
ISSUED ON: December 31, ’93
MODEL NAME
Ricoh ARDF53 115/60 USA, Canada A437-17 2263030001
INFOTEC ARDF5020 220,240/50 Europe A437-26 Service Part Only
Ricoh DF53 220,240/50 Europe, etc. A437-27 2263090001
V/Hz DESTINATION CODE SERIAL NUMBER
S. Hamano, Assistant General Manager
Technical Support Department
MODIFICATION BULLETIN NO. 11 PAGE 1 OF 2
ISSUED ON: December 31, ’93
Model ARDF for Cosmos - 1 Volt/Hz
Modified Article Photocoupler
Reason for
Due to vendor change
Modification
Due to vendor change, th e fo llowing part has been changed. The interchangeability is O/O.
Parts Catalog
Old P/N New P/N Description
Page Index No.
9 119 14030388 Photocoupler - ON3111
9 119 14030784 Photocoupler - ON3131
Date of
Modification
Serial Number
MODIFICATION BULLETIN NO. 11 PAGE 2 OF 2
ISSUED ON: December 31, ’93
MODEL NAME
Ricoh ARDF53 115/60 USA, Canada A437-17
INFOTEC ARDF5020 220,240/50 Europe A437-26
Ricoh DF53 220,240/50 Europe, etc. A437-27
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 12 PAGE 1 OF 2
ISSUED ON: December 31, ’93
Model ARDF for Cosmos - 1 Volt/Hz
Modified Article Main Board Cover & Feed-out Motor Cover
Reason for
To standardize with other model
Modification
Inter-
Old P/N New P/N Description Q’ty Used
A4221183 A4221475 Main Board Cover 1 → 1O/O 51 3
A4371184 A4371161 Feed-out Motor Cover 1 → 1O/O 46 3
A4221210 A4972090 Inverter Roller 1 → 1O/O 38 7
change-
ability
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
S. Hamano, Assistant General Manager
Technical Support Department
MODIFICATION BULLETIN NO. 12 PAGE 2 OF 2
ISSUED ON: December 31, ’93
MODEL NAME
Ricoh ARDF53 115/60 USA, Canada A437-17
INFOTEC ARDF5020 220,240/50 Europe A437-26
Ricoh DF53 220,240/50 Europe, etc. A437-27
V/Hz DESTINATION CODE SERIAL NUMBER
MODIFICATION BULLETIN NO. 13 PAGE 1 OF 5
ISSUED ON: January 15, ’94
Model ARDF for COSMOS 1 Volt/Hz
Modified Article Friction Belt
Draw
No.
Reason for
Modification
Old Parts
No.
A4221352 A4221360 Friction Belt Holder
A4971170 A4221358 Friction Belt
A4221003 A4971034 Feed Roller
To standardize with other model, and the original separation can be improved by this
modification
New Parts
A4971024 Guide Mylar
No.
Description Rank
Q’ty Used
Old→New
1 → 1
1 → 1
1 → 1
0 → 1
Date of
Modification
Inter-
change-
ability
X/X 68 5
X/X as a set X/O 69 5
X/X 47 5
Parts needed for replacement by new part
Part No. Description No. Page
* New Index No.
Serial
Number
Parts
Catalog
* 96 5
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
MODIFICATION BULLETIN NO. 13 PAGE 2 OF 5
DETAILS OF MODIFICATION
To improve the original separation, the following parts have been modified.
1. Friction Belt Holder : The conf iguration of the friction belt hold er ha s bee n chang ed as shown .
ISSUED ON: January 15, ’94
Old
2. Friction Belt : The conf igu ration of the belt has been changed and a mylar has been added to impro ve feed ing of th e
original.
Old
New
Mylar (This mylar has no parts number)
New
MODIFICATION BULLETIN NO. 13 PAGE 3 OF 5
DETAILS OF MODIFICATION
3. Original Feed Roller : To impro ve fe ed ing of the orig ina l, th e gro ove has been added to the feed roller.
ISSUED ON: January 15, ’94
Old
Flat
Groove
New
Guide Mylar
Guide Mylar
MODIFICATION BULLETIN NO. 13 PAGE 4 OF 5
DETAILS OF MODIFICATION
4. Guide Myla r: A gu ide myla r has be en added to th e original guide to improve fee ding of the original.
ISSUED ON: January 15, ’94
Old
Original Guide
125
Original Guide
Original
Feed Roller
New
125
100
S. Hamano, Assistant General Manager
Technical Support Department
MODIFICATION BULLETIN NO. 13 PAGE 5 OF 5
ISSUED ON: January 15, ’94
MODEL NAME
Ricoh ARDF53 115/60 USA, Canada A437-17 2363030001
INFOTEC ARDF5020 220,240/50 Europe A437-26 Service Part Only
Ricoh DF53 220,240/50 Europe, etc. A437-27 2263090001
V/Hz DESTINATION CODE SERIAL NUMBER
